Framing Specifications
MPE-27
Fireplace Dimensions
775,534M Rev. N/C 11/05
Front View Right Side
23 ¹⁄₂"
Top View
⁵⁄₈"
1 ¹⁄₈"
32"
28"
23 ¹⁄₄"
27 ¹⁄₈"11"
9 ¹⁄₂"
Front View
31 ¹⁄₄"
(794 mm)
Side View
25"
(635 mm)
Note: Framing dimensions are calculated for an in front of the
wall front face installation with finish dry wall in place.
11"
(280 mm)
32"
(833 mm) 25"
(635 mm)
51 ¹⁄₄"
(1302 mm)
22 ¹⁄₂"
(572 mm)
Corner View
4"
(102 mm)
Electrical
Junction
Box
(On Right
Side)
2 x 4
Electrical
Junction
Box
31 ¹⁄₄"
(794 mm)
Fireplace Specifications
Cat. No.: H3428
Model: MPE-27
Description:
Merit Plus Electric Fireplace - 27”
Shipping Weight: 78 lb.'s (35 KG)
Packaging:
34 1/2” x 14” x 34”
(876 mm x 356 mm x 864 mm)
14.1 cu. ft.
Power Requirements:
(120 Volt, 60 Hz.)
Rated Wattage - 1600 Watts
Amperage - 15 Amps
Blower CFM: 83 CFM
(120 V): 5,461 BTU/HR
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Specifications and clearances are subject to change
without notice. Refer to the Installation Instructions
before installation of this appliance for updated dimen-
sions instructions.

MPE-27
775,534M Rev. N/C 11/05
Mantel Clearance: Combustible and Non-
combustible mantels may be installed at
any height above the top of the face of
fireplace.
Hearth Protection: A hearth is not
mandatory, but may be used for aesthetic
purposes. Secure the hearth extension
to the floor to prevent possible shifting.
Do no block the airflow beneath the
appliance.
Sides: 25.5 mm - 1 inch
Floor: 25.5 mm - 1 inch
Top: 25.5 mm - 1 inch
Minimum Clearances to Combustibles
Power LED
Flame Control
Button ON/OFF Power
Button
Temperature
LED
Temperature
Control Button
Remote Control
Receiver
FL TM
Fireplace Controls
This Merit Plus Electric Fireplace is provided with an Infrared light Remote Control. All
functions of the fireplace can be controlled through the remote control.
Note: The effective range of the remote control is up to approximately 25 feet (8 meters).
Manual Controls are also provided on the appliance.
Charred Split Oak Log Set With
Glowing Ember Bed Featuring
Exclusive Lennox Glowing
Ember Crystals
Bronze-Tinted Flush Panel
Glass Door Adds A Touch Of
Elegance And Realism
Standard 5,000 BTU Heater/
Blower With Three Built-in
Thermostatic Settings Delivers
Measured Warmth To Any
Room Environment
Fireplace Features
Easy-Access Manual Controls
Mounted On The Unit Makes
Operation Simple
• Plug-In Ready With Standard Three
Pronged 110V Grounded Power Cord
Makes Installation Easy.
• On/Off Switch, Adjustable Flames/
Ember Beds And Easy-To-Use Heater
Temperature Settings Provides
Customized Control.
• Adjustable Flame And Ember
Intensity Provide Customizable Fire
Presentation.
• Remote Control Adds Convenience.
CUS
®
CSA Report No. 46-M198
Remote Control Manual Controls
