LevelOne FCS-3102 User manual

Network Camera User’s Manual
1/59
FCS-3102
Dome Network Camera
2-Megapixel, Outdoor, PoE 802.3af,
Day & Night, IR LEDs, WDR, 3DNR
User Manual
Version 1.0

Network Camera User’s Manual
2/59
Table of Contents
Overview...............................................................................................................3
Package Contents.................................................................................................4
Connections..........................................................................................................5
Hardware description.....................................................................................5
Hardware Installation............................................................................................7
Connect to the Network Camera.........................................................................10
Install the IP Finder program........................................................................10
Bonjour program..........................................................................................17
C2.mylevel1.com(Free DDNS service)........................................................18
Initial Access to the Network Camera.................................................................19
Primary user’s capability .....................................................................................20
Main Screen with Camera View...................................................................20
Client Setting ...............................................................................................23
Definitions in Configuration.................................................................................25
System parameters.............................................................................................25
Security...............................................................................................................27
Network...............................................................................................................29
Access list...........................................................................................................32
Audio and Video setting......................................................................................35
Video record .......................................................................................................39
Stream................................................................................................................41
Application..........................................................................................................43
Storage...............................................................................................................46
Syslog.................................................................................................................48
Status and Parameters.......................................................................................48
Maintenance .......................................................................................................50
Appendix.............................................................................................................52
A. Troubleshooting & Frequently Asked Questions......................................52
B. Technical specifications...........................................................................58
Default Settings
IP Address
DHCP
Username
root
Password

Network Camera User’s Manual
3/59
Overview
FCS-3102 is a Dome network camera.
Law in your country may prohibit the use of surveillance devices. The Network Camera
is not only a high-performance web-ready camera but also can be part of a flexible
surveillance system. It is the user’s responsibility to ensure that the operation of such
devices is legal before installing this unit for its intended use.
It is important to first verify that all contents received are complete according to the list in
the "Package Contents" chapter. Take notice of the warnings in “Quick installation guide”
before the Network Camera is installed, then carefully read and follow the instructions in
the “Installation” chapter to avoid damages due to faulty assembly and installation. This
also ensures the product is used properly as intended.
The Network Camera is accessible via the LAN or Internet connection. Connect your
Network Camera directly to a computer network or DSL modem, and with a standard
Web browser you get instant, on demand video streams. Within minutes you can set up
the Network Camera to capture a video sequence to a PC. Live video image can be
uploaded to a website for the world to see or made available only to select users on the
network.
The Network Camera is a network device and its use should be straightforward for those
who have basic network knowledge.
The Network Camera is designed for various applications including video sharing,
general security/surveillance, etc. The “How to Use” chapter suggests ways to best
utilize the Network Camera and ensure proper operations.
Minimum System Requirement
Dome Network Camera
2-Megapixel, Outdoor, PoE 802.3af, Day & Night, IR LEDs, WDR, 3DNR
Network Environment
LAN
10/100M Ethernet
Monitoring System Recommended for Internet Explorer
System Hardware
Basic requirements
·CPU: Intel® Celeron® Dual-Core @2.70GHz or above
·Memory Size: 2 GB or above Recommended
·VGA card resolution: 1024 x 768 or above
System Requirement for Viewer & Recorder Application
Support OS
XP, Windows 7
System Hardware
1-4 cameras surveillance application
·CPU: Intel® Celeron® Dual-Core @ 2.70GHz or above
·Memory Size: 2 GB or above
·VGA card resolution: 1024 x 768 or above

Network Camera User’s Manual
4/59
Package Contents
If any of the above items are missing, please contact your dealer immediately.
Note:Using a power supply with a different voltage than the one included with the
Network Camera will cause damage and void the warranty for this product.
Network Camera (Wired or PoE)
Software CD
Power adapter
Quick installation guide
Screws
Moisture Absorber/RJ45 Female

Network Camera User’s Manual
5/59
Connections
Hardware description
Outer View
Inner View

Network Camera User’s Manual
6/59
In the beginning when the camera is installed, you can use the tool kit to open the cover,
in addition to the SD card can be inserted to prevent the use of fogging, Dry pack Ruoyi
torn bags, placed in the air for too long will lose effect. Please lock the top cover as soon
as possible.
If the camera has not been installed at the beginning adhesive dry pack, fog occurs after
a period of time so that when the image is not clear, then please do not cut off the power,
The camera cover is open from about 5 to 10 minutes, and after the image is completely
restored Explicit, and then stick in the dry pack camera, and you can lock the cover.

Network Camera User’s Manual
7/59
Hardware Installation
1. Attach the Network Camera with the included stand
2. Place the Camera fix it onto ceiling or wall
Use screws to fix the Network Camera onto the ceiling or wall.

Network Camera User’s Manual
8/59

Network Camera User’s Manual
9/59
3. Power over Ethernet (PoE)
Using a PoE-enabled switch
The Network Camera is PoE-compliant, allowing transmission of power and data via a
single Ethernet cable. Follow the below illustration to connect the Network Camera to a
PoE-enabled switch via Ethernet cable.
Using a non-PoE switch
Use a PoE power injector (optional) to connect between the Network Camera and a
non-PoE switch

Network Camera User’s Manual
10/59
Connect to the Network Camera
Install the IP Finder program
When you installed your Network camera on your LAN environment, you may install “IP
Finder” to discover Network camera’s IP address. The Administrator must place the
product software CD into the CD-ROM drive of the PC running in Microsoft Windows. An
auto-run program will pop up (If the program is not on auto-run, go to the root directory
of the software CD and click on “autorun.exe”).
Click on “Software Utility” item, after the window contents changed, click on “Install IP
Finder” to run “IP Finder” program.

Network Camera User’s Manual
11/59
“IP Finder” is used to search the IP address of Network Cameras or Video
servers on a LAN. After searching, Video Servers or Network Cameras will be
located by the IP Finder.

Network Camera User’s Manual
12/59
Search Camera
Click search Camera button, The program will search for all family network
devices on the same LAN. After searching, the main installer window will pop up.
Click on the MAC and model name which matches the product label on your
device to connect to the Network Camera via Internet Explorer.

Network Camera User’s Manual
13/59
Setup Camera
Auto Install Wizard will be started and that it can auto guide through the
installation process. Press the “Next” button execute next process. For more
information, please refer to the Network section on page 33.

Network Camera User’s Manual
14/59

Network Camera User’s Manual
15/59

Network Camera User’s Manual
16/59

Network Camera User’s Manual
17/59
Bonjour program
Safari browser supports Bonjour search program the will search for all family network
devices on the same LAN.

Network Camera User’s Manual
18/59
C2.mylevel1.com(Free DDNS service)
1. When you want to connect the network camera over Internet, you can use the
service “C2.mylevel1.com”. The “ip-discovery.com” is a free DDNS server for
this camera. Make sure that the router must start UPnP and DHCP server
functions. You can get the domain name which you wish very easily after
registration. In Network page—DDNS settings of this camera, you just input the
host name you want and your e-mail address, and click “Register”, then you can
have the hostname for this camera not longer than 20 seconds if the DDNS
registration result is OK. Then you can connect to this ip camera by
*http://XXX.c2.mylevel1.com:@@@@
*XXX: the host name you type
*@@@@: The HTTP port (get it automatically by c2.mylevel1 server)
User password: Default the password is last six number of the MAC. To change
“root” password at “Security configuration” can change the user password, This
“User password” is entered in the c2.mylevel1.com Password.
Note: You must set the ports between your router and camera manually if the registration
is failed.

Network Camera User’s Manual
19/59
Initial Access to the Network Camera
(1) For the initial access to the Network Camera in Windows, the web browser may
prompt for permission to install a new plug-in for the Network Camera. This plug-in
has been registered for certificate and is used to display the video in the browser.
Users may click on to proceed.
1. Click “Install” and “Run” ActiveX controls
2.The video will be displayed.

Network Camera User’s Manual
20/59
Primary user’s capability
Main Screen with Camera View
The main page has three parts:
1. Configuration functions: The camera can be configured using these user
interfaces.
2. Connection control buttons: These buttons provide the remote and local
switching stream.
3. Camera View: What the camera sees.
Click the configuration in the bottom of left column to link to the configuration page.
Configuration functions:
“ePTZ Settings“ Electronic pan/tilt/zoom capabilities that enable users to move to a
target region instantly for close-up shots by simply clicking on the video feeds on their
screen rather than moving the camera physically.
“Client Settings” Clicking on this button links you to the client setting pages, please
check the following session for more details.
“Configuration” Please notes that only the administrator can access it.
“ Language” Click this button to choose a language for the user interface.
Language options are available in: English, traditional Chinese, Simplified Chinese,
Japanese, Spanish, Portuguese, French, German, Italiano.
Camera view:
On the top of image shows the connecting type of the Network Camera and the current
date/time.
