Lenovo ThinkStation C20 Quick reference guide

Lenovo BIOS Windows
M a nag e m e n t Instrumentation
In t e rf a c e Deployment Guide for
Workstations (S20/D20/C20)
Date: September 2010

FirstEdition(September2010)

©CopyrightLenovo2010.Allrightsreserved.

@Copyright Lenovo 2010 I
Contents
Preface....................................................................................................................................III
Chapter 1. Overview ............................................................................................................... 1
Using Windows Management Instrumentation................................................................................................. 1
Key benefits ..................................................................................................................................................... 1
Function................................................................................................................................................... 2
Environment ............................................................................................................................................ 2
Interface................................................................................................................................................... 2
Supported computers ....................................................................................................................................... 2
Chapter 2. Script Classes and Parameter ............................................................................ 3
Configuring BIOS settings.............................................................................................................................. 3
Return types...................................................................................................................................................... 3
Password Authentication................................................................................................................................. 4
Available BIOS setting names ........................................................................................................................ 4
Chapter 3. Typical Usage .......................................................................................................11
Listing current BIOS settings.........................................................................................................................11
Changing BIOS settings .................................................................................................................................11
Changing the boot order .................................................................................................................................11
Restoring default settings...............................................................................................................................12
Limitations.......................................................................................................................................................12
Chapter 4. Security.................................................................................................................13
Appendix A. Sample Visual Basic scripts for configuring BIOS settings..........................15
Restore default settings................................................................................................................................... 15
List all BIOS settings on the local computer .................................................................................................. 16
Set a single BIOS setting on the local computer............................................................................................. 16
Set a single BIOS setting on the local computer if a Administration password exists .................................... 17
List all BIOS settings on the remote computer ............................................................................................... 18
Set a single BIOS setting on a remote computer............................................................................................. 18
Set a single BIOS setting on a remote computer when a Administrator password exists ............................... 19
Appendix B. Notices ..............................................................................................................22
Trademarks .....................................................................................................................................................23

@Copyright Lenovo 2010 III
Preface
ThepurposeofthisguideistoexplainhowtomodifyBIOS
settingsandbootorderusingWindowsManagement
Instrumentation(WMI)throughtheLenovoclient‐management
interface.ThisguideisintendedforskilledITadministratorswho
arefamiliarwithconfiguringBIOSsettingsoncomputersintheir
organizations.

ThisguideisprovidedinaZIPfilepackagethatcontainsthis
deploymentguideaswellasVisualBasicsamplescriptstouse
whenconfiguringBIOSsettings.

ThisdeploymentguideisdevelopedforITprofessionalstoassist
withtheuniquechallengesthattheyencounter.Ifyouhave
suggestionsorcomments,communicatewithyourLenovo®
authorizedrepresentative.Tolearnmoreaboutthetechnologiesthat
canhelpyoulowerthetotalcostofownershipandtocheckfor
periodicupdatestothisguide,visitthefollowingWebsite:
www.lenovo.com/support

@Copyright Lenovo 2010 1
Chapter 1. Overview
ITadministratorsarealwayslookingforeasierwaystomanage
clientcomputerBIOSsettings,whichincludehardwaresettings
andbootorder.TheLenovoBIOSWMIinterfaceprovidesa
simplifiedwaytochangethesesettings.Lenovohasdevelopeda
BIOSinterfacethatcanbemanipulatedthroughWindows
ManagementInstrumentation(WMI).TheLenovoBIOSWMI
interfaceenablesITadministratorstomakequeriesoncurrent
BIOSsettings,restoresettingstotheirfactorydefaults,change
singlesettings,andmodifythebootordereitheratclient
computersorremotely.
Using Windows Management Instrumentation
WMIisprovidedasastandardfeatureinmostWindows®operating
systems.Itprovidesapowerfulsetoffunctions,suchas
query‐basedinformationretrievalandeventnotification,which
enablesuserstomanagebothlocalandremotecomputers.The
LenovoBIOSWMIinterfaceextendsthecapabilitiesofWMIto
allowmanagementofBIOSsettings.

ThefollowingillustrationshowshowWMIcanbeusedtoaccess
LenovoBIOSsettings.

WMIusesWindowsScriptHost(WSH)tointerpretscripts.Youcan
writeyourscriptsineitherWindowsVisualBasicScriptingEdition
(VBScript)orJavaScript.
Key benefits
TheLenovoBIOSWMIinterfaceprovidesthefollowingbenefits:

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Workstations 2
Function
·FlexibleBIOSconfiguration,includingtheabilitytochangea
singleBIOSsettingorallBIOSsettings
·NodependencyonaspecificBIOSlevel
Environment
·Remoteorlocalcapabilities
·Supportofunattendedoperations
·Nosoftwareinstallation,includingmanagedobjectformat(MOF),
required
·ReplacesDOS‐basedBIOSconfigurationtools
Interface
·Easytoadoptforvariousmanagementservers
·ReplacescurrentSMIinterface
·Commoninterfacefordifferentproducts
Supported computers
BIOSsetupthroughWMIissupportedonthefollowingnew
Thinkstationproducts only:

·Thinkstation S20/C20/D20
Thinkstation S20 requires BIOS version 60KT40A or later
Thinkstation C20/C20x/D20 requires BIOS version 61KT44A or later

Chapter 2. Script Classes and Parameter
ThischaptercontainsWMIimplementationdetailsforconfiguring
BIOSsettings.

Configuring BIOS settings
ThefollowinginterfacedetailscanbeusedtoaccessLenovoBIOS
settings.
∙Namespace:ʺ\root\WMIʺ
∙BaseClass:ʺLenovo_BIOSElementʺ
∙Interfacedetails(seeTable1)
Table 1. Interface Details
ClassNameTypeParameter/ReturnExample
Lenovo_BiosSetting Query CurrentSetting:ʺItem,Valueʺ ʺWakeOnLAN,
Lenovo_SetBiosSetting Method ʺItem,Value,ʺ ʺWakeOnLAN,Disabled,”
Lenovo_SaveBiosSetting Method ʺPassword,Encoding,KbdLang,ʺ ʺpswd,ascii,us,ʺ
Lenovo_DiscardBiosSetting Method ʺ,ʺ ʺ,ʺ
Lenovo_LoadBiosSetting Method ʺ,ʺ ʺ,ʺ
Return types
Youwillreceiveoneofthefollowingreturntypesaftermakingchangesto
BIOSsettings:
Table 2. Return Types
ReturnTypeDescription
Success Operationcompletedsuccessfully.
NotSupported Thefeatureisnotsupportedonthissystem.
InvalidParameter Theitemorvalueprovidedisnotvalid.
AccessDenied
Thechangecouldnotbemadeduetoanauthenticationproblem.
Ifasupervisorpasswordexists,thecorrectsupervisorpassword
mustbeprovided.
System Busy BIOS changes have already been made that neet to be
committed. Reboot the system and try again.
@Copyright Lenovo 2010 3

Password Authentication
IfanAdministratorpasswordisalreadyset,youmustspecifythat
administratorpasswordbeforeyoucanchangeanyBIOSsettings.
Theformatforpasswordparametersisʺabc,ascii,usʺwith
descriptionsinTable3.
Table 3. Password parameters format, password authentication
ParameterDescriptionPossibleselections
Parameter1 Currentpassword·“abc”‐rawasciicharacter
·“1e302e”–scancode
Parameter2 Passwordencoding ·“ascii”
·“scancode”
Parameter3 Keyboardlanguages
(validonlyifencodingis″ascii″)·″us″‐EnglishUS,English,French‐Canadian,
Italian,Japanese,Korean,Norwegian,Polish,
Portuguese,Spanish‐European,
Spanish‐LatinAmerican,Swiss,Turkish
·″fr″‐French‐European,Belgian
·″gr″‐German,Czech,Slovak,Slovenian
Available BIOS setting names
SomeBIOSsettingsaredependentonthepresenceofcertainhardware
features.Settingsmightvaryondifferentcomputers.
Notes:
1. BIOS settings and values are case sensitive.
2. "Load Defaults" will only change the values for BIOS
settings that can be changedvia the WMI interface.

Table 4. List of Available BIOS settings for S20
Item Name Selection Name Load
"Legacy Diskette A" “Disabled”, “Enabled” Y
"Serial Port A" "Disabled", "Enabled", "Automatic" Y
"Serial A Base IO Address" "3F8", "2F8", "3E8", "2E8" Y
"Serial A Interrupt" "IRQ3", "IRQ4" Y
"Serial Port B" "Disabled", "Enabled", "Automatic" Y
"Serial B Base IO Address" "3F8", "2F8", "3E8", "2E8" Y
"Serial B Interrupt" "IRQ3", "IRQ4" Y
"USB Support" “Disabled”, “Enabled” Y
"USB Front Ports" “Disabled”, “Enabled” Y
"USB Card Reader" “Disabled”, “Enabled” Y
“Serial ATA” “Disabled”, “Enabled Y
"Native Mode Operation" "Automatic", "Serial ATA" Y
Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Workstations 4

"Sata Disk Pre-Delay" "Disabled", "3 Seconds", "6 Seconds",
"9 Seconds", "12 Seconds", "15 Seconds",
"21 Seconds", "30 Seconds"
Y
"Sata Mode Selection" "IDE", "AHCI", "RAID" Y
"eSata Port" “Disabled”, “Enabled” Y
"Audio Support" “Disabled”, “Enabled” Y
"System Board Ethernet" “Disabled”, “Enabled” Y
"PXE Boot Agent" “Disabled”, “Enabled” Y
"PCI Parity" “Disabled”, “Enabled” Y
"Plug and Play Operating System" "No", "Yes" Y
"Default Primary Video Adapter" "Auto", "PCI" Y
"Turbo Mode" “Disabled”, “Enabled” Y
"Active Processors" "Max. Cores", "One Core" Y
"HyperThreading" “Disabled”, “Enabled” Y
"Execute Disable Bit" “Disabled”, “Enabled” Y
"Intel Virtualization Technology" “Disabled”, “Enabled” Y
"Fan Acoustics" "Normal", "Quiet", "High" Y
"Intel VT for Directed I/O (VT-d)" “Disabled”, “Enabled” Y
"EIST (GV3) & C State" “Disabled”, “Enabled” Y
"EIST (GV3)" “Disabled”, “Enabled” Y
"CPU C State" “Disabled”, “Enabled” Y
"After Power Loss" "Stay Off", "Last State", "Power On" Y
"EuP lot 6" “Disabled”, “Enabled” Y
"Wake on LAN" "Disabled", "Automatic", "Primary" Y
"PCI Wake Up" "Disabled", "Automatic", "Primary" Y
"PCI Modem Ring Detect" "Disabled", "Automatic", "Primary" Y
"Serial Port A Ring Detect" "Disabled", "Automatic", "Primary" Y
@Copyright Lenovo 2010 5

"Primary Startup Sequence",
"Automatic Startup Sequence",
"Error Startup Sequence",
"Manufacturing Startup Sequence"
"Legacy Diskette A",
"IDE 0",
"ESATA",
"IDE 1",
"IDE 2",
"ESATA C20",
"IDE 3",
"IDE 4",
"IDE CDROM 0",
"IDE CDROM 1",
"IDE CDROM 2",
"USB FDD",
"USB HDD",
"USB KEY",
"USB CDROM",
"PCI BEV 0",
"PCI LAN 0",
"PCI BEV 1",
"PCI LAN 1",
"PCI BEV 2",
"PCI BEV 3",
"PCI BEV 4",
"PCI SCSI",
"SCSI 0",
"SCSI 1",
"SCSI 2",
"SCSI 3",
"SCSI 4",
"SCSI 5",
"Nothing Here"
Y
Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Workstations 6

Table 5. List of Available BIOS settings for D20/C20X
Item Name Selection Name Load
"Legacy Diskette A" “Disabled”, “Enabled” Y
"Serial Port A" "Disabled", "Enabled", "Automatic" Y
"Serial A Base IO Address" "3F8", "2F8", "3E8", "2E8" Y
"Serial A Interrupt" "IRQ3", "IRQ4" Y
"Serial Port B" "Disabled", "Enabled", "Automatic" Y
"Serial B Base IO Address" "3F8", "2F8", "3E8", "2E8" Y
"Serial B Interrupt" "IRQ3", "IRQ4" Y
"USB Support" “Disabled”, “Enabled” Y
"USB Front Ports" “Disabled”, “Enabled” Y
"USB Card Reader" “Disabled”, “Enabled” Y
"ICH SATA" “Disabled”, “Enabled” Y
“Serial ATA” “Disabled”, “Enabled Y
"Native Mode Operation" "Automatic", "Serial ATA" Y
"Sata Disk Pre-Delay" "Disabled", "3 Seconds", "6 Seconds",
"9 Seconds", "12 Seconds", "15 Seconds",
"21 Seconds", "30 Seconds"
Y
"Sata Mode Selection" "IDE", "AHCI", Y
"eSata Port" “Disabled”, “Enabled” Y
"Marvell SATA/SAS Controller" “Disabled”, “Enabled” Y
"Audio Support" “Disabled”, “Enabled” Y
"System Board Ethernet" “Disabled”, “Enabled” Y
"PXE Boot Agent" “Disabled”, “Enabled” Y
"System Board Ethernet #2" “Disabled”, “Enabled” Y
"PXE Boot Agent #2" “Disabled”, “Enabled” Y
"PCI Parity" “Disabled”, “Enabled” Y
"Plug and Play Operating System" "No", "Yes" Y
"Default Primary Video Adapter" "Auto", "PCI" Y
"Turbo Mode" “Disabled”, “Enabled” Y
"Active Processors" "Max. Cores", "One Core" Y
"HyperThreading" “Disabled”, “Enabled” Y
"Execute Disable Bit" “Disabled”, “Enabled” Y
"Intel Virtualization Technology" “Disabled”, “Enabled” Y
"PCIe Peer to Peer Transactions" “Disabled”, “Enabled” Y
"NUMA Aware" “Disabled”, “Enabled” Y
"Fan Acoustics" "Normal", "Quiet", "High" Y
"Intel VT for Directed I/O (VT-d)" “Disabled”, “Enabled” Y
"EIST (GV3) & C State" “Disabled”, “Enabled” Y
"EIST (GV3)" “Disabled”, “Enabled” Y
"CPU C State" “Disabled”, “Enabled” Y
"After Power Loss" "Stay Off", "Last State", "Power On" Y
"EuP lot 6" “Disabled”, “Enabled” Y
"Wake on LAN" "Disabled", "Automatic", "Primary" Y
"PCI Wake Up" "Disabled", "Automatic", "Primary" Y
"PCI Modem Ring Detect" "Disabled", "Automatic", "Primary" Y
"Serial Port A Ring Detect" "Disabled", "Automatic", "Primary" Y
@Copyright Lenovo 2010 7

"Primary Startup Sequence",
"Automatic Startup Sequence",
"Error Startup Sequence",
"Manufacturing Startup Sequence"
"Legacy Diskette A",
"IDE 0",
"ESATA",
"IDE 1",
"IDE 2",
"ESATA C20",
"IDE 3",
"IDE 4",
"IDE CDROM 0",
"IDE CDROM 1",
"IDE CDROM 2",
"USB FDD",
"USB HDD",
"USB KEY",
"USB CDROM",
"PCI BEV 0",
"PCI LAN 0",
"PCI BEV 1",
"PCI LAN 1",
"PCI BEV 2",
"PCI BEV 3",
"PCI BEV 4",
"PCI SCSI",
"SCSI 0",
"SCSI 1",
"SCSI 2",
"SCSI 3",
"SCSI 4",
"SCSI 5",
"Nothing Here"
Y
Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Workstations 8

Table 6. List of available BIOS settings for C20
Item Name
Selection Name
Load
"Legacy Diskette A" “Disabled”, “Enabled” Y
"Serial A Interrupt" "IRQ3", "IRQ4" Y
"USB Support" “Disabled”, “Enabled” Y
"USB Front Ports" “Disabled”, “Enabled” Y
"USB Card Reader" “Disabled”, “Enabled” Y
"ICH SATA" “Disabled”, “Enabled” Y
"Native Mode Operation" "Automatic", "Serial ATA" Y
"Sata Disk Pre-Delay" "Disabled", "3 Seconds", "6 Seconds",
"9 Seconds", "12 Seconds", "15 Seconds",
"21 Seconds", "30 Seconds"
Y
"Sata Mode Selection" "IDE", "AHCI", "RAID" Y
"eSata Port" “Disabled”, “Enabled” Y
"Marvell SATA/SAS Controller" “Disabled”, “Enabled” Y
"Audio Support" “Disabled”, “Enabled” Y
"System Board Ethernet" “Disabled”, “Enabled” Y
"PXE Boot Agent" “Disabled”, “Enabled” Y
"System Board Ethernet #2" “Disabled”, “Enabled” Y
"PXE Boot Agent #2" “Disabled”, “Enabled” Y
"PCI Parity" “Disabled”, “Enabled” Y
"Plug and Play Operating System" "No", "Yes" Y
"Default Primary Video Adapter" "Auto", "PCI" Y
"Turbo Mode" “Disabled”, “Enabled” Y
"Active Processors" "Max. Cores", "One Core" Y
"HyperThreading" “Disabled”, “Enabled” Y
"Execute Disable Bit" “Disabled”, “Enabled” Y
"Intel Virtualization Technology" “Disabled”, “Enabled” Y
"PCIe Peer to Peer Transactions" “Disabled”, “Enabled” Y
"NUMA Aware" “Disabled”, “Enabled” Y
"Fan Acoustics" "Normal", "Quiet", "High" Y
"Intel VT for Directed I/O (VT-d)" “Disabled”, “Enabled” Y
"EIST (GV3) & C State" “Disabled”, “Enabled” Y
"EIST (GV3)" “Disabled”, “Enabled” Y
"CPU C State" “Disabled”, “Enabled” Y
"After Power Loss" "Stay Off", "Last State", "Power On" Y
"EuP lot 6" “Disabled”, “Enabled” Y
"Wake on LAN" "Disabled", "Automatic", "Primary" Y
"PCI Wake Up" "Disabled", "Automatic", "Primary" Y
"PCI Modem Ring Detect" "Disabled", "Automatic", "Primary" Y
"Serial Port A Ring Detect" "Disabled", "Automatic", "Primary" Y
@Copyright Lenovo 2010 9

"Primary Startup Sequence",
"Automatic Startup Sequence",
"Error Startup Sequence",
"Manufacturing Startup Sequence"
"Legacy Diskette A",
"IDE 0",
"ESATA",
"IDE 1",
"IDE 2",
"ESATA C20",
"IDE 3",
"IDE 4",
"IDE CDROM 0",
"IDE CDROM 1",
"IDE CDROM 2",
"USB FDD",
"USB HDD",
"USB KEY",
"USB CDROM",
"PCI BEV 0",
"PCI LAN 0",
"PCI BEV 1",
"PCI LAN 1",
"PCI BEV 2",
"PCI BEV 3",
"PCI BEV 4",
"PCI SCSI",
"SCSI 0",
"SCSI 1",
"SCSI 2",
"SCSI 3",
"SCSI 4",
"SCSI 5",
"Nothing Here"
Y
Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Workstations 10

@Copyright Lenovo 2010 11
Chapter 3. Typical Usage
ThroughWMI,youcanconfigureBIOSsettingsinthe
followingways:
·ListBIOSsettings
·ChangeBIOSsettings
·Changethebootorder(sometimesreferredtoasthestartup
sequence)
·LoaddefaultBIOSsettings
Listing current BIOS settings
ForalistofallavailableBIOSsettingsthatcanbechanged
throughWMIonaspecificcomputer,usethe
Lenovo_BiosSettingclass(see“ListallBIOSsettingsonthe
localcomputer”onpage12and“ListallBIOSsettingsonthe
remotecomputer”onpage14forsamplescripts).

SeeTable4onpage4foralistofavailableBIOSsettings.
Changing BIOS settings
TochangeaBIOSsetting,completethefollowingsteps:
1.IdentifytheBIOSsettingyouwanttochangeusingthe
Lenovo_BiosSettingclass(see“ListallBIOSsettingsonthelocal
computer”onpage12and“ListallBIOSsettingsontheremote
computer”onpage14forsamplescripts).
2.Identifythevaluetowhichthesettingwillbechanged.

Note:SeeTable4onpage4foralistofavailablevaluesfora
particularsetting.
3.ChangetheBIOSsettingtothedesiredvalueusingthe
Lenovo_SetBiosSettingclass,thenusetheLenovo_SaveBiosSetting
classtosavethesettings(see“SetasingleBIOSsettingonthelocal
computer”onpage12and“SetasingleBIOSsettingonaremote
computer”onpage14forsamplescripts).

Note:BIOSsettingsandvaluesarecasesensitive.

AftermakingchangestotheBIOSsettings,youmustrebootthe
computerbeforethechangeswilltakeeffect.
Changing the Startup Sequence
Tochangethestartup sequqence,completethefoll\owingsteps:
1. Determine the current setting for "StartupSequence" by using

Lenovo BIOS Windows Management Instrumentation Interface Deployment Guide for Workstations 12
Lenovo_BiosSettingclass(see“ListallBIOSsettingsonthelocal
computer”onpage12and“ListallBIOSsettingsontheremote
computer”onpage14forsamplescripts).
2. Tosetanewbootorder,usetheLenovo_SetBiosSettingclass,
thenusetheLenovo_SaveBiosSettingclasstosavethesettings
(see“SetasingleBIOSsettingonthelocalcomputer”onpage12
and“SetasingleBIOSsettingonaremotecomputer”onpage14
forsamplescripts).Specifyanewbootorderby listingthe boot
devicesinorder,separatedbycolons.Devicesthatarenot
specifiedareexcludedfromthebootorder.Inthefollowing
example,theCDdrive0isthefirstbootdeviceandharddisk
drive0isthesecondstartupdevice.
AHCI_CD:AHCI_HDD
Restoring default settings
TorestoredefaultBIOSsettings,usetheLenovo_LoadDefaultSettingsclass,
andthenusetheLenovo_SaveBiosSettingsclasstosavetheBIOSchanges
(seesamplescripts).
Limitations
ThefollowingWMIlimitationsexistforBIOSsetup:

·Passwordsettingandchangingarenotsupported.

@Copyright Lenovo 2010 13
Chapter 4. Security
WMI‐basedadministrationscriptsoperatingoveraremoteconnectionsend
dataoverthenetworkincleartextbydefault.Youcanenhancesecurityby
modifyingWMI‐basedadministrationscriptstoestablishanencrypted
remoteconnectionasfollows:
1.Setanimpersonationlevelof″impersonate″
2.Setanauthenticationlevelof″pktPrivacy″

SeeAppendixA,“SampleVisualBasicscriptsforconfiguringBIOS
settings,”onpage11forsamplescriptsusedtoimplementWMI‐based
administrationscriptsthatincludetheseparametersforencryption.
