LEMEGA DR3 User manual

Owner's manual
LIFE & ALOUD
DR3 PORTABLE DAB & FM RADIO
LIFE & ALOUD
[email protected]
www.lemegaaudio.com
DR3 PORTABLE DAB & FM RADIO
If you have any questions or suggestions, please share with us.

Table of Contents
1 Introduction - --------------------------------------01
1.1 Safety instruction ---------------------------------------01
1.2 Features ---------------------------------------02
1.3 Carton contents - --------------------------------------02
2 Controls, connectors and display
2.1 Main controls ---------------------------------------02
2.2 Connectors ----------------------------------------04
2.3 Display -------------------------------------- 05
3 Started and setup ---------------------------------------06
3.1 12/24 hour display - --------------------------------------06
3.2 Time/ Date - --------------------------------------06
3.3 Auto- update - -------------------------------------- 07
3.4 Manual set - --------------------------------------07
4 Operation - --------------------------------------07
4.1 ---------------------------------07DAB radio mode (Optional) - -----
4.2 FM radio mode - --------------------------------------10
4.3 Bluetooth mode ----------------------------------------11
5 --------------------------------12Alarms snooze and sleep -------
5.1 Alarms ---------------------------------------12
5.2 Snooze ---------------------------------------13
5.3 Sleep ---------------------------------------14
6 System settings ---------------------------------------14
6.1 Equalizer ----------- ----------------------------15
6.2 Time/Date ---------------------------------------16
6.3 Backlight ------------ ----------------------------16
6.4 Language - --------------------------------------17
6.5 Factory reset - ---------- ----------------------------17
7 Troubleshooting and error messages
7.1 Error messages ----------- ----------------------------17
7.2 Troubleshooting ---------------------------------------18
8 -----------Technical Specification ---------------------------19

1
1. Introduction
1.1 Safety Instructions
Please store this instruction manual for future reference.
• Do not use this product near water or moisture.
• Clean only with a dry cloth.
• Unplug this product from the wall outlet before cleaning.
• Place the unit on a solid surface.
• Do not put it in a closed bookcase or a cabinet that may keep air
from flowing through its ventilation openings.
• Do not install near any heat sources, such as radiators, heat
registers, stoves or other appliances that produce heat.
• Protect the power cord from being walked on or pinched
particularly at plugs and the point where they exit from the product.
• Servicing is required when the product has been damaged. Do not
attempt to service this product yourself. Opening or removing
covers may expose you to dangerous voltages orother hazards.
• Please contact the manufacturer to be referred to an authorized
service center near you.
• To prevent risk of fire or electric shock, avoid over loading wall
outlets, extension cords, or integral convenience receptacles.
• Do not let objects or liquids enter the product.
• Use proper power sources. Plug the product into a proper power
source, as described in the operating instructions or as marked on
the product.
1.2 Features
This manual describes how to use the DR3 with the following modes:
• DAB/DAB+ digital radio with a wide choice of channels and digita
quality sound broadcast free-to-air.
• FM with RDS (Radio Data System)
• Bluetooth to act as a Bluetooth wireless speaker for Bluetooth
capable smart devices.
1.3 Carton contents
After you unpack the box, you will find the following items:
• 1 DR3 unit
• 1 Owner’s manual
• 1 Warranty card
2. Controls, connectors and display
2.1 Main controls
12
89
3
7
6
45
21

/ TUNE-
/ TUNE+
1.PRESET: Long press button 1, 2,3+ to preset and save your
favorite stations save 20 favorite stations); Short Press button
1,2,3+ to select the favorite station to play or Preset recall. You can
save 20 stations by pressing button 3+ and by scrolling the preset
list to achieve.
2. : : Press to select the previous track under FM/DAB
/Bluetooth mode.; Press and hold the Tune- button 2 seconds to
auto-scan the stations under the FM mode.
3. : : Press to select the next track under FM/DAB/
Bluetooth Mode; Press and hold the Tune+ button 2 seconds to
auto-scan the stations under the FM mode.
4. MENU: press the MENU to show the MENU for the current mode.
Press again to show now playing screen.
5. BACK: press the BACK to return to the previous screen.
6. : Press to select Play/Pause under BT mode.
7. SELECT/ VOLUME/MUTE/SNOOZE:
a. Power: Turn on or back to standby mode (showing clock and
date), or cancel sleep, or cancel alarm function.
b. VOLUME: Rotate the scroll button to adjust the volume up or
down during playback.
c. MUTE: Press the scroll button to mute the music when
playing.
d. SELECT: Rotate the scroll button scroll through a menu or
station list. Press to the scroll button to select the chosen option.
Press and hold Select scroll button to auto scan DAB/FM stations.
8. INFO: View more information about the station or track playing.
Press again to cycle through further information screens then return
to the normal playing screen.
FULL SIDESHOW: Press and hold INFO button to switch DAB
normal playing screen image to full screen slide show image.
9 SOURCE: Press to Source to select different modes DAB, FM,
Bluetooth.
2.2 Connectors.
As shown below has connectors (from left to right) for the following:
• DC power in (5V)
• Headphone Jack
• Battery compartment
10 11 12
10 DC power in (5V) 12 Battery compartment.
11 Headphones out.
2
1. Preset 1,2,3+
3
4. Menu
5. Back
8.Info
7.Power on/off& Select/Snooze/MuteVolume&
9.Source
6. Play/Pause
e. SNOOZE: Press the scroll button to snooze a set time when
alarm sounding.
43
TUNE+ /
TUNE- /

2.3 Display
The screen shows various menus, dialogues and displays as
described below.
There are basically six types of screen:
• Standby (clock)
• Splash (mode)
• Now playing
• Dialogue
• Error/Information
• Menu
When text is too long to fit on the screen, it is first shown truncated,
then after a few seconds, slowly scrolls so that you can read it all.
The Standby screen shows the time, date and any active alarm
times.
As you cycle through the play modes using SOURCE, DR3 shows a
splash screen for each mode. After one second, DR3 enters the
selected mode and tries to start playing the last station or track that
was playing in that mode. If this is not possible, DR3 tries to connect
to the selected source by scanning for stations, or prompting for
user input as appropriate.
Now playing screens show information about the audio source and
track now playing, where available.
Dialogue screens are shown to allow the user to change settings.
Error/Information screens give specific messages for a few seconds,
then change automatically to another screen.
Menus
DR3 has basically three types of menu. Use the Select control to
step through and select options. A scroll bar on the right of the
screen shows if there are further options above or
below those visible.
Each mode has a Mode menu, with options specific to that mode.
Below for DAB mode menu as an example.
System settings >.The '>' indicates options leading to further menus.
The System settings menu allows access to system settings
and information such as time, language and software update.
Menus with more options than will fit on one screen have a ">"in the
right.
Some menus, for example the System settings menu, have several
submenus.
3. Started and setup
DR3 is easy to use. To play DAB or FM radio, all you need is a power
source (a 100-240 V mains supply);
1). Place DR3 on a suitable shelf or table.
2). Extend the telescopic antenna.
3). Connect the power adaptor between DR3 and the mains supply.
3.1 12/24 hour display
To change between 12 and 24 hour display, select Set 12/24 hour
and then select your preference.
3.2 Time/date
The time and date can be updated manually or automatically.
65

3.3 Auto-update
Auto-update works with data sent over DAB, FM. The clock is only
updated when in a corresponding mode, so it is best to select a
mode you use regularly.
3.4 Manual set
If you set No update, the wizard now prompts you to set the time and
date manually. The date is displayed as DD-MM-YYYY and MM-DD-
YYYY.
4 Operation
This section describes the operating functions available for each of
the four audio sources.
4.1 DAB radio mode
DAB radio mode receives DAB/DAB+ digital radio and displays
information about the station and programme /track as broadcast.
To enter DAB mode, either press Mode until the display shows DAB
Radio.
4.1.1 Scanning for stations
The first time you use DR3, or if the station list is empty,the radio
automatically performs a full scan to see what stations are
available. You may also need to start a scan manually to update the
list of stations for one of the following reasons:
New stations may become available from time to time.
If reception was not good for the original scan (for example the
antenna was not up), this may result in an empty or incomplete list of
available stations.
If you have poor reception of some stations causing the audio to
break up, you may wish to list only stations with good signal strength.
To do a full scan Select Menu > Full scan.
Once a scan is complete, the radio returns to playing the previously-
selected station or first station on the station list.
To remove stations that are listed but unavailable Select Menu >
Prune invalid.
4.1.2 Manual tune
As well as the normal method of scanning, you can also manually
tune to a particular channel / frequency. This can be useful for
adjusting your antenna to achieve the best possible reception and
scanning a particular channel to update the station list.
To manually tune
Press Menu > Manual tune then use select control button to display
a particular channel/frequency, press Select to tune to that
channel/frequency.
The display shows a live indication of the received signal strength
on the selected frequency.
Adjustments to your antenna will be manifested in the received
signal strength displayed.
Note: The division in the signal strength bar indicates the audio
quality threshold – if the signal strength, as indicated by the solid
rectangles, falls below this threshold the audio quality will
deteriorate.
When a channel/frequency is selected DR3 also scans for any DAB
stations on the selected frequency and updates the station list with
any new stations found. To listen to any stations found return to the
Now playing screen and select the required station from the station
list as normal.
87

4.1.3Now playing information
While a station is playing, the screen shows its name and DLS
(Dynamic Label Segment) information broadcast by the station such
as programme name, track title and contact details.
Slideshow
The normal now playing screen shows a thumbnail of the currently
available slideshow image. (If no slideshow image is available a
default DAB thumbnail image is displayed). The Select button
cycles through the following slideshow displays.
Slideshow image and DLS text being broadcast by the current
station.
Normal now playing screen.
To view further information Press Info .
Each time you press Info , the next set of information is displayed,
cycling through: DLS text, DL Plus information (this is only
displayed if broadcast by the station), programme type,
ensemble name, channel number/frequency, signal strength, power
status and date.
4.1.4 Other settings
Dynamic range compression (DRC)
This function reduces the difference between the loudest and
quietest audio being broadcast.
Effectively, this makes quiet sounds comparatively louder, and loud
sounds comparatively quieter.
Note: DRC only works if it is enabled by the broadcaster for a
specific station.
To change the DRC setting Select Menu > DRC > The options
available are: DRC high | low | off.
4.2 FM radio mode
FM radio mode receives analogue radio from the FM band and
displays RDS (Radio Data System) information about the station
and show (where broadcast).
To enter FM mode: Press Mode until the display shows FM Mode.
4.2.1 Selecting stations
The first time you select FM radio, DR3 is set to the lowest frequency
in the FM band. On subsequent selections the last used
frequency/station is displayed.
To scan for a station in FM mode
Press Select DR3 scans up through the FM band frequencies,
showing the current frequency on the screen display.
A scan stops when a signal is found. DR3 can be set to stop at each
station or only at stations with a strong signal.
Alternatively, you can tune, using the select control button to rotate
in 50 kHz steps.
4.2.2 Now playing information
While FM radio is playing, the screen shows its frequency, or if RDS
information is available, station name and any further
RadioText' information. If no information is available, just the
frequency and a No RadioText message is shown.
To view further information about the broadcast Press Info.
Each time you press Info, the next set of information is displayed,
cycling through: RDS Radio text programme type, frequency, name,
mono/stereo,power status, and date.
10
9

4.2.3 Settings
Scan settings
By default, FM scans stop at any available station (All stations).This
may include poor quality audio from weak stations.
Options: Strong stations only | All stations
To change the scan settings, to stop only at stations with good
signal strength
Select Menu > Scan setting then Strong stations only.
Audio settings
By default, all stereo stations are reproduced in stereo. For weak
stations, this may result in poor quality audio. The audio quality can
be improved using mono.
Options: Stereo allowed | Forced mono
To play weak stations in mono
Select Menu > Audio setting > Forced mono.
4.3 Bluetooth
Bluetooth mode allows DR 3 to act as a wireless speaker playing
audio content from a connected Bluetooth capable device.
To enter Bluetooth mode: Press source to choose Bluetooth mode
To connect a Bluetooth capable device.
Use your Bluetooth capable smart device to pair and connect with
the DR3.
4.3.1 Display information
The screen displays either a Bluetooth Pairing or Bluetooth
connected message depending on the connection state.
5 Alarms snooze and sleep
As well as a clock/calendar, there are two versatile wake-up alarms
with snooze facility, and a sleep function to turn the system off after
a set period of time. The alarm sound for each alarm can use a
buzzer or a selection from the audio sources.
To set the clock/calendar
The settings for the internal clock and setting Alarm, Snooze and
Sleep function are all accessible via the Systems Setting menu.
5.1 Alarms
Note: Alarms will only function when the DR3 unit is On or in
Standby mode.
An active alarm is indicated by its icon in the bottom line of the
display.
Note: Alarms can be switched on or off in standby mode (see below).
To set alarms
Press Menu/System setting/Alarm and use the Select control knob
to select the required Alarm 1 or 2.
To exit alarm setting mode, press Menu or Back (alternatively, the
Alarm display will timeout and automatically return to the Now
Playing screen after a short time).
The alarm setup prompts you for the following parameters. Select a
value for each parameter in turn turning the select control button
and press Select to confirm and move on to the next parameter.
Parameters
Alarm – Off | On
Frequency - Daily | Once | Weekends | Weekdays
1211

Choose the days on which the alarm is active.
Note: if you choose 'Once', you are prompted to enter the required
date.
Wake Up time – hours and minutes
Source – Buzzer | Digital Radio| FM
If DAB or FM is chosen as the audio source you will also be
prompted to select the Last played station.
Duration – 15 | 30 | 45 | 60 | 90 | 120 minutes
If the alarm is not cancelled M1 returns to standby after this time
period.
Volume – rotate the top control button to set the required alarm
volume 4-16.
This is the volume the alarm will build up to. (Initially the alarm
sounds at a low volume and gradually gets louder to the set volume).
In all listening modes active alarms are indicated by displaying the
relevant Alarm 1 and/or Alarm 2 icons.
At the set time, the alarm will sound, quietly at first, then gradually
building up to the set volume. When an alarm sounds, the icon in the
display flashes.
To cancel a sounding alarm and switch the radio to standby Press
Standby or Alarm.
5.2 Snooze
To temporarily silence a sounding alarm, press Snooze. You can
change the snooze period by repeatedly pressing Snooze.
Snooze periods are 5, 10, 15 and 30 minutes. The radio returns to
standby for the set time period with a snooze countdown displayed.
When the countdown reaches 0 (zero) the alarm is triggered again.
Press Standby or Alarm to fully cancel a sounding alarm and switch
the radio to standby.
5.3 Sleep
To set the sleep timer while the radio is playing Press Menu>
System setting>Sleep. You can choose the sleep delay time in
minutes from: Sleep Off | 15 |30 | 45 | 60 | 90.
Use select control button to cycle through the options then press
Select to choose the displayed option.
Once you select a sleep delay period, the display returns to the Now
playing screen displaying a Crescent moon icon and the remaining
time, in minutes, before the sleep time expires.
After the sleep delay period the radio switches to standby mode.
6 System settings
The System Settings allow you to tailor the DR3 with a variety of
options to suit you.
To access system settings from any mode Select Menu >System
Settings >, then choose from the various options as described in the
menu as below.
The System Setting Menu options are:
• Sleep
• Alarm
• Equaliser
• Time/Date
• Backlight
• Language
• Factory Reset
• Software upgrade
• Software version
1413

To navigate through the menus
The following controls are used to move about the menu tree to
choose and select the required settings:
Select – (pressing the Select control button) this selects the
currently displayed option, if the option has a further sub-menu the
first option of the sub-menu is displayed. If the option is a setting
value, the displayed value is selected and either the next setting is
highlighted or, if there are no further settings, the display returns to
the parent menu for that setting.
Select control button – cycles forwards and backwards through the
current menu or setting options.
Back – jumps back to the parent menu of the currently displayed
menu or setting.
Menu to return to the Now Playing screen.
6.1 Equalizer
This presents a My Equaliser option to allow you to create your own
equaliser settings.
My EQ… | Normal | Classic | Jazz | Pop | Rock | Speech
6.1.1 My EQ setup…
This option allows you to set a bias in the treble and bass audio
frequencies and turn 'Loudness' On or Off. Values can be set
between -7 (Minus 7) and +7 (plus 7).
Treble – (Use the select control button to choose a bias value
between -7 and +7)
Bass – (Use the select control button to choose a bias value
between -7 and +7)
Loudness – No or Yes. (When Yes, low-level high and low frequency
sounds are boosted to give a ‘fuller' sound.)
6.2 Time/Date
The time and date can be updated manually or automatically With
auto-update, the time and date are automatically synchronised with
national time signals broadcast over DAB and FM (when available).
You can also select the display format for the time and date.
The Time menu contains the following options:
• Set Time/Date – (see below)
• Auto update - Update from Any | Update from digital radio | Update
from FM | No Update
• Set 12/24 hour - 12 | 24
• Set date format - DD-MM-YYYY | MM-DD-YYYY.
Set time/date
This option is for manually setting the time and date displayed.The
time displays as hh:mm, with the first value, hh, active (flashing).
Adjust each value using the select control button and press Select to
confirm. The next value then becomes active and flashes. The date
values follow and are set in the same way.
Note: The date displays as DD-MM-YYYY or MM-DD-YYYY
depending on your choice of date format (see above).
6.3 Backlight
The DR3 has a backlight with three brightness settings, and
adjustable timeout (this is the time delay, in seconds, after which the
display switches to the Dim level).
There are three settings:
• Timeout - Light On | 10 | 20 | 30 | 45 | 60 | 90 | 120 | 180 sec
• On level - High | Mid | Low
• Dim level - High | Mid | Low
1615

6.4 Language
The default language is English. To change, select Menu > System
settings > Language >then select your language.
6.5 Factory reset
A factory reset clears all user defined settings, replacing them with
the original default values, so time/date,preferences/ settings and
DAB station list are all lost.
If you select Factory reset, you are asked to confirm by selecting
“Yes”.
7 Troubleshooting and error messages
7.1 Error messages
Message
Des cri ption
DAB mode
Service not availa ble
No DAB reception
Sig nal error
The DAB signal ha s been interr up ted .
No DAB Statio n
The current station does not broadcast an identity name.
(No Name)
The listed st ati on ca nnot be fou nd.
No statio ns fo und
No DAB st ati ons are avai lab le – check ae rial .
FM mode
No RadioText No RDS text inf orm ation is ava ilabl e on thi s station .
No PTY No RDS prog ramme type inform ati on is availab le.
No Name No RDS st ati on na me is be ing broa dc ast
Gen eral mes sages
Update fa ile d Soft ware upgrad e fai led
7.2 Troubleshooting
Check/move antenna, Move radio
Rescan high-strength stations only.
For DAB or DAB+, check the
current status of local coverage
with your national digital radio
authority.
As above then rescan stations
Solutions
Low signal
Low signal
Cause
strength
strength
FM: Hiss
DAB: burbling/
intermittent
cut-out
DAB:
No stations
available’
message
Problem
Message
Des cri ption
Tim e is not set
No time value is cu rren tly set on this platf orm .
Tim e Not saved Any changes mad e to the time setting s will be los t.
Ala rm Not saved Any changes mad e to the Alarm se ttings will be los t.
Invalid Date The entered va lue do es no t match a va lid da te.
1817

Power Supply: 5V DC or 4 x AA batteries battery not included][
Dimension (mm): 175*106*54MM
Weight: 0.45KG
8 Technical Specification:
Model: DR3
Type:
Speaker: 1 X 2.5” full range speaker
Portable DAB & FM Radio
Power: 3W RMS
Specifications subject to change without notice.
[e-mail]
www.lemegaaudio.com
19
If you have any questions or suggestions, please share with us.
