IMPORTANT SAFETY PRECAUTIONS
1
IMPORTANT SAFETY PRECAUTIONS
Read these instructions. Breaking the rules may be dangerous or illegal.
Further detailed information is given in this user guide.
WWAARRNNIINNGG!!VViioollaattiioonnoofftthheeiinnssttrruuccttiioonnssmmaayyccaauusseesseerriioouussiinnjjuurryyoorrddeeaatthh..
1. Never use an unapproved battery since this could damage the phone and/or battery and could
cause the battery to explode.
2. Never place your phone in a microwave oven as it will cause the battery to explode.
3. Never store your phone in temperatures less than -4°F or greater than 122°F.
4. Do not dispose of your battery by fire or with hazardous or flammable materials.
5. When riding in a car, do not leave your phone or set up the hands-free kit near an air bag. If
wireless equipment is improperly installed and the air bag is deployed, you may be seriously
injured.
6. Do not use a hand-held phone while driving.
7. Do not use the phone in areas where its use is prohibited. (For example: aircraft)
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 1

IMPORTANT SAFETY PRECAUTIONS
2
IMPORTANT SAFETY PRECAUTIONS
1. Do not expose the battery charger or adapter to direct sunlight or use it in places with high
humidity, such as a bathroom.
2. Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean
your phone. This could cause a fire.
3. Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the
phone.
4. Do not use your phone in high explosive areas as the phone may generate sparks.
5. Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if
it is loose as it may cause a fire or electric shock.
6. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as
it may cause electric shock or fire.
7. Do not handle the phone with wet hands while it is being charged. It may cause an electric
shock or seriously damage your phone.
8. Do not disassemble the phone.
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 2

3
IMPORTANT SAFETY PRECAUTIONS
1. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or
cause electric shock or fire.
2. Do not hold or let the antenna come in contact with your body during a call.
3. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the
battery. This could cause a fire.
4. Give instructions for children to use the battery carefully.
5. Be careful that children do not swallow any parts (such as rubber plugs, earphone, connection
parts of the phone, etc.) This could cause asphyxiation or suffocation resulting in serious injury
or death.
6. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.
7. Only use the batteries and chargers provided by LG. The warranty will not be applied to
products provided by other suppliers.
8. Only authorized personnel should service the phone and its accessories. Faulty installation or
service may result in accidents and consequently invalidate the warranty.
9. An emergency call can be made only within a service area. For an emergency call, make sure that
you are within a service area and that the phone is turned on.
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 3

TABLE OF CONTENTS
TABLE OF CONTENTS
4
Important Safety Precautions
1
Table of Contents 4
Welcome 9
Technical Details 10
FCC RF Exposure Information 12
Phone Overview 13
Menus Overview 14
Getting Started with Your
Phone 16
The Battery 16
Installing the Battery 16
Removing the Battery 16
Charging the Battery 16
Battery Charge Level 17
Turning the Phone On and Off 17
Turning the Phone On 17
Turning the Phone Off 17
Signal Strength 18
Screen Icons 18
Making Calls 18
Correcting Dialing Mistakes 19
Redialing Calls 19
Receiving Calls 19
Quick Access to Convenient
Features 20
Vibrate Only mode 20
Lock Mode 20
Mute Function 20
Volume Quick Adjustment 20
Call Waiting 21
Caller ID 21
Speed Dialing 21
Entering and Editing
Information 22
Text Input 22
Key Functions 22
Symbols Mode 23
Changing Letter Case 23
Contacts in Your Phone’s
Memory 24
The Basics of Storing Contacts Entries
24
Options to Customize Your Contacts 24
Adding or Changing the Group 24
Changing the Call Ringer 25
Adding or Changing the Memo 25
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 4

5
TABLE OF CONTENTS
Adding or Changing the Picture ID 25
Adding Speed Dial 26
Editing Contacts Entries 26
Adding Another Phone Number 26
Default Numbers 27
Changing the Default Number 27
Editing Stored Phone Numbers 27
Editing Stored Names 27
Editing Customized Options 28
Deleting 28
Deleting a Contact Entry or a Phone
Number from a Contact 28
Phone Numbers With Pauses 29
Storing a Number with Pauses 29
Adding a Pause to an Existing Number
30
Searching Your Phone’s Memory 30
Scrolling Through Your Contacts 30
Making a Call From Your Phone’s
Memory 32
Messaging 33
1. New Text Message 34
2. New Picture Message 36
3. Inbox 37
4. Sent 38
5. Drafts 39
6. Voicemail 40
7. Settings 40
7.1 Auto Save 40
7.2 Auto Delete 40
7.3 Text-Auto View 40
7.4 Picture-Auto Receive 41
7.5 Text-Callback # 41
7.6 Edit Voicemail # 41
7.7 Entry Mode 41
7.8 Quick-Text 41
7.9 Text-Auto Play 41
7.0 Text Signature 41
7.* Speed Messaging 41
8. Delete All 42
Axcess Apps 43
1. Axcess Apps 44
2. Axcess Info 44
Axcess Web 45
1. Start Browser 45
2. Web Message 47
3. Web Settings 47
Multimedia 48
1. Take Picture 48
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 5

TABLE OF CONTENTS
TABLE OF CONTENTS
6
2. Record Video 50
3. Record Voice 50
Contacts 51
1. New Contact 51
2. Contact List 52
3. Groups 52
4. Speed Dials 53
5. My Name Card 53
Recent Calls 54
1. Missed 54
2. Received 54
3. Dialed 55
4. Data 55
5. All Calls 55
6. Call Timer 55
7. Data Counter 55
My Media 56
1. Image 56
2. Video 56
3. Audio 56
4. Shuffle 57
5. Music 57
Celltop 58
1. Start Celltop 59
Settings 59
1. Tools 59
1.1 Voice Command 59
1.2 Calendar 60
1.3 Alarm Clock 60
1.4 World Clock 61
1.5 Notepad 61
1.6 Calculator 61
1.7 Ez Tip Calc 62
1.8 Stopwatch 62
1.9 Unit Converter 62
2. Sound 63
2.1 Ringers 63
2.2 Volume 63
2.3 Message Alerts 63
2.4 Alert Type 63
2.5 Service Alerts 63
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 6

7
TABLE OF CONTENTS
2.6 Power On/Off Tones 64
3. Display 64
3.1 Wallpaper 64
3.2 Banner 64
3.3 Backlight 65
3.4 Menu Styles 65
3.5 Languages 65
3.6 Dial fonts 65
3.7 Clocks 65
3.8 Color Schemes 66
4. Security 66
4.1 Lock Phone 66
4.2 Restrict Call 66
4.3 Emergency #s 67
4.4 Change Lock Code 67
4.5 Reset Default 67
5. Call Settings 68
5.1 Answer Options 68
5.2 Auto Retry 68
5.3 One-Touch Dial 68
5.4 Voice Privacy 68
5.5 Auto Volume 69
5.6 Application Mode 69
5.7 TTY Mode 69
6. System 69
6.1 Network 69
6.2 PC Connection 70
6.3 Location 72
6.4 Touch Sensor Level 72
7. Bluetooth®73
7.1 Paired Devices 73
7.2 Power 74
7.3 My Visibility 74
7.4 Bluetooth Name 74
7.5 Bluetooth Info 75
8. Memory 75
9. Software Update 75
0. Phone Info. 75
Safety 76
TIA Safety Information 76
Exposure to Radio Frequency Signal 76
Antenna Care 76
Phone Operation 76
Tips on Efficient Operation 77
Driving 77
Electronic Devices 77
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 7

TABLE OF CONTENTS
8
TABLE OF CONTENTS
Pacemakers 77
Persons with pacemakers: 77
Hearing Aids 78
Other Medical Devices 78
Health Care Facilities 78
Vehicles 78
Posted Facilities 78
Aircraft 78
Blasting Areas 78
Potentially Explosive Atmosphere 79
For Vehicles Equipped with an Air Bag
79
Safety Information 79
Charger and Adapter Safety 79
Battery Information and Care 79
Explosion, Shock, and Fire Hazards 80
General Notice 80
Important safety information 81
Avoiding hearing damage 81
Using your phone safely 82
Important safety information 82
Avoiding hearing damage 82
Using headsets safely 82
FDA Consumer Update 83
10 Driver Safety Tips 90
Consumer Information on SAR 92
FCC Hearing-Aid Compatibility
(HAC) Regulations for Wireless
Devices 94
Accessories 96
Limited Warranty Statement97
Index 100
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 8

WELCOME
Thank you for choosing the AX8600 cellular phone
designed to operate with the latest digital mobile
communication technology, Code Division Multiple
Access (CDMA). Along with the many advanced
features of the CDMA system, such as greatly
enhanced voice clarity, this compact phone offers:

Celltop capability

Music capability and microSDTM card slot

Significantly enhanced voice clarity.

Slim and sleek design with internal antenna (Internal
antenna described as antenna throughout this user
guide)

Large, easy-to-read, 9-line backlit LCD with status
icons.

Paging, messaging, voice mail, and caller ID.

22-key keypad.

Speakerphone feature.

Menu-driven interface with prompts for easy
operation and configuration.

Any key answer, auto answer, auto retry, one-touch
and speed dialing with 99 memory locations.

Bilingual (English and Spanish) capabilities.

Bluetooth®wireless technology.
Important Information
This user’s guide provides important information on
the use and operation of your phone. Please read all
the information carefully prior to using the phone for
the best performance and to prevent any damage to
or misuse of the phone. Any unapproved changes or
modifications will void your warranty.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of
FCC rules. Operation is subject to the following two
conditions: (1) This device and its accessories may not
cause harmful interference, and (2) this device and its
accessories must accept any interference received,
including interference that causes undesired operation.
WELCOME
9
Note
The Bluetooth®word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by LG
Electronics is under license. Other trademarks and trade
names are those of their respective owners.
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 9

10
TECHNICAL DETAILS
TECHNICAL DETAILS
Technical Details
The AX8600 is an all digital phone that operates on
both Code Division Multiple Access (CDMA)
frequencies: Cellular services at 800 MHz and
Personal Communication Services (PCS) at 1.9 GHz.
CDMA technology uses a feature called DSSS (Direct
Sequence Spread Spectrum) that enables the phone to
keep communication from being crossed and to use
one frequency channel by multiple users in the same
specific area. This results in a 10-fold capacity increase
when compared with analog mode. In addition, features
such as soft / softer handoff, hard handoff, and
dynamic RF power control technologies combine to
reduce call interruptions.
The Cellular and PCS CDMA networks consist of
MSO (Mobile Switching Office), BSC (Base Station
Controller), BTS (Base Station Transmission System),
and MS (Mobile Station).
* TSB-74: Protocol between an IS-95A system and
ANSI J-STD-008
1xRTT system receives twice as many subscribers in
the wireless section as IS-95. Its battery life is twice
as long as IS-95. High-speed data transmission is
also possible.
The following table lists some major CDMA
standards.
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 10

TECHNICAL DETAILS
11
CDMA Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol and
inter-band operations
IS-95 adapted for PCS frequency
band CDMA2000 1xRTT Air
Interface
MAS-BS
PCSC-RS
Intersystem operations
Non-signaling data comm.
CDMA2000 High Rate Packet Data
Air Interface
1xEV-DO Inter-Operability
Specification for CDMA2000 Access
Network Interfaces
Recommended Minimum Performance
Standards for CDMA2000 High Rate
Packet Data Access Terminal Test
Application Specification (TAS) for
High Rate Packet Data Air Interface
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-856
TIA/EIA/IS-878
TIA/EIA/IS-866
TIA/EIA/IS-890
TIA/EIA/IS-96-B
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Short Message Service
Packet Data
Position Determination Service
(gpsOne)
High Speed Packet Data
Network
Service
1x EV-DO
Related
interface
Designator Description
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 11

12
TECHNICAL DETAILS
TECHNICAL DETAILS
FCC RF Exposure Information
WARNING! Read this information before operating
the phone.
In August 1996, the Federal Communications
Commission (FCC) of the United States, with its action in
Report and Order FCC 96-326, adopted an updated
safety standard for human exposure to Radio Frequency
(RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the
safety standard previously set by both U.S. and
international standards bodies. The design of this phone
complies with the FCC guidelines and these international
standards.
Bodily Contact During Operation
This device was tested for typical use with the back
of the phone kept 0.6 inches (1.5 cm) from the
body. To comply with FCC RF exposure requirements,
a minimum separation distance of 0.6 inches (1.5 cm)
must be maintained between the user’s body and the
back of the phone, including the antenna, whether
extended or retracted. Third-party belt-clips, holsters,
and similar accessories containing metallic
components should not be used. Avoid the use of
accessories that cannot maintain 0.6 inches (1.5 cm)
distance between the user’s body and the back of the
phone and have not been tested for compliance with
FCC RF exposure limits.
Vehicle-Mounted External Antenna
(Optional, if available.)
A minimum distance of 8 inches (20cm) must be
maintained between the user / bystander and the
vehicle-mounted external antenna to satisfy FCC RF
exposure requirements. For more information about
RF exposure, visit the FCC website at www.fcc.gov.
Caution
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result
in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a
damaged antenna comes into contact with the skin a minor
burn may result. Contact your local dealer for a replacement
antenna.
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 12

PHONE OVERVIEW
PHONE OVERVIEW
13
1. Earpiece
2. Flip Open to answer an incoming call and close to end the call.
3. LCD Screen Displays messages and indicator icons. When the flip is open,
Power Save mode automatically dims the screen and then darkens it if no
keys are pressed.
4. Side Keys Use to adjust the ringer volume in standby mode and the earpiece
volume during a call.
5. Left Soft Key Use to access Celltop to see your ringtones and call log right
next to today's sports scores and weather.
6. OK Key Select the function displayed at the bottom of the LCD between the
Left and Right Soft Key functions.
7. SEND Key Use to make or answer calls.
8. Battery Charging Port/ Headset Adapter Port Allows you to charge the
battery of your phone or plug in an optional headset for convenient, hands-
free conversations.
9. Vibrate Mode Key Use to set the mode (from standby mode press and hold
for about 3 seconds).
10. Voice Commands/ Speakerphone Key* Use for quick access to Voice
Commands. During a call, use to turn on speakerphone mode.
11. Side Camera Key Use for quick access to Camera function (When the flip is
open).
12. Navigation Keys Use for quick access to Contact List, Ringers, Axcess
Apps. and Mobile Web.
13. Right Soft Key Use to select an action within a menu.
14. PWR/END Key Use to turn the power on/off and to end a call. Also returns
to the main menu display screen.
15. BACK/Camera Key Deletes single spaces or characters with a quick press,
but press and hold to delete entire words. Will also back you out of menus,
one level at a time.
16. Alphanumeric Keypad Use to enter numbers and characters and select
menu items.
17. Lock Mode Key Use to lock the phone (from standby mode press and hold
for about 3 seconds).
18. Camera Lens Used to take a photo. Keep it clean for optimal photo quality.
19. microSD™ card slot Insert microSD card for external memory. Use LG-
approved microSD card.
* Speakerphone function is only available while a call is in progess.
2
4
6
3
7
9
12
14
13
19
10
11
17
16
15
18
8
1
5
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 13

14
MENUS OVERVIEW
MENUS OVERVIEW
Messaging
1. New Text Message
2. New Picture Message
3. Inbox
4. Sent
5. Drafts
6. Voicemail
7. Settings
1. Auto Save
2. Auto Delete
3. Text-Auto View
4. Picture-Auto
Receive
5. Text-Callback #
6. Edit Voicemail #
7. Entry Mode
8. Quick-Text
9. Text-Auto Play
0. Text Signature
*. Speed Messaging
8. Delete All
1. Delete Inbox
2. Delete Sent
3. Delete Drafts
4. Delete All Messages
Axcess Apps
1. Axcess Apps
2. Axcess Info
Axcess Web
1. Start Browser
2. Web Message
3. Web Settings
Multimedia
1. Take Picture
2. Record Video
3. Record Voice
Contacts
1. New Contact
2. Contact List
3. Groups
4. Speed Dials
5. My Name Card
Recent Calls
1. Missed
2. Received
3. Dialed
4. Data
5. All Calls
6. Call Timer
1. Last Call
2. Home Calls
3. Roam Calls
4. All Calls
7. Data Counter
1. Received Data
2. Sent Data
3. All Data
My Media
1. Image
2. Video
3. Audio
4. Shuffle
5. Music
Celltop
1. Start Celltop
Settings
1. Tools
1. Voice Command
2. Calendar
3. Alarm Clock
4. World Clock
5. Notepad
6. Calculator
7. Ez Tip Calc
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 14

MENUS OVERVIEW
15
8. Stopwatch
9. Unit Converter
2. Sound
1. Ringers
2. Volume
3. Message Alerts
4. Alert Type
5. Service Alerts
6. Power On/Off Tones
3. Display
1. Wallpaper
2. Banner
3. Backlight
4. Menu Styles
5. Languages
6. Dial Fonts
7. Clocks
8. Color Schemes
4. Security
1. Lock Phone
2. Restrict Call
3. Emergency #s
4. Change Lock Code
5. Reset Default
5. Call Settings
1. Answer Options
2. Auto Retry
3. One-Touch Dial
4. Voice Privacy
5. Auto Volume
6. Application Mode
7. TTY Mode
6. System
1. Network
2. PC Connection
3. Location
4. Touch Sensor Level
7. Bluetooth
1. Paired Devices
2. Power
3. My Visibility
4. Bluetooth Name
5. Bluetooth Info
8. Memory
1. Save Options
2. Memory Status
3. Phone Media Status
4. User Memory
9. Software Update
0. Phone Info.
1. My Number
2. SW Version
3. Icon Glossary
Menu Access
Press to Menu access nine phone menus. There
are two methods of accessing menus and submenus:

Use the navigation key to highlight and select, or

Press the number key that corresponds to the
menu (or submenu).
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 15

16
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
The Battery
The phone comes with a rechargeable battery. Keep
the battery charged while not in use in order to
maximize talk and standby time. The battery charge
level is shown at the top of the LCD screen.
Installing the Battery
Insert the battery into the opening by first aligning
the bottom of the battery with the terminals near the
bottom of the phone. Align the battery cover over
the battery then slide it slightly upward until it clicks
into place.
Removing the Battery
Turn the phone off. Slide the battery downward and
remove it. Use the opening near the top of the
battery to lift the battery out.
Charging the Battery
To use the charger provided with your phone:
Warning! Use only the charger provided with the
phone. Using any charger other than the one included
with the AX8600 may damage your phone or battery.
1. Plug the end of the adapter into the phone’s
charger port and the other end into an electrical
outlet.
2. The charge time varies depending upon the
battery level.
Note
It is important to fully charge the battery before initial
use of the phone.
NOTICE
Triangle symbol should
face up.
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 16

17
GETTING STARTED WITH YOUR PHONE
Battery Charge Level
The battery charge level is shown at the top right of
the LCD screen. When the battery charge level
becomes low, the low battery sensor alerts you in
three ways: sounding an audible tone, blinking the
battery icon, and displaying a warning message.
If the battery charge level becomes exceedingly low,
the phone automatically switches off and any
function in progress is not saved.
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery or connect the phone to
an external power source such as a vehicle power
charger or hands-free car kit.
2. Press for about 3 seconds until the LCD
screen lights up.
Turning the Phone Off
1. Press and hold until the display turns off.
EmptyFully Charged
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 17

18
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
Signal Strength
Call quality depends on the signal strength in your
area. The signal strength is indicated on the screen
as the number of bars next to the signal strength
icon: The more bars, the better the signal strength. If
the signal quality is poor, move to an open area. If
you are in a building, the reception may be better
near a window.
Screen Icons
To see the icon glossary, go to Menu -> Settings ->
Phone Info. -> Icon Glossary on your phone.
Making Calls
1. Make sure the phone is turned on. If not, press
for about 3 seconds.
2. Enter the phone number (include the area code if
needed).
3. Press .
lf the phone is locked, enter the lock code (the
last 4 digits of your phone number by default and
it's changeable in Settings menu).
Call Failed - indicates the call did not go through.
Restricted - indicates outgoing calls are in
restricted mode.
4. Press to end the call.
Note
If the phone is restricted, you can only dial phone
numbers saved in the Emergency Numbers or your
Contacts list. To turn off this function:
Menu -> Settings -> Security -> Lock
Code
-> Restrict Call -> None -> OK
Note
The call quality is also affected by the places where you
are and weather conditions with RF emission changes.
AX8600_Eng_new.qxd 1/23/07 3:27 PM Page 18
