For tips on avoiding jams, see Avoiding jams.
If you do experience a jam, see the following instructions in this topic to clear the jam and
continue printing.
•Understanding jam messages
•Locating jams with messages
•Clearing jams from the printer
•Clearing jams from the optional duplex unit
•Clearing jams from the optional envelope feeder
•Clearing jams from the optional mailbox
•Clearing jams from the optional finisher

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
2
Printing
www.lexmark.com
Lexmark W820
Understanding jam messages
When a jam occurs, the printer displays a two-line 2xx Paper Jam message and stops
operating. Although the location of the jam appears on the second line of the display,
you
must clear all paper from the entire paper path
.PressGo to clear the message and continue
printing.
See Paper path for an explanation about areas where you can access jams. Immediately
following Paper path see the illustrations of areas where you can access jams.
Note: If you have an optional finisher attached to your printer, the secondary
message Leave Staple Job in Finisher or Clear Staple Job from Finisher
alternates with the 2xx Paper Jam message.

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
3
Printing
www.lexmark.com
Lexmark W820
Paper path
The paper path is the route paper travels as it makes its way from the selected paper source
through the printer and into the selected output bin. To clear the paper in the path, start at the
paper source the printer is using for the current job. Open all doors and covers between the
source and the selected output bin. If you are not sure which source the printer is using, start
withtray5,ifinstalled;otherwise,startwithtray2.
See the following illustrations for a better understanding of the path the paper travels through
the printer and its options. The jam numbers are listed based on location within the paper
path.
The doors and covers that give you access to paper in the path when a jam occurs are
labeled on the Message maps.

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
4
Printing
www.lexmark.com
Lexmark W820
Paper path of standard trays and optional trays, optional duplex unit, and
multipurpose feeder
254
258
247
257
252
260
251
259
248
249
261
273 256
250, 253, 255
232, 233, 234
244
245
242
243
241
200
246
201,
202
204
208, 231 209, 210, 211

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
5
Printing
www.lexmark.com
Lexmark W820
Paper path of optional envelope feeder in relation to trays, optional duplex unit,
andpathtotheoptionalmailbox
271, 272

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
6
Printing
www.lexmark.com
Lexmark W820
Paper path of optional mailbox in relation to printer and optional duplex unit
280
282
281
281
284
For each bin, the curved
portion of the path
leading into the bin and
thepathtothebinis284
For each bin, this area
is 285

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
7
Printing
www.lexmark.com
Lexmark W820
Paper path of transport unit and optional finisher in relation to printer and
optional duplex unit
285
284
283
282
281
287 280
294
290
291
288, 293
289
286 292
295

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
8
Printing
www.lexmark.com
Lexmark W820
Message maps
You can use the message map on the front of the printer (or on the transport unit if the
finisher is installed) to locate the doors, covers, and options you must open or remove to clear
the paper path.

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
9
Printing
www.lexmark.com
Lexmark W820
Locating jams with messages
Message Area where jam occurs See:
200 Paper Jam Open Door A
201 Paper Jam Open Door A
202 Paper Jam Open Door A
Rollers under the print cartridge Tray1andtheprint
cartridge area
204 Paper Jam Open Door A Fuser area Fuser area
208 Paper Jam Open Door A
209 Paper Jam Open Door A Duplex unit area or the fuser area step 5 on page 20
210 Paper Jam Open Door E Fuser area
211 Paper Jam Open Door A Fuser area
231 Paper Jam Open Door E
232 Paper Jam Open Door E
233 Paper Jam Open Door E
234 Paper Jam Open Door E
Duplex unit Clearing jams from the
optional duplex unit
241 Paper Jam Open Door A Around tray 1 Tray1andtheprint
cartridge area
241 Paper Jam Open Tray 1 In or behind tray 1 Behind trays 1, 2, and 3
242 Paper Jam Open Door B Around tray 2 Tray 2

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
10
Printing
www.lexmark.com
Lexmark W820
242 Paper Jam Open Tray 2 In or behind tray 2 Behind trays 1, 2, and 3
243 Paper Jam Open Door A Around tray 1 Tray1andtheprint
cartridge area
244 Paper Jam Open Door B Around tray 2 Tray 2
244 Paper Jam Open Tray 3 In or behind tray 3 Behind trays 1, 2, and 3
245 Paper Jam
Open Doors A, B Around trays 1 and 2 Tray1andtheprint cartridge area
Tray 2
246 Paper Jam Open Door B Around tray 2 Tray 2
247 Paper Jam Open Door C Around trays 3, 4, and 5 Tray 3
Tray 4
Tray 5
247 Paper Jam Open Tray 4 In or behind tray 4 Tray 4
248 Paper Jam
Open Doors B, C Around trays 2, 3, 4, and 5 Tray 2 Tray 3
Tray 4
Tray 5
Message Area where jam occurs See:

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
11
Printing
www.lexmark.com
Lexmark W820
249 Paper Jam Open Door C Around trays 3, 4, and 5 Tray 3
Tray 4
Tray 5
250 Paper Jam Open Door B Around tray 2 Tray 2
251 Paper Jam Open Door C Around trays 3, 4, and 5 Tray 3
Tray 4
Tray 5
251 Paper Jam Open Tray 5 In tray 5 Tray 5
252 Paper Jam
Open Doors B, C Around trays 2, 3, 4, and 5 Tray 2 Tray 3
Tray 4
Tray 5
253 Paper Jam
Open Doors A, B, C Aroundtrays1,2,3,4,and5 Tray1andtheprint cartridge area
Tray 2
Tray 3
Tray 4
Tray 5
254 Paper Jam Open Door C Around trays 3, 4, and 5 Tray 3
Tray 4
Tray 5
Message Area where jam occurs See:

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
12
Printing
www.lexmark.com
Lexmark W820
254 Paper Jam Open Tray 5 In tray 5 Tray 5
255 Paper Jam Open Door A Around tray 1 Tray1andtheprint
cartridge area
255 Paper Jam
Remove MP Feeder Multipurpose feeder Multipurpose feeder
255 Paper Jam
Remove Envelope Envelope feeder Clearing jams from the optional envelope feeder
Removing the optional
envelope feeder
256 Paper Jam
Open Doors A, B Around trays 1 and 2 Tray1andtheprint cartridge area
Tray 2
257 Paper Jam
Open Door B Around tray 2 Tray 2
258 Paper Jam Open Door C Around trays 3, 4, and 5 Tray 3
Tray 4
Tray 5
259 Paper Jam Open Door C Around trays 3, 4, and 5 Tray 3
Tray 4
Tray 5
Message Area where jam occurs See:

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
13
Printing
www.lexmark.com
Lexmark W820
259 Open Tray 5 In tray 5 Tray 5
260 Paper Jam Open Door E In the duplex unit Clearing jams from the
optional duplex unit
261 Paper Jam
Open Doors B, C Around trays 2, 3, 4, and 5 Tray 2 Tray 3
Tray 4
Tray 5
271 Paper Jam
Remove Env Feeder
272 Paper Jam
Remove Env Feeder
Envelope feeder Clearing jams from the
optional envelope feeder
Removing the optional
envelope feeder
273 Paper Jam
Remove Envelope Envelope feeder Clearing jams from the optional envelope feeder
273 Paper Jam
Remove MP Paper Multipurpose feeder Multipurpose feeder
280 Paper Jam Open Cover H Transport unit Iftheprintmediaisjammed
inside the transport unit
between the rollers:
280 Paper Jam Open Door D Mailbox Clearing jams from the
optional mailbox
Message Area where jam occurs See:

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
14
Printing
www.lexmark.com
Lexmark W820
281 Paper Jam Open Cover H Transport unit Iftheprintmediaisjammed
inside the transport unit
between the rollers:
281 Paper Jam Open Door D Mailbox Clearing jams from the
optional mailbox
282 Paper Jam Open Cover H Transport unit Iftheprintmediaisjammed
inside the transport unit
between the rollers:
282 Paper Jam Open Door D Mailbox Clearing jams from the
optional mailbox
283 Paper Jam Open Cover H Transport unit Iftheprintmediaisjammed
inside the transport unit
between the rollers:
284 Paper Jam Open Cover H Transport unit
284 Paper Jam Open Door D Mailbox Clearing jams from the
optional mailbox
285 Paper Jam Open Cover H Transport unit Iftheprintmediaisjammed
inside the transport unit
between the rollers:
285 Paper Jam Open Door D Mailbox Clearing jams from the
optional mailbox
Message Area where jam occurs See:

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
15
Printing
www.lexmark.com
Lexmark W820
286 Paper Jam Open Cover H Transport unit Iftheprintmediaisjammed
inside the transport unit
between the rollers:
287 Paper Jam
Open Deflector G Finisher - Deflector Iftheprintmediaisjammed under the divertor cover:
288 Paper Jam Open Door K Above the hole punch area page 73
289 Paper Jam Open Door K
290 Paper Jam Open Door K Above the stapler page 76
291 Paper Jam Open Door K Finisher Clearing jams from the
optional finisher
292 Paper Jam Open Cover J Finisher top cover page 72
293 Paper Jam Open Cover J Finisher top cover Iftheprintmediaisjammed
under the finisher top
cover:
294 Paper Jam Open Cover J Finisher top cover
Message Area where jam occurs See:

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
16
Printing
www.lexmark.com
Lexmark W820
Clearing jams from the printer
Tray 1 and the print cartridge area
Note: The following instructions are written assuming you are using the
multipurpose feeder and the duplex unit. If you are using the envelope
feeder, you must remove it before opening the duplex unit door. For
instructions, see Removing the optional envelope feeder.
295 Paper Jam
Open Door K
This message alternates with
the following message:
Clear Staple Job
from Finisher
Finisher accumulator (area
where sheets accumulate in
order to be stapled)
page 72
Message Area where jam occurs See:

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
17
Printing
www.lexmark.com
Lexmark W820
1Open the multipurpose feeder.

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
18
Printing
www.lexmark.com
Lexmark W820
2Push up on the latch to release the duplex unit door (Door E).
3Gently lower the door to the open position.

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
19
Printing
www.lexmark.com
Lexmark W820
4Pull up on handle to open the printer side door (Door A).

Clearing print media jams
Paper handling
Maintenance
Troubleshooting
Administration
Index
20
Printing
www.lexmark.com
Lexmark W820
5Remove the paper based on what part is visible.
–If the paper is visible, pull it straight out and continue with step 9 on page 22.
–If the paper is not visible or there is not enough showing to grasp easily, it is still in
the tray. Complete step 6 on page 21 through step 9 on page 22.
–If the paper is not visible in the tray, the paper is lodged behind the tray and
requires that you remove the tray. See Behindtrays1,2,and3.
