Submittal Data :
Job Name :
Purchaser :
Engineer :
Submitted To :
Submitted By :
Unit Designation : Schedule No.:
Location :
P.O. No. :
Architect :
Date :
For : □Reference □Approval □Construction
Model No.:
36
1 31/3250
1 31/32 * 6 = 11 13/16
13 15/16
22 5/16
1 3/32
2 13/16
3 1/32
5 27/32
4 7/32
11 3/32
11 3/32
2
2 3/32
1 31/32
1 15/32
2
2 - R5/8
6 1/26 1/2
9 5/8
30 5/16
450
10 27/32
13/32
21 5/16
20 13/32
30 5/16
10 1/2
11 7/32
9 5/8
2 7/32
3 15/16
LAN121CNM
LAU121CNM
Capacities :
Cooling
Outdoor Design Temp.(℉,DB/WB)
Cooling
SEER
EER
Indoor Unit :
Power Supply (V,Ph,Hz)
Maximum Fuse Size
Minimum Ampacity
Weight (lbs)
Sound (dB(A),H/M/L Cool)
Air Circulation (CFM)
Dehumidification (pts/hr)
Outdoor Unit :
Power Supply (V,Ph,Hz)
Maximum Fuse Size
Minimum Ampacity
Weight (lbs)
Sound (dB(A), High Cool)
Refrigerant Piping :
Maximum Length (ft)
Maximum Height Difference (ft)
Liquid Side (O.D)
Gas Side (O.D)
Standard Features :
• Five Year Compressor Warranty
• Three Year Functional Parts Warranty
• Changeable Front Panel Color Option
• R-410a Refrigerant
• Plasma Air Purifying System
• Triple Filter Air Purifying System
• Chaos Swing Air Circulation
• Jet Cool TM
• LCD Wireless Remote Controller
• Auto Restart
• 24 Hour On/Off Timer
11,500 Btu/h
95/75
13
10.5
36V DC
Powered by
Outdoor Unit
20.5
41/36/34
330
3.0
115,1,60
20
10.5
72.8
48
50
25
1/4”
1/2”
LA121CNM
Note :
ⒸLG Electronics USA 2006 SD-LA121CNM-VER1
