Lewitt DGT 450 User manual

1
ALL YOU NEED
NOTHING LESS THAN IOS // OS X // WINDOWS MULTI-PURPOSE USB MICROPHONE
// DGT 450
USER MANUAL
Made for iPhone 6s, iPhone 6s Plus, iPhone 6, iPhone 6 Plus,
iPhone 5, iPhone 5s, iPhone 5c, iPad (4th generation),
iPad Air, iPad mini, iPod touch (5th generation)

2
// Index
Intro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Recording Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating the microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Tech Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Saftey Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3

4
// Intro
Thank you for choosing a LEWITT DGT 450!
In brief: It’s one of the most capable USB microphone on the market. It’s compatible with Windows, Mac and
even iOS devices. It can be used to record vocals, instruments, ambient sound, samples, podcasts and more.
Be sure to check out our Breakout Box although it’s not included in the package - it’s a clever additional
accessory available online and at your local dealer. With this little box you will be able to plug in and record your
guitar, synthesizer, mixing desk or any other line output-equipped device. You can also plug in any MIDI input
device directly and record everything on seperate tracks in one run ...
You see, this is way more than a simple USB microphone: it’s your Digital Multi-Tool.

5
// Features
// Professional small diaphragm capsule for authentic
recordings of any acoustic event
// Switchable to cardioid polar pattern
// Illuminated user interface for quick and easy
handling even in dark environments
// Recording with iPhone, iPod touch or iPad
// Bus-powered on PC & Mac
// Zero-latency direct monitoring
// Mixable direct monitoring and tape return signal for
host device playback and zero-latency monitoring of
the microphone
// Asynchronus USB transfer: precise internal clock
handles the samplerate timing to avoid jitter and
ensure bit & pitch accurate audio reproduction
// Top applications
// Home studio and live recording
// Sample and demo recording
// Podcasts and YouTube productions
// Mobile / outdoor recording
// Streaming

6
// Recording Modes
We’ve built two different recording modes into your DGT 450 to make it more versatile, we’d like to briey
introduce them to you here:
Cardioid Mode // Best used for vocal recording or other applications where you need good rear rejection.
Singer/Songwriter Mode // Only availbale with the Breakout Box (not inlcuded). Channel 1 is the cardioid
mic and channel 2 is the line input. Use this mode for simultaneous recording of acoustic and line sources. For
example: plug in your guitar to the line input and sing into the microphone to put the two signals on separate
tracks. If you plug a stereo source into the line input, it will be summed mono (this could possibly cause phase
issues on some synthesizers).

7
// Setup
Connect the hi-speed 18-pin data connector with the microphone, then connect the USB plug to the computer
or the lightning connector to your iOS device. If you need to extend the USB cable, be sure to use a HI-SPEED-
compatible USB extension cord. We do not recommend the use of USB hubs, but if you need to, only use a
powered hub or use the USB port to power the DGT 450.
OS X (10.6 and up) // Connect the DGT 450 to the USB port.
Open “system preferences” in the menu at the top of the screen.
Click on the “Sound” icon.
Click the “Output” tab and select “DGT 450”.
Click the “Input” tab and also select the “DGT 450”.
Download the Control Center at www.lewitt-audio.com/DGT-Series/DGT-450/Downloads in order to
change the settings of your DGT 450 from your computer
Windows // Connect the DGT 450 to the USB port.
Download and install the drivers – please follow the onscreen instructions.
To use the DGT 450 with your preferred sequencer / digital audio workstation, refer to the software manual.
Download the Control Center at www.lewitt-audio.com/DGT-Series/DGT-450/Downloads in order to
change the settings of your DGT 450 from your computer.
iOS // Just plug and play. Make sure that a power supply is connected to the USB port.

8
// User Interface
Input indicator // Displays active recording mode
a // Cardioid Mode
b // Singer/Songwriter Mode
Monitoring modes // Mix the output signal of your device
with the input signal of your microphone – simply put: hear the
playback and your voice at the same time ...
Return // Monitor the output of your PC, Mac or iOS device
Direct // Monitor the input of the DGT 450 without any latency
High-pass fi lter // Use these  lters to get rid of unwanted
low frequencies like wind, footsteps, structure-borne noise, ...
The high-pass  lter at 80Hz affects the microphone and line
input at 12dB per octave.
Pre-Attenuation // For loud signals to prevent clipping.
-10 dB of pre-attenuation affect the microphone only.
a b

9
LED Graph // Displays a value for some settings
like headphone gain, input gain, and others.
I/O Gain // Input and output gain settings
Jog Dial // Push and turn to change settings.
Status Indicator // Displays the current state of
the microphone:
Illuminated white // Standard mode
Not illuminated // Settings mode
Illuminated red // Overload has occurred.
Decrease the gain or change the pre-attenuation
setting.
USB // use the dedicated USB port as power
supply for the DGT 450. As long as it‘s connected
to a PC‘s USB port, it will be powerd via the data
connection.
Breakout Box (not inlcuded) // Adds the
functionality of an interface to your DGT 450.
Data Connector // Connects your DGT 450 to
your device.
Headphone Jack // Plug in your headphones
here.
MIDI In // Plug in your MIDI device here.
Line In // Plug in your instrument here.

10
// Operating the microphone
The following will walk you through all the settings of your DGT 450.
Standard Mode // This is the default state of the device when you power it on ( is illuminated white).
Settings Mode // This is where you can change all the settings on your DGT 450 including recording modes,
monitoring options, high-pass lters, pre-attenuation and gain. The illuminated LEWITT logo will turn off as
soon as the microphone switches to Settings Mode. Press the jog dial to enter the settings mode, to switch
from setting to setting and rotate it to change the selected setting.
Headphone/Output Gain // The headphone symbol is lit. Rotate the jog dial to change the output volume.
ATTENTION: Your DGT 450 has a professional, built-in headphone amp. Be sure to check your gain settings
befor using headphones, the signal can be very loud. Honestly, we mean it - this can seriously harm your ears.
Input Gain // Press the jog dial until the input gain symbol is lit. We use a very ne gain control – there are
intermediate steps that do not show up on the LEDs. The settings will change depending on the selected
recording mode. You can set input gain levels for all recording modes individually.
Cardioid Mode selected // Gain L R will be lit. Rotate the jog dial to change the gain.
Singer/Songwriter Mode selected (only available with the optional Breakout Box) // Gain L will be lit
rst. This lets you set the gain for the left channel – in this mode, it’s the cardioid microphone. Press the

11
jog dial; Gain R will now be lit. This lets you change the gain of the right channel – in this mode, it’s the line
input.
Recording Mode // The selected recording mode symbol is lit. Rotate the jog dial to change the recording
mode if a Breakout Box is connected to the DGT 450. Press the jog dial to switch to the next setting.
Monitoring Mode // Use the jog dial to blend between tape return monitoring and direct monitoring . The
LED graph shows the mixture of the two modes. Press the jog dial to switch to the next option.
Low-cut Filter // Set the low cut with the jog dial. Available settings are: at and 80Hz@12dB/Oct.
Pre-Attenuation // Set the pre-attenuation by rotating the jog dial the options are 0dB, -10dB.

12
// Tech Data
// Microphone
Acoustical operating principle //
pressure gradient transducer, permanently polarized,
XY-stereo
Transducer Ø //
17 mm / 0.67 inch
Polar pattern //
Cardioid
Frequency range (3 dB) //
50 to 20,000 Hz
Dynamic range of mic. amp. //
≥ 93 dB (A)
Pre-attenuation pad //
10 dB
Low cut Filter //
12 dB / octave at 80 Hz
Front to back ratio @ 1kHz //
≥ 15 dB (A)
Analog gain range //
0 to 44 dB
Microphone self noise (0 dB gain) //
≤ 25 dB (A)
Limiting SPL (0 dB gain) //
≥ 118 dB (A)
// General
Resolution //
24 Bit
Sample rates //
44.1 kHz // 48 kHz // 88.2 kHz // 96 kHz
Supply voltage //
on iOS additional 5V / 500mA micro-USB power
supply required
Connector //
18-pin lockable hi-speed connector

13
Dimensions //
138 x 52 x 36 mm
5,43 x 2,04 x 1,42 inch
Net weight //
310 g, 10.9 oz
// Compatible Platforms
Apple and PC //
OS X (10.6 and up) , Windows XP, 7, 8 and 8.1
iOS Platforms //
Made for iPhone 6s, iPhone 6s Plus, iPhone 6,
iPhone 6 Plus, iPhone 5, iPhone 5s, iPhone 5c,
iPad (4th generation), iPad Air, iPad mini,
iPod touch (5th generation)
// Line-in
Input impedance //
1 Meg ohm / 10 pF
Full scale input voltage (0 dB gain) //
0.7 VRMS, -0.9 dBu (re 0.775 VRMS)
Input dynamic range //
≥ 96 dB (A)
Frequency response //
20 to 20,000 Hz
Operating principle //
Mono line input
Analog gain range //
0 to 12dB
// Headphones
Output power //
20mW at 16 ohm, THD < 0.5%
16mW at 32 ohm, THD < 0.5%
Frequency response //
20 to 20,000 Hz
Headphone volume control //
- 60 dB to 0 dB

14
// Saftey Guidelines
// The capsule is a sensitive, high precision component. Make sure you do not drop it from high heights and
avoid strong mechanical stress and force.
// To ensure high sensitivity and best sound reproduction of the microphone, avoid exposing it to moisture, dust
or extreme temperatures.
// Keep this product out of the reach of children.
// Do not use force on the switch or cable of the microphone.
// When disconnecting the microphone cable, grasp the connector and do not pull the cable.
// Do not attempt to modify or x it. Contact qualied service personnel in case any service is needed. Please do
not disassemble or modify the microphone for any reasons as this will void users warranty.
// The casing of the microphone can be cleaned easily using a wet cloth, never use alcohol or another solvent
for cleaning. If necessary the foam wind stopper can be washed with soap water. Please wait till it is dry before
using it again.
// Please also refer to the owner’s manual of the component to be connected to the microphone.

15
// Warranty
All products manufactured by LEWITT GmbH feature a limited two-year warranty. This two-year warranty is
specic to the date of purchase as shown on your purchase receipt.
LEWITT GmbH shall satisfy the warranty obligations by remedying any material or manufacturing faults free of
charge at LEWITT’s discretion either by repair or by exchanging individual parts or the entire appliance. Any
defective parts removed from a product during the course of a warranty claim shall become the property of
LEWITT GmbH.
While under warranty period, defective products may be returned to the authorized LEWITT dealer together
with original proof of purchase. To avoid any damages in transit, please use the original packaging if available.
Please do not send your product to LEWITT GmbH directly as it will not be serviced. Freight charges have to be
covered by the owner of the product.
For further information please visit www.lewitt-audio.com or check your warranty card.

16
// Regulatory Information
LEWITT GmbH declares under its sole responsibility
that DGT 450 complies with the European directive
2004/108/EC and 2006/95/EC. The product has been
tested according to harmonized European standards:
EN 55022: 2010
EN 55024: 2010
EN 61000-3-2: 2006 + A2: 2009
EN 61000-3-3: 2008
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011
Product testing was carried out by SEM. Test
Compliance Service Co., Ltd. noti ed body number
SEM11124587 / SEM11126875.
LEWITT GmbH hereby declares under its sole
responsibility that DGT 450 has been tested and
conforms to the following FCC and ANSI standards:
FCC Part 15B Section 15.205, 15.107 and 15.109
ANSI C63.4-2009
Product testing was carried out by SEM. Test
Compliance Service Co., Ltd.
WEEE note: Electronic waste has to be collected
separately. Please bring this device to a local recycling
center at the end of its life time.
Manufacturers signature:
Date: July, 26th 2015 DI Roman Perschon
Place: Vienna, AUSTRIA CEO – Lewitt GmbH
Declaration of conformity can be downloaded at
www.lewitt-audio.com or obtained from
[e-mail].
