LG ARNU073CEA2 User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
(Company) (ProjectManager)
Tag#:
ARNU073CEA2
MultiV™FloorStanding(withcase)
Btu/hIndoorUnit
Performance:
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB
Outdoor: 95°FDB
Indoor: 70°FDB
Outdoor: 47°FDB/43°FWB
HeatingCapacity(Btu/h)8,500
Electrical:
PowerSupply(V/Hz/Ø) 208‐230/60/1
RatedAmps(A)0.1
Piping:
Refrigerant:
Condensate:
StandardFeatures:
•LimitedWarrantywithLGCerfiedInstallaon
•TwoYearFunctionalPartsWarranty
ControlsFeatures:
•Autochangeover
(HeatRecoveryonly)
•Autooperaon
•Autorestart
•Childlock
•Dualthermistorcontrol
•Groupcontrol
•E.S.P.control
•Hotstart
•Selfdiagnoscs
•Sleepmode
•Timer(on/off)
•Weeklyschedule
•Sodry(dehumidificaon)
•Fanspeedcontrol
UnitData:
RefrigerantType R410A
RefrigerantControl EEV
Fan:
Type Sirocco
Quantity 1
Motor/Drive BrushlessDigitallyControlled/Direct
Notes:
Page1of2VRF‐SB‐DL‐001‐US011H15
PowerInput¹(W) 30
AirflowRateH/M/L(CFM) 300/265/229
EnteringMixedAir:
HeatingMin(°FDB) 59
TotalCoolingCapacity(Btu/h) 7,500
Filter WashablePre‐filter
1.ThePowerInputisratedathighspeed.
2.Requiresa7‐Dayprogrammablecontroller.
3.SeeEngineeringManualforsensibleandlatentcapacies.
4.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
5.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedandmust
complywithapplicablelocalandnationalcode.
6.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
7.Thisunitcomeswithadrynitrogencharge.
8.Thisdataisrated0abovesealevel,with25ofrefrigerantlineperindoorunitanda0
leveldifferencebetweenoutdoorandindoorunits.Allcapacitiesarenetwithacombinationratio
between95–105%.
9.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
7,500
²
O
p
tionalAccessories:
WirelessHandheldRemoteController(PQWRHDF0)
7‐DayProgrammableController(PQRCUSA)
SimpleControllerwithMode(PQRCUCS0C)
SimpleControllerwithoutMode(PQRCFCS0C)
DryContactUnit(PQDSB1,PQDSBC)
WallMountedTemperatureSensor(PQRSTA0)
CondensateLine(in,OD) 3/4
Factor
y
InstalledPum
p
No
CoolingMax³(°FWB) 76
SoundPressure⁴dB(A)(H/M/L) 35/33/31
LGElectronicsUSA,Inc.1000SylvanAve,EnglewoodCliffs,NJ07632/www.lg‐vrf.com
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
NetUnitWeight(lbs) 60
ShippingWeight(lbs) 69
LiquidLine(in,OD) 1/4Flare
VaporLine(in,OD) 1/2Flare

Page2of2VRF‐SB‐DL‐001‐US011H15
ARNU073CEA2
MultiV™FloorStanding(withcase)
Btu/hIndoorUnit
JobName/Location:
Tag#:
Date:
PONo.:
7,500
LGElectronicsUSA,Inc.1000SylvanAve,EnglewoodCliffs,NJ07632/www.lg‐vrf.com
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
