Lenovo VIBE Z2 Pro User manual

Lenovo VIBE Z2 Pro
Quick Start Guide
ENGLISH
FRANÇAIS

Getting support
For support on network service and billing, contact your wireless
network operator. For instructions on how to use your VIBE, go to:
http://support.lenovo.com.
Read first-Regulatory information
Be sure to read the Regulatory Notice for your country or region
before using the wireless devices contained in your VIBE. To obtain a
PDF version of the Regulatory Notice, refer to the “Downloading
publications” section below.
Downloading publications
To download the publications for your VIBE, go to:
http://support.lenovo.com and follow the instructions on the screen.
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the United
States, other countries, or both.
Other company, product, or service names may be trademarks or
service marks of others.
ENGLISH

Contents
First glance................................................................................................ 1
Installing the Micro SIM card...................................................................... 2
Charging the battery.................................................................................. 3
Technical specifications ............................................................................. 4
Important safety and handling information ................................................. 5
Service and Support information.............................................................. 13
Warranty information................................................................................ 14
Environmental, recycling, and disposal information .................................. 16
Restriction of Hazardous Substances Directive (RoHS)............................ 17
Specific Absorption Rate information....................................................... 18
Precautionary Guidelines for mobile users................................................ 19

Microphone
Flashlight
Micro USB connector
Speaker
Front-facing camera
On/Off button
Volume buttons
Rear-facing camera
Headset connector
Micro-SIM-card trayReceiver
1
4
7
10
2
5
8
11
3
6
9
12
Anti-noise mic
11
9
2
3
4
12
108
765
1
1
1
First glance

A Micro SIM card provided by your carrier is required in order to use
cellular services. Install the Micro SIM card as shown.
Step 1.
Step 2.
Step 3.
Insert the SIM eject tool that comes with your VIBE into the
hole in the Micro-SIM-card tray.
Pull out the Micro-SIM-card tray and position the Micro SIM
card into the tray in correct orientation.
Carefully insert the tray with the installed Micro SIM card
back into the slot.
Only Micro SIM cards work with your VIBE.
Always turn off your VIBE first before you insert or remove a Micro SIM card.
Insert or remove a Micro SIM card with your VIBE on may damage your
Micro SIM card or VIBE permanently.
* In some countries, LTE is not supported.
Slot 1. Support *LTE/WCDMA/GSM
Slot 2. Only support GSM
Slot1
Slot2
1
2
Installing the Micro SIM card

Your VIBE has a built-in rechargeable battery. For more information about
battery safety, see the “Built-in rechargeable battery notice”. The battery of
your VIBE isn’t user replaceable; it can be replaced only by an authorized
service provider.
2
1
Low battery power Charging Fully charged
Charge the battery as shown.
Turn on
Press and hold the On/Off button for a few seconds.
Press and hold the On/Off button for a few seconds, then tap
Power off.
Press and hold the On/Off button for a few seconds, then tap
Restart.
Method 1.
Method 2.
Connect your VIBE to a power outlet using the cable and
USB power adapter that come with your VIBE.
Connect your VIBE to a computer using the cable that
comes with your VIBE.
Turn off
Restart
1
3
Charging the battery

Type: CMOS
Pixels: 16 megapixels (back) + 5 megapixels (front)
Processor: Qualcomm MSM8974AC
, quad-core , 2.5 GHz
Size: 6 inches Screen: multi-touch
Resolution: 2560 × 1440 pixels LCD type: IPS
Name: Lenovo VIBE Z2 Pro Model: Lenovo K920
Bluetooth 4.0
WLAN 802.11 a/b/g/n/ac
②LTE, DC-HSPA+, WCDMA, EDGE/GPRS/GSM
GPS
Battery: 4000 mAh
Height: 156 mm (6.14 inches) Width: 81.3 mm (3.20 inches)
Depth: 7.7 mm (0.30 inch) Weight: 179 g (0.39 lb)
Name and model
①Depending on the measuring method, the dimensions and weight
might vary slightly.
②In some counties, LTE is not supported.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
1
4
Technical specifications

1
5
Important safety and handling information
Important safety information
CAUTION
To avoid personal injury, property damage, or accidental damage to the product,
read all of the information in this section before using the product.
Handling
 Handle Lenovo Phone with care
Do not drop, bend, or puncture Lenovo Phone; do not insert foreign
objects into or place heavy objects on Lenovo Phone. Sensitive
components inside might become damaged.
 Prevent Lenovo Phone and adapter from getting wet
Do not immerse Lenovo Phone in water or leave Lenovo Phone in a
location where it can get saturated with water or other liquids.
Repairing
Do not disassemble or modify Lenovo Phone. Lenovo Phone is a sealed unit.
There are no end-user serviceable parts inside. All internal repairs must be
done by a Lenovo-authorized repair facility or a Lenovo-authorized technician.
Attempting to open or modify Lenovo Phone will void the warranty.
Lenovo Phone screen is made of glass. The glass might break if Lenovo Phone
is dropped on a hard surface, is the subject of a high impact, or is crushed by a
heavy object. If the glass chips or cracks, do not touch the broken glass or
attempt to remove it from Lenovo Phone. Stop using Lenovo Phone
immediately and contact Lenovo technical support for repair, replacement, or
disposal information.
Battery
Batteries supplied by Lenovo for use with your product have been tested for
compatibility and should only be replaced with approved parts.
Dispose of used batteries according to the instructions.

1
6
Rechargeable battery notice
CAUTION
Risk of explosion if the battery is replaced with an incorrect type.
When replacing the lithium battery, use only the same or an equivalent type
that is recommended by the manufacturer. The battery contains lithium and
can explode if not properly used, handled, or disposed of.
Dispose of used batteries according to the instructions
Do not:
 Throw or immerse into water
 Heat to more than 100°C (212°F)
 Repair or disassemble
Built-in rechargeable battery notice
CAUTION
Do not attempt to replace the internal rechargeable lithium ion battery. Contact
Lenovo Support for factory replacement.
Charging
Charge Lenovo Phone in the temperature range of 0°C (32 °F)—45°C (113°F).
You can use any of the following charging methods to safely recharge the
internal battery of Lenovo Phone:
Charging method Display on Display off
ac adapter Supported, but the battery
will charge slowly.
Supported
USB connection between
the dc-in connector on
Lenovo Phone and a USB
connector on a personal
computer or other devices
that comply with the USB
2.0 standards.
Supported, but will
compensate power
consumption and the battery
will charge more slowly than
usual.
Supported, but the
battery will charge
slowly.
