LG LS091HSV3 Installation and operation manual

SINGLE ZONE HIGH EFFCIENCY, STANDARD AND
EXTENDED PIPE WALL MOUNT ENGINEERING MANUAL
Single Zone Wall Mount Systems
3/4 to 2-3/4 Tons

EM-SZ-HighEfficiencyWallmount-HSV3-HV3-HLV-9-16
For continual product development, LG Electronics U.S.A., Inc., reserves the right to change specifications without notice.
©LG Electronics U.S.A., Inc.
PROPRIETARY DATA NOTICE
This document, as well as all reports, illustrations, data, information, and
other materials is the property of LG Electronics U.S.A., Inc.

Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 3
Introduction
About LG Electronics, Inc.
LG Electronics, Inc. is a global leader and technology innovator
in consumer electronics, mobile communications, and home
appliances, employing more than 213,000 people in more than 60
countries worldwide. With $136 billion (USD) revenue in 2011,
LG Electronics, Inc. is ranked among Fortune 500’s list of largest
companies. LG Electronics, Inc. comprises five business units—
Home Entertainment, Mobile Communications, Air Conditioning,
Business Solutions, and Home Appliance. LG is one of the world’s
leading producers of flat panel televisions, audio and video products,
mobile handsets, air conditioners, and washing machines. LG’s
commercial air conditioning business unit was established in 1968
and has built its lineup of residential and commercial products to
include VRF, Flex-Multi, duct-free split systems, packaged terminal
air conditioners (PTACs), and room air conditioners. In 2011, the air
conditioning and energy solutions business unit grew to include LED
lighting and solar products. For more information, visit www.lg.com.
Duct Free Split (DFS) Technology
LG HVAC systems offer a range of solutions that are cost efficient,
quiet and attractive. Duct-Free Split (DFS) systems are “split” into
indoor and outdoor units, and provide a smart alternative to both
central HVAC and window-mounted air conditioners. These inverter
heat pump systems are available in a variety of configurations to suit
different cooling and heating situations. Installation by a qualified
HVAC contractor is safe and easy – little to no duct work or sheet
metal is required.
Inverter Systems
LG Single Zone Inverter Wall Mount air-source systems offer the
opportunity to minimize ductwork in the same configuration. The
system offers zoning without the need for zone damper systems.
The LG Single Zone Inverter Wall Mount system’s advanced controls
provide exceptional building dehumidification and temperature
control, and can rapidly adapt system operating parameters to the
ever changing building load. The LG Single Zone Inverter Wall Mount
system is easy to design, install, and maintain. The modular design
allows occupants to control their environmental condition, providing
individualized control of the set-point temperature and allowing oc-
cupants to condition only the occupied zones.
Quality Commitment
LG is committed to the success of DFS projects. We provide industry
leading technical support during installation and commissioning. LG
offers a variety of classes designed for installers and servicers to
ensure that every DFS system installation is completed successfully.
Classes are conducted at LG’s training centers and in field locations
at various times throughout the year and upon special request.

4|INTRODUCTION
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
TABLE OF CONTENTS
Architectural Appeal.............................................................................. 6
Product Features and Benets ............................................................ 8
Unit Nomenclature................................................................................. 9
General Data ................................................................................... 10-17
Electrical Data...................................................................................... 18
Outdoor Unit Dimensions.............................................................. 19-21
Indoor Unit Dimensions................................................................. 22-25
Outdoor Unit Acoustic Data................................................................ 26
Indoor Unit Acoustic Data.............................................................. 27-28
Refrigerant Flow Diagrams............................................................ 29-32
Wiring Diagrams............................................................................. 33-39
Accessories .................................................................................... 40-42
Performance Data........................................................................... 43-52
Equipment Selection Procedure ................................................... 54-56
Building Ventilation Design Guide............................................... 57-58
Placement Considerations ............................................................ 59-61
Refrigerant Piping Design ............................................................. 64-65
Installation & Layout Best Practices ............................................ 66-70
Electrical Connections................................................................... 71-72
Mechanical Specications.................................................................. 74
Acronyms............................................................................................. 75
TABLE OF SYMBOLS
This symbol indicates a potentially hazardous situation which, if not avoided, may result in death, serious
injury, property damage or equipment damage.
This symbol indicates additional helpful information such as an explanation, a comment, or a clarication
about the subject.
This symbol indicates a recommendation or tip. Recommendations instruct the user to apply the suggested
practice to ensure the best operating results in order to achieve the maximum benet of the product. Tips
contain practical information that may help the user solve a problem or describe actions that may save time.

INTRODUCTION
“Architectural Appeal” on page 6

6|INTRODUCTION
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Benefits of Single Zone Wall
Mount Systems
•Available from 9,000 - 33,000 Btu/h
•Inverter technology
•All season use - heat pump models for both
cooling and heating capabilities
•Operating range for outdoor units of 14°F to
118°F in cooling and -4°F to 75°F in heating
•Operating range for indoor units of 64°F to
90°F in cooling and 60°F to 86°F in heating
•Quiet operation inside and outside
•Duct-free split system
Convergence of Technological Innovation with Flexibility and Style
Single Zone Inverter
Wall Mount Systems
Single zone wall mount duct free split (DFS)
systems are among the industry’s best air-
conditioning units. Choosing an LG single
zone wall mount product provides a system
designer an edge to engineer a system with
individual control, and design flexibility with
advanced controls.
Single zone systems are available in a
nominal capacity range of 3/4 to 2-3/4
tons. These are best suited for applications
with zones that require heating or cooling,
such as residential, and small business
office buildings. Single zone wall mount
outdoor and indoor units are available in
208–230V/60Hz/1Ph.
Adaptable and Flexible
Single zone wall mount duct-free split (DFS)
systems allow cooling or heating for the
entire residence or just a single room
without the need for evasive ductwork.
There is no tearing down of walls or altering
the homes appearance. Long refrigerant
piping lengths allow for extra design flex-
ibility in indoor unit installation.
These units may be used for a number of
residential or commercial environments
such as:
• Older homes
• New home construction
• Office buildings
• Restaurants
• Hospitals / Medical facilities
• Schools
• Nursing homes
• Retail establishments
• Place of worship
Inverter Technology
Inverter variable-speed DFS systems
are measurably quieter and consume
less energy than conventional air
conditioners. The inverter compressor
ramps up or down to match the required
room capacity and maintain the comfort
level. When the selected temperature
is reached, the inverter compressor
operates at low speed to maintain that
comfort level, thereby using less energy.
ARCHITECTURAL APPEAL

“Product Features and Benefits” on page 8
“Unit Nomenclature” on page 9
“General Data” on page 10
“Electrical Data” on page 18
“Outdoor Unit Dimensions” on page 19
“Indoor Unit Dimensions” on page 22
“Acoustic Data” on page 26
“Refrigerant Flow Diagrams” on page 29
“Wiring Diagrams” on page 33
“Accessories” on page 40
PRODUCT DATA

8|PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Single Zone Systems
Single zone systems are equipped with
inverter components that offer superior
load matching and long piping installation.
The product works for optimizing power
consumption in residential and small office
buildings. Utilizing multiple indoor wall mount
units each with custom temperature controls
allow for precise temperature settings in
each zone of the building. Single zone sys-
tems allow flexibility in interior design and
complement any decor.
Low Sound Levels
When outdoor units operate fully loaded,they
have one of the quietest sound levels in the
industry. Sound is almost undetectable dur-
ing off-peak operation. To promote a quiet,
comfortable environment, the single zone
system indoor units operate at sound levels
as low as 24 dB(A) (High Efficiency Single
Zone) and outdoor units as low as 45 dB(A)
at full load (High Efficiency Single Zone).
LG customers often ask if the outdoor unit is
running after commissioning is complete. All
rotating components are soft-started by the
controller using digitally controlled inverters,
which reduce undesirable noise caused by
fans and compressors cycling on and off.
Comfort Control at Its
Best
Tight temperature control through precise
load matching maximizes the time that the
indoor units remove moisture. Unlike
traditional air conditioning control systems,
which use thermostatic controls to maintain
room temperatures, LG Single Zone Inverter
controls continuously adjust the indoor unit
fan speed and refrigerant flow, indirectly pro-
viding lower and more consistent humidity
levels in the conditioned space. The longer
the indoor coil temperature is below the
dew-point of the room in conjunction with air
movement across the coil, the space humid-
ity level will vary little, compared to technolo-
gies that cycle fans and compressors on and
off multiple times per hour. The outdoor unit
responds by varying the compressor speed
and outdoor fan motors as needed to main-
tain system operating pressure. As a result,
the single zone systems deliver precise
space temperature control.
Inverter Driven
The rotary (9k-12k Btu/h systems) and twin
rotary (18k-36k Btu/h systems) compressors
are optimized to maximize compressor ef-
ficiency, which reduces power consumption
and monthly utility bills. This latest inverter
technology allows single zone system out-
door units to vary the compressor motor
shaft speed to deliver an appropriate amount
of cooling to the indoor unit. Precise refriger-
ant volume delivery translates into long
periods with coil surface temperatures below
dew point and minimizes compressor and
fan component run time. Occupants remain
comfortable while utility costs are reduced.
Simplified Installation
Cooling and heating applications that use
single zone systems simplify and reduce
the mechanical and control system design
time. The designer no longer has to be
concerned with interconnecting chilled and
condenser water piping, air-distribution duct
systems,matching and selecting chillers,
towers,pumps, coils, fans, air handlers, or
Variable Air Volume (VAV) boxes.
Operating Range
Single zone systems have a nominal capac-
ity range of 3/4 to 2-3/4 tons (depending on
outdoor/indoor units).
Operating ranges for single zone systems:
Cooling: 14°F DB to 118°F DB
Heating: -4°F WB to 75°F WB
Installing an optional Low Ambient Wind
Baffle Kit will allow operation down to 0°F in
cooling mode for all single zone systems.
Compact Size
Single zone outdoor units have the following
footprints:
Single Zone High Efficiency
LSU091HSV3, LSU121HSV3
(WxHxD (in)) 30 5/16 x 21 1/2 x 11 5/16.
LSU181HSV3, LSU240HSV3
(WxHxD (in)) 34-1/4 x 31-1/2 x 12-5/8.
Single Zone Standard
LSU307HV3, LSU360HV3
(WxHxD (in)) 34-1/4 x 31-1/2 x 12-5/8.
Single Zone Extended Pipe
LSU240HLV, LSU300HLV, LSU360HLV
(WxHxD (in)) 34-1/4 x 31-1/2 x 12-5/8.
Fin Design with Gold-
Fin™ Coating
All single zone outdoor units are provided
with large surface coils made of copper
tubes with louvered aluminum fins designed
to maximize unit operating efficiency over a
wide range of ambient conditions.
Standard from the factory, every single zone
outdoor unit coil fin surface is coated with
LG’s exclusive GoldFin™ anti-corrosive
coating designed to prevent natural surface
corrosion of the aluminum fins. This main-
tains heat transfer properties of the coil for
an extended time.
A hydrophilic coating is applied to the
outdoor unit coil fin surface over the GoldFin
coating. This coating enhances the develop-
ment of heavier water droplets gathering
on the fin surface. As a result, the droplets
roll off the fin surfaces, delaying the point
when frost forms on the coil surface during
heating operation. This coating also makes it
possible to easily clean the outdoor unit coil
using a mild soap.
Other Features
•Inverter variable speed compressor
•Jet Cool / Jet Heat
•Dehumidifying mode
•Chaos Wind
•Auto restart
•Auto operation
•Self-cleaning indoor coil
•Condensate sensor connection
•Cooling only function
•Precision load matching
•Meets AHRI 210/240
PRODUCT FEATURES AND BENEFITS

PRODUCT DATA | 9
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Single Zone Indoor and Outdoor Units
LS N091 HSV 3
Indoor/Outdoor Product
HV - Standard Wall Mount
HSV - High Efficiency Wall Mount
HLV - Extended Pipe
091 = 9,000
121 = 11,200
181 = 18,200
240 = 22,000
300/307 = 30,000
360 = 33,000
Type
N = Indoor Wall Mount Unit
U = Outdoor Heat Pump Unit
Family
LS = High Efficiency Wall Mount/
Standard Wall Mount
3 = Third Generation
Nominal Capacity
Generation
UNIT NOMENCLATURE
(Nominal cooling capacity in Btu/h)

10 |PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone High Efciency & Single Zone Standard System Pairing Table
The following tables show the available outdoor and indoor units, along with the factory provided controllers.
Table 1: Single Zone High Efciency & Single Zone Standard System Pairing Table
Outdoor Unit Model Indoor Unit Model Controller
LSU091HSV3
LSU121HSV3
LSN091HSV3
LSN121HSV3
AKB73855712
LSU181HSV3 LSN181HSV3 AKB73855712
LSU240HSV3 LSN240HSV3 AKB73855713
LSU307HV3
LSU360HV3 LSN307HV3
LSN360HV3
AKB73855713

PRODUCT DATA | 11
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone Extended Pipe System Pairing Table
Table 2: Single Zone Extended Pipe System Pairing Table
Outdoor Unit Model Indoor Unit Model Controller
LSU240HLV
LSU300HLV
LSU360HLV
LSN240HLV
LSN300HLV
LSN360HLV
AKB74055401

12 |PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Type Single Zone High Efciency Units
System Model Number (IDU/ODU)
LS091HSV3
(LSN091HSV3/
LSU091HSV3)
LS121HSV3
(LSN121HSV3/
LSU121HSV3)
LS181HSV3
(LSN181HSV3/
LSU181HSV3)
LS240HSV3
(LSN240HSV3/
LSU240HSV3)
Nominal Cooling Capacity (Btu/h) 9,000 11,200 18,200 22,000
Cooling Power Input1(kW) 0.67 0.89 1.4 1.7
Nominal Heating Capacity (Btu/h)110,800 13,300 22,000 27,600
Heating Power Input1(kW) 0.70 1.0 1.7 2.3
Cooling COP 3.90 3.66 3.69 3.66
EER 13.3 12.5 12.6 12.5
SEER 21.5 21.5 20.5 20.0
HSPF 11.0 11.0 9.7 10.2
Power Supply (V/Hz/Ø) 208-230/60/1
Outdoor Unit Operating Range2
Cooling (°F DB) 14-118
Heating (°F WB) -4-75
Indoor Unit Operating Range2
Cooling (°F) 64-90
Heating (°F) 60-86
Unit Data
Refrigerant Type3R410A
Refrigerant Control EEV
IDU Sound Pressure4dB(A) (H/M/L) 38/33/24 39/33/24 45/40/35 46/43/39
ODU Sound Pressure4dB(A) 45 45 53 54
Power/Communication Cable5 (No. x AWG) 4 x 18
IDU Net/Shipping Weight (lbs) 23/28 23/28 32/41 36/42
ODU Net/Shipping Weight (lbs) 75/79 75/79 123/131 128/137
Compressor
Compressor Type (Qty) Rotary (1) Rotary (1) Twin Rotary (1) Twin Rotary (1)
Fan
IDU Type (Qty) Cross Flow (1)
ODU Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
IDU Max/H/M/L (CFM) 388/335/272/212 423/353/272/212 735/622/509/399 883/742/629/424
ODU Max (CFM) 1,165 1,165 2,119 2,119
Table 3: Single Zone High Efciency Unit Specications
GENERAL DATA
Single Zone High Efciency Unit Specications
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1Power Input is rated at high speed.
2Low Ambient Wind Baffle Kit allows operation down to 0°F in cooling mode.
3Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy R410A
refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608 of CAA.
4Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
5All power/communication cables to be minimum 18 AWG, 4-conductor, stranded, shielded and must
comply with applicable and national code.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb
(WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet bulb
(WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).

PRODUCT DATA | 13
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone High Efciency Unit Specications
Type Single Zone High Efciency Units
System Model Number (IDU/ODU)
LS091HSV3
(LSN091HSV3/
LSU091HSV3)
LS121HSV3
(LSN121HSV3/
LSU121HSV3)
LS181HSV3
(LSN181HSV3/
LSU181HSV3)
LS240HSV3
(LSN240HSV3/
LSU240HSV3)
Piping
Liquid Line (in, OD) 1/4 1/4 3/8 3/8
Vapor Line (in, OD) 3/8 3/8 5/8 5/8
Condensation Line (OD, ID) 27/32, 5/8 27/32, 5/8 27/32, 5/8 27/32, 5/8
Additional Refrigerant Charge (oz/ft) 0.22 0.22 0.38 0.38
Max Pipe Length6(ft) 65.6 65.6 98.4 98.4
Piping Length6(no add’l refrigerant, ft) 41.0 41.0 24.6 24.6
Max Elevation Difference (ft) 32.8 32.8 49.2 49.2
Table 4: Single Zone High Efciency Unit Specications Continued
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
6Piping lengths are equivalent.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).

14 |PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Table 5: Single Zone Standard Unit Specications
Type Single Zone Standard Units
System Model Number (IDU/ODU) LS307HV3 (LSN307HV3/LSU307HV3) LS360HV3 (LSN360HV3/LSU360HV3)
Nominal Cooling Capacity (Btu/h) 30,000 33,000
Cooling Power Input1(kW) 3.0 4.0
Nominal Heating Capacity (Btu/h)132,000 35,200
Heating Power Input1(kW) 3.1 3.8
Cooling COP 2.93 2.40
EER 10.0 8.2
SEER 18.0 16.1
HSPF 9.5 9.9
Power Supply (V/Hz/Ø) 208-230/60/1 208-230/60/1
Outdoor Unit Operating Range
Cooling (°F DB) 14-118 14-118
Heating (°F WB) -4-75 -4-75
Indoor Unit Operating Range
Cooling (°F) 64-90 64-90
Heating (°F) 60-86 60-86
Unit Data
Refrigerant Type2R410A R410A
Refrigerant Control EEV EEV
IDU Sound Pressure3dB(A) (H/M/L) 49/44/39 49/44/39
ODU Sound Pressure3dB(A) 55 55
Power/Communication Cable4 (No. x AWG) 4 x 18 4 x 18
IDU Net/Shipping Weight (lbs) 36/42 36/42
ODU Net/Shipping Weight (lbs) 128/137 128/137
Compressor
Compressor Type (Qty) Twin Rotary (1) Twin Rotary (1)
Fan
IDU Type (Qty) Cross Flow Cross Flow
ODU Type (Qty) Propeller Propeller
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
IDU Max/H/M/L (CFM) 883/770/629/424 883/795/629/424
ODU Max (CFM) 2,119 2,119
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy
R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608
of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cables to be minimum 18 AWG, 4-conductor, stranded, shielded and must
comply with applicable and national code.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
GENERAL DATA
Single Zone Standard Specications

PRODUCT DATA | 15
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
Type Single Zone Standard Units
System Model Number (IDU/ODU) LS307HV3 (LSN307HV3/LSU307HV3) LS360HV3 (LSN360HV3/LSU360HV3)
Piping
Liquid Line (in, OD) 3/8 3/8
Vapor Line (in, OD) 5/8 5/8
Condensation Line (OD/ID) 27/32, 5/8 27/32, 5/8
Additional Refrigerant Charge (oz/ft) 0.38 0.38
Max Pipe Length5(ft) 98.4 98.4
Piping Length5(no add’l refrigerant, ft) 24.6 24.6
Max Elevation Difference (ft) 49.2 49.2
Table 6: Single Zone Standard Unit Specications Continued
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
5Piping lengths are equivalent.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
GENERAL DATA
Single Zone Standard Specications

16 |PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone Extended Pipe Unit Specications
Type Single Zone Extended Pipe Units
System Model Number (IDU/ODU) LS240HLV (LSN240HLV/
LSU240HLV)
LS300HLV (LSN300HLV/
LSU300HLV)
LS360HLV (LSN360HLV/
LSU360HLV)
Nominal Cooling Capacity (Btu/h) 22,000 30,000 33,000
Cooling Power Input1(kW) 1.7 3.0 4.0
Nominal Heating Capacity (Btu/h)127,000 32,000 35,200
Heating Power Input1(kW) 2.3 3.1 3.8
Cooling COP 3.66 2.93 2.40
EER 12.5 10.0 8.2
SEER 21.0 18.5 16.5
HSPF 11 10 10
Power Supply (V/Hz/Ø) 208-230/60/1
Outdoor Unit Operating Range
Cooling (°F DB) 14-118
Heating (°F WB) -4-75
Indoor Unit Operating Range
Cooling (°F) 64-90
Heating (°F) 60-86
Unit Data
Refrigerant Type2R410A
Refrigerant Control EEV
IDU Sound Pressure3dB(A) (H/M/L) 49/44/40 49/44/40 49/44/40
ODU Sound Pressure3dB(A) 55 55 55
Power/Communication Cable4 (No. x AWG) 4 x 18
IDU Net/Shipping Weight (lbs) 40/46 40/46 40/46
ODU Net/Shipping Weight (lbs) 125/133 125/133 125/133
Compressor
Compressor Type (Qty) Twin Rotary (1) Twin Rotary (1) Twin Rotary (1)
Fan
IDU Type (Qty) Cross Flow
ODU Type (Qty) Propeller
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
IDU Max/H/M/L (CFM) 848/706/530/459 848/706/530/459 848/706/530/459
ODU Max (CFM) 2,119 2,119 2,119
Table 7: Single Zone Extended Pipe Unit Specications
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy
R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608
of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cables to be minimum 18 AWG, 4-conductor, stranded, shielded and must
comply with applicable and national code.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).

PRODUCT DATA | 17
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone Extended Pipe Unit Specications
Type Single ZoneExtended Pipe Units
System Model Number (IDU/ODU) LS240HLV (LSN240HLV/
LSU240HLV)
LS300HLV (LSN300HLV/
LSU300HLV)
LS360HLV (LSN360HLV/
LSU360HLV)
Piping
Liquid Line (in, OD) 3/8 3/8 3/8
Vapor Line (in, OD) 5/8 5/8 5/8
Condensation Line (OD, ID) 27/32, 5/8 27/32, 5/8 27/32, 5/8
Additional Refrigerant Charge (oz/ft) 0.38 0.38 0.38
Max Pipe Length5(ft) 164 164 164
Piping Length5(no add’l refrigerant, ft) 24.6 24.6 24.6
Max Elevation Difference (ft) 98.4 98.4 98.4
Table 8: Single Zone Extended Pipe Unit Specications Continued
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
5Piping lengths are equivalent.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).

18 |PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
ELECTRICAL DATA
Model Number Nom. Tons Compressor Qty Compressor (A)
Cool/Heat Fan Qty ODU Fan (A) MCA (A) MOP (A)
LSU091HSV3 3/4 1 8.7/8.7 1 0.40 10 15
LSU121HSV3 1 1 8.7/8.7 1 0.40 10 15
LSU181HSV3 1-1/2 1 15.4/15.4 1 0.25 19 25
LSU240HSV3 1-3/4 1 15.4/15.4 1 0.25 19 25
Table 9: Single Zone High Efciency Unit Electrical Data
Model Number Nom. Tons Compressor Qty Compressor (A)
Cool/Heat Fan Qty ODU Fan (A) MCA (A) MOP (A)
LSU307HV3 2-1/2 1 15.4/15.4 1 0.25 19 25
LSU360HV3 2-3/4 1 15.4/15.4 1 0.25 19 25
Table 10: Single Zone Standard Unit Electrical Data
Model Number Nom. Tons Compressor Qty Compressor (A)
Cool/Heat Fan Qty ODU Fan (A) MCA (A) MOP (A)
LSU240HLV 1-3/4 1 17.3/17.3 1 0.25 23 35
LSU300HLV 2-1/2 1 17.3/17.3 1 0.25 23 35
LSU360HLV 2-3/4 1 17.3/17.3 1 0.25 23 35
Table 11: Single Zone Extended Pipe Unit Electrical Data

PRODUCT DATA | 19
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
OUTDOOR UNIT DIMENSIONS
LSU091HSV3, LSU121HSV3
30-5/16
22 4-3/16
13-7/8
6-1/8
2-1/8
10-7/8 1
20-7/8
21-1/2
10-1/2
2-13/16 8-1/8
4
3
2
5
11-5/16
Ø18-5/16
Unit: inch
Return Air Grille

20 |PRODUCT DATA
Single Zone High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
© LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
OUTDOOR UNIT DIMENSIONS
LSU181HSV3, LSU240HSV3, LSU307HV3, LSU360HV3
34-1/4 21-1/2
12-5/8
14-3/16
6-5/16
2-3/16
13-1/8 12-5/8
31-1/2
30-13/16
15-3/8
3-1/8
2
Ø20-7/8
ksrameRema
Nt
raP.oNmetI
1 Return Air Grille 2
3
4 5 6
Unit: inch
