Lex System SUPER Series User manual

SUPER Series Panel PC
Assembly Guide

1-1 Installing for SO-DIMM ............... ......................................................... .
Super Series (3L) Panel PC Exploded Drawing .........................................
1
6
Contents
Super Series (2L) Panel PC Exploded Drawing .........................................
5
2
1-3 Installing for SATA HDD Version .........................................................
3
1-2 Installing for Mini PCI-e Card ...............................................................

1
(Fig.1)
1-1 Installing for SO-DIMM
2. Insert the memory into the SODIMM at
a 45 degree angle. (Fig.2)
(Fig.2)
(Fig.4)
1. Remove 9 pcs M3*6 round head screws from
the top cover & open the cover. (Fig.1)
(Fig.2)
Notices:
The connectors are designed to ensure the
correct insertion. If you feel resistance,
check the connectors & golden finger direction,
and realign the card.
3. Press down the memory to secure the
memory within SODIMM. (Fig.3)
(Fig.3)

(Fig.4)
(Fig.5)
(Fig.6)
45°
1-2 Installing for Mini PCI-e Card
2
5. Insert the Mini PCIe card into the
socket at a 45 degree angle. (Fig.5)
4. Remove the secured screws of
Mini PCIe socket . (Fig.4)
6. Press down the Mini PCIe card and
secure the card with screws. (Fig.6)
(Fig.6)

(Fig.7)
(Fig.5)
(Fig.6)
1-3 Installing for SATA HDD Version
7. Attach the HDD to the HDD KIT via
4PCS M3*4 flat head screw (Fig.7)
(Fig.8) 8. Connect the SATA DATA Cable with
motherboard. (Fig.8)
3
9. Connect the SATA Power Cable with
motherboard. (Fig.9)
(Fig.9)

(Fig.12)
(Fig.11)
(Fig.10)
(Fig.12)
(Fig.6)
4
12.Connect the SATA Power Cable wit HDD.
(Fig.12)
10. Secure the HDD KIT to the system via
3 pcs M3*4 flat screws. (Fig.10) 11.Connect the SATA DATA Cable with HDD. (Fig.11)
13. Put the cover back & screws it via 9 pcs round head M3*6 screw. (Fig.13)
(Fig.13)

5
Super Series (2L) Panel PC
Exploded Drawing
9
8
7
6
5
12
4
3
1
2
11
10
1
1
1
1
1
1
1
2
3
4
5
6
Touch
Keypad
Front Cover
Middle Frame
Main Board
HDD Bracket
17 HDD
18 10 Panel
19 Back Cover
110 Middle Sponge
111 Touch Tape
112 WP Sponge
No
Name Q'ty

6
Super Series (3L) Panel PC
Exploded Drawing
1
1
1
1
1
1
1
2
3
4
5
6
Touch
Keypad
Front Cover
Middle Frame
Main Board
HDD Bracket
17 HDD
18 10 Panel
19 Back Cover
110 Middle Sponge
111 Touch Tape
112 WP Sponge
Name Q'ty
No
9
6
12
4
3
1
2
11
10
7
8
