Parts catalog 7-1
5026
Go Back
Previous
Next
7. Parts catalog
How to use this parts catalog
The following legend is used in the parts catalog:
•Asm-index: Identifies the assembly and the item in the diagram. For example, 3-1 indicates Assembly 3
and item number 1 in the table.
•Part number: Identifies the unique number that identifies this FRU.
•Units/mach: Refers to the number of units actually used in the base machine or product.
•Units/option: Refers to the number of units in a particular option. It does not include the rest of the base
machine.
•Units/FRU: Refers to the number of units packaged together and identified by the part number.
•NS: (Not shown) in the Asm-Index column indicates that the part is procurable but is not pictured in the
illustration.
•Model information used in the parts catalog:
Asm-
index Part number Units/mach Units/
FRU Description
Abbreviation
used Machine type and model Printer name Description
310 5026-310 Lexmark C746n Network-ready
330 5026-330 Lexmark C746dn Network-ready with duplex
330 5026-330 Lexmark C746dtn Network-ready with duplex and 550 sheet
tray
510 5026-510 Lexmark C748e Network-ready with etask touch screen
530 5026-530 Lexmark C748de Network-ready with etask touch screen and
duplex
530 5026-530 Lexmark C748dte Network-ready with etask touch screen,
duplex, and 550 sheet tray
www MK-Electronic de

7-2 Service Manual
5026
Go Back
Previous
Next
Assembly 1: Covers (C746)
1
2
3
4
5
16 17
17
13
14
15
6
7
8
9
10
11
12
18
www MK-Electronic de

Parts catalog 7-3
5026
Go Back
Previous
Next
Assembly 1: Covers (C746)
Index P/N Units/
mach Units/ FRU Description
1—1 40X7520 1 1 Top access cover assembly, 2.3 inch
2 40X7660 1 1 2.3 inch operator panel buttons parts package
Includes the following:
•Button kit
•Sleep button
•Return button
•Select button
•Navigation button
•Home button
•LED Lens
3 40X5121 1 1 Bin full sensor with cable
4 40X7603 1 1 2.3 inch operator panel assembly with card
Includes the following:
•LCD Display
•UICC card
5 40X7966 1 1 Top access cover parts package
Includes the following:
•Bin full flag
•Operator panel display bracket
6 40X5106 1 1 Output bin extension cover
7 40X5103 1 1 Rear upper cover
8 40X5993 1 1 Top cover assembly
9 40X5287 1 1 Cooling fan filter
10 40X5145 1 1 Rear frame cover
11 40X5105 1 1 Rear right cover
12 40X5153 1 1 Dust cover assembly
13 40X5104 1 1 Rear left cover
14 40X5994 1 1 Right cover
15 40X7661 1 1 Front access door cover assembly
16 40X5102 1 1 Left cover
17 40X5119 1 1 Top access cover links (slider cam)
Note: The left link is also available in the top access cover assembly and
the right link is also available in the EP drive assembly
18 40X8317 1 1 Operator panel bezel, C74x (blank logo)
18 40X6879 1 1 Operator panel bezel, C746n
18 40X7335 1 1 Operator panel bezel, C746dn and C746dtn
www MK-Electronic de

7-4 Service Manual
5026
Go Back
Previous
Next
Assembly 2: Covers (C748)
1
2
3
6
19 18
18
17
15
16
78
9
11
12
14
13
20
4
5
10
www MK-Electronic de

Parts catalog 7-5
5026
Go Back
Previous
Next
Assembly 2: Covers (C748)
Index P/N Units/
mach Units/ FRU Description
2—1 40X5988 1 1 Top access cover assembly, 4.3 inch
2 40X5990 1 1 4.3 inch operator panel buttons parts package
Includes the following:
•Button kit
•Home button
•Sleep button
•LED Lens
3 40X5121 1 1 Bin full sensor with cable
4 40X5989 1 1 UICC card
5 40X7116 1 1 4.3 inch LCD display
6 40X7966 1 1 Top access cover parts package
Includes the following
•Bin full flag
•Operator panel display bracket
7 40X5106 1 1 Output bin extension cover
8 40X5103 1 1 Rear upper cover
9 40X5993 1 1 Top cover assembly
10 40X7703 1 1 Speaker
11 40X5287 1 1 Cooling fan filter
12 40X5145 1 1 Rear frame cover
13 40X5153 1 1 Dust cover assembly
14 40X5105 1 1 Rear right cover
15 40X5994 1 1 Right cover
16 40X7661 1 1 Front access door cover assembly
17 40X5104 1 1 Rear left cover
18 40X5119 1 1 Top access cover links (slider cam)
Note: The left link is also available in the top access cover assembly and
the right link is also available in the EP drive assembly
19 40X5102 1 1 Left cover
20 40X8317 1 1 Operator panel bezel, C74x (blank logo)
20 40X6877 1 1 Operator panel bezel, C748de
20 40X8259 1 1 Operator panel bezel, C748e
www MK-Electronic de

7-6 Service Manual
5026
Go Back
Previous
Next
Assembly 3: Front
1
2
3
4
7
12
11
13
14
10
A
B
D
E
C
G
F
F
5
6
8
9
www MK-Electronic de

Parts catalog 7-7
5026
Go Back
Previous
Next
Assembly 3: Front
Index P/N Units/
mach Units/ FRU Description
3—1 40X8110 1 1 Fuser assembly, 115 V
1 40X8111 1 1 Fuser assembly, 230 V
1 40X8112 1 1 Fuser assembly, 100 V
2 Printer pad, included in screws parts packet (P/N 40X5136)
3 40X1446 1 1 Right bellcrank assembly, with spring
4 40X5132 1 1 MP feeder/duplex drive parts packet
Includes the following
•Retainer release arm
•Grease packet (Nyogel 744)
•Washer
•Duplex engagement gear
•MP feeder reduction gear
•MP feeder/duplex reduction gear
•MP feeder drive cover
5 40X6319 1 1 Cranklift spring and metal clip
6 40X8308 1 1 Paper pick assembly
7 40X5152 2 2 Pick arm roll
8 40X5999 1 1 Paper tray assembly, 550-sheet
9 40X6496 1 1 MPF pick arm assembly
10 40X5111 1 1 Front door parts packet
Includes the following:
•A—Front access door cap (1)
•B—Right cable assembly (1)
•C—Front access cover pivot (1)
•D—Left cable assembly (1)
•E—Front access door straps (2)
•F—Front access door bracket (1)
•G—Screw
11 40X5113 1 1 Duplex reference edge assembly
12 40X5995 1 1 Front door assembly
13 40X8307 1 1 Transfer module
14 40X1447 1 1 Left bellcrank assembly, with spring
www MK-Electronic de

7-8 Service Manual
5026
Go Back
Previous
Next
Assembly 4: Right
1
2
3
4
5
6
7
www MK-Electronic de

Parts catalog 7-9
5026
Go Back
Previous
Next
Assembly 4: Right
Index P/N Units/
mach Units/ FRU Description
4—1 40X5290 1 1 EP drive assembly
2 40X5991 1 1 Low-voltage power supply
3 40X5126 1 1 Motor driver card
4 40X8309 1 1 MP feeder/duplex motor
5 40X5128 1 1 24 V interlock switch
6 40X5127 1 1 5 V interlock switch
7 40X5998 1 1 MPF paper present sensor with cable
www MK-Electronic de

7-10 Service Manual
5026
Go Back
Previous
Next
Assembly 5: Rear
www MK-Electronic de

Parts catalog 7-11
5026
Go Back
Previous
Next
Assembly 5: Rear
Index P/N Units/
mach Units/ FRU Description
5—1 40X5123 1 1 Printhead assembly
2 40X5107 1 1 System board support shield
3 40X5996 1 1 System board, 4.3 inch model
3 40X7953 1 1 System board, 2.3 inch model
NS 40X0269 1 1 Power cord—USA, Canada, Bolivia, Peru
NS 40X0288 1 1 Power cord (8 ft.)—Argentina
NS 40X0301 1 1 Power cord (8 ft.)—Australia, New Zealand
NS 40X3141 1 1 Power cord (8 ft.)—Austria, Belgium, Catalan, Czechoslovakia, Finland,
France, Germany, Greece, Hungary, Ireland, Italy, Netherlands, Norway,
Paraguay, Poland, Portugal, Russia, Spain, Sweden, Turkey, United
Kingdom
NS 40X0271 1 1 Power cord (8 ft.)—Hong Kong, Ireland, United Kingdom
NS 40X4596 1 1 Power cord (8 ft.)—Brazil
NS 40X0273 1 1 Power cord (8 ft.)—Chile, Uruguay
NS 40X0303 1 1 Power cord (8 ft.)—China
NS 40X1774 1 1 Power cord (8 ft.)—Denmark, Finland, Norway, Sweden
NS 40X0275 1 1 Power cord (8 ft.)—Israel
NS 40X3609 1 1 Power cord (8 ft.)—Japan
NS 40X1792 1 1 Power cord (8 ft.)—Korea
NS 40X1773 1 1 Power cord (8 ft.)—South Africa
NS 40X1772 1 1 Power cord (8 ft.)—Switzerland
NS 40X1791 1 1 Power cord (8 ft.)—Taiwan
www MK-Electronic de

7-12 Service Manual
5026
Go Back
Previous
Next
Assembly 6: Left
(4 places)
1B
(4 places)(4 places)
1A
1C
(4 places)
(4 places)
3
(8 places)
(4 places)
1G
1E
1F
5
1D 2
6
4
www MK-Electronic de

Parts catalog 7-13
5026
Go Back
Previous
Next
Assembly 6: Left
Index P/N Units/
mach Units/ FRU Description
6—1 40X5137 1 1 Contact springs kit
Includes the following:
•A—Torsion PCD contact spring
•B—Torsion CR contact spring
•C—Contact spring cap
•D—Charge roll contact spring
•E—HVPS TAR contact spring
•F—HVPS doctor/developer contact spring
•G—HVPS Db contact spring
•Screw
2 40X7159 1 1 Auger shaft and gear parts pack
3 40X5307 1 1 Waste toner HV contact assembly
4 40X5129 1 1 High-voltage power supply
5 40X1416 4 1 Toner level sensor
6 40X8373 1 1 Toner cartridge contacts
www MK-Electronic de

7-14 Service Manual
5026
Go Back
Previous
Next
Assembly 7: Top
Index P/N Units/
mach Units/ FRU Description
7—1 40X5122 1 1 Color-On-Demand assembly
2 40X5109 1 1 Cooling fan
3 40X5130 1 1 Top cover camshaft assembly
4 40X5108 1 1 Cartridge cooling fan
3
4
1
2
www MK-Electronic de

Parts catalog 7-15
5026
Go Back
Previous
Next
Assembly 8: Cable parts packet
Index P/N Units/
mach Units/ FRU Description
NS 40X7973 1 1 Cables parts packet, including
•Duplex/MPF motor cable
•Fuser AC cable
•Fuser DC cable
•HVPS cable
•Transport cable
•Fuser and cartridge 1 motor cable
•Cartridge 2 and 3 motor cable
•USB-A cable
•550 option cable
•Transport motor cable
•Speaker cable
•UICC cable (for single-function)
•UICC cable (for multi-function)
•Operator panel ground cable (for single-function)
•Operator panel ground cable (for multi-function)
NS 40X6351 1 1 Motor driver cable
www MK-Electronic de

7-16 Service Manual
5026
Go Back
Previous
Next
Assembly 9: Optional 550-sheet media drawer and tray
Index P/N Units/
opt Units/ FRU Description
9—1 40X5140 1 1 550-sheet tray option (drawer and tray assembly)
2 40X5168 2 2 Pick arm roll, 550-sheet tray
3 40X5141 1 1 550-sheet tray assembly
3
2
1
www MK-Electronic de

Parts catalog 7-17
5026
Go Back
Previous
Next
Assembly 10: Optional special media tray assembly
Index P/N Units/
opt. Units/ FRU Description
10—1 40X5142 1 1 Special media assembly, including tray
2 40X5152 2 2 Pick arm roll, 550-sheet drawer
3 40X5143 1 1 Special media tray assembly
1
3
2
www MK-Electronic de

7-18 Service Manual
5026
Go Back
Previous
Next
Assembly 11: Optional high-capacity input option (HCIT)
4
2
1
6
5
7
8
11
12
10
13
14
3
9
www MK-Electronic de

Parts catalog 7-19
5026
Go Back
Previous
Next
Assembly 11: Optional high-capacity input option (HCIT)
Index P/N Units/
option Units/ FRU Description
11—1 40X5157 1 1 Top plate assembly
2 40X5168 2 2 HCIT pick arm roll
3 40X5156 1 1 Feed with bushing
4 40X5149 1 1 HCIT rear cover
5 40X4585 2 1 Tray latch with spring
6 40X5159 1 1 HCIT controller card assembly
7 40X4587 1 1 Slide assembly with springs
8 40X5147 1 1 HCIT right cover
9 40X5155 1 1 Elevator motor with sensor
10 40X5158 1 1 Photointerrupter sensor with cable assembly
11 40X4593 2 1 HCIT drawer slide assembly
12 40X5146 1 1 HCIT front tray cover
13 40X5144 1 1 HCIT paper drawer tray assembly
14 40X5148 1 1 HCIT left cover
www MK-Electronic de
