LG Multi V ARNU073B3G2 User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
(Company) (ProjectManager)
Tag#:
ARNU073B3G2
MultiV™DuctedLowStaticBottomReturn
Btu/hIndoorUnit
Performance:
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB
Outdoor
:
95°FDB
Indoor: 70°FDB
Outdoor
:
47°FDB/43°FWB
HeatingCapacity(Btu/h)8,500
Electrical:
PowerSupply(V/Hz/Ø) 208‐230/60/1
RatedAmps(A)0.1
Pi
p
in
g
:
Refrigerant:
LiquidLine(in,OD) 1/4Flare
VaporLine(in,OD) 1/2Flare
Condensate:
StandardFeatures:
•LimitedWarrantywithLGCerfiedInstallaon
•TwoYearFunctionalPartsWarranty
ControlsFeatures:
•Autochangeover
(HeatRecoveryonly)
•Autooperaon
•Autorestart
•Childlock
•Dualthermistorcontrol
•Groupcontrol
•E.S.P.control
•Hotstart
•Selfdiagnoscs
•Sleepmode
•Timer(on/off)
•Weeklyschedule
•Sodry(dehumidificaon)
•Fanspeedcontrol
UnitData:
RefrigerantType R410
RefrigerantControl EEV
NetUnitWeight(lbs) 38
ShippingWeight(lbs) 43
Fan:
Type Sirocco
Quantity 1
Motor/Drive BrushlessDigitallyControlled/Direct
Notes:
PowerInput¹(W) 30
CondensateLine(in,OD) 1AirflowRateH/M/L(CFM) 283/229/194
EnteringMixedAir:
HeatingMin(°FDB) 59
TotalCoolingCapacity(Btu/h) 7,500
FactoryInstalledPump² Yes
CoolingMax⁴(°FWB) 76
SoundPressure⁵dB(A)(H/M/L) 33/32/29
Filter WashablePre‐filter
1.ThePowerInputisratedathighspeed.
2.Maximumliis27infromboomofunit.
3.Requiresa7‐Dayprogrammablecontroller.
4.SeeEngineeringManualforsensibleandlatentcapacies.
5.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
6.Factorysetasstandard.
7.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedand
mustcomplywithapplicablelocalandnationalcode.
8.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
9.Thisunitcomeswithadrynitrogencharge.
10.Thisdataisrated0abovesealevel,with25ofrefrigerantlineperindoorunitanda
0ftleveldifferencebetweenoutdoorandindoorunits.Allcapacitiesarenetwitha
combinationratiobetween95–105%.
11.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
7,500
ReturnAirGrille‐PBSGB30
ReturnAirCanvas‐PBSC30
Shownwithoptionalaccessories–PBSGB30&PBSC30
ExternalStaticPressure⁶(inwg) 0.08
Page1of2VRF‐SB‐DH‐001‐US012B07
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice.
LGElectronicsU.S.A.,Inc.,EnglewoodCliffs,NJ.Allrightsreserved.“LGLife’sGood”isaregisteredtrademarkofLGCorp./www.lg‐vrf.com
O
p
tionalAccessories:
WirelessHandheldRemoteController‐PQWRHDF0
7‐DayProgrammableController(Black)‐PQRCVSL0
SimpleControllerwithMode(Black)‐PQRCVCL0Q
SimpleControllerwithoutMode(Black)PQRCHCA0Q
DryContactUnit‐PQDSB1
WallMountedTemperatureSensor‐PQRSTA0
7‐DayProgrammableController(White)‐PQRCVSL0QW
SimpleControllerwithMode(White)‐PQRCVCL0QW
SimpleControllerwithoutMode(White)‐PQRCHCA0QW
DryContactUnit‐PQDSBC

ARNU073B3G2
MultiV™DuctedLowStaticBottomReturn
Btu/hIndoorUnit
JobName/Location:
Tag#:
Date:
PONo.:
35-1/2"
7-1/2"
23-3/8"
1/2"
6-7/16"
1/2"
31-5/16"
7"
11/16"
3/4"
28-9/16" 4-11/16"
1-9/16"
2-3/4"
5-15/16"
10-7/8" 9-7/16"
8-1/2"
3-11/16"
15"
15/16"
33-7/16"
1-9/16"
W
H D
L1 L2 L3 L4 L5 L6 L7 L8 L9
L10 L11 L12 L13 L14 L15
M1 M2 M3 M4 M5
7/8"
2-9/16"
4-15/16"
5-1/16" 1-7/16"
L16 L17 L18 L19 L20
Note‐Alldimensionshavea
toleranceof±0.25in.
7,500
Page2of2VRF‐SB‐DH‐001‐US012B07
