LevelOne FVT-2202 User manual

Copper to Fiber
Stand-Alone Media Converter
Quick Installation Guide
Model
No.
Description
FVT-2001
RJ45 to SC Fast Ethernet Media Converter,
Multi-Mode Fiber, 2km
FVT-2002
RJ45 to ST Fast Ethernet Media Converter,
Multi-Mode Fiber, 2km
FVT-2201
RJ45 to SC Fast Ethernet Media Converter,
Single-Mode Fiber, 20km
FVT-2202
RJ45 to SC BIDI Fast Ethernet Media Converter
Set, Single-Mode Fiber, 20km
FVT-2401
RJ45 to SC Fast Ethernet Media Converter,
Single-Mode Fiber, 40km
GVT-2000
RJ45 to SFP Gigabit Media Converter
GVT-2001
RJ45 to SC Gigabit Media Converter, Multi-Mode
Fiber, 550m
GVT-2002
RJ45 to SC Gigabit Media Converter, Single-Mode
Fiber, 20km
Ver. 1.4 - 1910

Table of Contents
1. INTRODUCTION...................................................1
1.1. FEATURES............................................................1
1.2. PACKAGE CONTENTS........................................... 2
2. HARDWARE DESCRIPTION ..............................3
2.1. FRONT PANEL......................................................3
2.2. REAR PANEL........................................................4
2.3. LED INDICATORS ................................................5
2.4. DIP-SWITCH......................................................... 7
3. CABLING ................................................................9
4. SPECIFICATION ................................................. 11
5. OPTIONAL SFP MODULES............................... 13

1
1. Introduction
LevelOne media converters are Fast Ethernet 10/100Base-TX to
100Base-FX and 10/100/1000Base-T to 1000Base-SX/LX
converters to provide the flexibility required in network integration.
The TX port auto-sense connection speed, auto-negotiates half/full
duplex modes and auto-selects MDIX media type. The fiber
connectors come with multimode or singlemode, SC, ST or SFP
connector to provide necessary connection interface and distance
capabilities.
LevelOne have designed 19” racks to organize media converters the
smart way by providing a single power supply. With the
Plug-and-play technology, the converter is easy to set-up and run.
For simple, cost-effective network design, LevelOne converter
series is the perfect solution to bridge the complex network
infrastructure.
1.1. Features
Fast Ethernet Module
▪Comply with IEEE 802.3, 802.3u and 802.3x standards.
▪Convert between UTP cabling and Fiber-optic cabling.
▪One RJ-45 connector, Auto-MDI/MDIX for UTP port.
▪Support 10/100 Mbps Auto-negotiation for UTP port.
▪Fiber cabling connectivity up to 40Km.
▪Store-and-forward switching to separate two collision domains.
▪One fiber connector (SC/ ST) for 100Base-FX.
▪6 DIP-switches to set the operation mode
▪Link- Lost-Forwarding function.

2
Gigabit Ethernet Module
▪Comply with IEEE 802.3, 802.3u and 802.3x, IEEE 802.3ab
1000BaseT, 802.3z 1000Base SX/LX standards.
▪Convert between UTP cabling and Fiber-optic cabling.
▪One RJ-45 connector, Auto-MDI/MDIX for UTP port.
▪Support 10/100/1000 Mbps Auto-negotiation for UTP port
▪Fiber cabling connectivity up to 80Km.
▪Store-and-forward switching to separate two collision domains.
▪One fiber connector (SC / SFP) for 1000Base-SX/LX
▪DIP-switches to set the operation mode function.
▪Link- Lost-Forwarding function.
1.2. Package Contents
- Stand-alone Media Converter
- Power Adapter (10/100M 5V,1A; 10/100/1000M 5V,2A)
- User Manual
Compare the contents of your converter module with the checklist
above. If any item is damaged or missing, please contact your local
dealer for service.

3
2. Hardware Description
2.1. Front Panel
FVT-2001 / FVT-2002 / FVT-2201 / FVT-2401
GVT-2000
GVT-2001
(1) RJ-45 Port (3) Fiber/SFP Connector
(2) LED Indicators (4) DIP-Switch
3
2
1
4

4
2.2. Rear Panel
Power Adapter: (10/100M DC 5V, 1A; 10/100/1000M DC 5V, 2A)
The rear panel contains a power socket. This power socket accepts
DC 5V voltage and minimum 1A & 2A supplied current.
4

5
2.3. LED Indicators
Fast Ethernet Module
LED
Status
Meaning
PWR
On
Power on
FX 100
On
100Mbps Fiber Speed
TX 100
On
100Mbps UTP Speed
OFF
10 Mbps UTP Speed
FDX
On
Converter works in the full duplex mode
OFF
Converter works in the half duplex mode
FX
LINK/ACT
On
Connection status display for fiber link.
“ON”indicates that Fiber link is in correct
connection.
Blinks
Active status display of fiber link
“Blink”indicates packet goes through FX end.
TX
LINK/ACT
On
Connection status display for electric link.
“ON”indicates that electric link is in correct
connection.
Blinks
Active status display of fiber link
“Blink”indicates packet goes through TX end

6
Gigabit Ethernet Module
LED
Status
Meaning
PWR
On
Power on
1000
On
1000Mbps UTP Speed
100
On
100Mbps UTP Speed
FDX
On
Converter works in the full duplex mode
Off
Converter works in the half duplex mode
LINK/ACT
(UTP)
Blinks
Active status display of electrical interface link
Blink” indicates packet goes through TP
LNK/ACT
(Fiber)
Blinks
Active status display of fiber interface link
“Blink” indicates packet goes through FX
Note: The UTP port speed is 10Mbps when both 100 and 1000 LED indicators
"OFF"

7
DIP-switch
The DIP-switch is used to configure operation mode for LLF (Link
Lost Forwarding) and operation mode for UTP/Fiber port. The
default value of DIPswitch is OFF.
Fast Ethernet Module
No
Status
Description
1
ON
LFP is Enable
OFF
LFP is Disable
2
ON
Flow Conntrol Enable
OFF
Flow Conntrol Disable
Gigabit Ethernet Module
No
Status
Description
1
ON
LFP is Enable
OFF
LFP is Disable
2
ON
Flow Conntrol Enable
OFF
Flow Conntrol Disable

8
Link Lost Forwarding:
When LLF is enable, allow UTP link failures to be reported to the
fiber side and also allow Fiber link failure to be reported to the UTP
side. Therefore, A link loss forward feature is provided in both UTP
and Fiber side.
Pure Converter mode (Gigabit Ethernet Module):
When pure converter mode is enabling (on), it operates with the
minimum latency. The transmission flow does not wait until entire
frame is ready, but instead it forwards the received data immediately
after the data being received. And TP port should be forced at1000M
in this application. When DIP-Switch is in Switch Converter mode
(off), the converter function is same as Switch Hub.
Note:
Please don’t change the DIP-switch setting when UTP or fiber port is
transmitting or receiving data. It may cause some data error.

9
3. Cabling
Fast Ethernet Module
▪Twisted-pair segment can be use unshielded twisted pair (UTP)
or shielded twisted pair (STP) cabling. The cable must comply
with the IEEE 802.3u 100Base TX standard for Category 5. The
cable between the converter and the link partner (switch, hub,
workstation, etc.) must be less than 100 meters (328 ft.) long.
▪Fiber segment using multi-mode connector type must use 50 or
62.5/125 um multi-mode fiber cable. You can connect two
devices up to a 2-kilometer (6,562 ft.) distance.
▪Fiber segment using single-mode connector type must use
8/125 or 9/125 um single-mode fiber cable. You can connect two
devices in the distance of 40 Kilometers in full duplex operation.
For half-duplex operation, the recommended maximum distance
is 412 meters (1,352 ft.)
Gigabit Ethernet Module
▪Using four twisted-pair, Category 5 cabling for RJ-45 port
connection. The cable between the converter and the link
partner (switch, hub, workstation, etc.) must be less than 100
meters (328 ft.) long.
▪Fiber segment using multi-mode connector type must use 50 or
62.5/125 um multi-mode fiber cable. You can connect two
devices up to 550m distances.
▪Fiber segment using single-mode connector type must use
8/125 or 9/125 um single-mode fiber cable. You can connect two
devices in the distance of 80 Kilometers in full duplex operation.
For half-duplex operation, the recommended maximum distance
is 412 meters (1,352 ft.)

10
Optical Fiber
Module Name
Wavelength
Avg. Launch
Power
Avg.
Sensitivity
100Base-FX Fiber SC MM
1310 (nm)
>-21dBm
-31dBm
100Base-FX Fiber ST MM
1310 (nm)
>-21dBm
-31dBm
100Base-FX Fiber SC SM
20KM
1310 (nm)
>-15dBm
-34dBm
100Base-FX Fiber SC SM
40KM
1310 (nm)
>-10dBm
-37dBm
1000Base-SX Fiber SC MM
850 (nm)
>-10.5dBm
-20dBm
Module Name
Avg. Power
Loss Budget
Max. FDX
Fiber
Distance
Fiber Size (um)
100Base-FX Fiber SC MM
10 (dBm)
2 (Km)
62.5/125
50/125
100Base-FX Fiber ST MM
10 (dBm)
2 (Km)
62.5/125
50/125
100Base-FX Fiber SC SM
19 (dBm)
20(Km)
9/125
8/125
100Base-FX Fiber SC SM
27 (dBm)
40(Km)
9/125
8/125
1000Base-SX Fiber SC MM
9.5 (dBm)
550 (m)
62.5/125
50/125

11
4. Specification
Fast Ethernet Module
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX/100BASE-FX
IEEE802.3x Flow Control and Back pressure
Connector
Fiber: Duplex ST/SC
RJ-45 Socket: CAT-3/5 (10/100Mbps)
Twisted Pair cable, Auto MDI/MDI-X, Auto-Negotiation
Switch
architecture
Store and Forward
Fiber
parameters
Fiber Core: Multi-Mode (62.5/125um, 50/125um)
Single-Mode (8/125um, 9/125um)
Wavelength: 1310nm(Multi-mode)
1310nm(Single-mode)
Fiber Distance: Multi-Mode Fiber 2KM
Single-Mode Fiber (20KM or 40KM)
Transparent
packet
64 to 1600 Bytes for Non-VLAN Ethernet packet
Link Fault
Pass through
UTP➔Fiber: If UTP port link down, then converter will forced
fiber to link down.
Fiber ➔UTP: If Fiber port link down, the media converter will
force UTP port to link down.
DIP Switch
DIP Switch 1: LFP function
DIP Switch 2: Transmission Mode
DIP Switch 3: Auto/Force the UTP port work mode
DIP Switch 4: 10/100M for UTP port
DIP Switch 5: Full/Half Duplex mode for UTP port
DIP Switch 6: Normally close
LED
Power, UTP (100Mbps, LINK/ACT, FDX)
Fiber (LINK/ACT, 100Mbps)
Power
DC5V / 1A
Dimension
71mm x 94mm x 26mm
EMI & safety
CE, FCC Class A

12
Gigabit Ethernet Module
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE 802.3ab 1000BaseT
IEEE 802.3z 1000BaseSX/LX standards
IEEE802.3x Flow Control and Back pressure
Connector
Fiber: SC / SFP
RJ-45 Socket: CAT-5 (10/100/1000Mbps or pure 1000Mbps)
Twisted Pair cable, Auto MDI/MDI-X, Auto-Negotiation
Switch
architecture
Store and Forward
Fiber
parameters
Fiber Core: Multi-Mode (62.5/125um, 50/125um)
Wavelength: 850nm(Multi-mode)
Fiber Distance: 550M (Multi-Mode Fiber)
Transparent
packet
64 to 9000 Bytes for Ethernet packet
Link Lost
Forward
UTP➔Fiber: If UTP port link down, then converter will forced
fiber to link down.
Fiber ➔UTP: If Fiber port link down, the media converter will
force UTP port to link down.
DIP Switch
DIP Switch 1: LFP function
DIP Switch 2 and 3 performance 4 types work mode
DIP Switch 2 and 3 is OFF = Store and forward
DIP Switch 2 is OFF, 3 is ON = Cut through mode
DIP Switch 2 is ON, 3 is OFF = Smart pass through
DIP Switch 2 and 3 is ON = Pass through mode
LED
Power, UTP (LINK/ACT, 100Mbps, 1000Mbps, FDX)
Fiber (LINK/ACT)
Power
DC5V / 2A
Dimension
71mm x 94mm x 26mm
EMI & safety
CE, FCC Class A

13
5. Optional SFP Modules
CVH-2000 supports 3.3V mini-GBIC module
Model No.
Description
GVT-0300
1.25G MMF SFP Transceiver, 550 m, 850nm
GVT-0301
1.25G SMF SFP Transceiver, 10 km, 1310nm
GVT-0302
1.25G SMF SFP Transceiver, 80 km, 1550nm
