Disassembly of Waste Electrical and Electronic Equipment (WEEE) Manual
EU Waste Electronic and Electrical Equipment Directive require producers to provide information of the different electronic
and electrical materials and components found in their products at its end-of-life, and disassembly references to treatment
and recycling facilities.
The disassembly information for this product has been prepared for use by a recognized treatment or recycling facility and
is not intended to be used by others.
1. Product information
2. Materials and components list for selective treatment
3. Disassembly tools
4. Disassembly references
The following information is intended only for the use of treatment and recycling facilities.
All disassembly instructions should be performed with the power switch in the OFF position. Disconnect the power cord
from the wall outlet and from the printer before continuing. If there are any other devices attached to the printer, then turn
them off as well, and unplug any cables going into the printer.
1. Product information
Model name(s)—Indicate all model name(s) within the product family
Model name
Lexmark MS310 series –
Lexmark MS310d, Lexmark MS310dn
Lexmark MS410 series –
Lexmark MS410d, Lexmark MS410dn
Lexmark MS510 series –
Lexmark MS510dn (Lexmark M1145)
Lexmark MS610 series –
Lexmark MS610dn , Lexmark MS610dtn, Lexmark MS610de (Lexmark M3150), Lexmark MS610dte
* Add rows as needed
2. Materials and components list for selective treatment
Items
Quantity
Notes
Polychlorinated biphenyls (PCB) containing capacitors
0
N/A
Mercury containing components, such as switches or
backlighting lamps
0
N/A
Batteries
1
Lithium Manganese Dioxide coin cell
located on the system controller card

Doc No.: Rev. 001 Page 2 of 13
Printed circuit boards greater than 10 cm2
4
Plus one (1) for MS610dtn and
MS610dte models (locations illustrated
in 4.2)
Toner cartridges, liquid and pasty, as well as colour
toner
1
Located inside front cover
Plastic containing brominated flame retardants
1 Fan;
12
Sensors;
3 Fuser
parts
Fan(s) and Sensors (locations
illustrated in 4.2)
Plastic parts located in the
fuser assembly marked with
recycle code that includes "FR17"
(See Appendix A for description)
Asbestos waste and components which contain
asbestos
0
N/A
Cathode ray tubes
0
N/A
Chlorofluorocarbons (CFC), Hydrochlorofluorocarbons
(HCFC) or Hydrofluorocarbons (HFC), Hydrocarbons
(HC)
0
N/A
Gas discharge lamps
0
N/A
Liquid Crystal Display (LCD) greater than 100 cm2and
those back-lighted with Gas discharge lamps
0
N/A
External electrical cables
1
Power cord located on the back lower
left quadrant
Components containing refractory fibres
0
N/A
Components containing radioactive substances
0
N/A
Electrolyte capacitors containing substances of
concern1
1
Capacitor(s) located on Power Supply
(locations illustrated in 4.2)
1With (height > 25 mm, diameter > 25 mm or proportionately similar volume)
3. Disassembly tools
4. Disassembly references
4.1. Removal procedure(s)
MS310 WEEE removal MS410 WEEE removal MS510 & MS510 WEEE removal
WEEE materials and components removal procedures are available upon request.
Contact: [e-mail]
Item
#2 Phillips screwdriver, magnetic
Wire cutter
E-clip puller or small flat-head screwdriver
Standard slotted head screwdriver

Doc No.: Rev. 001 Page 3 of 13
4.2. Graphical illustration of material’s and component’s location
MS310 Series
Location

Doc No.: Rev. 001 Page 4 of 13
MS310 Series
Location

Doc No.: Rev. 001 Page 5 of 13
MS310 Series
Location

Doc No.: Rev. 001 Page 6 of 13
MS410 Series
Location

Doc No.: Rev. 001 Page 7 of 13
MS410 Series
Location

Doc No.: Rev. 001 Page 8 of 13
MS410 Series
Location

Doc No.: Rev. 001 Page 9 of 13
MS510 & MS610 Series
Location

Doc No.: Rev. 001 Page 10 of
13
MS510 & MS610 Series
Location

Doc No.: Rev. 001 Page 11 of
13
MS510 & MS610 Series
Location

Doc No.: Rev. 001 Page 12 of
13
MS310, MS410, MS510 & MS610 Series
Location

Doc No.: Rev. 001 Page 13 of
13
Appendix A
Plastic containing brominated flame retardants
Part Description
Parts Marking
Location
ALIGNER –FUSR HEATER ASM
PET-(GF+MD)40 FR(17)
FUSER AREA
GUIDE (MECHANICAL) –GUIDE-
LOWER INPUT
PET-(GF+MD)40 FR(17)
FUSER AREA
GUIDE (MECHANICAL) –FUSER
LOWR EXIT
PET-(GF+MD)40 FR(17)
FUSER AREA
