LEMEGA DR2 User manual

Owner's manual
LIFE & ALOUD
DR2 PORTABLE AM & FM RADIO
LIFE & ALOUD
[email protected]
www.lemegaaudio.com
DR2 PORTABLE AM & FM RADIO
If you have any questions or suggestions, please share with us.

1 2
1. Introduction
Safety Instructions
PLEASE READ THIS OWNER'S MANUAL COMPLETELY BEFORE
OPERATING THIS UNIT AND STORE THIS INSTRUCTION
MANUAL FOR FUTURE REFERENCE.
2. CONTROLS, CONNECTORS
PRODUCT OVERVIEW
2. CLOCK
1. Preset 1,2,3+
3. SOURCE
4. ALARM
5.SLEEP
8.PLAY/PAUSE /
7.Power on/off& Select/MuteVolume&
9.TUNE+ /
6. TUNE- /
Unplug this product from the wall outlet before cleaning.
Place the unit on a solid surface.
Do not put it in a closed bookcase or a cabinet that may keep air
from flowing through its ventilation openings.
Do not install near any heat sources, such as radiators, heat
registers, stoves or other appliances that produce heat.
Protect the power cord from being walked on or pinched
particularly at plugs and the point where they exit from the
product.
Servicing is required when the product has been damaged. Do
not attempt to service this product yourself.
Opening or removing covers may expose you to dangerous
voltages or other hazards.
Please contact the manufacturer to be referred to an authorized
service center near you.
To prevent risk of fire or electric shock, avoid over loading wall
outlets, extension cords, or integral convenience receptacles.
Do not let objects or liquids enter the product.
Use proper power sources. Plug the product into a proper power
source, as described in the operating instructions or as marked
on the product.
Clean only with a dry cloth.
●
●
●
●
●
●
●
●
●
●
●
●
●
Do not use this product near water or moisture.
12
8 9
3
7
6
45

10 11 12
10 DC power in (5V) 12 Battery compartment.
11 Headphones out.
ACCESSORIES INCLUDED
Carefully remove the unit and all accessories from the package.
Please verify that you have all the following accessories before
recycling the gift box.
Owner's Manual
Warranty Card
Power charging cable
GETTING STARTED
UNDERSTANDING THE CONTROL FUNCTIONS
QUICK SETUP
Fully extend the Telescopic antenna to ensure good reception in
both AM and FM Radio modes. It may be necessary to alter the
position of the Radio and/or the Telescopic antenna to achieve the
best signal.
1. Connect the power cable to the input at the rear of the DR2 and
then plug the cable into an outlet or insert 4 x “AA” batteries into the
battery compartment to power on.
2.Fully extend the rear telescoping antenna.
3.Press the Power knob on the front to turn the DR2 on.
4.Press the front panel Source button to select the desired source.
5.Adjust the volume to the desired level using the SELECT knob on
the front.
6.In AM/FM mode, the TUNE+/TUNE- button allows you to navigate
between different stations. Push SELECT knob to choose the
stations you want to listen to.
REAR VIEW
3 4
1.PRESET1, 2, 3+: Preset 20 AM and 20 FM favorite stations.
Store a station to the preset list - to store a station, selected your
desired radio station, then press and hold the PRESET 1/2/3+ button
for a second until the LCD display “Preset store #”. There are 20 AM
presets and 20 FM presets.
Either press the TUNE+/TUNE- button to select your desired station
preset number or rotate the SELECT knob and push the SELECT
knob to confirm your selection.
Recall a station from the Preset list
To recall a preset station, press and hold the “3+” button and rotate
the SELECT knob to select presets station that you have stored.
When the display shows your desired preset number push SELECT
knob to confirm.
2. CLOCK: Press and hold CLOCK button to choose 24H/12H. Then
rotate the SELECT knob to adjust the hours/minutes and push
SELECT knob to confirm.
3.SOURCE: Briefly press to cycle through the sources:
FM, AM and Bluetooth.
GUIDE TO FEATURES

6
1)In FM mode, DR2 will tune to the start of the available FM range
(87.50MHz) or the last FM station listed.
2)To manually change the FM frequency, Press the TUNE+/TUNE-
button to change the frequency by 0.1MHz.
4. ALARM: Briefly press alarm button and use SELECT knob to
cycle through Alarm 1 and Alarm 2.
Rotate and press th e SELE CT knob to adjust and set the hour and
minutes and press to move to the next setting.
Alarm Mode： Buzz/AM/FM
Volume: rotate the SELECT knob to set the required alarm volume
from 0 to 30.
5. SLEEP： with the DR2 playing AM/FM, you can set a period of
time before the radio enters 'standby' mode.
Note: the radio must be active and not in 'standby' mode already.
To set the sleep timer, Briefly press SLEEP to cycle through the
sleep timer from 10 MINS, 20 MINS, 30 MINS, 40 MINS, 50 MINS, 60
MINS, 70 MINS, 80MINS, 90 MINS or Sleep OFF. Stop when the
required time is displayed, after a brief moment the screen returns to
the screen being used before the sleep function was selected.
To cancel a sleep time, select Sleep OFF from the sleep options.
Note: A sleep time is automatically cancelled if DR2 is put into
Standby.
. TUNE- / : Press to select the previous track under
AM/FM/Bluetooth mode; Press and hold the Tune- button 2 seconds
to auto-scan the stations under the AM/FM mode.
7.POWER (Turn ON/OFF/STANDBY ):
1)Push to power the DR2 On or Off (Standby).
2)When your DR2 is using power adapter, press POWER button to
switch 'on' and 'standby' .Unplug the power adapter to turn off your
DR2 completely.
3)When your DR2 is using batteries, press POWER button to switch
'on' and 'off'.
5 6
VOLUME +/VOLUME- button: Turn the Volume dial to increase or
decrease the volume. The volume knob may also be used to
navigate when in the station List.
8. PLAY& PAUSE/ : Press and hold this button to do auto scan
AM/FM stations and store the available stations to preset list
automatically.
In AM/FM mode, Press and hold “Play/Pause” button, it will
automatically scan for the available radio stations and store the
stations to preset list.
9. TUNE+ / : Press to select the next track under AM / FM/
Bluetooth Mode; Press and hold the Tune+ button 2 seconds to
auto-scan the stations under the AM/FM mode.
Bluetooth Operation
Streaming music and control from Smart device.
Prior to pairing, verify your device is not connected to any other
Bluetooth product. Devices may pair differently. Below is a general
guide.
1. Press to Mode to Bluetooth mode. This will power on the
Bluetooth. Turn the volume up about ¼ to start. Also turn up the
volume on the smart device (the device you are streaming from).
2. Turn on the Bluetooth on your enabled device.
3. Select Bluetooth device name “LEMEGA DR2” when it appears on
your device's screen to initiate searching.
4. You can start to play your music files wirelessly. Adjust the volume
level on your device.
You should not have to pair your device again.
Depending on your device, you may need to make multiple attempts
at Pairing and/or Connecting to the “LEMEGA DR2”, but please give
your device adequate time to Pair or Connect before repeating the
process.

Model: DR2
Type: Portable AM& FM Radio
Power output: 1CH X 2W
Power Supply: 5V DC or 4AA batteries [battery not included]
Dimension (mm): 175*106*54MM
Weight: 0.45KG
Specifications are subject to change without notice.
If you have any questions or suggestions, please share with us.
[e-mail]
www.lemegaaudio.com
TECHNICAL SPECIFICATION
9
