Lenovo ThinkCentre Neo 50s i5-12400 User manual

neo 50s Gen 3
User Guide
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Lenovo ThinkCentre
Neo 50s i5-12400 / 16GB / 512GB / Windows 11 Pro o cerca il tuo prodotto tra le migliori offerte di PC
Desktop e Workstation

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
following:
• Safety and Warranty Guide
• Generic Safety and Compliance Notices
• Setup Guide
First Edition (November 2021)
© Copyright Lenovo 2021.
LI ITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
iscover your Lenovo computer . . . . iii
Chapter 1. Meet your computer . . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 3
Features and specifications . . . . . . . . . . . 5
USB specifications . . . . . . . . . . . . . . 6
Chapter 2. Get started with your
computer . . . . . . . . . . . . . . . . . 7
Access networks . . . . . . . . . . . . . . . 7
Connect to the wired Ethernet . . . . . . . . 7
Connect to Wi-Fi networks (for selected
models) . . . . . . . . . . . . . . . . . 7
Connect an external display . . . . . . . . . . . 7
anage cables with a smart cable clip . . . . . . . 7
Chapter 3. Explore your computer . . . 9
The Vantage app . . . . . . . . . . . . . . . 9
Set the power plan . . . . . . . . . . . . . . 9
Transfer data . . . . . . . . . . . . . . . . . 9
Connect to a Bluetooth-enabled device (for
selected models) . . . . . . . . . . . . . 9
Use the optical drive (for selected models) . . 10
Use a media card (for selected models) . . . . 11
Purchase accessories . . . . . . . . . . . . 11
Chapter 4. Secure your computer
and information . . . . . . . . . . . . 13
Lock the computer . . . . . . . . . . . . . 13
UEFI BIOS passwords . . . . . . . . . . . . 14
Use software security solutions. . . . . . . . . 15
Windows firewalls . . . . . . . . . . . . 15
Antivirus programs . . . . . . . . . . . . 15
Computrace Agent software embedded in
firmware (for selected models) . . . . . . . 15
Use BIOS security solutions . . . . . . . . . . 15
Wipe the storage drive data . . . . . . . . 15
Cover presence switch . . . . . . . . . . 16
Intel BIOS guard . . . . . . . . . . . . . 16
Smart USB Protection . . . . . . . . . . 16
Chapter 5. UEFI BIOS . . . . . . . . . 19
What is UEFI BIOS. . . . . . . . . . . . . . 19
Enter the BIOS menu. . . . . . . . . . . . . 19
Navigate in the BIOS interface . . . . . . . . . 19
Change the display language of UEFI BIOS . . . . 19
Set the system date and time . . . . . . . . . 20
Change the boot priority order . . . . . . . . . 20
Enable or disable the configuration change
detection feature . . . . . . . . . . . . . . 20
Enable or disable the automatic power-on
feature . . . . . . . . . . . . . . . . . . 21
Enable or disable the smart power-on feature (for
selected models) . . . . . . . . . . . . . . 21
Enable or disable the ErP LPS compliance mode . . 21
Change the ITS performance mode . . . . . . . 22
Change BIOS settings before installing a new
operating system . . . . . . . . . . . . . . 22
Update UEFI BIOS. . . . . . . . . . . . . . 23
Recover from a BIOS update failure . . . . . . . 23
Clear C OS . . . . . . . . . . . . . . . . 23
Chapter 6. iagnostics . . . . . . . . 25
Lenovo diagnostic tools . . . . . . . . . . . 25
The Vantage app . . . . . . . . . . . . . . 25
Chapter 7. CRU replacement . . . . . 27
CRU list . . . . . . . . . . . . . . . . . . 27
Remove or replace a CRU . . . . . . . . . . . 28
Vertical stand . . . . . . . . . . . . . . 28
Computer cover . . . . . . . . . . . . . 28
Front bezel . . . . . . . . . . . . . . . 29
Optical drive . . . . . . . . . . . . . . 30
Hard disk drive . . . . . . . . . . . . . 31
emory module . . . . . . . . . . . . . 36
.2 solid-state drive . . . . . . . . . . . 37
Coin-cell battery. . . . . . . . . . . . . 38
Heat-sink-and-fan assembly . . . . . . . . 39
PCI-Express connector cable . . . . . . . 41
PCI-Express card . . . . . . . . . . . . 41
Power supply assembly . . . . . . . . . . 42
Chapter 8. Help and support . . . . . 45
Self-help resources . . . . . . . . . . . . . 45
Call Lenovo . . . . . . . . . . . . . . . . 47
Before you contact Lenovo . . . . . . . . 47
Lenovo Customer Support Center . . . . . . 47
Purchase additional services. . . . . . . . . . 48
Appendix A. Compliance
information . . . . . . . . . . . . . . . 49
Appendix B. Notices and
trademarks . . . . . . . . . . . . . . . 51
© Copyright Lenovo 2021 i

ii neo 50s Gen 3 User Guide

iscover your Lenovo computer
Thank you for choosing a Lenovo® computer! We are dedicated to delivering the best solution to you.
Before starting your tour, please read the following information:
• Illustrations in this documentation might look different from your product.
• Depending on the model, some optional accessories, features, software programs, and user interface
instructions might not be applicable to your computer.
• Documentation content is subject to change without notice. To get the latest documentation, go to https://
pcsupport.lenovo.com.
© Copyright Lenovo 2021 iii

iv neo 50s Gen 3 User Guide

Chapter 1. Meet your computer
Front
1. ThinkCentre® LED 2. Optical drive eject button*
3. Optical drive activity indicator* 4. Power button with power indicator
5. Storage drive activity indicator 6. icrophone connector
7. Headset connector 8. SD-card slot*
9. USB-C® (3.2 Gen 1) connector 10. USB 3.2 connectors Gen 1
11. Internal speaker*
* for selected models
Power indicator
Show the system status of your computer.
• On: The computer is starting up or working.
• Off: The computer is off or in hibernation mode.
• Blinking: The computer is in sleep mode.
Related topics
• “USB specifications” on page 6.
• “Use the optical drive (for selected models)” on page 10.
© Copyright Lenovo 2021 1

• “Use a media card (for selected models)” on page 11.
2neo 50s Gen 3 User Guide

Rear
1. Audio line-out connector 2. HD I™ out connector
3. DisplayPort™ out connector 4. VGA-out connector
5. USB 2.0 connectors 6. USB 3.2 connector Gen 1 (with smart power-on
feature)
7. USB 3.2 connector Gen 1 8. PCI-Express card area
9. Power cord connector 10. Padlock loop
11. Security-lock slot 12. Serial connector*
13. Ethernet connector 14. Smart cable clip slots
15. Serial connector*
* for selected models
Serial connector
Connect an external modem, a serial printer, or other devices that use a serial connector.
Related topics
• “Lock the computer” on page 13.
• “Connect an external display” on page 7.
• “USB specifications” on page 6.
• “Enable or disable the smart power-on feature (for selected models)” on page 21.
Chapter 1.eet your computer 3

4neo 50s Gen 3 User Guide

Features and specifications
For detailed specifications of your computer, go to https://psref.lenovo.com.
imensions
• Width: 100.0 mm (3.9 inches)
• Height: 274.8 mm (10.8 inches)
• Depth: 308.0 mm (12.1 inches)
Weight (without packaging) aximum configuration as shipped: 4.5 kg (9.9 lb)
Hardware configuration Type Device Manager in the Windows search box and then press Enter. Type the
administrator password or provide confirmation, if prompted.
Power supply • 180-watt automatic voltage-sensing power supply
• 260-watt automatic voltage-sensing power supply
Electrical input • Input voltage: From 100 V ac to 240 V ac
• Input frequency: 50/60 Hz
Memory
Up to two double data rate 4 (DDR4) non-error correction code (non-ECC)
unbuffered dual in-line memory modules (UDI s)
aximum memory capacity: 64 GB
Storage device
• Hard disk drive*
• .2 solid-state drive*
To view the storage drive capacity of your computer, type Disk Management in the
Windows search box and then press Enter.
Note: The storage drive capacity indicated by the system is less than the nominal
capacity.
Video features
• The integrated graphics card supports the following:
– DisplayPort out connector
– HD I out connector
– VGA-out connector
• The optional discrete graphics card provides an enhanced video experience
and extended capabilities.
Expansion
• Card reader*
• emory slots
• .2 solid-state drive slot
• Optical drive*
• PCI Express slots
• Storage drive bay
Network features
• Bluetooth*
• Ethernet LAN
• Wireless LAN*
* for selected models
Chapter 1.eet your computer 5

USB specifications
Note: Depending on the model, some USB connectors might not be available on your computer.
Connector name escription
• USB 2.0 connector
• USB 3.2 connector Gen 1
Connect USB-compatible devices, such as a USB
keyboard, USB mouse, USB storage device, or USB
printer.
• USB-C (3.2 Gen 1) connector
• Charge USB-C compatible devices with the output
voltage and current of 5 V and 3 A.
• Connect to USB-C accessories to help expand your
computer functionality. To purchase USB-C
accessories, go to https://www.lenovo.com/accessories.
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device ata rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1 5
3.2 Gen 2 / 3.1 Gen 2 10
3.2 Gen 2 × 2 20
Thunderbolt 3 40
Thunderbolt 4 40
6neo 50s Gen 3 User Guide

Chapter 2. Get started with your computer
Access networks
This section helps you access networks through connecting to a wired or wireless network.
Connect to the wired Ethernet
Connect your computer to a local network through the Ethernet connector on your computer with an
Ethernet cable.
Connect to Wi-Fi networks (for selected models)
Click the network icon in the Windows® notification area, and then select a network for connection. Provide
required information, if needed.
Connect an external display
Connect a projector or a monitor to your computer to give presentations or expand your workspace.
Connect a wireless display
Ensure that both your computer and the wireless display support iracast®.
Press Windows logo key + K and then select a wireless display to connect.
Change display settings
1. Right-click a blank area on the desktop and select display settings.
2. Select the display that you want to configure and change display settings of your preference.
Manage cables with a smart cable clip
Note: You can purchase a smart cable clip from Lenovo.
© Copyright Lenovo 2021 7

To manage cables of devices (such as the keyboard and the mouse) with a smart cable clip:
1. Pull the cables through the dents in the clip.
2. Install the clip as shown.
8neo 50s Gen 3 User Guide

Chapter 3. Explore your computer
The Vantage app
The preinstalled Vantage app is a customized one-stop solution to help you maintain your computer with
automated updates and fixes, configure hardware settings, and get personalized support.
To access the Vantage app, type Vantage in the Windows search box.
Key features
The Vantage app enables you to:
• Know the device status easily and customize device settings.
• Download and install UEFI BIOS, firmware and driver updates to keep your computer up-to-date.
• onitor your computer health, and secure your computer against outside threats.
• Scan your computer hardware and diagnose hardware problems.
• Look up warranty status (online).
• Access User Guide and helpful articles.
Notes:
• The available features vary depending on the computer model.
• The Vantage app makes periodic updates of the features to keep improving your experience with your
computer. The description of features might be different from that on your actual user interface.
Set the power plan
For ENERGY STAR® compliant computers, the following power plan takes effect when your computers have
been idle for a specified duration:
• turn off the display: After 10 minutes
• put the computer to sleep: After 25 minutes
To awaken the computer from Sleep mode, press any key on your keyboard.
To reset the power plan:
1. Right-click the battery status icon and select Power Options.
2. Choose or customize a power plan of your preference.
Transfer data
Quickly share your files using the built-in Bluetooth technology among devices with the same features. You
also can install a disc or media card to transfer data.
Connect to a Bluetooth-enabled device (for selected models)
You can connect all types of Bluetooth-enabled devices to your computer, such as a keyboard, a mouse, a
smartphone, or speakers. Place the device that you are attempting to connect to less than 10 meters (33
feet) from the computer.
© Copyright Lenovo 2021 9

1. Type Bluetooth in the Windows search box and then press Enter.
2. Turn on Bluetooth, if it is off.
3. Select a Bluetooth device, and then follow the on-screen instructions.
Use the optical drive (for selected models)
If your computer has an optical drive, read the following information.
Know the type of your optical drive
1. Type Device Manager in the Windows search box and then press Enter. Type the administrator password
or provide confirmation, if prompted.
2. Select an optical drive, and then follow the on-screen instructions.
Install or remove a disc
1. With the computer on, press the eject button on the optical drive. The tray slides out of the drive.
2. Insert a disc into the tray or remove a disc from the tray, and then push the tray back into the drive.
Note: If the tray does not slide out of the drive when you press the eject button, turn off the computer. Then,
insert a straightened paper clip into the emergency-eject hole adjacent to the eject button. Use the
emergency eject only in an emergency.
Record a disc
1. Insert a recordable disc into the optical drive that supports recording.
2. Do one of the following:
• Type AutoPlay in the Windows search box and then press Enter. Turn on Use AutoPlay for all media
and devices.
• Open Windows edia Player.
• Double-click the ISO file.
3. Follow the on-screen instructions.
10 neo 50s Gen 3 User Guide

Use a media card (for selected models)
If your computer has a SD-card slot, read the following information.
Install a media card
1. Locate the SD-card slot.
2. Ensure that the metal contacts on the card are facing the ones in the SD-card slot. Insert the card firmly
into the SD-card slot until it is secured in place.
Remove a media card
Attention: Before removing the card:
1. Click the triangular icon in the Windows notification area to show hidden icons. Right-click the icon
prompting you to safely remove hardware and eject media.
2. Select the corresponding item to eject the card from the Windows operating system.
3. Press the card and remove it from your computer. Store the card safely for future use.
Purchase accessories
Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your
computer. Options include memory modules, storage devices, network cards, power adapters, keyboards,
mice, and more.
To shop at Lenovo, go to https://www.lenovo.com/accessories.
Chapter 3.Explore your computer 11

12 neo 50s Gen 3 User Guide

Chapter 4. Secure your computer and information
Lock the computer
Note: Lenovo makes no comments, judgments, or warranties about the function, quality, or performance of
the locking device and security feature. You can purchase computer locks from Lenovo.
Padlock
Locking the computer cover through a padlock prevents unauthorized access to the inside of your computer.
Kensington-style cable lock
Lock your computer to a desk, table, or other fixtures through a Kensington-style cable lock.
© Copyright Lenovo 2021 13

UEFI BIOS passwords
You can set passwords in UEFI (Unified Extensible Firmware Interface) BIOS (Basic Input/Output System) to
strengthen the security of your computer.
Password types
You can set a power-on password, supervisor password, system management password, or hard disk
password in UEFI BIOS to prevent unauthorized access to your computer. However, you are not prompted to
enter any UEFI BIOS password when your computer resumes from sleep mode.
• Power-on password
When a power-on password is set, you are prompted to enter a valid password each time the computer is
turned on.
• Supervisor password
Setting a supervisor password deters unauthorized users from changing configuration settings. If you are
responsible for maintaining the configuration settings of several computers, you might want to set a
supervisor password.
When a supervisor password is set, you are prompted to enter a valid password each time you try to enter
the BIOS menu.
If both the power-on password and supervisor password are set, you can enter either password.
However, you must use your supervisor password to change any configuration settings.
• Hard disk password
Setting a hard disk password prevents unauthorized access to the data on the storage drive. When a hard
disk password is set, you are prompted to enter a valid password each time you try to access the storage
drive.
Note: After you set a hard disk password, your data on the storage drive is protected even if the storage
drive is removed from one computer and installed in another.
• System management password (for selected models)
You can enable the system management password to have the same authority as the supervisor
password to control security related features. To customize the authority of the system management
password through the UEFI BIOS menu:
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Security ➙ System Management Password Access Control.
3. Follow the on-screen instructions.
If you have set both the supervisor password and the system management password, the supervisor
password overrides the system management password.
Set, change, and remove a password
Before you start, print these instructions.
1. Restart the computer. When the logo screen is displayed, press F1 or Fn+F1.
2. Select Security.
3. Depending on the password type, select Set Supervisor Password, Set Power-On Password, Set
System Management Password, or Hard isk Password and press Enter.
4. Follow the on-screen instructions to set, change, or remove a password.
5. Press F10 or Fn+F10 to save the changes and exit.
14 neo 50s Gen 3 User Guide
