LG AMNW07GSJL0 Operation manual

Indoor unit
R32 Heat Pump (50 / 60Hz)
0CTI5-08B (Replaces 0CTI5-08A)
P/No. : MFL67502513

MULTI/SINGLE
Indoor unit
General information
Product data

General information
MULTI/SINGLE
Indoor unit
1.Model Line Up
2.External Appearance
3.Nomenclature

2
MULTI/SINGLE Indoor unit General information
1. Model Line Up
Note
1. Refer the Combination Table of Product Data Book for Outdoor Units.
•୙ : Connectable with SINGLE model only.
• : Connectable with MULTI model only(R32/R410A common use).
• : Connectable with SINGLE or MULTI model(R32/R410A common use for MULTI model only.).
• * : Residential Single Split compatible.
2. This product contains Fluorinated greenhouse gases.
Category Chassis
Name
Capacity Index [kW (kBtu/h)]
1.5
(5)
2.1
(7)
2.5
(9)
3.5
(12)
4.2
(15)
5.0
(18)
7.1
(24)
7.5
(30)
10.0
(36)
12.0
(42)
14.0
(48)
15.0
(60)
Wall Mounted Unit (1)
Deluxe SJ 
SK 
Standard plus SJ 
SK 
Standard SJ 
SK 
Wall Mounted Unit (2)
Deluxe SJ **
SK **
Standard plus SJ **
SK **
Standard SJ **
SK *
Wall Mounted Unit (3) Standard plus (S) SJ 
SK 
Wall Mounted Unit (4) SR ୙୙
ART COOL Mirror
AM**BP NS* SJ 
SK 
AC**BQ NS* SJ **
SK **
ART COOL Gallery SF 
ART COOL Silver SJ **
SK *
Ceiling Mounted
Cassette
1-way TU 
4-Way TR 
TQ 
Dual Vane 4-Way TP-B ୙
TM-A ୙୙୙୙
Ceiling Concealed Duct
Middle Static Pressure
M1 ୙
M2 ୙୙
M3 ୙୙
Low Static Pressure (Slim)
L5 
L6 
L3 
Ceiling Suspended Unit VM1 ୙୙୙
VM2 ୙୙୙୙
Console QA ୙୙ ୙

3
MULTI/SINGLE Indoor unit General information
2. External Appearance
•Wall Mounted Unit (1) •Wall Mounted Unit (2)
AMNW07GSJL0 [DM07RP NSJ]
ASNW09GJ1Z0 [DM09RP NSJ]
ASNW12GJ1Z0 [DM12RP NSJ]
ASNW18GK1Z0 [DM18RP NSK]
ASNW24GK1Z0 [DM24RP NSK]
AMNW05GSJB0 [PM05SP NSJ]
AMNW07GSJB0 [PM07SP NSJ]
ESNW09GJ2F0 [PM09SP NSJ]
ESNW12GJ2F0 [PM12SP NSJ]
AMNW15GSJB0 [PM15SP NSJ]
ESNW18GK2F0 [PM18SP NSK]
ESNW24GK2F0 [PM24SP NSK]
AMNW07GSJA0 [PM07EP NSJ]
ESNW09GJ3A0 [PM09EP NSJ]
ESNW12GJ3A0 [PM12EP NSJ]
ESNW18GK3A0 [PM18EP NSK]
AMNW24GSKA0 [PM24EP NSK]
S3NM09JL1ZA [DC09RQ NSJ]
S3NM12JL1ZA [DC12RQ NSJ]
S3NM18KL1ZA [DC18RQ NSK]
S3NM24K21ZA [DC24RQ NSK]
S3NM09JA2FA [PC09SQ NSJ]
S3NM12JA2FA [PC12SQ NSJ]
S3NM18KL2FA [PC18SQ NSK]
S3NM24K22FA [PC24SQ NSK]
S3NM09JA3BA [SC09EQ NSJ]
S3NM12JA3BA [SC12EQ NSJ]
S3NM18KL3BA [SC18EQ NSK]
•Wall Mounted Unit (3)
ZMNW05GSJC0 [MJ05PC NSJ]
ZMNW07GSJC0 [MJ07PC NSJ]
ZMNW09GSJC0 [MJ09PC NSJ]
ZMNW12GSJC0 [MJ12PC NSJ]
ZMNW15GSJC0 [MJ15PC NSJ]
ZMNW18GSKC0 [MJ18PC NSK]
ZMNW24GSKC0 [MJ24PC NSK]
•ARTCOOL Gallery •Wall Mounted Unit (4)
ZMNW09GAF10 [MA09R NF1]
ZMNW12GAF10 [MA12R NF1]
ZJNW30GRLA1 [US30F NR0]
ZJNW36GRLA1 [US36F NR0]
•ARTCOOL Mirror •ARTCOOL Silver
AMNW07GSJR0 [AM07BP NSJ]
USNW09GJRZ0 [AM09BP NSJ]
USNW12GJRZ0 [AM12BP NSJ]
USNW18GKRZ0 [AM18BP NSK]
AMNW24GSKR0 [AM24BP NSK]
S3NM09JARZA [AC09BQ NSJ]
S3NM12JARZA [AC12BQ NSJ]
S3NM18KLRZA [AC18BQ NSK]
S3NM24K2RZA [AC24BQ NSK]
S3NM09JASZA [AC09SQ NSJ]
S3NM12JASZA [AC12SQ NSJ]
S3NM18KLSZA [AC18SQ NSK]
•Ceiling Suspended Unit •Ceiling Mounted Cassette 4-way
ZVNW18GM1A1 [UV18F N10]
ZVNW24GM1A1 [UV24F N10]
ZVNW30GM1A1 [UV30F N10]
ZVNW36GM2A1 [UV36F N20]
ZVNW42GM2A1 [UV42F N20]
ZVNW48GM2A1 [UV48F N20]
ZVNW60GM2A1 [UV60F N20]
ZMNW05GTRA0 [MT06R NR0]
ZMNW07GTRA0 [MT08R NR0]
ZTNW09GRLA1 [CT09F NR0]
ZTNW12GRLA1 [CT12F NR0]
ZTNW18GQLA1 [CT18F NQ0]
•Ceiling Mounted Cassette 1-way •Ceiling Mounted Cassette (Dual Vane 4-Way)
ZMNW09GTUA0 [MT09R NU1]
ZMNW12GTUA0 [MT11R NU1]
ZTNW24GBLA1 [CT24F NB0]
ZTNW30GBLA1 [UT30F NB0]
ZTNW36GALA1 [UT36F NA0]
ZTNW42GALA1 [UT42F NA0]
ZTNW48GALA1 [UT48F NA0]
ZTNW60GALA1 [UT60F NA0]
•Ceiling Concealed Duct – Middle static pressure •Ceiling Concealed Duct – Low static pressure
ZBNW18GM1A1 [CM18F N10]
ZBNW24GM1A1 [CM24F N10]
ZBNW30GM1A1 [UM30F N10]
ZBNW36GM2A1 [UM36F N20]
ZBNW42GM2A1 [UM42F N20]
ZBNW48GM3A1 [UM48F N30]
ZBNW60GM3A1 [UM60F N30]
ZBNW09GL5A1 [CL09F N50]
ZBNW12GL5A1 [CL12F N50]
ZBNW18GL6A1 [CL18F N60]
ZBNW24GL3A1 [CL24F N30]
•Console
ZQNW09GALA1 [UQ09F NA0]
ZQNW12GALA1 [UQ12F NA0]
ZQNW18GALA1 [UQ18F NA0]

4
MULTI/SINGLE Indoor unit General information
3. Nomenclature
3.1 Factory Model Name
Basic (Except for the exception case below)
Model
Name ZTN W 18 G Q L A 1
No.12345678
No. Signification
1
Z*N : Indoor units using R32
* Indicates Product type
M : Only for Multi systems
T : Ceiling Mounted Cassette
B : Ceiling Concealed Duct
V : Ceiling Suspended Unit
A*N, E*N, U*N : Indoor units using R410A and R32 Commonly
* Indicates Product type
M : Only for Multi systems
J, S : Wall Mounted unit / ARTCOOL Mirror
2Model type
W/H : DC Inverter Heat pump
3Nominal Capacity
Ex) 7,000 Btu/h Class ˧ '07', 18,000 Btu/h Class ˧ '18'
4Electrical rating
G: 1Ø, 220-240V, 50 Hz / 1Ø, 220V, 60 Hz
5
Indoor unit type for ASN-, ESN-, USN-, Z*N- series models
Chassis name
Indoor unit type for AMN-, Z*N- series models
S : Wall Mounted Unit / ART COOL Mirror
T : Ceiling Mounted Cassette
A : ART COOL
6
Indoor unit type for ASN-, ESN-, USN-, ZTN- series models
L : Basic
1 : Deluxe type
2 : Standard plus type
3 : Standard type
R : ARTCOOL Mirror type
Indoor unit type for AMN-, Z*N- series models
Chassis name
7
Product type (Z*N- series)
A : Basic, C : Standard plus (S)
Functions for Wall Mounted Unit (AMN-, ASN-, ESN- series)
L/Z : Ionizer + 4 Way Air flow + Wi-Fi
B/F : Non-Ionizer + 4 Way Air flow + Wi-Fi
Functions for ART COOL Mirror (USN- series)
Z : Ionizer + 4 Way
Panel Color for ART COOL Mirror(AMN- series)
R : Mirror
Panel Color for ART COOL
1 : Gallery
8Serial number

3. Nomenclature
5
MULTI/SINGLE Indoor unit General information
Wall Mounted Unit (2)
Model
Name S 3 N M 09 J L 1 Z A
No.12345678910
No. Signification
1Product Type
S : Split
2
Refrigerant
3 : R32
4 : R410A
3
Supply Type
N : Indoor Unit
U : Outdoor Unit
4Model Type
M : Common Indoor unit for Multi and Residential system
5Nominal Capacity
Ex) 7,000 Btu/h Class ˧ '07', 18,000 Btu/h Class ˧ '18'
6
Indoor unit Chassis name
J : SJ
K : SK
7
Outdoor unit Chassis name for Residential system
L : UL2
2 : U24A
4 : U4
8
Look & Color (SJ, SK Chassis)
R : ART COOL (Mirror Black)
1 : R Look (White Panel : Transparent)
2 : Semi-R Look (White Panel : Silver Deco)
3 : E Look (White Pane)
9
Function
B : Non-Ionizer + 4way
F : Non-Ionizer + 4way + Wi-Fi
Z : Ionizer + 4way + Wi-Fi
10 Standard Model No.

MULTI/SINGLE Indoor unit
3. Nomenclature
6
General information
3.2 Buyer Model Name
Basic (Except for the exception case below)
Model
Name CT18FNQ0
No.1234567
No. Signification
1
Connectable Outdoor unit type
M : Indoor units only for Multi systems
U : Indoor units only for Single CAC systems
C : Common Indoor Unit for Multi and Single CAC
2
Product type
T : Ceiling Mounted Cassette
M, B, L: Ceiling Concealed Duct
V : Ceiling Suspended Unit
A : ART COOL
J : Wall Mounted Unit
Q : Console
3Nominal Capacity
Ex) 7,000 Btu/h Class ˧ '07', 18,000 Btu/h Class ˧ '18'
4
Detailed product type
R : Indoor Units using R32
F : Free Combination
5
Indoor Unit / Outdoor Units
N : Indoor Unit
U : Outdoor Unit
6Chassis name
7Serial number

3. Nomenclature
7
MULTI/SINGLE Indoor unit General information
Wall Mounted Unit / ARTCOOL Mirror / ARTCOOL Silver
Model
Name P M 07 E P N SJ
No.1234567
No. Signification
1
Product type
D : Deluxe
P : Standard or Standard plus
A : ARTCOOL Mirror
2Connectable Outdoor unit type
M, C : Common Indoor unit for Multi and Residential system
3
Nominal Capacity
Ex) 7,000 Btu/h Class ˧ '07', 18,000 Btu/h Class ˧ '18'
4
Product Look
R : R-Look
E : E-Look
S : Semi R-Look
B : Mirror-Look
5Serial
6
Indoor Unit / Outdoor Units
N : Indoor Unit
U : Outdoor Unit
7Chassis name

MULTI/SINGLE Indoor unit
3. Nomenclature
8
General information
Wall Mounted Unit (2)
Model
Name D C 09 R Q N SJ
No.1234567
No. Signification
1
Product type
D : Deluxe
P : Standard plus
S : Standard
A : ARTCOOL Mirror
2Connectable Outdoor unit type
C : Multi Compatible
3
Nominal Capacity
Ex) 7,000 Btu/h Class ˧ '07', 18,000 Btu/h Class ˧ '18'
4
Product Look
R : R-Look
S : Semi R-Look
E : E-Look
B : Black Mirror-Look
5Serial
6
Indoor Unit / Outdoor Units
N : Indoor Unit
U : Outdoor Unit
7Chassis name

3. Nomenclature
9
MULTI/SINGLE Indoor unit General information
Wall Mounted Unit (3)
Model
Name M J 05 PC N SJ
No. 1 2 3 4 5 6
No. Signification
1Connectable Outdoor unit type
M : Indoor units only for Multi systems
2Product type
J : Wall Mounted Unit
3Nominal Capacity
Ex) 7,000 Btu/h Class ˧ '07', 18,000 Btu/h Class ˧ '18'
4Detailed product type
PC : Standard plus (S)
5
Indoor Unit / Outdoor Units
N : Indoor Unit
U : Outdoor Unit
6Chassis name

Product data
MULTI/SINGLE
Indoor unit
Wall Mounted Unit (1)
Wall Mounted Unit (2)
Wall Mounted Unit (3)
Wall Mounted Unit (4)
ARTCOOL Mirror
ARTCOOL
ARTCOOL Silver
Ceiling Mounted cassette 1-way
Ceiling Mounted cassette 4-way
Ceiling Mounted cassette (Dual Vane 4-Way)
Ceiling concealed duct - Middle static pressure
Ceiling concealed duct - Low static pressure
Ceiling Suspended Unit
Console

Wall Mounted Unit (1)
MULTI/SINGLE
Indoor unit
1.List of Functions
2.Specifications
3.Dimensions
4.Piping diagrams
5.Wiring diagrams
6.Air flow and temperature distribution
7.Sound levels
8.Installation

2
MULTI/SINGLE Indoor unit Wall Mounted Unit (1)
1. List of functions
Deluxe
List of function
Category Functions
AMNW07GSJL0 [DM07RP NSJ], ASNW09GJ1Z0 [DM09RP NSJ]
ASNW12GJ1Z0 [DM12RP NSJ], ASNW18GK1Z0 [DM18RP NSK]
ASNW24GK1Z0 [DM24RP NSK]
Air flow
Air supply outlet 1
Airflow direction control (left & right) O (5 Steps)
Airflow direction control (up & down) O (6 Steps)
Auto swing (left & right) O
Auto swing (up & down) O
Airflow steps (fan/cool/heat) 6 / 6 / 6
Chaos wind(auto wind) O
Jet cool/heat O / O
Swirl wind X
Air purifying
Triple filter (Deodorizing) X
Air purifier (Plasma) X
Air purifier (Ionizer) O
Allergy Safe filter X
Long-life prefilter (washable / anti-fungus) O
Installation
Drain pump X
E.S.P. control* X
Electric heater X
High ceiling operation* X
Reliability Hot start O
Self diagnosis O
Convenience
Auto changeover X
Auto cleaning O
Auto operation(artificial intelligence) O
Auto Restart O
Child lock* O
Forced operation O
Group control* X
Sleep mode O (7hr)
Timer(on/off) O
Timer(weekly)* O
Two thermistor control* O
Auto Elevation Grille X
Special Functions Wi-Fi O (Embedded)
Humidity Control X
Wireless Remote Controller O**
Wired Remote Controller O (Accessory)
Network Solution(LGAP) O
Note
1. O : Applied, X : Not applied, Embedded : Included with product.
Accessory : Ordered and purchased separately the accessory package referring to the model name provided and install at field.
Accessory line-ups varies by region, so check your local catalogue or local sales material.
2. Some functions can be limited by remote controller.
3. Selecting a wireless remote controller in case of ducted type indoor units requires either a connection to the wired remote controller (Standard II) or
an IR receiver accessory to be connected to the duct in order to receive the signal.
4. * : These functions need to connect to the wired remote controller.
5. ** : It is included by default when the product is manufactured.
6. *** : This functions need to connect to the Standard III wired remote controller.

1. List of functions
3
MULTI/SINGLE Indoor unit Wall Mounted Unit (1)
Accessory Compatibility List
Category Product Remark
AMNW07GSJL0 [DM07RP NSJ]
ASNW09GJ1Z0 [DM09RP NSJ]
ASNW12GJ1Z0 [DM12RP NSJ]
ASNW18GK1Z0 [DM18RP NSK]
ASNW24GK1Z0 [DM24RP NSK]
Wireless Remote Controller PQWRHQ0FDB Heat Pump O
PWLSSB21H Heat Pump O
Wired
Remote
Controller
Simple PQRCVCL0Q(W) Simple O
PQRCHCA0Q(W) for Hotel O
Standard
PREMTB001 Standard II (White) O
PREMTBB01 Standard II (Black) O
PREMTB100** Standard III (White) O
PREMTBB10** Standard III (Black) O
Premium PREMTA000(A/B) Premium X
Dry contact
Simple Contact PDRYCB000 Simple Dry Contact O
Communication type
PDRYCB400 2 Points Dry Contact (For Setback) O
PDRYCB300 For 3rd Party Thermostat O
PDRYCB500 For Modbus O
Gateway IDU PI485 PHNFP14A0 Without case X
PSNFP14A0 With case X
ETC
Remote temperature
sensor PQRSTA0 - X
Zone controller ABZCA - X
COဌSensor PES-C0RV0 For ERV, ERV DX Indoor units X
Group control wire PZCWRCG3 0.25m X
2-Remo Control Wire PZCWRC2 0.25m X
Extension Wire PZCWRC1 10m O
Wi-Fi Controller* PWFMDD200 - O (Embedded)
Human detecting sensor PTVSMA0 - X
Note
1. O: Possible, X: Impossible, - : Not applicable, Embedded : Included with product.
2. * : Some advanced functions controlled by individual controller cannot be operated.
3. ** : It could not be operated some functions.
4. *** : Selecting a wireless remote controller in case of ducted type indoor units requires either a connection to the wired remote controller (Standard II)
or an IR receiver accessory to be connected to the duct in order to receive the signal.
5. If you need more detail, please refer to the BECON PDB or the manual of product. (http://partner.lge.com/global : Home> Doc.Library> Product >
Control(BECON))

MULTI/SINGLE Indoor unit
1. List of functions
4
Wall Mounted Unit (1)
Standard plus
List of function
Category Functions
AMNW05GSJB0 [PM05SP NSJ], AMNW07GSJB0 [PM07SP NSJ]
ESNW09GJ2F0 [PM09SP NSJ], ESNW12GJ2F0 [PM12SP NSJ]
AMNW15GSJB0 [PM15SP NSJ], ESNW18GK2F0 [PM18SP NSK]
ESNW24GK2F0 [PM24SP NSK]
Air flow
Air supply outlet 1
Airflow direction control (left & right) O (5 Steps)
Airflow direction control (up & down) O (6 Steps)
Auto swing (left & right) O
Auto swing (up & down) O
Airflow steps (fan/cool/heat) 6 / 6 / 6
Chaos wind(auto wind) O
Jet cool/heat O / O
Swirl wind X
Air purifying
Triple filter (Deodorizing) X
Air purifier (Plasma) X
Air purifier (Ionizer) X
Allergy Safe filter X
Long-life prefilter (washable / anti-fungus) O
Installation
Drain pump X
E.S.P. control* X
Electric heater X
High ceiling operation* X
Reliability Hot start O
Self diagnosis O
Convenience
Auto changeover X
Auto cleaning O
Auto operation(artificial intelligence) O
Auto Restart O
Child lock* O
Forced operation O
Group control* X
Sleep mode O (7hr)
Timer(on/off) O
Timer(weekly)* O
Two thermistor control* O
Auto Elevation Grille X
Special Functions Wi-Fi O (Embedded)
Humidity Control X
Wireless Remote Controller O**
Wired Remote Controller O (Accessory)
Network Solution(LGAP) O
Note
1. O : Applied, X : Not applied, Embedded : Included with product.
Accessory : Ordered and purchased separately the accessory package referring to the model name provided and install at field.
Accessory line-ups varies by region, so check your local catalogue or local sales material.
2. Some functions can be limited by remote controller.
3. Selecting a wireless remote controller in case of ducted type indoor units requires either a connection to the wired remote controller (Standard II) or
an IR receiver accessory to be connected to the duct in order to receive the signal.
4. * : These functions need to connect to the wired remote controller.
5. ** : It is included by default when the product is manufactured.
6. *** : This functions need to connect to the Standard III wired remote controller.

1. List of functions
5
MULTI/SINGLE Indoor unit Wall Mounted Unit (1)
Accessory Compatibility List
Category Product Remark
AMNW05GSJB0 [PM05SP NSJ]
AMNW07GSJB0 [PM07SP NSJ]
ESNW09GJ2F0 [PM09SP NSJ]
ESNW12GJ2F0 [PM12SP NSJ]
AMNW15GSJB0 [PM15SP NSJ]
ESNW18GK2F0 [PM18SP NSK]
ESNW24GK2F0 [PM24SP NSK]
Wireless Remote Controller PQWRHQ0FDB Heat Pump O
Wired
Remote
Controller
Simple PQRCVCL0Q(W) Simple O
PQRCHCA0Q(W) for Hotel O
Standard
PREMTB001 Standard II (White) O
PREMTBB01 Standard II (Black) O
PREMTB100** Standard III (White) O
PREMTBB10** Standard III (Black) O
Premium PREMTA000(A/B) Premium X
Dry contact
Simple Contact PDRYCB000 Simple Dry Contact O
Communication type
PDRYCB400 2 Points Dry Contact (For Setback) O
PDRYCB300 For 3rd Party Thermostat O
PDRYCB500 For Modbus O
Gateway IDU PI485 PHNFP14A0 Without case X
PSNFP14A0 With case X
ETC
Remote temperature
sensor PQRSTA0 - X
Zone controller ABZCA - X
COဌSensor PES-C0RV0 For ERV, ERV DX Indoor units X
Group control wire PZCWRCG3 0.25m X
2-Remo Control Wire PZCWRC2 0.25m X
Extension Wire PZCWRC1 10m O
Wi-Fi Controller* PWFMDD200 - O (Embedded)
Human detecting sensor PTVSMA0 - X
Note
1. O: Possible, X: Impossible, - : Not applicable, Embedded : Included with product.
2. * : Some advanced functions controlled by individual controller cannot be operated.
3. ** : It could not be operated some functions.
4. *** : Selecting a wireless remote controller in case of ducted type indoor units requires either a connection to the wired remote controller (Standard II)
or an IR receiver accessory to be connected to the duct in order to receive the signal.
5. If you need more detail, please refer to the BECON PDB or the manual of product. (http://partner.lge.com/global : Home> Doc.Library> Product >
Control(BECON))

MULTI/SINGLE Indoor unit
1. List of functions
6
Wall Mounted Unit (1)
Standard
List of function
Category Functions
AMNW07GSJA0 [PM07EP NSJ] ESNW09GJ3A0 [PM09EP NSJ]
ESNW12GJ3A0 [PM12EP NSJ] ESNW18GK3A0 [PM18EP NSK]
AMNW24GSKA0 [PM24EP NSK]
Air flow
Air supply outlet 1
Airflow direction control (left & right) O (Manual)
Airflow direction control (up & down) O (6 Steps)
Auto swing (left & right) X
Auto swing (up & down) O
Airflow steps (fan/cool/heat) 6 / 6 / 6
Chaos wind(auto wind) O
Jet cool/heat O / O
Swirl wind X
Air purifying
Triple filter (Deodorizing) X
Air purifier (Plasma) X
Air purifier (Ionizer) X
Allergy Safe filter X
Long-life prefilter (washable / anti-fungus) O
Installation
Drain pump X
E.S.P. control* X
Electric heater X
High ceiling operation* X
Reliability Hot start O
Self diagnosis O
Convenience
Auto changeover X
Auto cleaning O
Auto operation(artificial intelligence) O
Auto Restart O
Child lock* O
Forced operation O
Group control* X
Sleep mode O (7hr)
Timer(on/off) O
Timer(weekly)* X
Two thermistor control* X
Auto Elevation Grille X
Special Functions Wi-Fi X
Humidity Control X
Wireless Remote Controller O**
Wired Remote Controller X
Network Solution(LGAP) X
Note
1. O : Applied, X : Not applied, Embedded : Included with product.
Accessory : Ordered and purchased separately the accessory package referring to the model name provided and install at field.
Accessory line-ups varies by region, so check your local catalogue or local sales material.
2. Some functions can be limited by remote controller.
3. Selecting a wireless remote controller in case of ducted type indoor units requires either a connection to the wired remote controller (Standard II) or
an IR receiver accessory to be connected to the duct in order to receive the signal.
4. * : These functions need to connect to the wired remote controller.
5. ** : It is included by default when the product is manufactured.
6. *** : This functions need to connect to the Standard III wired remote controller.

1. List of functions
7
MULTI/SINGLE Indoor unit Wall Mounted Unit (1)
Accessory Compatibility List
Category Product Remark
AMNW07GSJA0 [PM07EP NSJ]
ESNW09GJ3A0 [PM09EP NSJ]
ESNW12GJ3A0 [PM12EP NSJ]
ESNW18GK3A0 [PM18EP NSK]
AMNW24GSKA0[PM24EP NSK]
Wireless Remote Controller PQWRHQ0FDB Heat Pump O
Wired
Remote
Controller
Simple PQRCVCL0Q(W) Simple X
PQRCHCA0Q(W) for Hotel X
Standard
PREMTB001 Standard II (White) X
PREMTBB01 Standard II (Black) X
PREMTB100** Standard III (White) X
PREMTBB10** Standard III (Black) X
Premium PREMTA000(A/B) Premium X
Dry contact
Simple Contact PDRYCB000 Simple Dry Contact X
Communication type
PDRYCB400 2 Points Dry Contact (For Setback) X
PDRYCB300 For 3rd Party Thermostat X
PDRYCB500 For Modbus X
Gateway IDU PI485 PHNFP14A0 Without case X
PSNFP14A0 With case X
ETC
Remote temperature
sensor PQRSTA0 - X
Zone controller ABZCA - X
COဌSensor PES-C0RV0 For ERV, ERV DX Indoor units X
Group control wire PZCWRCG3 0.25m X
2-Remo Control Wire PZCWRC2 0.25m X
Extension Wire PZCWRC1 10m X
Wi-Fi Controller* PWFMDD200 - X
Human detecting sensor PTVSMA0 - X
Note
1. O: Possible, X: Impossible, - : Not applicable, Embedded : Included with product.
2. * : Some advanced functions controlled by individual controller cannot be operated.
3. ** : It could not be operated some functions.
4. *** : Selecting a wireless remote controller in case of ducted type indoor units requires either a connection to the wired remote controller (Standard II)
or an IR receiver accessory to be connected to the duct in order to receive the signal.
5. If you need more detail, please refer to the BECON PDB or the manual of product. (http://partner.lge.com/global : Home> Doc.Library> Product >
Control(BECON))

8
MULTI/SINGLE Indoor unit Wall Mounted Unit (1)
2. Specifications
Deluxe
Model Name AMNW07GSJL0
[DM07RP NSJ]
ASNW09GJ1Z0
[DM09RP NSJ]
Power Supply V, Ø, Hz 220-240, 1, 50 220-240, 1, 50
220, 1, 60 220, 1, 60
Capacity Cooling kW 2.1 2.5
Heating kW 2.3 3.2
Power Input Min./Nom./Max. W 9 / 17 / 30 9 / 18 / 30
Running Current Min./Nom./Max. A 0.12 / 0.15 / 0.20 0.12 / 0.16 / 0.20
Casing Color - Munsell 7.5BG 10/2 (RAL 9016)
Dimensions
Body W x H x D mm 837 × 308 × 189 837 × 308 × 189
W x H x D inch 32-15/16 x 12-1/8 x 7-7/16 32-15/16 x 12-1/8 x 7-7/16
Shipping W x H x D mm 892 x 381 x 249 892 x 381 x 249
W x H x D inch 35-1/8 x 15 x 9-13/16 35-1/8 x 15 x 9-13/16
Weight Body kg (lbs) 8.3 (18.3) 8.3 (18.3)
Shipping kg (lbs) 11.6 (25.6) 11.6 (25.6)
Heat Exchanger
(Row x Column x Fins per inch) x
No. - (2 x 23 x 22) x 1 (2 x 23 x 22) x 1
Face Area m2 (ft2)0.20 (2.15) 0.20 (2.15)
Fan
Type - Cross Flow Fan Cross Flow Fan
Air Flow Rate H / M / L m3/min 7.5 / 6.1 / 4.9 7.7 / 6.4 / 5.0
H / M / L ft3/min 265 / 215 / 173 272 / 226 / 177
Fan Motor Type - BLDC BLDC
Output W x No. 30 x 1 30 x 1
Sound Pressure Level H / M / L dB(A) 35 / 31 / 26 36 / 32 / 27
Sound Power Level Rated dB(A) 56 56
Piping Connections
Liquid mm(inch) Ø 6.35 (1/4) Ø 6.35 (1/4)
Gas mm(inch) Ø 9.52 (3/8) Ø 9.52 (3/8)
Drain O.D. / I.D. mm Ø 21.5 / 16.0 Ø 21.5 / 16.0
Safety Devices - Fuse
- Thermal Protector for Fan Motor
Connections Method - Flared Flared
Power and Communication Cable (included Earth) No. x mm2
(AWG) 4C x 0.75 (18) 4C x 0.75 (18)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national code. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound Level Values are measured at Noise Measuring chamber accordance with standard. Therefore, these values depend on the ambient conditions
and values are normally higher in actual operation(Sound Pressure : LG Internal standard, Sound Power : EN 12102 (ISO 3741).
4. Capacities are net capacities and based on the following conditions. Refer to the Outdoor Unit Specifications for calculating the real capacity.
• Cooling : Indoor Ambient Temp. 27°CDB / 19°CWB, Outdoor Ambient Temp. 35°CDB / 24°CWB
• Heating : Indoor Ambient Temp. 20°CDB / 15°CWB, Outdoor Ambient Temp. 7°CDB / 6°CWB
• Interconnected Pipe is standard length and difference of Elevation (Outdoor ~ Indoor Unit) is 0m.
