Lexmark MS810n User manual

Doc No.: Rev. 001 Page 1 of 17
Disassembly of Waste Electrical and Electronic Equipment (WEEE) Manual
EU Waste Electronic and Electrical Equipment Directive require producers to provide information of the different electronic
and electrical materials and components found in their products at its end-of-life, and disassembly references to treatment
and recycling facilities.
The disassembly information for this product has been prepared for use by a recognized treatment or recycling facility and
is not intended to be used by others.
1. Product information
2. Materials and components list for selective treatment
3. Disassembly tools
4. Disassembly references
The following information is intended only for the use of treatment and recycling facilities.
All disassembly instructions should be performed with the power switch in the OFF position. Disconnect the power cord
from the wall outlet and from the printer before continuing. If there are any other devices attached to the printer, then turn
them off as well, and unplug any cables going into the printer.
1. Product information
Model name(s)—Indicate all model name(s) within the product family
Model name
Lexmark MS810 series –
Lexmark MS810n, Lexmark MS810dn, Lexmark MS810dtn, Lexmark MS810de (Lexmark M5155, Lexmark
M5163), Lexmark MS811n, Lexmark MS811dn, Lexmark MS811dtn, Lexmark MS812dn, Lexmark MS812dtn,
Lexmark MS812de (Lexmark M5170)
* Add rows as needed
2. Materials and components list for selective treatment
Items
Quantity
Notes
Polychlorinated biphenyls (PCB) containing capacitors
0
N/A
Mercury containing components, such as switches or
backlighting lamps
0
N/A
Batteries
1
Lithium Manganese Dioxide coin cell
located on the system controller card
Printed circuit boards greater than 10 cm2
8
Plus one (1) for MS810dtn, MS811dtn,
MS812dtn models (locations illustrated
in 4.2)
Toner cartridges, liquid and pasty, as well as colour
toner
1
Located inside front cover
Doc No.: Rev. 001 Page 2 of 17
Plastic containing brominated flame retardants
3 Fans;
11
Sensors;
8 Fuser
parts
Fan(s) and Sensors (locations
illustrated in 4.2)
Plastic parts located in the fuser
assembly marked with recycle code
that includes "FR17"or “FR16”
Asbestos waste and components which contain
asbestos
0
N/A
Cathode ray tubes
0
N/A
Chlorofluorocarbons (CFC), Hydrochlorofluorocarbons
(HCFC) or Hydrofluorocarbons (HFC), Hydrocarbons
(HC)
0
N/A
Gas discharge lamps
0
N/A
Liquid Crystal Display (LCD) greater than 100 cm2and
those back-lighted with Gas discharge lamps
1
MS812de LCD located inside OP
panel
External electrical cables
1
Power cord located on the back lower
left quadrant
Components containing refractory fibres
0
N/A
Components containing radioactive substances
0
N/A
Electrolyte capacitors containing substances of
concern1
4
Capacitor(s) located on Power Supply
(locations illustrated in 4.2)
1With (height > 25 mm, diameter > 25 mm or proportionately similar volume)
3. Disassembly tools
4. Disassembly references
4.1. Removal procedure(s)
MS710, MS810 WEEE removal
WEEE materials and components removal procedures are available upon request.
Contact: recycling@lexmark.com
4.2. Graphical illustration of material’s and component’s location
See next page
Item
#2 Phillips screwdriver, magnetic
Wire cutter
E-clip puller or small flat-head screwdriver
Standard slotted head screwdriver
Doc No.: Rev. 001 Page 3 of 17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 4 of 17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 5 of 17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 6 of 17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 7 of 17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 8 of 17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 9 of 17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 10 of
17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 11 of
17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 12 of
17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 13 of
17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 14 of
17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 15 of
17
MS710, MS810 Series
Location
Doc No.: Rev. 001 Page 16 of
17
MS710, MS810 Series
Location
Sensors
Picture does not show all sensors used by the product
Doc No.: Rev. 001 Page 17 of
17
Appendix A
Plastic containing brominated flame retardants
Part Description
Parts Marking
Location
Guide - Lower Exit
PET-(GF+MD)40FR(17)
FUSER AREA
Guide - Upper Exit
PET-(GF+MD)40FR(17)
FUSER AREA
Guide - Fuser Lower Entry
PET-(GF+MD)40FR(17)
FUSER AREA
Plate - Transfer
PC-CD10 FR(16)
FUSER AREA
Base - Fuser Wiper HR
PET-(GF+MD)40 FR(17)
FUSER AREA
Wiper - Fuser Non Wick HR
PSSY-GF22 FR(17)
FUSER AREA
Guide (Mechanical) - Lower Exit
PA66-GF30 FR(17)
FUSER AREA
Guide (Mechanical) - Entry
PET-(GF+MD)40 FR(17)
FUSER AREA
