LevelOne FCS-5041 User manual

LevelOne
User Manual
FCS-5041
Day/Night H.264
Megapixel PoE Outdoor
Network Camera
Ver 1.1

Product name:
Day/Night H.264 Megapixel PoE Outdoor
Network Camera (FCS-5041)
Release Date: 2013/01/29
Manual Revision:
V1.1
Firmware 1.1.8.3
Web site:
www.level1.com
Default Settings
IPAddress
DHCP
Username
admin
Password
admin
General Public License
This product incorporates open source code into the software and therefore falls under the
guidelines governed by the General Public License (GPL) agreement.
Adhering to the GPL requirements, the open source code and open source license for the
source code are available for free download at http://global.level1.com.
If you would like a copy of the GPL or other open source code in this software on a
physical CD medium, LevelOne (Digital Data Communications) offers to mail this CD to
you upon request, for a price of US$9.99 plus the cost of shipping.

3 3
Table of Contents
Before You Use This Product..............................................................................5
Package Contents ............................................................................................6
Overview........................................................................................................7
Device Appearance Description..........................................................................8
LED Behavior.............................................................................................9
Extension I/O Terminal Block.......................................................................9
Hardware Reset............................................................................................. 11
Installation ................................................................................................... 12
Hardware installation................................................................................ 12
System Requirements............................................................................... 13
Camera Connection .................................................................................. 14
Software Installation ................................................................................ 16
Access to the Network Camera........................................................................ 24
Check Network Settings............................................................................ 24
Add Password to prevent Unauthorized Access............................................. 24
Authentication ......................................................................................... 25
Installing plug-in...................................................................................... 25
Live View...................................................................................................... 27
Configuration ................................................................................................ 30
Camera/Video/Audio................................................................................. 30
Camera ............................................................................................. 30
Video ................................................................................................ 34
Audio ................................................................................................ 37
Network.................................................................................................. 38
IP Settings......................................................................................... 38
UPnP................................................................................................. 39
DDNS (dynamic domain name service).................................................. 39
HTTP/HTTPS....................................................................................... 41
Multicast............................................................................................ 42
EasyLink............................................................................................ 43
Event...................................................................................................... 44
Event Settings.................................................................................... 44
Motion Detection ................................................................................ 49
Digital Input (DI)................................................................................ 50
Notifications ............................................................................................ 51
FTP Settings ...................................................................................... 51
E-mail Settings................................................................................... 52
Samba Settings.................................................................................. 53
HTTP Settings .................................................................................... 53
Digital Output (DO)............................................................................. 54
Video Clip.......................................................................................... 55
Maintenance............................................................................................ 56
Language .......................................................................................... 56
User Management............................................................................... 56
IP Filter ............................................................................................. 57
Firmware Upgrade .............................................................................. 57
Configuration ..................................................................................... 58
Reset to Default ................................................................................. 59
Reboot .............................................................................................. 59
System ................................................................................................... 60
System Log........................................................................................ 60

4 4
Date and Time ................................................................................... 61
Save File Folder.................................................................................. 62
Device Information ............................................................................. 63

5 5
Before You Use This Product
The use of surveillance devices may be prohibited by law in your country. The Network
Camera is not only a high-performance web-ready camera but also can be part of a
flexible surveillance system. It is the user’s responsibility to ensure that the operation of
such devices is legal before installing this unit for its intended use.
It is important to first verify that all contents received are complete according to the list in
the "Package Contents" chapter.
Take notice of the warnings in “Quick installation guide” before the Network Camera is
installed, then carefully read and follow the instructions in the “Installation” chapter to
avoid damages due to faulty assembly and installation.

6 6
Package Contents
Camera
Bracket
CD Manual/utility
QIG
Power Adapter

7 7
Overview
The FCS-5041 is an outdoor bullet network camera. It adopts a megapixel sensor which
allows the camera to deliver extremely clear and detailed images that CCTV cameras
cannot offer. To optimize use of the megapixel resolution, the FCS-5041 uses efficient
H.264/ MJPEG/ MPEG-4 codec compression to deliver dual configurable video streams
simultaneously at up to 30 fps. These features make this series the perfect outdoor
camera for neighborhood, school campus, and parking lot surveillance.
The FCS-5041 has many user friendly features, such as the smart focus capability which
allows users to configure settings for excellent image quality without difficult procedures.
Support for Power over Ethernet enables the camera to use the same cable for power and
data transmission, eliminating the need to install an external power supply.
It provides a USB connector for option support WUA-5600 which is a 150Mbps NWireless
High Power Outdoor USB Adapter with 7dBi antenna. Installation will not be restricted by
location or landforms. The FCS-5041+WUA-5600 high power wireless solution can be set
within any wireless coverage.
With an IP67 certified outdoor enclosure, the FCS-5041 is not only weather proof, but also
dust and rust resistant. By utilizing a built-in industrial fan and heater, it can perform well
in extreme environments.

8 8
Device Appearance Description

9 9
LED Behavior
Function
LED Behavior
Description
Remark
Link
Blinking
Blinking while
connecting to
the network
Rear Left
(Orange)
Link
Unlit
No connection
Rear Left
(Orange)
Power
Continuous Illumination
Normal
Operation
Rear Right
(Green)
Power
Unlit
Power off
Rear Right
(Green)
Extension I/O Terminal Block
The Network Camera provides an extension I/O terminal block which is used to connect the
camera with external input/output devices. The pin definitions are listed as below.
Pin
Function
1
Power +4.5V
2
Digital Output
3
Digital Input
4
Ground
Pin
Function
1
RS485+
2
RS485-
3
AC24V
4
AC24V

10 10
DI/DO Diagram

11 11
Hardware Reset
The Reset Button can be used to reboot the camera or restore it to factory default settings.
If the camera experiences a problem, rebooting the camera may correct the problem. If
the problem remains, please restore the camera to factory default settings and reinstall the
software.
To Reboot - Press and hold the Reset Button for one second using a paper clip or thin
object. Wait for the camera to reboot.
To Restore – Press and hold the Reset Button for ten seconds until the LED light turns off.
When successful restored, the LED will be blue during normal operation.
Note - By restoring the camera, all settings will be restored to the factory default
settings.
USB port also support LevelOne WiFi Dongle (*) and SD/SDHC Pen-drive (*)
1) it supports LevelOne wireless outdoor USB dongle (WUA-5600)
2) it supports SD/SDHC Pen-drive (Maximum 32GB)
(*) Please check with your distributor whether supported by camera.

12 12
Installation
Hardware installation
WARNING: Do not mount the camera on a soft material. The camera may fall and be
damaged.
1. Choose the location on the wall to place the camera. Use the bracket as a guide and
drill four holes into the wall. Hammer the supplied plastic anchors into the holes.
2. Place the Network Camera on the bracket and use two screws to secure it to the
bracket.
3. The user needs the four screws which are included in the product package and a
screwdriver. Mount the bracket on the wall and position the four screw slots over the
plastic anchors. Insert the screws into the holes and use the screwdriver to tighten the
screws clockwise until they are secure.
4. Adjust the angle of the bracket so that the camera is facing the desired surveillance
area.

13 13
System Requirements
Microsoft Windows XP Home Edition SP2
Operating System:
Microsoft Windows XP Professional SP2
IBM PC/AT Compatible
Computer:
CPU:
Pentium 3GHz or faster
Memory:
1024 MB or more
Monitor:
1024 x 768 pixels or more, 24-bit True color or better
Network Interface:
10/100Mbps Network interface card must be installed
Web Browser:
Microsoft Internet Explorer 6.0 SP2
CD-ROM Drive:
It is necessary to read the operating instructions in the provided CD-ROM.
Adobe Reader:
It is necessary to read the operating instructions in the provided CD-ROM.
Audio function will not be working if a sound card is uninstalled on PC. Audio may
be interrupted depending on the network environment.

14 14
Camera Connection
Basic Connection (Without PoE)
1. To attach external devices, such as sensors and alarms, connect them to the
extension I/O terminal block.
2. Connect the camera to a switch using an Ethernet cable.
3. Connect the supplied power cable to the camera and plug it into a power outlet.
Power over Ethernet (PoE) Connection
The FCS-5041 is PoE compliant, so there are two options for connecting the camera to a
power and Ethernet source. The camera can either be connected to a PoE-enabled
switch or a non-PoE switch.
A. If using a PoE-enabled switch:
1. Use a single Ethernet cable to connect the camera to the PoE-enabled switch.x

15 15
B. If using a non-PoE switch:
1. Use a standard RJ-45 cable to connect the camera to a PoE Injector.
2. Use a standard RJ-45 cable to connect the PoE Injector to the non-PoE switch.
3. Use a standard power cable to connect the PoE Injector to a power outlet.

16 16
Software Installation
In this manual, "User" refers to whoever has access to the Network Camera, and "Administrator"
refers to the person who can configure the Network Camera and grant user access to the
camera.
After hardware connection checking, the users can run the Installation Wizard program included
in the product CD-ROM to automatically search for the Network Camera in the Intranet. There
may be many Network Cameras in the local network. Users can differentiate the Network
Cameras with the serial number. The serial number is printed on the labels on the carton
and the bottom of the Network Camera body.
1. Insert the Installation CD into the CD-ROM driver. Click install and shows the welcome
screen. Follow the steps to install the Installation wizard on user’s computer.

17 17

18 18

19 19
2. Do not check the box if user would like to check the hardware installation settings.
Otherwise click “Skip the hardware installation” to skip the hardware connection checking,
the program will automatically search for the Network Camera in the Intranet.
Click “Start” to continue.

20 20
3. Select the Network Camera from the survey list and enter the user name and password. The
user name and password are assigned as “admin/admin”.
