QuickInstallationGuide
ServeRAIDM1210SAS/SATAControllerforLenovoSystemx
ThankyouforpurchasingtheServeRAIDM1210SASSATAController
(hereafterreferredtoascontroller)forLenovo®Systemx.Beforeyou
installthecontroller,takeafewminutestoreadthisquickinstallation
guide.
Formoreinformationaboutthecontroller,refertothe
ServeRAIDM1210SAS/SATAControllerforLenovoSystem
xUser’sGuideontheServeRAIDmatrixWebsiteat
https:support.lenovo.comusendocumentsserv-raid.
Technicalsupport:T ogetassistanceforinstalling,configuring,or
usingthecontroller,gotohttp:www.lenovo.comsupport.
DAGER
Electricalcurrentfrompower,telephone,andcommunicationcablesishazardous.
Toavoidashockhazard:
•Donotconnectordisconnectanycablesorperforminstallation,maintenance,orreconfigurationofthis
productduringanelectricalstorm.
•Connectallpowercordstoaproperlywiredandgroundedelectricaloutlet.
•Connecttoproperlywiredoutletsanyequipmentthatwillbeattachedtothisproduct.
•Whenpossible,useonehandonlytoconnectordisconnectsignalcables.
•everturnonanyequipmentwhenthereisevidenceoffire,water,orstructuraldamage.
•Disconnecttheattachedpowercords,telecommunicationssystems,networks,andmodemsbeforeyou
openthedevicecovers,unlessinstructedotherwiseintheinstallationandconfigurationprocedures.
•Connectanddisconnectcablesasdescribedinthefollowingtablewheninstalling,moving,oropening
coversonthisproductorattacheddevices.
ToConnect:ToDisconnect:
1.TurneverythingOFF .
2.First,attachallcablestodevices.
3.Attachsignalcablestoconnectors.
4.Attachpowercordstooutlet.
5.TurndeviceON.
1.TurneverythingOFF .
2.First,removepowercordsfromoutlet.
3.Removesignalcablesfromconnectors.
4.Removeallcablesfromdevices.
1

Toinstallthecontroller,dothefollowing:
1.Unpackthecontrollerinastatic-freeenvironment,andinspectitfordamage.
Touchthestatic-protectivepackagethatcontainsthecontrollertoanyunpaintedsurfaceonthe
outsideoftheserver.Then,graspthecontrollerbythetopedgeoruppercorners,removeitfromthe
package,andinspectitfordamage.ContactyourLenovosalesrepresentativeorLenovoresellerif
thecontrollerappearstobedamaged.
Attention:Beforeyouchangethesystemconfiguration,makeabackupcopyofyourdatatoavoid
theriskofdataloss.
2.Preparetheserver.
Reviewallsafetyinformationprovidedwiththeserver.Turnofftheserver,anddisconnectthepower
cordfromtherearofthepowersupply.Dothesameforanyconnecteddevices.
3.Removetheservercover.
4.InsertthecontrollerintoanavailablePCIExpress(PCIe)slot.
Locateanemptyx4orx8PCIeslot.Removetheexpansion-slotbracketfortheselectedPCIeslot.
Savethebracketscrew,ifapplicable.ForthelocationandotherinformationaboutthePCIeslot,referto
theInstlltionndServiceGuideforyourserver.Themostup-to-dateInstlltionndServiceGuideis
alwaysavailablefordownloadathttp:www.lenovo.comsupport.
AlignthecontrollerwiththePCIeslot.Pressdowngentlyuntilthecontrollerisseatedfirmlyintheslot.
ThefollowingillustrationshowshowtoinsertthecontrollerintoaPCIeslot.
PCI Express Slot
Press
here
Screw
SFF-8643
Mini-SAS HD
Connector
ote:Yourcontrolleranditsbracketmightvaryfromthisillustration.SomePCIeslotssupportonly
PCIegraphicscards.Ifacontrollerisinstalledinoneoftheseslots,thecontrollerdoesnotfunction.
5.Securethecontrollerbrackettothesystemchassis.
Installthebracketscrew,ifapplicable,orengagethesystemretentionmechanismtosecurethe
controllertothesystemchassis.
2

6.ConnecttheSAScablebetweenthecontrollerandtheSASbackplaneoranyotherSATAor
SASdevice(ifapplicable).
Theprecedingfigureshowsthelocationofthecontrollerconnector.Thecontrollerconnectstoan
internaldevicethroughaninternalx4mini-SASHDconnector(SFF-8643).Ifyouuseothercables,
ensurethattheyconformtothecontrollerspecificationsasdescribedinthecontrolleruser’sguide.
7.Installtheservercover,connectthepowercords,andturnontheserver.
Trademarks
Lenovo,theLenovologo,andSystemxaretrademarksofLenovointheUnitedStates,othercountries,or
both.
Othercompany,product,orservicenamesmaybetrademarksorservicemarksofothers.
3

FirstEdition(April2016)
©CopyrightLenovo2016.
LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuanttoaGeneralServices
Administration“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.
GS-35F-05925.
