Lenovo A5000 User manual

English/Bahasa Indonesia
Quick Start Guide v1.0
Lenovo A5000

English
Learning more
Getting support
Read this guide carefully before using your smartphone.
To learn more information about your
Lenovo smartphone and obtain the latest
smartphone manuals, go to:
http://support.lenovo.com/.
For support on network service and billing,
contact your wireless network operator.
For instructions on how to use your
device, go to:
http://support.lenovo.com/.
Legal notices Lenovo and the Lenovo logo are
trademarks of Lenovo in the United States,
other countries, or both.
Other company, product, or service names
may be trademarks or service marks of
others.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.

Type: CMOS
Pixels: 8 megapixels (back) + 2 megapixels (front)
Processor: MTK MT6582
, Quad Core , 1.3 GHz
Size: 5 inches Screen: multi-touch
Resolution: 1280 × 720 pixels LCD type: IPS
Model: Lenovo A5000 System: Android
Battery: 4000 mAh
Height: 140 mm (5.5 inches) Width: 71.4 mm (2.8 inches)
Depth: 9.98 mm (0.39 inch) Weight: 155.9 g (0.3 lb)
Model and system
① Depending on the measuring method, the dimensions and weight
might vary slightly.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
Technical specifications
Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS

Back button
Micro USB
connector
Home button
Rear-facing
camera
Light/Proximity
sensor
Volume buttons
Headset
connector
Menu button
Touch screenOn/Off button
Front-facing
camera
Speaker Microphone
Receiver
Flashlight
13 14 15
First glance

You must insert the SIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
Step 1. Open the back cover.
Tip: The battery is
unremovable, and is fixed
to the phone. Please do
not pull the battery,
otherwise it will damage
the phone.
Step 2. Insert the (U)SIM cards.
Tip: Insert the (U)SIM card into
SIM1 slot and SIM card
into SIM2 slot.
Step 3. Insert the memory card.
Step 4. Install the back cover.
Always turn off your smartphone first before you insert or remove a
SIM card. Insert or remove a SIM card with your smartphone on may
damage your SIM card or smartphone permanently.
SIM2
SIM1
SIM2
SIM1
Micro
SD
Micro
SD
Preparing your smartphone

Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Tur n of f: Press and hold the On/Off button for a
few seconds, then tap Power off.
Your smartphone has a rechargeable battery. For more information
about battery safety, see the “Rechargeable battery notice” in the
Important Product Information Guide shipped with your smartphone.
Low battery power Fully charged Charging
2
1
Charge the battery as shown.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
Charging the battery

Pelajari lebih lanjut Untuk mengetahui informasi
selengkapnya tentang ponsel cerdas
Lenovo dan mendapatkan panduan
ponsel cerdas terbaru, kunjungi:
http://support.lenovo.com/.
Untuk dukungan penagihan dan
layanan jaringan, hubungi operator
jaringan nirkabel Anda. Untuk petunjuk
cara menggunakan perangkat Anda,
kunjungi: http://support.lenovo.com/.
Lenovo dan logo Lenovo adalah merek
dagang dari Lenovo di Amerika Serikat,
negara lain, atau keduanya.
Perusahaan, produk, atau nama layanan
lainnya mungkin merek dagang atau
merek layanan dari pihak lain.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
Bahasa Indonesia
Baca panduan ini dengan saksama sebelum menggunakan
ponsel cerdas.
Mendapatkan
dukungan
Pemberitahuan
hukum

Jenis: CMOS
Piksel: 8 megapiksel (belakang) + 2 megapiksel (depan)
Prosesor: MTK MT6582, Quad Core, 1,3 GHz
Ukuran: 5 inci Layar: multisentuh
Resolusi: 1280 × 720 piksel Tipe LCD: IPS
Model: Lenovo A5000 Sistem: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Baterai: 4000 mAh
Tinggi: 140 mm (5,5 inci) Lebar: 71,4 mm (2,8 inci)
Tebal: 9,98 mm (0,39 inci) Bobot: 155,9 g (0,3 lb)
Model dan sistem
Tergantung pada metode pengukuran, ukuran dan berat mungkin
sedikit berbeda.
Display
Baterai
Prosesor
Ukuran dan berat
Kamera
Komunikasi Nirkabel
Spesifikasi teknis

Tampilan sekilas
13 14 15
Kamera depanUnit penerima
Tombol On/Off
Sensor Kedekatan/
Cahaya
Tombol volume
Tombol Home
Layar sentuh
Tombol kembali
Senter
Tombol menu
Kamera
belakang
Speaker
Konektor headset
Konektor USB
Mikro
Mikrofon

Langkah 1. Buka penutup belakang.
Baterainya tidak dapat
dilepas, dan terpasang
permanen pada ponsel.
Harap jangan tarik
baterai, jika tidak
ponselnya akan rusak.
Saran:
Langkah 2. Masukkan kartu
(U)SIM.
Saran: Masukkan kartu
(U)SIM ke slot SIM1
dan kartu SIM ke slot
SIM2.
Langkah 3. Masukkan kartu
memori.
Langkah 4. Pasang penutup
belakang.
Untuk menggunakan layanan seluler, pasang kartu SIM yang
disediakan oleh operator seluler Anda. Siapkan ponsel cerdas Anda
seperti yang ditunjukkan.
Selalu matikan ponsel cerdas Anda lebih dulu sebelum Anda
memasukkan atau melepaskan kartu SIM. Memasukkan atau
melepaskan kartu SIM dengan ponsel cerdas masih menyala dapat
merusak kartu SIM atau ponsel cerdas Anda secara permanen.
Menyiapkan ponsel cerdas
SIM2
SIM1
SIM2
SIM1
Micro
SD
Micro
SD

Menyalakan atau Mematikan ponsel cerdas
Menyalakan: Tekan dan tahan tombol On/Off
hingga logo Lenovo ditampilkan.
Mematikan: Tekan dan tahan tombol On/Off
selama beberapa detik, lalu ketuk Matikan
Daya.
Ponsel cerdas Anda dilengkapi baterai isi ulang. Untuk informasi lebih
lanjut tentang keamanan baterai, lihat "Pemberitahuan baterai isi ulang"
di dalam Panduan Informasi Produk Penting yang dikirimkan bersama
ponsel cerdas Anda.
Isi baterai seperti yang ditunjukkan pada gambar.
Metode 1.
Metode 2.
Sambungkan ponsel cerdas ke outlet daya menggunakan
kabel dan adaptor daya USB yang disertakan bersama
ponsel cerdas Anda.
Sambungkan ponsel cerdas ke komputer menggunakan
kabel yang disertakan bersama ponsel cerdas Anda.
Mengisi daya baterai
Daya baterai rendah Terisi penuh Mengisi
2
1

70114787
Printed in China
First Edition (January 2015) © Copyright Lenovo 2015.
Edisi Pertama (Januari 2015) © Hak Cipta Lenovo 2015.
