ThinkSystem SR850
Setup Guide
Machine Types: 7X18 and 7X19

Note
Before using this information and the product it supports be sure to read and understand the safety
information and the safety instructions which are available at:https://pubs.lenovo.com/safety_documentation/
In addition be sure that you are familiar with the terms and conditions of the Lenovo warranty for your server
which can be found at:http://datacentersupport.lenovo.com/warrantylookup
Twenty-seventh Edition (November 2022)
© Copyright enovo 2017, 2022.
IMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration (GSA) contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No.
GS-35F-05925.

Contents
Contents . . . . . . . . . . . . . . . . . i
Safety . . . . . . . . . . . . . . . . . . iii
Safety inspection checklist . . . . . . . . . . . iv
Chapter 1. Introduction . . . . . . . . . 1
Server package contents . . . . . . . . . . . . 1
Features. . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . 3
Particulate contamination . . . . . . . . . . 7
Management options. . . . . . . . . . . . . . 8
Chapter 2. Server components . . . . 13
Front view . . . . . . . . . . . . . . . . . 13
Front operator panel . . . . . . . . . . . 16
Front operator panel with LCD display . . . . 16
Rear view . . . . . . . . . . . . . . . . . 21
Optional processor and memory expansion tray . . 24
PCIe riser-cards. . . . . . . . . . . . . . . 27
2.5-inch drive backplanes . . . . . . . . . . . 28
RAID adapters . . . . . . . . . . . . . . . 29
Internal cable routing. . . . . . . . . . . . . 30
Cable routing for 2.5-inch drives . . . . . . 30
Parts list. . . . . . . . . . . . . . . . . . 45
Power cords . . . . . . . . . . . . . . 49
Chapter 3. Server hardware setup . . 51
Server setup checklist . . . . . . . . . . . . 51
Installation Guidelines . . . . . . . . . . . . 52
System reliability guidelines . . . . . . . . 53
Working inside the server with the power on . . 53
Handling static-sensitive devices . . . . . . 54
Memory module installation rules and order . . . . 54
Memory module installation guideline . . . . 55
DRAM DIMM installation order . . . . . . . 56
DCPMM and DRAM DIMM installation order . . 75
Install server hardware options . . . . . . . . . 85
Remove the security bezel . . . . . . . . . 86
Remove the top cover . . . . . . . . . . 87
Remove the processor and memory
expansion tray or the system air baffle . . . . 88
Remove the fan cage assembly . . . . . . . 90
Install a processor-heat-sink module. . . . . 92
Install a memory module . . . . . . . . . 95
Install a drive backplane. . . . . . . . . . 96
Install a 2.5-inch hot-swap drive . . . . . . 98
Install the PCIe riser-card assembly . . . . . 99
Install the LOM adapter . . . . . . . . . . 101
How to adjust the position of the retainer on
the M.2 backplane . . . . . . . . . . . . 102
Install an M.2 drive in the M.2 backplane . . . 103
Install the M.2 backplane . . . . . . . . . 104
Install the fan cage assembly . . . . . . . . 105
Install the processor and memory expansion
tray or the system air baffle . . . . . . . . 106
Install the top cover . . . . . . . . . . . 110
Install the security bezel. . . . . . . . . . 111
Install the server in a rack . . . . . . . . . . . 112
Cable the server . . . . . . . . . . . . . . 113
Power on the server . . . . . . . . . . . . . 113
Validate server setup. . . . . . . . . . . . . 113
Power off the server . . . . . . . . . . . . . 113
Chapter 4. System configuration . . . 115
Set the network connection for the Lenovo XClarity
Controller . . . . . . . . . . . . . . . . . 115
Set front USB port for Lenovo XClarity Controller
connection. . . . . . . . . . . . . . . . . 116
Update the firmware . . . . . . . . . . . . . 117
Configure the firmware . . . . . . . . . . . . 120
Memory configuration . . . . . . . . . . . . 121
Configure Persistent Memory Module
(PMem) . . . . . . . . . . . . . . . . 121
RAID configuration . . . . . . . . . . . . . 126
Deploy the operating system. . . . . . . . . . 126
Back up the server configuration . . . . . . . . 127
Update the Vital Product Data (VPD). . . . . . . 128
Update the Universal Unique Identifier
(UUID). . . . . . . . . . . . . . . . . 128
Update the asset tag . . . . . . . . . . . 129
Chapter 5. Resolving installation
issues . . . . . . . . . . . . . . . . . 133
Appendix A. Getting help and
technical assistance . . . . . . . . . . 139
Before you call . . . . . . . . . . . . . . . 139
Collecting service data . . . . . . . . . . . . 140
Contacting Support . . . . . . . . . . . . . 141
Index . . . . . . . . . . . . . . . . . . 143
© Copyright Lenovo 2017 2022 i

ii ThinkSystem SR850 Setup Guide

Safety
Before installing this product read the Safety Information.
Antes de instalar este produto leia as Informações de Segurança.
Læs sikkerhedsforskrifterne før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen lue turvaohjeet kohdasta Safety Information.
Avant d'installer ce produit lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto leggere le Informazioni sulla Sicurezza.
Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto leia as Informações sobre Segurança.
© Copyright Lenovo 2017 2022 iii

Antes de instalar este producto lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Safety inspection checklist
Use the information in this section to identify potentially unsafe conditions with your server. As each machine
was designed and built required safety items were installed to protect users and service technicians from
injury.
Notes:
1. The product is not suitable for use at visual display workplaces according to §2 of the Workplace
Regulations.
2. The set-up of the server is made in the server room only.
CAUTION:
This equipment must be installed or serviced by trained personnel, as defined by the NEC, IEC 62368-
1 & IEC 60950-1, the standard for Safety of Electronic Equipment within the Field of Audio/Video,
Information Technology and Communication Technology. enovo assumes you are qualified in the
servicing of equipment and trained in recognizing hazards energy levels in products. Access to the
equipment is by the use of a tool, lock and key, or other means of security, and is controlled by the
authority responsible for the location.
Important: Electrical grounding of the server is required for operator safety and correct system function.
Proper grounding of the electrical outlet can be verified by a certified electrician.
Use the following checklist to verify that there are no potentially unsafe conditions:
1. Make sure that the power is off and the power cord is disconnected.
2. Check the power cord.
• Make sure that the third-wire ground connector is in good condition. Use a meter to measure third-
wire ground continuity for 0.1 ohm or less between the external ground pin and the frame ground.
• Make sure that the power cord is the correct type.
To view the power cords that are available for the server:
a. Go to:
iv ThinkSystem SR850 Setup Guide

http://dcsc.lenovo.com/#/
b. Click Preconfigured Model or Configure to order.
c. Enter the machine type and model for your server to display the configurator page.
d. Click Power ➙ Power Cables to see all line cords.
• Make sure that the insulation is not frayed or worn.
3. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo
alterations.
4. Check inside the server for any obvious unsafe conditions such as metal filings contamination water or
other liquid or signs of fire or smoke damage.
5. Check for worn frayed or pinched cables.
6. Make sure that the power-supply cover fasteners (screws or rivets) have not been removed or tampered
with.
© Copyright Lenovo 2017 2022 v

vi ThinkSystem SR850 Setup Guide

Chapter 1. Introduction
The ThinkSystem SR850 server is a 2U rack server designed for high-volume network transaction
processing. This high-performance multi-core server is ideally suited for networking environments that
require superior processor performance input/output (I/O) flexibility and high manageability.
Figure 1. ThinkSystem SR850
The server comes with a limited warranty. For details about the warranty see: https://support.lenovo.com/us/
en/solutions/ht503310
For details about your specific warranty see: http://datacentersupport.lenovo.com/warrantylookup
In addition the system service label on the top cover of the server provides a QR code for mobile access to
service information. You can scan the QR code with a mobile device for quick access to additional
information including parts installation replacement and error codes.
Following illustration is the QR code: https://support.lenovo.com/p/servers/sr850
Figure 2. QR code
Server package contents
When you receive your server verify that the shipment contains everything that you expected to receive.
The server package includes the following items:
Note: Some of the items listed are available on select models only.
• Server
© Copyright Lenovo 2017 2022 1

• Rail installation kit (optional). Detailed instructions for installing the rail installation kit are provided in the
package with the rail installation kit.
• Cable management arm or cable management bar.
• Material box including items such as rack installation guide and accessory kit.
Features
Performance ease of use reliability and expansion capabilities were key considerations in the design of
your server. These design features make it possible for you to customize the system hardware to meet your
needs today and provide flexible expansion capabilities for the future.
Your server implements the following features and technologies:
• Features on Demand
If a Features on Demand feature is integrated in the server or in an optional device that is installed in the
server you can purchase an activation key to activate the feature. For information about Features on
Demand see:
https://fod.lenovo.com/lkms
• enovo XClarity Controller (XCC)
The Lenovo XClarity Controller is the common management controller for Lenovo ThinkSystem server
hardware. The Lenovo XClarity Controller consolidates multiple management functions in a single chip on
the server system board.
Some of the features that are unique to the Lenovo XClarity Controller are enhanced performance higher-
resolution remote video and expanded security options. For additional information about the Lenovo
XClarity Controller refer to the XCC documentation compatible with your server at:
https://pubs.lenovo.com/lxcc-overview/
Important: Lenovo XClarity Controller (XCC) supported version varies by product. All versions of Lenovo
XClarity Controller are referred to as Lenovo XClarity Controller and XCC in this document unless
specified otherwise. To see the XCC version supported by your server go to https://pubs.lenovo.com/lxcc-
overview/.
• UEFI-compliant server firmware
Lenovo ThinkSystem firmware is Unified Extensible Firmware Interface (UEFI) compliant. UEFI replaces
BIOS and defines a standard interface between the operating system platform firmware and external
devices.
Lenovo ThinkSystem servers are capable of booting UEFI-compliant operating systems BIOS-based
operating systems and BIOS-based adapters as well as UEFI-compliant adapters.
Note: The server does not support Disk Operating System (DOS).
• Active Memory
The Active Memory feature improves the reliability of memory through memory mirroring. Memory
mirroring mode replicates and stores data on two pairs of DIMMs within two channels simultaneously. If a
failure occurs the memory controller switches from the primary pair of memory DIMMs to the backup pair
of DIMMs.
• arge system-memory capacity
The server supports synchronous dynamic random-access memory (SDRAM) registered dual inline
memory modules (DIMMs) with error correcting code (ECC). For more information about the specific types
and maximum amount of memory see “Specifications” on page 3.
2ThinkSystem SR850 Setup Guide

• Integrated Trusted Platform Module (TPM)
This integrated security chip performs cryptographic functions and stores private and public secure keys.
It provides the hardware support for the Trusted Computing Group (TCG) specification. You can
download the software to support the TCG specification when the software is available.
Note: For customers in Chinese Mainland integrated TPM is not supported. However customers in
Chinese Mainland can install a Trusted Cryptographic Module (TCM) adapter or a Lenovo-qualified TPM
adapter (sometimes called a daughter card).
• arge data-storage capacity and hot-swap capability
The hot-swap server models support a maximum of fourteen 3.5-inch hot-swap Serial Attached SCSI
(SAS) hard disk drives or hot-swap Serial ATA (SATA) hard disk drives. The simple-swap server models
support a maximum of eight 3.5-inch simple-swap SATA hard disk drives.
With the hot-swap feature you can add remove or replace hard disk drives without turning off the server.
• ight path diagnostics
Light path diagnostics provides LEDs to help you diagnose problems. For more information about the light
path diagnostics see Light path diagnostics panel and Light path diagnostics LEDs.
• Mobile access to enovo Service Information website
The server provides a QR code on the system service label which is on the cover of the server that you
can scan using a QR code reader and scanner with a mobile device to get quick access to the Lenovo
Service Information website. The Lenovo Service Information website provides additional information for
parts installation replacement videos and error codes for server support.
• Active Energy Manager
Lenovo XClarity Energy Manager is a power and temperature management solution for data centers. You
can monitor and manage the power consumption and temperature of Converged NeXtScale System x
and ThinkServer servers and improve energy efficiency using Lenovo XClarity Energy Manager.
• Redundant networking connection
The Lenovo XClarity Controller provides failover capability to a redundant Ethernet connection with the
applicable application installed. If a problem occurs with the primary Ethernet connection all Ethernet
traffic that is associated with the primary connection is automatically switched to the optional redundant
Ethernet connection. If the applicable device drivers are installed this switching occurs without data loss
and without user intervention.
• Redundant cooling and optional power capabilities
The server supports a maximum of two 550-watt or 750-watt hot-swap power supplies and three dual-
motor non hot-swap fans which provide redundancy for a typical configuration. The redundant cooling by
the fans in the server enables continued operation if one of the fans fails. The server comes with one 550-
watt or 750-watt hot-swap power supply and three non hot-swap fans.
Note: You cannot mix 550-watt and 750-watt power supplies in the server.
• ThinkSystem RAID support
The ThinkSystem RAID adapter provides hardware redundant array of independent disks (RAID) support
to create configurations. The standard RAID adapter provides RAID levels 0 and 1. An optional RAID
adapter is available for purchase.
Specifications
The following information is a summary of the features and specifications of the server. Depending on the
model some features might not be available or some specifications might not apply.
Chapter 1.Introduction 3

Table 1. Speci ications, Type 7X18 and 7X19
Specification Description
Dimension 2U server
• Height: 86.5 mm (3.4 inches)
• Width:
– With rack handles: 482 mm (19.0 inches)
– Without rack handles: 444.6 mm (17.5 inches)
• Depth: 763.7 mm (30.1 inches)
Note: The depth is measured with rack handles installed but without the security bezel
installed.
Weight (depending on the
configuration)
27.0 kg (59.6 lb) in maximum.
Processor (depending on
model)
Supports multi-core Intel Xeon processors with integrated memory controller and Intel
Ultra Path Interconnect (UPI) architecture.
• Two processor sockets (expandable up to four) with minimal requirement of two
installed on the system board.
• Designed for LGA 3647 sockets
• Scalable up to 28 cores
• Supports Intel Extended Memory 32/64 Technology (EM32/64T)
Memory See “Memory module installation rules and order” on page 54 for detailed information
about memory configuration and setup.
• Minimum: 16 GB
• Maximum:
– RDIMM: 1.5 TB
– LRDIMM: 3 TB
– 3DS-RDIMM: 6 TB
– DC Persistent Memory (DCPMM): 12 TB in Memory Mode
• Memory module types:
– Double-data-rate 4 (TruDDR4) error correcting code (ECC) 2666/2933 MT/s
registered DIMM (RDIMM) or load reduced DIMM (LRDIMM)
– DC Persistent Memory (DCPMM)
• Capacity (depending on the model):
– 8 GB 16 GB 32 GB and 64 GB RDIMM
– 64 GB LRDIMM
– 64 GB and 128 GB 3DS-RDIMM
– 128 GB 256 GB and 512 GB DCPMM
Note: DCPMM can be mixed with DRAM DIMMs with capacity of more than 16
GB. See “DC Persistent Memory Module (DCPMM) setup” on page 76 for more
information.
• Slots: 24 two-way interleaved slots (expandable to 48)
Note: List of supported memory module is different for 1st generation (Skylake) and
2nd generation (Cascade Lake) Intel Xeon processors. Make sure to install compatible
memory modules to avoid system error. For a list of supported DIMMs see: https://
serverproven.lenovo.com/.
Drive expansion Sixteen 2.5-inch drive bays:
• Eight 2.5-inch hot-swap SATA/SAS drive bays (bay 0-3 8-11)
• Eight 2.5-inch hot-swap SATA/SAS/NVMe drive bays (bay 4-7 12-15)
4ThinkSystem SR850 Setup Guide

Table 1. Speci ications, Type 7X18 and 7X19 (continued)
Expansion slots Eleven expansion slots:
• Slot 1: PCI Express 3.0 x16 (supports PCIe switch card)
• Slot 2: PCI Express 3.0 x8 (supports RAID adapters for SATA/SAS drives)
• Slot 3 - 5: PCI Express 3.0 for PCIe riser-card with the following slots available
depending on the riser-card installed:
– x8/x8/x8 PCIe full-height riser assembly provides:
– Slot 3: PCI Express 3.0 x8
– Slot 4: PCI Express 3.0 x8
– Slot 5: PCI Express 3.0 x8
– x8/x8/x8ML2 PCIe full-height riser assembly provides:
– Slot 3: PCI Express 3.0 x8
– Slot 4: PCI Express 3.0 x8
– Slot 5: Customized slot for x8 ML2 adapter
– x8/x16ML2 PCIe full-height riser assembly provides:
– Slot 3: PCI Express 3.0 x8
– Slot 4: Not available
– Slot 5: Customized slot for x16 ML2 adapter
• Slot 6: Customized slot for dual M.2 backplane that supports M.2 drives in three
different physical sizes:
– 42 mm (2242)
– 60 mm (2260)
– 80 mm (2280)
• Slot 7: Customized slot for LOM adapter
• Slot 8: PCI Express 3.0 x8
• Slot 9: PCI Express 3.0 x8
• Slot 10: PCI Express 3.0 x8 (supports RAID adapters for SATA/SAS drives)
• Slot 11: PCI Express 3.0 x16 (supports PCIe switch card)
Integrated functions • Lenovo XClarity Controller (XCC) which provides service processor control and
monitoring functions video controller and remote keyboard video mouse and
remote drive capabilities.
• One system-management RJ-45 connector on the rear to connect to a systems-
management network. This connector is dedicated to the Lenovo XClarity Controller
functions and runs at 1 GB speed.
• Light-path diagnostics
• Four universal serial bus (USB) ports:
– Two on the front of the server
– One USB 2.0 with Lenovo XClarity Controller management
– One USB 2.0 or 3.0 (depending on the model)
– Two USB 3.0 on the rear of the server
• One serial port
Network This server supports 1GbE and 10 GbE LOM adapters with the following requirements:
• 1GbE LOM adapter: maximal bandwidth of network environment is 1GB.
• 10GbE LOM adapter: minimal bandwidth of network environment is 1GB.
RAID adapter(depending
on model)
The following options with support for RAID levels 0 1 and 10 are available for this
server:
• ThinkSystem RAID 530-8i PCIe 12 GB Adapter
• ThinkSystem RAID 730-8i 1 GB Cache PCIe 12 GB Adapter
• ThinkSystem RAID 730-8i 2 GB Cache PCIe 12 GB Adapter
• ThinkSystem RAID 930-8i 2 GB Flash PCIe 12 GB Adapter
• ThinkSystem RAID 930-16i 4 GB Flash PCIe 12 GB Adapter
• ThinkSystem RAID 930-8e 4 GB Flash PCIe 12 GB Adapter
Fans Six (60 mm x 38 mm) internal system fans (N+1 redundancy)
Chapter 1.Introduction 5

Table 1. Speci ications, Type 7X18 and 7X19 (continued)
Electrical input This server comes with three types of power supply units:
• 750-watt platinum power supply
– Input power 115V or 220V ac
• 1100-watt platinum power supply
– Input power 115V or 220V ac
• 1600-watt platinum power supply
– Input power 220V ac
Two power supplies provide N+1 redundancy support.
CAUTION:
1. 240 V dc input (input range: 180-300 V dc) is ON Y supported in Chinese
Mainland.
2. Power supplies with 240 V dc are not hot-swappable. To remove the power
cord, ensure you have turned off the server or disconnected the dc power
sources at the breaker panel.
3. In order for the ThinkSystem products to operate error free in both a DC or AC
electrical environment, a TN-S earthing system which complies to 60364-1 IEC
2005 standard has to be present or installed.
Minimal configuration for
debugging
• Two processors in processor socket 1 and 2
• Two DIMMs in slot 8 and 20
• One power supply
• One drive with RAID adapter and backplane (If OS is needed for debugging)
• Six system fans (fan 1 to fan 6)
Acoustical noise emissions • Sound power idling
– 5.2 bels minimum
– 5.8 bels typical
– 6.4 bels maximum
• Sound power operating
– 5.8 bels minimum
– 6.8 bels typical
– 7.0 bels maximum
Heat output Approximate heat output:
• Minimum configuration: 447 BTU 131 W (in BTU per hour and watts)
• Maximum configuration: 5265 BTU 1543 W (in BTU per hour and watts)
6ThinkSystem SR850 Setup Guide

Table 1. Speci ications, Type 7X18 and 7X19 (continued)
Environment ThinkSystem SR850 complies with ASHRAE Class A2 specifications. Depending on the
hardware configuration some models comply with ASHRAE Class A3 and Class A4
specifications. System performance may be impacted when operating temperature is
outside ASHRAE A2 specification.
• Air temperature:
– Operating
– ASHRAE Class A2: 10°C to 35°C (50°F to 95°F); the maximum ambient
temperature decreases by 1°C for every 300 m (984 ft) increase in altitude
above 900 m (2 953 ft).
– ASHRAE Class A3: 5°C to 40°C (41°F to 104°F); the maximum ambient
temperature decreases by 1°C for every 175 m (574 ft) increase in altitude
above 900 m (2 953 ft).
– ASHRAE Class A4: 5°C to 45°C (41°F to 113°F); the maximum ambient
temperature decreases by 1°C for every 125 m (410 ft) increase in altitude
above 900 m (2 953 ft).
– Server off: 5°C to 45°C (41°F to 113°F)
– Shipment/storage: -40°C to 60°C (-40°F to 140°F)
• Maximum altitude: 3 050 m (10 000 ft)
• Relative Humidity (non-condensing):
– Operating
– ASHRAE Class A2: 8% to 80%; maximum dew point: 21°C (70°F)
– ASHRAE Class A3: 8% to 85%; maximum dew point: 24°C (75°F)
– ASHRAE Class A4: 8% to 90%; maximum dew point: 24°C (75°F)
– Shipment/storage: 8% to 90%
• Particulate contamination
Attention: Airborne particulates and reactive gases acting alone or in combination
with other environmental factors such as humidity or temperature might pose a risk to
the server. For information about the limits for particulates and gases see
“Particulate contamination” in ThinkSystem SR850 Maintenance Manual.
Operating systems
Supported and certified operating systems:
• Microsoft Windows Server
• VMware ESXi
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
References:
• Complete list of available operating systems: https://lenovopress.lenovo.com/osig.
• OS deployment instructions: “Deploy the operating system” on page 126.
Note: To maintain component reliability system performance might vary at ambient temperature higher than
35°C while all the fans are functioning. With one fan failing system performance might vary at ambient
temperature higher than 27°C.
Particulate contamination
Attention: Airborne particulates (including metal flakes or particles) and reactive gases acting alone or in
combination with other environmental factors such as humidity or temperature might pose a risk to the
device that is described in this document.
Risks that are posed by the presence of excessive particulate levels or concentrations of harmful gases
include damage that might cause the device to malfunction or cease functioning altogether. This
specification sets forth limits for particulates and gases that are intended to avoid such damage. The limits
must not be viewed or used as definitive limits because numerous other factors such as temperature or
Chapter 1.Introduction 7

moisture content of the air can influence the impact of particulates or environmental corrosives and gaseous
contaminant transfer. In the absence of specific limits that are set forth in this document you must
implement practices that maintain particulate and gas levels that are consistent with the protection of human
health and safety. If Lenovo determines that the levels of particulates or gases in your environment have
caused damage to the device Lenovo may condition provision of repair or replacement of devices or parts
on implementation of appropriate remedial measures to mitigate such environmental contamination.
Implementation of such remedial measures is a customer responsibility.
Table 2. Limits or particulates and gases
Contaminant imits
Reactive gases Severity level G1 as per ANSI/ISA 71.04-19851:
• The copper reactivity level shall be less than 200 Angstroms per month (Å/month ≈ 0.0035 μg/
cm2-hour weight gain).2
• The silver reactivity level shall be less than 200 Angstroms per month (Å/month ≈ 0.0035 μg/
cm2-hour weight gain).3
• The reactive monitoring of gaseous corrosivity must be conducted approximately 5 cm (2 in.) in
front of the rack on the air inlet side at one-quarter and three-quarter frame height off the floor
or where the air velocity is much higher.
Airborne
particulates Data centers must meet the cleanliness level of ISO 14644-1 class 8.
For data centers without airside economizer the ISO 14644-1 class 8 cleanliness might be met by
choosing one of the following filtration methods:
• The room air might be continuously filtered with MERV 8 filters.
• Air entering a data center might be filtered with MERV 11 or preferably MERV 13 filters.
For data centers with airside economizers the choice of filters to achieve ISO class 8 cleanliness
depends on the specific conditions present at that data center.
• The deliquescent relative humidity of the particulate contamination should be more than 60%
RH.4
• Data centers must be free of zinc whiskers.5
1 ANSI/ISA-71.04-1985. Environmental conditions or process measurement and control systems: Airborne
contaminants. Instrument Society of America Research Triangle Park North Carolina U.S.A.
2 The derivation of the equivalence between the rate of copper corrosion growth in the thickness of the corrosion
product in Å/month and the rate of weight gain assumes that Cu2S and Cu2O grow in equal proportions.
3 The derivation of the equivalence between the rate of silver corrosion growth in the thickness of the corrosion
product in Å/month and the rate of weight gain assumes that Ag2S is the only corrosion product.
4 The deliquescent relative humidity of particulate contamination is the relative humidity at which the dust absorbs
enough water to become wet and promote ionic conduction.
5 Surface debris is randomly collected from 10 areas of the data center on a 1.5 cm diameter disk of sticky
electrically conductive tape on a metal stub. If examination of the sticky tape in a scanning electron microscope
reveals no zinc whiskers the data center is considered free of zinc whiskers.
Management options
The XClarity portfolio and other system management options described in this section are available to help
you manage the servers more conveniently and efficiently.
8ThinkSystem SR850 Setup Guide

Overview
Options Description
Lenovo XClarity Controller
Baseboard management controller. (BMC)
Consolidates the service processor functionality Super I/O video controller and
remote presence capabilities into a single chip on the server system board.
Interface
• CLI application
• Web GUI interface
• Mobile application
• REST API
Usage and downloads
https://pubs.lenovo.com/lxcc-overview/
Lenovo XClarity Administrator
Centralized interface for multi-server management.
Interface
• Web GUI interface
• Mobile application
• REST API
Usage and downloads
http://sysmgt.lenovofiles.com/help/topic/com.lenovo.lxca.doc/aug_product_page.html
Lenovo XClarity Essentials
toolset
Portable and light toolset for server configuration data collection and firmware
updates. Suitable both for single-server or multi-server management contexts.
Interface
• OneC I: CLI application
• Bootable Media Creator: CLI application GUI application
• UpdateXpress: GUI application
Usage and downloads
https://pubs.lenovo.com/lxce-overview/
Chapter 1.Introduction 9

Options Description
Lenovo XClarity Provisioning
Manager
UEFI-based embedded GUI tool on a single server that can simplify management
tasks.
Interface
• Web interface (BMC remote access)
• GUI application
Usage and downloads
https://pubs.lenovo.com/lxpm-overview/
Important:
Lenovo XClarity Provisioning Manager (LXPM) supported version varies by product.
All versions of Lenovo XClarity Provisioning Manager are referred to as Lenovo
XClarity Provisioning Manager and LXPM in this document unless specified
otherwise. To see the LXPM version supported by your server go to https://
pubs.lenovo.com/lxpm-overview/.
Lenovo XClarity Integrator
Series of applications that integrate the management and monitoring functionalities of
the Lenovo physical servers with the software used in a certain deployment
infrastructure such as VMware vCenter Microsoft Admin Center or Microsoft System
Center while delivering additional workload resiliency.
Interface
GUI application
Usage and downloads
https://pubs.lenovo.com/lxci-overview/
Lenovo XClarity Energy
Manager
Application that can manage and monitor server power and temperature.
Interface
• Web GUI Interface
Usage and downloads
https://datacentersupport.lenovo.com/solutions/lnvo-lxem
Lenovo Capacity Planner
Application that supports power consumption planning for a server or rack.
Interface
• Web GUI Interface
Usage and downloads
https://datacentersupport.lenovo.com/solutions/lnvo-lcp
10 ThinkSystem SR850 Setup Guide

Functions
Options
Functions
Multi-
system
mgmt
OS
deploy-
ment
System
configu-
ration
Firm-
ware
up-
dates1
Event-
s/alert
moni-
toring
Inven-
tory/
logs
Pow-
er
mgmt
Power
planning
Lenovo XClarity Controller √ √2√ √4
Lenovo XClarity
Administrator √ √ √ √2√ √4
Lenovo
XClarity
Essen-
tials
toolset
OneCLI √ √ √2√ √4
Bootable Media
Creator √ √2√4
UpdateXpress √ √2
Lenovo XClarity Provisioning
Manager √ √ √3√5
Lenovo XClarity Integrator √ √6√ √ √ √ √7
Lenovo XClarity Energy
Manager √ √ √
Lenovo Capacity Planner √8
Notes:
1. Most options can be updated through the Lenovo tools. Some options such as GPU firmware or Omni-
Path firmware require the use of supplier tools.
2. The server UEFI settings for option ROM must be set to Auto or UEFI to update firmware using Lenovo
XClarity Administrator Lenovo XClarity Essentials or Lenovo XClarity Controller.
3. Firmware updates are limited to Lenovo XClarity Provisioning Manager Lenovo XClarity Controller and
UEFI updates only. Firmware updates for optional devices such as adapters are not supported.
4. The server UEFI settings for option ROM must be set to Auto or UEFI for detailed adapter card
information such as model name and firmware levels to be displayed in Lenovo XClarity Administrator
Lenovo XClarity Controller or Lenovo XClarity Essentials.
5. Limited inventory.
6. The Lenovo XClarity Integrator deployment check for System Center Configuration Manager (SCCM)
supports Windows operating system deployment.
7. Power management function is supported only by Lenovo XClarity Integrator for VMware vCenter.
8. It is highly recommended that you check the power summary data for your server using Lenovo
Capacity Planner before purchasing any new parts.
Chapter 1.Introduction 11

12 ThinkSystem SR850 Setup Guide
