Aboutthisdocument
ThisdocumentprovidesinformationaboutIntel®ActiveManagementTechnology(IntelAMT)forLenovo®
ThinkCentre®M91pdesktopcomputers.Thisdocumentprovidesstep-by-stepinstructionsonhowtouse
IntelAMT.
ThisdocumentisintendedfortrainedITprofessionalsorthoseresponsibleforconguringcomputers
throughouttheirorganizations.Thereadersshouldhavebasicknowledgeofnetworkandcomputer
technology,andbefamiliarwiththetermsTCP/IP,DHCP ,IDE,DNS,SubnetMask,DefaultGateway,Domain
Name,andsoon.
Thisdocumentprovidesinformationaboutthefollowingtopics:
Chapter1“IntroductiontoIntelvProandIntelAMT”onpage1:Thischapterprovidesageneralintroduction
toIntelvPro™andIntelAMT.
Chapter2“FeaturesandbenetsofIntelAMT”onpage3:Thischapterintroducesthefeaturesand
benetsofIntelAMT.
Chapter3“MainfeaturesofcomputersbuiltwithIntelAMT”onpage5:Thischapterintroducesthemain
featuresofIntelAMTbuilt-incomputers.
Chapter4“IntelAMTsetupandcongurationonLenovoThinkCentreM91pdesktopcomputers”on
page7:ThischapterprovidesdetailedinstructionsonhowtocongureIntelAMTsettingsonLenovo
ThinkCentreM91pdesktopcomputers.
Chapter5“Webuserinterface”onpage21:Thischapterprovidesinstructionsonhowtoaccessthe
IntelAMTWebuserinterface.
©CopyrightLenovo2011v

viThinkCentreM91pIntelActiveManagementTechnologyCongurationGuide

Chapter1.IntroductiontoIntelvProandIntelAMT
IntelvProisabusinesscomputerplatformthatprovidesbusinesscomputerswithenhancedremote
managementcapabilities.ForcomputersbuiltwithIntelvPro,ITadministratorscanuseathirdpartysoftware
toremotelycollectinventoryinformation,diagnoseproblems,andprovidevariousservicesregardlessof
thecomputerpowerstateortheoperatingsystemstate.ITadministratorscanalsoisolateandprotect
individualcomputersandthenetworkfromthreats.
AsafeatureofIntelvPro,IntelAMTisdesignedtoprovideremotemanagementofcomputersregardless
ofthecomputerpowerstateortheoperatingsystemstateaslongasthecomputersareconnectedtoan
electricaloutletandanetwork.
IntelAMTisdesignedasabuildingblockandnotacompletesolution.ThisenablesOriginalEquipment
Manufacturers(OEMs)toincorporateIntelAMTintotheirclientandserverhardwareplatforms.Competent
andauthorizedthirdpartyapplicationsprovidemanagementandsecurityservicesthattakeadvantageof
theIntelAMTfeatures,suchasout-of-bandaccesstoassetinformation,eventlogs,hardwareandsoftware
tables,andembeddedcapabilities.
Acronyms
Thefollowingtablelistsandexplainssomeacronymsusedinthisdocument.
AcronymDescription
ACLAccessControlList
AMTActiveManagementTechnology
ASFAlertStandardFormat
BIOSBasicInputOutputSystem
CIRAClientInitiatedRemoteAccess
DHCPDynamicHostCongurationProtocol
DNSDomainNameServer
FQDNFullyQualiedDomainName
FWFirmware
HBPHostBasedProvisioning
HECIHostEmbeddedControllerInterface
IDE-RIntegratedDeviceElectronics-Redirection
IPInternetProtocol
ISVIndependentSoftwareVendor
KVMKeyboard-Video-Mouse
LMSLocalManageabilityService
MEManagementEngine
MEBxManagementEngineBIOSExtension
MEIManagementEngineInterface
NVMNonvolatilememory
OEMOriginalEquipmentManufacturer
©CopyrightLenovo20111

AcronymDescription
OOBOut-of-band
PID/PPSProvisioningIDandProvisioningPre-sharedKey
PKIPublicKeyInfrastructure
PRTCProtectedRealTimeClock
PSKPre-sharedKey
PXEPrebootExecutionEnvironment
RCFGRemoteConguration
SHASecureHashAlgorithm
SMBSmallandMediumBusinesses
SOLSerial-over-LAN
TCPTransmissionControlProtocol
TLSTransportLayerSecurity
WOLWakeonLan
ZTCZeroTouchConguration
2ThinkCentreM91pIntelActiveManagementTechnologyCongurationGuide

Chapter2.FeaturesandbenetsofIntelAMT
ThischapterintroducesthefeaturesandbenetsofIntelAMT.
ThefollowingtableliststheLenovobusinesscomputerswithIntelAMTinstalled.
LenovocomputerIntelAMTversion
ThinkCentreM91pIntelAMT7.X
ThinkCentreM90pIntelAMT6.X
ThinkCentreM58pIntelAMT5.X
ThinkCentreM57pIntelAMT3.X
ThinkCentreM55pIntelAMT2.X
Featuresandbenets
ThinkCentreM91pcomputersbuiltwithIntelAMTenableITadministratorstobetterdiscover,heal,and
protectthenetworkedcomputingassets.
•Discover:IntelAMTstoreshardwareandsoftwareinformationinnonvolatilememory(NVM).Withbuilt-in
manageability,IntelAMTenablesITadministratorstodiscoverassetsremotely,evenwhencomputersare
turnedoff.
•Heal:Thebuilt-inmanageabilityofIntelAMTprovidesout-of-band(OOB)managementcapabilities,which
enableITadministratorstoremotelydiagnosecomputerproblemsandrecovercomputersevenifthe
operatingsystemsareinoperable.ProactivealertingandeventlogginghelpITadministratorsdetect
problemsquicklytoreducecomputerdowntime.
•Protect:TheIntelAMTsystemdefensefeatureenablesbetterprotectionforcomputersbyproactively
blockingincomingthreats,controllinginfectedcomputersbeforethecomputerscauseproblemsinthe
network,andalertingITadministratorswhencriticalsoftwareagentsareremovedfromthecomputers.
ThefollowingtableshowsthefeaturesandbenetsofIntelAMT.
Table1.FeaturesandbenetsofIntelAMT
FeaturesBenets
OOBsystemaccessEnablesremotemanagementofclientsregardlessof
clientpowerstateandoperatingsystemstate
RemotetroubleshootingandrecoverySignicantlyreducesIThelpdeskvisitsandincreasesIT
serviceefciency
ProactivealertingDecreasescomputerdowntimeandminimizesITservice
time
RemotehardwareassettrackingIncreasesspeedandaccuracywithreducedaccounting
costs,comparedwithmanualinventorytracking
©CopyrightLenovo20113

4ThinkCentreM91pIntelActiveManagementTechnologyCongurationGuide

Chapter3.MainfeaturesofcomputersbuiltwithIntelAMT
ComputersbuiltwithIntelAMTversion2.0orlaterhavethefollowingfeaturesandimprovements:
•Remotepowercontrol
–Poweron
–Poweroff
–Powerreset
–Powercycle
•Assetmanagement
–E-Assettag
–OOBhardwareinventory
•IntegratedDeviceElectronics-Redirection(IDE-R)
–Floppyredirection
–CDredirection
•Serial-over-LAN(SOL)
–Screenredirectionbasedontext
–Keyboardredirection
–Networkredirection
•Remoterestart
–Restartfromalocalharddiskdrive
–RestartfromalocalCDorDVDdrive
–RestartfromalocalPrebootExecutionEnvironment(PXE)
•Eventmanagement
–Eventalerting
–Eventlogging
–Auditlog
•Agentpresence
•Systemdefense
•ClientInitiatedRemoteAccess(CIRA)
•Keyboard-Video-Mouse(KVM)redirection
•HostBasedProvisioning(HBP)
CIRA
ThinkCentreM91pcomputersbuiltwithIntelAMTsupporttheClientInitiatedRemoteAccess(CIRA)
function.YoucanperformthisfunctionthroughISVapplications..
TheCIRAfunctionenablesclient-initiated,secureOOBcommunicationtothemanageabilityconsole,
whichincludes:
•User-initiatedcall-homefeature
©CopyrightLenovo20115

•Scheduled,automatedcall-homefeature(nouserinputrequired)
•TransportLayerSecurity(TLS)sessionestablishedthroughclientinitiation
KVMredirection
ThinkCentreM91pcomputersbuiltwithIntelAMT7.XsupportKeyboard-Video-Mouse(KVM)redirection
overInternetProtocol(IP).KVMredirectionenablesITadministratorstoremotelycontrolthekeyboard,video
orvisualdisplayunit,andmouseofthemanagedclients.KVMredirectionhasthefollowingadvantages:
•Workstably
•Basedonhardware
Note:KVMredirectionisbasedonhardwaresothatitcanworkcorrectlyregardlessoftheoperating
systemstateofthemanagedclients.
•Manageclientsthroughmanagementserversremotely
•Healing,installationandapplicationssupport
Notes:
1.KVMredirectioninIntelAMT7.XcanbeusedonlyoncomputerswithIntelintegratedgraphics.For
computerswithdiscretegraphicscards,theSerial-over-LAN(SOL)functioncanbeusedtosupport
remotediagnosticsandrepair.
2.TheKVMuserinterfacesareonlyavailableoncomputersthatsupportKVMredirection.Formore
informationaboutKVMuserinterfaces,see“SOL/IDER/KVM”onpage12.
HostBasedProvisioning
ThinkCentreM91pcomputersbuiltwithIntelAMTsupporttheHostBasedProvisioning(HBP)function.As
anewfeatureinIntelAMT7.X,thisfunctionprovidesnewinterfacesforsystemsetupandconguration
throughoperatingsystems.Italsohelpsreducecostandeffortsrelatedtosystemsetup,conguration,
andmaintenance.
ByenablingHBPfunction,youcansimplifyIntelvProtechnologyactivationthroughthefollowingways:
•FullyactivatevProthroughsoftware
•RemotelyndandactivateIntelvProtechnologyinanautomaticmanner
6ThinkCentreM91pIntelActiveManagementTechnologyCongurationGuide

Chapter4.IntelAMTsetupandcongurationonLenovo
ThinkCentreM91pdesktopcomputers
TheIntelManagementEngine(ME)isanisolatedandprotectedcomputingresourcethatrunsonanIntel
AMTcomputer.TheIntelManagementEngineBIOSExtension(MEBx)providesauserinterfacetochangeor
conguresettingsthatcontroltheoperationoftheIntelManagementEngine(ME).
AllchangestotheMEplatformcongurationsettingsarenotcachedintheMEBx,butcommittedtotheME
nonvolatilememoryuntilyouexittheMEBx.IftheIntelMEBxcrashesintheprocessoftheconguration,the
changesthatyouhavemadewillnotbesaved.
Note:ToperformtheCIRAfunction,congureyourcomputerintheMEBxformanualsetupand
congurationmodeorautomaticsetupandcongurationmode,andthenusetheCIRAfunctionthroughISV
applications.YoudonotneedtodoanyadditionalsetupandcongurationintheMEBx.
IntelAMTcongurationsettingsinSetupUtility
TheSetupUtilityprogramenablesyoutoviewandchangetheIntelAMTrelatedcongurationsettings
foryourcomputer.
TovieworchangetheIntelAMTcongurationsettings,dothefollowing:
1.RepeatedlypressandreleasetheF1keywhenturningonthecomputer.Whenyouhearmultiplebeeps
orseealogoscreen,releasetheF1key.TheSetupUtilityprogramstarts.
2.FromtheSetupUtilityprogrammainmenu,selectAdvanced➙Intel(R)Managebility.Thefollowing
windowwillbedisplayed.
Figure1.Intel(R)ManageabilitycongurationsettingsinSetupUtility
Inthewindow,youcanviewthefollowingIntelAMTcongurationsettings:
©CopyrightLenovo20117

OptionDefaultsettingDescription
Intel(R)ManageabilityControlEnabledUsedtoenableordisabletheIntel(R)
Manageabilityinterface.
Intel(R)AMTResetDisabledUsedtoenableordisabletheIntel
AMTresetfunction.
Press<Ctrl-P>toEnterMEBxEnabledUsedtoenableordisablethe
entranceoftheMEBxsetup
congurationmenu.
Formoreinformation,seetheinstructionsandthehelpmessagesonthescreen.
IntelMEBxsetupandconguration
ThissectionprovidesinstructionsonhowtosetupandcongureIntelAMTforyourcomputer.
EnteringtheMEBxcongurationuserinterface
RepeatedlypressandreleaseCtrl+Pwhenturningonthecomputer.WhenyouseetheIntelManagement
EngineBIOSExtensionwindow,releasetheCtrlandPkeys.Youwillbepromptedtopress1toenterthe
IntelMEBxMAINMENUwindow(Figure2)Press1toenterMEcongurationscreenswindow.Youwillbe
promptedtoentertheIntelMEpassword.TypetheIntelMEdefaultpasswordadminandthenyouwillbe
promotedtotypeanewpassword.TosetanewIntelMEpassword,see“ChangeMEPassword”onpage9.
Figure2.IntelMEBxMAINMENUwindow
Intel(R)MEGeneralSettings
SelectIntel(R)MEGeneralSettingsintheIntelMEBxMAINMENUwindowandpressEnter.TheINTEL(R)ME
PLATFORMCONFIGURATIONwindowopens(Figure3).Thiswindowenablesyoutocongurethegeneral
settingsoftheIntelME,suchasMEstate,MEpassword,powercontrol,andsoon.
8ThinkCentreM91pIntelActiveManagementTechnologyCongurationGuide

Figure3.INTEL(R)MEPLATFORMCONFIGURATIONwindow
ThefollowingoptionsarelistedintheINTEL(R)MEPLATFORMCONFIGURATIONwindow:
ChangeMEPassword
TheChangeMEPasswordoptionenablesyoutochangetheIntelMEpassword.
TochangetheIntelMEpassword,selectChangeMEPasswordandpressEnter.Typeyournewpassword
andpressEnter.Whenpromptedtoconrmthenewpassword,typeyournewpasswordagain.
Passwordconsiderations:Forsecurityreasons,itisrecommendedtouseastrongpasswordthatcannot
beeasilycompromised.Tosetastrongpassword,usethefollowingguidelines:
•Haveeightto32charactersinlength
•Containatleastonealphabeticcharacter,onenumericcharacter,andonesymbol
(!@#$%^&*andsoon)
•Containatleastoneuppercaseletterandonelowercaseletter
•Youcanalsousethespacebarandunderscore(_).
Notes:
•TheIntelMEpasswordhasalengthlimitof32characters.Ifyouentermorethan32characters,the
32ndcharacterwillbereplacedbythelastcharacteryouenter.Thus,thepasswordwillbecomprised
oftherst31charactersandthelastcharacter.
•TheIntelMEpasswordcanberesettothedefaultoneadminintheSetupUtilityprogram.Ifyouwant
toresetthepassword,settheIntel(R)AMTResetoptionfromDISABLEDtoENABLED.See“Intel
AMTcongurationsettingsinSetupUtility”onpage7.Whenthesystemrestarts,amessageFound
uncongurationofIntel(R)MEContinuewithunconguration(Y/N)willbedisplayed.PressY.When
youentertheMEBxagain,youwillndthatthepasswordhasbeensuccessfullyresettoadmin.
FWUpdateSettings
SelectFWUpdateSettingsandpressEnter.TheFWUpdateSettingswindowopens.
Chapter4.IntelAMTsetupandcongurationonLenovoThinkCentreM91pdesktopcomputers9

OptionDescription
LocalFWUpdateYoucanenable,disable,orusetheMEBxpasswordto
protecttheIntelMErmwarelocalupdate.Whenthe
LocalFWUpdateoptionissettoENABLED,theIT
administratorcanupdatetheIntelMErmwarelocally
throughthelocalIntelMEinterfaceorthroughthelocal
secureinterface.WhentheLocalFWUpdateoptionis
settoDISABLED,thelocalIntelMErmwareupdateis
notallowed.WhentheLocalFWUpdateoptionissetto
PasswordProtected,LocalFWupdateisprotectedby
theMEBxpassword.
SetPRTC
SelectSetPRTCintheINTEL(R)MEPLATFORMCONFIGURATIONwindowandpressEnter.Youare
promptedtoentertheProtectedRealTimeClock(PRTC)valueinCoordinatedUniversalTime(UTC)format
(YYYY:MM:DD:HH:MM:SS).SettingaPRTCvaluehelpsmaintainthePRTCwhenyourcomputeristurned
off.ThevalidPRTCdaterangesfromJanuary1,2004toJanuary4,2021.
PowerControl
ThePowerControlmenuenablesyoutoconguretheMEpowercontrolpolicies.Toconformwiththe
ENERGYSTARprogramandtheEuPLot6requirements,theIntelMEcanbeturnedoffinvarioussleep
states.SelectPowerControlandpressEnter.TheINTEL(R)MEPOWERCONTROLwindowopens.Inthe
INTEL(R)MEPOWERCONTROLwindow,thefollowingoptionswillbedisplayed.
10ThinkCentreM91pIntelActiveManagementTechnologyCongurationGuide

OptionDescription
Intel(R)MEONinHostSleepStatesUsedtospecifywhentheIntelMEwillbeturnedon.
SelectIntel(R)MEONinHostSleepStatesandpress
Enter.Youcanchoosewhichpowerpackagewillbeused.
•Desktop:ONinS0–Thisoptionmeansonlywhen
yourcomputeristurnedonandoperationalwillthe
IntelMEbeturnedon.
•Desktop:ONinS0,MEWakeinS3,S4-5–This
optionmeanstheIntelMEwillbeturnedonwhenyour
computeristurnedonandoperational.TheIntelME
canberemotelywokenupwhenyourcomputerisin
sleepmode,hibernationmode,orturnedoff.
Notes:
–S0:Poweronstate
–S3:Standbysleepstate
–S4:Hibernatesleepstate
–S5:Shutdownsleepstate
WithIntelMEWakeonLan(WOL),afterthetime-outtimer
expires,theIntelMEremainsintheM-off1stateuntila
commandissenttotheIntelME.Afterthiscommandis
sent,theIntelMEwilltransitiontotheM02orM33state
andwillrespondtothenextcommand.Apingtothe
IntelMEcanalsomaketheIntelMEtransitiontoanM0
orM3state.IntelMEtakesashorttimetotransitionfrom
theM-offstatetotheM0orM3state.Duringthistime,
thesystemwillnotrespondtoanyIntelMEcommands.
WhentheIntelMEisintheM0orM3state,thesystem
willrespondtoIntelMEcommands.
IdleTimeoutUsedtoenabletheIntelMEtowakeupanddenethe
IntelMEidletimeoutintheM3state.Theidletimeout
valueindicatestheamountoftimethattheIntelMEis
allowedtoremainidleintheM3statebeforetransitioning
totheM-offstate.Theidletimeoutvalueshouldbe
enteredinminutes.
Note:IftheIntelMEisintheM0state,itwillnottransition
totheM-offstate.
Intel(R)AMTConguration
TheIntel(R)AMTCongurationmenuenablesyoutocongureanIntelAMTcapablecomputertosupport
theIntelAMTmanagementfeatures.
SelectIntel(R)AMTCongurationfromtheIntelMEBxMAINMENUwindowandpressEnter.Amessage
willbedisplayedindicatingthatyoucanupdatenetworksettingsfromtheIntel(R)MEGeneralSettings
menu.PressEnterandtheINTEL(R)AMTCONFIGURATIONwindowopens(Figure4).
1.M-off:AnIntelMEFWpowerstatewhentheIntelMEFWisshutdown.
2.M0:AnIntelMEFWpowerstatewhentheIntelAMTcomputeristurnedonandoperational.
3.M3:AnIntelMEFWpowerstatewhentheIntelAMTcomputerisinsleepmode,hibernationmode,orturnedoff.
Chapter4.IntelAMTsetupandcongurationonLenovoThinkCentreM91pdesktopcomputers11

Figure4.INTEL(R)AMTCONFIGURATIONwindow
ThefollowingoptionsarelistedintheINTEL(R)AMTCONFIGURATIONwindow:
•“ManageabilityFeatureSelection”onpage12
•“SOL/IDER/KVM”onpage12
•“UserConsent”onpage13
•“PasswordPolicy”onpage14
•“NetworkSetup”onpage14
•“ActivateNetworkAccess”onpage16
•“UncongureNetworkAccess”onpage16
•“RemoteSetupAndConguration”onpage17
ManageabilityFeatureSelection
TheManageabilityFeatureSelectionoptionisusedtoenableordisabletheIntelMEmanageability
feature.ThedefaultsettingisENABLED.
Note:IfyoudisabletheManageabilityFeatureSelectionfunction,allthenetworksettingsincludingACLs
willberesettofactorydefaultsettings.
SOL/IDER/KVM
SelectSOL/IDER/KVMintheINTEL(R)AMTCONFIGURATIONwindowandpressEnter.TheSOL/IDER/KVM
windowopens.Thefollowingoptionswillbedisplayed.
OptionDescription
Username&PasswordUsedtoenableordisabletheusernameandpassword
fortheSOL/IDERsession.IftheKerberosnetwork
authenticationprotocolisused,thisoptionshouldbe
settoDISABLEDbecausetheuserauthenticationis
managedthroughKerberos.IftheKerberosnetwork
authenticationprotocolisnotused,theITadministrator
canchoosetoenableordisabletheusernameand
passwordfortheSOL/IDERsession.
12ThinkCentreM91pIntelActiveManagementTechnologyCongurationGuide
