Leuze electronic BCL 338i User manual

BCL 338i
Bar code readers
en 01-2017/06 50135199 We reserve the right to make technical changes
Original operating instructions

Leuze electronic BCL 338i
© 2017
Leuze electronic GmbH + Co. KG
In der Braike 1
D-73277 Owen / Germany
Phone: [phone]
Fax: [phone]
http://www.leuze.com
[email protected]m

Leuze electronic BCL 338i1
Table of contents
1 General information......................................................................................... 10
1.1 Explanation of symbols................................................................................................... 10
1.2 Declaration of Conformity............................................................................................... 10
2 Safety ................................................................................................................ 11
2.1 Intended use ..................................................................................................................... 11
2.2 Foreseeable misuse......................................................................................................... 11
2.3 Competent persons ......................................................................................................... 12
2.4 Exemption of liability .......................................................................................................12
2.5 Laser safety notices ........................................................................................................ 13
3 Fast commissioning / operating principle..................................................... 16
3.1 Mounting the BCL 338i.................................................................................................... 16
3.2 Device arrangement and selection of the mounting location...................................... 16
3.3 BCL 338ielectrical connection....................................................................................... 17
3.4 BCL 338ion the EtherCAT .............................................................................................. 22
3.5 Further settings................................................................................................................ 23
3.6 Starting the device ........................................................................................................... 24
3.7 Bar code reading.............................................................................................................. 26
4 Device description........................................................................................... 27
4.1 About the bar code readers of the BCL 300iseries...................................................... 27
4.2 Characteristics of the bar code readers of the BCL 300iseries.................................. 28
4.3 Device construction......................................................................................................... 30
4.4 Reading techniques......................................................................................................... 33
4.4.1 Line scanner (single line)............................................................................................................. 33
4.4.2 Line scanner with oscillating mirror.............................................................................................. 34
4.4.3 Raster scanner (raster line) ......................................................................................................... 35
4.5 Fieldbus systems .............................................................................................................36
4.5.1 EtherCAT ..................................................................................................................................... 36
4.6 Heating.............................................................................................................................. 37
4.7 autoReflAct ....................................................................................................................... 37
4.8 Reference codes ..............................................................................................................38
4.9 autoConfig ........................................................................................................................ 38

2 BCL 338iLeuze electronic
Table of contents
5 Technical data.................................................................................................. 39
5.1 General specifications of the bar code readers............................................................ 39
5.1.1 Line scanner / raster scanner.......................................................................................................39
5.1.2 Oscillating-mirror scanner ............................................................................................................41
5.1.3 Line / raster scanner with deflecting mirror ..................................................................................41
5.2 Heating models of the bar code readers ....................................................................... 42
5.2.1 Line scanner / raster scanner with heating...................................................................................43
5.2.2 Oscillating-mirror scanner with heating ........................................................................................43
5.2.3 Line scanner / raster scanner with deflecting mirror and heating.................................................44
5.3 Dimensioned drawings.................................................................................................... 45
5.3.1 Dimensioned drawing of complete overview of the BCL 338iwith MS 3xx / MK 3xx / ME 3xx....45
5.3.2 Dimensioned drawing of line scanner with / without heating........................................................46
5.3.3 Dimensioned drawing of deflecting mirror scanner with / without heating....................................47
5.3.4 Dimensioned drawing of oscillating-mirror scanner with / without heating...................................48
5.3.5 Dimensioned drawings of MS 3xx / ME 3xx / MK 3xx connection hoods.....................................49
5.4 Reading field curves / optical data................................................................................. 51
5.4.1 Bar code characteristics...............................................................................................................51
5.4.2 Raster scanner.............................................................................................................................52
5.5 Reading field curves........................................................................................................ 53
5.5.1 High Density (N) - optics: BCL 338iS/R1 N 102 (H)....................................................................54
5.5.2 High Density (N) - optics: BCL 338iS/R1 N 100 (H)....................................................................54
5.5.3 Medium Density (M) - optics: BCL 338iS/R1 M 102 (H)..............................................................55
5.5.4 Medium Density (M) - optics: BCL 338iS/R1 M 100 (H)..............................................................55
5.5.5 Medium Density (M) - optics: BCL 338iO M 100 (H)...................................................................56
5.5.6 Low Density (F) - optics: BCL 338iS/R1 F 102 (H) .....................................................................57
5.5.7 Low Density (F) - optics: BCL 338iS/R1 F 100 (H) ....................................................................57
5.5.8 Low Density (F) - optics: BCL 338iO F 100 (H)...........................................................................58
5.5.9 Ultra Low Density (L) - optics: BCL 338iS L 102 (H)...................................................................59
5.5.10 Ultra Low Density (L) - optics: BCL 338iS L 100 (H)...................................................................59
5.5.11 Ultra Low Density (L) - optics: BCL 338iO L 100 (H) ..................................................................60
5.5.12 Ink Jet (J) - optics: BCL 338iR1 J 100.........................................................................................61
6 Installation and mounting ............................................................................... 62
6.1 Storage, transportation ................................................................................................... 62
6.2 Mounting the BCL 338i.................................................................................................... 63
6.2.1 Mounting via M4 x 5 screws.........................................................................................................63
6.2.2 BT 56 mounting device ................................................................................................................64
6.2.3 BT 59 mounting device ................................................................................................................66
6.2.4 BT 300 - 1, BT 300 W mounting devices......................................................................................67

Leuze electronic BCL 338i3
Table of contents
6.3 Device arrangement......................................................................................................... 68
6.3.1 Selecting a mounting location...................................................................................................... 68
6.3.2 Avoiding total reflection – Line scanner ....................................................................................... 69
6.3.3 Avoiding total reflection – deflecting mirror scanner....................................................................69
6.3.4 Avoiding total reflection – oscillating-mirror scanner ................................................................... 70
6.3.5 Mounting location......................................................................................................................... 70
6.3.6 Devices with integrated heating................................................................................................... 71
6.3.7 Possible read angles between BCL 338iand bar code............................................................... 71
6.4 Cleaning............................................................................................................................ 72
7 Electrical connection....................................................................................... 73
7.1 Safety notices for the electrical connection.................................................................. 74
7.2 BCL 338ielectrical connection....................................................................................... 75
7.2.1 MS 338 connector hood with 3 integrated M12 connectors.........................................................75
7.2.2 ME 338 103 connection hood with M12 connection cables......................................................... 76
7.2.3 ME 338 104 connection hood with M8/M12 connection cables...................................................78
7.2.4 ME 338 214 connection hood with M8/M12/RJ45 connection cables .........................................79
7.2.5 MK 338 terminal hood with spring-cage terminals.......................................................................80
7.3 Detailed description of the connections........................................................................ 82
7.3.1 PWR / SW IN/OUT - Voltage supply and switching input/output 1 and 2.................................... 82
7.3.2 SENSOR - direct connection of an external sensor (ME 338 xx4 only)....................................... 84
7.3.3 SERVICE – USB interface (Mini-B type) ..................................................................................... 85
7.3.4 HOST / BUS IN for BCL 338i....................................................................................................... 86
7.3.5 BUS OUT for the BCL 338i.......................................................................................................... 88
7.4 EtherCAT topologies ....................................................................................................... 89
7.4.1 EtherCAT wiring........................................................................................................................... 90
7.5 Cable lengths and shielding ........................................................................................... 91
8 Display elements and display......................................................................... 92
8.1 BCL 338iLED indicators ................................................................................................. 92
8.2 MS 338/ME 338…/MK338 LED indicators....................................................................... 95
8.3 BCL 338idisplay .............................................................................................................. 97
9 Leuze webConfig tool...................................................................................... 99
9.1 Connecting the SERVICE USB interface........................................................................ 99
9.2 Installing the required software.................................................................................... 100
9.2.1 System requirements................................................................................................................. 100
9.2.2 Installing the USB driver ............................................................................................................ 100
9.3 Starting the webConfig tool .......................................................................................... 101

4 BCL 338iLeuze electronic
Table of contents
9.4 Short description of the webConfig tool ..................................................................... 102
9.4.1 Module overview in the Configuration menu ..............................................................................102
10 Commissioning and configuration .............................................................. 104
10.1 Measures to be performed prior to the initial commissioning .................................. 104
10.2 Starting the device......................................................................................................... 104
10.3 Additional settings for the BCL 338i............................................................................ 105
10.3.1 Decoding and processing the read data ....................................................................................105
10.3.2 Control of the decoding ..............................................................................................................107
10.3.3 Control of the switching outputs .................................................................................................108
10.4 Transmitting configuration data................................................................................... 109
10.4.1 Via the webConfig tool ...............................................................................................................109
10.4.2 Replacing a defective BCL 338i.................................................................................................109
11 BCL 338iin the EtherCAT system................................................................ 110
11.1 Ethernet over EtherCAT - EoE ...................................................................................... 110
11.2 CANopen over EtherCAT - CoE .................................................................................... 111
11.3 Starting the BCL 338iin the EtherCAT system ........................................................... 112
11.4 Device profile ................................................................................................................. 113
11.4.1 Device description file ................................................................................................................113
11.4.2 Object directory overview...........................................................................................................115
11.4.3 Communication objects..............................................................................................................116
11.4.3.1 Object 1000hDevice type...........................................................................................................116
11.4.3.2 Object 1008hManufacturer Device Name..................................................................................116
11.4.3.3 Object 1009hManufacturer Hardware Version...........................................................................116
11.4.3.4 Object 100AhManufacturer Software Version............................................................................116
11.4.3.5 Object 1018hIdentity Object.......................................................................................................117
11.4.3.6 Objects 1600h… 1607h– general mapping ...............................................................................118
11.4.3.7 Object 1600h1st Receive PDO Mapping RxPDO1 (Submission data, 8 bytes) ........................119
11.4.3.8 Object 1601h2nd Receive PDO Mapping RxPDO2 (Submission data, 16 bytes) .....................119
11.4.3.9 Object 1602h3rd Receive PDO Mapping RxPDO3 (Submission data, 32 bytes) ......................120
11.4.3.10 Object 1603h4th Receive PDO Mapping RxPDO4 (Submission data, 48 bytes) ......................121
11.4.3.11 Object 1604h5th Receive PDO Mapping RxPDO5 (Submission data, 64 bytes) ......................122
11.4.3.12 Object 1605h6th Receive PDO Mapping RxPDO6 (Submission data, 96 bytes) ......................123
11.4.3.13 Object 1606h7th Receive PDO Mapping RxPDO7 (Submission data, 128 bytes) ....................124
11.4.3.14 Object 1607h8th Receive PDO Mapping RxPDO8 (Submission data, 252 bytes) ....................125
11.4.3.15 Objects 1A00h… 1A07h– general mapping ..............................................................................126
11.4.3.16 Object 1A00h1st Transmit PDO Mapping TxPDO1 (Result data, 8 bytes)................................128
11.4.3.17 Object 1A01h2nd Transmit PDO Mapping TxPDO2 (Result data, 16 bytes).............................128
11.4.3.18 Object 1A02h3rd Transmit PDO Mapping TxPDO3 (Result data, 32 bytes) .............................129
11.4.3.19 Object 1A03h4th Transmit PDO Mapping TxPDO4 (Result data, 48 bytes)..............................130
11.4.3.20 Object 1A04h5th Transmit PDO Mapping TxPDO5 (Result data, 64 bytes)..............................131
11.4.3.21 Object 1A05h6th Transmit PDO Mapping TxPDO6 (Result data, 96 bytes)..............................132

Leuze electronic BCL 338i5
Table of contents
11.4.3.22 Object 1A06h7th Transmit PDO Mapping TxPDO7 (Result data, 128 bytes) ...........................133
11.4.3.23 Object 1A07h8th Transmit PDO Mapping TxPDO8 (Result data, 252 bytes) ........................... 134
11.4.3.24 Object 1C00hSync Manager Communication Type .................................................................. 135
11.4.3.25 Object 1C12hSync Manager 2 PDO Assignment...................................................................... 136
11.4.3.26 Object 1C13hSync Manager 3 PDO Assignment...................................................................... 136
11.4.4 Device-specific objects .............................................................................................................. 137
11.4.4.1 Objects 0x2000hto 0x2007hResult data ................................................................................... 137
11.4.4.2 Object 0x2050hStatus result data ............................................................................................. 138
11.4.4.3 Objects 0x2100hto 0x2107hSubmission data........................................................................... 140
11.4.4.4 Object 0x2150hStatus submission data .................................................................................... 142
11.4.4.5 Object 0x2200hActivation.......................................................................................................... 144
11.4.4.6 Object 0x2300hFragmented result ............................................................................................ 146
11.4.4.7 Object 0x2400hFragmented submission ................................................................................... 148
11.4.4.8 Object 0x2450hDevice status and control................................................................................. 150
11.5 Communication examples ............................................................................................ 151
11.5.1 Application case: Reading a bar code ....................................................................................... 151
11.5.2 Application case: Transmitting 'PT' sequences ......................................................................... 153
12 Online commands.......................................................................................... 154
12.1 Overview of commands and parameters..................................................................... 154
12.1.1 General online commands......................................................................................................... 155
12.1.2 Online commands for system control ........................................................................................162
12.1.3 Online commands for configuring the switching inputs/outputs................................................. 163
12.1.4 Online commands for the parameter set operations.................................................................. 166
13 Diagnostics and troubleshooting................................................................. 173
13.1 General causes of errors............................................................................................... 173
13.2 Interface errors............................................................................................................... 173
14 Type overview and accessories ................................................................... 175
14.1 Part number code .......................................................................................................... 175
14.2 BCL 338itype overview................................................................................................. 176
14.3 Accessories - Connection hoods ................................................................................. 177
14.4 Accessories – Connectors ............................................................................................ 177
14.5 Accessory USB cable .................................................................................................... 177
14.6 Accessories – Mounting device ................................................................................... 177
14.7 Accessory - Reflector for AutoReflAct......................................................................... 177

6 BCL 338iLeuze electronic
Table of contents
14.8 Accessory - Ready-made cables for voltage supply .................................................. 178
14.8.1 Contact assignment of PWR connection cable ..........................................................................178
14.8.2 Technical data of the cables for voltage supply .........................................................................178
14.8.3 Order codes of the cables for voltage supply.............................................................................178
14.9 Accessory - Ready-made cables for bus connection................................................. 178
14.9.1 General information....................................................................................................................178
14.9.2 Contact assignment of M12 EtherCAT connection cable...........................................................179
14.9.3 Technical data for M12 EtherCAT connection cable..................................................................179
14.9.4 Order codes for M12 EtherCAT connection cable......................................................................180
15 Maintenance ................................................................................................... 181
15.1 General maintenance information................................................................................ 181
15.2 Repairs, servicing .......................................................................................................... 181
15.3 Disassembling, packing, disposing ............................................................................. 181
16 Appendix ........................................................................................................ 182
16.1 Declarations of Conformity........................................................................................... 182
16.2 ASCII character set ........................................................................................................ 184
16.3 Bar code samples .......................................................................................................... 188
16.3.1 Module 0.3 .................................................................................................................................188
16.3.2 Module 0.5 .................................................................................................................................189

Leuze electronic BCL 338i7
Figures and tables
Figure 2.1: Laser apertures, laser warning signs .................................................................................. 14
Figure 2.2: Laser warning and information signs – supplied stick-on labels ......................................... 15
Figure 3.1: BCL 338i- MS 338 connection hood with M12 connectors ................................................ 17
Figure 3.2: BCL 338i- ME 338 103 connection hood with M12 connection cables.............................. 18
Figure 3.3: BCL 338i- ME 338 104 connection hood with M8/M12 connection cables........................ 19
Figure 3.4: BCL 338i- ME 338 214 connection hood with M8/M12/RJ45 connection cables .............. 20
Figure 3.5: BCL 338i- MK 338 terminal hood with spring-cage terminals............................................ 21
Figure 3.6: Cable fabrication for MK 338 terminal hood........................................................................ 21
Figure 4.1: Line scanner, line scanner with deflecting mirror and oscillating-mirror scanner................ 27
Figure 4.2: Possible bar code orientation.............................................................................................. 29
Figure 4.3: BCL 338idevice construction - line scanner....................................................................... 30
Figure 4.4: Device construction BCL 338i- Line scanner with deflecting mirror................................... 30
Figure 4.5: BCL 338idevice construction - oscillating-mirror scanner .................................................. 31
Figure 4.6: Device construction - MS 338 connector hood ................................................................... 31
Figure 4.7: Device construction - MK 338 terminal hood ...................................................................... 32
Figure 4.8: Device construction - MS 338 103 / MS 338 104 connector hoods .................................... 32
Figure 4.9: Deflection principle for the line scanner .............................................................................. 33
Figure 4.10: Deflection principle for the line scanner with oscillating mirror add-on ............................... 34
Figure 4.11: Deflection principle for the raster scanner........................................................................... 35
Figure 4.13: Reflector arrangement for autoReflAct................................................................................37
Table 5.1: Technical data of the BCL 338iline/raster scanners without heating ................................. 39
Table 5.2: Technical data of the BCL 338ioscillating-mirror scanners with heating ........................... 41
Table 5.3: Technical data of the BCL 338ideflecting mirror scanners without heating ....................... 41
Table 5.4: Technical data of the BCL 338iline / raster scanners with heating .................................... 43
Table 5.5: Specifications of the BCL 338ioscillating-mirror scanners with heating............................. 43
Table 5.6: Technical data of the BCL 338ideflecting mirror scanners with heating ............................ 44
Figure 5.1: Dimensioned drawing of complete overview of the BCL 338iwith MS 3xx /
MK 3xx / ME 3xx ................................................................................................................. 45
Figure 5.2: Dimensioned drawing of BCL 338iS…102 line scanner .................................................... 46
Figure 5.3: Dimensioned drawing of BCL 338iS…100 with deflecting mirror ...................................... 47
Figure 5.4: Dimensioned drawing of BCL 338iO…100 oscillating-mirror scanner............................... 48
Figure 5.5: Dimensioned drawing of MS 3xx connector hood / ME 3xx connection hood .................... 49
Figure 5.6: Dimensioned drawing of MK 3xx terminal hood.................................................................. 50
Figure 5.7: The most important characteristics of a bar code ............................................................... 51
Table 5.7: Raster line cover dependent on the distance...................................................................... 52
Figure 5.8: Zero position of the reading distance.................................................................................. 53
Table 5.8: Reading conditions ............................................................................................................. 53
Figure 5.9: "High Density" reading field curve for line scanner without deflecting mirror ...................... 54
Figure 5.10: "High Density" reading field curve for line scanner with deflecting mirror........................... 54
Figure 5.11: "Medium Density" reading field curve for line scanner without deflecting mirror................. 55
Figure 5.12: "Medium Density" reading field curve for line scanner with deflecting mirror...................... 55
Figure 5.13: "Medium Density" reading field curve for oscillating-mirror scanners ................................. 56
Figure 5.14: Lateral "Medium Density" reading field curve for oscillating-mirror scanners ..................... 56

8 BCL 338iLeuze electronic
Figures and tables
Figure 5.15: "Low Density" reading field curve for line scanner without deflecting mirror ...................... 57
Figure 5.16: "Low Density" reading field curve for line scanner with deflecting mirror ........................... 57
Figure 5.17: "Low Density" reading field curve for oscillating-mirror scanners ....................................... 58
Figure 5.18: Lateral "Low Density" reading field curve for oscillating-mirror scanners ........................... 58
Figure 5.19: "Ultra Low Density" reading field curve for line scanner without deflecting mirror.............. 59
Figure 5.20: "Ultra Low Density" reading field curve for line scanner with deflecting mirror................... 59
Figure 5.21: "Ultra Low Density" reading field curve for oscillating-mirror scanners .............................. 60
Figure 5.22: Lateral "Ultra Low Density" reading field curve for oscillating-mirror scanners .................. 60
Figure 5.23: "Ink Jet" reading field curve for line scanner with deflecting mirror .................................... 61
Figure 6.1: Device name plate BCL 338i.............................................................................................. 62
Figure 6.2: Fastening options using M4x5 threaded holes ................................................................... 63
Figure 6.3: BT 56 mounting device ....................................................................................................... 64
Figure 6.4: Mounting example of BCL 338iwith BT 56 ........................................................................ 65
Figure 6.5: BT 59 mounting device ....................................................................................................... 66
Figure 6.6: BT 300 - 1, BT 300 W mounting devices ............................................................................ 67
Figure 6.7: Total reflection – line scanner............................................................................................. 69
Figure 6.8: Total reflection – line scanner............................................................................................. 69
Figure 6.9: Total reflection – BCL 338iwith oscillating-mirror scanner................................................. 70
Figure 6.10: Reading angle for the line scanner ..................................................................................... 71
Figure 7.1: Location of the electrical connections................................................................................. 73
Figure 7.2: BCL 338i- MS 338 connection hood with M12 connectors................................................ 75
Figure 7.3: BCL 338i- ME 338 103 connection hood with M12 connection cables.............................. 76
Figure 7.4: BCL 338i- ME 338 104 connection hood with M8/M12 connection cables........................ 78
Figure 7.5: BCL 338i- ME 338 214 connection hood with M8/M12/RJ45 connection cables .............. 79
Figure 7.6: BCL 338i- MK 338 terminal hood with spring-cage terminals............................................ 80
Figure 7.7: Cable fabrication for MK 338 terminal hood ....................................................................... 81
Table 7.1: PWR / SW IN/OUT pin assignment .................................................................................... 82
Figure 7.1: Switching input connection diagram SWIO_1 and SWIO_2 ............................................... 83
Figure 7.2: Switching output connection diagram SWIO_1 / SWIO_2.................................................. 84
Table 7.2: SENSOR pin assignment ................................................................................................... 84
Table 7.3: SERVICE pin assignment – Mini-B type USB interface...................................................... 85
Table 7.4: Pin assignment HOST / BUS IN for BCL 338i.................................................................... 86
Figure 7.1: HOST / BUS IN cable assignments on RJ-45 .................................................................... 87
Table 7.5: Pin assignment BUS OUT for BCL 338i............................................................................. 88
Figure 7.3: EtherCAT in a linear topology............................................................................................. 89
Table 7.6: Cable lengths and shielding................................................................................................ 91
Figure 8.1: BCL 338i- LED indicators .................................................................................................. 92
Figure 8.2: MS 338/ME 338…/MK 338 - LED indicators ...................................................................... 95
Figure 8.3: BCL 338i- Display.............................................................................................................. 97
Figure 9.1: Connecting the SERVICE USB interface............................................................................ 99
Figure 9.2: The start page of the webConfig tool................................................................................ 101
Figure 9.3: Module overview in the webConfig tool ............................................................................ 102
Figure 10.1: Storing configuration data in the webConfig tool .............................................................. 109

Leuze electronic BCL 338i9
Figures and tables
Figure 11.1: Configuration options ........................................................................................................ 114
Figure 11.2: Sequence diagram for data acceptance/data rejection..................................................... 141
Figure 11.3: Sequence diagram for reading a bar code........................................................................ 152
Figure 11.4: Sequence diagram for configuring with 'PT' sequences ................................................... 153
Table 13.1: General causes of errors................................................................................................... 173
Table 13.2: Interface error ................................................................................................................... 173
Table 14.2: BCL 358itype overview .................................................................................................... 176
Table 14.3: Connection hoods for the BCL 338i.................................................................................. 177
Table 14.4: Connectors for the BCL 338i............................................................................................ 177
Table 14.5: Service cable for the BCL 338i......................................................................................... 177
Table 14.6: Mounting devices for the BCL 338i................................................................................... 177
Table 14.7: Reflector for autoReflAct operation................................................................................... 177
Table 14.8: PWR cable for the BCL 338i............................................................................................. 178
Figure 14.1: Cable construction of EtherNet/IP connection cable......................................................... 179
Table 14.9: Bus connection cables for the BCL 338i........................................................................... 180
Figure 16.1: BCL 338iDeclaration of Conformity.................................................................................. 182
Figure 16.2: Connection hood / connection unit declaration of conformity............................................ 183
Figure 16.3: Bar code sample labels (module 0.3)................................................................................ 188
Figure 16.4: Bar code sample labels (module 0.5)................................................................................ 189

General information
10 BCL 338iLeuze electronic
1 General information
1.1 Explanation of symbols
The symbols used in this technical description are explained below.
Attention!
This symbol precedes text messages which must strictly be observed. Failure to observe the
provided instructions could lead to personal injury or damage to equipment.
Attention Laser!
This symbol warns of possible danger through hazardous laser radiation.
Note!
This symbol indicates text passages containing important information.
1.2 Declaration of Conformity
The bar code readers of the BCL 300iseries have been developed and manufactured in
accordance with the applicable European standards and directives.
Note!
You can find the Declaration of Conformity of the devices in the appendix of the manual on
Page 182.
The manufacturer of the product, Leuze electronic GmbH & Co. KG in D-73277 Owen,
possesses a certified quality assurance system in accordance with ISO 9001.
UL
US
C
LISTED

Safety
Leuze electronic BCL 338i11
TNT 35/7-24V
2Safety
The bar code readers of the BCL 3xxiseries were developed, manufactured and tested in
accordance with the applicable safety standards. They correspond to the state of the art.
2.1 Intended use
Bar code readers of the BCL 3xxiseries are conceived as stationary, high-speed scanners
with integrated decoders for all current bar codes used for automatic object detection.
Areas of application
The bar code readers of the BCL 3xxiseries are especially designed for the following areas
of application:
• Storage and conveying technologies, in particular for object identification on fast-
moving conveyor belts
• Pallet transport systems
• Automobile sector
• Omnidirectional reading
Attention
For UL applications, use is only permitted in Class 2 circuits in accordance with the NEC
(National Electric Code).
2.2 Foreseeable misuse
Any use other than that defined under "Intended use" or which goes beyond that use is
considered improper use.
CAUTION
Observe intended use!
Only operate the device in accordance with its intended use. The protection of per-
sonnel and the device cannot be guaranteed if the device is operated in a manner not
complying with its intended use.
Leuze electronic GmbH + Co. KG is not liable for damages caused by improper use.
Read the technical description before commissioning the device. Knowledge of this
technical description is an element of proper use.
NOTE
Comply with conditions and regulations!
Observe the locally applicable legal regulations and the rules of the employer's liability
insurance association.

Safety
12 BCL 338iLeuze electronic
In particular, use of the device is not permitted in the following cases:
• in rooms with explosive atmospheres
• as stand-alone safety component in accordance with the machinery directive 1)
• for medical purposes
2.3 Competent persons
Connection, mounting, commissioning and adjustment of the device must only be carried
out by competent persons.
Prerequisites for competent persons:
• They have a suitable technical education.
• They are familiar with the rules and regulations for occupational safety and safety at
work.
• They are familiar with the technical description of the device.
• They have been instructed by the responsible person on the mounting and operation
of the device.
Certified electricians
Electrical work must be carried out by a certified electrician.
Due to their technical training, knowledge and experience as well as their familiarity with
relevant standards and regulations, certified electricians are able to perform work on elec-
trical systems and independently detect possible dangers.
In Germany, certified electricians must fulfill the requirements of accident-prevention regu-
lations BGV A3 (e.g. electrician foreman). In other countries, there are respective regula-
tions that must be observed.
2.4 Exemption of liability
Leuze electronic GmbH + Co. KG is not liable in the following cases:
• The device is not being used properly.
• Reasonably foreseeable misuse is not taken into account.
• Mounting and electrical connection are not properly performed.
• Changes (e.g., constructional) are made to the device.
1) Use as safety-related component within the safety function is possible, if the component combination is designed
correspondingly by the machine manufacturer.
NOTE
Do not modify or otherwise interfere with the device!
Do not carry out modifications or otherwise interfere with the device.
The device must not be tampered with and must not be changed in any way.
The device must not be opened. There are no user-serviceable parts inside.
Repairs must only be performed by Leuze electronic GmbH + Co. KG.

Safety
Leuze electronic BCL 338i13
TNT 35/7-24V
2.5 Laser safety notices
ATTENTION, LASER RADIATION – LASER CLASS 2
Never look directly into the beam!
The device satisfies the requirements of IEC 60825-1:2007 (EN 60825-1:2007) safety
regulations for a product of laser class 2 as well as the U.S. 21 CFR 1040.10 regulations
with deviations corresponding to "Laser Notice No. 50" from June 24, 2007.
Never look directly into the laser beam or in the direction of reflected laser beams!
If you look into the beam path over a longer time period, there is a risk of injury to the
retina.
Do not point the laser beam of the device at persons!
Interrupt the laser beam using a non-transparent, non-reflective object if the laser
beam is accidentally directed towards a person.
When mounting and aligning the device, avoid reflections of the laser beam off reflec-
tive surfaces!
CAUTION! The use of operating or adjusting devices other than those specified here
or carrying out of differing procedures may lead to dangerous exposure to radiation.
Observe the applicable statutory and local laser protection regulations.
The device must not be tampered with and must not be changed in any way.
There are no user-serviceable parts inside the device.
Repairs must only be performed by Leuze electronic GmbH + Co. KG.
NOTE
Affix laser information and warning signs!
Laser warning and laser information signs are affixed to the device (see Figure 2.1):
In addition, self-adhesive laser warning and information signs (stick-on labels) are supplied
in several languages (see Figure 2.2).
Affix the laser information sheet to the device in the language appropriate for the place
of use.
When using the device in the U.S.A., use the stick-on label with the "Complies with
21 CFR 1040.10" notice.
Affix the laser information and warning signs near the device if no signs are attached
to the device (e.g., because the device is too small) or if the attached laser information
and warning signs are concealed due to the installation position.
Affix the laser information and warning signs so that they are legible without exposing
the reader to the laser radiation of the device or other optical radiation.

Safety
14 BCL 338iLeuze electronic
Figure 2.1: Laser apertures, laser warning signs
ALaser aperture
BLaser warning sign
CLaser information sign with laser
parameters
A
B
C
A
B
C
A
B
C
BCL 3xxiS/R1 … 102 (H) BCL 3xxiS/R1 … 100 (H)
BCL 3xxiO … 100 (H)

Safety
Leuze electronic BCL 338i15
TNT 35/7-24V
Figure 2.2:Laser warning and information signs – supplied stick-on labels
AVOID EXPOSURE – LASER RADIATION
IS EMITTED FROM THIS APERTURE
EXPOSITION DANGEREUSE – UN RAYONNEMENT
LASER EST ÉMIS PAR CETTE OUVERTURE
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
DIN EN 60825-1:2008-05
Max. Leistung (peak):
Impulsdauer:
Wellenlänge:
RADIAZIONE LASER
NON FISSARE IL FASCIO
APARRECCHIO LASER DI CLASSE 2
EN 60825-1:2007
Potenza max. (peak):
Durata dell'impulso:
Lunghezza d'onda:
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
EN 60825-1:2007
Maximum Output (peak):
Pulse duration:
Wavelength:
RAYONNEMENT LASER
NE PAS REGARDER DANS LE FAISCEAU
APPAREIL À LASER DE CLASSE 2
EN 60825-1:2007
Puissance max. (crête):
Durée d`impulsion:
Longueur d`onde:
RADIACIÓN LÁSER
NO MIRAR FIJAMENTE AL HAZ
PRODUCTO LÁSER DE CLASE 2
EN 60825-1:2007
Potencia máx. (peak):
Duración del impulso:
Longitud de onda:
RADIAÇÃO LASER
NÃO OLHAR FIXAMENTE O FEIXE
EQUIPAMENTO LASER CLASSE 2
EN 60825-1:2007
Potência máx. (peak):
Período de pulso:
Comprimento de onda:
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1:2007
Complies with 21 CFR 1040.10
Maximum Output (avg):
Pulse duration:
Wavelength:
䉏⏘戟⺓
▎䦃展⏘㧮
伊䉏⏘ℶ❐
GB7247.1-2012
㦏⮶戢⒉᧤⽿⋋᧥
厘⑁㖐兼㢅梃
㽱栎
1,8 mW
<150 μs
655 nm
1,8 mW
<150 μs
655 nm
1.8 mW
<150 μs
655 nm
1,8 mW
<150
μ s
655 nm
1,8 mW
<150 μs
655 nm
1,8 mW
<150 μs
655 nm
<1 mW
<150 μs
655 nm
1.8 mW
<150 μs
655 nm
50120562-02

Fast commissioning / operating principle
16 BCL 338iLeuze electronic
3 Fast commissioning / operating principle
Below you will find a short description for the initial commissioning of the BCL 338i. Detailed
explanations for all listed points can be found throughout this technical description.
3.1 Mounting the BCL 338i
The BCL 338ibar code readers can be mounted in two different ways:
• Via four M4x6 screws on the device bottom.
• Via a BT 56 mounting device in the fastening groove on the housing bottom.
3.2 Device arrangement and selection of the mounting location
In order to select the right mounting location, several factors must be considered:
• Size, orientation, and position tolerance of the bar codes on the objects to be scan-
ned.
• The reading field of the BCL 338iin relation to the bar code module width.
• The resulting minimum and maximum reading distance from the respective reading
field.
• The permissible cable lengths between the BCL 338iand the host system depending
on which interface is used.
• The correct time for data output. The BCL 338ishould be positioned in such a way
that, taking into consideration the time required for data processing and the conveyor
belt speed, there is sufficient time to e.g. initiate sorting operations on the basis of the
read data.
• The display and control panel should be very visible and accessible.
• For configuring and commissioning with the webConfig tool, the USB interface should
be easily accessible.
For specific information, please refer to Chapter 6 and Chapter 7.
Note!
The beam exits the BCL 338ias follows for the respective devices:
- line scanner parallel to the housing base
- deflecting mirror 105 degrees to the housing base
- oscillating mirror perpendicular to the housing base.
The black areas in Figure 6.2 are the housing base. The best read results are obtained
when:
•The BCL 338iis mounted in such a way that the scanning beam is incident on the bar
code at an angle of inclination greater than ±10° … 15° to vertical.
• The reading distance lies in the middle area of the reading field.
• The bar code labels are of good print quality and have good contrast ratios.
• You do not use high-gloss labels.
• There is no direct sunlight.

Fast commissioning / operating principle
Leuze electronic BCL 338i17
TNT 35/7-24V
3.3 BCL 338ielectrical connection
For the electrical connection of the BCL 338i, various connection variants are available.
The voltage supply (18 … 30VDC) is connected acc. to the connection type selected.
2 freely programmable switching inputs/outputs for individual adaptation to the respec-
tive application are also available here. Detailed information on this topic can be found in
Chapter 7.3.4.
MS 338 connector hood with 2 integrated M12 connectors
Figure 3.1: BCL 338i- MS 338 connection hood with M12 connectors
Note!
The shielding connection is done via the M12 connector housing.
Note!
The integrated parameter memory for the simple replacement of the BCL 338iis located in
the MS 338. In the integrated parameter memory, both the settings and the network address
are saved and transmitted to a new device.
Note!
In the case of EtherCAT line topology, the network is interrupted when the BCL 338i is remo-
ved from the MS 338.
PWR / SW IN/OUT
SWIO_2
SWIO_1
3
2
1
4
5
GNDIN VIN
FE
SERVICE
21354
GNDD+D-VB ID
BUS OUTHOST / BUS IN
TD+ 1
2
3
4
RD+
RD-
TD- TD+ 1
2
3
4
RD+
RD-
TD-
Mini-B USB socket
(behind protective cap)
M12 plug
(A-coded)
M12 socket
(D-coded)
ETHERCAT IN
M12 socket
(D-coded)
ETHERCAT OUT
Connector hood
MS 338
ETHERCAT OUT LED
(split, two-colored):
ACT1 / LINK1
ETHERCAT IN LED
(split, two-colored):
ACT0 / LINK0

Fast commissioning / operating principle
18 BCL 338iLeuze electronic
ME 338 103 connection hood with M12 connection cables
Figure 3.2: BCL 338i- ME 338 103 connection hood with M12 connection cables
Note!
The shielding connection is done via the M12 connector housing.
Note!
The integrated parameter memory for the simple replacement of the BCL 338iis located in
the ME 338 103. In the integrated parameter memory, both the settings and the network
address are saved and transmitted to a new device.
Note!
In the case of EtherCAT line topology, the network is interrupted when the BCL 338i is re-
moved from the ME 338 103.
PWR
SWIO_2
SWIO_1
3
2
1
4
5
GNDIN VIN
FE
Seal Plug
not connected
SERVICE
21345
GNDDIBV-D+D
HOST / BUS IN
TD+ 1
2
3
4
RD+
RD-
TD-
BUS OUT
TD+ 1
2
3
4
RD+
RD-
TD-
Mini-B USB socket
(behind protective cap)
M12 plug
(A-coded)
ETHERCAT IN
M12 socket
(D-coded)
ETHERCAT OUT
M12 socket
(D-coded)
Connection hood
ME 338 103
ETHERCAT OUT
LED (split, two-colored):
ACT1 / LINK1
ETHERCAT IN
LED (split, two-colored):
ACT0 / LINK0
①
②
③
④
⑤
Dummy plug
①
②
③
④
⑤
