3013-1AU Atom 230 1.60 512KB 1GB 1TB2(1TB, 0, 0, 0) None GMA 950 eSATA Gigabit Black Windows Home Server Sep 09
3013-1BU Atom 230 1.60 512KB 1GB 2TB (1TB, 1TB, 0, 0) None GMA 950 eSATA Gigabit Black Windows Home Server Sep 09
Processor
Implementation
Memory
Graphics
SATA disks
Disk bays
SATA controller
S ATA DV D ±RW
SATA cables
eSATA port
Diskette drive
Media reader
Chipset
Front ports
Rear ports
Rear audio ports
Audio
External speakers
Internal speaker
Ethernet
Modem
Security chip
Keyboard
Mouse
Power supply
Security
Intel®Atom™Processor 230 with single-core,
Hyper-Threading technology, Intel 64 Technology,
Execute Disable Bit, 533MHz system bus, and 512KB L2 cache
Processor in Micro-FCBGA package in BGA437 socket
1GB std, 2GB max8,
PC2-6400 800MHz DDR2,
non-parity, one 240-pin DIMM socket
Non-Italics: standard memory in socket; no sockets available
Intel Graphics Media Accelerator 950 (GMA 950),
integrated graphics in 945GC, uses main memory,
no monitor ports, remote access via network
1TB or 2TB std, up to 8TB capacity, SATA 3Gb/s, 7200 rpm,
Four hard disk bays, tool-less, support hot-swap*
* Need to first remove disk in software via Windows Home Server Console
Serial ATA, SATA 3.0Gb/s, integrated in ICH7
None
Four SATA cables (each 1-drop to device), Four SATA connectors
One external SATA (eSATA) port on rear
None
None
Intel 945GC Express Chipset, I/O Controller Hub 7 [ICH7] (SATA 3.0Gb/s,
ethernet MAC, PCI 2.3, USB, LPC bus)
One USB 2.0 with USB copy button (Easy USB file transfer function)
Four USB 2.0, one eSATA, ethernet (RJ-45)
None
None
None
None
Gigabit ethernet on planar, Marvell®88E8071
None
None
None
None
200 watts, universal, auto switch
Security slot (in rear for optional Kensington®Microsaver®cable)
IdeaCentre™D400 (3013)
GHz
Type-model Processor Memory8SATA disks
SATA
optical Graphics
Avail
date
Personal Systems Reference (PSREF)
Small Form Factor
L2
cache
See footnotes for important warranty information
US models announced September 1, 2009
© Lenovo
(HS1-1) September 2009
eS ATA
Limited Warranty1
➫ 1-year parts and labor
➫ Customer Replaceable Unit (CRU)
parts only (with limited onsite service
for selected parts3, 8 am - 5 pm,
Mon - Fri coverage excluding holidays,
often next business day response time)
➫Service upgrade options
(in eligible locations):9
• 3-year Lenovo Onsite Repair
9x5 Next Business Day (43R8882)
➫ 24x714 toll-free support for warranty
issues during the warranty period1
via 877-453-6686
•Black color bezel
• 7.9" W X 8.2" D X 8.3" H
• 200mm W X 208.6mm D X 212mm H
•14.3 lb (6.5 kg) for maximum configuration
Bay ①3.5", 1" high, external, standard disk
Bay ②3.5", 1" high, external, optional disk*
Bay ③3.5", 1" high, external, optional disk*
Bay ④ 3.5", 1" high, external, optional disk*
* Bay used in some models
Slot 1: half-length,low-profile, PCI Express x4
Ethernet
• A Digital home storage, smaller than a 9 inch cube and built to store/share music,
movies, files and more.
• Easy plug-and-play set up and convenient remote access.
• Provides four 3.5 inch bays for hard disks, up to 8TB capacity.
• Easy USB file transfer, pressing one button to copy USB drive contents to the internal hard drives.
`Preload
Available at these retailers
•lenovo.com
Preloaded operating system20
- Genuine Windows®Home Server
Preloaded applications5
• LightsOut
• iTunes Server
• LED brightness control
• One Key USB backup
• IP address configuration
• System Information
Client applications (Needs customer
installation, Client software CD included)
• Windows Home Server Connector Software
• Lenovo Home Server EasyAccess utilitty
Color
Data protection features
•Back up all your home digital devices
automatically
•Duplicate important data automatically,
copy designated data to two internal
hard drives for added safety (some
models)
•Inbuilt flash drive allows easy recovery
and prevents data lost in the event of a
system problem
