Lex LuxCommander B3700 User manual

LM-LXCMD 003
Portable Work Lights
LuxCommander®
User Manual
(Models B3700, B6700 & B7700)
PowerGATE®
Switches & Panels
PowerPLUS
Installed Distribution Boxes
TM
PowerRAMP®
Cable Protectors
Power Control Solutions
™
Dimming & Control
™
PowerHOUSE
Portable Distribution Boxes
TM
PowerPARTS
Wiring Devices
TM
PowerRACK
Rolling Distribution Racks
TM
WeldingRACK
WR6
TM
PowerFLEX
Cable Assemblies
TM
LuxCommander®
Portable Work Lights

Designed for use in harsh environments, the Lex Products LuxCommander®Portable Work Light delivers three
times more light output than conventional uorescent worklights for a brighter and safer worksite. This user
manual reviews information critical to the proper operation of the LuxCommander®. Please take time to review all
precautions and warnings in the manual prior to use. Store this manual in a safe location for future reference.
Unpacking and Inspection
Before you begin your installation check the shipment carefully to conrm it arrived complete and undamaged.
1. Check the contents against the packing list to ensure the device is the correct model.
2. Check the unit for loose or broken components, which might have resulted from shipping.
3. Inspect for signs of damage to wiring devices, cords or xture shell.
If there is any damage to the LuxCommander®Portable Work Light, contact Lex Products toll free at
[phone] or email [email protected].
LuxCommander® Components (Typical)
Fig. 1
Heavy Duty
Polyurethane Caps
(2) Hanging Straps Weather Resistant
for Wet Locations
Uses Readily Available
Lamps for Easy
Replacement
Weather Resistant Feed
Thru Feature for ‘Daisy
Chaining’
Aluminum Frame and Poly-
carbonate Shell
Ballast Accepts Anywhere
from 120 to 277 VAC
When Equipped with
Appropriate Connectors
Ultra Durable Cord
for Sunlight, Water
and Oil Resistance
Waterproof ON/OFF
for Safety
Introduction

Important Safety Precautions
When using the LuxCommander® Portable Work Light, basic safety precautions should always be followed to
reduce the risk of re, electric shock, and personal injury. These precautions include:
A. Use only three-wire outdoor extension cords that have three-prong grounding plugs and grounding connectors
that accept the LuxCommander’s® plug.
i. The LuxCommander® features a polarized plug to reduce the risk of electrical shock.
B. Ground Fault Circuit Interrupter (GFCI) protection is to be provided where the LuxCommander®is used in
wet or potentially wet locations. Industry-standard receptacles are available with built-in GFCI protection to
provide this measure of safety.
C. Use only with an extension cord for outdoor use, such as those that use either cord type SW, SW-A, SOW,
SOW-A, STW, STW-A, STOW, STOW-A, SJW, SJW-A, SJOW, SJOW-A, SJTW, SJTW-A, or SJTOW, SJTOW.
D. Do not use in hazardous atmospheres or locations where a spark might lead to ignition or explosion.
E. Use work light in a horizontal or switch-end DOWN position to increase xture life
and prevent overheating.
F. If hanging xture vertically, make sure the feed end (with male plug) and ballast
are below the feed thru end (with female connector) (See Fig. 2 for incorrect
position). Failure to do so can result in overheating and reduce the ballast life.
G. Do not connect more than 10 lights together on any given string.
Maximum recommended daisy-chain distance is 200 feet total, not
including xture length.
NOTE: The feed thru feature is for connecting lights only, not other power loads.
Operating Instructions
Step 1: Locating the LuxCommander®
- The LuxCommander® is designed to be used in indoor or outdoor locations.
- The xture must not rest in standing water.
- Suspend LuxCommander® from an appropriate location using the straps provided.
NOTE: Do NOT hang the xture by the power cord.
Step 2: Making Connections
- If using the feed thru feature, connect the feed thru BEFORE the input connection is made.
- Fully insert the feed-thru extension plug into the LuxCommander® connector tail.
- Fully insert the power connector into the LuxCommander® plug tail.
Step 3: Powering up the LuxCommander® System
- Best practice dictates that loads are applied gradually the rst time a system is set up.
- Turn on the xture furthest from the power source and work towards it, turning on xtures as you go.
Setting Up the LuxCommander®
Fig. 2

WE DELIVER THE POWERTM
Lex Products Corporation
15 Progress Drive
Shelton CT 06484
203.363.3738
203.363.3742 Fax
Lex West
12701 Van Nuys Boulevard
Suite Q
Pacoima, CA 91331
818.768.4474
818.768.4040 Fax
www.lexproducts.com
[email protected]
800.643.4460
© Copyright Lex Products 2019
Produced in the United States of America
All Rights Reserved.
Lex Products logo and lexproducts.com are
trademarks or registered trademarks of Lex
Products in the United States,
other countries, or both.
Fixture Care
– Replace uorecent lamps after 20,000 hours of use.
– Replace LED lamps after 40,000 hours of use.
– Clean outside of shell with soap and water as needed
(avoid solvents).
Fixture Maintenance
Step 1: UNPLUG the light from power to prevent any
hazard.
Step 2: Unscrew the central, plastic nut at the end
of the light furthest from the switch.
Step 3: Pull the at disc and rubber bumper free from
the light. DO NOT disconnect any internal
wiring.
Step 4: Flip the at disc 90 degrees (see Fig. 3), and
then push it through the slots in the bumper.
(see Fig. 4)
Step 5: The bumper can now be removed completely.
Step 6: Repeat steps 2 through 5 for the other end of
the xture.
Step 7: Slide the xture assembly out of the
polycarbonate shell.
Step 8: Lamps are held in place with spring loading.
Do not use a tool to pry the glass lamp in or
out of the holder.
a. B3700: Compress both spring-loaded
sockets to remove the lamps.
b. B6700/B7700: Pull and tilt the spring-loaded
disc away from each lamp as it is removed
or installed.
Technical Support
Lex Products is available to help answer any product related inquiries. For any questions or technical advice,
please call toll free 855-LEX-1002 (855-539-1002) or email [email protected].
Troubleshooting Guide
Fig. 3
Fig. 4
