Lenovo A526 User manual

Lenovo A526
Quick Start Guide v1.0
Read this guide carefully before using your phone.

GPS
Model: Lenovo A526 System: Android 4.2.2
Battery: 2000 mAh
Wireless communication
Display
Model and system
Power and battery
CPU
① Size and weight
Camera
①Based on actual measurements.
② Launch with Android 4.2 which only supports BT 4.0 PXP profile.
Size: 4.5” FWVGA Screen: 1 point touch
Resolution: 854 × 480 LCD type: TN
CPU: MT6582M Quad Core 1.3GHz
Height: 132 mm Width: 67.6 mm Depth: 11.1 mm
Weight: 145 g
②Bluetooth 4.0 WLAN WCDMA, GSM, EDGE
Type: CMOS
Pixels: 5.0 MP (back) + 0.3 MP (front)
Technical specifications
For more information about Lenovo Mobile Phone functions,
Regulatory Notices and other useful manuals, go to
http://support.lenovo.com/.

Micro USB
Earphone jack
Receiver
MicrophoneOn/Off button
Speaker
5
Volume key
2
6
3
78
4
1
6
1
3
4
10
11
12
9
5
7
8
9
10 11
Back button
Home button Menu button
2
Front camera
12
Back camera
First glance

2
1
SIM1
3G/2G
SIM2
2G
SIM1
SIM2
SIM1
3G/2G
SIM2
2G
SIM1
SIM2
You need to insert the SIM card provided by your carrier to use cellular
services. Install your phone as shown.
DO NOT insert or remove the SIM cards while your phone is turned on.
Doing so can permanently damage your SIM card or your phone.
Step 3. Install the battery.
Step 1. Open the back cover.
Step 2. Insert the SIM cards and
the memory card.
Tip: Insert (U)SIM card into
SIM 1 slot and SIM card
into SIM 2 slot.
Step 4. Install the back cover.
Preparing your phone

Method 1. Connect your phone to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
For more information about battery safety, see the Important Product
Information Guide.
Charge the battery as shown.
2
1
Charging the battery

8306LV8001W
Printed in China
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be trademarks
or service marks of others.
First Edition (January 2014)
© Copyright Lenovo 2014.
Learn more
For more information about Lenovo Mobile Phone functions,
Regulatory Notices and other useful manuals, go to
http://support.lenovo.com/.
