Lenovo IdeaCentre Q180 Guide Manual

Front view Install optical drive (selected
models only)
Initial setup instructions Rear view
Tiny Desktop PC
Q180 Series
1
2
Power button
Hard disk drive indicator
Optical drive
Memory card reader
USB ports (2)
Headphone connector
Microphone connector
SPDIF port
VGA connector
USB ports (5)
HDMI-out port
Ethernet connector
Power connector
Connect to power
Version: 1.0 2011.08
31500792
Read the detailed information in the Safety and Warranty Guide
before using this computer.
Notes:
• FiguresandillustrationsinthisQuickReferenceare
provided for reference only and may differ from actual
product appearance.
• Productdesignandspecicationsmaybechangedwithout
notice.
• Thecolorandshapemayvarydependingonthemodel.
Attention: Be sure not to block any air vents on the computer.
Blocked air vents may cause thermal problems.

Install metal bracket Stand
Thecomputerchassiscanbeplacedinaverticalposition.
Note: Make sure to install the base stand before placing the
chassis in a vertical position.
Thecomputerchassiscanalsobeplacedinahorizontalposition.
