LevelOne HUBBLE Series User guide

HUBBLE series NVR
System Administrator’s Manual
For V5.02.01 Firmware

HUBBLE series System Administrator’s Manual
2
Legal Notice
Disclaimer
⚫ The information contained in this document is intended for general information purposes.
Digital Data Communications GmbH Corporation shall not be liable for errors contained
herein or for incidental or consequential damages arising from the furnishing, performance,
or use of this manual.
⚫ The information contained herein is subject to change without notice.
⚫ The English version of this document is the official one for all purpose. All the translated
versions are provided as a convenience. Any discrepancies or differences created in the
translations of any other languages are not legally binding.
⚫ Microsoft® and Windows® are registered trademarks of Microsoft Corporation.
All other product or company names mentioned in this document may be trademarks or
registered trademarks of their respective owners.

HUBBLE series System Administrator’s Manual
3
Regulatory Compliance Information
Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to the equipment that are not expressly approved by
the responsible party for compliance could void the user’s authority to operate the equipment.
European Community Compliance Statement
This product has been tested and found to comply with the limits for
Class B Information Technology Equipment according to European
Standard EN 55022 and EN 55024. In a domestic environment, this
product may cause radio interference in which cause the user be
require to take adequate measures.

HUBBLE series System Administrator’s Manual
4
About This Manual
Target Audience
This manual is intended for System Administrators who are responsible for installing and
setting up video surveillance system. The reader is expected to know the fundamentals of IP
surveillance system integration and to own the administrative privileges to install and
configure all the devices.
Technical Support
If you have any questions during system installation, please feel free to contact our engineers
via our mail [e-mail]

HUBBLE series System Administrator’s Manual
5
TABLE OF CONTENTS
Legal Notice ......................................................................................... 2
About This Manual .............................................................................. 4
1Introduction 9
Product Overview ................................................................................ 9
NVR Server / Client Architecture ............................................9
Remote Client PC Requirements..........................................10
Supported Video Format .......................................................11
Installation......................................................................................... 12
Prepare the Devices ..............................................................12
Network Connection Architecture ........................................14
LAN Port .............................................................................................14
WAN Port ............................................................................................15
2Local Client Operations 16
Log in to / out of NVR ........................................................................ 16
Log In......................................................................................16
Log Out...................................................................................16
Input Devices .........................................................................17
Onscreen Keyboard ............................................................................17
Onscreen Keyboard Settings ..............................................................17
Quick Setup............................................................................18
Step 1: Log in to NVR .........................................................................18
Step 2: Format the Hard Disks ...........................................................18
Step 3: Add Devices............................................................................19
Live Page Overview............................................................................ 20
Customize Live Screen Layout.............................................21
Change Channel Position ...................................................................22
Change Layout....................................................................................23
Manage Device Live View .....................................................24
Quick Playback ...................................................................................25

HUBBLE series System Administrator’s Manual
6
Optical PTZ .........................................................................................26
Manage Devices................................................................................. 27
Cameras .................................................................................27
Add Cameras ......................................................................................28
Add Cameras Manually ................................................................29
Add Cameras by RTSP ................................................................30
Delete Cameras ..................................................................................31
Change Camera Settings....................................................................31
Video Settings ..............................................................................32
Motion Setup ................................................................................33
Point-of-Sales (POS) System................................................34
Add POS .............................................................................................34
Change POS Settings.........................................................................35
Configure POS Event and Schedule ..................................................35
Set Event Rules ...........................................................................36
Delete POS .........................................................................................36
Parking System......................................................................37
Add Parking System ...........................................................................37
Change Parking System Settings .......................................................38
Configure Parking System Event and Schedule.................................39
Set Event Rules ...........................................................................39
Delete Parking System .......................................................................40
Network Input Output Module ..............................................41
Add Network DIO ................................................................................41
Change Network DIO Settings............................................................42
Configure Network IO Event and Schedule ........................................43
Set Event Rules ...........................................................................43
Delete Network DIO ............................................................................44
Access Control ......................................................................45
Add Access Control Device ................................................................45
Change Access Control Settings ........................................................46
Basic.............................................................................................46
Devices.........................................................................................47
Management ................................................................................48
User..............................................................................................50
Time Period ..................................................................................51
Configure Access Control Event and Schedule ..................................52
Set Event Rules ...........................................................................52

HUBBLE series System Administrator’s Manual
7
Delete Access Control Device ............................................................53
Schedule Recordings .......................................................................... 54
Event-Recording File Length ................................................55
Set the Recording Schedule .................................................55
Set the Event Schedule .........................................................56
Event Management............................................................................ 57
Event-Handling Schedule .....................................................57
Set Event Rules .....................................................................58
Beep....................................................................................................58
PTZ .....................................................................................................59
Digital Output (DO) .............................................................................59
Email ...................................................................................................60
URL.....................................................................................................60
ANS.....................................................................................................61
Clear Event Rules ..................................................................61
Playback Recording............................................................................ 62
Playback User Interface ........................................................62
Playback Video ......................................................................63
Search by Time ...................................................................................63
Search by Event..................................................................................64
Export Video ..........................................................................64
System Setup ..................................................................................... 65
System....................................................................................65
Device Information ..............................................................................65
Date & Time ........................................................................................66
Setup Manually ............................................................................66
Synchronize with Time Zone ........................................................66
Synchronize with NTP server .......................................................66
COM Port Settings ..............................................................................67
E-mail Settings....................................................................................68
System Event......................................................................................70
Local DIO ............................................................................................71
Local Audio Setup ...............................................................................72
Network Settings ...................................................................73
Ethernet Settings ................................................................................74
Web Port Setting .................................................................................75

HUBBLE series System Administrator’s Manual
8
Enable DHCP Server ..........................................................................76
Enable DDNS Service.........................................................................77
Enable ANS Service............................................................................78
Enable Network Address Translation (NAT) .......................................79
Power over Ethernet (PoE) .................................................................80
Storage Settings ....................................................................81
Storage Management .........................................................................81
Format Hard Disks .......................................................................82
Disk Deletion ................................................................................82
Check Disk Status ........................................................................82
iSCSI...................................................................................................83
Network Neighborhood .......................................................................84
NFS Server .........................................................................................84
Controller ...............................................................................85
Software Keyboard .............................................................................85
Joystick ...............................................................................................85
User Management..................................................................86
Add a Group........................................................................................86
Add a User ..........................................................................................87
Edit a User ..........................................................................................88
Delete a User ......................................................................................88
Maintenance...........................................................................89
Firmware Upgrade ..............................................................................89
Backup / Restore Settings ..................................................................90
Backup .........................................................................................90
Restore.........................................................................................91
Troubleshooting ..................................................................................91
Factory Default....................................................................................92
Log..........................................................................................92

HUBBLE series System Administrator’s Manual
9
Introduction
Product Overview
Levelone HUBBLE series (hereafter referred to as NVR) is a compact and reliable
multi-channel standalone NVR. It features a stable embedded Linux operating system and
capabilities of supporting mega-pixel resolution H.265 or H.264 streaming, an HDMI output
for local display, PTZ control, scheduled / event-triggered / event speed-up recording, event
management, synchronized playback, time / event-based playback search and video
bookmarks. Its intuitive user interface allows the system installer to enjoy effortless
installation experience, while making it easy for new users to get acquainted with the
operation by first-time use. Other than the local client, the remote PC client may access the
NVR system simultaneously, and experience user-friendly web interface customized for
browser-based operations.
NVR Server / Client Architecture
In a video surveillance system architecture, NVR serves as service provider, aimed to run
24/7 non-stop video management service for clients. An NVR client makes requests for
monitoring video stream or playing back recordings from NVR.
There are two types of NVR clients: Local Client and Remote Client.A client, connecting
from whether a remote computer or from local, will be offered the same functionalities of
NVR.
⚫Local Client: In the local site, the client user directly operates NVR by connecting an HDMI
monitor and a USB mouse to the physical NVR.
⚫Remote Client: Over the TCP/IP network, the Remote Client communicates with NVR
through HTTP Protocol. This client user will have to use a computer with Internet Explorer
to access the NVR web interface, without the need of installing any client program
beforehand. Logging in to NVR is as simple as visiting a website.

HUBBLE series System Administrator’s Manual
10
Remote Client PC Requirements
As NVR itself is a self-contained unit, the table below provides basic guidelines only for
selecting proper hardware for the remote PC client. If your live view display quality is not
satisfactory, please consider computers with more advanced spec as the decoding of
multiple channels requires good hardware for smooth performance (*1).
*1 The quality of video display performance lies not only in the hardware but a few variables.
Please refer to Supported Video Format on page 11 for instructions on how to achieve
ideal video performance.
*2 PC spec requirements are the same for 32-bit and 64-bit systems.
*3 Microsoft Windows operating system has limits on memory and address space,
regardless of the real or virtual memory available on a particular computer.
Please use 64-bit system if your computer has more than 4GB RAM.
*4 Please make sure your operating system is fully patched with the latest service packs.
PC Spec (*2)
Minimum Requirements
CPU Processor
Intel Core i3-3250 @ 3.50 Ghz
RAM
4GB (*3)
Network
Ethernet (1000 Base-T recommended)
Operating System
Windows 7, Windows 8, Windows 10
(All versions) (*4)
Display Resolution
1080p
Browser
Internet Explorer 11
