5313-3AU 4x5 Celeron E1200 1.60 512KB 2 1GB 160GB2DVD GMA 3100 None Home Basic Jul 08
5313-3BU 4x5 Celeron E1200 1.60 512KB 2 1GB 16-in-1 250GB DVD±RW GMA 3100 Mod None Home Prem Jul 08
5313-4AU 4x5 Pentium E2180 2.00 1MB 2 2GB 16-in-1 320GB DVD±RW GMA 3100 Mod None Camera Home Prem Jul 08
5313-4BU 4x5 Pentium E2180 2.00 1MB 2 3GB 16-in-1 500GB DVD±RW GMA 3100 None Camera Home Prem Jul 08
5313-4DU 4x5 Pentium E2200 2.20 1MB 2 2GB 250GB DVD±RW GMA 3100 None Home Prem Oct 08
5313-4EU 4x5 Pentium E2200 2.20 1MB 2 3GB 320GB DVD±RW GMA 3100 None Home Prem Oct 08
5313-4CU 4x5 Pentium E2200 2.20 1MB 2 4GB 16-in-1 500GB DVD±RW GMA 3100 None Camera Home Prem Jul 08
5313-5CU 4x5 Pentium E5200 2.50 2MB 2 4GB 16-in-1 640GB DVD±RW GMA 3100 None Home Prem Nov 08
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D
S ATA DV D ±RW
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel Celeron Dual-Core Processor E1200 with
dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 512KB L2 cache or
Intel Pentium®Dual-Core Processor E2180,E2200,or E5200
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus;
E2180/E2200: 1MB L2 cache; E5200: 2MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
1GB, 2GB, 3GB,or 4GB std, 4GB max8, PC2-5300 667MHz
DDR2, non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available;
Non-italics: standard memory in one socket; 1 socket available
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
160GB, 250GB, 320GB, 500GB, or 640GB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7DH
Some: DVD-ROM DL SATA 1.5Gb/s 16X-48X Max4
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
One
None
None
Some: 16-in-1 media reader, internal USB 2.0
Intel G31 Express Chipset; I/O Controller Hub 7 Digital Home (ICH7DH) for
SATA 3Gb/s, PCI Express®x1, PCI 2.3, USB, LPC bus / Winbond®W83627DHG
Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
Some: 56K10 V.92 data/fax soft modem, PCI adapter
None
None
Some: Lenovo Bright Eye camera, 0.3-megapixel, fixed focus
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K210 (5313) - Celeron®and Pentium®
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US models announced November 12, 2008; previous models on July 15 or October 22, 2008
© Lenovo
(KW1-3) November 2008
Modem
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black and silver bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x1 Ver 1.1
Slot 2: half-length,full-height, PCI Express x16 Ver 1.1
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* modem in slot in some models
Camera
Monitor
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
• (Select models) Healthcare eyesight protection software detect distance between user and monitor
and adjusts monitor brightness based on environment
• (Select models) Lenovo Bright Eye camera and VeriFace face recognition software help control access to
your computer by recognizing your face
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Preloaded operating system20
- Some: Genuine Windows®Vista®
Home Basic 32
- Some: Genuine Windows Vista
Home Premium 32
✧5313-3AU/3BU: Vista Basic logo
✧Others: Vista Premium logo
Preloaded applications5
• Lenovo®OneKey Recovery
•Lenovo Healthcare Software
•Lenovo Media Studio
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•EarthLink®
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
•Corel®WinDVD®(DVD, DVD±RW)
•CyberLink Power2Go (DVD, DVD±RW)
☞

5313-1FU 4x5 Core 2 Duo E7200 2.53 3MB 2 4GB 16-in-1 640GB2DVD±RW GMA 3100 None None Home Prem Oct 08
5313-2BU 4x5 Core 2 Quad Q6600 2.40 8MB 4 4GB 16-in-1 500GB DVD±RW GMA 3100 None None Cam Home Prem Jul 08
5313-2CU 4x5 Core 2 Quad Q6600 2.40 8MB 4 4GB 16-in-1 500GB Blu-ray 9300 GE None None Home Prem Jul 08
5313-2FU 4x5 Core 2 Quad Q6600 2.40 8MB 4 4GB 16-in-1 1TB Blu-ray 9300 GE None None Home Prem Oct 08
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
EIDE cables
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Core 2 Duo™Processor E7200 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q6600 with quad-core
(dual-core on dual-die), Intel 64 Technology,
Virtualization Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 8MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB std, 4GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available
Some: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G31, uses main memory,
one 15-pin analog D-sub connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
256MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out, VGA connector,
DVI-I connector, HDCP-compliant
500GB, 640GB, or 1TB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH7DH
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
supports HD-DVD playback, DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
One
None
None
16-in-1 media reader, internal USB 2.0
Intel G31 Express Chipset; I/O Controller Hub 7 Digital Home (ICH7DH) for
SATA 3Gb/s, PCI Express®x1, PCI 2.3, USB, LPC bus / Winbond®W83627DHG
Super I/O for serial, parallel, keyboard, mouse functions
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (DB-15, DVI-I in some models)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
10/100 ethernet on planar, Intel 82562GZ (PHY/MAC)
None
None
None
Some: Lenovo Bright Eye camera, 0.3-megapixel, fixed focus
104-key anti-bacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K210 (5313)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞US models announced October 22, 2008; previous models on July 15, 2008
© Lenovo
(KW1-4) February 2009
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
☞
Cores
☞
•Black and silver bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x1 Ver 1.1
Slot 2: half-length,full-height, PCI Express x16 Ver 1.1**
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
** used in some models
Cam-
era
Monitor
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo®Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
• (Select models) Healthcare eyesight protection software detect distance between user and monitor
and adjusts monitor brightness based on environment
• (Select models) Lenovo Bright Eye camera and VeriFace face recognition software help control access to
your computer by recognizing your face
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Modem
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 32
✧Vista Premium logo
Preloaded applications5
• Lenovo®OneKey Recovery
•Lenovo Healthcare Software
•Lenovo Media Studio
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•EarthLink®
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•VeriFace™
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)

5358-4AU 4x5 E2220 2.40 1MB 2 2GB 16-in-1 250GB2Blu-ray GMA 4500 None None Prem 64 Basic Jan 09
5358-4BU 4x5 E2220 2.40 1MB 2 4GB 16-in-1 640GB Blu-ray GMA 4500 None None Prem 64 Basic Jan 09
5358-1FU 4x5 E5200 2.50 2MB 2 4GB 16-in-1 500GB DVD±RW GMA 4500 None None Prem 64 Basic Jan 09
5358-1BU 4x5 E5200 2.50 2MB 2 4GB 16-in-1 640GB DVD±RW 9300 GE None None 11b/g Prem 64 Prem Jan 09
5358-2CU 4x5 Q8200 2.33 4MB 4 4GB 16-in-1 640GB DVD±RW 9300 GE None None Prem 64 Prem Jan 09
5358-2DU 4x5 Q8200 2.33 4MB 4 4GB 16-in-1 1TB Blu-ray 9300 GE None None 11b/g Prem 64 Prem Jan 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Wireless
Ethernet
Modem
Security chip
TV tuner
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Dual-Core Processor E2220 or E5200
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus;
E2220: 1MB L2 cache; E5200: 2MB L2 cache or
Intel Core™2 Quad Processor Q8200 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
2GB or 4GB std, 4GB max8, PC3-8500 1066MHz DDR3,
non-parity, dual-channel capable, two 240-pin DIMM sockets
Italics: standard memory in both sockets; no sockets available;
Non-italics: standard memory in one socket; 1 socket available
Some: Intel Graphics Media Accelerator 4500 (GMA 4500),
integrated graphics in G43, uses main memory,
DirectX®10, one 15-pin analog VGA DB-15 connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
512MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out for TV-out,
VGA DB-15 connector, DVI-I connector, HDCP-compliant
250GB, 500GB, 640GB or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH10
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G43 Express Chipset (PCI Express®2.0 x16), I/O Controller Hub 10
[ICH10] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB, LPC bus),
SMSC®SCH5147-NW Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Six USB 2.0, one serial (9-pin), keyboard (PS/2), mouse (PS/2), ethernet (RJ-45),
1BU/2CU/2DU: monitor (VGA DB-15, DVI-I), S-Video out;
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
Some: 11b/g wireless4, Broadcom BCM4312, PCIe x1 adapter
10/100 ethernet on planar, Realtek®RTL8102E
None
None
None
None
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K220 (5358)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced January 13, 2009
© Lenovo
(KW2-2) March 2009
Monitor
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 2.0 **
Slot 2: half-length,full-height, PCI Express x1 Ver 2.0 *
Slot 3: half-length,full-height, 32-bit PCI Ver 2.3
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter in slot in some models
** used in some models
802.11
wireless
Camera
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)
Vista
logo

57093697 4x5 E2220 2.40 1MB 2 5GB (2, 2, 1) 16-in-1500GB2DVD±RW GMA 3100 None None None Prem 64 Jan 09
57093706 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1640GB DVD±RW GMA 3100 None None None Prem 64 Mar09
57093729 4x5 E7300 2.66 3MB 2 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW GMA 3100 None None None Prem 64 Jan 09
57094418 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 None None None Prem 64 Mar09
57093719 4x5 Q8200 2.33 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW GMA 3100 None None None Prem 64 Mar09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E2220 or E5200
with dual-core, Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus;
E2220: 1MB L2 cache; E5200: 2MB L2 cache or
Intel Core 2 Duo™Processor E7300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8200 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB, 6GB, or 8GB std, 8GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, four 240-pin DIMM sockets
Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G33, uses main memory,
one 15-pin analog VGA DB-15 connector
500GB , 640GB, or 1TB, SATA 3.0Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH9DH
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G33 Express Chipset (PCI Express®x16), I/O Controller Hub 9 Digital
Home [ICH9DH] (SATA 3.0Gb/s support, PCI Express x1, ethernet MAC, PCI 2.3,
USB, LPC bus), SMSC®SCH5617 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45), monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm),
SPDIF-out
High Definition (HD) audio, ADI1988 codec
None
None
Gigabit ethernet on planar, Intel 82256DC
None
None
None
None
None
None
104-key anti-bacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K230
GHz
Part
number Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞ US models announced March 17, 2009; previous models on February 24, 2009
© Lenovo
(KW3-1) March 2009
☞
☞
☞
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
Cam-
era
TV
tuner
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo®Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•TigerDirect
Remote
control
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
✧Vista Basic logo
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2007
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)
DIMM
capacity

5359-1BU 4x5 E2220 2.40 1MB 2 5GB (2, 2, 1) 16-in-1 500GB2DVD±RW GMA 3100 Prem 64 Jan 09
5359-2EU 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-2BU 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-3EU 4x5 E7300 2.66 3MB 2 6GB (2, 2, 2) 16-in-1 1TB DVD±RW GMA 3100 11b/g Prem 64 Jan 09
5359-3AU 4x5 E7400 2.80 3MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-4CU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Jan 09
5359-4DU 4x5 Q8200 2.33 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW 9300 GE 11b/g Prem 64 Jan 09
5359-4GU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Feb 09
5359-5AU 4x5 Q9400 2.66 6MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB Blu-ray 9300 GE TV Remote 11b/g Prem 64 Jan 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E2220 or E5200
with dual-core, 800MHz system bus;
E2220: 1MB L2 cache; E5200: 2MB L2 cache or
Intel Core™2 Duo Processor E7300 or E7400 with dual-core
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8200 or Q9400 with quad-core
(dual-core on dual-die), 1333MHz system bus;
Q8200: 4MB L2 cache; Q9400: 6MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
4GB, 5GB, 6GB,or 8GB std, 8GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, four 240-pin DIMM sockets
Some: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G33, uses main memory,
one 15-pin analog VGA DB-15 connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
512MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out for TV-out,
VGA DB-15 connector, DVI-I connector, HDCP-compliant
500GB, 640GB, or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH9DH
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
DVD and CD recordable
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G33 Express Chipset (PCI Express®x16), I/O Controller Hub 9 Digital
Home [ICH9DH] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB,
LPC bus), SMSC®SCH5617 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45),
4DU/5AU: monitor (VGA DB-15, DVI-I), S-Video out;
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm),
SPDIF-out
High Definition (HD) audio, ADI1988 codec
None
None
Gigabit ethernet on planar, Intel 82256GC
Some: 11b/g wireless4, Broadcom®BCM4312, PCIe x1 adapter
None
None
Some: Hybrid tuner, support analog (NTSC) and digital ( ATSC) signal ,
Hauppauge WinTV-HVR-1250,PCIe x 1
Some: Philips®Vista MCE remote control (40-button), IR receiver via USB
None
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K230 (5359)
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
☞ US model announced February 24, 2009; previous models on January 13, 2009
© Lenovo
(KW3-2) March 2009
TV
tuner
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
☞
Cores
•Black color bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1 **
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter or TV tuner in slot in some models
** used in some models
802.11
wireless
Remote
control
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Available at these retailers
•lenovo.com
•Fry's
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
✧5359-4DU/5AU: Vista Premium logo
✧Others: Vista Basic logo
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW, Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)
DIMM
capacity

5359-2HU 4x5 E5200 2.50 2MB 2 6GB (2, 2, 2) 16-in-1 500GB2DVD±RW GMA 3100 Prem 64 Aug09
5359-3NU 4x5 E7500 2.93 3MB 2 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 11b/g Prem 64 Aug09
5359-3JU 4x5 E7500 2.93 3MB 2 6GB (2, 2, 2) 16-in-1 500GB DVD±RW GMA 3100 Prem 64 Aug09
5359-3LU 4x5 E7500 2.93 3MB 2 8GB (2, 2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Aug 09
5359-4PU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 TV Remote 11b/g Prem 64 Aug 09
5359-4GU 4x5 Q8200 2.33 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW GMA 3100 Prem 64 Aug09
5359-4QU 4x5 Q8200 2.33 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW 9300 GE 11b/g Prem 64 Aug 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Wireless
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E5200 with dual-core,
800MHz system bus, and 2MB L2 cache or
Intel Core™2 Duo Processor E7500 with dual-core
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8200 with quad-core
(dual-core on dual-die), 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
6GB or 8GB std, 8GB max8, PC2-5300 667MHz DDR2,
non-parity, dual-channel capable, four 240-pin DIMM sockets
Some: Intel Graphics Media Accelerator 3100 (GMA 3100),
integrated graphics in G33, uses main memory,
one 15-pin analog VGA DB-15 connector
Some: NVIDIA®GeForce®9300 GE, PCI Express®x16,
512MB memory, DirectX®10, TurboCache,
PureVideo™ HD technology, S-video out for TV-out,
VGA DB-15 connector, DVI-I connector, HDCP-compliant
500GB, 640GB, or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH9DH
Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Two SATA cables (each 1-drop to device), four SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G33 Express Chipset (PCI Express®x16), I/O Controller Hub 9 Digital
Home [ICH9DH] (SATA 3.0Gb/s, PCI Express x1, ethernet MAC, PCI 2.3, USB,
LPC bus), SMSC®SCH5617 Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Four USB 2.0, one serial (9-pin), parallel (25-pin), keyboard (PS/2),
mouse (PS/2), ethernet (RJ-45),
4QU: monitor (VGA DB-15, DVI-I), S-Video out;
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm),
SPDIF-out
High Definition (HD) audio, ADI1988 codec
None
None
Gigabit ethernet on planar, Intel 82256GC
Some: 11b/g wireless4, Broadcom®BCM4312, PCIe x1 adapter
None
None
Some: Hybrid tuner, support analog (NTSC) and digital ( ATSC) signal ,
Hauppauge WinTV-HVR-1250,PCIe x 1
Some: Philips®Vista MCE remote control (40-button), IR receiver via USB
None
104-key antibacterial keyboard (PS/2 connector)
Optical Wheel Mouse (USB connector), 400 dpi
280 watts, universal, manual switch
IdeaCentre™K230 (5359) - August 2009
GHz
Type-model Processor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced August 19, 2009
© Lenovo
(KW3-3) August 2009
TV
tuner
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black color bezel
• 7.1" W X 17.0" D X 15.0" H
• 180mm W X 432mm D X 380mm H
•21.5 lb (9.75 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 1.1 **
Slot 2: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 3: half-length,full-height, PCI Express x1 Ver 1.1 *
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter or TV tuner in slot in some models
** used in some models
802.11
wireless
Remote
control
• Antibacterial keyboard uses special material on the surface of the keys to restrain bacterial growth
• Lenovo Rescue System provides OneKey recovery and OneKey Antivirus without booting into Windows
Vista
preload
Preloaded operating system20
- Genuine Windows®Vista®
Home Premium 64
✧5359-4QU: Vista Premium logo
✧Others: Vista Basic logo
Preloaded applications5
• Lenovo®OneKey Recovery
• Driver and Application Installation
•Trend Micro™PC-cillin™Internet Security 2008
•Windows Live™Toolbar
• Microsoft®Office 2007 Trial (60-day)
•Corel®WinDVD®(DVD±RW)
•CyberLink Power2Go (DVD±RW)
DIMM
capacity

Lenovo IdeaCentre K300
Lenovo IdeaCentre K300
Lenovo IdeaCentre K300
toolless disk drive removal
Lenovo IdeaCentre K300
(monitor not included)
Lenovo IdeaCentre K300
top button
Lenovo IdeaCentre K300
Power control switch

5316-1AU 4x5 Q8300 2.50 4MB 4 6GB (2, 2, 2) 16-in-1 640GB2DVD±RW GMA X4500 Prem 64 Oct 09
5316-1BU 4x5 Q8300 2.50 4MB 4 6GB (2, 2, 2) 16-in-1 640GB DVD±RW HD4350 TV Remote 11b/g11 Prem 64 Oct 09
5316-1GU 4x5 Q8300 2.50 4MB 4 6GB (2, 2, 2) 16-in-1 640GB Blu-ray HD4650 Prem 64 Oct 09
5316-1CU 4x5 Q8300 2.50 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW HD4650 11b/g Prem 64 Oct 09
5316-2AU 4x5 E5300 2.60 2MB 2 3GB (1, 2) 16-in-1 320GB DVD±RW GMA X4500 Prem 64 Oct 09
5316-2CU 4x5 E7500 2.93 3MB 2 4GB (2, 2) 16-in-1 640GB DVD±RW GMA X4500 Prem 64 Oct 09
5316-1EU 4x5 Q8300 2.50 4MB 4 8GB (2, 2, 2, 2) 16-in-1 1TB DVD±RW HD4650 TV Remote Prem 64 Oct 09
Processor
Implementation
Memory
Graphics
SATA disk
SATA controller
S ATA DV D ±RW
SATA Blu-ray™
SATA cables
EIDE controller
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Wireless
Ethernet
Modem
Security chip
TV tuner
Remote control
Camera
Keyboard
Mouse
Power supply
Intel®Pentium®Processor E5300 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
800MHz system bus, and 2MB L2 cache or
Intel Core 2 Duo™Processor E7500 with dual-core,
Intel 64 Technology, Execute Disable Bit, EIST,
1066MHz system bus, and 3MB L2 cache or
Intel Core 2 Quad Processor Q8300 with quad-core
(dual-core on dual-die), Intel 64 Technology, Execute Disable Bit,
EIST, 1333MHz system bus, and 4MB L2 cache
Processor in FC-LGA6 package in LGA775 socket
3GB, 4GB, 6GB, or 8GB std, 8GB max8, dual-channel capable,
PC3-8500 1066MHz DDR3, non-parity, four 240-pin DIMM sockets
Some: Intel Graphics Media Accelerator X4500 (GMA X4500),
integrated graphics in G43, uses main memory,
DirectX®10, one 15-pin analog VGA DB-15 connector
Some: ATI™Radeon™ HD 4350, PCI Express®x16,
512MB memory, DirectX®10, ATI Avivo™ HD,
VGA, DVI-I, HDCP-compliant
Some: ATI™Radeon™ HD 4650, PCI Express®x16,
1GB memory, DirectX®10, ATI Avivo™ HD,
VGA, HDMI, DisplayPort, HDCP-compliant
320GB, 640GB,or 1TB SATA 3Gb/s, 7200 rpm
Serial ATA, SATA 3.0Gb/s, integrated in ICH10R, RAID 0 support
Some: Multi-Burner DL DVD±RW SATA 1.5Gb/s Drive
Some: Blu-ray Disc reader (no Blu-ray media burning), BD-ROM,
DVD and CD recordable
Two SATA cables (each 1-drop to device), five SATA connectors
None
None
16-in-1 media reader, internal USB 2.0
Intel G43 Express Chipset (PCI Express®2.0 x16), I/O Controller Hub 10 RAID
[ICH10R] (SATA 3.0Gb/s with RAID 0 support, PCI Express x1, ethernet MAC,
PCI 2.3, USB, LPC bus), SMSC®SCH5147-NW Super I/O
Two USB 2.0, microphone (stereo, 3.5mm), headphone (stereo, 3.5mm)
Six USB 2.0, one serial (9-pin), keyboard (PS/2), mouse (PS/2), ethernet (RJ-45),
HD 4650 models: monitor (VGA DB-15, HDMI, DisplayPort)
HD 4350 models: monitor (VGA DB-15, DVI-I)
Others: monitor (VGA DB-15)
Line-in (stereo, 3.5mm), line-out (stereo, 3.5mm), microphone-in (stereo, 3.5mm)
High Definition (HD) audio, ALC662 codec
None
None
Some: 11b/g wireless4, Broadcom BCM4312, PCIe x1 adapter
10/100 ethernet on planar, Realtek®RTL8102E
None
None
Some: Hybrid tuner, support analog (NTSC) and digital ( ATSC) signal ,,PCIe x 1
Some: Philips®Win7 MCE remote control (40-button), IR receiver via USB
None
Full-size keyboard (PS/2 connector), Fn keys, black
Optical Wheel Mouse (USB connector), 1000 dpi, black
280 watts, universal, manual switch
IdeaCentre™K300 (5316) - Windows 7
GHz
Type-model
Pro-
cessor Memory8SATA
disk
SATA
optical Graphics
Avail
date
Slot x
bay
Personal Systems Reference (PSREF)
Tower
L2
cache
See footnotes for important warranty information
US models announced October 22, 2009
© Lenovo
(TNA1-1) October 2009
Media
reader
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
Cores
•Black bezel
• 7.09" W X 17.32" D X 15.35" H
• 180mm W X 440mm D X 390mm H
•24.6 lb (11.2 kg)
•Toolless cover removal
•Toolless disk, optical drive removal
•Toolless adapter retention
Bay ①5.25", 1.6" high, access, standard optical
Bay ②5.25", 1.6" high, access, open
Bay ③3.0", 1" high, access, 16-in-1 media reader
Bay ④3.5", 1" high, no access, standard disk
Bay ⑤ 3.5", 1" high, no access, optional disk
Slot 1: half-length,full-height, PCI Express x16 Ver 2.0 **
Slot 2: half-length,full-height, PCI Express x1 Ver 2.0 *
Slot 3: half-length,full-height, PCI Express x1 Ver 2.0
Slot 4: half-length,full-height, 32-bit PCI Ver 2.3
* Wireless adapter in slot in some models
** Graphics adapter in slot in some models
802.11
wireless
Remote
control
•Power control switch on front to adjust power and energy for three modes (cool, auto, and turbo)
• Lenovo Rescue System provides OneKey recovery without booting into Windows
Win 7
preload
Preloaded operating system20
- Genuine Windows®7
Home Premium 64
Preloaded applications5(only some listed)
• Lenovo®OneKey Recovery
• Driver and Application Installation
• McAfee VirusScan®Plus
(30 days of virus defi nitions)
•Lenovo Power Dial
•Lenovo Healthcare Software
•Corel®WinDVD®(Blu-ray)
•CyberLink Power2Go (DVD±RW, Blu-ray)
TV
tuner
DIMM
capacity

Partial list of accessories supported on:
IdeaCentre K210, K220, and K230
Storage and removable storage
USB 2.0 MyKey E10 Flash Drive 1GB 45J7701 ann 04/29/08
USB 2.0 MyKey E10 Flash Drive 2GB 45J7702 ann 04/29/08
USB 2.0 MyKey E10 Flash Drive 4GB 45J7703 ann 04/29/08
USB 2.0 MiniKey M10D1 Flash 2GB (gray) 45J7752 ann 05/20/08
USB 2.0 MiniKey M10D2 Flash 2GB (black) 45J7754 ann 05/20/08
USB 2.0 MiniKey M10E1 Flash 2GB (teal) 45J7756 ann 05/20/08
USB 2.0 MiniKey M10E2 Flash 2GB (pink) 45J7758 ann 05/20/08
USB 2.0 Essential Memory Key 4GB 45J7904 ann 06/24/08
USB 2.0 Essential Memory Key 8GB 45J7905 ann 07/15/08
USB 2.0 Essential Memory Key 32GB 45K1258 ann 10/28/08
USB 2.0 DataSlim E16 Portable HD 160GB 45J7700 ann 04/29/08
USB 2.0 Portable Secure 160GB Hard Disk 43R2018 ann 11/18/08
USB 2.0 Portable Secure 320GB Hard Disk 43R2019 ann 11/18/08
USB 2.0 Portable 500GB Hard Disk 45K1690 ann 05/26/09
Keyboard
Preferred Pro USB Keyboard 73P5220 ann 06/21/05
Enhanced Performance USB Keyboard 73P2620 ann 03/23/04
Ultraslim Wireless Keyboard and Mouse52 57Y4700 ann 09/15/09
52 Wireless via 2.4GHz technology using a micro-size USB receiver.
Mouse
Lenovo Laser Mouse (USB) 41U3074 ann 01/23/07
IdeaPad Mini Optical Mouse M10 (black) 47J7729 ann 06/17/08
IdeaPad Mini Optical Mouse M10A (black) 45J7730 ann 07/15/08
Lenovo Mini Optical Mouse M30 (black) 47J7735 ann 06/17/08
Lenovo Mini Optical Mouse M30 (white) 47J7736 ann 06/17/08
Lenovo Mini Optical Mouse M30 (red) 47J7737 ann 06/17/08
Lenovo Mini Optical Mouse M30 (blue) 47J7738 ann 06/17/08
Mini Wireless Laser Mouse N10 (black) 45J7731 ann 06/17/08
Mini Wireless Laser Mouse N10 (red) 45J7732 ann 06/17/08
Monitors
Lenovo
®
D185 Wide 18.5" Monitor 6318HB1 ann 01/27/09
Lenovo L215 Wide 21.5" Monitor 6325HB1 ann 01/27/09
Lenovo L215p Wide 21.5" Monitor 6325HC1 ann 01/27/09
ThinkVision
®
L174 17" Monitor 9227AE1 ann 04/15/08
ThinkVision L1700p 17" Monitor 9417HE2 ann 09/17/08
ThinkVision L1711p 17" Monitor 5047HB2 ann 10/20/09
ThinkVision L1900p 19" Monitor 4431HE1 ann 11/11/08
ThinkVision L1940p Wide 19" Monitor 4424HB6 ann 09/17/08
ThinkVision L1951p Wide 19" Monitor 2448HB6 ann 10/20/09
ThinkVision L2240p Wide 22" Monitor 4422HB6 ann 09/17/08
ThinkVision L2250p Wide 22" Monitor 2572HB6 ann 10/20/09
ThinkVision L2251p Wide 22" Monitor 2572HD6 ann 10/20/09
ThinkVision L2251x Wide 22" Monitor 2578HB6 ann 10/20/09
ThinkVision L2440p Wide 24" Monitor 4420HB2 ann 09/17/08
ThinkVision L2440x Wide 24" Monitor 4421HB2 ann 09/17/08
Monitor Accessories46
ThinkVision USB Soundbar 40Y7616 ann 08/23/05
ThinkVision Soundbar 45K1263 ann 09/16/08
Kensington®MicroSaver®Cable Lock 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Easy Reach Monitor Stand 55Y9258 ann 09/22/09
Radial Arm 19K4464 ann 05/05/00
46
Compatible on selected ThinkVision monitors.
More information at www.lenovo.com/support/monitoraccessories
Consumer monitors
Lenovo L195 Wide 19" LCD Monitor 4418HC1 ann 09/02/08
Lenovo L222 Wide 22" LCD Monitor 4432HF1 ann 09/02/08
Other accessories at www.lenovo.com/accessories
Accessories Guide pdf at www.lenovo.com/accessoriesguide
© Lenovo
(O-IC) July 2009
IdeaCentre™Accessories Personal Systems Reference (PSREF)

Availability: All offers subject to avail-
ability. Lenovo reserves the right to alter
product offerings and specifications at
any time, without notice. Lenovo is not
responsible for photographic or typo-
graphic errors.
Warranty: For a copy of applicable
product warranties, write to: Warranty In-
formation, P.O. Box 12195, RTP, NC, 27709,
Attn: Dept ZPYA/B676. Lenovo makes no
representation or warranty regarding third
party products or services.
1 Limited warranty: Support unrelated to
a warranty issue may be subject to ad-
ditional charges.
2 Hard disk drive: GB = billion bytes, TB =
trillion bytes. Accessible capacity is less;
up to 4GB is service partition.
3Customer Replacement Units (CRUs)
are designed to be replaced by custom-
ers during the applicable warranty pe-
riod. Lenovo will send a technician onsite
to perform a repair if remote telephone
diagnosis does not isolate the problem,
if customer replaceable parts are unable
to resolve the problem, or at the request
of the customer. For a list of customer
replaceable parts, contact Lenovo. Sup-
port unrelated to a warranty issue may
be subject to additional charges.
5Included software may differ from its
retail version (if available), and may not
include user manuals or all program
functionality. License agreements may
apply.
8Memory: For PCs without a separate
video card, memory supports both
system and video. Accessible system
memory is less than the amount stated,
depending on video mode.
9Service upgrade options: Service
period begins with the equipment date
of purchase. Service must be purchased
during the original limited product war-
rantyperiod. Service levels are response
time objectives and are not guarantees.
1 0 Modem speeds: Public network
download speeds are limited to 53Kbps.
Upload speeds are limited to 48Kbps for
V.92 modems. Actual speeds depend on
many factors and are often less than the
maximum possible. V.92 functions and
speeds require compatible phone line
and server equipment. Check with your
telephone and ISP service providers for
availability.
14 Response times may vary. May exclude
some holidays. Telephone support may
be subject to additional charges.
20 Operating System: Level of support var-
ies by operating system. Operating sys-
tems not preloaded on the system may
not provide full feature functionality. Refer
to lenovo.com/pc/support and enter your
machine type and model number for
more information.
This publication was developed for prod-
ucts and services offered in the United
States. Lenovo may not offer the products,
services or features discussed in this
document in other countries. Lenovo may
withdraw an offering at any time. Informa-
tion is subject to change without notice.
Consult your local representative for
information on offerings available in your
area.
Lenovo reserves the right to change spec-
ifications and other product information
at any time without prior notice. Lenovo is
not responsible for photographic or typo-
graphical errors. LENOVO PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WAR-
RANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
Some jurisdictions do not allow disclaimer
of express or implied warranties in certain
transactions; therefore this disclaimer may
not apply to you.
Trademarks: Lenovo, the Lenovo logo,
New World. New Thinking., Access Con-
nections, Rescue and Recovery, Think-
Vantage, and ThinkVision are trademarks
of Lenovo. Microsoft, Windows, and Vista
are registered trademarks of Microsoft
Corporation. Intel, the Intel logo, Intel
Inside logo, Intel Core and Core Inside
are trademarks of Intel Corporation in the
US and other countries. AMD, the AMD
logo, AMD Athlon, AMD Sempron, and
combinations thereof, are trademarks
of Advanced Micro Devices, Inc. PCI
Express is a trademark of PCI-SIG. Other
company, product, or service names may
be trademarks or service marks of oth-
ers.
Visit www.lenovo.com/safecomputing
periodically for the latest information on
safe and effective computing.
Visit www.lenovo.com/psref
for the latest version of
Personal Systems Reference.
© Lenovo, 2009.
All rights reserved.
Lenovo
1009 Think Place
Morrisville, NC 27560
U.S.A.
October 2009
icbook.pdf
