Lenovo B8080-H How to use

YOGA TABLET 10 HD+
Lenovo B8080-F / B8080-H (V)
Safety, Warranty & Quick Start
Guide 9.
English/ㆶ։ѣᮽ0䷩橼󰵶㔯

English
Electronic emission
notices
Learn more
Legal notices Lenovo and the Lenovo logo are trademarks of
Lenovo in the United States, other countries, or
both.
Other company, product, or service names may
be trademarks or service marks of others.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
LIMITED AND RESTRICTED RIGHTS NOTICE: If
data or software is delivered pursuant a General
Services Administration “GSA” contract, use,
reproduction, or disclosure is subject to
restrictions set forth in Contract No.
GS-35F-05925.
Read this guide carefully before using your YOGA TABLET 10 HD+.
All information labeled with * in this guide refers only to the WLAN + 3G
model (Lenovo B8080-H(V) ).
Radio and Telecommunications Terminal
Equipment Directive
This product is in compliance with the essential
requirements and other relevant provisions of the
Radio and Telecommunications Terminal
Equipment Directive, 1999/5/EC.
European Union conformity
For more information about your YOGA TABLET
10 HD+ functions, please refer to the “User
Guide” app in your YOGA TABLET 10 HD+.
For “Regulatory Notices”, please go to
http://support.lenovo.com/.
Getting support For support on network service and billing,
please contact your wireless network operator.
For instructions on how to use your YOGA
TABLET 10 HD+, go to
http://support.lenovo.com/.

Technical specifications
Approx. 614 g *Approx. 619 g
Qualcomm APQ8028 1.6GHz
*Qualcomm MSM8228 1.6GHz
9000 mAh
Model & version
①Weight
Camera
Battery
Display
Wireless
communication
8 MP AF (back) + 1.6 MP HD (front)
Size: 10.1 inches
Resolution: 1920 × 1200
Bluetooth 4.0 WLAN 802.11 b/g/n GPS
*WCDMA, GSM
①Actual product may differ.
*Version: WLAN + 3G
CPU
YOGA TABLET 10 HD+
Version: WLAN
Android 4.3
*Version: WLAN + 3G
(Data only)
(Voice)
*Model: Lenovo B8080-HV;
*Model: Lenovo B8080-H;
Model: Lenovo B8080-F;
System

5
10
Micro USB
2
6
3
789
4
1
11
On/Off button
Speakers Microphone Volume key
Earphone jack Bracket Back camera
microSD card slot*Micro SIM card slot
The WLAN model ( Lenovo B8080-F ) does not have a Micro SIM card slot.
3
261 mm
180 mm
3 mm
1
2
3
4 4
8.1 mm
21 mm
5
6
78
9
10
11
First glance
Front camera

1
2
1
You can use cellular services with the WLAN + 3G model ( Lenovo B8080-H(V) ) by
inserting the Micro SIM card provided by your carrier.
Install the Micro SIM card and the microSD card as shown.
Step 1. Lift the bracket.
Step 2. Open the card slot cover.
Insert the Micro SIM card
and microSD card and then
repalce the card slot cover.
Step 3. Push back the bracket.
Only Micro SIM card works with your YOGA TABLET 10 HD+.
!!! DO not insert or remove the Micro SIM card while your YOGA TABLET 10 HD+ is
turned on. Doing so can permanently damage your Micro SIM card or YOGA
TABLET 10 HD+.
2
2
1
Preparing your YOGA TABLET 10 HD+

Turning on/off
Before using your YOGA TABLET 10 HD+, you might need to charge the battery.
Charge the battery as shown.
Connect your YOGA TABLET 10 HD+ to a power outlet using the included cable and
USB power adapter.
Low battery Fully charged Charging
Tur n on: Press and hold the On/Off button until the
Lenovo logo is displayed.
Tur n of f: Press and hold the On/Off button for a few
seconds, then tap Power off .
Starting to use your YOGA TABLET 10 HD+
Taking screenshots
Press and hold the On/off button and the Volume down button at the same time.

Read before using your tablet
Read first-Regulatory information
The following sections provide critical safety and regulatory information for Lenovo
tablets and instructions on how to access electronic versions of the publications
developed for your tablet.
Downloading publications
Accessing your User Guide
The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of your product. Refer to the
Lenovo Limited Warranty for a full explanation of Lenovo warranty terms. See “Lenovo
Limited Warranty notice” later in this document for details on accessing the full
warranty.
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
You can get help and information from the Customer Support Center by telephone.
Before contacting a Lenovo technical support representative, please have the following
information available: model and serial number, the exact wording of any error
message, and a description of the problem.
Your technical support representative might want to walk you through the problem
while you are at your device during the call.
Device models equipped with wireless communications comply with the radio frequency
and safety standards of any country or region in which it has been approved for wireless
use. In addition, if your product contains a telecom modem, it complies with the
requirements for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region before using the wireless
devices contained in your device. To obtain a PDF version of the Regulatory Notice, refer
to the “Downloading publications” section below.
Electronic versions of your publications are available from the
http://support.lenovo.com. To download the publications for your device, go to:
http://support.lenovo.com and follow the instructions on the screen.
Your User Guide contains detailed information about your device. To access your User
Guide, use one of the following methods:
Go to: http://support.lenovo.com and follow the instructions on the screen.
Start your device, access User Guide from the Browser favorites.
Service and Support information
Telephone technical support

WARNING: Handling the cord on this product or cords associated with accessories
sold with this product will expose you to lead, a chemical known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash hands
after handling.
Polyvinyl Chloride (PVC) cable and cord notice
Built-in rechargeable battery notice
Prevent hearing damage
Your device has a headphone connector. Always use the headphone connector for
headphones (also called a headset) or earphones.
Worldwide Lenovo Support telephone list
DANGER:
Do not attempt to replace the internal rechargeable lithium ion battery. Contact Lenovo
Support for factory replacement.
CAUTION:
Excessive sound pressure from earphones and headphones can cause hearing loss.
Adjustment of the equalizer to maximum increases the earphone and headphone
output voltage and the sound pressure level. Therefore, to protect your hearing, adjust
the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time at high volume
can be dangerous if the output of the headphone or earphone connectors do not
comply with specifications of EN 50332-2.
The headphone output connector of your device complies with EN 50332-2 Sub
clause 7. This specification limits the device's maximum wide band true RMS output
voltage to 150 mV. To help protect against hearing loss, ensure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band
characteristic voltage of 75 mV. Using headphones that do not comply with EN
If the telephone number for your country or region is not listed, contact your Lenovo
reseller or Lenovo marketing representative.
Important safety and handling information
Plastic bag notice
DANGER:
Plastic bags can be dangerous. Keep plastic bags away from babies and children to
avoid danger of suffocation.
Important: Telephone numbers are subject to change without notice. The most
up-to-date telephone list for the Customer Support Center is always available at
http://www.lenovo.com/support/phone.

Warning statement:
To prevent possible hearing damage, do not listen at high volume levels for a long
period of time.
Lenovo Limited Warranty notice
This product is covered by the terms of the Lenovo Limited Warranty, version
L505-0010-02 08/2011. Read the Lenovo Limited Warranty (LLW) at http://www.leno-
vo.com/warranty/llw_02. You can view the LLW in a number of languages from this
Web site. If you cannot view the LLW from the Web site, contact your local Lenovo
office or reseller to obtain a printed version of the LLW.
Lenovo B8080
Model & Version
Model Version
WLAN
WLAN+3G (Data only)
WLAN+3G (Voice)
Lenovo B8080-F
Lenovo B8080-H
Lenovo B8080-HV
Sound pressure warning statement
For the device that is tested in accordance with EN 60950-1:
2006+A11:2009:+A1:2010+A12:2011, it is mandatory to perform audio tests for
EN50332.
This device has been tested to comply with the Sound Pressure Level requirement laid
down in the applicable EN 50332-1 and/or EN 50332-2 standards. Permanent hearing
loss may occur if earphones or headphones are used at high volume for prolonged
periods of time.
Warranty information
50332-2 can be dangerous due to excessive sound pressure levels.
If your device came with headphones or earphones in the package, as a set, the
combination of the headphones or earphones and the device already complies with
the specifications of EN 50332-1. If different headphones or earphones are used,
ensure that they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headphones that do not comply with EN 50332-1 can be dangerous due to excessive
sound pressure levels.

Bosnia-Herzegovina, Croatia, Cyprus,
Greece, Macedonia, Romania,
Slovenia, Serbia, Poland, Slovakia,
Hungary, Bulgaria
parts and labor - 1 year
battery pack - 1 year 1,4
Canada, Japan parts and labor - 1 year
battery pack - 1 year 1,5
Austria, France, Germany, Iceland,
Israel, Ireland, Italy, Latvia, Lithuania,
Switzerland, the United Kingdom
parts and labor - 1 year
battery pack - 1 year 1,3
Australia, New Zealand parts and labor - 1 year
battery pack - 1 year 1,3
Russia, Ukraine, the Republic of
Kazakhstan, Belarus, Turkmenistan,
Azerbaijan, Georgia
parts and labor - 1 year
battery pack - 1 year 4
Argentina, Colombia, Peru,Venezuela,
Bolivia, Uruguay,Chile, Paraguay,
Ecuador
parts and labor - 1
year limited warranty*
battery pack - 1 year
1,4
United States of America, Mexico parts and labor - 1 year
limited warranty*
battery pack - 1 year
1,5
Brazil
parts and labor - 1 year
limited warranty*
battery pack - 1 year
4
Denmark, Estonia, Finland,
Norway, Spain, Sweden, Belgium,
Luxembourg, Netherlands
parts and labor - 2 years
battery pack - 1 year 1,3
Turkey, Czech Republic parts and labor - 2 years
battery pack - 1 year 1,4
* Excludes some components. 90-day limited warranty for power adapters, keyboards,
plastics and hinges.
Types of Warranty Service
1. Customer Replaceable Unit (“CRU”) Service
2. On-site Service
Warranty period and type of Warranty service
Country or Region of Purchase Warranty Period Type of Warranty
Service
Korea, Taiwan parts and labor - 1 year
battery pack - 1 year 1,3,4
Indonesia, Malaysia, Thailand,
Philippines, Vietnam,Singapore
parts and labor - 1 year
battery pack - 1 year 1,4
China (Hong Kong S.A.R.), China
(Macau S.A.R.), India, Bahrain, Kuwait,
Oman, Qatar, Egypt, South Africa,
Saudi Arabia, UAE, Algeria, Nigeria,
Kenya, Sri Lanka
parts and labor - 1 year
battery pack - 1 year 1,4

3. Courier or Depot Service
4. Customer Carry-In Service
5. Mail-in Service
6. Customer Two-Way Mail-in Service
7. Product Exchange Service
For a full explanation of the types of warranty service, refer to the full warranty. See
“Lenovo Limited Warranty notice” for details on accessing the full warranty.
Environmental, recycling, and disposal information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to responsibly
recycle their equipment when it is no longer needed. Lenovo offers a variety of
programs and services to assist equipment owners in recycling their IT products. For
information on recycling Lenovo products, go to: http://www.lenovo.com/recycling.
Important WEEE information
Country-specific information is available at http://www.lenovo.com/recycling.
Recycling information for Japan
Recycling and disposal information for Japan is available at:
http://www.lenovo.com/recycling/japan.
Additional recycling statements
Additional information about recycling device components and batteries is in your User
Guide. See “Accessing your User Guide” for details.
Battery recycling marks
The battery recycling information of Taiwan
ᔘ䴱⊖䄁ഔ᭬
Battery recycling information for the United States and Canada

Battery recycling information for the European Union
Energy efficiency mark
EurAsia compliance mark
Restriction of Hazardous Substances Directive (RoHS)
Tur kish
The Lenovo product meets the requirements of the Republic of Turkey Directive on the
Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment (EEE).
Ukraine
India
RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
European Union
Lenovo products sold in the European Union, on or after 3 January 2013 meet the
requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (“RoHS recast” or “RoHS 2”).
For more information about Lenovo progress on RoHS, go to:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf
Notice for users in Mexico
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es
posible que este equipo o dispositivo no cause interferencia perjudicial y (2)
este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la
que pueda causar su operación no deseada.

Users have to use the connection to USB interfaces with USB 2.0 version or higher.
Please make sure the temperature for device will not be higher than 40 oC.
The device could be used with a separation distance of 0cm to the human body.
The adapter shall be installed near the equipment and shall be easily accessible.
These devices complied with the essential requirements of Article 3 of the R&TTE
1999/5/EC Directive.
All the reports of the applied standards have the Positive Opinion of Notified Body:
PHOENIX TESTLAB, Königswinkel 10 D-32825 Blomberg, Germany
Electronic emission notices
CE Caution
Federal Communications Commission (FCC) Declaration of Conformity
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital ,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiated radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communi-
cations. However, there is no guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.

Industry Canada Note
This device complies with Industry Canada license-exempt RSS standard(s). Operation
is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
IC: 10407A-B8080F
IC Radiation Exposure Statement
This EUT is compliance with SAR for general population/uncontrolled exposure limits in
IC RSS-102 and had been tested in accordance with the measurement methods and
procedures specified in IEEE 1528 and IEC 62209. This equipment should be installed
and operated with minimum distance 0 cm between the radiator and your body. This
device and its antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter.
Cet appareil est conforme aux limites d'exposition DAS incontrôlée pour la population
générale de la norme CNR-102 d'Industrie Canada et a été testé en conformité avec les
méthodes de mesure et procédures spécifiées dans IEEE 1528 et IEC 62209.
Cet appareil doit être installé et utilisé avec une distance minimale de 0 cm entre
l’émetteur et votre corps. Cet appareil et sa ou ses antennes ne doivent pas être
co-localisés ou fonctionner en conjonction avec tout autre antenne ou transmetteur.

FCC RF Exposure Information (SAR)
This device is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the United States.
During SAR testing, this device is set to transmit at its highest certified power level in all
tested frequency bands, and placed in positions that simulate RF exposure in usage
near the body with the separation of 0 mm. Although the SAR is determined at the
highest certified power level, the actual SAR level of the device while operating can be
well below the maximum value. This is because the device is designed to operate at
multiple power levels so as to use only the power required to reach the network. In
general, the closer you are to a wireless base station antenna, the lower the power
output.
The exposure standard for wireless s employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg.
Tests for SAR are conducted using standard operating positions accepted by the FCC
with the device transmitting at its highest certified power level in all tested frequency
bands.
The FCC has granted an Equipment Authorization for this model device with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this model device is on file with the FCC and can be found under the
Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:
O57B8080F.
For this device, the highest reported SAR value for usage near the body is 1.15 W/kg.
SAR compliance for body operation is based on a separation distance of 0 mm between
the unit and the human body.

⭫ᆆ䗆ሺ
༦᱄
Ҽ䀙ᴪཐؗᚥ
⌋ᗁ༦᱄ Lenovo ૂLenovo ᗳḽᱥ Lenovo ൞㗄ളૂ/
ᡌެԌളᇬᡌ൦Ⲻ୼ḽȾ
ެԌޢȽӝ૷ᡌᵃࣗ〦㜳ᱥެԌޢⲺ
୼ḽᡌ㘻ᵃࣗḽ䇦Ⱦ
㔅ᶒ∊ᇔ僂ᇚᦾᵹ⭕ӝȾDolby ૂ D ḽᘍᱥ
ᶒ∊ᇔ僂ᇚⲺ⌞߂୼ḽȾ
ᴿ䲆ᵹ࡟༦᱄φྸ󰵳ᮦᦤᡌ䖥Ԭד➝䙐⭞ᵃࣗ
㇗⨼δGSAε  ᨆ ב θެֵ⭞Ƚགྷ࡬ᡌޢᔶ
㕌Ѱ GS-35F-05925 ⲺᶗⅴⲺ㓜ᶕȾ
ᔶခֵ⭞ YOGA TABLET 10 HD+ ҁࢃθ䈭Ԋ㓼䰻䈱ᵢ᤽঍Ⱦ
ᵢ᤽঍ѣḽᴿ * Ⲻᡶᴿؗᚥӻ᤽ WLAN +3G ශ (Lenovo B8080-H(V))Ⱦ
ᰖ㓵⭫䙐ؗ㓾ㄥ᤽Ԛ
↚ӝ૷ㅜᰖ㓵⭫䙐ؗ㓾ㄥ᤽Ԛ 1999/5/EC
Ⲻะᵢ㾷≸ૂެԌ⴮ީ㿺ᇐȾ
⅝ⴕ㿺ᙝ
ᴿީ YOGA TABLET 10 HD+ ࣕ㜳Ⲻᴪཐؗᚥ
θ䈭৸䰻 YOGA TABLET 10 HD+ ѣⲺć⭞ᡭ
᤽঍Ĉᓊ⭞ぁᓅȾᴿީć⌋㿺༦᱄Ĉθ䈭䇵䰤
http://support.lenovo.com/Ⱦ
㧭᭥ᤷ ᴿީ㖇㔒ᵃࣗૂ䇗䍯᭥ᤷθ䈭㚊㌱ᛞⲺᰖ㓵㖇㔒
䘆㩛୼Ⱦᴿީྸ֋ֵ⭞ YOGA TABLET 10 HD+
Ⲻ
䈪᱄θ䈭䇵䰤 http://support.lenovo.com/Ⱦ
ㆶ։ѣᮽ

ᢶᵥ㿺Ṳ
㓜614 g *㓜619 g
Qualcomm APQ8028 1.6GHz
*Qualcomm MSM8228 1.6GHz
9000 mAh
ශ⡾ᵢ
Ś䠃䠅
᩺܅ཪ
⭫⊖
ᱴ⽰ኅ
ᰖ㓵䙐䇥
8 MP AFδε+ 1.6 MP HDδࢃε
ተሮφ10.1 㤧ሮ
࠼䗞⦽φ1920 × 1200
Bluetooth 4.0 WLAN 802.11 b/g/n GPS
*WCDMAθGSM
Ś䈭ԛᇔ䱻ӝ૷Ѱ߼Ⱦ
*⡾ᵢφWLAN + 3G
CPU
YOGA TABLET 10 HD+
⡾ᵢφWLAN
Android 4.3
*⡾ᵢφWLAN + 3G
δӻᮦᦤε
δ䈣丩ε
*ශφLenovo B8080-HVχ
*ශφLenovo B8080-Hχ
ශφLenovo B8080-Fχ
㌱㔕

5
10
Micro USB
2
6
3
789
4
1
11
ᔶ/ީ᤿䫤
ᢢ༦ಞ 哜ށ伄 丩䠅䭤
㙩ᵰᨈᆊ ᢎ󰶍 ᩺܅ཪ
microSD গᨈ″*Micro SIM গᨈ″
WLAN ශ (Lenovo B8080-F) ⋗ᴿ Micro SIM গᨈ″Ⱦ
3
261 mm
180 mm
3 mm
1
2
3
4 4
8.1 mm
21 mm
5
6
78
9
10
11
ཌ㿸
ࢃ᩺܅ཪ

1
2
1
ሯӄ WLAN + 3G ශ (Lenovo B8080-H(V))θᨈޛ䘆㩛୼ᨆבⲺ Micro SIM গ঩ֵ⭞
㴸ビᵃࣗȾ
ᆿ㻻 Micro SIM গૂ microSD গⲺᯯ⌋ྸഴᡶ⽰Ⱦ
ㅢ1 ↛φᨆ䎭ᢎ󰶍Ⱦ
ㅢ2 ↛φᢉᔶগ″ⴌȾᨈޛ Micro SIM গ
ૂmicroSD গθ❬ⴌрগ″ⴌȾ
ㅢ3 ↛φ᧞ഔᢎ󰶍Ⱦ
YOGA TABLET 10 HD+ 㜳ֵ⭞ Micro SIM গȾ
!!!YOGA TABLET 10 HD+ ༺ӄᢉᔶ⣬ᘷᰬ࠽ᨈᤊ Micro SIM গȾࡏ㜳≮ѻᦕ
අMicro SIM গᡌ YOGA TABLET 10 HD+Ⱦ
2
2
1
߼༽ᛞⲺ YOGA TABLET 10 HD+

ᢉᔶ/ީ䰣
ֵ⭞ YOGA TABLET 10 HD+ ࢃθ㜳䴶㾷㔏⭫⊖ݻ⭫Ⱦ
㔏⭫⊖ݻ⭫Ⲻᯯ⌋ྸഴᡶ⽰Ⱦ
⭞䳅䱺Ⲻ⭫㔼ૂ USB ⭫Ⓠ䘸䞃ಞሼ YOGA TABLET 10 HD+ 䘔᧛ࡦ⭫ⓆᨈᓝȾ
⭫⊖⭫䠅ք ⭫䠅ᇂޞݻ┗ ↙൞ݻ⭫
ᔶᵰφ
᤿օᔶ/ީ᤿䫤θ⴪ࡦᱴ⽰ Lenovo ḽ䇼Ⱦ
ީᵰφ
᤿օᔶީ᤿䫤ࠖ〈䫕θ❬⛯᤿ćީᵰĈȾ
ᔶခֵ⭞ YOGA TABLET 10 HD+
ᡠኅ
ᰬ᤿օᔶ/ީ᤿䫤ૂ丩䠅䲃ք䭤Ⱦ
