PERFORMANCE DATA MANUAL
Variable Refrigerant Flow Outdoor Units
6.0 to 42.0 Tons

For continual product development, LG Electronics U.S.A., Inc. reserves the right to change specifications without notice.
© LG Electronics U.S.A., Inc.
This document, as well as all reports, illustrations, data, information,
and other materials are the property of LG Electronics U.S.A., Inc., and are
disclosed by LG Electronics U.S.A., Inc. only in confidence.
This document is for design purposes only.
Asummary list of safety precautions is on page 3.
For more technical materials such as submittals, catalogs, installation,
owner’s, and service manuals, visit www.lghvac.com.
PROPRIETARY DATA NOTICE

PERFORMANCE DATA | 3
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
Performance Data....................................................................................................................................................................................................4-156
Cooling Capacity...................................................................................................................................................................................................5-100
Heating Capacity...............................................................................................................................................................................................101-156
Correction Factors..............................................................................................................................................................................................157-160
Defrost Correction Factor for Heating Operation...................................................................................................................................................... 158
Equivalent Length Calculation..................................................................................................................................................................................158
Elevation Correction Factors.............................................................................................................................................................................159-160
TABLE OF CONTENTS
TABLE OF SYMBOLS
DANGER This symbol indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING This symbol indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION This symbol indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
This symbol indicates situations that may result in equipment or property damage accidents only.
This symbol indicates an action that should not be performed.

Cooling Capacity Data on page 5
Heating Capacity Data on page 100
PERFORMANCE
DATA

PERFORMANCE DATA | 5
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
COOLING CAPACITY DATA
72,000 Btu/h 208-230V / 460V Outdoor Units
ARUM072BTE5 / ARUM072DTE5
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
130%
-9.9 65.5 1.37 77.8 1.66 90.4 1.97 93.7 2.13 95.1 2.30 98.4 2.63 100.7 2.72
-5 65.5 1.45 77.8 1.76 90.4 2.08 93.7 2.25 95.1 2.42 98.4 2.78 100.7 2.87
0 65.5 1.50 77.8 1.83 90.4 2.17 93.7 2.34 95.1 2.52 98.4 2.89 100.7 2.99
5 65.5 1.56 77.8 1.89 90.4 2.25 93.7 2.42 95.1 2.61 98.4 3.00 100.7 3.10
10 65.5 1.60 77.8 1.95 90.4 2.31 93.7 2.49 95.1 2.69 98.4 3.08 100.7 3.19
14 65.5 1.66 77.8 2.02 90.4 2.39 93.7 2.58 95.1 2.79 98.4 3.20 100.7 3.30
20 65.5 1.69 77.8 2.05 90.4 2.43 93.7 2.62 95.1 2.83 98.4 3.24 100.7 3.35
25 65.5 1.71 77.8 2.08 90.4 2.46 93.7 2.66 95.1 2.86 98.4 3.28 100.7 3.39
30 65.5 1.74 77.8 2.10 90.4 2.49 93.7 2.69 95.1 2.89 98.4 3.31 100.7 3.43
35 65.5 1.76 77.8 2.13 90.4 2.52 93.7 2.72 95.1 2.93 98.4 3.35 100.7 3.47
40 65.5 1.78 77.8 2.15 90.4 2.55 93.7 2.75 95.1 2.96 98.4 3.39 100.7 3.51
45 65.5 1.80 77.8 2.18 90.4 2.58 93.7 2.78 95.1 2.99 98.4 3.43 100.7 3.55
50 65.5 1.82 77.8 2.20 90.4 2.60 93.7 2.81 95.1 3.02 98.4 3.46 100.7 3.58
55 65.5 1.85 77.8 2.24 90.4 2.65 92.4 2.87 93.7 3.08 97.0 3.52 99.4 3.61
60 65.5 1.91 77.8 2.32 89.1 2.76 90.3 2.98 91.4 3.20 94.7 3.63 97.0 3.65
65 65.5 1.95 77.8 2.37 87.7 2.81 89.1 3.04 90.1 3.26 93.3 3.75 95.7 3.78
70 65.5 1.87 77.8 2.28 86.1 2.80 87.1 3.08 88.4 3.38 91.6 3.76 94.0 3.79
75 65.5 1.92 77.8 2.43 84.8 3.00 85.7 3.31 87.1 3.62 90.3 3.93 92.6 3.96
80 65.5 2.18 77.8 2.76 82.4 3.43 83.4 3.78 84.8 4.16 87.9 4.27 90.3 4.31
85 65.5 2.32 77.8 2.95 81.1 3.66 82.4 4.04 83.4 4.41 86.6 4.45 89.0 4.49
90 65.5 2.63 76.4 3.35 78.8 4.16 79.8 4.60 81.1 4.76 84.3 4.80 86.6 4.84
95 66.2 2.79 75.9 3.57 78.3 4.44 79.6 4.91 80.6 4.93 83.8 4.97 86.2 5.02
100 66.2 3.02 74.6 3.86 76.9 4.81 78.3 5.16 79.3 5.19 82.8 5.24 85.2 5.29
105 66.2 3.41 72.6 4.37 74.9 5.43 76.1 5.55 77.2 5.58 79.9 5.63 81.1 5.69
110 66.2 3.82 69.6 4.92 72.5 5.92 72.7 5.95 73.8 5.97 75.3 6.03 75.6 6.09
115 65.8 4.42 67.0 5.66 67.0 6.24 67.0 6.24 67.0 6.24 68.0 6.25 68.3 6.26
118 57.2 3.75 58.3 4.80 58.4 5.25 58.4 5.30 58.4 5.30 59.2 5.31 59.0 5.31
122 45.7 2.84 46.7 3.65 46.5 4.00 46.6 4.00 46.7 4.01 47.5 4.02 47.5 4.04
120%
-9.9 59.6 1.29 71.1 1.57 82.6 1.85 88.5 2.00 92.5 2.16 96.7 2.47 98.7 2.55
-5 59.6 1.36 71.1 1.65 82.6 1.96 88.5 2.11 92.5 2.27 96.7 2.61 98.7 2.70
0 59.6 1.42 71.1 1.72 82.6 2.03 88.5 2.19 92.5 2.37 96.7 2.71 98.7 2.80
5 59.6 1.47 71.1 1.78 82.6 2.11 88.5 2.27 92.5 2.45 96.7 2.81 98.7 2.91
10 59.6 1.51 71.1 1.83 82.6 2.17 88.5 2.34 92.5 2.52 96.7 2.89 98.7 2.99
14 59.6 1.57 71.1 1.90 82.6 2.25 88.5 2.42 92.5 2.61 96.7 3.00 98.7 3.10
20 59.6 1.59 71.1 1.93 82.6 2.28 88.5 2.46 92.5 2.65 96.7 3.04 98.7 3.14
25 59.6 1.61 71.1 1.95 82.6 2.31 88.5 2.49 92.5 2.68 96.7 3.07 98.7 3.18
30 59.6 1.63 71.1 1.97 82.6 2.33 88.5 2.52 92.5 2.71 96.7 3.11 98.7 3.22
35 59.6 1.65 71.1 2.00 82.6 2.36 88.5 2.56 92.5 2.75 96.7 3.15 98.7 3.26
40 59.6 1.67 71.1 2.02 82.6 2.39 88.5 2.59 92.5 2.78 96.7 3.19 98.7 3.30
45 59.6 1.69 71.1 2.05 82.6 2.42 88.5 2.62 92.5 2.81 96.7 3.22 98.7 3.34
50 59.6 1.71 71.1 2.07 82.6 2.45 88.5 2.65 92.5 2.84 96.7 3.26 98.7 3.37
55 59.6 1.74 71.1 2.11 82.6 2.49 88.5 2.70 91.5 2.90 95.4 3.32 97.7 3.40
60 59.6 1.80 71.1 2.18 82.6 2.60 87.9 2.81 88.9 3.01 93.0 3.42 95.0 3.48
65 59.6 1.83 71.1 2.23 82.6 2.65 86.6 2.86 87.9 3.07 91.7 3.53 94.0 3.56
70 59.6 1.80 71.1 2.18 82.6 2.69 84.9 2.96 85.9 3.25 90.0 3.61 92.0 3.64
75 59.6 1.84 71.1 2.33 82.6 2.88 83.6 3.17 84.9 3.48 88.6 3.78 91.0 3.80
80 59.6 2.09 71.1 2.65 80.3 3.29 81.3 3.63 82.3 3.99 86.3 4.10 88.3 4.14
85 59.6 2.23 71.1 2.83 79.0 3.52 80.0 3.88 81.3 4.23 84.9 4.27 87.3 4.31
90 59.6 2.53 71.1 3.22 76.7 3.99 77.7 4.41 78.7 4.57 82.6 4.60 84.6 4.65
95 60.2 2.68 71.9 3.43 76.2 4.26 77.2 4.71 78.5 4.73 82.1 4.77 84.5 4.82
100 60.2 2.90 71.9 3.70 74.8 4.62 76.2 4.96 77.2 4.99 81.1 5.03 83.1 5.08
105 60.2 3.27 70.7 4.19 72.9 5.21 74.0 5.33 75.0 5.36 78.7 5.41 80.0 5.46
110 60.2 3.67 68.9 4.72 71.1 5.68 71.4 5.71 72.4 5.73 74.7 5.79 75.0 5.84
115 58.5 4.25 66.4 5.43 66.4 5.99 66.4 5.99 66.4 5.99 68.0 6.00 68.3 6.01
118 52.3 3.75 57.7 4.60 57.8 5.04 57.8 5.08 57.8 5.08 59.2 5.09 59.0 5.10
122 41.8 2.84 46.3 3.50 46.1 3.84 46.2 3.84 46.3 3.85 47.6 3.86 47.5 3.88
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).

6 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
COOLING CAPACITY DATA
72,000 Btu/h 208-230V / 460V Outdoor Units
ARUM072BTE5 / ARUM072DTE5
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
110%
-9.9 55.2 1.19 65.9 1.43 76.5 1.70 81.8 1.84 87.2 1.97 96.0 2.25 98.1 2.34
-5 55.2 1.25 65.9 1.51 76.5 1.79 81.8 1.94 87.2 2.08 96.0 2.38 98.1 2.47
0 55.2 1.30 65.9 1.57 76.5 1.87 81.8 2.02 87.2 2.17 96.0 2.47 98.1 2.57
5 55.2 1.35 65.9 1.63 76.5 1.93 81.8 2.10 87.2 2.25 96.0 2.56 98.1 2.66
10 55.2 1.39 65.9 1.68 76.5 1.99 81.8 2.16 87.2 2.31 96.0 2.64 98.1 2.74
14 55.2 1.44 65.9 1.74 76.5 2.06 81.8 2.24 87.2 2.40 96.0 2.73 98.1 2.83
20 55.2 1.46 65.9 1.77 76.5 2.09 81.8 2.27 87.2 2.43 96.0 2.78 98.1 2.88
25 55.2 1.48 65.9 1.79 76.5 2.12 81.8 2.29 87.2 2.46 96.0 2.82 98.1 2.92
30 55.2 1.50 65.9 1.81 76.5 2.14 81.8 2.32 87.2 2.49 96.0 2.86 98.1 2.95
35 55.2 1.52 65.9 1.84 76.5 2.17 81.8 2.35 87.2 2.53 96.0 2.90 98.1 3.00
40 55.2 1.54 65.9 1.87 76.5 2.21 81.8 2.38 87.2 2.56 96.0 2.94 98.1 3.04
45 55.2 1.57 65.9 1.89 76.5 2.24 81.8 2.42 87.2 2.61 96.0 2.99 98.1 3.09
50 55.2 1.59 65.9 1.93 76.5 2.28 81.8 2.46 87.2 2.65 96.0 3.04 98.1 3.14
55 55.2 1.62 65.9 1.96 76.5 2.32 81.8 2.52 87.2 2.70 94.7 3.09 96.7 3.17
60 55.2 1.67 65.9 2.03 76.5 2.42 81.8 2.61 87.2 2.81 92.3 3.19 94.3 3.21
65 55.2 1.71 65.9 2.08 76.5 2.46 81.8 2.67 87.2 2.86 90.9 3.29 93.0 3.32
70 55.2 1.72 65.9 2.09 76.5 2.58 81.8 2.84 85.5 3.11 89.2 3.46 91.3 3.49
75 55.2 1.77 65.9 2.23 76.5 2.76 81.8 3.04 84.2 3.34 87.9 3.62 89.9 3.65
80 54.7 2.01 65.2 2.54 75.7 3.16 80.0 3.48 81.0 3.83 84.6 3.93 86.6 3.97
85 54.7 2.14 65.2 2.72 75.7 3.37 78.7 3.72 79.7 4.06 83.3 4.09 85.3 4.13
90 54.7 2.42 65.2 3.09 75.4 3.83 76.4 4.23 77.4 4.38 80.9 4.41 83.0 4.46
95 54.7 2.57 65.2 3.28 74.1 4.09 75.1 4.52 76.1 4.53 79.6 4.58 81.6 4.62
100 54.7 2.78 65.2 3.55 73.1 4.43 74.1 4.75 75.1 4.78 78.6 4.82 80.6 4.87
105 54.7 3.13 65.2 4.02 70.8 5.00 71.8 5.11 72.8 5.14 76.3 5.19 78.2 5.24
110 54.7 3.52 65.2 4.53 68.6 5.45 68.8 5.48 69.8 5.49 72.0 5.55 72.3 5.60
115 54.7 4.07 65.2 5.21 65.7 5.75 65.7 5.75 66.0 5.75 67.3 5.76 67.6 5.77
118 52.8 3.71 56.7 4.41 57.2 4.83 57.2 4.87 57.5 4.87 58.6 4.88 58.4 4.89
122 42.2 2.81 45.5 3.36 45.6 3.68 45.7 3.69 46.0 3.69 47.1 3.70 47.0 3.72
100%
-9.9 48.5 1.05 57.9 1.26 67.2 1.50 72.0 1.63 79.1 1.76 88.7 2.04 93.7 2.12
-5 48.5 1.10 57.9 1.33 67.2 1.58 72.0 1.72 79.1 1.86 88.7 2.15 93.7 2.24
0 48.5 1.15 57.9 1.39 67.2 1.64 72.0 1.79 79.1 1.94 88.7 2.23 93.7 2.33
5 48.5 1.19 57.9 1.44 67.2 1.70 72.0 1.85 79.1 2.01 88.7 2.32 93.7 2.41
10 48.5 1.22 57.9 1.48 67.2 1.75 72.0 1.91 79.1 2.06 88.7 2.38 93.7 2.48
14 48.5 1.27 57.9 1.53 67.2 1.81 72.0 1.98 79.1 2.14 88.7 2.47 93.7 2.57
20 48.5 1.31 57.9 1.58 67.2 1.87 72.0 2.03 79.1 2.21 88.7 2.54 93.7 2.64
25 48.5 1.34 57.9 1.62 67.2 1.92 72.0 2.08 79.1 2.26 88.7 2.60 93.7 2.70
30 48.5 1.37 57.9 1.66 67.2 1.97 72.0 2.13 79.1 2.32 88.7 2.66 93.7 2.77
35 48.5 1.40 57.9 1.69 67.2 2.00 72.0 2.16 79.1 2.36 88.7 2.70 93.7 2.81
40 48.5 1.42 57.9 1.72 67.2 2.03 72.0 2.20 79.1 2.40 88.7 2.75 93.7 2.86
45 48.5 1.45 57.9 1.75 67.2 2.07 72.0 2.24 79.1 2.44 88.7 2.80 93.7 2.91
50 48.5 1.48 57.9 1.79 67.2 2.12 72.0 2.29 79.1 2.50 88.7 2.86 93.7 2.97
55 48.5 1.50 57.9 1.82 67.2 2.16 72.0 2.34 79.1 2.55 88.7 2.91 92.7 3.02
60 48.5 1.55 57.9 1.89 67.2 2.25 72.0 2.43 79.1 2.64 88.4 3.00 90.1 3.07
65 48.5 1.58 57.9 1.93 67.2 2.29 72.0 2.47 79.1 2.69 87.1 3.10 89.1 3.16
70 48.5 1.63 57.9 1.98 67.2 2.44 72.0 2.69 79.1 2.99 85.4 3.32 87.1 3.38
75 48.5 1.67 57.9 2.12 67.2 2.61 72.0 2.88 79.1 3.21 84.1 3.48 86.1 3.52
80 48.5 1.90 57.9 2.41 67.2 2.99 72.0 3.30 79.1 3.68 81.8 3.78 83.4 3.83
85 48.5 2.03 57.9 2.57 67.2 3.19 72.0 3.52 78.8 3.90 80.5 3.94 82.4 3.99
90 48.5 2.30 57.9 2.92 67.2 3.63 72.0 4.01 76.1 4.21 78.1 4.24 79.8 4.31
95 48.5 2.43 57.9 3.11 67.2 3.87 72.0 4.28 75.2 4.36 76.8 4.40 78.8 4.47
100 48.5 2.63 57.9 3.36 67.2 4.19 70.7 4.49 73.9 4.59 75.8 4.63 77.5 4.69
105 48.5 2.95 57.9 3.78 66.8 4.71 68.8 4.82 71.6 4.91 73.5 4.96 75.3 5.02
110 48.5 3.30 57.9 4.25 66.0 5.11 67.5 5.14 68.9 5.23 70.0 5.28 71.3 5.36
115 48.5 3.79 57.9 4.85 62.9 5.35 64.8 5.35 66.4 5.43 67.0 5.44 67.3 5.48
118 48.5 3.83 50.8 4.55 54.7 4.50 56.4 4.54 57.8 4.61 58.4 4.62 58.1 4.65
122 41.5 3.46 40.7 3.46 43.6 3.42 45.1 3.43 46.3 3.49 46.9 3.50 46.8 3.53

PERFORMANCE DATA | 7
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
90%
-9.9 43.7 0.93 52.1 1.12 60.8 1.32 64.9 1.42 69.1 1.52 77.5 1.75 85.8 1.92
-5 43.7 0.98 52.1 1.18 60.8 1.39 64.9 1.50 69.1 1.60 77.5 1.84 85.8 2.03
0 43.7 1.02 52.1 1.23 60.8 1.45 64.9 1.56 69.1 1.67 77.5 1.92 85.8 2.11
5 43.7 1.06 52.1 1.27 60.8 1.50 64.9 1.62 69.1 1.73 77.5 1.99 85.8 2.18
10 43.7 1.09 52.1 1.31 60.8 1.55 64.9 1.66 69.1 1.78 77.5 2.05 85.8 2.25
14 43.7 1.13 52.1 1.36 60.8 1.60 64.9 1.72 69.1 1.84 77.5 2.12 85.8 2.33
20 43.7 1.17 52.1 1.41 60.8 1.66 64.9 1.79 69.1 1.92 77.5 2.20 85.8 2.42
25 43.7 1.21 52.1 1.45 60.8 1.71 64.9 1.84 69.1 1.98 77.5 2.26 85.8 2.49
30 43.7 1.24 52.1 1.49 60.8 1.76 64.9 1.90 69.1 2.05 77.5 2.32 85.8 2.57
35 43.7 1.28 52.1 1.54 60.8 1.81 64.9 1.96 69.1 2.11 77.5 2.39 85.8 2.65
40 43.7 1.32 52.1 1.59 60.8 1.87 64.9 2.02 69.1 2.17 77.5 2.46 85.8 2.72
45 43.7 1.35 52.1 1.62 60.8 1.91 64.9 2.06 69.1 2.22 77.5 2.52 85.8 2.79
50 43.7 1.38 52.1 1.66 60.8 1.96 64.9 2.11 69.1 2.27 77.5 2.58 85.8 2.85
55 43.7 1.39 52.1 1.68 60.8 1.99 64.9 2.15 69.1 2.31 77.5 2.63 85.8 2.87
60 43.7 1.45 52.1 1.75 60.8 2.07 64.9 2.24 69.1 2.41 77.5 2.73 85.1 2.91
65 43.7 1.47 52.1 1.79 60.8 2.11 64.9 2.28 69.1 2.45 77.5 2.78 84.5 3.05
70 43.7 1.51 52.1 1.84 60.8 2.19 64.9 2.41 69.1 2.63 77.5 3.10 82.9 3.28
75 43.7 1.54 52.1 1.92 60.8 2.34 64.9 2.58 69.1 2.82 77.5 3.24 81.6 3.42
80 43.7 1.73 52.1 2.18 60.8 2.67 64.9 2.94 69.1 3.22 77.5 3.58 79.4 3.72
85 43.7 1.84 52.1 2.32 60.8 2.86 64.9 3.14 69.1 3.44 76.5 3.77 78.1 3.88
90 43.7 2.07 52.1 2.63 60.8 3.24 64.9 3.57 69.1 3.92 74.3 4.12 75.9 4.18
95 43.7 2.21 52.1 2.79 60.8 3.45 64.9 3.81 69.1 4.18 73.0 4.28 74.6 4.34
100 43.7 2.28 52.1 2.91 60.8 3.60 64.9 3.96 69.1 4.28 72.0 4.46 73.3 4.51
105 43.7 2.65 52.1 3.37 60.8 4.07 64.9 4.34 68.3 4.58 69.8 4.79 70.7 4.84
110 43.7 3.04 52.1 3.89 60.8 4.46 64.9 4.68 65.6 4.97 66.4 5.14 67.0 5.20
115 43.7 3.29 52.1 4.22 56.9 4.70 61.6 4.90 62.4 5.13 63.0 5.24 63.3 5.31
118 43.7 3.49 50.8 4.55 49.5 3.95 53.6 4.16 54.4 4.35 54.9 4.45 54.6 4.50
122 41.5 3.46 40.7 3.46 39.5 3.01 42.8 3.14 43.5 3.30 44.1 3.37 44.0 3.42
80%
-9.9 38.9 0.81 46.3 0.97 54.0 1.13 57.5 1.23 61.4 1.32 68.8 1.51 76.2 1.68
-5 38.9 0.85 46.3 1.03 54.0 1.19 57.5 1.30 61.4 1.40 68.8 1.60 76.2 1.78
0 38.9 0.89 46.3 1.07 54.0 1.24 57.5 1.35 61.4 1.45 68.8 1.66 76.2 1.85
5 38.9 0.92 46.3 1.11 54.0 1.29 57.5 1.40 61.4 1.51 68.8 1.72 76.2 1.92
10 38.9 0.95 46.3 1.14 54.0 1.32 57.5 1.44 61.4 1.55 68.8 1.77 76.2 1.97
14 38.9 0.98 46.3 1.18 54.0 1.37 57.5 1.49 61.4 1.61 68.8 1.83 76.2 2.04
20 38.9 1.02 46.3 1.22 54.0 1.43 57.5 1.55 61.4 1.66 68.8 1.90 76.2 2.12
25 38.9 1.05 46.3 1.26 54.0 1.47 57.5 1.59 61.4 1.71 68.8 1.96 76.2 2.19
30 38.9 1.08 46.3 1.29 54.0 1.52 57.5 1.64 61.4 1.75 68.8 2.01 76.2 2.25
35 38.9 1.11 46.3 1.33 54.0 1.56 57.5 1.68 61.4 1.80 68.8 2.07 76.2 2.32
40 38.9 1.14 46.3 1.37 54.0 1.60 57.5 1.73 61.4 1.85 68.8 2.12 76.2 2.38
45 38.9 1.16 46.3 1.38 54.0 1.63 57.5 1.75 61.4 1.87 68.8 2.15 76.2 2.41
50 38.9 1.17 46.3 1.40 54.0 1.65 57.5 1.78 61.4 1.90 68.8 2.18 76.2 2.44
55 38.9 1.19 46.3 1.43 54.0 1.68 57.5 1.81 61.4 1.94 68.8 2.22 76.2 2.48
60 38.9 1.23 46.3 1.47 54.0 1.74 57.5 1.87 61.4 2.02 68.8 2.30 76.2 2.59
65 38.9 1.25 46.3 1.50 54.0 1.77 57.5 1.91 61.4 2.06 68.8 2.34 76.2 2.65
70 38.9 1.28 46.3 1.55 54.0 1.82 57.5 1.97 61.4 2.14 68.8 2.53 76.2 2.92
75 38.9 1.31 46.3 1.58 54.0 1.91 57.5 2.10 61.4 2.28 68.8 2.69 76.2 3.08
80 38.9 1.43 46.3 1.79 54.0 2.18 57.5 2.38 61.4 2.60 68.8 3.09 76.2 3.45
85 38.9 1.53 46.3 1.90 54.0 2.32 57.5 2.54 61.4 2.79 68.8 3.29 76.2 3.53
90 38.9 1.72 46.3 2.16 54.0 2.63 57.5 2.89 61.4 3.17 68.8 3.62 74.9 3.75
95 38.9 1.82 46.3 2.28 54.0 2.81 57.5 3.07 61.4 3.37 68.8 3.75 73.3 3.85
100 38.9 1.97 46.3 2.46 54.0 3.03 57.5 3.29 61.4 3.50 68.8 3.90 71.7 3.97
105 38.9 2.24 46.3 2.82 54.0 3.37 57.5 3.53 61.4 3.76 68.0 4.05 69.6 4.17
110 38.9 2.54 46.3 3.21 54.0 3.57 57.5 3.77 61.4 4.05 65.6 4.20 65.9 4.38
115 38.9 2.72 46.3 3.43 54.0 3.69 57.5 3.96 57.5 4.14 57.9 4.30 57.9 4.56
118 38.9 2.89 46.3 3.65 49.5 3.95 50.5 3.76 50.1 3.52 50.4 3.65 50.0 3.87
122 38.9 3.12 40.8 3.44 39.5 3.01 40.4 2.84 40.1 2.66 40.5 2.76 40.2 2.94
COOLING CAPACITY DATA
72,000 Btu/h 208-230V / 460V Outdoor Units
ARUM072BTE5 / ARUM072DTE5

8 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
COOLING CAPACITY DATA
72,000 Btu/h 208-230V / 460V Outdoor Units
ARUM072BTE5 / ARUM072DTE5
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
70%
-9.9 34.1 0.71 40.5 0.85 47.3 1.00 50.5 1.07 53.7 1.14 60.1 1.30 66.9 1.46
-5 34.1 0.75 40.5 0.89 47.3 1.05 50.5 1.13 53.7 1.20 60.1 1.38 66.9 1.54
0 34.1 0.78 40.5 0.93 47.3 1.10 50.5 1.17 53.7 1.25 60.1 1.43 66.9 1.60
5 34.1 0.81 40.5 0.96 47.3 1.14 50.5 1.22 53.7 1.30 60.1 1.48 66.9 1.66
10 34.1 0.84 40.5 0.99 47.3 1.17 50.5 1.25 53.7 1.33 60.1 1.53 66.9 1.71
14 34.1 0.87 40.5 1.03 47.3 1.21 50.5 1.30 53.7 1.38 60.1 1.58 66.9 1.77
20 34.1 0.90 40.5 1.06 47.3 1.25 50.5 1.34 53.7 1.43 60.1 1.63 66.9 1.83
25 34.1 0.92 40.5 1.09 47.3 1.28 50.5 1.37 53.7 1.47 60.1 1.67 66.9 1.88
30 34.1 0.95 40.5 1.12 47.3 1.31 50.5 1.41 53.7 1.51 60.1 1.72 66.9 1.93
35 34.1 0.97 40.5 1.15 47.3 1.35 50.5 1.45 53.7 1.55 60.1 1.76 66.9 1.98
40 34.1 1.00 40.5 1.18 47.3 1.38 50.5 1.48 53.7 1.59 60.1 1.81 66.9 2.03
45 34.1 1.01 40.5 1.20 47.3 1.40 50.5 1.51 53.7 1.61 60.1 1.84 66.9 2.06
50 34.1 1.03 40.5 1.22 47.3 1.43 50.5 1.53 53.7 1.64 60.1 1.87 66.9 2.10
55 34.1 1.05 40.5 1.24 47.3 1.45 50.5 1.56 53.7 1.67 60.1 1.90 66.9 2.14
60 34.1 1.08 40.5 1.28 47.3 1.50 50.5 1.62 53.7 1.73 60.1 1.97 66.9 2.22
65 34.1 1.09 40.5 1.31 47.3 1.53 50.5 1.65 53.7 1.77 60.1 2.01 66.9 2.26
70 34.1 1.12 40.5 1.34 47.3 1.58 50.5 1.69 53.7 1.82 60.1 2.08 66.9 2.40
75 34.1 1.14 40.5 1.37 47.3 1.61 50.5 1.75 53.7 1.90 60.1 2.22 66.9 2.54
80 34.1 1.23 40.5 1.51 47.3 1.82 50.5 1.99 53.7 2.16 60.1 2.46 66.9 2.82
85 34.1 1.31 40.5 1.61 47.3 1.94 50.5 2.12 53.7 2.32 60.1 2.62 66.9 2.94
90 34.1 1.47 40.5 1.81 47.3 2.20 50.5 2.40 53.7 2.63 60.1 2.92 66.9 3.19
95 34.1 1.55 40.5 1.93 47.3 2.34 50.5 2.56 53.7 2.79 60.1 3.07 66.9 3.29
100 34.1 1.68 40.5 2.08 47.3 2.53 50.5 2.76 53.7 2.87 60.1 3.21 66.9 3.38
105 34.1 1.90 40.5 2.37 47.3 2.79 50.5 2.95 53.7 3.12 60.1 3.39 66.9 3.58
110 34.1 2.14 40.5 2.69 47.3 2.95 50.5 3.13 53.7 3.38 60.1 3.53 64.9 3.85
115 34.1 2.30 40.5 2.87 47.3 3.05 50.5 3.31 53.7 3.48 60.1 3.63 61.2 4.10
118 34.1 2.44 40.5 3.04 47.3 3.24 50.5 3.50 48.8 3.48 50.4 3.08 50.0 3.48
122 34.1 2.64 40.5 3.30 42.2 3.09 40.3 2.88 39.1 2.64 40.5 2.34 40.2 2.64
60%
-9.9 29.3 0.62 34.7 0.72 40.5 0.84 43.1 0.90 46.0 0.97 51.8 1.10 57.2 1.23
-5 29.3 0.65 34.7 0.76 40.5 0.89 43.1 0.95 46.0 1.02 51.8 1.16 57.2 1.30
0 29.3 0.68 34.7 0.79 40.5 0.93 43.1 0.99 46.0 1.06 51.8 1.21 57.2 1.35
5 29.3 0.70 34.7 0.82 40.5 0.96 43.1 1.02 46.0 1.10 51.8 1.25 57.2 1.40
10 29.3 0.72 34.7 0.84 40.5 0.99 43.1 1.05 46.0 1.14 51.8 1.29 57.2 1.44
14 29.3 0.75 34.7 0.87 40.5 1.02 43.1 1.09 46.0 1.18 51.8 1.33 57.2 1.49
20 29.3 0.77 34.7 0.90 40.5 1.06 43.1 1.13 46.0 1.21 51.8 1.38 57.2 1.54
25 29.3 0.79 34.7 0.93 40.5 1.08 43.1 1.16 46.0 1.25 51.8 1.41 57.2 1.58
30 29.3 0.81 34.7 0.95 40.5 1.11 43.1 1.19 46.0 1.28 51.8 1.45 57.2 1.63
35 29.3 0.83 34.7 0.98 40.5 1.14 43.1 1.22 46.0 1.31 51.8 1.49 57.2 1.67
40 29.3 0.85 34.7 1.01 40.5 1.17 43.1 1.26 46.0 1.34 51.8 1.53 57.2 1.71
45 29.3 0.86 34.7 1.01 40.5 1.18 43.1 1.27 46.0 1.36 51.8 1.54 57.2 1.72
50 29.3 0.87 34.7 1.02 40.5 1.19 43.1 1.28 46.0 1.37 51.8 1.55 57.2 1.74
55 29.3 0.88 34.7 1.04 40.5 1.21 43.1 1.30 46.0 1.39 51.8 1.58 57.2 1.77
60 29.3 0.91 34.7 1.08 40.5 1.25 43.1 1.35 46.0 1.44 51.8 1.63 57.2 1.84
65 29.3 0.92 34.7 1.09 40.5 1.28 43.1 1.37 46.0 1.47 51.8 1.67 57.2 1.88
70 29.3 0.95 34.7 1.12 40.5 1.31 43.1 1.41 46.0 1.51 51.8 1.72 57.2 1.95
75 29.3 0.96 34.7 1.14 40.5 1.34 43.1 1.44 46.0 1.56 51.8 1.82 57.2 2.08
80 29.3 1.02 34.7 1.25 40.5 1.50 43.1 1.63 46.0 1.77 51.8 2.04 57.2 2.35
85 29.3 1.09 34.7 1.33 40.5 1.59 43.1 1.74 46.0 1.90 51.8 2.15 57.2 2.42
90 29.3 1.22 34.7 1.50 40.5 1.80 43.1 1.97 46.0 2.13 51.8 2.40 57.2 2.64
95 29.3 1.29 34.7 1.59 40.5 1.91 43.1 2.10 46.0 2.26 51.8 2.51 57.2 2.78
100 29.3 1.39 34.7 1.71 40.5 2.06 43.1 2.26 46.0 2.36 51.8 2.66 57.2 2.90
105 29.3 1.58 34.7 1.94 40.5 2.28 43.1 2.41 46.0 2.56 51.8 2.82 57.2 3.16
110 29.3 1.77 34.7 2.21 40.5 2.46 43.1 2.56 46.0 2.77 51.8 3.02 57.2 3.45
115 29.3 1.90 34.7 2.35 40.5 2.55 43.1 2.70 46.0 2.87 51.8 3.19 57.2 3.69
118 29.3 2.01 34.7 2.50 40.5 2.71 43.1 2.87 46.0 3.05 50.4 3.08 50.0 3.48
122 29.3 2.16 34.7 2.70 40.5 2.94 40.2 2.91 38.9 2.70 40.5 2.34 40.2 2.64

PERFORMANCE DATA | 9
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
50%
-9.9 24.3 0.53 28.9 0.63 33.8 0.70 36.0 0.75 38.3 0.81 43.1 0.90 47.6 1.00
-5 24.3 0.56 28.9 0.66 33.8 0.74 36.0 0.80 38.3 0.86 43.1 0.95 47.6 1.05
0 24.3 0.58 28.9 0.69 33.8 0.77 36.0 0.83 38.3 0.89 43.1 0.99 47.6 1.10
5 24.3 0.60 28.9 0.71 33.8 0.80 36.0 0.86 38.3 0.92 43.1 1.03 47.6 1.14
10 24.3 0.62 28.9 0.73 33.8 0.82 36.0 0.88 38.3 0.95 43.1 1.06 47.6 1.17
14 24.3 0.64 28.9 0.76 33.8 0.85 36.0 0.92 38.3 0.99 43.1 1.09 47.6 1.21
20 24.3 0.67 28.9 0.78 33.8 0.88 36.0 0.95 38.3 1.02 43.1 1.13 47.6 1.26
25 24.3 0.69 28.9 0.80 33.8 0.91 36.0 0.98 38.3 1.04 43.1 1.17 47.6 1.30
30 24.3 0.71 28.9 0.82 33.8 0.94 36.0 1.00 38.3 1.07 43.1 1.20 47.6 1.34
35 24.3 0.73 28.9 0.84 33.8 0.97 36.0 1.03 38.3 1.10 43.1 1.23 47.6 1.37
40 24.3 0.75 28.9 0.87 33.8 0.99 36.0 1.06 38.3 1.13 43.1 1.26 47.6 1.41
45 24.3 0.76 28.9 0.88 33.8 1.01 36.0 1.07 38.3 1.14 43.1 1.28 47.6 1.43
50 24.3 0.77 28.9 0.89 33.8 1.02 36.0 1.09 38.3 1.16 43.1 1.30 47.6 1.45
55 24.3 0.78 28.9 0.91 33.8 1.04 36.0 1.10 38.3 1.18 43.1 1.32 47.6 1.47
60 24.3 0.80 28.9 0.93 33.8 1.07 36.0 1.14 38.3 1.22 43.1 1.36 47.6 1.53
65 24.3 0.81 28.9 0.95 33.8 1.09 36.0 1.16 38.3 1.23 43.1 1.39 47.6 1.55
70 24.3 0.83 28.9 0.96 33.8 1.11 36.0 1.19 38.3 1.27 43.1 1.43 47.6 1.60
75 24.3 0.84 28.9 0.98 33.8 1.14 36.0 1.21 38.3 1.29 43.1 1.45 47.6 1.63
80 24.3 0.87 28.9 1.04 33.8 1.22 36.0 1.32 38.3 1.41 43.1 1.63 47.6 1.85
85 24.3 0.92 28.9 1.09 33.8 1.29 36.0 1.40 38.3 1.50 43.1 1.73 47.6 1.98
90 24.3 1.03 28.9 1.23 33.8 1.45 36.0 1.57 38.3 1.69 43.1 1.95 47.6 2.24
95 24.3 1.09 28.9 1.30 33.8 1.54 36.0 1.67 38.3 1.80 43.1 2.07 47.6 2.38
100 24.3 1.14 28.9 1.37 33.8 1.63 36.0 1.76 38.3 1.90 43.1 2.21 47.6 2.52
105 24.3 1.25 28.9 1.52 33.8 1.80 36.0 1.95 38.3 2.11 43.1 2.44 47.6 2.81
110 24.3 1.38 28.9 1.67 33.8 1.99 36.0 2.16 38.3 2.34 43.1 2.73 47.6 3.14
115 24.3 1.48 28.9 1.80 33.8 2.14 36.0 2.33 38.3 2.52 43.1 2.94 47.6 3.38
118 24.3 1.60 28.9 1.95 33.8 2.33 36.0 2.53 38.3 2.75 43.1 3.08 47.6 3.48
122 24.3 1.76 28.9 2.15 33.8 2.57 36.0 2.81 38.3 2.70 40.5 2.34 40.2 2.64
COOLING CAPACITY DATA
72,000 Btu/h 208-230V / 460V Outdoor Units
ARUM072BTE5 / ARUM072DTE5

10 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
COOLING CAPACITY DATA
96,000 Btu/h 208-230V / 460V Outdoor Units
ARUM096BTE5 / ARUM096DTE5
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
130%
-9.9 87.3 1.71 103.7 2.07 120.5 2.46 125.0 2.65 126.7 2.86 131.1 3.28 134.3 3.39
-5 87.3 1.80 103.7 2.19 120.5 2.59 125.0 2.80 126.7 3.02 131.1 3.46 134.3 3.58
0 87.3 1.87 103.7 2.27 120.5 2.70 125.0 2.91 126.7 3.14 131.1 3.60 134.3 3.72
5 87.3 1.94 103.7 2.36 120.5 2.80 125.0 3.02 126.7 3.26 131.1 3.73 134.3 3.86
10 87.3 2.00 103.7 2.42 120.5 2.88 125.0 3.10 126.7 3.35 131.1 3.84 134.3 3.97
14 87.3 2.07 103.7 2.51 120.5 2.98 125.0 3.22 126.7 3.47 131.1 3.98 134.3 4.11
20 87.3 2.11 103.7 2.55 120.5 3.03 125.0 3.27 126.7 3.52 131.1 4.03 134.3 4.17
25 87.3 2.14 103.7 2.59 120.5 3.06 125.0 3.31 126.7 3.56 131.1 4.08 134.3 4.22
30 87.3 2.16 103.7 2.62 120.5 3.10 125.0 3.35 126.7 3.60 131.1 4.13 134.3 4.27
35 87.3 2.19 103.7 2.65 120.5 3.13 125.0 3.39 126.7 3.64 131.1 4.17 134.3 4.32
40 87.3 2.22 103.7 2.68 120.5 3.17 125.0 3.43 126.7 3.69 131.1 4.22 134.3 4.37
45 87.3 2.24 103.7 2.71 120.5 3.21 125.0 3.46 126.7 3.72 131.1 4.27 134.3 4.42
50 87.3 2.26 103.7 2.74 120.5 3.24 125.0 3.50 126.7 3.76 131.1 4.31 134.3 4.46
55 87.3 2.30 103.7 2.79 120.5 3.30 123.2 3.57 125.0 3.84 129.3 4.39 132.5 4.49
60 87.3 2.37 103.7 2.89 118.8 3.44 120.5 3.71 121.9 3.99 126.2 4.52 129.3 4.54
65 87.3 2.42 103.7 2.95 117.0 3.50 118.8 3.79 120.1 4.06 124.4 4.67 127.6 4.71
70 87.3 2.33 103.7 2.83 114.8 3.49 116.1 3.84 117.9 4.21 122.2 4.68 125.3 4.72
75 87.3 2.39 103.7 3.02 113.0 3.73 114.3 4.12 116.1 4.51 120.4 4.90 123.5 4.93
80 87.3 2.72 103.7 3.44 109.9 4.27 111.2 4.71 113.0 5.18 117.3 5.32 120.4 5.36
85 87.3 2.89 103.7 3.67 108.1 4.56 109.9 5.03 111.2 5.49 115.5 5.54 118.6 5.59
90 87.3 3.28 101.9 4.18 105.0 5.18 106.4 5.73 108.1 5.92 112.3 5.97 115.5 6.03
95 88.2 3.48 101.2 4.44 104.4 5.53 106.1 6.11 107.5 6.13 111.7 6.19 114.9 6.25
100 88.2 3.76 99.4 4.81 102.6 5.99 104.4 6.43 105.7 6.47 110.4 6.53 113.5 6.59
105 88.2 4.24 96.8 5.44 99.9 6.76 101.4 6.92 103.0 6.95 106.5 7.02 108.1 7.08
110 88.2 4.76 92.7 6.13 96.6 7.37 96.9 7.41 98.4 7.43 100.4 7.51 100.8 7.58
115 87.8 5.51 89.4 7.05 89.4 7.77 89.4 7.77 89.4 7.77 90.7 7.79 91.1 7.80
118 76.3 4.67 77.7 5.97 77.8 6.54 77.8 6.59 77.8 6.59 78.9 6.61 78.6 6.62
122 61.0 3.54 62.3 4.54 62.0 4.98 62.2 4.99 62.3 4.99 63.4 5.01 63.3 5.03
120%
-9.9 79.4 1.61 94.8 1.95 110.2 2.31 118.1 2.49 123.3 2.68 128.9 3.08 131.6 3.18
-5 79.4 1.70 94.8 2.06 110.2 2.44 118.1 2.63 123.3 2.83 128.9 3.25 131.6 3.36
0 79.4 1.77 94.8 2.14 110.2 2.53 118.1 2.73 123.3 2.95 128.9 3.38 131.6 3.49
5 79.4 1.83 94.8 2.22 110.2 2.63 118.1 2.83 123.3 3.05 128.9 3.50 131.6 3.62
10 79.4 1.88 94.8 2.28 110.2 2.70 118.1 2.91 123.3 3.14 128.9 3.60 131.6 3.72
14 79.4 1.95 94.8 2.36 110.2 2.80 118.1 3.02 123.3 3.26 128.9 3.73 131.6 3.86
20 79.4 1.98 94.8 2.40 110.2 2.84 118.1 3.07 123.3 3.30 128.9 3.79 131.6 3.91
25 79.4 2.01 94.8 2.43 110.2 2.87 118.1 3.10 123.3 3.34 128.9 3.83 131.6 3.96
30 79.4 2.03 94.8 2.46 110.2 2.91 118.1 3.14 123.3 3.38 128.9 3.87 131.6 4.01
35 79.4 2.06 94.8 2.49 110.2 2.94 118.1 3.18 123.3 3.42 128.9 3.92 131.6 4.06
40 79.4 2.08 94.8 2.52 110.2 2.98 118.1 3.22 123.3 3.46 128.9 3.97 131.6 4.11
45 79.4 2.11 94.8 2.55 110.2 3.01 118.1 3.26 123.3 3.50 128.9 4.01 131.6 4.16
50 79.4 2.13 94.8 2.58 110.2 3.05 118.1 3.29 123.3 3.54 128.9 4.06 131.6 4.20
55 79.4 2.17 94.8 2.62 110.2 3.11 118.1 3.37 122.0 3.61 127.1 4.13 130.3 4.23
60 79.4 2.24 94.8 2.72 110.2 3.24 117.2 3.49 118.5 3.75 124.0 4.26 126.7 4.33
65 79.4 2.28 94.8 2.78 110.2 3.29 115.4 3.57 117.2 3.82 122.2 4.40 125.3 4.44
70 79.4 2.24 94.8 2.72 110.2 3.35 113.2 3.68 114.6 4.04 120.0 4.49 122.7 4.53
75 79.4 2.30 94.8 2.90 110.2 3.58 111.5 3.95 113.2 4.33 118.2 4.70 121.3 4.74
80 79.4 2.61 94.8 3.30 107.1 4.10 108.4 4.52 109.7 4.97 115.1 5.11 117.7 5.15
85 79.4 2.78 94.8 3.53 105.3 4.38 106.7 4.83 108.4 5.27 113.3 5.32 116.4 5.36
90 79.4 3.15 94.8 4.01 102.3 4.97 103.6 5.50 104.9 5.69 110.1 5.73 112.8 5.79
95 80.3 3.34 95.8 4.27 101.6 5.31 102.9 5.87 104.7 5.89 109.5 5.95 112.6 6.00
100 80.3 3.61 95.8 4.61 99.8 5.75 101.6 6.17 102.9 6.21 108.1 6.27 110.8 6.32
105 80.3 4.07 94.3 5.22 97.1 6.49 98.7 6.64 100.0 6.68 105.0 6.73 106.7 6.80
110 80.3 4.57 91.9 5.88 94.9 7.08 95.1 7.11 96.6 7.14 99.6 7.21 99.9 7.28
115 78.1 5.29 88.5 6.77 88.5 7.46 88.5 7.46 88.5 7.46 90.7 7.47 91.1 7.49
118 69.7 4.67 77.0 5.73 77.1 6.27 77.1 6.33 77.1 6.33 79.0 6.34 78.6 6.35
122 55.7 3.54 61.7 4.36 61.4 4.78 61.6 4.79 61.7 4.79 63.4 4.81 63.3 4.83

PERFORMANCE DATA | 11
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
110%
-9.9 73.6 1.48 87.8 1.79 102.0 2.12 109.1 2.30 116.2 2.46 128.0 2.81 130.7 2.91
-5 73.6 1.56 87.8 1.88 102.0 2.23 109.1 2.42 116.2 2.59 128.0 2.96 130.7 3.07
0 73.6 1.63 87.8 1.96 102.0 2.32 109.1 2.52 116.2 2.70 128.0 3.08 130.7 3.19
5 73.6 1.68 87.8 2.03 102.0 2.41 109.1 2.61 116.2 2.80 128.0 3.19 130.7 3.31
10 73.6 1.73 87.8 2.09 102.0 2.48 109.1 2.69 116.2 2.88 128.0 3.28 130.7 3.41
14 73.6 1.80 87.8 2.17 102.0 2.57 109.1 2.78 116.2 2.98 128.0 3.40 130.7 3.53
20 73.6 1.82 87.8 2.20 102.0 2.61 109.1 2.82 116.2 3.03 128.0 3.46 130.7 3.58
25 73.6 1.84 87.8 2.23 102.0 2.64 109.1 2.85 116.2 3.07 128.0 3.51 130.7 3.63
30 73.6 1.87 87.8 2.26 102.0 2.67 109.1 2.89 116.2 3.10 128.0 3.56 130.7 3.68
35 73.6 1.89 87.8 2.29 102.0 2.71 109.1 2.93 116.2 3.15 128.0 3.61 130.7 3.74
40 73.6 1.92 87.8 2.32 102.0 2.75 109.1 2.97 116.2 3.19 128.0 3.66 130.7 3.78
45 73.6 1.95 87.8 2.36 102.0 2.79 109.1 3.02 116.2 3.25 128.0 3.72 130.7 3.85
50 73.6 1.98 87.8 2.40 102.0 2.84 109.1 3.07 116.2 3.30 128.0 3.78 130.7 3.91
55 73.6 2.02 87.8 2.44 102.0 2.89 109.1 3.13 116.2 3.36 126.2 3.85 128.9 3.94
60 73.6 2.08 87.8 2.53 102.0 3.01 109.1 3.25 116.2 3.50 123.1 3.97 125.8 4.00
65 73.6 2.13 87.8 2.59 102.0 3.07 109.1 3.32 116.2 3.56 121.2 4.10 124.0 4.13
70 73.6 2.15 87.8 2.61 102.0 3.21 109.1 3.53 114.0 3.88 119.0 4.31 121.7 4.35
75 73.6 2.20 87.8 2.78 102.0 3.44 109.1 3.79 112.2 4.15 117.2 4.51 119.9 4.54
80 72.9 2.50 86.9 3.17 101.0 3.93 106.7 4.34 108.0 4.77 112.8 4.90 115.5 4.94
85 72.9 2.66 86.9 3.38 101.0 4.20 104.9 4.63 106.2 5.06 111.0 5.10 113.7 5.14
90 72.9 3.02 86.9 3.84 100.5 4.77 101.8 5.27 103.2 5.45 107.9 5.50 110.6 5.55
95 72.9 3.20 86.9 4.09 98.8 5.09 100.1 5.63 101.4 5.65 106.1 5.70 108.8 5.75
100 72.9 3.46 86.9 4.42 97.5 5.52 98.8 5.92 100.1 5.95 104.8 6.01 107.5 6.06
105 72.9 3.90 86.9 5.00 94.4 6.22 95.7 6.37 97.0 6.40 101.7 6.46 104.3 6.52
110 72.9 4.38 86.9 5.64 91.5 6.79 91.8 6.82 93.1 6.84 96.0 6.91 96.4 6.98
115 72.9 5.07 86.9 6.49 87.6 7.15 87.6 7.15 88.0 7.15 89.8 7.17 90.2 7.18
118 70.4 4.62 75.6 5.50 76.3 6.02 76.3 6.07 76.6 6.07 78.2 6.08 77.8 6.09
122 56.3 3.51 60.6 4.18 60.8 4.58 60.9 4.59 61.4 4.60 62.8 4.61 62.6 4.63
100%
-9.9 64.7 1.30 77.1 1.57 89.6 1.86 96.0 2.03 105.5 2.20 118.3 2.53 124.9 2.64
-5 64.7 1.37 77.1 1.66 89.6 1.97 96.0 2.14 105.5 2.32 118.3 2.67 124.9 2.78
0 64.7 1.43 77.1 1.73 89.6 2.04 96.0 2.23 105.5 2.41 118.3 2.78 124.9 2.90
5 64.7 1.48 77.1 1.79 89.6 2.12 96.0 2.31 105.5 2.50 118.3 2.88 124.9 3.00
10 64.7 1.52 77.1 1.84 89.6 2.18 96.0 2.38 105.5 2.57 118.3 2.97 124.9 3.09
14 64.7 1.58 77.1 1.91 89.6 2.26 96.0 2.46 105.5 2.66 118.3 3.07 124.9 3.20
20 64.7 1.63 77.1 1.97 89.6 2.33 96.0 2.53 105.5 2.75 118.3 3.16 124.9 3.29
25 64.7 1.67 77.1 2.02 89.6 2.39 96.0 2.59 105.5 2.82 118.3 3.24 124.9 3.37
30 64.7 1.71 77.1 2.07 89.6 2.45 96.0 2.65 105.5 2.89 118.3 3.31 124.9 3.44
35 64.7 1.74 77.1 2.11 89.6 2.49 96.0 2.69 105.5 2.94 118.3 3.37 124.9 3.50
40 64.7 1.77 77.1 2.14 89.6 2.53 96.0 2.73 105.5 2.98 118.3 3.42 124.9 3.56
45 64.7 1.81 77.1 2.19 89.6 2.58 96.0 2.79 105.5 3.04 118.3 3.49 124.9 3.63
50 64.7 1.84 77.1 2.23 89.6 2.63 96.0 2.85 105.5 3.11 118.3 3.56 124.9 3.70
55 64.7 1.87 77.1 2.27 89.6 2.69 96.0 2.91 105.5 3.17 118.3 3.62 123.6 3.76
60 64.7 1.93 77.1 2.35 89.6 2.80 96.0 3.02 105.5 3.29 117.9 3.74 120.1 3.83
65 64.7 1.97 77.1 2.40 89.6 2.85 96.0 3.08 105.5 3.36 116.1 3.86 118.7 3.94
70 64.7 2.03 77.1 2.47 89.6 3.04 96.0 3.35 105.5 3.73 113.9 4.14 116.1 4.21
75 64.7 2.09 77.1 2.63 89.6 3.25 96.0 3.59 105.5 4.00 112.1 4.34 114.8 4.39
80 64.7 2.37 77.1 3.00 89.6 3.72 96.0 4.11 105.5 4.58 109.0 4.71 111.2 4.77
85 64.7 2.52 77.1 3.20 89.6 3.98 96.0 4.38 105.1 4.86 107.3 4.90 109.9 4.97
90 64.7 2.86 77.1 3.64 89.6 4.52 96.0 4.99 101.5 5.24 104.2 5.29 106.4 5.36
95 64.7 3.03 77.1 3.88 89.6 4.82 96.0 5.33 100.2 5.43 102.4 5.48 105.1 5.56
100 64.7 3.27 77.1 4.18 89.6 5.21 94.3 5.60 98.5 5.71 101.1 5.76 103.3 5.85
105 64.7 3.68 77.1 4.71 89.1 5.86 91.7 6.00 95.5 6.12 98.0 6.17 100.4 6.26
110 64.7 4.11 77.1 5.29 88.1 6.36 90.0 6.40 91.9 6.51 93.3 6.58 95.0 6.67
115 64.7 4.72 77.1 6.04 83.8 6.66 86.4 6.66 88.6 6.76 89.4 6.77 89.8 6.82
118 64.7 4.76 67.7 5.67 73.0 5.60 75.2 5.65 77.1 5.74 77.8 5.75 77.5 5.79
122 55.4 4.31 54.3 4.31 58.2 4.27 60.1 4.28 61.8 4.34 62.5 4.36 62.4 4.40
COOLING CAPACITY DATA
96,000 Btu/h 208-230V / 460V Outdoor Units
ARUM096BTE5 / ARUM096DTE5

12 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
90%
-9.9 58.3 1.16 69.4 1.39 81.0 1.64 86.6 1.77 92.1 1.89 103.3 2.18 114.4 2.39
-5 58.3 1.23 69.4 1.47 81.0 1.74 86.6 1.87 92.1 1.99 103.3 2.30 114.4 2.52
0 58.3 1.28 69.4 1.53 81.0 1.81 86.6 1.94 92.1 2.08 103.3 2.39 114.4 2.62
5 58.3 1.32 69.4 1.58 81.0 1.87 86.6 2.01 92.1 2.15 103.3 2.48 114.4 2.72
10 58.3 1.36 69.4 1.63 81.0 1.93 86.6 2.07 92.1 2.21 103.3 2.55 114.4 2.80
14 58.3 1.41 69.4 1.69 81.0 1.99 86.6 2.15 92.1 2.29 103.3 2.64 114.4 2.90
20 58.3 1.46 69.4 1.75 81.0 2.07 86.6 2.23 92.1 2.39 103.3 2.74 114.4 3.01
25 58.3 1.50 69.4 1.81 81.0 2.13 86.6 2.30 92.1 2.47 103.3 2.81 114.4 3.10
30 58.3 1.55 69.4 1.86 81.0 2.19 86.6 2.37 92.1 2.55 103.3 2.89 114.4 3.19
35 58.3 1.59 69.4 1.92 81.0 2.26 86.6 2.44 92.1 2.62 103.3 2.98 114.4 3.29
40 58.3 1.64 69.4 1.97 81.0 2.33 86.6 2.51 92.1 2.70 103.3 3.07 114.4 3.39
45 58.3 1.68 69.4 2.02 81.0 2.38 86.6 2.57 92.1 2.77 103.3 3.14 114.4 3.47
50 58.3 1.72 69.4 2.06 81.0 2.44 86.6 2.63 92.1 2.83 103.3 3.21 114.4 3.55
55 58.3 1.74 69.4 2.10 81.0 2.48 86.6 2.68 92.1 2.88 103.3 3.27 114.4 3.58
60 58.3 1.80 69.4 2.18 81.0 2.57 86.6 2.78 92.1 3.00 103.3 3.40 113.5 3.62
65 58.3 1.83 69.4 2.22 81.0 2.63 86.6 2.84 92.1 3.05 103.3 3.46 112.7 3.80
70 58.3 1.88 69.4 2.29 81.0 2.72 86.6 3.00 92.1 3.27 103.3 3.86 110.6 4.08
75 58.3 1.92 69.4 2.39 81.0 2.91 86.6 3.21 92.1 3.52 103.3 4.03 108.9 4.26
80 58.3 2.15 69.4 2.71 81.0 3.32 86.6 3.66 92.1 4.01 103.3 4.46 105.9 4.64
85 58.3 2.29 69.4 2.89 81.0 3.56 86.6 3.91 92.1 4.29 102.0 4.69 104.1 4.83
90 58.3 2.58 69.4 3.27 81.0 4.03 86.6 4.45 92.1 4.88 99.0 5.13 101.1 5.21
95 58.3 2.75 69.4 3.47 81.0 4.30 86.6 4.74 92.1 5.21 97.3 5.33 99.4 5.40
100 58.3 2.84 69.4 3.62 81.0 4.48 86.6 4.93 92.1 5.32 96.0 5.56 97.7 5.62
105 58.3 3.29 69.4 4.20 81.0 5.06 86.6 5.40 91.1 5.71 93.0 5.96 94.3 6.03
110 58.3 3.78 69.4 4.84 81.0 5.55 86.6 5.83 87.4 6.19 88.6 6.40 89.3 6.47
115 58.3 4.10 69.4 5.25 75.9 5.85 82.1 6.10 83.2 6.39 84.0 6.53 84.4 6.61
118 58.3 4.35 67.7 5.67 66.0 4.92 71.5 5.18 72.5 5.42 73.2 5.54 72.9 5.61
122 55.4 4.31 54.3 4.31 52.6 3.74 57.1 3.91 58.1 4.10 58.7 4.20 58.6 4.26
80%
-9.9 51.9 1.01 61.7 1.21 72.0 1.41 76.7 1.53 81.9 1.65 91.7 1.88 101.6 2.10
-5 51.9 1.06 61.7 1.28 72.0 1.49 76.7 1.61 81.9 1.74 91.7 1.99 101.6 2.21
0 51.9 1.10 61.7 1.33 72.0 1.55 76.7 1.68 81.9 1.81 91.7 2.07 101.6 2.30
5 51.9 1.14 61.7 1.38 72.0 1.60 76.7 1.74 81.9 1.88 91.7 2.14 101.6 2.39
10 51.9 1.18 61.7 1.42 72.0 1.65 76.7 1.79 81.9 1.93 91.7 2.20 101.6 2.46
14 51.9 1.22 61.7 1.47 72.0 1.71 76.7 1.86 81.9 2.00 91.7 2.28 101.6 2.54
20 51.9 1.27 61.7 1.52 72.0 1.78 76.7 1.92 81.9 2.07 91.7 2.37 101.6 2.64
25 51.9 1.31 61.7 1.57 72.0 1.83 76.7 1.98 81.9 2.13 91.7 2.44 101.6 2.72
30 51.9 1.34 61.7 1.61 72.0 1.89 76.7 2.04 81.9 2.18 91.7 2.50 101.6 2.81
35 51.9 1.38 61.7 1.66 72.0 1.95 76.7 2.09 81.9 2.24 91.7 2.57 101.6 2.88
40 51.9 1.42 61.7 1.70 72.0 2.00 76.7 2.15 81.9 2.30 91.7 2.64 101.6 2.96
45 51.9 1.44 61.7 1.72 72.0 2.03 76.7 2.19 81.9 2.33 91.7 2.68 101.6 3.00
50 51.9 1.46 61.7 1.75 72.0 2.05 76.7 2.21 81.9 2.37 91.7 2.72 101.6 3.04
55 51.9 1.48 61.7 1.78 72.0 2.09 76.7 2.25 81.9 2.41 91.7 2.77 101.6 3.09
60 51.9 1.53 61.7 1.84 72.0 2.16 76.7 2.33 81.9 2.51 91.7 2.86 101.6 3.22
65 51.9 1.55 61.7 1.87 72.0 2.21 76.7 2.38 81.9 2.56 91.7 2.92 101.6 3.29
70 51.9 1.60 61.7 1.92 72.0 2.27 76.7 2.45 81.9 2.67 91.7 3.15 101.6 3.64
75 51.9 1.63 61.7 1.96 72.0 2.38 76.7 2.61 81.9 2.84 91.7 3.35 101.6 3.84
80 51.9 1.78 61.7 2.23 72.0 2.72 76.7 2.97 81.9 3.24 91.7 3.85 101.6 4.29
85 51.9 1.90 61.7 2.37 72.0 2.89 76.7 3.17 81.9 3.47 91.7 4.10 101.6 4.40
90 51.9 2.14 61.7 2.69 72.0 3.27 76.7 3.60 81.9 3.95 91.7 4.51 99.9 4.66
95 51.9 2.27 61.7 2.84 72.0 3.49 76.7 3.82 81.9 4.20 91.7 4.66 97.8 4.79
100 51.9 2.45 61.7 3.06 72.0 3.77 76.7 4.09 81.9 4.36 91.7 4.86 95.6 4.95
105 51.9 2.79 61.7 3.51 72.0 4.19 76.7 4.39 81.9 4.68 90.6 5.05 92.8 5.19
110 51.9 3.17 61.7 4.00 72.0 4.45 76.7 4.69 81.9 5.04 87.4 5.23 87.9 5.46
115 51.9 3.39 61.7 4.27 72.0 4.60 76.7 4.93 76.7 5.16 77.2 5.35 77.2 5.68
118 51.9 3.60 61.7 4.54 66.0 4.92 67.4 4.68 66.8 4.38 67.2 4.54 66.6 4.82
122 51.9 3.89 54.4 4.28 52.6 3.74 53.8 3.54 53.5 3.31 54.0 3.44 53.6 3.66
COOLING CAPACITY DATA
96,000 Btu/h 208-230V / 460V Outdoor Units
ARUM096BTE5 / ARUM096DTE5

PERFORMANCE DATA | 13
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
70%
-9.9 45.4 0.89 54.0 1.06 63.0 1.24 67.3 1.33 71.6 1.42 80.1 1.62 89.1 1.82
-5 45.4 0.94 54.0 1.11 63.0 1.31 67.3 1.40 71.6 1.50 80.1 1.71 89.1 1.92
0 45.4 0.98 54.0 1.16 63.0 1.36 67.3 1.46 71.6 1.56 80.1 1.78 89.1 1.99
5 45.4 1.01 54.0 1.20 63.0 1.41 67.3 1.51 71.6 1.61 80.1 1.85 89.1 2.07
10 45.4 1.04 54.0 1.24 63.0 1.45 67.3 1.56 71.6 1.66 80.1 1.90 89.1 2.13
14 45.4 1.08 54.0 1.28 63.0 1.51 67.3 1.61 71.6 1.72 80.1 1.97 89.1 2.20
20 45.4 1.11 54.0 1.32 63.0 1.55 67.3 1.67 71.6 1.78 80.1 2.03 89.1 2.28
25 45.4 1.15 54.0 1.36 63.0 1.59 67.3 1.71 71.6 1.83 80.1 2.08 89.1 2.34
30 45.4 1.18 54.0 1.39 63.0 1.63 67.3 1.76 71.6 1.88 80.1 2.14 89.1 2.40
35 45.4 1.21 54.0 1.43 63.0 1.68 67.3 1.80 71.6 1.93 80.1 2.19 89.1 2.47
40 45.4 1.24 54.0 1.47 63.0 1.72 67.3 1.85 71.6 1.98 80.1 2.25 89.1 2.53
45 45.4 1.26 54.0 1.49 63.0 1.75 67.3 1.88 71.6 2.01 80.1 2.29 89.1 2.57
50 45.4 1.28 54.0 1.52 63.0 1.78 67.3 1.91 71.6 2.04 80.1 2.32 89.1 2.61
55 45.4 1.30 54.0 1.55 63.0 1.81 67.3 1.94 71.6 2.08 80.1 2.37 89.1 2.67
60 45.4 1.34 54.0 1.60 63.0 1.87 67.3 2.01 71.6 2.15 80.1 2.46 89.1 2.77
65 45.4 1.36 54.0 1.63 63.0 1.90 67.3 2.05 71.6 2.20 80.1 2.50 89.1 2.81
70 45.4 1.40 54.0 1.67 63.0 1.96 67.3 2.11 71.6 2.27 80.1 2.59 89.1 2.99
75 45.4 1.42 54.0 1.70 63.0 2.00 67.3 2.18 71.6 2.37 80.1 2.77 89.1 3.17
80 45.4 1.53 54.0 1.88 63.0 2.27 67.3 2.48 71.6 2.69 80.1 3.06 89.1 3.51
85 45.4 1.63 54.0 2.00 63.0 2.42 67.3 2.64 71.6 2.89 80.1 3.26 89.1 3.66
90 45.4 1.83 54.0 2.26 63.0 2.74 67.3 2.99 71.6 3.27 80.1 3.64 89.1 3.97
95 45.4 1.93 54.0 2.40 63.0 2.92 67.3 3.19 71.6 3.47 80.1 3.82 89.1 4.09
100 45.4 2.09 54.0 2.59 63.0 3.15 67.3 3.44 71.6 3.58 80.1 4.00 89.1 4.21
105 45.4 2.37 54.0 2.95 63.0 3.47 67.3 3.67 71.6 3.89 80.1 4.22 89.1 4.46
110 45.4 2.67 54.0 3.35 63.0 3.67 67.3 3.89 71.6 4.21 80.1 4.39 86.6 4.79
115 45.4 2.86 54.0 3.57 63.0 3.80 67.3 4.12 71.6 4.34 80.1 4.52 81.6 5.10
118 45.4 3.04 54.0 3.79 63.0 4.03 67.3 4.36 65.1 4.34 67.2 3.84 66.6 4.33
122 45.4 3.28 54.0 4.11 56.2 3.85 53.8 3.59 52.2 3.28 54.0 2.91 53.6 3.29
60%
-9.9 39.0 0.77 46.3 0.89 54.0 1.05 57.4 1.12 61.3 1.21 69.0 1.37 76.3 1.53
-5 39.0 0.81 46.3 0.94 54.0 1.11 57.4 1.18 61.3 1.27 69.0 1.44 76.3 1.61
0 39.0 0.85 46.3 0.98 54.0 1.15 57.4 1.23 61.3 1.33 69.0 1.50 76.3 1.68
5 39.0 0.88 46.3 1.02 54.0 1.19 57.4 1.28 61.3 1.37 69.0 1.56 76.3 1.74
10 39.0 0.90 46.3 1.05 54.0 1.23 57.4 1.31 61.3 1.41 69.0 1.60 76.3 1.79
14 39.0 0.93 46.3 1.08 54.0 1.27 57.4 1.36 61.3 1.46 69.0 1.66 76.3 1.85
20 39.0 0.96 46.3 1.12 54.0 1.31 57.4 1.41 61.3 1.51 69.0 1.71 76.3 1.92
25 39.0 0.99 46.3 1.16 54.0 1.35 57.4 1.45 61.3 1.55 69.0 1.76 76.3 1.97
30 39.0 1.01 46.3 1.19 54.0 1.38 57.4 1.49 61.3 1.59 69.0 1.80 76.3 2.03
35 39.0 1.03 46.3 1.22 54.0 1.42 57.4 1.52 61.3 1.63 69.0 1.85 76.3 2.08
40 39.0 1.06 46.3 1.25 54.0 1.46 57.4 1.56 61.3 1.67 69.0 1.90 76.3 2.13
45 39.0 1.07 46.3 1.26 54.0 1.47 57.4 1.58 61.3 1.69 69.0 1.91 76.3 2.15
50 39.0 1.08 46.3 1.27 54.0 1.48 57.4 1.59 61.3 1.70 69.0 1.93 76.3 2.17
55 39.0 1.10 46.3 1.30 54.0 1.51 57.4 1.62 61.3 1.73 69.0 1.97 76.3 2.21
60 39.0 1.13 46.3 1.34 54.0 1.56 57.4 1.68 61.3 1.80 69.0 2.04 76.3 2.29
65 39.0 1.15 46.3 1.36 54.0 1.59 57.4 1.71 61.3 1.83 69.0 2.08 76.3 2.34
70 39.0 1.18 46.3 1.40 54.0 1.64 57.4 1.75 61.3 1.88 69.0 2.14 76.3 2.43
75 39.0 1.20 46.3 1.42 54.0 1.67 57.4 1.79 61.3 1.94 69.0 2.27 76.3 2.59
80 39.0 1.27 46.3 1.55 54.0 1.87 57.4 2.04 61.3 2.21 69.0 2.54 76.3 2.92
85 39.0 1.35 46.3 1.65 54.0 1.98 57.4 2.17 61.3 2.36 69.0 2.67 76.3 3.02
90 39.0 1.52 46.3 1.87 54.0 2.24 57.4 2.45 61.3 2.65 69.0 2.99 76.3 3.29
95 39.0 1.61 46.3 1.98 54.0 2.38 57.4 2.61 61.3 2.81 69.0 3.12 76.3 3.46
100 39.0 1.72 46.3 2.12 54.0 2.57 57.4 2.81 61.3 2.93 69.0 3.31 76.3 3.61
105 39.0 1.96 46.3 2.42 54.0 2.84 57.4 3.00 61.3 3.19 69.0 3.52 76.3 3.94
110 39.0 2.21 46.3 2.75 54.0 3.06 57.4 3.18 61.3 3.45 69.0 3.76 76.3 4.30
115 39.0 2.36 46.3 2.93 54.0 3.18 57.4 3.37 61.3 3.57 69.0 3.98 76.3 4.59
118 39.0 2.50 46.3 3.11 54.0 3.38 57.4 3.58 61.3 3.80 67.2 3.84 66.6 4.33
122 39.0 2.70 46.3 3.36 54.0 3.66 53.6 3.63 51.9 3.36 54.0 2.91 53.6 3.29
COOLING CAPACITY DATA
96,000 Btu/h 208-230V / 460V Outdoor Units
ARUM096BTE5 / ARUM096DTE5

14 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
50%
-9.9 32.4 0.66 38.6 0.78 45.0 0.87 48.0 0.94 51.0 1.01 57.4 1.12 63.4 1.24
-5 32.4 0.70 38.6 0.82 45.0 0.92 48.0 0.99 51.0 1.07 57.4 1.18 63.4 1.31
0 32.4 0.73 38.6 0.86 45.0 0.96 48.0 1.03 51.0 1.11 57.4 1.23 63.4 1.37
5 32.4 0.75 38.6 0.89 45.0 0.99 48.0 1.07 51.0 1.15 57.4 1.28 63.4 1.42
10 32.4 0.78 38.6 0.91 45.0 1.02 48.0 1.10 51.0 1.18 57.4 1.31 63.4 1.46
14 32.4 0.80 38.6 0.95 45.0 1.06 48.0 1.14 51.0 1.23 57.4 1.36 63.4 1.51
20 32.4 0.83 38.6 0.97 45.0 1.10 48.0 1.18 51.0 1.27 57.4 1.41 63.4 1.57
25 32.4 0.86 38.6 1.00 45.0 1.14 48.0 1.22 51.0 1.30 57.4 1.45 63.4 1.61
30 32.4 0.88 38.6 1.02 45.0 1.17 48.0 1.25 51.0 1.33 57.4 1.49 63.4 1.66
35 32.4 0.91 38.6 1.05 45.0 1.20 48.0 1.28 51.0 1.37 57.4 1.54 63.4 1.71
40 32.4 0.93 38.6 1.08 45.0 1.24 48.0 1.31 51.0 1.40 57.4 1.57 63.4 1.75
45 32.4 0.94 38.6 1.09 45.0 1.25 48.0 1.33 51.0 1.42 57.4 1.59 63.4 1.77
50 32.4 0.96 38.6 1.11 45.0 1.27 48.0 1.35 51.0 1.44 57.4 1.62 63.4 1.80
55 32.4 0.98 38.6 1.13 45.0 1.29 48.0 1.37 51.0 1.46 57.4 1.65 63.4 1.83
60 32.4 1.00 38.6 1.16 45.0 1.33 48.0 1.42 51.0 1.52 57.4 1.70 63.4 1.90
65 32.4 1.01 38.6 1.18 45.0 1.35 48.0 1.44 51.0 1.54 57.4 1.73 63.4 1.93
70 32.4 1.04 38.6 1.20 45.0 1.38 48.0 1.49 51.0 1.58 57.4 1.78 63.4 1.99
75 32.4 1.05 38.6 1.22 45.0 1.41 48.0 1.51 51.0 1.61 57.4 1.81 63.4 2.03
80 32.4 1.08 38.6 1.29 45.0 1.52 48.0 1.64 51.0 1.76 57.4 2.02 63.4 2.31
85 32.4 1.15 38.6 1.36 45.0 1.61 48.0 1.74 51.0 1.87 57.4 2.16 63.4 2.46
90 32.4 1.28 38.6 1.53 45.0 1.81 48.0 1.95 51.0 2.11 57.4 2.43 63.4 2.79
95 32.4 1.35 38.6 1.62 45.0 1.91 48.0 2.08 51.0 2.24 57.4 2.58 63.4 2.96
100 32.4 1.42 38.6 1.71 45.0 2.02 48.0 2.20 51.0 2.37 57.4 2.75 63.4 3.14
105 32.4 1.56 38.6 1.89 45.0 2.24 48.0 2.43 51.0 2.62 57.4 3.04 63.4 3.50
110 32.4 1.72 38.6 2.09 45.0 2.48 48.0 2.70 51.0 2.92 57.4 3.40 63.4 3.91
115 32.4 1.84 38.6 2.24 45.0 2.67 48.0 2.90 51.0 3.14 57.4 3.66 63.4 4.21
118 32.4 1.99 38.6 2.43 45.0 2.90 48.0 3.15 51.0 3.42 57.4 3.84 63.4 4.33
122 32.4 2.19 38.6 2.68 45.0 3.20 48.0 3.50 51.0 3.36 54.0 2.91 53.6 3.29
COOLING CAPACITY DATA
96,000 Btu/h 208-230V / 460V Outdoor Units
ARUM096BTE5 / ARUM096DTE5

PERFORMANCE DATA | 15
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
130%
-9.9 109.1 2.47 129.6 3.00 150.7 3.56 156.2 3.84 158.4 4.15 163.9 4.75 167.8 4.91
-5 109.1 2.61 129.6 3.17 150.7 3.76 156.2 4.05 158.4 4.37 163.9 5.01 167.8 5.18
0 109.1 2.71 129.6 3.29 150.7 3.91 156.2 4.22 158.4 4.55 163.9 5.22 167.8 5.39
5 109.1 2.81 129.6 3.41 150.7 4.05 156.2 4.37 158.4 4.72 163.9 5.41 167.8 5.59
10 109.1 2.89 129.6 3.51 150.7 4.17 156.2 4.50 158.4 4.85 163.9 5.56 167.8 5.75
14 109.1 3.00 129.6 3.64 150.7 4.32 156.2 4.66 158.4 5.03 163.9 5.76 167.8 5.95
20 109.1 3.05 129.6 3.70 150.7 4.38 156.2 4.73 158.4 5.10 163.9 5.84 167.8 6.04
25 109.1 3.09 129.6 3.74 150.7 4.43 156.2 4.79 158.4 5.16 163.9 5.91 167.8 6.11
30 109.1 3.14 129.6 3.79 150.7 4.49 156.2 4.85 158.4 5.21 163.9 5.98 167.8 6.18
35 109.1 3.17 129.6 3.84 150.7 4.54 156.2 4.90 158.4 5.28 163.9 6.05 167.8 6.26
40 109.1 3.21 129.6 3.88 150.7 4.59 156.2 4.97 158.4 5.34 163.9 6.12 167.8 6.33
45 109.1 3.24 129.6 3.92 150.7 4.64 156.2 5.02 158.4 5.39 163.9 6.18 167.8 6.40
50 109.1 3.28 129.6 3.96 150.7 4.69 156.2 5.07 158.4 5.45 163.9 6.24 167.8 6.46
55 109.1 3.33 129.6 4.04 150.7 4.78 154.0 5.18 156.2 5.56 161.7 6.35 165.6 6.51
60 109.1 3.44 129.6 4.18 148.5 4.98 150.6 5.38 152.3 5.77 157.8 6.55 161.7 6.58
65 109.1 3.51 129.6 4.27 146.2 5.07 148.5 5.48 150.1 5.88 155.5 6.77 159.4 6.82
70 109.1 3.38 129.6 4.10 143.5 5.05 145.1 5.56 147.3 6.10 152.7 6.77 156.7 6.84
75 109.1 3.46 129.6 4.38 141.3 5.41 142.9 5.96 145.1 6.54 150.5 7.09 154.4 7.15
80 109.1 3.94 129.6 4.98 137.4 6.18 139.0 6.82 141.3 7.50 146.6 7.70 150.5 7.77
85 109.1 4.19 129.6 5.32 135.2 6.61 137.4 7.28 139.0 7.96 144.3 8.02 148.3 8.09
90 109.1 4.75 127.4 6.05 131.3 7.50 132.9 8.29 135.2 8.58 140.4 8.65 144.3 8.73
95 110.3 5.03 126.5 6.44 130.4 8.01 132.7 8.85 134.4 8.89 139.7 8.97 143.6 9.05
100 110.3 5.45 124.3 6.96 128.2 8.68 130.4 9.32 132.1 9.37 138.0 9.45 141.9 9.54
105 110.3 6.14 121.0 7.88 124.8 9.79 126.8 10.02 128.7 10.07 133.2 10.16 135.1 10.26
110 110.3 6.90 115.9 8.88 120.8 10.68 121.2 10.73 122.9 10.77 125.5 10.87 126.0 10.98
115 109.7 7.98 111.7 10.21 111.7 11.26 111.7 11.26 111.7 11.26 113.3 11.28 113.8 11.30
118 95.4 6.76 97.1 8.65 97.3 9.47 97.3 9.55 97.3 9.55 98.7 9.57 98.3 9.59
122 76.2 5.13 77.9 6.58 77.5 7.21 77.7 7.22 77.9 7.23 79.2 7.25 79.1 7.28
120%
-9.9 99.3 2.33 118.5 2.82 137.7 3.34 147.6 3.61 154.2 3.89 161.2 4.46 164.5 4.61
-5 99.3 2.46 118.5 2.98 137.7 3.53 147.6 3.80 154.2 4.10 161.2 4.70 164.5 4.86
0 99.3 2.56 118.5 3.10 137.7 3.67 147.6 3.96 154.2 4.27 161.2 4.89 164.5 5.06
5 99.3 2.65 118.5 3.21 137.7 3.80 147.6 4.10 154.2 4.42 161.2 5.07 164.5 5.24
10 99.3 2.73 118.5 3.31 137.7 3.91 147.6 4.22 154.2 4.55 161.2 5.22 164.5 5.39
14 99.3 2.83 118.5 3.43 137.7 4.06 147.6 4.37 154.2 4.72 161.2 5.41 164.5 5.59
20 99.3 2.87 118.5 3.48 137.7 4.11 147.6 4.44 154.2 4.78 161.2 5.48 164.5 5.67
25 99.3 2.91 118.5 3.52 137.7 4.16 147.6 4.50 154.2 4.84 161.2 5.55 164.5 5.74
30 99.3 2.94 118.5 3.56 137.7 4.21 147.6 4.55 154.2 4.89 161.2 5.61 164.5 5.80
35 99.3 2.98 118.5 3.60 137.7 4.26 147.6 4.61 154.2 4.95 161.2 5.68 164.5 5.88
40 99.3 3.02 118.5 3.65 137.7 4.32 147.6 4.67 154.2 5.02 161.2 5.75 164.5 5.95
45 99.3 3.05 118.5 3.69 137.7 4.37 147.6 4.72 154.2 5.07 161.2 5.81 164.5 6.02
50 99.3 3.09 118.5 3.73 137.7 4.41 147.6 4.77 154.2 5.13 161.2 5.88 164.5 6.08
55 99.3 3.14 118.5 3.80 137.7 4.50 147.6 4.87 152.5 5.23 158.9 5.98 162.8 6.13
60 99.3 3.24 118.5 3.94 137.7 4.69 146.5 5.06 148.1 5.44 155.0 6.17 158.4 6.28
65 99.3 3.31 118.5 4.02 137.7 4.77 144.3 5.16 146.5 5.54 152.8 6.37 156.7 6.43
70 99.3 3.24 118.5 3.94 137.7 4.85 141.5 5.34 143.2 5.85 150.0 6.50 153.3 6.57
75 99.3 3.32 118.5 4.20 137.7 5.19 139.4 5.72 141.5 6.28 147.7 6.81 151.7 6.86
80 99.3 3.78 118.5 4.78 133.9 5.94 135.5 6.55 137.2 7.20 143.8 7.39 147.2 7.46
85 99.3 4.02 118.5 5.11 131.7 6.34 133.3 6.99 135.5 7.64 141.6 7.70 145.5 7.77
90 99.3 4.56 118.5 5.81 127.8 7.20 129.5 7.96 131.1 8.24 137.7 8.30 141.0 8.38
95 100.3 4.83 119.8 6.18 127.0 7.69 128.6 8.50 130.8 8.53 136.8 8.61 140.8 8.69
100 100.3 5.23 119.8 6.68 124.7 8.33 127.0 8.94 128.6 8.99 135.2 9.08 138.5 9.16
105 100.3 5.89 117.8 7.57 121.4 9.40 123.4 9.62 125.0 9.67 131.2 9.75 133.4 9.84
110 100.3 6.62 114.8 8.52 118.6 10.25 118.9 10.30 120.7 10.34 124.4 10.44 124.9 10.54
115 97.6 7.66 110.6 9.80 110.6 10.81 110.6 10.81 110.6 10.81 113.4 10.83 113.9 10.85
118 87.1 6.76 96.2 8.30 96.3 9.09 96.3 9.17 96.3 9.17 98.7 9.19 98.3 9.20
122 69.6 5.13 77.2 6.31 76.8 6.92 77.0 6.93 77.2 6.94 79.3 6.96 79.1 6.99
COOLING CAPACITY DATA
120,000 Btu/h 208-230V / 460V Outdoor Units
ARUM121BTE5 / ARUM121DTE5

16 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
110%
-9.9 92.0 2.14 109.8 2.59 127.5 3.07 136.4 3.32 145.3 3.56 160.0 4.06 163.4 4.22
-5 92.0 2.26 109.8 2.73 127.5 3.24 136.4 3.51 145.3 3.76 160.0 4.29 163.4 4.45
0 92.0 2.35 109.8 2.84 127.5 3.37 136.4 3.65 145.3 3.91 160.0 4.46 163.4 4.63
5 92.0 2.44 109.8 2.94 127.5 3.49 136.4 3.78 145.3 4.05 160.0 4.62 163.4 4.80
10 92.0 2.51 109.8 3.03 127.5 3.59 136.4 3.89 145.3 4.17 160.0 4.76 163.4 4.93
14 92.0 2.60 109.8 3.14 127.5 3.72 136.4 4.03 145.3 4.32 160.0 4.93 163.4 5.11
20 92.0 2.64 109.8 3.19 127.5 3.77 136.4 4.09 145.3 4.39 160.0 5.01 163.4 5.19
25 92.0 2.67 109.8 3.23 127.5 3.82 136.4 4.13 145.3 4.44 160.0 5.08 163.4 5.26
30 92.0 2.70 109.8 3.27 127.5 3.87 136.4 4.18 145.3 4.50 160.0 5.15 163.4 5.32
35 92.0 2.74 109.8 3.32 127.5 3.92 136.4 4.24 145.3 4.56 160.0 5.23 163.4 5.41
40 92.0 2.78 109.8 3.36 127.5 3.98 136.4 4.30 145.3 4.62 160.0 5.30 163.4 5.48
45 92.0 2.83 109.8 3.42 127.5 4.04 136.4 4.37 145.3 4.70 160.0 5.39 163.4 5.57
50 92.0 2.87 109.8 3.48 127.5 4.11 136.4 4.44 145.3 4.78 160.0 5.48 163.4 5.66
55 92.0 2.92 109.8 3.54 127.5 4.19 136.4 4.54 145.3 4.87 157.8 5.57 161.2 5.71
60 92.0 3.02 109.8 3.67 127.5 4.36 136.4 4.71 145.3 5.06 153.8 5.75 157.2 5.80
65 92.0 3.08 109.8 3.75 127.5 4.44 136.4 4.81 145.3 5.16 151.6 5.94 154.9 5.98
70 92.0 3.11 109.8 3.78 127.5 4.65 136.4 5.12 142.5 5.61 148.7 6.24 152.1 6.30
75 92.0 3.19 109.8 4.03 127.5 4.98 136.4 5.49 140.3 6.02 146.5 6.53 149.9 6.58
80 91.1 3.62 108.7 4.59 126.2 5.69 133.3 6.28 135.0 6.90 141.0 7.09 144.4 7.15
85 91.1 3.86 108.7 4.90 126.2 6.08 131.1 6.70 132.8 7.32 138.8 7.39 142.2 7.45
90 91.1 4.37 108.7 5.57 125.7 6.90 127.3 7.63 129.0 7.90 134.9 7.96 138.3 8.04
95 91.1 4.63 108.7 5.92 123.5 7.37 125.1 8.15 126.8 8.18 132.7 8.26 136.0 8.33
100 91.1 5.02 108.7 6.41 121.8 7.99 123.5 8.58 125.1 8.62 131.0 8.70 134.3 8.78
105 91.1 5.65 108.7 7.25 118.0 9.02 119.7 9.23 121.3 9.27 127.1 9.35 130.4 9.44
110 91.1 6.35 108.7 8.17 114.4 9.83 114.7 9.88 116.4 9.91 120.0 10.01 120.5 10.10
115 91.1 7.35 108.7 9.40 109.5 10.36 109.5 10.36 110.0 10.36 112.2 10.38 112.7 10.40
118 88.0 6.69 94.5 7.96 95.3 8.71 95.3 8.79 95.8 8.79 97.7 8.81 97.3 8.82
122 70.3 5.08 75.8 6.05 76.0 6.63 76.2 6.65 76.7 6.66 78.4 6.68 78.3 6.70
100%
-9.9 80.9 1.89 96.4 2.28 112.0 2.70 120.0 2.94 131.9 3.18 147.9 3.67 156.2 3.82
-5 80.9 1.99 96.4 2.40 112.0 2.85 120.0 3.10 131.9 3.36 147.9 3.87 156.2 4.03
0 80.9 2.07 96.4 2.50 112.0 2.96 120.0 3.23 131.9 3.49 147.9 4.03 156.2 4.20
5 80.9 2.15 96.4 2.59 112.0 3.07 120.0 3.34 131.9 3.62 147.9 4.18 156.2 4.35
10 80.9 2.21 96.4 2.66 112.0 3.16 120.0 3.44 131.9 3.72 147.9 4.30 156.2 4.47
14 80.9 2.29 96.4 2.76 112.0 3.27 120.0 3.57 131.9 3.86 147.9 4.45 156.2 4.64
20 80.9 2.36 96.4 2.85 112.0 3.38 120.0 3.67 131.9 3.98 147.9 4.58 156.2 4.77
25 80.9 2.42 96.4 2.93 112.0 3.46 120.0 3.75 131.9 4.08 147.9 4.69 156.2 4.88
30 80.9 2.48 96.4 3.00 112.0 3.55 120.0 3.84 131.9 4.19 147.9 4.80 156.2 4.99
35 80.9 2.52 96.4 3.05 112.0 3.61 120.0 3.90 131.9 4.25 147.9 4.88 156.2 5.07
40 80.9 2.56 96.4 3.10 112.0 3.66 120.0 3.96 131.9 4.32 147.9 4.95 156.2 5.15
45 80.9 2.62 96.4 3.17 112.0 3.74 120.0 4.05 131.9 4.41 147.9 5.06 156.2 5.26
50 80.9 2.67 96.4 3.23 112.0 3.82 120.0 4.13 131.9 4.50 147.9 5.16 156.2 5.36
55 80.9 2.71 96.4 3.29 112.0 3.89 120.0 4.21 131.9 4.59 147.9 5.25 154.5 5.44
60 80.9 2.80 96.4 3.40 112.0 4.05 120.0 4.38 131.9 4.77 147.3 5.41 150.1 5.54
65 80.9 2.86 96.4 3.48 112.0 4.13 120.0 4.46 131.9 4.86 145.1 5.59 148.4 5.70
70 80.9 2.95 96.4 3.58 112.0 4.41 120.0 4.85 131.9 5.40 142.4 6.00 145.1 6.10
75 80.9 3.02 96.4 3.82 112.0 4.71 120.0 5.20 131.9 5.79 140.2 6.28 143.5 6.36
80 80.9 3.43 96.4 4.35 112.0 5.39 120.0 5.95 131.9 6.64 136.3 6.82 139.1 6.91
85 80.9 3.65 96.4 4.64 112.0 5.76 120.0 6.35 131.3 7.04 134.1 7.10 137.4 7.20
90 80.9 4.14 96.4 5.27 112.0 6.54 120.0 7.23 126.9 7.60 130.2 7.66 133.0 7.77
95 80.9 4.39 96.4 5.61 112.0 6.98 120.0 7.72 125.3 7.87 128.0 7.94 131.3 8.05
100 80.9 4.74 96.4 6.06 112.0 7.55 117.9 8.11 123.1 8.27 126.3 8.35 129.2 8.47
105 80.9 5.33 96.4 6.82 111.4 8.49 114.6 8.69 119.4 8.86 122.5 8.94 125.5 9.06
110 80.9 5.95 96.4 7.66 110.1 9.22 112.6 9.26 114.8 9.43 116.7 9.53 118.8 9.66
115 80.9 6.84 96.4 8.75 104.8 9.65 108.0 9.65 110.7 9.79 111.7 9.81 112.2 9.88
118 80.9 6.90 84.6 8.21 91.2 8.11 94.0 8.19 96.4 8.31 97.3 8.33 96.9 8.38
122 69.2 6.25 67.8 6.24 72.7 6.18 75.1 6.19 77.2 6.29 78.1 6.31 78.0 6.37
COOLING CAPACITY DATA
120,000 Btu/h 208-230V / 460V Outdoor Units
ARUM121BTE5 / ARUM121DTE5

PERFORMANCE DATA | 17
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
90%
-9.9 72.9 1.68 86.8 2.02 101.3 2.38 108.2 2.56 115.2 2.74 129.1 3.15 143.0 3.46
-5 72.9 1.78 86.8 2.13 101.3 2.51 108.2 2.70 115.2 2.89 129.1 3.33 143.0 3.65
0 72.9 1.85 86.8 2.21 101.3 2.62 108.2 2.81 115.2 3.01 129.1 3.46 143.0 3.80
5 72.9 1.92 86.8 2.29 101.3 2.71 108.2 2.92 115.2 3.12 129.1 3.59 143.0 3.94
10 72.9 1.97 86.8 2.36 101.3 2.79 108.2 3.00 115.2 3.20 129.1 3.69 143.0 4.05
14 72.9 2.04 86.8 2.45 101.3 2.89 108.2 3.11 115.2 3.32 129.1 3.82 143.0 4.20
20 72.9 2.12 86.8 2.54 101.3 3.00 108.2 3.23 115.2 3.46 129.1 3.96 143.0 4.36
25 72.9 2.18 86.8 2.62 101.3 3.09 108.2 3.33 115.2 3.57 129.1 4.08 143.0 4.49
30 72.9 2.24 86.8 2.69 101.3 3.18 108.2 3.43 115.2 3.69 129.1 4.19 143.0 4.63
35 72.9 2.31 86.8 2.78 101.3 3.27 108.2 3.53 115.2 3.80 129.1 4.32 143.0 4.77
40 72.9 2.38 86.8 2.86 101.3 3.37 108.2 3.64 115.2 3.91 129.1 4.45 143.0 4.91
45 72.9 2.43 86.8 2.93 101.3 3.45 108.2 3.72 115.2 4.01 129.1 4.55 143.0 5.03
50 72.9 2.48 86.8 2.99 101.3 3.53 108.2 3.80 115.2 4.09 129.1 4.65 143.0 5.14
55 72.9 2.52 86.8 3.04 101.3 3.59 108.2 3.88 115.2 4.17 129.1 4.74 143.0 5.18
60 72.9 2.61 86.8 3.16 101.3 3.73 108.2 4.03 115.2 4.34 129.1 4.93 141.8 5.24
65 72.9 2.65 86.8 3.22 101.3 3.80 108.2 4.11 115.2 4.42 129.1 5.02 140.9 5.50
70 72.9 2.73 86.8 3.31 101.3 3.94 108.2 4.34 115.2 4.74 129.1 5.60 138.2 5.91
75 72.9 2.78 86.8 3.47 101.3 4.22 108.2 4.65 115.2 5.09 129.1 5.84 136.1 6.18
80 72.9 3.11 86.8 3.93 101.3 4.82 108.2 5.31 115.2 5.81 129.1 6.45 132.3 6.72
85 72.9 3.31 86.8 4.19 101.3 5.15 108.2 5.66 115.2 6.21 127.5 6.80 130.2 6.99
90 72.9 3.74 86.8 4.74 101.3 5.84 108.2 6.44 115.2 7.07 123.8 7.44 126.4 7.55
95 72.9 3.99 86.8 5.03 101.3 6.23 108.2 6.87 115.2 7.55 121.6 7.72 124.3 7.83
100 72.9 4.12 86.8 5.24 101.3 6.49 108.2 7.14 115.2 7.71 120.0 8.05 122.1 8.14
105 72.9 4.77 86.8 6.08 101.3 7.33 108.2 7.82 113.9 8.27 116.3 8.63 117.8 8.74
110 72.9 5.48 86.8 7.02 101.3 8.05 108.2 8.44 109.3 8.97 110.7 9.27 111.6 9.38
115 72.9 5.93 86.8 7.61 94.8 8.47 102.6 8.83 104.1 9.25 105.0 9.45 105.5 9.58
118 72.9 6.30 84.6 8.21 82.6 7.12 89.3 7.50 90.6 7.85 91.4 8.02 91.1 8.12
122 69.2 6.25 67.8 6.24 65.8 5.42 71.4 5.67 72.6 5.94 73.4 6.08 73.3 6.17
80%
-9.9 64.8 1.46 77.1 1.76 90.0 2.04 95.9 2.22 102.3 2.39 114.6 2.73 127.0 3.04
-5 64.8 1.54 77.1 1.85 90.0 2.15 95.9 2.34 102.3 2.52 114.6 2.88 127.0 3.21
0 64.8 1.60 77.1 1.93 90.0 2.24 95.9 2.43 102.3 2.62 114.6 2.99 127.0 3.33
5 64.8 1.66 77.1 2.00 90.0 2.32 95.9 2.52 102.3 2.72 114.6 3.10 127.0 3.46
10 64.8 1.71 77.1 2.06 90.0 2.39 95.9 2.59 102.3 2.80 114.6 3.19 127.0 3.56
14 64.8 1.77 77.1 2.13 90.0 2.47 95.9 2.69 102.3 2.90 114.6 3.31 127.0 3.68
20 64.8 1.84 77.1 2.21 90.0 2.57 95.9 2.79 102.3 3.00 114.6 3.43 127.0 3.83
25 64.8 1.89 77.1 2.27 90.0 2.66 95.9 2.87 102.3 3.08 114.6 3.53 127.0 3.94
30 64.8 1.95 77.1 2.33 90.0 2.74 95.9 2.96 102.3 3.16 114.6 3.63 127.0 4.06
35 64.8 2.00 77.1 2.40 90.0 2.82 95.9 3.03 102.3 3.25 114.6 3.73 127.0 4.18
40 64.8 2.06 77.1 2.46 90.0 2.89 95.9 3.12 102.3 3.34 114.6 3.83 127.0 4.29
45 64.8 2.08 77.1 2.49 90.0 2.93 95.9 3.17 102.3 3.38 114.6 3.88 127.0 4.35
50 64.8 2.11 77.1 2.53 90.0 2.97 95.9 3.21 102.3 3.43 114.6 3.94 127.0 4.41
55 64.8 2.14 77.1 2.57 90.0 3.02 95.9 3.26 102.3 3.50 114.6 4.01 127.0 4.48
60 64.8 2.22 77.1 2.66 90.0 3.13 95.9 3.38 102.3 3.63 114.6 4.15 127.0 4.66
65 64.8 2.25 77.1 2.71 90.0 3.20 95.9 3.44 102.3 3.71 114.6 4.22 127.0 4.77
70 64.8 2.32 77.1 2.79 90.0 3.29 95.9 3.55 102.3 3.86 114.6 4.56 127.0 5.28
75 64.8 2.36 77.1 2.84 90.0 3.45 95.9 3.78 102.3 4.12 114.6 4.85 127.0 5.56
80 64.8 2.58 77.1 3.23 90.0 3.94 95.9 4.30 102.3 4.70 114.6 5.58 127.0 6.21
85 64.8 2.76 77.1 3.43 90.0 4.19 95.9 4.59 102.3 5.03 114.6 5.94 127.0 6.38
90 64.8 3.10 77.1 3.89 90.0 4.74 95.9 5.21 102.3 5.71 114.6 6.53 124.9 6.76
95 64.8 3.29 77.1 4.12 90.0 5.06 95.9 5.53 102.3 6.08 114.6 6.76 122.2 6.94
100 64.8 3.55 77.1 4.44 90.0 5.46 95.9 5.93 102.3 6.32 114.6 7.03 119.5 7.16
105 64.8 4.05 77.1 5.08 90.0 6.08 95.9 6.36 102.3 6.78 113.3 7.31 116.0 7.52
110 64.8 4.59 77.1 5.79 90.0 6.45 95.9 6.79 102.3 7.30 109.3 7.58 109.8 7.91
115 64.8 4.91 77.1 6.19 90.0 6.66 95.9 7.14 95.9 7.47 96.5 7.75 96.5 8.22
118 64.8 5.21 77.1 6.58 82.6 7.12 84.2 6.78 83.5 6.34 84.0 6.58 83.3 6.98
122 64.8 5.64 68.1 6.20 65.8 5.42 67.3 5.13 66.9 4.80 67.5 4.99 67.0 5.30
COOLING CAPACITY DATA
120,000 Btu/h 208-230V / 460V Outdoor Units
ARUM121BTE5 / ARUM121DTE5

18 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
70%
-9.9 56.8 1.29 67.5 1.53 78.8 1.80 84.1 1.93 89.5 2.05 100.2 2.35 111.4 2.63
-5 56.8 1.36 67.5 1.61 78.8 1.90 84.1 2.03 89.5 2.17 100.2 2.48 111.4 2.78
0 56.8 1.41 67.5 1.68 78.8 1.98 84.1 2.11 89.5 2.25 100.2 2.58 111.4 2.89
5 56.8 1.46 67.5 1.74 78.8 2.05 84.1 2.19 89.5 2.34 100.2 2.68 111.4 2.99
10 56.8 1.51 67.5 1.79 78.8 2.11 84.1 2.26 89.5 2.40 100.2 2.75 111.4 3.08
14 56.8 1.56 67.5 1.86 78.8 2.18 84.1 2.34 89.5 2.49 100.2 2.85 111.4 3.19
20 56.8 1.61 67.5 1.92 78.8 2.25 84.1 2.41 89.5 2.58 100.2 2.94 111.4 3.30
25 56.8 1.66 67.5 1.97 78.8 2.31 84.1 2.48 89.5 2.65 100.2 3.02 111.4 3.39
30 56.8 1.70 67.5 2.02 78.8 2.36 84.1 2.54 89.5 2.72 100.2 3.09 111.4 3.48
35 56.8 1.75 67.5 2.08 78.8 2.43 84.1 2.61 89.5 2.79 100.2 3.17 111.4 3.57
40 56.8 1.80 67.5 2.13 78.8 2.49 84.1 2.68 89.5 2.86 100.2 3.26 111.4 3.66
45 56.8 1.82 67.5 2.16 78.8 2.53 84.1 2.73 89.5 2.91 100.2 3.31 111.4 3.72
50 56.8 1.85 67.5 2.20 78.8 2.57 84.1 2.77 89.5 2.96 100.2 3.37 111.4 3.78
55 56.8 1.89 67.5 2.24 78.8 2.62 84.1 2.81 89.5 3.01 100.2 3.43 111.4 3.86
60 56.8 1.94 67.5 2.32 78.8 2.71 84.1 2.92 89.5 3.12 100.2 3.56 111.4 4.01
65 56.8 1.97 67.5 2.36 78.8 2.76 84.1 2.97 89.5 3.18 100.2 3.62 111.4 4.07
70 56.8 2.03 67.5 2.42 78.8 2.84 84.1 3.06 89.5 3.28 100.2 3.75 111.4 4.33
75 56.8 2.06 67.5 2.47 78.8 2.90 84.1 3.16 89.5 3.43 100.2 4.01 111.4 4.59
80 56.8 2.22 67.5 2.72 78.8 3.29 84.1 3.59 89.5 3.89 100.2 4.43 111.4 5.09
85 56.8 2.36 67.5 2.90 78.8 3.51 84.1 3.83 89.5 4.19 100.2 4.72 111.4 5.30
90 56.8 2.65 67.5 3.27 78.8 3.97 84.1 4.33 89.5 4.74 100.2 5.27 111.4 5.76
95 56.8 2.80 67.5 3.47 78.8 4.22 84.1 4.62 89.5 5.03 100.2 5.54 111.4 5.93
100 56.8 3.02 67.5 3.75 78.8 4.56 84.1 4.99 89.5 5.18 100.2 5.80 111.4 6.10
105 56.8 3.43 67.5 4.28 78.8 5.03 84.1 5.32 89.5 5.63 100.2 6.11 111.4 6.45
110 56.8 3.86 67.5 4.85 78.8 5.32 84.1 5.64 89.5 6.10 100.2 6.36 108.2 6.94
115 56.8 4.15 67.5 5.17 78.8 5.50 84.1 5.96 89.5 6.28 100.2 6.55 102.0 7.39
118 56.8 4.41 67.5 5.49 78.8 5.84 84.1 6.32 81.4 6.28 84.0 5.56 83.3 6.27
122 56.8 4.75 67.5 5.95 70.3 5.58 67.2 5.19 65.2 4.75 67.5 4.22 67.0 4.76
60%
-9.9 48.8 1.12 57.9 1.30 67.5 1.52 71.8 1.62 76.6 1.75 86.3 1.98 95.4 2.21
-5 48.8 1.18 57.9 1.37 67.5 1.60 71.8 1.71 76.6 1.85 86.3 2.09 95.4 2.34
0 48.8 1.22 57.9 1.42 67.5 1.67 71.8 1.78 76.6 1.92 86.3 2.17 95.4 2.43
5 48.8 1.27 57.9 1.47 67.5 1.73 71.8 1.85 76.6 1.99 86.3 2.25 95.4 2.52
10 48.8 1.31 57.9 1.52 67.5 1.78 71.8 1.90 76.6 2.05 86.3 2.32 95.4 2.59
14 48.8 1.35 57.9 1.57 67.5 1.84 71.8 1.97 76.6 2.12 86.3 2.40 95.4 2.69
20 48.8 1.39 57.9 1.63 67.5 1.90 71.8 2.04 76.6 2.19 86.3 2.48 95.4 2.78
25 48.8 1.43 57.9 1.68 67.5 1.95 71.8 2.10 76.6 2.25 86.3 2.55 95.4 2.86
30 48.8 1.46 57.9 1.72 67.5 2.00 71.8 2.15 76.6 2.30 86.3 2.61 95.4 2.93
35 48.8 1.50 57.9 1.77 67.5 2.05 71.8 2.21 76.6 2.36 86.3 2.68 95.4 3.01
40 48.8 1.54 57.9 1.81 67.5 2.11 71.8 2.27 76.6 2.42 86.3 2.75 95.4 3.09
45 48.8 1.55 57.9 1.83 67.5 2.12 71.8 2.29 76.6 2.45 86.3 2.77 95.4 3.11
50 48.8 1.57 57.9 1.84 67.5 2.14 71.8 2.31 76.6 2.47 86.3 2.80 95.4 3.14
55 48.8 1.59 57.9 1.88 67.5 2.19 71.8 2.35 76.6 2.51 86.3 2.85 95.4 3.20
60 48.8 1.64 57.9 1.94 67.5 2.26 71.8 2.43 76.6 2.61 86.3 2.95 95.4 3.32
65 48.8 1.66 57.9 1.97 67.5 2.31 71.8 2.48 76.6 2.65 86.3 3.01 95.4 3.39
70 48.8 1.70 57.9 2.03 67.5 2.37 71.8 2.54 76.6 2.72 86.3 3.10 95.4 3.52
75 48.8 1.74 57.9 2.06 67.5 2.41 71.8 2.59 76.6 2.81 86.3 3.28 95.4 3.75
80 48.8 1.84 57.9 2.25 67.5 2.70 71.8 2.95 76.6 3.20 86.3 3.68 95.4 4.23
85 48.8 1.96 57.9 2.39 67.5 2.87 71.8 3.14 76.6 3.42 86.3 3.87 95.4 4.37
90 48.8 2.20 57.9 2.70 67.5 3.25 71.8 3.55 76.6 3.84 86.3 4.33 95.4 4.76
95 48.8 2.33 57.9 2.86 67.5 3.45 71.8 3.78 76.6 4.07 86.3 4.52 95.4 5.02
100 48.8 2.50 57.9 3.08 67.5 3.72 71.8 4.07 76.6 4.25 86.3 4.80 95.4 5.23
105 48.8 2.84 57.9 3.50 67.5 4.11 71.8 4.35 76.6 4.62 86.3 5.10 95.4 5.71
110 48.8 3.20 57.9 3.98 67.5 4.43 71.8 4.61 76.6 5.00 86.3 5.45 95.4 6.22
115 48.8 3.42 57.9 4.25 67.5 4.60 71.8 4.88 76.6 5.17 86.3 5.76 95.4 6.65
118 48.8 3.62 57.9 4.50 67.5 4.89 71.8 5.18 76.6 5.51 84.0 5.56 83.3 6.27
122 48.8 3.90 57.9 4.87 67.5 5.30 67.0 5.26 64.9 4.87 67.5 4.22 67.0 4.76
COOLING CAPACITY DATA
120,000 Btu/h 208-230V / 460V Outdoor Units
ARUM121BTE5 / ARUM121DTE5

PERFORMANCE DATA | 19
Performance Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
50%
-9.9 40.5 0.96 48.2 1.13 56.3 1.26 60.0 1.36 63.8 1.47 71.8 1.63 79.3 1.80
-5 40.5 1.01 48.2 1.19 56.3 1.33 60.0 1.44 63.8 1.55 71.8 1.72 79.3 1.90
0 40.5 1.05 48.2 1.24 56.3 1.39 60.0 1.49 63.8 1.61 71.8 1.78 79.3 1.98
5 40.5 1.09 48.2 1.28 56.3 1.44 60.0 1.55 63.8 1.67 71.8 1.85 79.3 2.05
10 40.5 1.12 48.2 1.32 56.3 1.48 60.0 1.59 63.8 1.71 71.8 1.90 79.3 2.11
14 40.5 1.16 48.2 1.37 56.3 1.53 60.0 1.65 63.8 1.78 71.8 1.97 79.3 2.19
20 40.5 1.21 48.2 1.41 56.3 1.60 60.0 1.71 63.8 1.84 71.8 2.04 79.3 2.27
25 40.5 1.24 48.2 1.45 56.3 1.65 60.0 1.76 63.8 1.88 71.8 2.10 79.3 2.34
30 40.5 1.28 48.2 1.48 56.3 1.70 60.0 1.81 63.8 1.93 71.8 2.16 79.3 2.41
35 40.5 1.31 48.2 1.52 56.3 1.74 60.0 1.86 63.8 1.98 71.8 2.22 79.3 2.47
40 40.5 1.35 48.2 1.56 56.3 1.79 60.0 1.90 63.8 2.03 71.8 2.28 79.3 2.53
45 40.5 1.37 48.2 1.58 56.3 1.81 60.0 1.93 63.8 2.06 71.8 2.31 79.3 2.57
50 40.5 1.38 48.2 1.61 56.3 1.84 60.0 1.96 63.8 2.09 71.8 2.34 79.3 2.61
55 40.5 1.41 48.2 1.64 56.3 1.87 60.0 1.99 63.8 2.12 71.8 2.39 79.3 2.65
60 40.5 1.44 48.2 1.68 56.3 1.93 60.0 2.06 63.8 2.20 71.8 2.46 79.3 2.76
65 40.5 1.46 48.2 1.71 56.3 1.96 60.0 2.09 63.8 2.22 71.8 2.50 79.3 2.80
70 40.5 1.50 48.2 1.74 56.3 2.00 60.0 2.15 63.8 2.28 71.8 2.58 79.3 2.89
75 40.5 1.52 48.2 1.77 56.3 2.05 60.0 2.18 63.8 2.33 71.8 2.62 79.3 2.95
80 40.5 1.56 48.2 1.87 56.3 2.20 60.0 2.37 63.8 2.55 71.8 2.93 79.3 3.34
85 40.5 1.66 48.2 1.97 56.3 2.33 60.0 2.52 63.8 2.71 71.8 3.12 79.3 3.57
90 40.5 1.86 48.2 2.21 56.3 2.62 60.0 2.83 63.8 3.05 71.8 3.52 79.3 4.04
95 40.5 1.96 48.2 2.34 56.3 2.77 60.0 3.01 63.8 3.24 71.8 3.74 79.3 4.29
100 40.5 2.06 48.2 2.48 56.3 2.93 60.0 3.18 63.8 3.43 71.8 3.98 79.3 4.55
105 40.5 2.25 48.2 2.73 56.3 3.24 60.0 3.51 63.8 3.80 71.8 4.41 79.3 5.06
110 40.5 2.49 48.2 3.02 56.3 3.59 60.0 3.90 63.8 4.23 71.8 4.92 79.3 5.66
115 40.5 2.67 48.2 3.24 56.3 3.86 60.0 4.20 63.8 4.55 71.8 5.30 79.3 6.10
118 40.5 2.88 48.2 3.52 56.3 4.20 60.0 4.57 63.8 4.96 71.8 5.56 79.3 6.27
122 40.5 3.18 48.2 3.89 56.3 4.64 60.0 5.07 63.8 4.87 67.5 4.22 67.0 4.76
COOLING CAPACITY DATA
120,000 Btu/h 208-230V / 460V Outdoor Units
ARUM121BTE5 / ARUM121DTE5

20 | PERFORMANCE DATA
MULTI V 5 Outdoor Unit Performance Data Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
© /*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
TC = Total Capacity (MBh). PI = Power Input (kW) (includes compressor and outdoor fan).
Cooling range with the LowAmbient Baffle Kit (sold separately) is -9.9°F to +122°F and is achieved
only when all indoor units are operating in cooling mode. Does not impact heat recovery system
synchronous operating range.
The System Combination Ratio must be between 50–130%.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Combination
(%) Outdoor
air temp.
(°F DB)
IndoorAir Temp. °F DB/°F WB
68/57 73/61 79/64 80/67 85/70 88/73 91/76
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW MBh kW
130%
-9.9 130.9 2.98 155.5 3.61 180.8 4.29 187.4 4.63 190.1 4.99 196.7 5.72 201.4 5.91
-5 130.9 3.14 155.5 3.81 180.8 4.53 187.4 4.88 190.1 5.27 196.7 6.04 201.4 6.24
0 130.9 3.27 155.5 3.97 180.8 4.71 187.4 5.08 190.1 5.48 196.7 6.28 201.4 6.49
5 130.9 3.39 155.5 4.11 180.8 4.88 187.4 5.27 190.1 5.68 196.7 6.51 201.4 6.73
10 130.9 3.49 155.5 4.23 180.8 5.02 187.4 5.42 190.1 5.84 196.7 6.70 201.4 6.92
14 130.9 3.61 155.5 4.38 180.8 5.20 187.4 5.61 190.1 6.06 196.7 6.94 201.4 7.17
20 130.9 3.67 155.5 4.45 180.8 5.28 187.4 5.70 190.1 6.14 196.7 7.04 201.4 7.28
25 130.9 3.73 155.5 4.51 180.8 5.34 187.4 5.77 190.1 6.21 196.7 7.12 201.4 7.36
30 130.9 3.78 155.5 4.57 180.8 5.40 187.4 5.84 190.1 6.28 196.7 7.20 201.4 7.45
35 130.9 3.82 155.5 4.63 180.8 5.47 187.4 5.91 190.1 6.36 196.7 7.28 201.4 7.54
40 130.9 3.87 155.5 4.68 180.8 5.53 187.4 5.98 190.1 6.43 196.7 7.37 201.4 7.63
45 130.9 3.91 155.5 4.73 180.8 5.60 187.4 6.04 190.1 6.49 196.7 7.45 201.4 7.70
50 130.9 3.95 155.5 4.77 180.8 5.65 187.4 6.10 190.1 6.56 196.7 7.52 201.4 7.78
55 130.9 4.01 155.5 4.86 180.8 5.76 184.8 6.24 187.4 6.69 194.0 7.65 198.7 7.84
60 130.9 4.14 155.5 5.04 178.1 6.00 180.7 6.48 182.8 6.96 189.3 7.89 194.0 7.93
65 130.9 4.23 155.5 5.15 175.5 6.10 178.1 6.61 180.1 7.09 186.6 8.15 191.3 8.22
70 130.9 4.07 155.5 4.95 172.2 6.08 174.2 6.70 176.8 7.35 183.3 8.16 188.0 8.24
75 130.9 4.17 155.5 5.27 169.5 6.51 171.5 7.18 174.2 7.88 180.6 8.55 185.3 8.61
80 130.9 4.74 155.5 6.00 164.8 7.45 166.8 8.22 169.5 9.04 175.9 9.28 180.6 9.36
85 130.9 5.05 155.5 6.41 162.2 7.96 164.8 8.77 166.8 9.58 173.2 9.67 177.9 9.75
90 130.9 5.72 152.9 7.29 157.5 9.04 159.5 9.99 162.2 10.34 168.5 10.42 173.2 10.52
95 132.3 6.06 151.8 7.75 156.5 9.65 159.2 10.66 161.2 10.70 167.6 10.81 172.3 10.91
100 132.3 6.56 149.1 8.39 153.8 10.46 156.5 11.22 158.5 11.28 165.6 11.39 170.3 11.49
105 132.3 7.40 145.1 9.49 149.8 11.79 152.1 12.07 154.4 12.13 159.8 12.24 162.1 12.36
110 132.3 8.31 139.1 10.69 144.9 12.86 145.4 12.93 147.5 12.97 150.6 13.10 151.2 13.22
115 131.7 9.61 134.1 12.30 134.1 13.56 134.1 13.56 134.1 13.56 136.0 13.59 136.6 13.61
118 114.5 8.15 116.6 10.42 116.7 11.40 116.7 11.51 116.7 11.51 118.4 11.53 117.9 11.55
122 91.5 6.18 93.5 7.92 93.0 8.68 93.3 8.70 93.5 8.71 95.1 8.74 94.9 8.77
120%
-9.9 119.2 2.81 142.2 3.40 165.2 4.03 177.1 4.34 185.0 4.68 193.4 5.37 197.4 5.55
-5 119.2 2.96 142.2 3.59 165.2 4.25 177.1 4.58 185.0 4.94 193.4 5.67 197.4 5.86
0 119.2 3.08 142.2 3.73 165.2 4.42 177.1 4.77 185.0 5.14 193.4 5.89 197.4 6.09
5 119.2 3.19 142.2 3.87 165.2 4.58 177.1 4.94 185.0 5.33 193.4 6.11 197.4 6.31
10 119.2 3.28 142.2 3.98 165.2 4.71 177.1 5.08 185.0 5.48 193.4 6.28 197.4 6.50
14 119.2 3.40 142.2 4.13 165.2 4.89 177.1 5.27 185.0 5.68 193.4 6.51 197.4 6.73
20 119.2 3.46 142.2 4.19 165.2 4.96 177.1 5.35 185.0 5.76 193.4 6.60 197.4 6.83
25 119.2 3.50 142.2 4.24 165.2 5.01 177.1 5.42 185.0 5.83 193.4 6.68 197.4 6.91
30 119.2 3.55 142.2 4.29 165.2 5.07 177.1 5.48 185.0 5.90 193.4 6.76 197.4 6.99
35 119.2 3.59 142.2 4.34 165.2 5.13 177.1 5.56 185.0 5.97 193.4 6.84 197.4 7.08
40 119.2 3.63 142.2 4.40 165.2 5.20 177.1 5.62 185.0 6.04 193.4 6.93 197.4 7.17
45 119.2 3.68 142.2 4.44 165.2 5.26 177.1 5.69 185.0 6.11 193.4 7.00 197.4 7.25
50 119.2 3.72 142.2 4.50 165.2 5.32 177.1 5.75 185.0 6.18 193.4 7.08 197.4 7.33
55 119.2 3.78 142.2 4.58 165.2 5.42 177.1 5.87 183.0 6.30 190.7 7.21 195.4 7.38
60 119.2 3.90 142.2 4.74 165.2 5.65 175.8 6.10 177.8 6.55 186.0 7.43 190.0 7.56
65 119.2 3.98 142.2 4.85 165.2 5.75 173.1 6.22 175.8 6.67 183.3 7.68 188.0 7.74
70 119.2 3.91 142.2 4.75 165.2 5.84 169.9 6.43 171.8 7.05 180.0 7.83 184.0 7.91
75 119.2 4.00 142.2 5.06 165.2 6.25 167.2 6.90 169.9 7.56 177.3 8.21 182.0 8.26
80 119.2 4.55 142.2 5.76 160.6 7.15 162.6 7.89 164.6 8.67 172.6 8.91 176.6 8.99
85 119.2 4.84 142.2 6.15 158.0 7.64 160.0 8.42 162.6 9.20 169.9 9.28 174.6 9.36
90 119.2 5.49 142.2 6.99 153.4 8.67 155.4 9.59 157.3 9.92 165.2 10.00 169.2 10.10
95 120.4 5.82 143.7 7.44 152.3 9.26 154.3 10.24 157.0 10.28 164.2 10.37 169.0 10.47
100 120.4 6.30 143.7 8.05 149.7 10.04 152.3 10.77 154.3 10.83 162.2 10.93 166.3 11.03
105 120.4 7.10 141.4 9.11 145.7 11.33 148.1 11.58 150.0 11.65 157.5 11.75 160.1 11.86
110 120.4 7.98 137.8 10.27 142.3 12.35 142.7 12.41 144.8 12.45 149.3 12.57 149.9 12.69
115 117.1 9.23 132.8 11.81 132.8 13.02 132.8 13.02 132.8 13.02 136.0 13.04 136.6 13.07
118 104.5 8.15 115.4 10.00 115.6 10.95 115.6 11.05 115.6 11.05 118.4 11.07 117.9 11.09
122 83.5 6.18 92.6 7.61 92.1 8.33 92.4 8.35 92.6 8.36 95.1 8.39 94.9 8.42
COOLING CAPACITY DATA
144,000 Btu/h 208-230V / 460V Outdoor Units
ARUM144BTE5 / ARUM144DTE5
