LeMaitre TINY-FOGGER User manual

1
Operating manual
TINY-FOGGER
New version

3
Thank you for purchasing this TINY-FOGGER.
As you will notice from the table of contents, the manual for your new gadget is
quite extensive.
To guarantee perfect and successful work with this machine, please take some
time to read the manual carefully.
And finally we wish you a lot of fun when using your new TINY-FOGGER.

4
Set of Equipment supplied
– 1 TINY-FOGGER with connected battery cable
– 1 control panel with cable
– 1 rechargeable battery 12V / 2 Ah
– 1 charger
– 1 fluid tank (50 milliliters) with quick connector and air valve
– 1 bottle of fluid (250 milliliter)
– 4 T-Clips for connecting the fluid tubing and the control cable
When the order includes a radio remote, the following items are supplied
additionally:
– 1 receiver with stereo jack
– 1 radio remote
– 1 manual „Radio remote control“
Please check whether all the products you ordered are supplied.

5
Contents
1. Procedure of the TINY-FOGGER 6
2. Safety Instructions 7
3. Operating the TINY-FOGGER 8
3.1 Descriptions of the Parts
3.2 Selecting the Location
3.3 Mounting the TINY-FOGGER
3.4 Starting-up the TINY-FOGGER
3.5 Programming the fogging time
3.6 Status Display of the Battery
4. The rechargeable Battery 11
4.1 Capacity
4.2 Operating and Storing
4.3 Charging the Battery
4.4 Safety Instructions
4.5 Technical Data
5. The Charger 13
5.1 Operating the Charger
5.2 General Notes
5.3 Technical Data
6. Service and Maintenance 15
6.1 Changing the Vaporizer
6.1.1 Removal of the Vaporizer
6.1.2 Installation of the Vaporizer
6.1.3 Calibrating the Vaporizer
6.2 The machine does not work perfectly
6.2.1 There will be no fog if…
6.2.2 The yellow LED lights permanently if…
6.2.3 If the new vaporizer can‘t be calibrated…
7. Technical Data 18
8. Warranty Conditions 19

6
1. Procedure of the TINY-FOGGER
The TINY FOGGER is a battery-operated, microprocessor-controlled mini fog
generator. It is based (as are most fog generators) on the vaporizer principle, i.e.
a glycol fluid is evaporated and condenses into fog when leaving the fog nozzle.
However, the TINY-FOGGER only heats when fog is actually needed.
It uses only 20 milliamperes in idle status and consequently it may remain
connected to the the battery for several hours with no discharging to speak of.
When emitting fog a strong current of 5 to 6 AMP runs with peak levels of 12 to
13 AMP.
The following sequence produces fog:
a) Warming up (1 second, without pumping fluid).
b) The pump runs between 1 second and 2 minutes – depending on application.
c) Heat again (15 seconds without pumping any fluid).
During the phases a and c a new start of the fogging process is possible. Just
press the gray start/program button.

7
2. Safety Instructions
A fog machine is not a toy!
• Very hot steam escapes from the nozzle. Danger of getting burnt.
• Occasionally very hot droplets of fluid may escape when in operation.
Thus never aim at persons directly and keep a minimum distance of 3 m to the
nozzle.
• Never touch the nozzle when in operation. Danger of getting burnt.
• The location for the machine must be non-flammable, non-combustible and
not sensitive to heat. It has to be twice as big as the machine.
• Keep a minimum distance of 60 cm to all flammable, combustible objects and
objects sensitive to heat.
• Glycol is alcohol and burns with a slightly bluish, almost invisible flame. Never
point the fog at strong sources of ignition like fire or pyrotechnic effects.
• Never open the machine and leave the machine unattended when connected
to a power supply.
• The visibility has to be more than 2 m in rooms where people walk around.
• Only use the supplied TINY-FLUID. Different types of fluid do not generate the
fog you require and destroy your fog generator.
• Donotswallowthefogfluid.Keepitawayfromchildren.Incaseofeyecontact,
rinse with a lot of water. Consult a doctor should you have accidentally
swallowed some fluid.
• Spilled fluid or splashed fluid droplets can cause slip hazard. Mop up the fluid
and dispose of it according to regulations. TINY-FLUID is completely water-
soluble and biodegradable.
• Fog may activate smoke detectors.
Artificially-made fog can be produced in many different ways. The method
used here to produce fog, with a device which works according to the vaporizer
principle, is the most harmless one.
No case has so far been reported in which a sound human being has been
harmed because of using our device to produce artificial fog. However, this can
only be guaranteed if the professional fog generators are used accordingly, i.e.
at the correct vaporization temperatures as well as with the correctly mixed fog
fluid.
We, however, recommend: People with health problems or problems of the
respiratory tract or with an inclination for allergies should avoid any contact
with artificially-made fog.

8
3. Operating the TINY-FOGGER
3.1 Description of the Parts
(1) Air vents
(2) Fog nozzle
(3) Fluid tube
(4) Cable to remote
and battery
(5) Screws
3.2 Selecting the Location
The location for the TINY-FOGGER must
• be dry
• guarantee sufficient air supply
• have sufficient distance (at least 30 cm) from inflammable materials
• have very little vibration
• have an ambient operating temperature between 5°C and 45°C
• have a relative air humidity of less than 80%.
Start button Sockets for cable
for the control panel
and the radio remote

9
3. Operating the TINY-FOGGER
3.3 Mounting the TINY-FOGGER
3.4 Starting up
1) Pour the TINY-FLUID into the fluid bottle and firmly lock the bottle. Plug the
connecting spout of the fluid tubing into the quick connector of the fluid
bottle (audible click).
Check the cleanness of the connecting spout, so that no dirt (fluff etc.) can be
sucked in by the pump. Even the smallest impurity immediately leads to clog-
ging of the machine.
2) Plug the cable of the control panel or the cable of the radio remote (only, if
radio remote control was supplied)into the stereo jack socket at the machine
before you connect the TINY-FOGGER to the battery.
3) Connect battery cable to the battery.
4) Press start button at the control panel (black) briefly. After approx. 1 second
the unit generates fog according to the fogging time preset by the factory.
Caution:
The wires in the fog nozzle must not be damaged. Should these wires be
damaged, the unit will no longer work correctly when generating fog and the
vaporizer must be changed (see section 6.1).
If the Tiny-Fogger is to be built in props or similar, make sure that a fog-free air
supply is guaranteed. Too high a fog concentration can condense inside the
machine and can result in damages caused by moisture.
When installing the TINY-FOGGER make sure that
• no fog is passed back into the fog generator,
• no condensed fluid runs into the apparatus,
• the air vents (1) are not covered or concealed,
• no objects jut out into the fog nozzle (2) (danger of destruction of the fine
wires of the vaporizer).

10
3. Operating the TINY-FOGGER
3.5 Programming the fogging time
3.6 Battery Status Display
Theyellowlight-emittingdiode(LED)ontheTINY-FOGGER indicateshowstrong/
efficient the battery still is and/or when it must be recharged.
1) LED flashes slowly:
Battery capacity of 15% – 100 %,
the battery is fully operational.
2) LED flashes fast:
Battery capacity below 15% –
the battery should be changed and/or charged.
3) LED lights up permanently:
the battery is flat.
or: the Vaporizer is damaged (see point 6.1)
For some applications it will be useful to program in a fixed fog amount, which
canbeeasily reproducedlater. Toprogramafoggingduration,usethe blue button
[11] at the back of the machine.
The blue button must be pressed and held down until the desired fogging time
isachieved– then releaseit.Thisprogrammedfogamountcan then bereproduced
by briefly pressing the button on the control panel or the topmost button on the
receiver of the radio remote. You can reproduce the programmed fog amount in
this manner as often as you like. The programmed fogging duration will remain
in memory until you program a new one in the above manner.
Ifyou wish to control the foggingtime manually, with noprogrammed fogging
duration whatsoever, then press the blue button once briefly. Now the machine
will produce fog for as long as you press the button on the control panel or the
transmitter of the radio remote.
Socket for connecting
the cable of the control
panel or the receiver of
the radio remote (11)Switchfor programming
the fogging time and for
calibrating a new vaporizer
Yellow LED
(Battery status display)

11
4. The rechargeable battery
4.3 Charging the battery
4.1 Capacity
4.2 Operating and Storing
The supplied battery is a maintenance-free 12V lead-gel accumulator which is
calibratedin the best possible waywith the connected loadsof the TINY-FOGGER.
It can be used in every position.
The connection to the TINY-FOGGER or the charger is established by means of
a battery clip which also serves as protection against incorrect polarity.
The battery has a capacity of 2 Ah and is supplied in a charged status. A fully-
charged battery can generate more than 100 fog emissions of 4-5 seconds. The
permanent fogging time amounts to 10 minutes.
Whenusedcorrectly, the batteryholdsits capacity for several yearsand/or some
hundred charge/discharge cycles.
Lead-gel batteries are a very robust bank of capacitors which need little care
andmaintenance.However, theirworkinglifecan be shortenedrapidly by storing
them when discharged.
Caution: Do not store a discharged battery! As a result, it can lose a large part
of its capacity after two weeks!
Forcharging the batterypleaseuse thesuppliedautomaticcharger.A discharged
battery can be charged within 6-8 hours.
If the battery is discharged, the red LED on the charger will be alight.
If the battery is fully charged, the red LED on the charger will not be alight.

12
4. The rechargeable battery
4.4 Safety Regulations
4.5 Technical Data
Model PanasonicLC-TA122PUlead-gelbattery
Output voltage 12 V, 2.0 Ah/20 HR
Temperature range 5°C to 45°C
Dimensions 180 x 22 x 61 mm
Weight 650 g
• The supplied battery can supply high discharging currents. Therefore:
– Never short-circuit the battery.
– Never change the cable sizes.
• Positioning of the battery
– Make sure the battery is not placed near sources of heat,
– Should you place your battery near a source of heat, the performance of the
battery will decrease the more the temperature rises.
• Using the battery in closed units
– Don‘t use the battery in completely sealed casings or units.
– To prevent a blast of hydrogen leaking from the battery, the casings must be
ventilated.
• Dismantling the battery
– Don‘t dismantle batteries as they do contain electrolytes which may damage
clothing or hurt the skin. If the electrolyte comes in contact with skin or eyes,
immediately rinse with water or consult a doctor.
• Avoid short-circuits
– Do not short-circuit the battery: A short circuit of the battery causes very
high voltages which can damage the battery.
• Keep away from fire
– Do not expose the battery to fire or burn it. The battery might explode.

13
5. The Charger
5.1 Operation
5.2 General Notes
An automatic charger for 12 V lead-gel battery is supplied.
• Plug the charging set BCA 120-600 to a power socket
(220-230 V~/50Hz or 110 V~/50Hz).
• Connect the output line of the charger with the battery to be charged.
• Check whether the charge display (red LED) lights up.
• As soon as the red light on the charge display goes out the charging process is
completed.
• Disconnect the charger from the socket.
• Disconnect the battery from the charger.
1) Ifthe chargedisplay does not light up after connectingit to the battery, check
the following points:
• quality of the connections (possible oxidation of the battery ends)
• state of the battery (a stored, uncharged battery may become sulfated and
can not hold a charge)
2) If the control display lights up permanently, this might indicate probable
battery problems:
• short circuit within the battery or in the output lines
• incorrect Polarity of the connected battery if the red LED is permanently on.
•the batteryvoltagecannot reach13,8V(especially inthecaseof oldbatteries)
3) Protect the unit against rain
4) Use the charger exclusively for charging the TINY-FOGGER battery

14
5. The Charger
5.3 Technical Data
Model BCA 120-600
Input voltage 230 V~ or 110 V~/50 Hz +/– 10%
Output voltage 12 V =/600 mA
End of charging at 13,8 V =
Temperature range –10°C to +35°C
Isnsulation 4 kV between primary and second
Setting regulated at 13,8 V preset
Class of Insulation IP 40
Protection class II
Case material Noryl SE 1
Dimensions 80 x 56 x 46 mm
Display LED red (charging display) goes out at
a charging current of < 60 mA
Weight 0.5 kg

15
6. Service and Maintenance
(6) Pump cable
(8) Fluid
tubing
(9)
Tubing
spout
(7) Vaporizer
(10) Male
connector strip
Connectors for
pumping cable
6.1 Changing the Vaporizer
The micro vaporizer especially developed for the TINY-FOGGER has a limited
working life. Depending on application duration, you can achieve between 2,000
and 5,000 fogging cycles. After these the fogging performance declines con-
siderably and the vaporizer must be changed.
6.1.1 Removal of the Vaporizer
• Separate the TINY-FOGGER from the battery (take off the battery clip),
• Unscrew the two screws (5) with a suitable screwdriver (No. 1. Phillips),
• Take off the casing cover,
• Unplug the connector for pump cable (6),
• Now you can slide out the vaporizer (7) upwards,
• Remove the blue fluid tubing (8) from tubing spout (9) of the vaporizer. In
case the tubing does not come off, you can pull it down with a pair of pliers or
a similar tool,
• Clean the interior of the unit with an absorbant, fluff-free cloth.

16
6. Service and Maintenance
6.1.2 Installation of the Vaporizer
• Connect the machine to the battery, press the blue button [11] at the back of
the machine once and disconnect the machine from the battery
• Plug the blue fluid tubing (8) onto tubing spout (9) of the new vaporizer
• Plug the male connector strip (10) of the vaporizer into the female connector
strip of the unit
• Connect the pump cable (6) to the vaporizer
• Check the connections once again and make sure that the fluid tubing is not
twisted or bent
• Fasten the casing cover with the two screws (5). Ensure that the base of the
casing and the vaporizer engage into the corresponding guide grooves of the
lid part
6.1.3 Calibration of the Vaporizer
Since all evaporators have different electrical qualities, the TINY-FOGGER must
be calibrated after every exchange of the vaporizer.
IMPORTANT:During the calibrationprocess the vaporizer temperature must be
at 20°C. Never start fogging before the calibrating process. Too cold or too warm
units must first adapt to the room temperature (20°C).
• With the battery disconnected press and hold down the blue button [11] at
the back of the machine.
• Connectthebattery clip to the batteryand then release the button.Theyellow
LED (battery status display) will flash six times with a short pause after the
second and the fourth flashes.
• The calibration process is now complete.
6.2 The machine does not work perfectly
• the battery is discharged (yellow charge indicator (LED) lights up permanently,
the pump automatically cuts off) => charge the battery
• the fluid tank or the fluid tubing is empty or the connecting spout of the fluid
tubing is not correctly plugged into the quick connector on the fluid tank
=> refill the fluid tank, check to see that the tubing plug is properly fitted to
the quick connector
• the vaporizer is clogged or broken => change the vaporizer (see point 6.1)
6.2.1 There will be no fog if…

17
6. Service and Maintenance
6.3 Care and Maintenance
To ensure perfect performance of the TINY-FOGGER, you should consider the
following notes:
• Make sure the fluid bottle as well as of the connecting spout and the quick
connector are clean and free from small bits of dirt.
• Clean the unit from time to time, especially if you use it in a built-in state/
condition. Unscrew the unit with a suitable screwdriver (No. 1 Phillips) and
wipe it out carefully using a dry, fluff-free cloth.
• Shouldthe vaporizer become clogged, pleasechange it in theway as described
in section 6.3.
• If the TINY-FOGGER isn‘t in use for a longer time, please take care that the
fluid tube is emptied. It could be that some fluid drops come out of the nozzle
and the surrounding gets wet and greasy.
• thebattery isdischarged=> disconnectthemachinefromthebatteryand charge
the battery
• the vaporizer is clogged or broken => change the vaporizer (see point 6.1)
Note: the new vaporizer must be calibrated as explained in point 6.1.3!
6.2.2 The yellow LED lights permanently if…
• Disconnect the machine from the battery
• Remove the new vaporizer as explained in point 6.1.1
• Connect the machine to the battery and press the blue button [11] at the back
of the machine once
• Disconnect the machine from the battery
• Install the new vaporizer again and calibrate it as explained in point 6.1.3
6.2.3 If the new vaporizer can‘t be calibrated (no confirmation of the process by
the LED), please perform the following procedure:

18
Procedure Vaporizing fog generator
Power requirement 70 Watts
Voltage 12 V battery
Warm up time < 1 sec
Fluid tan capacity 50 ml
Fogging time programmable
Continuous output with battery 10 min.
Temperature control microprocessor
Control cable remote
radio remote (option)
Dimensions TINY (L x W x H) 91 x 34 x 51 mm
Weight TINY approx. 300 g
Manufactured for Look – Solutions made in Germany
7. Technical Data

19
8. Warranty Conditions
For the miniature fog machine TINY-FOGGER Look‘ guarantee is:
1. Free of charge, subject to the following conditions (No. 2 - 6) we will repair any defect or
faultinthe unit if itis caused by aprovenfactory fault and hasbeenadvised immediately
afterappearance and within 6month of delivery to theend user. Insignificant deviations
of the regular production quality does not guarantee replacement rights, nor do faults
or defects caused by water, by generally abnormal environment conditions or Force
Majeure.
2. Guarantee Service will be done in the following way: Faulty parts will be repaired or
replaced (our chioce) with correct parts. Faulty units have to be brought to us or our
service centres or to be sent to us or our service centres at customer‘s expenses. The
invoice and/or receipt showing the purchase date and the serial number has to come
withthe faulty unit, otherwise this will notbe guarantee service.Replaced parts become
our property.
3. The customer looses all rights for guarantee services, if any repairs or adjustments are
done to the units by unauthorized persons and/or if spare parts are used which are nor
approvedby us. Theright of guaranteeservice is alsolost if fluidsother than the original
„TINY-FOGGER FLUID“ have been used or if units are sent to us with full fluid bottles.
Alsononcompliancewiththeinstructionsin thismanualormistakesby incorrecthandling/
treating of the machine will lead to a loss of guarantee and also any faults and damages
caused by undue force.
4. Any freight costs arrising in connection with the guarantee services have to be born by
the customer.
5. Guarantee services do not cause an extension of the guarantee time or the start of a
new guarantee time. The warranty for replaced parts ends with the guarantee time of
the whole unit.
6. If a defect/fault can not be repaired by us in a satisfactory time, we will, within 6 months
after sale of the unit, on choice of the customer, either:
• replace the whole unit for free or
• refund the lesser value or
• take back the whole unit and refund the purchase price, but not more than the usual
market price at the time of the refund.
7. Further claims, especially for damages, losses etc. outside the unit are excluded.
Other guarantee regulations may be valid outside Germany. Please check with your dealer!
If you should send the unit for service, do not forget to remove any liquid from the fluid
bottle.
