Mounting Instructions EN
g500 G50AB045 ... G50BB320 |
45 Nm ... 20000 Nm
Bevel gearbox / Bevel gearbox
with three−phase AC motor
l

,Please read these instructions before you start working!
Follow the enclosed safety instructions.
0Abb. 0Tab. 0

Contents i
3
Lenze ¯ MA 12.0014 ¯ 5.1
1 About this documentation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Document history 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Conventions used 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Terminology used 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Notes used 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Safety instructions 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 General safety instructions for drive components 8. . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Application as directed 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Foreseeable misuse 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Residual hazards 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Product description 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Important notes 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Identification 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.1 Nameplate 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.2 Gearbox code 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Mechanical installation 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Important notes 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Transport 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Preparation 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3.1 General information about the assembly of drive systems 22. . . . . . . . . . .
4.3.2 Gearboxes with breathers 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3.3 Gearbox with compensation container
(preferably for mounting pos. "C") 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3.4 Mounting the gearboxes 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3.5 Maximum permissible load at the motor adapter 26. . . . . . . . . . . . . . . . . .
4.3.6 Mounting of motors to gearboxes with an adapter and a
flexible coupling 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3.7 Coupling hubs 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3.8 Mounting of motors to gearboxes with a short adapter with a
plug−in hollow shaft with a keyway (drive−end version B or H) 33. . . . . . . .
4.3.9 Attachment of gearboxes with hollow shafts and keyway 34. . . . . . . . . . .
4.3.10 Mounting the shrink disc with a rotating cover 38. . . . . . . . . . . . . . . . . . . .
4.3.11 Mounting the fixed cover 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3.12 Mounting the hoseproof hollow shaft cover 42. . . . . . . . . . . . . . . . . . . . . .
4.3.13 Torque plate assembly 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Electrical installation 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 Motor connection 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Motor options 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contentsi
4 Lenze ¯ MA 12.0014 ¯ 5.1
6 Commissioning and operation 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 Important notes 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 Before switching on 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.3 Initial commissioning 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.4 During operation 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Maintenance 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.1 Important notes 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2 Maintenance intervals 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3 Maintenance operations 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3.1 Position of the lubricant monitoring elements 50. . . . . . . . . . . . . . . . . . . .
7.3.2 Table of lubricants 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3.3 Checking the oil level 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3.4 Changing the oil 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3.5 Lubricate roller bearings 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3.6 Drain condensation 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.4 Repair 65. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Troubleshooting and fault elimination 66. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

About this documentation 1
5
Lenze ¯ MA 12.0014 ¯ 5.1
1 About this documentation
Contents
¯ This documentation serves for safety−relevant operations on and with the
gearboxes. It contains safety instructions which must be observed.
¯ All personnel working on and with the gearboxes must have the documentation
available during the work and observe the information and notes relevant for
them.
¯ The documentation must always be complete and in a perfectly readable state.
¯ The information in this documentation can be supplemented by further
documents, if necessary, e.g. information regarding the motors mounted,
additional components on the gearbox or motor, or with regard to gearboxes and
motors in ATEX design.
Target group
This documentation is directed at qualified skilled personnel according to IEC 60364.
Qualified skilled personnel are persons who have the required qualifications to carry out
all activities involved in installing, mounting, commissioning, and operating the
product.
ITip!
Information and tools concerning the Lenze products can be found in the
download area at
www.lenze.com

About this documentation
Document history
1
6 Lenze ¯ MA 12.0014 ¯ 5.1
1.1 Document history
Material number Version Description
13457390 1.0 02/2014 TD29 First edition for the pilot series
.Xqô 5.1 09/2018 TD29 "Maintenance" chapter: g500−B240 − lubricated for
life
Table new: load carrying capacity of the eye bolt
.Xqô 5.1 09/2018 TD29 Complete revision including the cast iron gearboxes
13535365 4.0 05/2017 TD09 Drawing exchanged in the chapter "Disassembly of
gearbox with hollow shaft"
Auxiliary tool table supplemented
Important note corrected in the Maintenance
chapter
Ambient temperatures changed in the lubricant
table
13553160 5.0 06/2018 TD15 Array of products extended
.Xqô 5.1 09/2018 TD29 Error corrections
1.2 Conventions used
This documentation uses the following conventions to distinguish different types of
information:
Type of information Writing Example/notes
Numeric notation
Decimal Standard notation Example: 1234
Decimal separator Point The decimal point is always used.
For example: 1234.56
Icons
Page reference ^Reference to another page with additional
information
For instance: ^16 = see page 16
Documentation reference ,Reference to another documentation with
additional information
Example: ,EDKxxx = see EDKxxx documentation
Wildcard LWildcard for options, selection data
1.3 Terminology used
Term In the following text used for
Gearboxes Gearboxes of the g500 product family
Drive system Drive systems with g500 gearboxes and other Lenze drive
components

About this documentation
Notes used
1
7
Lenze ¯ MA 12.0014 ¯ 5.1
1.4 Notes used
The following pictographs and signal words are used in this documentation to indicate
dangers and important information:
Safety instructions
Layout of the safety instructions:
}Danger!
(characterises the type and severity of danger)
Note
(describes the danger and gives information about how to prevent
dangerous situations)
Pictograph and signal word Meaning
{Danger!
Danger of personal injury through dangerous electrical
voltage
Reference to an imminent danger that may result in death
or serious personal injury if the corresponding measures are
not taken.
}Danger!
Danger of personal injury through a general source of
danger
Reference to an imminent danger that may result in death
or serious personal injury if the corresponding measures are
not taken.
(Stop!
Danger of property damage
Reference to a possible danger that may result in property
damage if the corresponding measures are not taken.
Application notes
Pictograph and signal word Meaning
)Note! Important note to ensure trouble−free operation
ITip! Useful tip for easy handling
,Reference to another document

Safety instructions
General safety instructions for drive components
2
8 Lenze ¯ MA 12.0014 ¯ 5.1
2 Safety instructions
2.1 General safety instructions for drive components
(in compliance with Low−Voltage Directive 2014/35/EU)
At the time of dispatch, the drive components are in line with the latest state of the art
and can be regarded as operationally safe.
Scope
The following general safety instructions apply to all Lenze drive and automation
components.
The product−specific safety and application notes given in this documentation must be
observed!
General hazards
}Danger!
Disregarding the following basic safety measures may lead to severe
personal injury and damage to material assets!
¯ Lenze drive and automation components ...
... must only be used for the intended purpose.
... must never be operated if damaged.
... must never be subjected to technical modifications.
... must never be operated unless completely assembled.
... must never be operated without the covers/guards.
... can − depending on their degree of protection − have live, movable or rotating parts
during or after operation. Surfaces can be hot.
... must not be actuated if the drive system shows vibration accelerations > 2g
(20m/s2).
... must not be actuated in the resonance range of a system or the Lenze drive system.
¯ All specifications of the corresponding enclosed documentation must be
observed.
This is vital for safe and trouble−free operation and for achieving the specified
product features.
¯ Only qualified skilled personnel are permitted to work with or on Lenze drive and
automation components.
According to IEC 60364 or CENELEC HD 384, these are persons ...
... who are familiar with the installation, assembly, commissioning and operation of
the product,
... possess the appropriate qualifications for their work,
... and are acquainted with and can apply all the accident prevent regulations,
directives and laws applicable at the place of use.

Safety instructions
General safety instructions for drive components
2
9
Lenze ¯ MA 12.0014 ¯ 5.1
Temperatures
The permissible temperature range is determined by the following:
¯ The lubricant specifications in connection with the expected oil temperatures in
operation (see chapter 7.2 and nameplate).
¯ The thermal class of the motor considering the motor temperature expected
during operation (see nameplate and/or operating instructions of the motor).
¯ Protect geared motors against direct solar radiation. Avoid heat concentration
beneath covers.
The operating temperature is determined by the power loss, the ambient temperature
and the cooling system!
(Stop!
With mineral oil, the upper temperature limit for continuous operation is
80°C, with synthetic oil and shaft sealing rings made of FP (Viton) it is
100°C. If these temperatures are exceeded, measures are necessary to
reduce the temperature, (¶66).
}Danger!
Depending on the operating conditions, surfaces may be hot, provide
protection against accidental contact.
Ambient media
¯ Gearboxes are protected against dust and spray water.
¯ Motors according to their enclosure (see nameplate and/or operating instructions
for the motor).
¯ Ambient media − especially chemically aggressive − can destroy shaft seals and
coatings (plastic). Abrasive media endanger shaft seals.
¯ The installation site of the drive must be free of shocks and vibration.
¯ Protect geared motors against direct solar radiation. Avoid heat concentration
beneath covers.
¯ Dirt of dust deposits impede the heat dissipation (cooling).
Transport
Before transport
¯ check that all component parts are safely mounted;
¯ check that all component parts with a loose fastening are secured or removed;
¯ tighten all transport aids (eye bolts or support plates).
Use an appropriate means of transport and lifting equipment! (¶19)

Safety instructions
General safety instructions for drive components
2
10 Lenze ¯ MA 12.0014 ¯ 5.1
Storage
If you do not install the gearbox immediately, provide for proper storage conditions.
¯ Generally
–Store gearboxes indoors in a dry, clean (low−dust) and sunlight−protected
environment.
–The storage location must be free from vibrations and shocks (Veff < 0.2 mm/s)
in order to prevent roller bearing standstill damage.
–Temperature changes with condensate formation are to be avoided.
–Do not activate ventilation unit, in order to prevent air exchange with the
ambient air.
¯ Up to one year:
–Store gearboxes with a ventilation unit with the vent plug on top.
–Shafts and uncoated surfaces are delivered in a protected against rust status.
Aftertreatment is required where the corrosion protection has been damaged.
–Remove the plug for motors with condensation drain holes (option)(¶21).
¯ More than one year, up to two years:
–Apply a long−term corrosion preventive (e.g. Anticorit BW 366 from the Fuchs
company) to the shafts and uncoated surfaces before storing the motor away.
–Install gearbox in mounting position A.
–Fill gearbox up to the top vent hole / oil hole with the oil grade specified (see
nameplate). Then mount the locking screw and ventilation unit (do not activate)
again.
Corrosion protection
Lenze offers paints with different resistance characteristics for drive systems. Since the
resistance may be reduced when the paint coat is damaged, defects in paint work (e.g.
through transport or assembly) must be removed professionally to reach the required
corrosion resistance.
)Note!
Increased surface and corrosion protection can be achieved by using
adapted coating systems.
Mechanical installation
¯ Provide for careful handling and avoid mechanical overload. During handling
neither bend components, nor change the insulation distances.

Safety instructions
General safety instructions for drive components
2
11
Lenze ¯ MA 12.0014 ¯ 5.1
Electrical installation
¯ Carry out the electrical installation according to the relevant regulations (e. g.
cable cross−sections, fusing, connection to the PE conductor). Additional notes are
included in the documentation.
¯ The Instructions contain notes concerning wiring according to EMC regulations
(shielding, earthing, filters and cable routing). The compliance with limit values
required by the EMC legislation is the responsibility of the manufacturer of the
machine or system.
Warning: The inverters are automation components which can be used in industrial
environment according to EN 61000−6−4. These products may cause radio
interference in residential areas. If this happens, the operator may need to take
appropriate action.
¯ Only plug in or remove pluggable terminals in the deenergised state!
Commissioning
¯ If required, you have to equip the system with additional monitoring and
protective devices in accordance with the respective valid safety regulations (e. g.
law on technical equipment, regulations for the prevention of accidents).
¯ Before commissioning remove transport locking devices and keep them for later
transports.
Geared motors for deep−freeze applications
¯ Geared motors for deep−freeze applications are specially optimised to operation
at very low temperatures. Observe that for operation outside the temperature
range specified (e.g. during commissioning) increased wear or even failures may
occur.
¯ We recommend loading the gearbox with a maximum of 50 % of the rated output
torque if it is outside the specified temperature range during commissioning.
Disposal
Sort individual parts according to their properties. Dispose of them as specified by the
current national regulations.

Safety instructions
Application as directed
2
12 Lenze ¯ MA 12.0014 ¯ 5.1
2.2 Application as directed
All products which this documentation applies to are no household appliances but are
exclusively intended as components for re−utilisation for commercial use or
professional use in terms of IEC/EN 61000−3−2. They meet the requirements of the
Low−Voltage Directive 2014/35/EU and the requirements of the harmonised standards
of the IEC/EN 60034 series.
Only use the products under the operating conditions and power limits specified in this
documentation.
Do not use the brakes installed as fail−safe brakes. It cannot be ruled out that the braking
torque is reduced by disruptive factors which cannot be influenced.
¯ Drives
–... must only be operated under the operating conditions and power limits
specified in this documentation.
–... comply with the protection requirements of the EU Low−Voltage Directive.
Any other use shall be deemed inappropriate!

Safety instructions
Foreseeable misuse
2
13
Lenze ¯ MA 12.0014 ¯ 5.1
2.3 Foreseeable misuse
Impermissible applications:
¯ In a potentially explosive atmosphere
–Exception: special ATEX design
¯ In aggressive environments (acids, gases, vapours, dusts, or oils).
¯ Under water or in liquids
¯ Under radiation

Safety instructions
Residual hazards
2
14 Lenze ¯ MA 12.0014 ¯ 5.1
2.4 Residual hazards
Protection of persons
¯ Risk of burns!
–Hot surfaces up to 140 °C during operation! Provide protection against contact.
¯ Highfrequency voltages can be capacitively transferred to the motor housing
through the inverter supply.
–Earth motor housing carefully.
¯ Risk of injury due to rotating shaft!
–Before working on the drive system, ensure that the motor is at a standstill.
¯ Danger of unintentional starting or electrical shocks!
–Connections must only be made when the equipment is deenergised and the
motor is at standstill.
–Installed brakes are no fail−safe brakes.
¯ Dangerous voltages at the power terminals, even if the plug is removed: residual
voltage >60 V!
Motor protection
¯ Installed thermal detectors are no full protection for the machine.
–If required, limit the maximum current, parameterise the controller such that it
will be switched off after some seconds of operation with I > IN, especially if
there is the danger of blocking.
–Installed overload protection does not prevent an overload under any
conditions.
¯ Installed brakes are no fail−safe brakes.
–The torque can be reduced due to disruptive factors that cannot be influenced,
e.g. by ingressing oil due to a defect shaft sealing ring on the A side.
¯ Fuses are no motor protection.
–Use current−dependent motor protection switches at average operating
frequency.
–Use installed thermal detectors at high operating frequency.
¯ In the case of permanent−magnet motors, too high torques cause
demagnetisation.
–The maximum torques according to catalogue must not be exceeded.
¯ If deviations from normal operation occur, e.g. increased temperature, noise,
vibration, determine the cause and, if necessary, contact the manufacturer. If in
doubt, switch off the motor.
¯ Design with plug:
–Never disconnect plug when energised! Otherwise, the plug can be destroyed.
–Switch off power supply and inhibit controller prior to disconnecting the plug.
Fire protection
¯ Fire hazard
–Prevent contact with flammable substances.

Product description
Important notes
3
15
Lenze ¯ MA 12.0014 ¯ 5.1
3 Product description
3.1 Important notes
¯ The most important technical data is given on the nameplate.
¯ The product catalogues contain further technical data.

Product description
Identification
Nameplate
3
16 Lenze ¯ MA 12.0014 ¯ 5.1
3.2 Identification
3.2.1 Nameplate
Geared motor with a directly mounted motor (layout A)
L
C86
cos j
Hz
kW
r/min
V
A
1
16.1
16.2
16.3
10.2
8.1
15
8.2 8.3
11
16.4
16.5
16.6
16.4
16.5
h%
10.3
9
2
3
4
67.1 7.2
5.1
5.3
5.2
5.4
18
27
14.3
14.2
14.1
13
23
16.7
22
26
19
15
17
21
20.1
Geared motor with a directly mounted motor (layout B, with QR code)
L
h%
cos j
Hz
kW
r/min
V
A
9
2
1
16.1
16.2
16.3
18
15
14.1
11
16.4
16.5
16.6
16.7
16.4
16.5
5.4
5.2
C86
14.3
17
30
5.3
5.1
4
3
7.2
7.1
6
33.1
8.1 8.2 8.3
20.1
10.2 10.3
43
23 13 14.2
22
33.2
21
Gearbox with motor adapter
L
18 6
5.2
7.1
5.1 10.2
11
17
20.1
27
1
3
5.4
5.3
4
7.2
10.3
30
Three−phase AC motor for motor adapter
L
h%
cos j
*
-
Hz
kW
r/min
V
A
2
1
4
16.1
16.2
16.3
9
22
8.1
18
14.2
15
21
8.2 8.3
23 26
14.1
11
10.2 10.3
16.4
16.5
16.6
16.7
27
14.3
16.4
16.5
13
20.1
*
-

Product description
Identification
Nameplate
3
17
Lenze ¯ MA 12.0014 ¯ 5.1
Pos. Contents
1Manufacturer / production location
2Type of motor / standard
3Gearbox type
4Motor type
5Technical data
5 5.1 Ratio
5 5.2 Rated torque
5 5.3 Rated speed
5 5.4 Rated frequency
5 5.5 Rated voltage
5 5.6 Rated current
5 5.7 Maximum current
5 5.8 Rated power [kW]
5 5.9 Rated power [HP]
5 5.10 Continuous standstill torque
6Position of system modules / mounting position
7Lubricant details
7 7.1 Lubricant amount
7 7.2 Lubricant type
8Brake data
8 8.1 Type
8 8.2 AC/DC brake voltage
8 8.3 Braking torque, electrical power input
9Feedback / pulse encoder or resolver data
10 Production data
10 10.2 Material number
10 10.3 Serial number
11 Bar code
13 Information with regard to the operating mode
14 Additional motor specifications
14 14.1 Temperature class
14 14.2 Enclosure
14 14.3 Motor protection
15 Applicable conformities, approvals and certificates
16 Rated data for various frequencies
16 16.1 Hz = frequency
16 16.2 kW = motor power
16 16.3 rpm = motor speed
16 16.4 V = motor voltage
16 16.5 A = motor current
16 16.6 cos j= motor power factor
16 16.7 h= motor efficiency: at a rated power of 100%
17 Application factor / load capacity
18 Year of manufacture / week of manufacture
19 UL file number
20 Customer data
20 20.1 Additional customer data
21 UL category (e.g. inverter duty motor)
22 C86 = motor code for inverter parameterisation (code 0086)
23 Efficiency class
26 CC number Department of Energy (optional)
27 Permissible ambient temperature (e.g. Ta £40°C)
30 Weight
33 Encoder data
33.1 Encoder type
33.2 Encoder voltage
43 Internal key: QR code

Product description
Gearbox code
3
18 Lenze ¯ MA 12.0014 ¯ 5.1
3.2.2 Gearbox code
Example G 50 A B 045 M H B R 2 N 2E
Meaning Variant Gearbox code
Product family G 50
Generation A
B
Gearbox type Bevel gearbox B
Output torque 45 Nm 045
110 Nm 111
240 Nm 124
450 Nm 145
600 Nm 160
820 Nm 182
1500 Nm 215
2700 Nm 227
4300 Nm 243
8000 Nm 280
13000 Nm 313
20000 Nm 320
Type of construction Geared motor M
Gearbox N
Shaft type Solid shaft with featherkey V
Hollow shaft with keyway H
Hollow shaft with shrink disk S
Housing type Foot mounting + centering A
Foot mounting B
Centering C
Flange mounting Without flange R
Flange with through holes K
Number of stages 2−stage 2
3−stage 3
Drive size Without adapter (integrated motor) C
00
...
82
1A
...
2K
NEMA adapter with a jaw coupling
with a keyway
A
NEMA adapter with a plug−in hollow
shaft with a keyway
B
IEC adapter with a plug−in hollow shaft
with a keyway
H
IEC adapter with a jaw coupling N
IEC adapter with a jaw coupling with a
keyway
T

Mechanical installation
Important notes
4
19
Lenze ¯ MA 12.0014 ¯ 5.1
4 Mechanical installation
4.1 Important notes
¯ Use load carrying equipment for transport!
¯ Before the transport
–check that all components are safely mounted,
–fasten all transport aids (eye bolts or support plates).
}Danger!
Danger due to toppling or falling loads!
¯ The payload of the hoists and load handling devices must at least
correspond to the weight of the load.
¯ Secure the load handling device so that it won’t slip from its position.
¯ The load must be secured in such a way that it cannot topple or fall
down.
¯ Do not stay under a pending load!
4.2 Transport
}Danger!
The motors attached to the gearbox are partially equipped with eyebolts.
They are exclusively determined for mounting/dismounting the motor to
the gearbox and must not be used for the complete geared motor!
The position of the transport holes can be gathered from the illustrations shown in the
following. As a standard, the G50BB145 ... G50BB243 size gearbox is provided with
transport holes for eye bolts complying with DIN 580 in the gearbox cover. The eye bolt
is not included in the scope of supply!
For the smaller drives with solid shafts, the output shaft thread can be used or the drive
is transported using a securing rope. The rope should be wrapped around the round area
between the motor−gearbox interface.
The gearboxes of sizes G50BB280 ... G50BB320 can be lifted at the ear that is cast on to
the housing.
G50A0B45 ... G50BB124 G50BB145 ... G50BB243 G50BB280 ... G50BB320
1.
2.
Fig. 1 Positioning of the eye bolt for transporting the complete drive system

Mechanical installation
Transport
4
20 Lenze ¯ MA 12.0014 ¯ 5.1
)Note!
As standard, threads are delivered with plug screws. The plug can be
easily removed, e.g. by using a screwdriver blade. For the thread size and
load carrying capacity of the eye bolt, please see Tab. 1.
Eye bolt position Thread
M6 M8 M10 M12 M16 M20 M24
80 140 230 340 700 1200 1800
£45°
−−−−− 100 170 240 500 860 1290
£45°
−−−−− 70 115 170 350 600 900
Tab. 1 Load carrying capacity of each eye bolt in kg
}Danger!
Completely screw in transport aids (such as eye bolts or bearing plates),
they must be flat and applied over their entire surface!
If possible, the transport aids (such as eye bolts or bearing plates) must
be stressed vertically in the direction of the screw axis! Angular tension or
tension to the sides reduces the payload! Observe the information
provided in DIN 580!
Use additional appropriate lifting aids, if required, to achieve a direction
of loading which is as vertical as possible (highest payload). Secure lifting
aids against shifting!
(Stop!
Observe load carrying capacity!
Standing beneath floating loads is prohibited!
