Lenovo ThinkCentre E63z User manual

ThinkCentreE63z
UserGuide
MachineTypes:10D4,10D5,10D6,10D7,10E0,10E1,10E2,10E3,
10EJ,10EK,10EL,and10EM

Note:eforeusingthisinformationandtheproductitsupports,besuretoreadandunderstandthe“Read
thisfirst:Importantsafetyinformation”onpageiiiandAppendixF“Notices”onpage87.
FourthEdition(May2016)
©CopyrightLenovo201,2016.
LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuanttoaGeneralServices
Administration“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.
GS-35F-05925.

Contents
Readthisfirst:Importantsafety
information..............iii
eforeusingthismanual............iii
Serviceandupgrades.............iii
Staticelectricityprevention...........iv
Powercordsandpoweradapters........iv
Extensioncordsandrelateddevices.......v
Plugsandoutlets...............v
Externaldevices...............v
Heatandproductventilation..........v
Operatingenvironment............vi
Powersupplystatement............vi
Cleaningandmaintenance..........vii
Glasspartsnotice.............vii
Tip-overhazardpreventionnotice.......vii
Chapter1.Productoverview......1
Locations..................1
Locatingconnectors,controls,andindicators
onthefrontofyourcomputer........2
Locatingconnectorsontherearofyour
computer................3
Locatingthemachinetypeandmodellabel..4
Adjustingtheframestand...........5
Features..................5
Specifications................9
Lenovoprograms..............9
Accessingaprogramonyourcomputer...10
AnintroductiontoLenovoprograms....10
Chapter2.Usingyourcomputer...13
Registeringyourcomputer..........13
UsingWindowsshortcutkeys.........13
Usingthewheelmouse...........14
Settingthecomputervolume.........14
AddinganicontotheWindowsnotificationarea.14
Managingpower..............15
Advancedconfigurationandpowerinterface
(ACPI)IOS..............15
AutomaticPower-onfeatures.......15
Usingthesingle-touchormulti-touchfeature...15
NavigatingamongscreensontheWindows8.1
operatingsystem..............16
AccessingControlPanelontheWindows8.1
operatingsystem..............17
Frequentlyaskedquestions.........17
Chapter3.Youandyourcomputer..19
Accessibilityandcomfort..........19
Arrangingyourworkspace........19
Comfort...............19
Glareandlighting............20
Aircirculation.............20
Electricaloutletsandcablelengths.....20
Accessibilityinformation.........20
Movingyourcomputertoanothercountryor
region..................23
Chapter.Security..........25
Securityfeatures..............25
AttachingaKensington-stylecablelock.....26
Usingpasswords..............26
IOSpasswords............26
Windowspasswords..........27
Usingandunderstandingfirewalls.......27
Protectingdataagainstviruses........27
Chapter5.Advancedconfiguration..29
UsingtheSetupUtilityprogram........29
StartingtheSetupUtilityprogram.....29
Viewingandchangingsettings......29
UsingIOSpasswords.........30
Enablingordisablingadevice.......31
Selectingastartupdevice........31
EnablingErPLPScompliancemode....32
ExitingtheSetupUtilityprogram......32
UpdatingorrecoveringtheIOS.......33
IOSlevels..............33
Usingsystemprograms.........33
ChangingtheIOSsettingsbeforeinstallinga
newoperatingsystem..........34
UpdatingtheIOS...........34
Chapter6.Preventingproblems...35
Keepingyourcomputercurrent........35
Gettingthelatestdevicedriversforyour
computer...............35
Gettingthelatestsystemupdates.....35
Cleaningandmaintenance..........35
asics................36
Cleaningyourcomputer.........36
Goodmaintenancepractices.......37
Movingyourcomputer...........38
Chapter7.Troubleshootingand
diagnostics..............39
©CopyrightLenovo2014,2016i

asictroubleshooting............39
Troubleshootingprocedure..........40
Troubleshooting..............40
Audioproblems............41
Intermittentproblems..........41
Harddiskdriveproblems.........42
Problemswiththekeyboardormouse...42
Monitorproblems............43
Networkingproblems..........44
Ihaveconnectedanoptiontomycomputer,
butitdoesnotwork...........46
Performanceandlockupproblems.....46
Theprinterdoesnotwork........47
Serialconnectorcannotbeaccessed....47
Softwareproblems...........47
USdeviceproblems..........48
Diagnostics................49
LenovoSolutionCenter.........49
Chapter8.Recoveryinformation...51
RecoveryinformationfortheWindows7operating
system..................51
Creatingandusingrecoverymedia.....51
Performingbackupandrecoveryoperations.52
Creatingandusingarescuemedium....54
Reinstallingprogramsanddevicedrivers..54
Solvingrecoveryproblems........56
RecoveryinformationfortheWindows8.1
operatingsystem..............56
Refreshingyourcomputer........56
Resettingyourcomputertothefactory-default
settings................56
Usingtheadvancedstartupoptions....57
RecoveringyouroperatingsystemifWindows
8.1failstostart.............57
RecoveryinformationfortheWindows10operating
system..................58
Chapter9.Installingorreplacing
hardware...............61
Handlingstatic-sensitivedevices.......61
Installingorreplacinghardware........61
Installingexternaloptions........61
Installingorremovingtheacpoweradapter.61
Replacingthekeyboardormouse.....63
Replacingthewirelesskeyboardormouse..64
Obtainingdevicedrivers.........67
Chapter10.Gettinginformation,help,
andservice..............69
Informationresources............69
Windowshelpsystem..........69
SafetyandWarranty...........69
LenovoWebsite............69
LenovoSupportWebsite.........70
Helpandservice..............70
Usingthedocumentationanddiagnostic
program...............70
Callingforservice............70
Usingotherservices..........71
Purchasingadditionalservices......71
AppendixA.Regulatory
information..............73
Exportclassificationnotice..........73
Electronicemissionsnotices.........73
FederalCommunicationsCommission
DeclarationofConformity........73
Eurasiancompliancemark..........75
razilaudionotice.............75
Mexicowireless-radiocomplianceinformation..75
Taiwanvisionprecautionnotice........76
Additionalregulatoryinformation.......76
AppendixB.WEEEandrecycling
information..............77
ImportantWEEEinformation.........77
RecyclinginformationforJapan........77
Recyclinginformationforrazil........78
atteryrecyclinginformationforTaiwan.....78
atteryrecyclinginformationfortheEuropean
Union..................79
AppendixC.RestrictionofHazardous
Substances(RoHS)Directive.....81
EuropeanUnionRoHS...........81
ChinaRoHS................81
TurkishRoHS...............81
UkraineRoHS...............82
IndiaRoHS................82
TaiwanRoHS...............82
AppendixD.ChinaEnergyLabel...83
AppendixE.ENERGYSTARmodel
information..............85
AppendixF .Notices..........87
Trademarks................88
Index..................89
iiThinkCentreE63zUserGuide

Readthisfirst:Importantsafetyinformation
Thischaptercontainsthesafetyinformationthatyoumustbefamiliarwith.
Beforeusingthismanual
CAUTION:
Beforeusingthismanual,besuretoreadandunderstandalltherelatedsafetyinformationforthis
product.RefertotheinformationinthissectionandthesafetyinformationintheSafety,Warranty,and
SetupGuidethatyoureceivedwiththisproduct.Readingandunderstandingthissafetyinformation
reducestheriskofpersonalinjuryanddamagetoyourproduct.
IfyounolongerhaveacopyoftheSafety,Warranty,andSetupGuide,youcanobtainaPortableDocument
Format(PDF)versionfromtheLenovo®SupportWebsiteathttp://www.lenovo.com/UserManuals.The
LenovoSupportWebsitealsoprovidestheSafety,Warranty,andSetupGuideandthisUserGuidein
additionallanguages.
Serviceandupgrades
DonotattempttoserviceaproductyourselfunlessinstructedtodosobytheCustomerSupportCenteror
yourdocumentation.OnlyuseaServiceProviderwhoisapprovedtorepairyourparticularproduct.
Note:Somecomputerpartscanbeupgradedorreplacedbythecustomer.Upgradestypicallyare
referredtoasoptions.ReplacementpartsapprovedforcustomerinstallationarereferredtoasCustomer
ReplaceableUnits,orCRUs.Lenovoprovidesdocumentationwithinstructionswhenitisappropriatefor
customerstoinstalloptionsorreplaceCRUs.Youmustcloselyfollowallinstructionswheninstallingor
replacingparts.TheOffstateofapowerindicatordoesnotnecessarilymeanthatvoltagelevelsinsidea
productarezero.eforeyouremovethecoversfromaproductequippedwithapowercord,alwaysensure
thatthepoweristurnedoffandthattheproductisunpluggedfromanypowersource.Formoreinformation
onCRUs,refertoChapter9“Installingorreplacinghardware”onpage61.Ifyouhaveanyquestionsor
concerns,contacttheCustomerSupportCenter.
Althoughtherearenomovingpartsinyourcomputerafterthepowercordhasbeendisconnected,the
followingwarningsarerequiredforyoursafety.
CAUTION:
Hazardousmovingparts.Keepfingersandotherbodypartsaway.
CAUTION:
Beforeyouopenthecomputercover,turnoffthecomputerandwaitseveralminutesuntilthe
computeriscool.
©CopyrightLenovo2014,2016iii

Staticelectricityprevention
Staticelectricity,althoughharmlesstoyou,canseriouslydamagecomputercomponentsandoptions.
Improperhandlingofstatic-sensitivepartscancausedamagetothepart.Whenyouunpackanoption
orCRU,donotopenthestatic-protectivepackagecontainingthepartuntiltheinstructionsdirectyou
toinstallit.
WhenyouhandleoptionsorCRUs,orperformanyworkinsidethecomputer,takethefollowingprecautions
toavoidstatic-electricitydamage:
•Limityourmovement.Movementcancausestaticelectricitytobuilduparoundyou.
•Alwayshandlecomponentscarefully.Handleadapters,memorymodules,andothercircuitboardsbythe
edges.Nevertouchexposedcircuitry.
•Preventothersfromtouchingcomponents.
•Whenyouinstallastatic-sensitiveoptionorCRU,touchthestatic-protectivepackagecontainingthe
parttoametalexpansion-slotcoverorotherunpaintedmetalsurfaceonthecomputerforatleasttwo
seconds.Thisreducesstaticelectricityinthepackageandyourbody.
•Whenpossible,removethestatic-sensitivepartfromthestatic-protectivepackagingandinstallthepart
withoutsettingitdown.Whenthisisnotpossible,placethestatic-protectivepackagingonasmooth,
levelsurfaceandplacethepartonit.
•Donotplacethepartonthecomputercoverorothermetalsurface.
Powercordsandpoweradapters
Useonlythepowercordsandpoweradapterssuppliedbytheproductmanufacturer.Donotusetheac
powercordforotherdevices.
Thepowercordsshallbesafetyapproved.ForGermany,itshallbeH03VV-F,3G,0.75mm2(thepowercord
connectedtothepoweradapter),H05VV-F,3G,0.75mm2(thepowercordconnectedtotheinternalpower
supplyassembly),orbetter.Forothercountries,thesuitabletypesshallbeusedaccordingly.
Neverwrapapowercordaroundapoweradapterorotherobject.Doingsocanstressthecordinwaysthat
cancausethecordtofray,crack,orcrimp.Thiscanpresentasafetyhazard.
Alwaysroutepowercordssothattheywillnotbewalkedon,trippedover,orpinchedbyobjects.
Protectpowercordandpoweradaptersfromliquids.Forinstance,donotleaveyourpowercordorpower
adapternearsinks,tubs,toilets,oronfloorsthatarecleanedwithliquidcleansers.Liquidscancausea
shortcircuit,particularlyifthepowercordorpoweradapterhasbeenstressedbymisuse.Liquidsalsocan
causegradualcorrosionofpowercordterminalsand/ortheconnectorterminalsonapoweradapter,
whichcaneventuallyresultinoverheating.
Ensurethatallpowercordconnectorsaresecurelyandcompletelypluggedintoreceptacles.
Donotuseanypoweradapterthatshowscorrosionattheacinputpinsorshowssignsofoverheating(such
asdeformedplastic)attheacinputoranywhereonthepoweradapter.
Donotuseanypowercordswheretheelectricalcontactsoneitherendshowsignsofcorrosionor
overheatingorwherethepowercordappearstohavebeendamagedinanyway.
ivThinkCentreE63zUserGuide

Extensioncordsandrelateddevices
Ensurethatextensioncords,surgeprotectors,uninterruptiblepowersupplies,andpowerstripsthatyouuse
areratedtohandletheelectricalrequirementsoftheproduct.Neveroverloadthesedevices.Ifpowerstrips
areused,theloadshouldnotexceedthepowerstripinputrating.Consultanelectricianformoreinformation
ifyouhavequestionsaboutpowerloads,powerrequirements,andinputratings.
Plugsandoutlets
Ifareceptacle(poweroutlet)thatyouintendtousewithyourcomputerequipmentappearstobedamaged
orcorroded,donotusetheoutletuntilitisreplacedbyaqualifiedelectrician.
Donotbendormodifytheplug.Iftheplugisdamaged,contactthemanufacturertoobtainareplacement.
Donotshareanelectricaloutletwithotherhomeorcommercialappliancesthatdrawlargeamountsof
electricity;otherwise,unstablevoltagemightdamageyourcomputer,data,orattacheddevices.
Someproductsareequippedwithathree-prongedplug.Thisplugfitsonlyintoagroundedelectricaloutlet.
Thisisasafetyfeature.Donotdefeatthissafetyfeaturebytryingtoinsertitintoanon-groundedoutlet.If
youcannotinserttheplugintotheoutlet,contactanelectricianforanapprovedoutletadapterortoreplace
theoutletwithonethatenablesthissafetyfeature.Neveroverloadanelectricaloutlet.Theoverallsystem
loadshouldnotexceed80percentofthebranchcircuitrating.Consultanelectricianformoreinformation
ifyouhavequestionsaboutpowerloadsandbranchcircuitratings.
esurethatthepoweroutletyouareusingisproperlywired,easilyaccessible,andlocatedclosetothe
equipment.Donotfullyextendpowercordsinawaythatwillstressthecords.
esurethatthepoweroutletprovidesthecorrectvoltageandcurrentfortheproductyouareinstalling.
Carefullyconnectanddisconnecttheequipmentfromtheelectricaloutlet.
Externaldevices
DonotconnectordisconnectanyexternaldevicecablesotherthanUniversalSerialus(US)cableswhile
thecomputerpowerison;otherwise,youmightdamageyourcomputer.Toavoidpossibledamageto
attacheddevices,waitatleastfivesecondsafterthecomputerisshutdowntodisconnectexternaldevices.
Heatandproductventilation
Computers,poweradapters,andmanyaccessoriescangenerateheatwhenturnedonandwhenbatteries
arecharging.Alwaysfollowthesebasicprecautions:
•Donotleaveyourcomputer,poweradapter,oraccessoriesincontactwithyourlaporanypartofyour
bodyforanextendedperiodwhentheproductsarefunctioningorwhenthebatteryischarging.Your
computer,poweradapter,andmanyaccessoriesproducesomeheatduringnormaloperation.Extended
contactwiththebodycouldcausediscomfortor,potentially,askinburn.
•Donotchargethebatteryoroperateyourcomputer,poweradapter,oraccessoriesnearflammable
materialsorinexplosiveenvironments.
•Ventilationslots,fans,andheatsinksareprovidedwiththeproductforsafety,comfort,andreliable
operation.Thesefeaturesmightinadvertentlybecomeblockedbyplacingtheproductonabed,sofa,
carpet,orotherflexiblesurface.Neverblock,cover,ordisablethesefeatures.
©CopyrightLenovo2014,2016v

Inspectyourdesktopcomputerfordustaccumulationatleastonceeverythreemonths.eforeinspecting
yourcomputer,turnoffthepowerandunplugthecomputer'spowercordfromtheelectricaloutlet;then
removeanydustfromventsandperforationsinthebezel.Ifyounoticeexternaldustaccumulation,then
examineandremovedustfromtheinsideofthecomputerincludingheatsinkinletfins,powersupplyvents,
andfans.Alwaysturnoffandunplugthecomputerbeforeopeningthecover.Ifpossible,avoidoperating
yourcomputerwithintwofeetofhigh-trafficareas.Ifyoumustoperateyourcomputerinornearahigh-traffic
area,inspectand,ifnecessary,cleanyourcomputermorefrequently.
Foryoursafetyandtomaintainoptimumcomputerperformance,alwaysfollowthesebasicprecautions
withyourdesktopcomputer:
•Keepthecoverclosedwheneverthecomputerispluggedin.
•Regularlyinspecttheoutsideofthecomputerfordustaccumulation.
•Removedustfromventsandanyperforationsinthebezel.Morefrequentcleaningsmightberequiredfor
computersindustyorhigh-trafficareas.
•Donotrestrictorblockanyventilationopenings.
•Donotstoreoroperateyourcomputerinsidefurniture,asthismightincreasetheriskofoverheating.
•Airflowtemperaturesintothecomputershouldnotexceed35°C(95°F).
•Donotinstallairfiltrationdevices.Theymayinterferewithpropercooling.
Operatingenvironment
Theoptimalenvironmentinwhichtouseyourcomputeris10°C–35°C(50°F–95°F)withhumidityranging
between35%and80%.Ifyourcomputerisstoredortransportedintemperatureslessthan10°C(50°F),
allowthecoldcomputertoriseslowlytoanoptimaloperatingtemperatureof10°C–35°C(50°F–95°F)before
use.Thisprocesscouldtaketwohoursinextremeconditions.Failuretoallowyourcomputertorisetoan
optimaloperatingtemperaturebeforeusecouldresultinirreparabledamagetoyourcomputer.
Ifpossible,placeyourcomputerinawell-ventilatedanddryareawithoutdirectexposuretosunshine.
Keepelectricalappliancessuchasanelectricfan,radio,high-poweredspeakers,airconditioner,and
microwaveovenawayfromyourcomputerbecausethestrongmagneticfieldsgeneratedbythese
appliancescandamagethemonitoranddataontheharddiskdrive.
Donotplaceanybeveragesontopoforbesidethecomputerorotherattacheddevices.Ifliquidisspilledon
orinthecomputeroranattacheddevice,ashortcircuitorotherdamagemightoccur.
Donoteatorsmokeoveryourkeyboard.Particlesthatfallintoyourkeyboardcancausedamage.
Powersupplystatement
Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.
viThinkCentreE63zUserGuide

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabelattached.
Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwithoneoftheseparts,
contactaservicetechnician.
Cleaningandmaintenance
Keepyourcomputerandworkspaceclean.Shutdownthecomputerandthendisconnectthepower
cordbeforecleaningthecomputer.Donotsprayanyliquiddetergentdirectlyonthecomputeroruse
anydetergentcontainingflammablematerialtocleanthecomputer.Spraythedetergentonasoftcloth
andthenwipethecomputersurfaces.
Glasspartsnotice
CAUTION:
Somepartsofyourproductmaybemadeofglass.Thisglasscouldbreakiftheproductisdropped
onahardsurfaceorreceivesasubstantialimpact.Ifglassbreaks,donottouchorattempttoremove
it.Stopusingyourproductuntiltheglassisreplacedbytrainedservicepersonnel.
Tip-overhazardpreventionnotice
•Placethecomputeronasturdyandlowbase,oranchorthefurnitureandpositionthecomputeras
farbackonthefurnitureaspossible.
•Keepremotecontrols,toys,andotheritemsthatmightattractchildrenoffthecomputer.
•Keepthecomputer,cables,andcordsoutofthereachofchildren.
•Supervisechildreninroomswherethesesafetytipshavenotbeenfollowed.
©CopyrightLenovo2014,2016vii

viiiThinkCentreE63zUserGuide

Chapter1.Productoverview
Thischapterprovidesthefollowinginformation:
•Locationsofconnectors
•Computerfeatures
•SoftwareprogramsprovidedbyLenovo
Locations
Thissectionprovidesthefollowingtopics:
•“Locatingconnectors,controls,andindicatorsonthefrontofyourcomputer”onpage2
•“Locatingconnectorsontherearofyourcomputer”onpage3
•“Locatingthemachinetypeandmodellabel”onpage4
Note:Thecomponentsinyourcomputermightlookslightlydifferentfromtheillustrations.
©CopyrightLenovo2014,20161

Locatingconnectors,controls,andindicatorsonthefrontofyour
computer
Thefollowingillustrationshowsthelocationsoftheconnectors,controls,andindicatorsonthefrontofyour
computer.
Figure1.Frontconnector,control,andindicatorlocations
1Integratedcameraactivityindicator(availableonsome
models)
2Integratedcamera(availableonsomemodels)
3Integratedmicrophones4Powerindicator
5Internalspeakers6Cardreaderslot(availableonsomemodels)
7Headsetconnector8US3.0connectororAlwaysOnUSconnector
2ThinkCentreE63zUserGuide

Locatingconnectorsontherearofyourcomputer
Thefollowingillustrationshowsthelocationsoftheconnectorsontherearofyourcomputer.Some
connectorsontherearofyourcomputerarecolor-codedtohelpyoudeterminewheretoconnectthe
cablesonyourcomputer.
Figure2.Rearconnectorlocations
1US2.0connectors(2)2HDMIconnector(availableonsomemodels)
3Ethernetconnector4acpoweradapterconnector
5Security-lockslot6Powerbutton
ConnectorDescription
acpoweradapterconnectorUsedtoattachtheacpoweradaptertoyourcomputerforpowersupply.
EthernetconnectorUsedtoattachanEthernetcableforalocalareanetwork(LAN).
Note:TooperatethecomputerwithinFCCClasslimits,useaCategory5eor
betterEthernetcable.
HDMIconnectorUsedtodeliveruncompressedhigh-definitionvideoandmultichanneldigitalaudio
signalsthroughasinglecable.Ahigh-performancemonitor,adirectdrivemonitor,
oranotheraudioorvideodevicethatusesaHigh-DefinitionMultimediaInterface
(HDMI)connectorcanbeattachedtothisHDMIconnector.
US2.0connectorUsedtoattachadevicethatrequiresaUS2.0connection,suchasakeyboard,a
mouse,ascanner,aprinter,orapersonaldigitalassistant(PDA).
Chapter1.Productoverview3

Locatingthemachinetypeandmodellabel
Themachinetypeandmodellabelidentifiesyourcomputer.WhenyoucontactLenovoforhelp,themachine
typeandmodelinformationhelpssupporttechnicianstoidentifyyourcomputerandprovidefasterservice.
Themachinetypeandmodellabelisattachedonthebottomofyourcomputerasshown.
Figure3.Machinetypeandmodellabel
ThinkCentreE63zUserGuide

Adjustingtheframestand
Yourcomputermightcomewithaframestandthatyoucanusetoadjustthecomputertoyourcomfortable
position.Pullthestandopenandadjustthepositionofthecomputeratanangleofbetween10°and60°
asshowninthefollowingillustration.
CAUTION:
Ensurethattheangleisatleast10°fromtheverticalposition;otherwise,thecomputermightbe
unstableandtipover.
60
Figure.Adjustingtheframestand
Features
Thecomputerfeaturesintroducedinthissectioncoversavarietyofmodels.
Toviewtheinformationaboutyourspecificmodel,dooneofthefollowing:
•OntheMicrosoft®Windows®7operationsystem,clickStart,right-clickComputer,andselectProperties
toviewtheinformation.
•OntheMicrosoftWindows8.1operatingsystem,gotothedesktopandmoveyourpointertothe
top-rightorbottom-rightcornerofthescreentodisplaythecharms.ThenclickSettings➙PCinfoto
viewtheinformation.
•OntheMicrosoftWindows10operatingsystem,clicktheStartbuttontoopentheStartmenu.Then,click
Settings➙System➙Abouttoviewtheinformation.
Microprocessor
Toviewthemicroprocessorinformationofyourcomputer,dothefollowing:
•OntheMicrosoftWindows7operationsystem,clickStart,right-clickComputer,andselectProperties
toviewtheinformation.
Chapter1.Productoverview5

•OntheMicrosoftWindows8.1operatingsystem,gotothedesktopandmoveyourpointertothe
top-rightorbottom-rightcornerofthescreentodisplaythecharms.ThenclickSettings➙PCinfoto
viewtheinformation.
•OntheMicrosoftWindows10operatingsystem,clicktheStartbuttontoopentheStartmenu.Then,click
Settings➙System➙Abouttoviewtheinformation.
Memory
Yourcomputersupportsuptotwodoubledatarate3unbuffereddualinlinememorymodules(DDR3
UDIMMs).
Todeterminetheamountofmemoryinstalledonyourcomputer,dothefollowing:
•OntheMicrosoftWindows7operatingsystem,clickStart,right-clickComputer,andselectProperties
toviewtheinformation.
•OntheMicrosoftWindows8.1operatingsystem,gotothedesktopandmoveyourpointertothe
top-rightorbottom-rightcornerofthescreentodisplaythecharms.ThenclickSettings➙PCinfoto
viewtheinformation.
•OntheMicrosoftWindows10operatingsystem,clicktheStartbuttontoopentheStartmenu.Then,click
Settings➙System➙Abouttoviewtheinformation.
Internaldrives
•Cardreader(availableonsomemodels)
•StandardSerialAdvancedTechnologyAttachment(SATA)harddiskdrive
•SATAsolid-statedrive(availableonsomemodels)
•SATAhybriddrive(availableonsomemodels)
Videofeatures
Onsomemodels,theintegratedgraphicssupportsHDMIconnectoronyourcomputer.
Audiofeatures
•Headsetconnector
•Integratedhigh-definition(HD)audio
•Internalspeakers
Input/Output(I/O)features
•Headsetconnector
•Ethernetconnector
•USconnectors
•AlwaysOnUSconnector(availableonsomemodels)
Formoreinformation,see“Locatingconnectors,controls,andindicatorsonthefrontofyourcomputer”on
page2and“Locatingconnectorsontherearofyourcomputer”onpage3.
Powersupply
65-wattautomaticvoltage-sensingpowersupply
Wirelessfeatures
Dependingonyourcomputermodel,thefollowingwirelessfeaturesaresupported:
•Wirelesslocalareanetwork(LAN)
6ThinkCentreE63zUserGuide

•luetooth
Systemmanagementfeatures
•Abilitytostorepower-onself-test(POST)hardwaretestresults
•DesktopManagementInterface(DMI)
DesktopManagementInterfaceprovidesacommonpathforuserstoaccessinformationaboutall
aspectsofacomputer.Theinformationincludesprocessortype,installationdate,attachedprintersand
otherperipherals,powersources,maintenancehistory,andsoon.
•ErPLPScompliancemode
Theenergy-relatedproductsdirective(ErP)lowestpowerstate(LPS)compliancemodereducesthe
consumptionofelectricitywhenyourcomputerisinsleeporoffmode.Formoreinformation,see
“EnablingErPLPScompliancemode”onpage32.
•PrebootExecutionEnvironment(PXE)
PrebootExecutionEnvironmentenablescomputerstostartthroughanetworkinterfaceindependentof
datastoragedevices(suchastheharddiskdrive)orinstalledoperatingsystems.
•SystemManagement(SM)asicInput/OutputSystem(IOS)andSMsoftware
TheSMIOSspecificationdefinesdatastructuresandaccessmethodsthatcanbeusedtoread
managementdatastoredintheIOSofacomputer.
•WakeonLAN
WakeonLANisanEthernetcomputernetworkingstandardthatallowsacomputertobeturnedon
orwokenupbyanetworkmessage.Themessageusuallyissentbyaprogramrunningonanother
computeronthesameLAN.
•WindowsManagementInstrumentation(WMI)
WindowsManagementInstrumentationisasetofextensionstotheWindowsDriverModel.Itprovidesan
operatingsysteminterfacethroughwhichinstrumentedcomponentsprovideinformationandnotification.
Securityfeatures
•AbilitytoenableanddisabledevicesandUSconnectors
Formoreinformation,see“Enablingordisablingadevice”onpage31.
•Avarietyofpasswordstodeterunauthorizeduseofyourcomputer
Formoreinformation,see“Usingpasswords”onpage26.
•ComputraceAgentsoftwareembeddedinfirmware
TheComputraceAgentsoftwareisanITassetmanagementandcomputertheftrecoverysolution.
Thesoftwaredetectsifchangeshavebeenmadeonthecomputer,suchashardware,software,or
thecomputercall-inlocation.YoumighthavetopurchaseasubscriptiontoactivatetheComputrace
Agentsoftware.
•Startupsequencecontrol
Formoreinformation,see“Selectingorchangingthestartupdevicesequence”onpage31.
•Startupwithoutkeyboardormouse
Yourcomputerisabletologintotheoperatingsystemwithoutkeyboardormouseconnected.
•SupportforaKensington-stylecablelock
Formoreinformation,see“AttachingaKensington-stylecablelock”onpage26.
Preinstalledoperatingsystem
Yourcomputerispreinstalledwithoneofthefollowingoperatingsystems:
Chapter1.Productoverview7

•MicrosoftWindows7operatingsystem
•MicrosoftWindows8.1operatingsystem
•MicrosoftWindows10operatingsystem
Operatingsystem(s),certifiedortestedforcompatibility(variesbymodeltype)
Theoperatingsystem(s)listedherearebeingcertifiedortestedforcompatibilityatthetimethispublication
goestopress.AdditionaloperatingsystemsmightbeidentifiedbyLenovoascompatiblewithyourcomputer
followingthepublicationofthismanual.Thislistissubjecttochange.Todetermineifanoperatingsystem
hasbeencertifiedortestedforcompatibility,checktheWebsiteoftheoperatingsystemprovider.
•Linux®
8ThinkCentreE63zUserGuide

Specifications
Thissectionliststhephysicalspecificationsforyourcomputer.
Dimensionsandweightwithoutpackage
Width:488mm(19.21inches)
Height:346mm(13.62inches)
Depth:62mm(2.44inches)
Maximumconfigurationasshipped:4.8kg(12.86lb)
Dimensionsandweightwithpackage
Width:590mm(23.23inches)
Height:449mm(17.68inches)
Depth:140mm(5.51inches)
Maximumconfigurationasshipped:7.23kg(19.37lb)
Environment
•Airtemperature:
Operating:From10°C(50°F)to35°C(95°F)
Storageinoriginalshippingpackage:From-40°C(-40°F)to60°C(140°F)
Storagewithoutpackage:From-10°C(14°F)to60°C(140°F)
•Humidity:
Operating:20%–80%(non-condensing)
Storage:20%–90%(non-condensing)
•Altitude:
Operating:From-15.2m(-50ft)to3048m(10000ft)
Storage:From-15.2m(-50ft)to10668m(35000ft)
Electricalinput
Inputvoltage:
•Lowrange:
Minimum:100Vac
Maximum:127Vac
Inputfrequency:50/60Hz
•Highrange:
Minimum:200Vac
Maximum:240Vac
Inputfrequency:50/60Hz
Lenovoprograms
YourcomputercomeswithLenovoprogramstohelpyouworkmoreeasilyandsecurely.Dependingon
theWindowsoperatingsystempreinstalled,theprogramsmightvary.
Chapter1.Productoverview9

Accessingaprogramonyourcomputer
Note:ForWindows7,someoftheLenovoprogramsmightbereadytobeinstalled,soyouneedtoinstall
themmanually.Then,youcanaccessandusetheseprograms.Toinstallaprogramthatisreadytobe
installed,opentheLenovoThinkVantage®Toolsprogram,andthenviewtheprogramiconsusingTiles.
Followtheinstructionsundergreyed-outiconstolocatetheiconforthedesiredprogram.Double-click
theicontoinstalltheprogram.
Toaccessaprogramonyourcomputer,dooneofthefollowing:
•ForWindows7orWindows10:
–FromWindowsSearch:
1.DependingonyourWindowsversion,dooneofthefollowing:
–ForWindows7:ClicktheStartbuttontoopentheStartmenu,andthentypetheprogram
nameintothesearchbox.
–ForWindows10:TypetheprogramnameintothesearchboxnexttotheStartbutton.
2.Inthesearchresults,clickthenameofthedesiredprogramtolaunchtheprogram.
–FromtheStartmenuorControlPanel:
1.ClicktheStartbuttontoopentheStartmenu.Then,clickthenameofthedesiredprogramto
launchtheprogram.
2.Iftheprogramnameisnotdisplayed,clickAllProgramsforWindows7orAllappsforWindows
10todisplaytheprogramlist.Fromthelistorafolderinthelist,clickthenameofthedesired
programtolaunchtheprogram.
3.IftheprogramnameisnotdisplayedontheStartmenu,accesstheprogramfromControlPanel.
a.DependingonyourWindowsversion,dooneofthefollowing:
–ForWindows7:ClickControlPanelontheStartmenu.
–ForWindows10:Right-clicktheStartbuttontoopentheStartcontextmenu,andthen
clickControlPanel.
b.ViewControlPanelusingLargeiconsorSmallicons,andthenclickthenameofthedesired
programtolaunchtheprogram.
•ForWindows8.1:
1.PresstheWindowskeytogototheStartscreen.Clickthenameofthedesiredprogramto
launchtheprogram.
2.Ifyoucannotfindtheprogramyouneed,clickthearrowiconinthebottom-leftcornerofthe
screentogototheAppsscreen.Findthedesiredprogramintheappslistorsearchforitinthe
searchboxinthetop-rightcornerofthescreen.
AnintroductiontoLenovoprograms
ThissectionprovidesinformationaboutthemajorLenovoprogramsavailableonyouroperatingsystem.
Note:Dependingonyourcomputermodel,someofthefollowingprogramsmightnotbeavailable.
•ForWindows7only:
–LenovoPowerENGAGE
TheLenovoPowerENGAGEprogramenablesyoutoregisteryourcomputerwithLenovo.
10ThinkCentreE63zUserGuide
