Lenovo 21D80006IX User manual

P15v Gen 3 and T15p Gen 3
User Guide
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Lenovo ThinkPad
P15v Gen 3 21D80006IX o cerca il tuo prodotto tra le migliori offerte di Notebook

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
following:
Safety and Warranty Guide
Setup Guide
Generic Safety and Compliance Notices
First Edition (April 2022)
© Copyright Lenovo 2022.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
Discover yo r Lenovo notebook. . . . . iii
Chapter 1. Meet yo r comp ter . . . . . 1
Front view . . . . . . . . . . . . . . . . . . 1
Side view . . . . . . . . . . . . . . . . . . 3
Bottom view . . . . . . . . . . . . . . . . . 5
Rear view . . . . . . . . . . . . . . . . . . 5
Features and specifications . . . . . . . . . . . 7
USB specifications. . . . . . . . . . . . . 7
Chapter 2. Get started with yo r
comp ter . . . . . . . . . . . . . . . . . 9
Access networks . . . . . . . . . . . . . . . 9
Connect to Wi-Fi networks. . . . . . . . . . 9
Connect to the wired Ethernet . . . . . . . . 9
Connect to a cellular network (for selected
models) . . . . . . . . . . . . . . . . . 9
Turn on the Airplane mode . . . . . . . . . 10
Interact with your computer . . . . . . . . . . 10
Use the keyboard shortcuts . . . . . . . . 10
Use the TrackPoint pointing device . . . . . 12
Use the trackpad . . . . . . . . . . . . 13
Use the touch screen (for selected models) . . 14
Connect to an external display . . . . . . . 16
Chapter 3. Explore yo r comp ter . . 19
Lenovo apps . . . . . . . . . . . . . . . . 19
The Vantage app . . . . . . . . . . . . 19
Lenovo Quick Clean / Clean Your Device . . . 19
Smart features (for selected models). . . . . . . 20
Color calibration (for selected models) . . . . . . 22
Intelligent cooling . . . . . . . . . . . . . . 23
Manage power . . . . . . . . . . . . . . . 23
Check the battery status . . . . . . . . . 24
Charge the computer . . . . . . . . . . . 24
Change the power settings . . . . . . . . 24
Transfer data . . . . . . . . . . . . . . . . 25
Set up a Bluetooth connection . . . . . . . 25
Use an SD card or smart card (for selected
models) . . . . . . . . . . . . . . . . 25
Accessories . . . . . . . . . . . . . . . . 26
Purchase accessories . . . . . . . . . . 26
Chapter 4. Sec re yo r comp ter
and information . . . . . . . . . . . . 27
Lock the computer . . . . . . . . . . . . . 27
Log in with your fingerprint . . . . . . . . . . 27
Log in with your face ID (for selected models) . . . 28
Protect data against power loss (for selected
models) . . . . . . . . . . . . . . . . . . 28
UEFI BIOS passwords . . . . . . . . . . . . 28
Password types . . . . . . . . . . . . . 28
Set, change, and remove a password . . . . 29
Associate your fingerprints with passwords
(for selected models) . . . . . . . . . . . 30
Certificate based BIOS management. . . . . 31
Chapter 5. Config re advanced
settings. . . . . . . . . . . . . . . . . 33
UEFI BIOS . . . . . . . . . . . . . . . . . 33
Enter the UEFI BIOS menu . . . . . . . . . 33
Navigate in the UEFI BIOS interface . . . . . 33
Set the system date and time. . . . . . . . 33
Change the startup sequence . . . . . . . 33
View UEFI BIOS Event log . . . . . . . . . 33
Detect memory retraining . . . . . . . . . 34
Reset system to factory defaults . . . . . . 35
Update UEFI BIOS . . . . . . . . . . . . 35
RAID (for Intel models only) . . . . . . . . . . 36
Storage drive requirements for RAID levels . . 36
Enter the Intel RST configuration utility . . . . 36
Create RAID volumes . . . . . . . . . . . 37
Delete RAID volumes . . . . . . . . . . . 37
Reset storage drives to non-RAID . . . . . . 37
Rebuild RAID 1 volumes. . . . . . . . . . 38
Install a Windows operating system and drivers . . 38
Chapter 6. CRU replacement . . . . . 41
CRU list . . . . . . . . . . . . . . . . . . 41
Disable Fast Startup and the built-in battery. . . . 41
Replace a CRU . . . . . . . . . . . . . . . 42
Keyboard . . . . . . . . . . . . . . . 42
Base cover assembly . . . . . . . . . . . 46
Wireless WAN card (for selected models) . . . 47
Coin-cell battery. . . . . . . . . . . . . 49
Memory module . . . . . . . . . . . . . 49
M.2 solid-state drive and its bracket . . . . . 50
Chapter 7. Help and s pport . . . . . 53
Frequently asked questions . . . . . . . . . . 53
Error messages . . . . . . . . . . . . . . . 54
Beep errors . . . . . . . . . . . . . . . . 55
Self-help resources . . . . . . . . . . . . . 56
Windows label . . . . . . . . . . . . . . . 57
Call Lenovo . . . . . . . . . . . . . . . . 57
© Copyright Lenovo 2022 i

Before you contact Lenovo . . . . . . . . 57
Lenovo Customer Support Center . . . . . . 58
Purchase additional services. . . . . . . . . . 59
Appendix A. Compliance
information . . . . . . . . . . . . . . . 61
Appendix B. Notices and
trademarks . . . . . . . . . . . . . . . 63
ii P15v Gen 3 and T15p Gen 3 User Guide

Discover yo r Lenovo notebook
Thank yo for choosing a Lenovo® notebook! We are dedicated to delivering the best sol tion to yo .
Before starting your tour, please read the following information:
Illustrations in this documentation might look different from your product.
Depending on the model, some optional accessories, features, software programs, and user interface
instructions might not be applicable to your computer.
Documentation content is subject to change without notice. To get the latest documentation, go to https://
pcsupport.lenovo.com.
© Copyright Lenovo 2022 iii

iv P15v Gen 3 and T15p Gen 3 User Guide

Chapter 1. Meet yo r comp ter
Front view
Infrared camera* / Camera* Webcam privacy shutter*
Microphones* Touch screen*
Speaker Power button
TrackPoint® pointing stick TrackPoint buttons
Trackpad Fingerprint reader
* for selected models
© Copyright Lenovo 2022 1

Webcam privacy sh tter
Slide the webcam privacy shutter to cover or uncover the camera lens. It is designed to protect your privacy.
Related topics
“Use the keyboard shortcuts” on page 10
“Use the TrackPoint pointing device” on page 12
“Use the trackpad” on page 13
“Use the touch screen (for selected models)” on page 14
“Log in with your fingerprint” on page 27
“Log in with your face ID (for selected models)” on page 28
2P15v Gen 3 and T15p Gen 3 User Guide

Side view
Intel models
Power connector USB-C® (Thunderbolt 4) connector
Smart card reader* Audio connector
SD card reader HDMI™ connector
USB 3.2 connector Gen 1 Always on USB 3.2 connector Gen 1
Ethernet connector Security-lock slot
* for selected models
Chapter 1.Meet your computer 3

AMD models
Power connector USB 4 connector
Smart card reader* Audio connector
SD card reader HDMI connector
USB 3.2 connector Gen 1 Always on USB 3.2 connector Gen 1
Ethernet connector Security-lock slot
* for selected models
Related topics
“USB specifications” on page 7
“Connect to the wired Ethernet” on page 9
“Connect to an external display” on page 16
“Charge the computer” on page 24
“Use an SD card or smart card (for selected models)” on page 25
“Lock the computer” on page 27
4P15v Gen 3 and T15p Gen 3 User Guide

Bottom view
Keyboard drainage hole Emergency-reset hole
Emergency-reset hole
If the computer stops responding and you cannot turn it off by pressing the power button, reset your
computer:
1. Disconnect your computer from ac power.
2. Insert a straightened paper clip into the hole to cut off power supply temporarily.
3. Connect your computer to ac power and then turn on your computer.
CAUTION:
When the comp ter is operating, it sho ld be placed on a hard and flat s rface with its bottom area
not in contact with ser’s bare skin. Under normal operating conditions, the temperat re of the
bottom s rface will remain within an acceptable range as defined in IEC 62368-1, b t s ch
temperat res can still be high eno gh to ca se discomfort or harm to the ser if directly to ched for
over one min te at a time. As s ch, it is recommended that sers avoid prolonged direct contact with
the bottom of the comp ter.
Rear view
Chapter 1.Meet your computer 5

Nano-SIM-card tray*
* for selected models
Related topic
“Connect to a cellular network (for selected models)” on page 9
6P15v Gen 3 and T15p Gen 3 User Guide

Feat res and specifications
For detailed specifications of your computer, go to https://psref.lenovo.com and search by product.
Memory Two slots, Double data rate 5 (DDR5) small outline dual in-line memory module
(SODIMM), up to 32 GB for each, up to 64 GB in total
Storage device Two slots, 2280 M.2 solid-state drive, up to 2 TB for each, up to 4 TB in total
A dio Dolby AudioTM Premium
Dolby Voice®
Display
Color display with In-Plane Switching (IPS) technology
Display ratio: 16:9
Display resolution: 1920 x 1080 pixels or 3840 x 2160 pixels
Dolby VisionTM*
Multi-touch technology*
Sec rity feat res
Face authentication*
Fingerprint reader
Glance Privacy Alert*
Glance Privacy Guard*
Discrete Trusted Platform Module (dTPM)*
Wireless feat res
Bluetooth
GPS (on wireless WAN model)*
Wireless LAN*
Wireless WAN (4G)*
Note: The 4G cellular service is provided by authorized mobile service carriers
in some countries or regions. You must have a cellular plan from a service
carrier to connect to the cellular network. The cellular data plan might vary by
location.
* for selected models
USB specifications
Note: Depending on the model, some USB connectors might not be available on your computer.
Chapter 1.Meet your computer 7

Connector name Description
USB 3.2 connector Gen 1
Connect USB-compatible devices, such as a USB keyboard, USB
mouse, USB storage device, or USB printer.
USB-C (Thunderbolt 4) connector
USB 4 connector
Charge USB-C compatible devices with the output voltage and
current of 5 V and 3 A (for Intel models only).
Connect to an external display:
– USB-C to VGA: up to 1920 x 1200 pixels, 60 Hz
– USB-C to DP: up to 5120 x 3200 pixels, 60 Hz
Connect to USB-C accessories to help expand your computer
functionality. To purchase USB-C accessories, go to https://
www.lenovo.com/accessories.
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1 5
3.2 Gen 2 / 3.1 Gen 2 10
3.2 Gen 2 × 2 20
4 Gen 2 × 2 20
4 Gen 3 × 2 40
Thunderbolt 3 40
Thunderbolt 4 40
8P15v Gen 3 and T15p Gen 3 User Guide

Chapter 2. Get started with yo r comp ter
Access networks
This section helps you connect to a wireless or wired network.
Connect to Wi-Fi networks
Click the network icon in the Windows® notification area, and then select a network for connection. Provide
required information, if needed.
Connect to the wired Ethernet
Connect your computer to a local network through the Ethernet connector on your computer with an
Ethernet cable.
Connect to a cell lar network (for selected models)
To connect a 4G cellular data network, you must have a wireless wide area network (WWAN) card and a
nano-SIM card installed. The nano-SIM card might come with your computer by countries or regions. If no
nano-SIM card is shipped, you will need to purchase one from authorized service carriers.
Depending on model, your computer might have no WWAN card installed. For installation procedures of the
WWAN card, see “Wireless WAN card (for selected models)” on page 47.
Notes:
© Copyright Lenovo 2022 9

The 4G cellular service is provided by authorized mobile service carriers in some countries or regions. You
must have a cellular plan from a service carrier to connect to the cellular network. The cellular data plan
might vary by location.
Network connection speeds might also vary by location, environment, network conditions and other
factors.
To establish a cellular connection:
1. Turn off the computer.
2. Locate the nano-SIM card slot and insert the nano-SIM card as shown. Note the orientation of the card
and ensure that it is seated correctly.
3. Turn on the computer.
4. Click the network icon, and then select the cellular network icon from the list. Provide required
information, if needed.
T rn on the Airplane mode
When the Airplane mode is enabled, all wireless features are disabled.
1. Type Airplane mode in the Windows search box and then press Enter.
2. Turn on the Airplane mode.
Interact with yo r comp ter
Your computer provides you various ways to navigate the screen.
Use the keyboard shortc ts
The special keys on the keyboard help you work more effectively.
https://support.lenovo.com/us/en/videos/vid500145
10 P15v Gen 3 and T15p Gen 3 User Guide

+
Invoke the special function printed as an icon on each key or standard function of
F1–F12 function keys.
FnLock indicator on: standard function
FnLock indicator off: special function
Enable / disable speakers
Decrease volume
Increase volume
Enable / disable microphones
Darken display
Brighten display
Manage external displays
Enable / disable wireless
Open / collapse notification center
Answer incoming calls on Microsoft Teams®
Decline incoming calls on Microsoft Teams
Open the Vantage app. You can customize the function of this key on the Vantage
app.
+
Open calculator
+
Enter sleep mode
+
Open Snipping Tool
+
Toggle keyboard backlight (for selected models)
+
Break operation
+
Pause operation
Chapter 2.Get started with your computer 11

+
Scroll contents
+
Send system request
+
Enter sleep mode
To wake up the computer, press Fn or the power button.
+
Go to beginning
+
Go to end
Use the TrackPoint pointing device
The TrackPoint pointing device enables you to perform all the functions of a traditional mouse, such as
pointing, clicking, and scrolling.
Use the TrackPoint pointing device
TrackPoint pointing stick
Use your finger to apply pressure to the pointing-stick nonslip cap in any direction parallel to the keyboard.
The pointer on the screen moves accordingly. The higher the pressure applied, the faster the pointer moves.
TrackPoint b ttons
The left-click button and right-click button correspond to the left and right buttons on a traditional mouse.
Press and hold the dotted middle button while using your finger to applying pressure to the pointing stick in
the vertical or horizontal direction. Then, you can scroll through the document, Web site, or apps.
12 P15v Gen 3 and T15p Gen 3 User Guide

Disable the TrackPoint pointing device
The TrackPoint pointing device is active by default. To disable the device:
1. Open the Start menu, and then click Settings ➙ Devices ➙ Mo se.
2. Follow the on-screen instructions to disable TrackPoint.
Replace the pointing-stick nonslip cap
Note: Ensure that the new cap has grooves a.
Use the trackpad
You can use the trackpad to perform all the pointing, clicking, and scrolling functions of a traditional mouse.
Use the trackpad
Left-click zone Right-click zone
Chapter 2.Get started with your computer 13

Use the to ch gest res
Tap once to select or open an item. Tap twice quickly to display a shortcut menu.
Two-finger zoom in or zoom out. Scroll through items.
Open the task view to see all open windows. Show the desktop.
Notes:
When using two or more fingers, ensure that you position your fingers slightly apart.
Some gestures are not available if the last action was done from the TrackPoint pointing device.
Some gestures are only available when you are using certain apps.
If the trackpad surface is stained with oil, turn off the computer first. Then, gently wipe the trackpad
surface with a soft and lint-free cloth moistened with lukewarm water or computer cleaner.
For more gestures, see the help information of the pointing device.
Disable the trackpad
The trackpad is active by default. To disable the device:
1. Open the Start menu, and then click Settings ➙ Devices ➙ To chpad.
2. In the Touchpad section, turn off the To chpad control.
Use the to ch screen (for selected models)
If your computer display supports the multi-touch function, you can navigate the screen with simple touch
gestures. For more touch gestures, refer to https://support.microsoft.com/windows.
Note: Some gestures might not be available when you are using certain apps.
14 P15v Gen 3 and T15p Gen 3 User Guide
