Lexmark T650n
Lexmark T650 Series
Power and versatility for
serious business printing!
PRINT
UP TO 55 PPM
NeTwORk
Lexmark T652n Lexmark T654n

Robust, ultra-fast and incredibly versatile, the Lexmark T650 Series fits every type of need. Whether you’re looking for a serious
performer for high-volume printing or an effective solution for printing on a wide range of media, these powerful monochrome
laser printers deliver the ultimate combination of quality, low ownership costs and outstanding reliability.
Print Less. Save More.
Print less? This may seem like a surprising message for a company dedicated solely to printing. But when you consider that businesses spend, on
average, up to 6% of their revenue on printing and active print management can cut office print costs by up to 30%1, it makes a lot of sense. Lexmark
products, solutions and services provide innovative ways to save you time, drive down costs and reduce your impact on the environment. We are
committed to helping you print less and save more.
(1) Source: InfoTrends/CapVentures, Network Document Solutions Forecast 2007-
2012, Network Document Solutions Consulting Service, August 2008
Intelligent functionality
The Lexmark T650 Series offers you a wide range of intelligent
features that help you maximize uptime, save money and work more
efficiently than ever before.
Prints black, thinks green
Printing responsibly means everyone wins – your business, your
budget and the environment! Lexmark T650 Series printers are
designed with sustainability in mind. They’re incredibly quiet and
equipped with a range of eco-conscious features to help you
print greener at every level.
Unrivalled versatilityQuality and productivity unite
Start accruing the benefits of a printer with the real power to perform.
With the new redesigned Lexmark T650 Series, you can now own
an office machine that pushes quality and performance to truly
impressive levels.
Every workgroup is different. So why not match your printer
to suit the way you work? Benefit from diverse media support
plus a range of flexible choices, including leading-edge paper
handling.
l
Opt for extra drawers to expand your input capacity up to
4,300 sheets
l
Ultra-reliable paper feeding supports diverse media, including
card stock and labels
l
Stapler option with 50-sheet capacity; offset job stacking
l
Install up to two 5-bin mailboxes to separate users output
l
Up to 600MHz processing power and up to 256MB of RAM
standard
l
Up to 55 ppm, first page out as fast as 7.5 seconds
l
Impressive print quality, up to 1200 x 1200 dpi
l
Automatically adjusts toner darkness for consistent results from first
page to last
l
Should the media required for a job not be available, Job Waiting
automatically places the job on hold to keep the print queue flowing
(hard-drive option required)
l
Performance enhancement on the Lexmark T652 and Lexmark
T654 speeds up output of short print jobs
l
Direct Web printing lets you print Web-based documents with ease
l
Models with Lexmark’s Embedded Solutions Framework can be
customized to meet specific workflow needs
l
Duplex printing models reduce paper consumption
l
Eco-Mode reduces power consumption
l
Series is as quiet as 53 dBA when printing; reduce sound even
more with Quiet Mode
l
Lexmark High Yield (25,000* pages) and Extra High Yield
(36,000* pages) Print Cartridges conserve resources

Explore the features that keep you moving
Lexmark T650 Series
4-line graphical display
Intuitive visuals for
exceptionally simple user
operation
Direct USB
Front USB port lets you
print PDFs and other
image files directly from a
memory device – no PC
needed
Special delivery
Mailbox options let you
assign users their own
output bins
Low cost of ownership
Reduce running costs with
high-capacity cartridges,
up to 36,000* pages
Secure PIN release
Use the alphanumeric pad
to release confidential jobs
Expandable input
Boost your paper input
capacity up to 4,300
sheets
Rock-solid reliability!
Introducing the new Lexmark T650 Series, a robust range of workgroup printers that are built to last – and keep up with
your heaviest print volumes.
Backed by an award-winning sixth-generation print engine and Lexmark’s proven track record in product innovation,
these rugged workhorses ensure maximum uptime while reliably delivering fast, high-quality pages year after year.
What’s more, the Lexmark T650 Series is backed by Lexmark’s 1-Year Exchange Service, which provides you with next-
business-day response (see Statement of Limited Warranty for details).
Now you can have a truly reliable solution that meets your highest expectations!

Performance
optimized
Intelligent
Job Waiting
Outstanding print
quality
Cutting-edge
security
Simplified
management
The Productivity Checklist
If you’ve got all these, then you’ve got a Lexmark!
Lexmark T650 Series
Which is more
advantageous – more
pages per minute or a
quicker time-to-first-page?
That depends on your
print job. Lexmark T650
Series printers can identify
the size and complexity of
your job and automatically
calculate the optimal speed
– quicker time-to-first-page
for short jobs and more
pages per minute for longer
jobs. So whatever you’re
printing, you’re always sure
to get the fastest result!
One person’s setback
should never mean a
bottleneck for the whole
workgroup! Say someone
launches a print job that
requires labels, but there
are none loaded. Why
lose precious uptime?
Lexmark’s Job Waiting
feature will simply hold that
job aside while everyone
else goes on working
without interruption (hard
drive required).
When you purchase
a high-performance
workgroup printer, you
expect high-performance
results and that includes
flawless print quality. The
Lexmark T650 Series
combines true 1200 x
1200 dpi with automatic
darkness adjustment and
pixel-boosting technology,
ensuring you high-quality,
professional documents
every time.
From network security to
user-access restrictions,
Lexmark makes sure
you’re fully equipped with
all the tools you need to
help keep your valuable
corporate data safe and
sound. In addition to IPSec,
SNMPv3 and 802.1x
network security, the
Lexmark T650 Series offers
an alphanumeric pad for
easy PIN authentication,
plus encryption and disk
wiping to secure the
optional hard drive.
Take a load off your
IT department. These
printers are network-ready
and very easy to set
up. If you have multiple
Lexmark devices installed,
the Lexmark Universal
Driver offers even easier
deployment. And Lexmark
MarkVision™ Professional
software provides simplified
remote management and
automated tools to keep
your workday flowing!

Lexmark T654n
Lexmark T650n
Get exactly the performance you need
Lexmark T652n
Three configurations available for
each T650 Series model
Solutions ready!
Ideal for small and midsize workgroups that want great
performance, excellent paper handling and an all-around
robust design.
l
Up to 45 ppm print speeds
l
500MHz processor
l
128MB standard memory
l
Recommended monthly volume: 3,000 to 20,000 pages
l
350-sheet standard input, 4,000 maximum
l
350-sheet standard output, 2,750 maximum
l
Ships with a 7,000*-page Return Program Print Cartridge
Available models: Lexmark T650n, Lexmark T650dn, Lexmark T650dtn
Available models: Lexmark T652n, Lexmark T652dn, Lexmark T652dtn
Offers high-endurance printing for busier workgroups, with
faster speeds, a bigger standard input drawer and models
with built-in duplex.
l
Up to 50 ppm print speeds
l
Recommended monthly volume: 3,000 to 30,000 pages
l
650-sheet standard input, 4,300 maximum
l
Ships with a 10,000*-page Return Program Print Cartridge
l
Built-in duplex models available for two-sided printing
Available models: Lexmark T654n, Lexmark T654dn, Lexmark T654dtn
l
Up to 55 ppm print speeds
l
600MHz processor
l
256MB standard memory
l
Recommended monthly volume: 5,000 to 35,000 pages
l
550-sheet standard output, 2,950 maximum
l
Lexmark Extra High Yield Print Cartridge (36,000* pages)
available
l
Lexmark Embedded Solutions Framework
n = network ready
dn = network ready plus duplex printing
dtn = network ready with duplex printing
plus extra input drawer
Enabled with Lexmark’s Embedded
Solutions Framework, the Lexmark
T654 family is the ideal platform for
tapping into the benefits of Lexmark’s
industry-leading enterprise workflow
solutions. They can help you print
less, lower costs, reduce waste
and significantly streamline your
processes. To learn more about
Lexmark solutions, contact your
Lexmark representative today.
l
Lexmark High Yield Print Cartridge (25,000* pages)
available
l
Lexmark High Yield Print Cartridge (25,000* pages)
available
The ultimate departmental workhorse, offering maximum
power, greater media flexibility, higher-yield replacement
toner, and a solutions-ready framework to expand your
workflow possibilities!
l
Ships with a 10,000*-page Return Program Print
Cartridge

Product specifications Lexmark T650 Series
Lexmark T650n Lexmark T652n Lexmark T654n
Maximum Monthly Duty Cycle
Recommended Monthly Page Volume
«Maximum Monthly Duty Cycle» is defined as the maximum number of pages a device could deliver in a month. This metric provides
a comparison of robustness in relation to other Lexmark printers and MFPs.
«Recommended Monthly Page Volume» is a range of pages that helps customers evaluate Lexmark’s product offerings based on the
average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages per
month be within the stated range for optimum device performance, based on factors including: supplies replacement intervals, paper
loading intervals, speed, and typical customer usage.
Trademarks
Lexmark and Lexmark with the diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
All other trademarks are the property of their respective owners. PCL is a registered trademark of Hewlett-Packard Company. AppleTalk, Mac and
Macintosh are trademarks of Apple Computer, Inc., registered in the United States and other countries. MarkNet and MarkVision are trademarks of
Lexmark International, Inc., registered in the United States and/or other countries. The USB-IF logos are trademarks of Universal Serial Bus Imple-
menters Forum, Inc. Microsoft, Windows, the Windows logo, Windows Vista, and the Windows Vista logo are trademarks or registered trademarks of
Microsoft Corporation in the United States and/or other countries. Citrix, MetaFrame and MetaFrame XP are registered trademarks or trademarks of
Citrix Systems, Inc. in the U.S. and other countries. Information in this document is subject to change without notice.
Printing
Print Technology Monochrome Laser
Print Speed (Letter, Black): Up to 45 ppm 50 ppm 55 ppm
Time to First Page (Black) As fast as 7.5 seconds
Print Resolution, Black 1200 Image Quality, 1200 x 1200 dpi, 2400 Image Quality, 600 x 600 dpi
Memory, Standard 128 MB 128 MB 256 MB
Memory, Maximum 640 MB 640 MB 1280 MB
Print Noise Level, Operating 53 dBA 54 dBA 55 dBA
Noise Level, Idle 26 dBA 30 dBA 30 dBA
Maximum Monthly Duty Cycle: Up to 200000 pages per month 225000 pages per month 275000 pages per month
Recommended Monthly Page Volume 3000 - 20000 pages 3000 - 30000 pages 5000 - 35000 pages
Supplies
Supplies Yield 25,000*-page High Yield Print Cartridge, *Average
standard page yield value declared in accordance
with ISO/IEC 19752., 7,000*-page Print Cartridge
25,000*-page High Yield Print Cartridge, *Average
standard page yield value declared in accordance
with ISO/IEC 19752., 7,000*-page Print Cartridge
25,000*-page High Yield Print Cartridge,
*Average standard page yield value declared in
accordance with ISO/IEC 19752., 7,000*-page
Print Cartridge, 36,000*-page Extra High Yield
Print Cartridge
Cartridge(s) Shipping with Product 7,000*-page Return Program Print Cartridge 10,000*-page Starter Return Program Print
Cartridge
10,000*-page Starter Return Program Print
Cartridge
Paper Handling
Paper Handling Standard 100-Sheet Multipurpose Feeder, 250-Sheet Input
Tray, 350-Sheet Output Bin
100-Sheet Multipurpose Feeder, 550-Sheet Input
Tray, 350-Sheet Output Bin
100-Sheet Multipurpose Feeder, 550-Sheet Input
Tray, 550-Sheet Output Bin
Paper Handling Optional 1,850-Sheet High-capacity Output Stacker,
200-Sheet Universally Adjustable Tray with
Drawer, 400-Sheet Universally Adjustable Tray
with Drawer, 5-Bin Mailbox, 550-Sheet Drawer,
Envelope Feeder, 250-Sheet Drawer, 250-Sheet
Duplex Unit, Optional furniture required., 2,000-
Sheet High-capacity Feeder, 550-Sheet Output
Expander, StapleSmart II Finisher
1,850-Sheet High-capacity Output Stacker,
200-Sheet Universally Adjustable Tray with
Drawer, 400-Sheet Universally Adjustable Tray
with Drawer, 5-Bin Mailbox, 550-Sheet Drawer,
Envelope Feeder, 250-Sheet Drawer, Optional
furniture required., 2,000-Sheet High-capacity
Feeder, 550-Sheet Output Expander, StapleSmart
II Finisher
1,850-Sheet High-capacity Output Stacker,
200-Sheet Universally Adjustable Tray with
Drawer, 400-Sheet Universally Adjustable Tray
with Drawer, 5-Bin Mailbox, 550-Sheet Drawer,
Envelope Feeder, 250-Sheet Drawer, Optional
furniture required., 2,000-Sheet High-capacity
Feeder, 550-Sheet Output Expander, StapleSmart
II Finisher
Paper Input Capacity, Standard 350 pages 20 lb or 75 gsm bond 650 pages 20 lb or 75 gsm bond 650 pages 20 lb or 75 gsm bond
Paper Input Capacity, Maximum 4000 pages 20 lb or 75 gsm bond 4300 pages 20 lb or 75 gsm bond 4300 pages 20 lb or 75 gsm bond
Paper Output Capacity, Standard 350 pages 20 lb or 75 gsm bond 350 pages 20 lb or 75 gsm bond 550 pages 20 lb or 75 gsm bond
Paper Output Capacity, Maximum 2750 pages 20 lb or 75 gsm bond 2750 pages 20 lb or 75 gsm bond 2950 pages 20 lb or 75 gsm bond
Media Types Supported Card Stock, Dual Web Labels, Envelopes, Integrated Labels, Paper Labels, Plain Paper, Polyester Labels, Transparencies, Vinyl Labels, Refer to the Card Stock
& Label Guide
Media Sizes Supported 10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, DL Envelope, A6 Card, Executive, Folio, JIS-B5, Legal, Letter, Statement, Universal
Compatibility
Network Protocol Support TCP/IP IPv4, IPX/SPX, AppleTalk™, LexLink (DLC), TCP/IP IPv6, TCP, UDP
Printer Languages (Standard) PCL 5e Emulation, PCL 6 Emulation, Personal Printer Data Stream (PPDS), PostScript 3 Emulation, xHTML, PDF 1.6, Direct Image, Microsoft XPS (XML Paper
Specification)
Standard Ports Ethernet 10/100BaseTX (RJ-45), One Internal
Card Slot, USB 2.0 Specification Hi-Speed
Certified, Front USB port Compatible with USB
2.0 Specification (Type A)
Ethernet 10/100BaseTX (RJ-45), One Internal
Card Slot, USB 2.0 Specification Hi-Speed
Certified, Front USB port Compatible with USB
2.0 Specification (Type A)
Ethernet 10/100BaseTX (RJ-45), One Internal
Card Slot, USB 2.0 Specification Hi-Speed
Certified, Front USB 2.0 Specification Hi-Speed
Certified port (Type A), Rear USB 2.0 Specification
Hi-Speed Certified port (Type A)
Microsoft Windows Operating Systems Supported 2000, XP, Server 2003, XP x64, Server 2003 running Terminal Services, 2000 Server running Terminal Services, Server 2003 x64, Server 2003 x64 running
Terminal Services, Vista, Vista x64, Server 2008, Server 2008 x64, Server 2008 running Terminal Services, Server 2008 x64 running Terminal Services
Apple Macintosh Operating Systems Supported Mac OS X, Mac OS 9.x
Other Operating Systems Supported www.lexmark.com
General
Product Warranty 1-Year Exchange Service, Next Business Day
Product Certifications www.lexmark.com
Size (in. - H x W x D) 13.7 x 16.7 x 19.4 in. 16.8 x 16.7 x 20.1 in. 17.2 x 16.7 x 20.1 in.
Weight (lb.) 40.6 lb. 50.7 lb. 51.6 lb.
Specified Operating Environment Temperature: 16 to 32°C (60 to 90°F), Humidity: 8 to 80% Relative Humidity, Altitude: 0 - 3048 Meters (10,000 Feet)

Ordering information Lexmark T650 Series
In the box
Lexmark T652n Laser Printer, Up to 10,000*-page starter Return Program Print Cartridge, Software and documentation CD, Setup guide or sheet (network
and local attachment), Power cord(s), Statement of limited warranty, Safety sheet or booklet, Lexmark Cartridge Collection Program information
In the box
Lexmark T650n Laser Printer, Up to 7,000*-page Return Program Print Cartridge, Software and documentation CD, Setup guide or sheet (network and local
attachment), Power cord(s), Statement of limited warranty, Safety sheet or booklet, Lexmark Cartridge Collection Program information
Models available
Lexmark T650n: Network ready, Part #30G0100
Lexmark T650dn: Network ready plus duplex, Part #30G0106
Lexmark T650dtn: Network ready plus duplex with extra input drawer, Part #30G0107
Models available
Lexmark T652n: Network ready, Part #30G0210
Lexmark T652dn: Network ready plus duplex, Part #30G0200
Lexmark T652dtn: Network ready plus duplex with extra input drawer, Part #30G0108
Part # Model
30G0100 Lexmark T650n
Lexmark T650n Part # Laser Toner/Print Cartridge
T650H11A T65x High Yield Return Program Print Cartridge
T650A11A T65x Return Program Print Cartridge
T650H04A T65x High Yield Return Program Print Cartridge for Label Applications
T650H21A T65x High Yield Print Cartridge
T650A21A T65x Print Cartridge
25A0013 Staple Cartridges (3 pack)
Part # Paper & Transparencies
70X7240 Laser Printer Transparencies (Letter)
Part # Paper Handling
30G0806 T650 250-Sheet Duplex Unit
30G0804 2000-Sheet High Capacity Feeder
30G0802 550-Sheet Drawer
30G0800 250-Sheet Drawer
30G0853 T65x High Capacity Output Stacker
30G0851 T65x Output Expander
30G0852 T65x 5-Bin Mailbox
30G0807 Envelope Feeder
30G0860 400-Sheet Universally Adjustable Tray with Drawer
30G0880 T65x Kiosk Presenter
30G0850 T65x StapleSmart II Finisher
30G0871 200-Sheet Universally Adjustable Tray with Drawer
Part # Furniture
16M1207 T650, T652, T654 Caster Base
Part # Memory Options
1022298 128MB DDR1-DRAM
1022299 256MB DDR1-DRAM
1022301 512MB DDR1-DRAM
14F0245 256MB Flash Card
14F0102 80+GB Hard Disk
30G0828 Japanese Font Card
30G0825 Korean Font Card
30G0826 Simplified Chinese Font Card
30G0827 Traditional Chinese Font Card
Part # Application Solutions
30G0829 Lexmark PrintCryption Card
30G0830 T650, T652 Forms and Bar Code Card
30G0831 T650, T652 Card for IPDS/SCS/TNe
Part # Connectivity
1021294 USB (2 Meter) Cable
14F0000 Parallel 1284-B Interface Card
1021231 Parallel (10’) Cable
14F0100 RS-232C Serial Interface Card
14F0037 MarkNet N8120 Gigabit Ethernet Print Server
14F0042 MarkNet N8130 Fiber Ethernet 100BaseFX, 10BaseFL Print Server
14F0040 MarkNet N8150 802.11b/g/n Wireless Print Server
14T0145 Lexmark N4050e 802.11g Wireless Print Server
14T0220 MarkNet™ N7020e Gigabit Ethernet Print Server
Part # Extended Warranties
2350293 2-Years Total Exchange Service, Next Business Day
2350294 3-Years Total Exchange Service, Next Business Day
2350295 4-Years Total Exchange Service, Next Business Day
2350296 5-Years Total Exchange Service, Next Business Day
2350297 1-Year Exchange Service Renewal, Next Business Day
2350301 Upgrade to Onsite Service, Next Business Day
2350302 2-Years Total Onsite Service, Next Business Day
2350303 3-Years Total Onsite Service, Next Business Day
2350304 4-Years Total Onsite Service, Next Business Day
2350305 5-Years Total Onsite Service, Next Business Day
2350306 1-Year Onsite Service Renewal, Next Business Day
Part # User Replaceable Parts
40X4724 T65x, X654e, X656e, X658e Fuser Maintenance Kit 110-120V
40X5852 Dual Charge Roll Assembly
40X1886 Transfer Roll Assembly
40X2665 Oil Fuser Wiper
40X2666 Wax Fuser Wiper
40X4308 Pick Roll Assembly
350-Sheet Output Bin
100-Sheet Multipurpose
Feeder
250-Sheet Input Tray
250-Sheet Drawer / 550-
Sheet Drawer
250-Sheet Drawer / 550-
Sheet Drawer
Envelope Feeder
250-Sheet Duplex Unit
250-Sheet Drawer / 550-
Sheet Drawer
250-Sheet Drawer / 550-
Sheet Drawer / 2,000-Sheet
High-capacity Feeder
T650, T652, T654
Caster Base
T65x StapleSmart II
Finisher
2 x T65x 5-Bin Mailbox T65x High Capacity Output
Stacker
3 x T65x Output Expander
T65x StapleSmart II
Finisher + T65x Output
Expander
T65x High Capacity Output
Stacker + T65x Output
Expander
T65x 5-Bin Mailbox + T65x
Output Expander
Paper Handling Standard
Paper Handling Optional
Part # Model
30G0210 Lexmark T652n
Lexmark T652n Part # Laser Toner/Print Cartridge
T650H11A T65x High Yield Return Program Print Cartridge
T650A11A T65x Return Program Print Cartridge
T650H04A T65x High Yield Return Program Print Cartridge for Label Applications
T650H21A T65x High Yield Print Cartridge
T650A21A T65x Print Cartridge
25A0013 Staple Cartridges (3 pack)
Part # Paper & Transparencies
70X7240 Laser Printer Transparencies (Letter)
Part # Paper Handling
30G0852 T65x 5-Bin Mailbox
30G0804 2000-Sheet High Capacity Feeder
30G0802 550-Sheet Drawer
30G0800 250-Sheet Drawer
30G0807 Envelope Feeder
30G0851 T65x Output Expander
30G0853 T65x High Capacity Output Stacker
30G0860 400-Sheet Universally Adjustable Tray with Drawer
30G0880 T65x Kiosk Presenter
30G0850 T65x StapleSmart II Finisher
30G0871 200-Sheet Universally Adjustable Tray with Drawer
Part # Furniture
16M1207 T650, T652, T654 Caster Base
Part # Memory Options
1022298 128MB DDR1-DRAM
1022299 256MB DDR1-DRAM
1022301 512MB DDR1-DRAM
14F0245 256MB Flash Card
14F0102 80+GB Hard Disk
30G0828 Japanese Font Card
30G0825 Korean Font Card
30G0826 Simplified Chinese Font Card
30G0827 Traditional Chinese Font Card
Part # Application Solutions
30G0829 Lexmark PrintCryption Card
30G0830 T650, T652 Forms and Bar Code Card
30G0831 T650, T652 Card for IPDS/SCS/TNe
Part # Connectivity
1021294 USB (2 Meter) Cable
14F0000 Parallel 1284-B Interface Card
1021231 Parallel (10’) Cable
14F0100 RS-232C Serial Interface Card
14F0037 MarkNet N8120 Gigabit Ethernet Print Server
14F0042 MarkNet N8130 Fiber Ethernet 100BaseFX, 10BaseFL Print Server
14F0040 MarkNet N8150 802.11b/g/n Wireless Print Server
14T0145 Lexmark N4050e 802.11g Wireless Print Server
14T0220 MarkNet™ N7020e Gigabit Ethernet Print Server
Part # Extended Warranties
2350328 2-Years Total Exchange Service, Next Business Day
2350329 3-Years Total Exchange Service, Next Business Day
2350330 4-Years Total Exchange Service, Next Business Day
2350331 5-Years Total Exchange Service, Next Business Day
2350332 1-Year Exchange Service Renewal, Next Business Day
2350336 Upgrade to Onsite Service, Next Business Day
2350337 2-Years Total Onsite Service, Next Business Day
2350338 3-Years Total Onsite Service, Next Business Day
2350339 4-Years Total Onsite Service, Next Business Day
2350340 5-Years Total Onsite Service, Next Business Day
2350341 1-Year Onsite Service Renewal, Next Business Day
Part # User Replaceable Parts
40X4724 T65x, X654e, X656e, X658e Fuser Maintenance Kit 110-120V
40X5852 Dual Charge Roll Assembly
40X1886 Transfer Roll Assembly
40X2665 Oil Fuser Wiper
40X2666 Wax Fuser Wiper
40X4308 Pick Roll Assembly
350-Sheet Output Bin
100-Sheet Multipurpose
Feeder
550-Sheet Input Tray
250-Sheet Drawer / 550-
Sheet Drawer
250-Sheet Drawer / 550-
Sheet Drawer
Envelope Feeder
250-Sheet Drawer / 550-
Sheet Drawer / 2,000-Sheet
High-capacity Feeder
250-Sheet Drawer / 550-
Sheet Drawer
T650, T652, T654
Caster Base
T65x StapleSmart II
Finisher
2 x T65x 5-Bin Mailbox T65x High Capacity Output
Stacker
3 x T65x Output Expander
T65x StapleSmart II
Finisher + T65x Output
Expander
T65x High Capacity
Output Stacker + T65x
Output Expander
T65x 5-Bin Mailbox + T65x
Output Expander
Paper Handling Standard
Paper Handling Optional

Ordering information Lexmark T650 Series
www.lexmark.com
Models available In the box
Lexmark T654n Laser Printer, Up to 10,000*-page starter Return Program Print Cartridge, Software and documentation CD, Setup guide or sheet (network
and local attachment), Power cord(s), Statement of limited warranty, Safety sheet or booklet, Lexmark Cartridge Collection Program information
Environmental commitment Cost-saving and environmental features
Lexmark believes that the environment is a critical component of responsible business
management and clearly demonstrates it by implementing the “4R” strategy: Reduce,
Recover, Reuse and Recycle. To learn more about these programs please visit www.
lexmark.com/recycle.
- Duplex models are Energy Star compliant
- Duplex printing, Print and Hold, multi-up and support of recycled paper help reduce paper consumption
- Eco-Mode reduces power consumption and Quiet Mode reduces noise
- High Yield Cartridges and Lexmark Cartridge Collection Program help reduce waste
Lexmark T654n: Network ready, Part #30G0310
Lexmark T654dn: Network ready plus duplex, Part #30G0300
Lexmark T654dtn: Network ready plus duplex with extra input drawer, Part #30G0109
Lexmark’s guarantee to you
Lexmark’s 1-Year Exchange Service, Next Business Day warranty on the Lexmark T650 Series provides added peace of mind. Enhanced service offerings may be available by contacting your Lexmark representative or visiting www.lexmark.com. Optimize your printer’s
performance and investment value by using Original Lexmark Supplies, Service and Parts.
Part # Model
30G0310 Lexmark T654n
Lexmark T654n Part # Laser Toner/Print Cartridge
T654X11A T654 Extra High Yield Return Program Print Cartridge
T650H11A T65x High Yield Return Program Print Cartridge
T650A11A T65x Return Program Print Cartridge
T654X04A T654 Extra High Yield Return Program Print Cartridge for Label Applications
T650H04A T65x High Yield Return Program Print Cartridge for Label Applications
T654X21A T654 Extra High Yield Print Cartridge
T650H21A T65x High Yield Print Cartridge
T650A21A T65x Print Cartridge
25A0013 Staple Cartridges (3 pack)
Part # Paper & Transparencies
70X7240 Laser Printer Transparencies (Letter)
Part # Paper Handling
30G0804 2000-Sheet High Capacity Feeder
30G0802 550-Sheet Drawer
30G0800 250-Sheet Drawer
30G0807 Envelope Feeder
30G0852 T65x 5-Bin Mailbox
30G0851 T65x Output Expander
30G0853 T65x High Capacity Output Stacker
30G0850 T65x StapleSmart II Finisher
30G0860 400-Sheet Universally Adjustable Tray with Drawer
30G0880 T65x Kiosk Presenter
30G0871 200-Sheet Universally Adjustable Tray with Drawer
Part # Furniture
16M1207 T650, T652, T654 Caster Base
Part # Memory Options
1025041 256MB DDR2-DRAM
1025042 512MB DDR2-DRAM
1025043 1024MB DDR2-DRAM
14F0245 256MB Flash Card
14F0102 80+GB Hard Disk
30G0828 Japanese Font Card
30G0825 Korean Font Card
30G0827 Traditional Chinese Font Card
30G0826 Simplified Chinese Font Card
Part # Application Solutions
30G0829 Lexmark PrintCryption Card
30G0835 T654 Card for IPDS and SCS/TNe
30G0834 T654 Forms and Bar Code Card
Part # Connectivity
1021294 USB (2 Meter) Cable
14F0000 Parallel 1284-B Interface Card
1021231 Parallel (10’) Cable
14F0100 RS-232C Serial Interface Card
14F0037 MarkNet N8120 Gigabit Ethernet Print Server
14F0042 MarkNet N8130 Fiber Ethernet 100BaseFX, 10BaseFL Print Server
14F0040 MarkNet N8150 802.11b/g/n Wireless Print Server
14T0145 Lexmark N4050e 802.11g Wireless Print Server
14T0220 MarkNet™ N7020e Gigabit Ethernet Print Server
Part # Extended Warranties
2350363 2-Years Total Exchange Service, Next Business Day
2350364 3-Years Total Exchange Service, Next Business Day
2350365 4-Years Total Exchange Service, Next Business Day
2350366 5-Years Total Exchange Service, Next Business Day
2350367 1-Year Exchange Service Renewal, Next Business Day
2350371 Upgrade to Onsite Service, Next Business Day
2350372 2-Years Total Onsite Service, Next Business Day
2350373 3-Years Total Onsite Service, Next Business Day
2350374 4-Years Total Onsite Service, Next Business Day
2350375 5-Years Total Onsite Service, Next Business Day
2350376 1-Year Onsite Service Renewal, Next Business Day
Part # User Replaceable Parts
40X4724 T65x, X654e, X656e, X658e Fuser Maintenance Kit 110-120V
40X5852 Dual Charge Roll Assembly
40X1886 Transfer Roll Assembly
40X2665 Oil Fuser Wiper
40X2666 Wax Fuser Wiper
40X4308 Pick Roll Assembly
550-Sheet Output Bin
100-Sheet Multipurpose
Feeder
550-Sheet Input Tray
250-Sheet Drawer / 550-
Sheet Drawer
250-Sheet Drawer / 550-
Sheet Drawer
Envelope Feeder
250-Sheet Drawer / 550-
Sheet Drawer
250-Sheet Drawer / 550-
Sheet Drawer / 2,000-Sheet
High-capacity Feeder
T650, T652, T654
Caster Base
T65x StapleSmart II
Finisher
2 x T65x 5-Bin Mailbox T65x High Capacity Output
Stacker
3 x T65x Output Expander
T65x StapleSmart II
Finisher + T65x Output
Expander
T65x High Capacity Output
Stacker + T65x Output
Expander
T65x 5-Bin Mailbox + T65x
Output Expander
Paper Handling Standard
Paper Handling Optional
