Lenovo ThinkServer TS450 Owner's manual

ThinkServerTS450
UserGuideandHardwareMaintenance
Manual
MachineTypes:70LY,70M0,70M1,and70M2

Welcome
Beoreusingyourserverandthisdocument,besuretoreadtheReadMeFirstthatcomeswithyourserver.
Lenovomakesconstantimprovementonthedocumentationoyourserver.Togetallthelatestdocuments,
goto:
http://www.lenovo.com/UserManuals
Note:Yourservermightlookslightlydierentromillustrationsinthisdocument.Toshowthemainparts
clearly,someotheillustrationsdonotshowallcomponents.
FourthEdition(August2016)
CopyrightLenovo2015,2016.
LIMITEDANDRESTRICTEDRIGHTSNOTICE:IdataorsotwareisdeliveredpursuanttoaGeneralServices
Administration“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetorthinContractNo.
GS-35F-05925.

Contents
Readthisfirst:safetyinformation..iii
Productsthatarenotassessed.........x
Saetyinspectionguide............x
Groundingrequirements............xi
Chapter1.Generalinformation.....1
Introduction.................1
Serverdocumentation.............2
Chapter2.Serversetuproadmap...5
Serversetupprocedure............5
Turningontheserver.............5
Turningotheserver.............5
Chapter3.Productoverview......7
Inthebox.................7
Featuresandspecificationsoyourserver.....7
Operatingenvironment...........10
Sotwareprograms.............10
ThinkServerEasyStartup.........10
ThinkServerEasyUpdateFirmwareUpdater.10
LenovoThinkServerPowerPlanner.....11
LenovoThinkServerDiagnostics......11
LenovoToolsCenterSuiteCLI.......11
Componentlocations............11
Machinetype,model,andserialnumber
label.................11
Frontviewotheserver.........13
Frontpanel..............14
Rearviewotheserver.........15
Serverlocks..............17
Servercomponents...........19
Hot-swapdriveactivityandstatusLEDs...21
Powerconversionboard.........22
Powerdistributionboard.........23
Hot-swappowersupplystatusLEDs....24
RAIDcard...............24
LenovoThinkServerSAS12GExpanderPCIe
Card.................26
Backplane..............27
Systemboardcomponents........30
Chapter4.Configuringtheserver..35
UsingtheSetupUtilityprogram........35
StartingtheSetupUtilityprogram.....35
SetupUtilityprograminterace......35
Usingpasswords............38
ConfiguringtheTPMunction.......40
Selectingastartupdevice........40
ExitingtheSetupUtilityprogram......40
UpdatingtheBIOS...........40
ConfiguringtheEthernetcontrollers....41
UsingtheThinkServerEasyStartupprogram.41
ConfiguringRAID..............44
AboutRAID..............44
RAIDoryourserver...........45
ConfiguringonboardSATAsotwareRAID..46
ConfiguringadvancedSATAorSAShardware
RAID.................48
Chapter5.Replacinghardware....51
PurchasingThinkServeroptions........51
Gettingamiliarwithimportantguidelines....51
Precautions..............51
Handlingstatic-sensitivedevices.....52
Systemreliabilityguidelines........52
Workinginsidetheserverwiththepoweron.53
Preparingyourserverinadvanceandremovingthe
servercover................53
Removingandinstallinghardware.......54
Frontbezel..............55
Memorymodule............56
PCIecard...............58
Opticaldrive..............60
Non-hot-swapdrive...........66
Tapedrive...............69
Solid-statedrive(2.5-inch)........72
Hot-swapdrive.............75
Hot-swappowersupply.........78
Powerconversionboard.........81
Backplane..............83
Non-hot-swappowersupply.......88
Intrusionswitch............90
Frontpanelboardassembly........91
Frontsysteman............93
Rearsysteman............95
Heatsinkandanassembly........97
Securedigitalmodule..........99
ThinkServerRAIDSuperCapacitorModule..102
ThunderboltMemoryModule.......105
LenovoThinkServerRAID520iupgrade
key.................106
CPU.................108
Coin-cellbattery............110
©CopyrightLenovo2015,2016i

Powerdistributionboard.........112
Forservicetechnicianonly:replacingthe
systemboard.............115
Completingthepartsreplacement.......118
Chapter6.Troubleshootingand
diagnostics.............121
Troubleshootingprocedure..........121
ViewingthestatusanddiagnosticLEDs.....121
Basictroubleshootingtables.........121
ThinkServerEasyStartupprogram
problems...............122
Opticaldriveproblems..........122
Storagedriveproblems.........123
Memorymoduleproblems........124
USBdeviceproblems..........124
Chapter7.Gettinginformation,help,
andservice.............125
Inormationresources............125
Usingthedocumentation.........125
ThinkServerWebsite..........125
LenovoSupportWebsite.........125
Helpandservice..............125
Beoreyoucall.............125
Callingorservice............126
Usingotherservices..........126
Purchasingadditionalservices......127
AppendixA.Regulatory
information.............129
Exportclassificationnotice..........129
Electronicemissionnotices..........129
FederalCommunicationsCommission(FCC)
Statement...............129
JapanVCCIClassAcompliancestatement..131
Japanesestatementoracpowerconsumption
orJEITAharmonicsguideline.......131
Japanesestatementocomplianceor
productslessthanorequalto20Aperphase
orJEITAharmonicsguideline.......132
Eurasiancompliancemark..........132
AppendixB.WEEEandrecycling
information.............133
ImportantWEEEinormation.........133
RecyclinginormationorBrazil........134
RecyclinginormationorJapan........134
BatteryrecyclinginormationorTaiwan.....134
BatteryrecyclinginormationortheEuropean
Union..................135
BatteryrecyclinginormationortheUnitedStates
andCanada................136
Requirementorbatteriescontaining
perchlorate................136
AppendixC.RestrictionofHazardous
Substances(RoHS)Directive....137
EuropeanUnionRoHS...........137
TurkishRoHS...............137
UkraineRoHS...............137
IndiaRoHS................137
ChinaRoHS................138
TaiwanBSMIRoHSdeclaration........139
AppendixD.Additional
statements.............141
Importantnotes..............141
Particulatecontamination..........141
GermanOrdinanceorWorkglossstatement...142
AppendixE.Notices.........143
Trademarks................144
AppendixF .Abbreviationsand
acronyms..............145
Index.................147
iiThinkServerTS450UserGuideandHardwareMaintenanceManual

Readthisfirst:safetyinformation
Note:Beoreusingtheproduct,besuretoreadandunderstandthemultilingualSafetyInformationonthe
LenovoWebsiteat:
https://support.lenovo.com/documents/LNVO-DOCS
ﺓ ء ﺍﺮ ﻗ ﻦﻣﺪ ﻛﺄﺗ ،ﺞ ﺘﻨﻤﻟﺍ ﻡ ﺍﺪ ﺨ ﺘﺳ ﺍ ﻞﺒﻗSafetyInforma ! on )ﺔ ﻣ ﻼﺴ ﻟﺍ ﺕﺎﻣ ﻮﻠﻌ ﻣ(ﻊ ﻗ ﻮ ﻣ ﻲﻓ ﺎﻬ ﻤ ﻬ ﻓﻭ ﺕ ﺎﻐﻠﻟﺍ ﺓ ﺩ ﺪ ﻌ ﺘﻤ ﻟﺍ Lenovo
ﺐﻳﻮ ﻟﺍ ﻰﻠﻋ.
Antesdeusaroproduto,certifique-sedelereentenderasSafetyInformation(Inormaçõessobresegurança)
multilínguesnositedaLenovo.
Предидаизползватепродукта,прочететеиразберетемногоезичнатаSafetyInformation(Информация
забезопасност)науебсайтанаLenovo.
PrijekorištenjanašegproizvodasvakakosrazumijevanjempročitajtevišejezičnidokumentSafetyInformation
(Inormacijeosigurnosti)naweb-mjestutvrtkeLenovo.
PředpoužitímtohotoproduktusinezapomeňtepřečístvícejazyčnýdokumentSafetyInformation
(Bezpečnostníinormace)nawebuspolečnostiLenovo.
Førdubrugerproduktet,skaldusørgeoratlæseogorståSafetyInformation(sikkerhedsorskriter),
derfindespåfleresprog,påLenovoswebsted.
LuemonikielinenSafetyInformation(Turvaohjeet)-julkaisuLenovonverkkosivustostaennentuotteenkäyttöä.
Avantd'utiliserceproduit,prenezconnaissancedesSafetyInformation(Inormationsrelativesàlasécurité)
multilinguessurlesiteWebLenovo.
Πρινχρησιμοποιήσετετοπροϊόν,φροντίστεναδιαβάσετεκαινακατανοήσετετιςSafetyInformation
(Πληροφορίεςασφαλείας)στοδικτυακότόποτηςLenovo.
VorVerwendungdesProduktssolltenSiediemehrsprachigenSafetyInformation(Sicherheitsinormationen)
auderLenovoWebsitelesenundverstehen.
רומב ש ו מ יש ה ינפל, ך מ ס מ ה ת א ןי ב ה ל ו א ור ק ל וד יפ ק הSafetyInforma ! on ) תחיטב א ש נ ב ע ד ימ ( ת פ ש ב ע יפ מ ה
ל ש ט נר ט ניא ה ר ת א ב ת ב רLenovo.
Atermékhasználataelőttolvassaát,ésismerjemegaLenovowebhelyéntöbbnyelveniselérhetőSafety
Information(Biztonságitájékoztató)címűdokumentumot.
Primadiutilizzareilprodotto,accertarsidileggereecomprendereladocumentazionemultilinguaSafety
Information(Inormazionisullasicurezza)sulsitoWebLenovo.
製品をご使用になる前に、LenovoWebサイトに掲載されているマルチリンガルのSafetyInformation(安全
上の注意)を読んで理解してください。
제품을사용하기전에Lenovo웹사이트의다국어SafetyInformation(안전정보)를주의깊게읽어
보십시오.
ZorgdatualleSafetyInformation(veiligheidsvoorschriten)opdewebsitevanLenovohebtgelezenen
begrepenvoordatuhetproductgebruikt.
©CopyrightLenovo2015,2016iii

PrzedskorzystaniemzproduktunależyzapoznaćsięzwielojęzycznymdokumentemSafetyInformation
(Inormacjedotyczącebezpieczeństwa),dostępnymwserwisieinternetowymLenovo.
Antesdeutilizaroproduto,certifique-sedequelêecompreendeadocumentaçãomultilingueSafety
Information(InormaçõessobreSegurança)nosítiodaWebdaLenovo.
Înaintedeautilizaprodusul,citiţişiînţelegeţiSafetyInformation(inormaţiiledesiguranţă)înmaimulte
limbidepesite-ulwebLenovo.
Førdubrukerproduktet,måduleseogorstådenflerspråkligeSafetyInformation(sikkerhetsinormasjonen)
pånettstedettilLenovo.
ПередиспользованиемпродуктаобязательноознакомьтесьсразделомSafetyInformation
(Информацияпотехникебезопасности),представленнымнанесколькихязыкахнавеб-сайтеLenovo.
在使用产品之前，请务必先阅读和了解LenovoWeb站点上的多语言SafetyInformation《安全信息》。
Prekorišćenjaproizvoda,obaveznopažljivoisarazumevanjempročitajtevišejezičneSafetyInformation
(Bezbednosneinormacije)naveblokacijikompanijeLenovo.
Skôrnežproduktzačnetepoužívať,prečítajtesiviacjazyčnéSafetyInformation(Bezpečnostnéinormácie)na
webovejlokalitespoločnostiLenovo.
Preduporaboizdelkaposkrbite,dabosteprebraliinrazumelirazdelekSafetyInformation(Varnostne
inormacije),kijenaspletnemmestuLenovonavoljovvečjezikih.
Antesdeusarelproducto,asegúresedeleeryentenderlasecciónSafetyInformation(Inormaciónde
seguridad)multilingüedelsitiowebdeLenovo.
InnanduanvänderdenhärproduktenärdetviktigtattduharlästochörståttdenflerspråkigaSafety
Information(säkerhetsinormationen)påLenovoswebbplats.
使用本產品之前，請務必先閱讀及瞭解Lenovo網站上多國語言版本的SafetyInformation（安全資訊）。
Ürünükullanmadanönce,LenovowebsitesindekiSafetyInformation(GüvenlikBilgileri)belgesini(birdençok
dildeyayınlanmaktadır)mutlakaokuyun.
Першніжвикористовуватипродукт,обов'язковопрочитайтеSafetyInformation(інструкціїзтехніки
безпеки),доступнірізнимимоваминавеб-сайтіLenovo.
ก
่
ีน์ฑณัภติลผ้ชในอ
้
โปรด อ
่
กจใา้ขเมาวคาํทะลแนา
ั
บ
SafetyInforma ! on (ยัภดอลปมาวคลูมอ้ข) ห ล า ย ภ า ษ า
์ตซไบ็วเนบ
Lenovo
Important:Ensurethatyoureadandunderstandallcautionanddangerstatementsinthisdocumentbeore
youperormtheprocedures.Readandunderstandanyadditionalsaetyinormationthatisincludedwiththe
serveroroptionaldevicebeoreyouinstall,remove,orreplacethedevice.
ivThinkServerTS450UserGuideandHardwareMaintenanceManual

Statement1
DANGER
Electricalcurrentfrompower,telephone,andcommunicationcablesishazardous.
Toavoidashockhazard:
•Donotconnectordisconnectanycablesorperforminstallation,maintenance,orreconfigurationofthis
productduringanelectricalstorm.
•Connectallpowercordstoaproperlywiredandgroundedelectricaloutlet.
•Ensurethatallpowercordconnectorsaresecurelyandcompletelypluggedintoreceptacles.
•Connecttoproperlywiredoutletsanyequipmentthatwillbeattachedtothisproduct.
•Whenpossible,useonehandonlytoconnectordisconnectsignalcables.
•Neverturnonanyequipmentwhenthereisevidenceoffire,water,orstructuraldamage.
•Disconnecttheattachedpowercords,telecommunicationssystems,networks,andmodemsbeforeyou
openthedevicecovers,unlessinstructedotherwiseintheinstallationandconfigurationprocedures.
•Connectanddisconnectcablesasdescribedinthefollowingtablewheninstalling,moving,oropening
coversonthisproductorattacheddevices.
Toconnect:Todisconnect:
1.TurneverythingOFF.
2.First,attachallcablestodevices.
3.Attachsignalcablestoconnectors.
4.Attachpowercordstooutlets.
5.TurndevicesON.
1.TurneverythingOFF.
2.First,removepowercordsromoutlets.
3.Removesignalcablesromconnectors.
4.Removeallcablesromdevices.
Statement2
DANGER
Dangerofexplosionifbatteryisincorrectlyreplaced.
Whenreplacingthelithiumcoincellbattery,useonlythesameoranequivalenttypethatis
recommendedbythemanufacturer.Thebatterycontainslithiumandcanexplodeifnotproperly
used,handled,ordisposedof.
Donot:
•Throworimmerseintowater
•Heattomorethan100°C(212°F)
•Repairordisassemble
Disposeofthebatteryasrequiredbylocalordinancesorregulations.
©CopyrightLenovo2015,2016v

Statement3
CAUTION:
Whenlaserproducts(suchasCD-ROMs,DVDdrives,fiberopticdevices,ortransmitters)are
installed,notethefollowing:
•Donotremovethecovers.Removingthecoversofthelaserproductcouldresultinexposureto
hazardouslaserradiation.Therearenoserviceablepartsinsidethedevice.
•Useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespecifiedherein
mightresultinhazardousradiationexposure.
DANGER
SomelaserproductscontainanembeddedClass3AorClass3Blaserdiode.Notethefollowing:
Laserradiationwhenopen.Donotstareintothebeam,donotviewdirectlywithoptical
instruments,andavoiddirectexposuretothebeam.
Statement4
≥18kg(39.7lb)≥32kg(70.5lb)≥55kg(121.2lb)
<32kg(70.5lb)<55kg(121.2lb)<100kg(220.5lb)
CAUTION:
Usesafepracticeswhenlifting.
Statement5
CAUTION:
Thepowercontrolbuttononthedeviceandthepowerswitchonthepowersupplydonotturnoff
theelectricalcurrentsuppliedtothedevice.Thedevicealsomighthavemorethanonepower
cord.Toremoveallelectricalcurrentfromthedevice,ensurethatallpowercordsaredisconnected
fromthepowersource.
viThinkServerTS450UserGuideandHardwareMaintenanceManual

Statement6
CAUTION:
Ifyouinstallastrain-reliefbracketoptionovertheendofthepowercordthatisconnectedtothe
device,youmustconnecttheotherendofthepowercordtoapowersourcethatiseasilyaccessible
incaseitneedstobedisconnected.
Statement7
CAUTION:
Ifthedevicehasdoors,ensurethatyouremoveorsecurethedoorsbeforemovingorliftingthe
devicetoprotectagainstpersonalinjury.Thedoorswillnotsupporttheweightofthedevice.
Statement8
CAUTION:
Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.
Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabel
attached.Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwith
oneoftheseparts,contactaservicetechnician.
Statement9
CAUTION:
Disconnectthehot-swapfancablesbeforeremovingthefanfromthedevicetoprotectagainst
personalinjury.
Statement10
CAUTION:
Thefollowinglabelindicatesasharp-edgehazard.
©CopyrightLenovo2015,2016vii

Statement11
CAUTION:
Thefollowinglabelindicatesapotentialheathazard.
Statement12
DANGER
Overloadingabranchcircuitisapotentialfirehazardandashockhazardundercertainconditions.T o
avoidthesehazards,ensurethatyoursystemelectricalrequirementsdonotexceedbranchcurrentratings
attheinstallationsite.
Statement13
CAUTION:
Ensurethattherackissecuredproperlytoavoidtippingwhentheserverunitisextendedontherails.
Statement14
CAUTION:
SomeaccessoryoroptionboardoutputsexceedClass2orlimitedpowersourcelimits.Y ou
mustinstalltheappropriateinterconnectingcablinginaccordancewithyourlocalelectricalcode
requirements.
Statement15
CAUTION:
Thepower-controlbuttononthedevicemayputthedeviceinstandbymodeinsteadofturningoff
thedevice.Inaddition,thedevicemighthavemultipleconnectionstodcpower.Toremoveall
electricalcurrentfromthedevice,ensurethatallconnectionstodcpoweraredisconnectedat
thedcpowerinputterminals.
viiiThinkServerTS450UserGuideandHardwareMaintenanceManual

Statement16
CAUTION:
Toreducetheriskofelectricshockorenergyhazards:
•Thisequipmentmustbeinstalledbytrainedservicepersonnelinarestricted-accesslocation,as
definedbyyourlocalelectricalcodeandthelatesteditionofIEC60950.
•Thebranchcircuitovercurrentprotectionmustberatedinaccordancewithlocalelectricalcode
requirements.
•Use1.3mm2or16AmericanWireGauge(AWG)copperconductoronly,notexceeding3meters
inlength.
•Torquethewiring-terminalscrewsto1.4newton-metersor12inch-pounds.
•Provideareadilyavailable,approvedandrateddisconnectdeviceinthefieldwiring.
Statement17
CAUTION:
ThisproductcontainsaClass1Mlaser.Donotviewdirectlywithopticalinstruments.
Statement18
CAUTION:
Donotplaceanyobjectontopofrack-mountedproducts.
Statement19
CAUTION:
Hazardousmovingparts.Keepfingersandotherbodypartsaway.
©CopyrightLenovo2015,2016ix

Statement20
CAUTION:
Alithiumionbatteryisprovided.T oavoidpossibleexplosion,donotburnthebattery.Replacethe
batteryonlywiththeLenovo-approvedpart.Recycleordiscardthebatteryasinstructedbylocal
regulations.
Productsthatarenotassessed
Typicalproductsthatarenotassessedincludebutnotlimitedtotheollowing:
•ServerandIT-rackcomponents(orexample,uninterruptiblepowersuppliesandcurrentdistribution
systems)
•DevicesinITrooms(orexample,bulkstorageunitsandnetworkproducts)
•Industriallow-voltageswitchgear
Safetyinspectionguide
Thepurposeothisinspectionguideistoassistyouinidentiyingpotentiallyunsaeconditions.Aseach
machinewasdesignedandbuilt,requiredsaetyitemswereinstalledtoprotectusersandservicetechnicians
rominjury.Thisguideaddressesonlythoseitems.Youshouldusegoodjudgmenttoidentiypotentialsaety
hazardsduetoattachmentonon-ThinkServereaturesoroptionsnotcoveredbythisinspectionguide.
Ianyunsaeconditionsarepresent,youmustdeterminehowserioustheapparenthazardcouldbeand
whetheryoucancontinuewithoutfirstcorrectingtheproblem.
Considertheseconditionsandthesaetyhazardstheypresent:
•Electricalhazards,especiallyprimarypower(primaryvoltageontheramecancauseseriousoratal
electricalshock)
•Explosivehazards,suchasadamagedCathodeRayTube(CRT)monitororabulgingcapacitor
•Mechanicalhazards,suchaslooseormissinghardware
Todeterminewhetherthereareanypotentiallyunsaeconditions,usetheollowingchecklistatthebeginning
oeveryservicetask.Beginthecheckswiththepowero,andthepowercordsdisconnected.
Checklist:
1.Checkexteriorcoversordamage(loose,broken,orsharpedges).
2.Powerotheserver.Disconnectthepowercords.
3.Checkthepowercordor:
a.Athird-wiregroundconnectoringoodcondition.Useametertomeasurethird-wireground
continuityor0.1ohmorlessbetweentheexternalgroundpinandtherameground.
b.Thepowercordshouldbetheauthorizedtypespecifiedoryourserver.Goto:
http://www.lenovo.com/serviceparts-lookup
c.Insulationmustnotberayedorworn.
4.Checkorcrackedorbulgingbatteries.
5.Removethecover.
6.Checkoranyobviousnon-ThinkServeralterations.Usegoodjudgmentastothesaetyoany
non-ThinkServeralterations.
xThinkServerTS450UserGuideandHardwareMaintenanceManual

7.Checkinsidetheunitoranyobviousunsaeconditions,suchasmetalfilings,contamination,wateror
otherliquids,orsignsofireorsmokedamage.
8.Checkorworn,rayed,orpinchedcables.
9.Checkthatthepower-supplycoverasteners(screwsorrivets)havenotbeenremovedortamperedwith.
Groundingrequirements
Electricalgroundingotheserverisrequiredoroperatorsaetyandcorrectsystemunction.Proper
groundingotheelectricaloutletcanbeverifiedbyacertifiedelectrician.
©CopyrightLenovo2015,2016xi

xiiThinkServerTS450UserGuideandHardwareMaintenanceManual

Chapter1.Generalinformation
Thischaptercontainstheollowingitems:
•“Introduction”onpage1
•“Serverdocumentation”onpage2
Introduction
Theollowingtablelistsimportantinormationaboutyourserverandwheretoobtaintheinormation.
InformationWheretoobtain
LenovoLimitedWarranty
(LLW)TheLLWcontainsthewarrantytermsthatapplytotheproductyoupurchasedrom
Lenovo®.TheLLWisavailableat:
http://www.lenovo.com/warranty/llw_02
IyoucannotobtaintheLLWromtheLenovoWebsite,contactyourlocalLenovo
oficeorresellertoobtainaprintedversionotheLLW,reeocharge.
WorldwideLenovoSupport
telephonelist
Telephonenumbersaresubjecttochangewithoutnotice.Themostup-to-date
telephonelistorLenovoSupportisalwaysavailableat:
http://www.lenovo.com/support/phone
Ithetelephonenumberoryourcountryorregionisnotlisted,contactyourLenovo
resellerorLenovomarketingrepresentative.
Mostup-to-dateinformation
abouttheserverhttp://www.lenovo.com/thinkserver
Latesttechnicalinformationhttp://www.lenovo.com/support
Instructionsonhowto
registeryourserverwith
Lenovo
Followtheinstructionsat:
http://www.lenovo.com/register
Whenyouregisteryourserver,inormationisenteredintoadatabase,whichenables
Lenovotocontactyouincaseoarecallorothersevereproblem.Ateryouregister
yourserverwithLenovo,youwillreceivequickerservicewhenyoucallLenovo
orhelp.Inaddition,somelocationsoerextendedprivilegesandservicesto
registeredusers.
ProductinformationlabelRecordinormationaboutyourserverintheollowingtable.Youwillneedthe
inormationiyoueverneedtohaveyourserverserviced.Theproductinormation
labelisattachedonthechassis.See“Machinetype,model,andserialnumber
label”onpage11.
Productname______________________________________________
Machinetypeandmodel(MT-M)______________________________________________
Serialnumber(S/N)______________________________________________
Dateofpurchase______________________________________________
©CopyrightLenovo2015,20161

Serverdocumentation
Thistopicprovidesageneraldescriptionoeachdocumentoryourserverandinstructionsonhow
toobtainallthedocuments.
Printeddocuments
Yourserverpackagecontainstheollowingprinteddocuments:
•ReadMeFirst
Thisisamultilingualdocument.Itillustratessaetysymbolsandinstructsyoutoreadthecomplete
saety,warranty,andsupportinormationprovidedontheLenovoWebsitebeoreusingtheserver.This
documentalsotellsyouhowtofindthemostup-to-dateinormationontheLenovoSupportWebsite.In
addition,recycling,environmental,andlegalnoticesareallincluded.
•Alettertocustomers
Thisisamultilinguallettertocustomers,whichtellscustomersthatLenovoisundertakingapaperless
electronicdocumentationinitiativetoprotectenvironment.Thisletteralsoprovidesinormationabout
howtocontactLenovoiyourequireaprintedversionoanyelectronicdocuments.
Electronicdocuments
•Youcanfindtheollowingelectronicdocumentsathttps://support.lenovo.com/documents/LNVO-DOCS:
–SafetyInformation
Thisisamultilingualdocumentthatincludesallthesaetystatementsoryourproduct.Ensurethatyou
readandunderstandthesesaetystatementsbeoreusingtheproduct.
–LenovoLimitedWarranty
ThisdocumentincludestheLenovotermsandwarrantystatements.
–LenovoLicenseAgreement
ThisdocumentincludesthetermsandconditionsotheLenovoLicenseAgreement.
•YoucanfindtheollowingelectronicdocumentsromtheLenovoSupportWebsite.Goto
http://www.lenovo.com/support,clickDocumentation,andollowtheinstructionsonthescreento
findthedocumentyouneed.
–Safety,Warranty,andSupportInformation
Thisisamultilingualdocumentthatincludesallthesaetystatementsoryourproductinmorethan30
languages.Ensurethatyoureadandunderstandallthesaetystatementsbeoreusingtheproduct.
ThisdocumentalsoincludestheLenovowarrantystatement,CustomerReplaceableUnits(CRUs)
inormation,andinormationabouthowtocontacttheLenovoCustomerSupportCenter.
–UserGuideandHardwareMaintenanceManual
Thisdocumentprovidesdetailedinormationtohelpyougetamiliarwithyourserverandhelpyouuse,
configure,andmaintainyourserver.
–MegaRAISASSoftwareUserGuide(Englishonly)
ThisdocumentprovidesinormationaboutRedundantArrayoIndependentDisks(RAID)andhowto
usetheutilityprogramstoconfigure,monitor,andmaintainyourserverRAIDandrelateddevices.
Note:ReertothisdocumentorhardwareRAIDinormationitheserverhasarequiredRAIDcard
installed.SeeRAIDcard.ForinormationaboutonboardsotwareRAID,seeConfiguringonboard
SATAsotwareRAID.
2ThinkServerTS450UserGuideandHardwareMaintenanceManual

–Otherdocuments
YoumightfindotherdocumentsortheHostBusAdapter(HBA),Ethernetcard,orotheroptionalparts.
Chapter1.Generalinormation3

4ThinkServerTS450UserGuideandHardwareMaintenanceManual

Chapter2.Serversetuproadmap
Thischapterprovidesageneralroadmaptoguideyouthroughsettingupyourserver.
Theserversetupprocedurevariesdependingontheconfigurationotheserverwhenitwasdelivered.In
somecases,theserverisullyconfiguredandyoujustconnecttheservertothenetworkandanacpower
source,andthenyoucanturnontheserver.Inothercases,theserverneedstohavehardwareeatures
installed,requireshardwareandfirmwareconfiguration,andrequiresanoperatingsystemtobeinstalled.
Serversetupprocedure
Theollowinglistisageneralprocedureorsettingupyourserver:
1.Unpacktheserverpackage.See“Inthebox”onpage7.
2.Installanyrequiredhardwareorserveroption.SeetherelatedtopicinChapter5“Replacinghardware”
onpage51.
3.ConnecttheEthernetcableandpowercordstotheserver.See“Rearviewotheserver”onpage
15tolocatetheconnectors.
4.Turnontheservertoveriyoperation.See“Turningontheserver”onpage5.
5.ReviewtheUnifiedExtensibleFirmwareInterace(UEFI)BasicInputOutputSystem(BIOS)settingsand
customizeasneeded.See“UsingtheSetupUtilityprogram”onpage35.
6.ConfigureRAIDandinstalltheoperatingsystemandbasicdrivers.See“UsingtheThinkServer
EasyStartupprogram”onpage41and“ConfiguringRAID”onpage44.
7.Installanyadditionaldriversneededoraddedeatures.Reertotheinstructionsthatcomewiththe
hardwareoption.
8.ConfigureEthernetsettingsintheoperatingsystembyreerringtotheoperatingsystemhelp.Youcan
skipthisstepitheoperatingsystemwasinstalledusingtheThinkServerEasyStartupprogram.
9.Checkorfirmwareupdates.Toupdatethefirmware,dooneotheollowing:
•Gotohttp://www.lenovo.com/driversandollowtheinstructionsontheWebpagetocheckorthe
latestlevelofirmware,suchastheBIOSupdatesanddevicedrivers.
•UsetheFirmwareUpdaterprogram.
10.Installotherapplications.Reertothedocumentationthatcomeswiththeapplicationsthatyouwantto
install.
Turningontheserver
Ateryoufinishunpackingandsettinguptheserver,connectittoanacpowersource.Pressthepower
buttonontherontpaneltoturnontheserver.See“Frontpanel”onpage14.
Turningofftheserver
CAUTION:
Thepowercontrolbuttononthedeviceandthepowerswitchonthepowersupplydonotturnoff
theelectricalcurrentsuppliedtothedevice.Thedevicealsomighthavemorethanonepower
cord.Toremoveallelectricalcurrentfromthedevice,ensurethatallpowercordsaredisconnected
fromthepowersource.
©CopyrightLenovo2015,20165

Theservercanbeturnedoinoneotheollowingways:
•Turnotheserverromtheoperatingsystemiyouroperatingsystemsupportsthiseature.Ateran
orderlyshutdownotheoperatingsystem,theserverturnsoautomatically.Forinstructionsonhow
toshutdownyourspecificoperatingsystem,reertotherelateddocumentationorhelpsystemor
theoperatingsystem.
•Pressthepowerbuttonontherontpaneltostartanorderlyshutdownotheoperatingsystemandturn
otheserver,iyouroperatingsystemsupportsthiseature.
•Iyourserverstopsrespondingandyoucannotturnito,pressandholdthepowerbuttononthe
rontpaneloroursecondsormore.Iyoustillcannotturnotheserver,disconnectallpowercords
romtheserver.
•Theservermightturnoasanautomaticresponsetoacriticalsystemailure.
6ThinkServerTS450UserGuideandHardwareMaintenanceManual
