Lennox Hearth Products Elite Series User manual

Report No. 050-S-6c-5
INSTALLATION AND OPERATION MANUAL
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
- Ne pas entreposer ni utilizer d’essence ni d’autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir
des téléphones se trouvant dans le bâtiment où vous
trouvez.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du fournis-
seur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindie.
- L’installation et l’entretien doivent être assurés par un
installateur ou un service d’entretien qualifié ou par
le fournisseur de gaz.
WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result causing property damage, personal injury
or death.
AVERTISSEMENT:Assurez-vousdebiensuivrelesinstruc-
tionsdonnéesdanscettenoticepourréduireauminimum
le risque d’incindie ou d’explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
• Suitable for installation into masonry or factory built fireplaces. This appliance is only for use with the type of
gas indicated on the rating plate. This appliance is not convertible for use with other gases unless a certified
kit is used.
• Lennox Hearth Products gas-burning appliances are designed for use as a supplemental heater. They are not
intended for continuous use as a primary heat source.
Designer™ (DBV)
In the Commonwealth of Massachusetts:
• Installation must be performed by a licensed plumber or gas tter
• See Table of Contents for location of additional Commonwealth of
Massachusetts requirements
US
Portland
WARNINGS
• Hot! Do not touch! The glass and surfaces of this appliance will be hot during operation and will retain heat
for a while after shutting off the appliance. Severe burns may result.
• Carefully supervise children in the same room as appliance. If small children are present in the home, it is
recommended that this appliance be fitted with a barrier screen kit. See Page 23 for ordering information.
B-Vent Gas
Fireplace Inserts
A French manual is available upon request. Order P/N 775,220CF.
Ce manuel d’installation est disponible en francais, simplement
en faire la demande. Numéro de la pièce 775,220CF.
P/N 775,220M Rev. B, 06/2009
Installer: Leave This Manual With The Appliance.
Consumer: Retain This Manual For Future Reference.
DRAFT
6/18/2009

2
FOR YOUR SAFETY do not install or operate your De-
signer™gasinsertwithoutfirstreadingandunderstanding
thismanual.Anyinstallationoroperationoftheappliance
deviating from that which is stated in this manual WILL
void the warranty and may be hazardous.
INSTALLATION AND REPAIR SHOULD ONLY BE DONE BY
A QUALIFIED SERVICE TECHNICIAN. DO NOT ATTEMPT
TO SERVICE THE APPLIANCE YOURSELF.
The insert should be inspected and cleaned before use
and at least annually by a qualified service technician.
More frequent cleaning may be required due to exces-
sive lint from bedding material, carpeting, etc.
It is imperative that control compartments, burners and
circulating air passageways of the room heater be kept
clean.
Adequate clearances around the combustion chamber
and accessibility clearances for servicing and proper
operation must be maintained.
Turn off the gas before servicing this appliance. It is
recommended that a qualified service technician per-
form an appliance check-up at the beginning of each
heating season.
All installations must conform with all local, state
and national codes. In the absence of local codes, the
installation must conform with National Fuel Gas Code
ANSI Z223.1-latest edition, also known as NFPA 54
(In Canada, the current CAN/CSA B149.1 installation
code). Refer to the National Fuel Gas Code and local
zoning and code authorities for details on installation
requirements. Your Designer gas insert must be vented
to the outside in accordance with the latest edition of
the National Fuel Gas Code.
This gas insert MUST be vented directly to the outside
and MUST NEVER be attached to a chimney serving a
separate solid fuel burning appliance. Each gas appli-
ance MUST USE a separate vent system. Common vent
systems are PROHIBITED.
This appliance uses room air for combustion. It is im-
perative that provisions for adequate combustion and
ventilationairbemade. ThisapplianceisNOTdesigned
to and will not operate in a negative pressure. Contact
your dealer if you suspect such a situation exists.
The appliance, when installed, must be electrically
grounded in accordance with local codes or in the ab-
sence of local codes, with the National Electrical Code,
ANSI/NFPA 70 - latest edition. In Canada, the current
CSA C22-1 Canadian Electrical Code - latest edition.
Do not make any make-shift compromises during in-
stallation. Any modification or alteration may result
in damage to the appliance or dwelling and will void
the warranty, certification and listings of this unit.
Failure to use manufacturer provided parts, variations
in techniques and construction materials or practices
other than those described in this manual may create
a fire hazard and void the limited warranty.
Your Lennox Hearth Products gas insert must be
equipped for the proper fuel type and altitude at which
it will be operated. Any operation outside the param-
eters outlined in this manual may result in a hazardous
condition and will void the warranty. Please carefully
read the sections pertaining to these subjects and/or
be sure your appliance is properly equipped.
Do not use this insert if any part has been under wa-
ter. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
Due to high temperatures, the insert should be located
out of traffic areas and away from furniture and draper-
ies.
Children and adults should be alerted to the hazards
of high surface temperature and should stay away to
avoid burns or clothing ignition. Young children should
be carefully supervised when they are in the same
room as the Lennox gas insert. Clothing or any other
flammable material should not be placed on or near
the insert.
Never use solid fuels such as wood, paper, cardboard,
coal, or any flammable liquids, etc., in this appli-
ance.
Any grill, panel, or glass removed for service MUST be
replaced prior to operating the insert. Do not operate
appliance with the glass front removed, cracked or
broken. Replacement of the glass should be done by a
qualified service technician.
DO NOT USE abrasive cleaner on the glass door as-
sembly. DO NOT ATTEMPT to clean the glass door when
it is hot.
Gold and nickel plated surfaces must be cleaned with
glass cleaner and a clean soft cloth before firing the first
timeorfingerprintswillremainpermanently. NEVERuse
brass polish to clean gold or nickel, this will remove
the plating!!!
When opening the lower door on the face while the
insert is burning, pull at the far left or far right vent
openings, because the door is hot during operation.
Lennox Hearth Products, its employees, or any of its
representatives assume no responsibility for any dam-
ages caused by an inoperable, inadequate, or unsafe
condition as a result of any improper operation, service
or installation procedures, whether direct or indirect.
INSTALLER: THESE INSTRUCTIONS ARE TO REMAIN
WITH THE HOME OWNER!
IMPORTANT SAFETY AND WARNING
INFORMATION

3
USING THIS MANUAL
Please read and carefully follow all of the instructions found in this
manual. Please pay special attention to the safety instructions provided
in this manual.
PRODUCT IS SUBJECT TO CHANGE WITHOUT NOTICE
CONGRATULATIONS!
When you purchased your new gas fireplace insert, you joined
theranksofthousandsofindividualswhoseanswertotheirhome
heating needs reflects their concern for aesthetics, efficiency
and our environment. We extend our continued support to help
you achieve the maximum benefit and enjoyment available from
your new gas fireplace insert.
Thank you for selecting a Lennox Hearth Products gas fireplace
insert as the answer to your home heating needs.
TABLE OF CONTENTS
Cautions and Safety .................................................... 2
Using this Manual ...................................................... 3
Orifice Size / Altitude Adjustment .................................... 4
Fireplace Requirements ............................................... 4
Codes and Approvals................................................... 4
New York City, New York (MEA) ...................................... 4
Requirements For The Commonwealth of Massachusetts........ 4
Pre-Installation........................................................5-7
Features......................................................... 5
Packaging List ................................................. 5
Ratings .......................................................... 5
Insert and Fireplace Dimensions............................ 6
Clearances to Combustibles ................................. 7
Insert Leveling ................................................. 7
Installation........................................................... 8-11
Venting Installation ........................................... 8
Flue Collar Connection ....................................... 8
Zero Clearance Fireplace Installation ...................... 9
Log Set and Ember Installation.............................. 9
Surround Panels Installation ...............................11
Face Installation .......................................................11
Gas Line Installation ..................................................12
Gas Pressure Requirements ................................12
Gas Supply Line Sizing ......................................12
LP and Natural Gas Supplies ...............................13
Air Shutter Adjustment.......................................13
Operating Instructions ............................................14-18
Pre-Lighting Checklist .......................................14
Lighting Instructions .........................................14
Flame Color and Behavior...................................15
Replacing Burner Orifices ...................................16
Paint Curing ...................................................16
Quiet Operation ...............................................16
Blower..........................................................16
Optional Wall Thermostat ...................................16
“On-Off” Switch And Thermostat...........................17
Pilot Adjustment ..............................................17
Millivolt Control System.....................................18
Maintenance and Servicing ......................................18-20
Maintenance Checklist.......................................18
Glass Maintenance ...........................................18
Door Removal .................................................19
Glass Door Cleaning And Repair ...........................19
Blower Removal ..............................................19
Fuel Conversion and Cassette Installation ...............20
Troubleshooting ........................................................21
Replacement Parts ....................................................22
Accessories.........................................................22-23
Insert Labels........................................................24-25
Product Reference Information ......................................26

4
Installation of these appliances are approved for installation in New York
City in the US state of New York.
• Must conform with all local, state and national installation codes. In
the absence of local codes, the installation must conform with National
Fuel Gas Code ANSI Z223.1 - latest edition, also known as NFPA 54
(In Canada, the current CAN/CSA B149.1 installation code). Refer to
the National Fuel Gas Code and local zoning and code authorities for
details on installation requirements.
• Must be vented directly to the outside in accordance with the latest
edition of the National Fuel Gas Code and must never be attached to
a chimney serving a separate solid fuel burning appliance.
• Uses room air for combustion. It is imperative that provisions for
adequate combustion and ventilation air be made. This appliance is
NOT designed to and will not operate in a negative pressure. Contact
your dealer if you suspect such a situation exists.
• Has been certified for use with either natural gas or propane.
• Is not for use with solid fuels.
• Is approved for sitting rooms and/or bedrooms.
Fireplace Requirements
These heaters are designed to be installed into an existing masonry
fireplace (built to UBC 37 or ULC S628 standards) or factory built solid
fuel, wood burning fireplace (listed to UL 127 or ULC S610) only. All
exhaust gases must be vented outside the structure. Combustion air
is drawn from outside the structure. When installing in a factory built
fireplace, the fireplace grate must be removed and the damper must be
removed or secured open.
If the factory-built fireplace has no gas access hole(s) provided, an access
hole of 1-1/2 inches (38 mm) or less may be drilled through the lower
sides or bottom of the firebox in a proper workmanship like manner. This
access hole must be plugged with a non-combustible insulation after the
gas supply line has been installed.
The installer must mechanically attach the marking supplied with the gas
fireplace insert to the inside of the firebox of the fireplace into which the
gas fireplace insert is installed.
IMPORTANT: When installing these appliances into a factory
built fireplace or heat-form, the air flow within and around the
fireplace shall not be altered by the installation of the insert
(i.e. DO NOT BLOCK louvers or cooling air inlet or outlet ports,
circulating air chambers in a steel fireplace liner or metal heat
circulator).
ORIFICE SIZE/ALTITUDE ADJUSTMENT
For altitudes above 2,000 feet (In Canada 4,500 FT/1370 M),the orifice
should be de-rated by 4% for every 1,000 feet to maintain the proper ratio
of gas to air. Improper orifice sizing may result in damage and unsafe
conditions. Changing the orifice should only be done by a qualified service
technician. Contact your Lennox Hearth Products dealer for proper orifice
sizes. (see Page 15 for more information)
THE DESIGNER™ INSERT
SMOKE DETECTORS
Since there are always several potential sources of fire in any home, we
recommend installing smoke detectors. If possible, install the smoke
detector in a hallway adjacent to the room (to reduce the possibility of
occasional false activation from the heat produced by the appliance). If
your local code requires a smoke detector be installed within the same
room, you must follow the requirements of your local code. Check with
your local building department for requirements in your area.
CODES AND APPROVALS
Certification
Gas appliances must be tested and certified by a nationally recognized
testing and certification laboratory to ANSI (American National Standard
Institute) gas appliance safety standards.
This insert has been tested and certified by OMNI -Test Laboratories to
ANSI Z21.88 / CSA 2.33 Standard for Vented Gas Fireplace Heaters and
CGA 2.17-M91 Gas-Fired Appliances for Use at High Altitudes in both
USA and Canada.
It has met all necessary ANSI Standards and is fully certified for installa-
tion in any community. If there are any questions or if you need further
substantiation either write to or call your Lennox Hearth Products dealer.
If you have further questions, please contact Lennox Hearth Products.
Check all local building and safety codes before installation. The instal-
lation instructions and appropriate code requirements must be followed
exactly and without compromise. In the absence of local codes the fol-
lowing standards and codes must be followed.
WARNING
THIS FIREPLACE HAS BEEN ALTERED TO
ACCOMMODATE A FIREPLACE INSERT AND
SHOULD BE INSPECTED BY A QUALIFIED
PERSON PRIOR TO RE-USE AS A
CONVENTIONAL FIREPLACE.
NEW YORK CITY, NEW YORK (MEA)
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS
(Massachusetts Approval #G3-1104-102)
Installationoftheseappliancesare approved forinstallationin theUSstate
of Massachusetts if the following additional requirements are met -
• Install this appliance in accordance with Massachusetts Rules and
Regulations 248 C.M.R. Sec. 5.08 2(a) through 2(e).
• Installation and repair must be done by a plumber or gas fitter licensed
in the Commonwealth of Massachusetts.
• The flexible gas line connector used shall not exceed 36 inches (92
centimeters) in length.
• The individual manual shut-off must be a T-handle type valve.

5
Features
Installation Options
Residential - Vented Vertical Only
Natural Gas Or Propane (LP)
Bedrooms
Optional Wall-mounted Or Remote Thermostat
Electrical
The blower motor requires 120 Volts AC for operation. The appliance is
not dependent on the blower or an outside electrical supply to operate.
Millivolt Valve
This insert is operated with a millivolt valve and therefore burns even
during a power outage.
Fuel
This insert comes from the factory equipped to burn natural gas at a speci-
fied elevation. The insert can be converted to burn LP (liquid propane) by
installing a conversion kit. Only Lennox Hearth Products conversion kits
can be used to convert from NG to LP or LP to NG. Contact your Lennox
Hearth Products dealer for details.
Packaging List
To install a Designer insert, an insert body, face, surround (flange) kit
and brick panel are required.
Insert Body Packaging List
1 Insert Body with Burner Cassette
1 Set of Refractory Brick Panels - Left and Right Sides
1 Log Set
1 Bag of Embers
1 Fasteners: 6 slotted 1/4" truss screws
6 speed nuts
9 spring clips
3 plastic adhesive wire restraints
1 Installation and Operation Manual
Decorative Faces - One Required
Arch Inset
Classic
Screen
Foundry™
Cast Pillar
Surround Kits - One Required
Traditional 1-pc. (41"W x 29"H)
Traditional 3-pc (29"H x 41"W, 29"H x 48"W, 33"H x
41"W, or 33"H x 48"W)
Cast Iron (45-1/2"W x 30"H-Cast Pillar face only) *
* See detailed dimensions on Page 23.
Surround Kit Contents
1 Top Surround
2 Side Surrounds
3 Black Extruded Trim Pieces
2 Elbowed Trim Fasteners
RATINGS Designer™ (DBV)
NATURAL GAS LP GAS
MAX/MIN INPUT BTUH 0-2,000 FT (0-610 M) u
30,000/20,500 28,500/17,100
MANIFOLD PRESSURE (IN. WC)
3.5 10.0
MIN. INLET PRESSURE (IN. WC)
5.0 10.5
MAXIMUM HEAT OUTPUT BTUS/ HOUR “STEADY STATE” 25,600 24,800
P4 Efficiency v
55.63% 57.89%
ORIFICE (DMS) 0-2,000 FT (0-610 M) u
#37 #52
uUnit factory equipped for 0-2000 FT/0-610 M, In Canada 0-4500 FT/0-1370 M
vTested to CSA P.4.1-02 “Testing Method for Measuring Annual Fireplace Efficiency.
Electrical Rating: 120 VAC, 60 HZ, Less Than 2 Amps
PRE-INSTALLATION

6NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Figure 2
Minimum Fireplace Opening Required
A = 29-3/4” (756mm) Front Opening
B = 19-1/2” (495mm) Height
C = 19” (483mm) Rear Width
D = 15-1/2” (394mm) Fireplace Depth
* Top air duct will need to be removed for short ZC applications.
Replace tap tights when removed.
Minimum
Fireplace
Cavity
Insert Dimensions
Width of insert behind Surround Panels 28" (711mm)
Rear height 18-1/2" (470mm)
Insert depth into fireplace 15-3/8" (391mm)
Flue center line from back of surround with
standard draft hood 12" (305mm)
Flue center line from back of surround with
extended draft hood 16"(406mm)
Flue collar diameter (OD) 3-15/16" (100mm)
A
B
C
D
Figure 1
Figure 3
Top View
4"
(102mm)
15-3/8"
(391mm)
Side View
20-1/8" (511mm)
16-1/4" (413mm)
4-1/2" (114mm)
10" (254mm)
28" (711mm)
12" (305mm)
20-1/8"
(511mm)
18-1/2"
(470mm)
19-1/2"
(495mm)
Insert Dimensions
See Figures 1, 2 and 3 showing insert dimensions and minimum
fireplace firebox dimensions to aid you in determining proper fit into
existing fireplace.
CAUTIONS
•Trim panels or surrounds must not seal ventila-
tion openings in the existing fireplace that the
appliance is installed in.
•The fireplace in which this gas insert is to be
installed must be thoroughly cleaned if it has
been used to burn wood or synthetic logs. Have
the chimney and all inside surfaces of the fire-
place brushed and vacuumed so that no soot,
embers, or loose combustion deposits can be
drawn into the heat circulation blower and blown
into the living area.
•If any portion of the chimney system shows signs
of structural or mechanical weaknesses, such
as: cracks, leaky joints, corroded or warped
surfaces, the faulty portion must be repaired
or replaced prior to installing this appliance.
•The factory built firebox must accept the insert
without modification other than removing bolted
or screwed together pieces such as baffles /
smoke shelf / deflectors, ash lips, glass door,
screen or door tracks, log grates, refractory or
masonry lining and damper assemblies. Any
fireplace component, which is removed, must be
retained so they can be reinstalled to restore the
fireplace to its original operating condition. The
removal of any part must not alter the integrity
of the outer shell of the pre-engineered fireplace
cabinet in any way. Any parts removed must be
replaceable. If any components are removed
from (or altered) from the existing fireplace,
a Warning Label (see Page 4) must be affixed
inside the fireplace firebox, so that it shall be
visibleuponremovalofthefireplaceinsert. Note:
RTV high temperature silicone is an approved
adhesive to affix the label.

7
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Note: Hearth protection to be min. 3/8” (10mm) thick non-combustible
or equivalent, with a k factor of .84.
Insert Leveling
At each front and rear corner of the insert is an adjustable leg provided
to level the insert should the hearth of the fireplace be uneven. To adjust
the legs, loosen the two 5/32" allen head screws, move the leg to the
desired height and then tighten the screws. Repeat these steps for each
adjusting leg.
E
H
F
G
J
C
L
MANTEL
TRIM
Mantel
Trim
Hearth / Floor Protection
Minimum Clearances to Combustibles
Minimum clearances include any projections such as shelves, window
sills,mantels,spacers/standoffsorsurfacestocombustibleconstruction
etc. above the appliance. Paint or lacquer used to finish the mantel
must be heat resistant in order to avoid discoloration.
The letters below, E through J, correspond to Figure 4 showing minimum
clearances required from the appliance to combustibles and the minimum
projection of the hearth extension.
E & J = 32.0” (813mm) from Top Facing or Mantel to Bottom of In-
sert
F 52.2 = 10.5” (267mm) from Edge of Glass to Side Facing or Side
Wall
Hearth Protection
G = Minimum Hearth Protection from Front of Insert*
H = Vertical Distance from Insert Bottom to Combustible Material.
Clearances
G
13”
(330mm)
10”
(254mm)
0”
(0mm)
H
0”
(0mm)
2”
(21mm)
4”
(102mm)
Figure 4
WARNING
B-Vent appliances are not designed to operate
in negatively pressured environments (pressure
within the home is less than pressures outside).
Significant negatively pressured environments
caused by weather, home design, or other devices
may impact the operation of these appliances.
Negative pressures may result in poor flame
appearance, sooting, damage to property and/or
severe personal injury. Do not operate these
appliances in negatively pressured environments.
Providing adequate ventilation to the appliance for
combustion air will eliminate a negative pressure
environment.

8NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Insert Venting
WARNING: This appliance is equipped with a safety control
system designed to protect against improper venting of combus-
tion products. Operation of this heater when not connected to
a properly installed and maintained venting system or tamper-
ing with the blocked vent shut-off system can result in carbon
monoxide (CO) poisoning and possible death.
Insert must be vented to the outside in accordance with the current edition
of the National Fuel Gas Code ANSI-Z223.1-latest edition, also known
as NFPA 54 (In Canada, the current CAN/CSA B149.1 installation code).
The insert must not be connected to a chimney flue serving a separate
solid fuel burning appliance.
This gas insert requires a 4” diameter B-vent or listed flex aluminum
or stainless chimney liner extending the entire length of the chimney to
ensure proper operation. The vent should terminate with a chimney cap
or rain cap. Chimney should be sealed around cap to prevent air and rain
from entering chimney. Adhere to vent manufacturer's instructions for
installation and vent termination.
The insert must be installed so the
draft hood is in the same atmospheric
pressure zone as the combustion air
inlet to the appliance.
Flue Collar Connection
This insert has a detachable flue col-
lar to ease installation. To detach flue
collar, unscrew the draft tube retaining
screw and slide draft tube and flue
collar to the rear. Attach flue collar
(with 3 sheet metal screws or a B-vent
connector) to vent pipe previously
installed in chimney. As the insert is
pushed into fireplace, guide draft tube
and flue collar into the guide brackets
until draft tube retaining screw can be
reinstalled in its original hole.
Figure 5
Draft Tube
Retaining
Screw
Chimney Cap
Storm Collar
Opened Flue
Damper
Figure 6
Chimney- UseWith B-vent
Chimney Or Single Wall
Gas Vent Flex Chimney
Liner Listed To UL 1777
Or ULC S635.
VENT KITS
Cat. # Model Description
H0906 VKBVI25 BVI, 4" Dia. x 25’ Length
H0907 VKBVI35 BVI, 4" Dia. x 35’ Length
WARNING
B-Vent Fireplace Insert Vent Requirements - Type B-Vent
or listed gas fuel type vent liner listed to UL 1777 (Chim-
ney Liners) or ULC S635 (Standard For Lining Systems
For Existing Masonry Or Factory-built Chimneys And
Vents).
Do not substitute the heat-rated flex liner (UL1777 or ULC
S635) for the exhaust with any other type liner or a fire
may result causing property damage, personal injury or
loss of life.
Figure 7
The following vent
liner kits are available
from Lennox Hearth
Products (see Figure 7
and table below).
INSTALLATION

9
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Zero Clearance Fireplace Installation
This insert may be installed in a masonry or factory built / zero clearance
(ZC) fireplace. When installing in a ZC fireplace the ZC grate must be
removed and the ZC damper must be removed or secured open. The ZC
doors, screen, refractory or masonry lining, baffles and smoke shelf may
be removed if necessary to install the gas insert. However, do not cut
or alter the fireplace components. The removal of any parts to facilitate
installation must not alter the integrity of the inner or outer shells of the
fireplace cabinet. Any parts removed must be replaceable if the insert is
taken out of the fireplace or the fireplace clearly marked with a paint stick
that "This fireplace has been altered and is no longer safe to operate."
The insert is designed to fit into a ZC fireplace with a minimum firebox
height of 19-1/2 inches (495 mm). To facilitate this installation the flue
collar is removable (See "Flue Collar Connection").
Glass Door Removal
See Page 19 for Glass Door Removal Instructions.
Brick Liner Installation
The brick panels are extremely fragile so handle them with care.
1. Remove the panels from their packing material.
2. The long rectangular panel goes in the rear of the firebox - the thin
layer of bricks should be down. The brick panel rests on the air control
panel. The rear brick panel is held in place by the side panels.
3. The rounded edge of the side panels goes to the front. Install the side
panels by sliding them along the side of the firebox. They are held in
place by two screws protruding from the top of the firebox.
Log Set and Ember Installation
If logs are not installed according to the log installation instruc-
tions, flame impingement and improper combustion could occur
and result in soot and/or excessive production of carbon monoxide
(CO), a colorless, odorless, toxic gas.
The size and position of the log set is critical to achieve a safe,
reliable and attractive flame pattern. Any attempt to use a different
log set in the appliance will void the warranty and will result in
incomplete combustion, sooting and poor flame quality.
Parts list: rear log, left front log, right front log, left top log, right top
log and small straight twig
1) Remove the logs from the box and carefully unwrap them. The logs
are fragile so handle them with care.
2) At the rear of the firebox is a log retainer (the circled area in Figure
10). This retainer can be rotated forward to increase the size of the
flames in front of the rear log. Rotate the retainer by loosening screw
A. For inserts burning propane the retainer may be rotated half the
way forward. For inserts burning natural gas, the retainer may be
rotated all the way forward. It may be necessary to try various setting
to find the optimum one. Never rotate the retainer to such an extent
as to cause sooting.
3) Align the holes in the bottom of the rear log (the longest log in the set)
with the two pegs just to the rear of the rear burner tube and slide the
log down onto the pegs. See Figure 10. The charred black surface of
the log should face the front. (Continued on the following page).
A
Figure 9
Figure 10

10 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Right Top Log
Left Top
Log
Hole to
Cover
Hole to
Cover
Flat Area
Embers
4) Rotate the right front log (3018 is cast into its bottom surface) so the
black charred surface is toward the front. Place this log so the two
holes in its bottom surface slide onto the two pegs on the right side
of the air control panel. See Figure 11.
5) Rotate the left front log (3017 is cast into its bottom surface) so the
black charred surface is toward the front and place it on the pegs
protruding from the left side of the air control panel as shown in
Figure 11.
6) The small straight top twig (3021) should be turned so the black flat
end is turned to the rear. Slide the holes in the bottom of this twig
over the right peg on the left front log and the hole on the right front
log. See Figure 12.
7) The left top log (3019) should be positioned as shown in Figure 12.
Slide the holes in the bottom of this log over the hole in the left end of
the rear log and the peg in the left end of the left front log. The right
top log (3020) should be positioned as shown in Figure 12. Slide the
holes in the bottom of this log over the peg in the right end of the right
front log and rest it on the flat spot on the rear log.
8) Figure 13 shows the entire log set assembled. The embers provided
may be placed one high in front of the front burner tube using care not
to cover all the burner ports. Any extra embers may be placed at the
ends of the front log, off the burner. Place small pinches of rockwool
on top of the embers.
Figure 11
Figure 12
Figure 13
Note: The pilot
flame can be
viewed through
this hole in the
front log.
