Lexmark MX6500e 6500e Use and care manual

6500e, T650n/dn/dtn, T652n/dn/dtn,
T654n/dn/dtn, X651 MFP, X652 MFP,
X654 MFP, X656 MFP, X658 MFP
Technical Reference
March 2013 www.lexmark.com
Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
All other trademarks are the property of their respective owners.
© 2013 Lexmark International, Inc.
All rights reserved.
740 West New Circle Road
Lexington, Kentucky 40550

Edition notice
March 2013
The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL,
INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of
express or implied warranties in certain transactions; therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these
changes will be incorporated in later editions. Improvements or changes in the products or the programs described may be made at any
time.
References in this publication to products, programs, or services do not imply that the manufacturer intends to make these available in all
countries in which it operates. Any reference to a product, program, or service is not intended to state or imply that only that product,
program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any existing intellectual
property right may be used instead. Evaluation and verification of operation in conjunction with other products, programs, or services,
except those expressly designated by the manufacturer, are the user’s responsibility.
For Lexmark technical support, visit support.lexmark.com.
For information on supplies and downloads, visit www.lexmark.com.
If you don't have access to the Internet, you can contact Lexmark by mail:
Lexmark International, Inc.
Bldg 004-2/CSC
740 New Circle Road NW
Lexington, KY 40550
USA
© 2013 Lexmark International, Inc.
All rights reserved.
Trademarks
Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other
countries.
Mac and the Mac logo are trademarks of Apple Inc., registered in the U.S. and other countries.
PCL® is a registered trademark of the Hewlett-Packard Company.
All other trademarks are the property of their respective owners.
UNITED STATES GOVERNMENT RIGHTS
This software and any accompanying documentation provided under this agreement are commercial computer software and documentation
developed exclusively at private expense.

Contents
Edition notice...............................................................................................2
Introduction.................................................................................................5
Understanding letters after model numbers............................................................................................5
Learning about the printer and the MFP option............................................7
Finding information about the printer......................................................................................................7
Printer Control Language (PCL) page formatting...........................................9
Printable areas..........................................................................................................................................9
Supported paper and envelope dimensions...........................................................................................10
Printer Job Language (PJL)..........................................................................12
PJL commands information.....................................................................................................................12
PostScript (PS) emulation...........................................................................13
Supported paper sizes.............................................................................................................................13
PostScript paper tray support.................................................................................................................14
PostScript envelope size support............................................................................................................16
PostScript envelope tray support............................................................................................................18
Printer and MFP option specifications........................................................20
Airflow requirement................................................................................................................................20
Noise emission levels..............................................................................................................................20
Electrical specifications...........................................................................................................................21
Power requirements................................................................................................................................22
Physical specifications.............................................................................................................................23
Clearance requirements..........................................................................................................................26
Environmental conditions.......................................................................................................................26
Altitude specifications and atmospheric pressure..................................................................................27
Appendix A: PCL support............................................................................28
PCL emulation commands.......................................................................................................................28
GL/2 commands......................................................................................................................................35
Contents 3

Appendix B: PJL support.............................................................................39
Common variables for both printer languages........................................................................................39
Lexmark‑unique PJL variables for both printer languages......................................................................42
Common variables for PCL emulation.....................................................................................................53
Lexmark‑unique variables for PCL emulation..........................................................................................54
Common variables for PostScript emulation...........................................................................................55
Lexmark‑unique variables for PostScript emulation...............................................................................55
Printer‑unique LRESOURCE variables......................................................................................................56
Status Readback commands....................................................................................................................56
USTATUS unsolicited status variables.....................................................................................................57
PJL messages for auto-continuable conditions.......................................................................................57
PJL messages for attendance conditions.................................................................................................69
PJL messages for paper handling.............................................................................................................96
PJL messages for paper jams.................................................................................................................102
Service errors........................................................................................................................................109
Device attendance messages................................................................................................................109
Lexmark‑unique PJL commands............................................................................................................109
File and device protection commands..................................................................................................111
Appendix C: PostScript support................................................................112
Supplemental operators........................................................................................................................112
Page device parameters........................................................................................................................116
User interpreter parameters.................................................................................................................121
System interpreter parameters.............................................................................................................122
Devices supported.................................................................................................................................125
Device parameters................................................................................................................................128
PostScript message keys commands.....................................................................................................138
Index........................................................................................................139
Contents 4

Introduction
Overview
This edition of the Technical Reference contains information about the 6500e option and the following single-function
(SFP) and multifunction (MFP) printers:
T650
T650n
T652dn
T654dn
T656dne
X651de
X652de
X654de
X656de
X656dte
X658d
X658de
X658dme
X658dfe
X658dte
X658dtme
X658dtfe
Understanding letters after model numbers
Some LexmarkTM printers and MFP options may have one or more letters after the model number to indicate features.
Acronym Meaning
dduplex1
de duplex and e-Task (electronic task) touch-screen interface
dfe duplex, finisher/stapler, and e-Task touch-screen interface
dhe duplex, high-capacity drawer, and e-Task touch-screen interface
dhn duplex, high-capacity drawer, and network
dme duplex, mailbox, and e-Task touch-screen interface
dn duplex and network
dnf duplex, network, and finisher/stapler
dnw or dw duplex, network, and wireless
dt duplex and additional tray2
1Duplex (two‑sided) printing using an optional duplex unit or an internal duplex unit based on the product
2The additional tray may be part of a drawer.
Introduction 5

Acronym Meaning
dte duplex, additional tray2, and e-Task touch-screen interface
dtfe duplex, additional tray2, finisher/stapler, and e-Task touch-screen interface
dtme duplex, additional tray2, mailbox, and e-Task touch-screen interface
dtn duplex, additional tray2, and network
dtpe duplex, additional tray2, finisher with hole punch, and e-Task touch-screen interface
dttn duplex, tandem tray module, and network
dtse duplex, additional tray2, stacker, and e-Task touch-screen interface
dtwe duplex, additional tray2, wireless, and e-Task touch-screen interface
e e-Task touch-screen interface
hdn hard disk, duplex, and network
nnetwork
nl network light model
ni network and ImageQuick
tn network and additional tray2
1Duplex (two‑sided) printing using an optional duplex unit or an internal duplex unit based on the product
2The additional tray may be part of a drawer.
Introduction 6

Learning about the printer and the MFP option
Finding information about the printer
What are you looking for? Find it here
Initial setup instructions:
•Connecting the printer
•Installing the printer software
Setup documentation—The setup documentation came
with the printer and is also available at
http://support.lexmark.com.
Additional setup and instructions for using the printer:
•Selecting and storing paper and specialty media
•Loading paper
•Configuring printer settings
•Viewing and printing documents and photos
•Setting up and using the printer software
•Configuring the printer on a network
•Caring for and maintaining the printer
•Troubleshooting and solving problems
User's Guide and Quick Reference Guide—The guides may
be available on the Software and Documentation CD.
For more information, visit
http://support.lexmark.com.
Instructions for:
•Connecting the printer to an Ethernet network
•Troubleshooting printer connection problems
Networking Guide—Open the Software and
Documentation CD, and then navigate to:
Documentation > User’s Guide and other publications >
Networking Guide
Help using the printer software Windows or Mac Help—Open a printer software program
or application, and then click Help.
Click
?
to view context‑sensitive information.
Notes:
•Help is automatically installed with the printer
software.
•The printer software is located in the printer
program folder or on the desktop, depending on
your operating system.
Learning about the printer and the MFP option 7

What are you looking for? Find it here
The latest supplemental information, updates, and customer
support:
•Documentation
•Driver downloads
•Live chat support
•E‑mail support
•Voice support
Lexmark support Web site—
http://support.lexmark.com
Note: Select your country or region, and then select
your product to view the appropriate support site.
Support telephone numbers and hours of operation for
your country or region can be found on the support Web
site or on the printed warranty that came with your
printer.
Record the following information (located on the store
receipt and at the back of the printer), and have it ready
when you contact customer support so that they may
serve you faster:
•Machine Type number
•Serial number
•Date purchased
•Store where purchased
Warranty information Warranty information varies by country or region:
•In the U.S.—See the Statement of Limited Warranty
included with this printer, or at
http://support.lexmark.com.
•In other countries and regions—See the printed
warranty that came with your printer.
Learning about the printer and the MFP option 8

Printer Control Language (PCL) page formatting
For more information on PCL, see the Printer Languages and Interfaces Technical Reference. It contains a complete
listing with descriptions of PCL commands.
To determine which PCL commands your printer supports, see “Appendix A: PCL support” on page 28.
Printable areas
The printable areas and logical pages for PCL emulation (both portrait and landscape orientation) are illustrated below.
See the legend that follows for definitions of areas Athrough I.
I
I
I
I
Legend:
APortrait physical page width and landscape physical page length
BPortrait physical page length and landscape physical page width
CPortrait logical page width
DLandscape logical page width
EDistance between the side edge of the physical page and the logical page in portrait
FDistance between the side edge of the physical page and the logical page in landscape
GDistance between the top and bottom edge of the physical page and logical page
HDistance between the left and right edge of the physical page and the printable area in portrait, or distance between
the top and bottom edge of the physical page and printable area in landscape
IDistance between the top and bottom edge of the physical page and the printable area in portrait, or distance between
the left and right edge of the physical page and the printable area in landscape
Note: The tables that follow in this chapter list the page sizes and dimensions of each area labeled on the preceding
diagram for all paper and envelope sizes your printer supports.
Printer Control Language (PCL) page formatting 9

Supported paper and envelope dimensions
The following table lists the page sizes and print area dimensions for all supported paper and envelope sizes. For more
information about the printable areas and logical pages for PCL emulation, see “Printable areas” on page 9.
Selection Paper/envelope
dimensions
Dimensions by area (pels)1
Page size
parameters2
Name mm inches A B C D E F G H I
Paper
2, 602 Letter 216 x 279 8.5 x 11 5100 6600 4800 6360 150 120 0 100 100
3, 603 Legal 216 x 356 8.5 x 14 5100 8400 4800 8160 150 120 0 100 100
12, 45, 612 JIS B5 182 x 257 7.2 x 10.1 4300 6070 4000 5830 150 120 0 100 100
26, 626 A4
(198 mm)3
210 x 297 8.3 x 11.7 4960 7014 4676 6778 142 118 0 80 100
26, 626 A4
(203 mm)3
210 x 297 8.3 x 11.7 4960 7014 4800 6778 80 118 0 80 100
1, 601 Executive 184 x 267 7.5 x 10.5 4350 6300 4050 6060 150 120 0 100 100
13, 613 A5 148 x 210 5.8 x 8.27 3496 4960 3196 4720 142 118 0 100 100
300 Oficio
(México)
216 x 340 8.5 x 13.4 5100 8040 4800 7800 150 120 0 100 100
4 or 10 Folio 216 x 330 8.5 x 13 5100 7800 4800 7560 150 120 0 100 100
15 Statement 139.7 x
215.9
5.5 x 8.5 3300 5100 3000 4860 150 120 0 100 100
24 A6 148 x 105 5.8 x 41 2480 3496 2199 3260 142 118 0 100 100
101 Universal 215.9 x
359.92
8.5 x 14.17 1800–
51004
1800–
85024
1500–
48004
1500–
82624
150 120 0 100 100
Envelope
80 7 3/4
Envelope
98.4 x 190.5 3.875 x 7.5 2324 4500 2024 4260 150 120 0 100 100
89 9 Envelope 98.4 x 225.4 3.875 x
8.875
2324 5324 2024 5084 150 120 0 100 100
1Pel dimensions are for 600 dpi.
2Page Size Parameters are explained in the Page Control table in the PCL chapter in the Printer Language and Interfaces
Technical Reference.
3The width of the logical page for A4 paper can be changed from the printer control panel or your application.
4For the Universal paper size, the area dimensions are listed in pel ranges.
5Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical
paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
Note: The explanation of the printable area assumes that the Print Area menu item is set to Normal. For more
information, see “Print Area Menu Item” in the PCL chapter in the Printer Language and Interfaces Technical Reference.
Printer Control Language (PCL) page formatting 10

Selection Paper/envelope
dimensions
Dimensions by area (pels)1
Page size
parameters2
Name mm inches A B C D E F G H I
81 10 Envelope 104.8 x
241.3
4.125 x 9.5 2474 5700 2174 5460 150 120 0 100 100
90 DL
Envelope
220 x 110 8.66 x 4.33 2598 5196 2314 4960 142 118 0 100 100
91 C5
Envelope
229 x 162 9.02 x 6.38 3826 5408 3542 5172 142 118 0 100 100
995, 100 B5
envelope
176.0 x
250.0
6.93 x 9.84 4156 5904 3872 5668 142 118 0 100 100
600 Other
Envelope
216 x 356 8.5 x 14 7012 8400 4800 8160 150 120 0 100 100
1Pel dimensions are for 600 dpi.
2Page Size Parameters are explained in the Page Control table in the PCL chapter in the Printer Language and Interfaces
Technical Reference.
3The width of the logical page for A4 paper can be changed from the printer control panel or your application.
4For the Universal paper size, the area dimensions are listed in pel ranges.
5Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical
paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
Note: The explanation of the printable area assumes that the Print Area menu item is set to Normal. For more
information, see “Print Area Menu Item” in the PCL chapter in the Printer Language and Interfaces Technical Reference.
Printer Control Language (PCL) page formatting 11

Printer Job Language (PJL)
PJL commands information
Your printer or scanner supports complete PJL commands, including certain commands that cause the printer or scanner
to enter PCL emulation, PostScript emulation, and Personal Printer Data Stream (PPDS).
For a complete listing with descriptions of PJL commands, see the Printer Languages and Interfaces Technical Reference.
To determine which commands your printer or scanner supports, see “Appendix B: PJL support” on page 39.
Printer Job Language (PJL) 12

PostScript (PS) emulation
Your MFP option supports complete PostScript emulation supplemental operators. For full, detailed descriptions of
these operators, see the PostScript emulation chapter of the Printer Languages and Interfaces Technical Reference.
To determine which commands your MFP option supports, see “Appendix C: PostScript support” on page 112.
Supported paper sizes
= Supported
X = Not supported
Paper sizes Model
Size Literal name Size (mm) Size (inches) Size (points)
6500e
MFP
option
T650,
T650n,
T652dn,
T654dn,
T656dne
X651de,
X652de,
X654de,
X656de,
X656dte,
X658d,
X658de,
X658dme,
X658dfe,
X658dte,
X658dtme,
X658dtfe
11 x 17 11x17 279.4 x 431.8 11 x 17 792 x 1224 XX
17 x 11 ledger 431.8 x 279.4 17 x 11 1224 x 792 XX
A3 a3 297 x 420 11.7 x 16.54 842 x 1191 XX X
A4 a4 210.0 x 297.0 8.3 x 11.7 595 x 842
A5 a5 148.0 x 210.0 5.83 x 8.27 419 x 595
A6 a6 105.0 x 148.0 4.13 x 5.83 297 x 419
Executive executivepage 184.2 x 266.7 7.25 x 10.5 522 x 756
Folio folio 215.9 x 330.2 8.5 x 13.0 612 x 936
JIS B4 b4* 257 x 364 10.12 x 14.33 729 x 1032 XX X
JIS B5 b5* 182.0 x 257.0 7.2 x 10.1 516 x 729
Legal legal 215.9 x 355.6 8.5 x 14.0 612 x 1008
Letter letter 215.9 x 279.4 8.5 x 11.0 612 x 792
* This is a Japanese Industry Standard (JIS) paper size. The same named designation is used by JIS
and the International Organization for Standardization (ISO) for different paper sizes.
PostScript (PS) emulation 13

= Supported
X = Not supported
Paper sizes Model
Size Literal name Size (mm) Size (inches) Size (points)
6500e
MFP
option
T650,
T650n,
T652dn,
T654dn,
T656dne
X651de,
X652de,
X654de,
X656de,
X656dte,
X658d,
X658de,
X658dme,
X658dfe,
X658dte,
X658dtme,
X658dtfe
Oficio oficio 215.9 x 340.4 8.5 x 13.4 612 x 965
(Lexmark‑unique
size)
612 x 972 (official
PostScript size)
Statement statement 139.7 x 215.9 5.5 x 8.5 396 x 612
Universal universal 215.9 x 359.92 8.5 x 14.17 612 x 1020
Custom custom 215.9 x 355.6 8.5 x 14.0 612 x 1020
* This is a Japanese Industry Standard (JIS) paper size. The same named designation is used by JIS
and the International Organization for Standardization (ISO) for different paper sizes.
PostScript paper tray support
When the printer receives one of the operators listed in “Tray selected with tray operators” on page 15, it performs
the actions listed in this section. This paper tray selection process ends when a suitable paper source is chosen and
paper is fed from this tray.
•The printer checks the value of manualfeed in statusdict and the ManualFeed page device parameter. If either one
is true, then the printer sends a message to load the requested size in the manual feeder or multipurpose feeder.
•The PageSize Policy is set to 0by means of setpagedevice.
•The printer checks the paper size loaded in the current active source to determine if it matches the requested size.
If the sizes match, then the paper is fed from the active source.
Note: The current active tray is the last source that was selected from the printer control panel or by the printer
language.
•If the requested size and the size loaded in the active source do not match, then the sources are searched in the
order defined by the Priority array in the InputAttributes dictionary in the pagedevice dictionary.
•If the requested media size is not found by the previous search, then the following search order is used:
–Tray 1
–Tray 2
–Tray 3
PostScript (PS) emulation 14

–Multipurpose feeder
–Tray 4
–Tray 5
•If the requested size cannot be located in any automatic source, then a configurationerror is issued and the job is
flushed.
For printers that support automatic two‑sided printing (duplexing):
•Automatic two‑sided printing is not supported for custom-size paper or for envelopes in the multipurpose feeder.
Automatic two‑sided printing is supported from the multipurpose feeder for all other papers.
•If the paper source is changed before the back side of a duplexed page prints, then a blank back page prints, the
paper source changes, and the information for the back side of the page is printed on the front side of a page sent
from the new paper source.
When these operators are used, it is equivalent to executing the following PostScript emulation sequence:
<< /PageSize [x y]/ImagingBBox null /Policies << /PageSize 0>> >>
setpagedevice
where x y are the PageSize in points.
Tray selected with tray operators
= Supported
X = Not supported Model
Operator Tray selected (corresponding image size is set)
6500e MFP
option
T650, T650n,
T652dn, T654dn,
T656dne
X651de, X652de,
X654de, X656de,
X656dte, X658d,
X658de, X658dme,
X658dfe, X658dte,
X658dtme, X658dtfe
11x17tray tray with 11 x 17‑size paper XX
a3tray tray with A3‑size paper XX X
a4tray tray with A4-size paper
a5tray tray with A5-size paper
a6tray tray with A6-size paper
b4tray tray with B4‑size paper XX X
b5tray tray with B5-size paper
customtray tray with custom-size paper XX X
executivetray tray with executive-size paper
foliotray tray with folio-size paper
ledgertray tray with ledger‑size paper XX X
legaltray tray with legal-size paper
lettertray tray with letter-size paper
PostScript (PS) emulation 15

= Supported
X = Not supported Model
Operator Tray selected (corresponding image size is set)
6500e MFP
option
T650, T650n,
T652dn, T654dn,
T656dne
X651de, X652de,
X654de, X656de,
X656dte, X658d,
X658de, X658dme,
X658dfe, X658dte,
X658dtme, X658dtfe
oficiotray tray with oficio‑size paper
statementtray tray with statement-size paper
PostScript envelope size support
The literal names in “Envelope sizes supported” on page 16 are also supported as operators in userdict. These
operators change the image size, but do not change the active paper source. Therefore, when these operators are used,
part of the image may be clipped.
When these literal names are used as operators, it is equivalent to executing the following PostScript emulation
sequence. The following example uses a 3.875 x 7.5 envelope.
<</Policies <</PageSize 7>> /PageSize [279 540]>> >>setpagedevice
Envelope sizes supported
= Supported
X = Not supported
Envelope sizes Model
Size name Literal name Size (mm) Size (inches) Size (points) 6500e
MFP
option
T650,
T650n,
T652dn,
T654dn,
T656dne
X651de,
X652de,
X654de,
X656de,
X656dte,
X658d,
X658de,
X658dme
, X658dfe,
X658dte,
X658dtm
e,
X658dtfe
7 3/4 3.875x7.5envelope 98.4 x 190.5 3.875 x 7.5 279 x 540
Commercial 9 3.875x8.875envelop
e
98.4 x 225.4 3.875 x 8.875 279 x 639
Commercial 10 4.125x9.5envelope 104.8 x 241.3 4.125 x 9.5 297 x 684
* For other envelopes, the page is formatted to 215.9 x 355.6 mm (8.5 x 14 in.) unless a size is specified by your software
program.
PostScript (PS) emulation 16

= Supported
X = Not supported
Envelope sizes Model
Size name Literal name Size (mm) Size (inches) Size (points) 6500e
MFP
option
T650,
T650n,
T652dn,
T654dn,
T656dne
X651de,
X652de,
X654de,
X656de,
X656dte,
X658d,
X658de,
X658dme
, X658dfe,
X658dte,
X658dtm
e,
X658dtfe
International B5 176x250envelope 176 x 250 6.93 x 9.84 499 x 708
International C5 162x229envelope 162 x 229 6.38 x 9.02 459 x 649
International DL 110x220envelope 110 x 220 4.33 x 8.66 312 x 624
Other envelope otherenvelope* 229.11 x 355.6 9.02 x 14 612 x 996
* For other envelopes, the page is formatted to 215.9 x 355.6 mm (8.5 x 14 in.) unless a size is specified by your software
program.
Literal names supported
= Supported
X = Not Supported
Literal names Model
Literal name Compatible literal name 6500e MFP option T650, T650n, T652dn,
T654dn, T656dne
X651de, X652de, X654de,
X656de, X656dte, X658d,
X658de, X658dme, X658dfe,
X658dte, X658dtme, X658dtfe
b5envelope 176x250envelope
c5envelope 162x229envelope
com10envelope 4.125x9.5envelope
dlenvelope 110x220envelope
monarcenvelope 3.875x7.5envelope
PostScript (PS) emulation 17

PostScript envelope tray support
If manualfeed in statusdict and the ManualFeed page device parameter are false when the printer receives one of the
envelopetray operators listed in “Envelopetray operator selections” on page 18, then the following occurs:
•The printer sets the PageSize Policy to 0.
•The printer checks the active source to see if it matches the requested envelope size. If the sizes match, then the
envelope is fed from the active source.
Note: The active source is the last source selected from the printer control panel or data stream.
•If the requested size and the size loaded in the active source do not match, then the sources are searched in the
order defined by the Priority array in the InputAttributes dictionary in the pagedevice dictionary.
•If the requested media size is not found by the previous search, then the following search order is used:
–Envelope feeder
–Multipurpose feeder
•If the requested size and type are not available from any automatic source, then you are prompted to load the
requested envelope size and type in the manual feed source.
•If the size is still not available, then a configurationerror is issued, and the print job is flushed.
If manualfeed or ManualFeed is true, then the printer prompts you to load the requested size manually. If no manual
feed exists on the printer, then a rangecheck error message is issued.
The envelope tray the printer selects when it receives an envelopetray operator is listed in “Envelopetray operator
selections” on page 18. These operators are equivalent to executing the following PostScript emulation sequence:
<</PageSize [x y] /ImagingBBox null /Policies<</PageSize 0>> >>
setpagedevice
where x y are the PageSize in points.
Envelopetray operator selections
= Supported
X = Not supported
Tray operators Model
Operator Tray selected (corresponding image
size is set)
6500e MFP
option
T650, T650n,
T652dn,
T654dn,
T656dne
X651de, X652de,
X654de, X656de,
X656dte, X658d,
X658de, X658dme,
X658dfe, X658dte,
X658dtme, X658dtfe
110x220envelopetray tray with 110 x 220‑size envelopes
dlenvelopetray tray with 110 x 220‑size envelopes
162x229envelopetray tray with 162 x 229‑size envelopes
c5envelopetray tray with 162 x 229‑size envelopes
176x250envelopetray tray with 176 x 250‑size envelopes
b5envelopetray tray with 176 x 250‑size envelopes
PostScript (PS) emulation 18

= Supported
X = Not supported
Tray operators Model
Operator Tray selected (corresponding image
size is set)
6500e MFP
option
T650, T650n,
T652dn,
T654dn,
T656dne
X651de, X652de,
X654de, X656de,
X656dte, X658d,
X658de, X658dme,
X658dfe, X658dte,
X658dtme, X658dtfe
3.875x7.5envelopetray tray with 3.875 x 7.5‑size envelopes
monarcenvelopetray tray with 3.875 x 7.5‑size envelopes
3.875x8.875envelopetray tray with 3.875 x 8.875‑size envelopes
4.125x9.5envelopetray tray with 4.125 x 9.5‑size envelopes
com10envelopetray tray with 4.125 x 9.5‑size envelopes
otherenvelopetray tray with other size envelopes
PostScript (PS) emulation 19

Printer and MFP option specifications
Airflow requirement
The room should meet ASHRAE 62—1989 standards.
Noise emission levels
The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO 9296.
Status
1-meter average sound pressure, dBA
6500e MFP
Option
T650n T652n/dn T654n/dn X651 MFP,
X652 MFP
X654 MFP,
X656 MFP
X658 MFP
ADF Color
Scan
35 Not
applicable
Not
applicable
Not
applicable
Not applicable Not applicable Not
applicable
ADF Mono
Scan
50 Not
applicable
Not
applicable
Not
applicable
Not applicable Not applicable Not
applicable
Copying Not
applicable
Not
applicable
Not
applicable
Not
applicable
55 56 55
Printing Not
applicable
53 (simplex)
56 (duplex)
54 (simplex)
54 (duplex)
55 (simplex)
56 (duplex)
54 (simplex)
54 (duplex)
56 (simplex)
56 (duplex)
55 (simplex)
55 (duplex)
Quiet Mode
printing
Not
applicable
47 51 51 51 52 50
Robust
mode Color
Scan
45 Not
applicable
Not
applicable
Not
applicable
Not applicable Not applicable Not
applicable
Robust
mode Mono
Scan
45 Not
applicable
Not
applicable
Not
applicable
Not applicable Not applicable Not
applicable
Scanning Not
applicable
Not
applicable
Not
applicable
Not
applicable
56 55 55
Standby
(Idle without
Power
Saver)
35 26 30 30 29 29 28
Note: Measurements apply to 300‑dpi, 600‑dpi, and 1200‑dpi printing.
Printer and MFP option specifications 20
