LG BL20 Chocolate User manual

BL20 User Guide
Some of the contents in this manual may
differ from your phone depending on the
software of the phone or your service
provider.

Congratulations on your purchase of the
advanced and compact BL20 phone by LG,
designed to operate with the latest digital
mobile communication technology.
Disposal of your old appliance
1When this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive 2002/96/EC.
2All electrical and electronic products should be disposed of separately
from the municipal waste stream via designated collection facilities
appointed by the government or the local authorities.
3The correct disposal of your old appliance will help prevent potential
negative consequences for the environment and human health.
4For more detailed information about disposal of your old appliance,
please contact your city office, waste disposal service or the shop
where you purchased the product.

3
Guidelines for safe and efficient use..... 5
Getting to know your phone ................ 11
Open view............................................ 12
Installing the SIM and battery..............13
Memory card ....................................... 14
Installing a memory card..................... 14
Removing the memory card.................14
Formatting the memory card ............... 14
Your standby screen ............................15
The quick keys ................................... 15
The main menu ..................................15
The status bar .................................... 16
Calls ............................................... 17
Making a call...................................... 17
Making a call from your contacts ......... 17
Answering and rejecting a call............. 17
Adjusting the call volume ....................17
Speed dialling..................................... 18
Using call divert.................................. 18
Using call barring................................ 19
Contacts............................................... 20
Searching for a contact....................... 20
Adding a new contact ......................... 20
Contact options .................................. 20
Adding a contact to a group ................ 21
Renaming a group .............................. 21
Messaging ........................................... 22
Messaging ......................................... 22
Sending a message ............................22
Entering text....................................... 23
Message folders................................. 24
Managing your messages ...................24
Using templates.................................. 25
Camera ............................................... 26
Taking a quick photo........................... 26
After you’ve taken your photo.............. 26
Getting to know the viewfinder............. 27
Viewing your saved photos..................27
Setting a photo as Wallpaper or
Picture ID........................................... 27
Video camera....................................... 28
Shooting a quick video........................ 28
After you’ve shot your video ................28
Watching your saved videos ................ 29
Adjusting the volume when viewing
a video............................................... 29
Contents

LG BL20 | User Guide
4
MP3 player........................................... 30
MP3 player ........................................ 30
Transferring music onto your phone ..... 30
Playing a song....................................30
Creating a playlist............................... 31
Playing a playlist.................................31
Editing a playlist .................................31
Deleting a playlist ............................... 32
My stuff ............................................... 33
Images............................................... 33
Images options menu.......................... 33
Sending a photo ................................. 34
Organising your images ......................34
Deleting an image ..............................34
Deleting multiple images..................... 34
Creating a slide show.......................... 35
Sounds .............................................. 35
Using a sound .................................... 35
Videos ............................................... 35
Watching a video................................ 35
Using options while video is paused..... 36
Sending a video clip............................ 36
Video options menu ............................ 36
External memory ................................ 37
Using your phone as a mass storage
device................................................ 37
Transferring a file to your phone .......... 38
Sending and receiving your files using
Bluetooth ........................................... 38
Games and Apps.................................. 40
Games and Apps ................................ 40
Playing a game................................... 40
Browser ............................................... 41
Accessing the web..............................41
Adding and accessing your bookmarks 41
Saving a page ....................................42
Accessing a saved page...................... 42
Viewing your browser history...............42
Changing the web browser settings ..... 42
Settings ............................................... 43
Changing your display settings ............ 43
Changing your security settings........... 43
Resetting your phone.......................... 44
Viewing memory status.......................44
Changing your Bluetooth settings.........44
Changing your connectivity settings ..... 44
Pairing with another Bluetooth device . 45
Using a Bluetooth headset................... 45
Accessories ......................................... 46
Network service .................................. 47
Technical data...................................... 47
Contents

5
Please read these simple guidelines. Not
following these guidelines may be dangerous
or illegal.
Exposure to radio frequency energy
THIS DEVICE MEETS INTERNATIONAL
GUIDELINES FOR EXPOSURE TO RADIO
WAVES
Your mobile device is a radio transmitter and
receiver. It is designed and manufactured
not to exceed the limits for exposure to radio
frequency (RF) recommended by international
guidelines (ICNIRP). These limits are part
of comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines were developed by
independent scientific organisations through
periodic and thorough evaluation of scientific
studies. The guidelines include a substantial
safety margin designed to assure the safety
of all persons, regardless of age and health.
The exposure standard for mobile devices
employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR
limit stated in the international guidelines is
2.0 W/kg*. Tests for SAR are conducted using
standard operating positions with the device
transmitting at its highest certified power
level in all tested frequency bands. Although
the SAR is determined at the highest certified
power level, the actual SAR of the device
while operating can be well below the
maximum value. This is because the device is
designed to operate at multiple power levels
so as to use only the power required to reach
the network. In general, the closer you are to
a base station, the lower the power output of
the device. Before a phone model is available
for sale to the public, compliance with the
European R&TTE directive must be shown.
This directive includes as one essential
requirement the protection of the health and
the safety for the user and any other person.
The highest SAR value for this device when
tested for use at the ear is 0.667 W/kg.
This device meets RF exposure guidelines
when used either in the normal use position
against the ear or when positioned at least
1.5 cm away from the body. When a carry
case, belt clip or holder is used for body-worn
operation, it should not contain metal and
should position the product at least 1.5 cm
away from your body. In order to transmit
data files or messages, this device requires
a quality connection to the network. In some
cases, transmission of data files or messages
may be delayed until such a connection
is available. Ensure the above separation
distance instructions are followed until the
Guidelines for safe and efficient use

LG BL20 | User Guide
6
transmission is completed. The highest SAR
value for this device when tested for use at
the body is 1.45 W/kg.
* The SAR limit for mobile devices used
by the public is 2.0 watts/kilogram (W/kg)
averaged over ten grams of body tissue. The
guidelines incorporate a substantial margin
of safety to give additional protection for
the public and to account for any variations
in measurements. SAR values may vary
depending on national reporting requirements
and the network band.
For SAR information in other regions please
look under product information at www.
lgmobile.com.
FCC SAR information
Your mobile device is also designed to meet
the requirements for exposure to radio waves
established by the Federal Communications
Commission (USA) and Industry Canada.
These requirements set a SAR limit of 1.6
W/kg averaged over 1 gram of tissue. The
highest SAR value reported under this
standard during product certifi cation for use
at the ear is 0.413 W/kg and when properly
worn on the body is 0.578 W/kg.
Additionally, this device was tested for typical
body-worn operations with the back of the
phone kept 0.79 inches (2cm) between the
users body and the back of the phone.
To comply with FCC RF exposure
requirements, a minimum separation distance
of 0.79 inches(2cm) must be maintained
between the user’s body and the back of
the phone.
* FCC Notice & Caution
Notice!
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
Caution!
Change or Modification that are not expressly
approved by the manufacturer could void the
user’s authority to operate the equipment.
Guidelines for safe and efficient use

7
Product care and maintenance
WARNING
Only use batteries, chargers and accessories
approved for use with this particular phone
model. The use of any other types may
invalidate any approval or warranty applying
to the phone, and may be dangerous.
• Do not disassemble this unit. Take it to a
qualified service technician when repair
work is required.
• Keep away from electrical appliances such
as TVs, radios, and personal computers.
• The unit should be kept away from heat
sources such as radiators or cookers.
• Do not drop.
• Do not subject this unit to mechanical
vibration or shock.
• Switch off the phone in any area where
you are required by special regulations.
For example, do not use your phone in
hospitals as it may affect sensitive medical
equipment.
• Do not handle the phone with wet hands
while it is being charged. It may cause an
electric shock and can seriously damage
your phone.
• Do not to charge a handset near
flammable material as the handset can
become hot and create a fire hazard.
• Use a dry cloth to clean the exterior of the
unit (do not use solvents such as benzene,
thinner or alcohol).
• Do not charge the phone when it is on soft
furnishings.
• The phone should be charged in a well
ventilated area.
• Do not subject this unit to excessive
smoke or dust.
• Do not keep the phone next to credit
cards or transport tickets; it can affect the
information on the magnetic strips.
• Do not tap the screen with a sharp object
as it may damage the phone.
• Do not expose the phone to liquid or
moisture.
• Use the accessories like earphones
cautiously. Do not press the antenna
unnecessarily.

LG BL20 | User Guide
8
Efficient phone operation
Electronics devices
All mobile phones may get interference,
which could affect performance.
• Do not use your mobile phone near
medical equipment without requesting
permission. Avoid placing the phone over
pacemakers, for example in your breast
pocket.
• Some hearing aids might be disturbed by
mobile phones.
• Minor interference may affect TVs, radios,
PCs, etc.
Road safety
Check the laws and regulations on the use of
mobile phones in the areas when you drive.
• Do not use a hand-held phone while driving.
• Give full attention to driving.
• Use a hands-free kit, if available.
• Pull off the road and park before making
or answering a call if driving conditions so
require.
• RF energy may affect some electronic
systems in your vehicle such as car
stereos and safety equipment.
• When your vehicle is equipped with an
air bag, do not obstruct with installed or
portable wireless equipment. It can cause
the airbag to fail or cause serious injury
due to improper performance.
• If you are listening to music whilst out and
about, please ensure that the volume is at
a reasonable level so that you are aware
of your surroundings. This is particularly
imperative when near roads.
Avoid damage to your hearing
Damage to your hearing can occur if you are
exposed to loud sound for long periods of
time. We therefore recommend that you do
not turn on or off the handset close to your
ear. We also recommend that music and call
volumes are set to a reasonable level.
Blasting area
Do not use the phone where blasting is in
progress. Observe restrictions, and follow any
regulations or rules.
Guidelines for safe and efficient use

9
Potentially explosive atmospheres
• Do not use the phone at a refueling point.
• Do not use near fuel or chemicals.
• Do not transport or store flammable
gas, liquid, or explosives in the same
compartment of your vehicle as your
mobile phone and accessories.
In aircraft
Wireless devices can cause interference
in aircraft.
• Turn your mobile phone off before
boarding any aircraft.
• Do not use it on the ground without
permission from the crew.
Children
Keep the phone in a safe place out of the
reach of small children. It includes small
parts which may cause a choking hazard if
detached.
Emergency calls
Emergency calls may not be available
under all mobile networks. Therefore, you
should never depend solely on the phone
for emergency calls. Check with your local
service provider.
Battery information and care
• You do not need to completely discharge
the battery before recharging. Unlike
other battery systems, there is no memory
effect that could compromise the battery’s
performance.
• Use only LG batteries and chargers. LG
chargers are designed to maximize the
battery life.
• Do not disassemble or short-circuit the
battery pack.
• Keep the metal contacts of the battery
pack clean.
• Replace the battery when it no longer
provides acceptable performance. The
battery pack maybe recharged hundreds
of times until it needs replacing.
• Recharge the battery if it has not been
used for a long time to maximize usability.

LG BL20 | User Guide
10
• Do not expose the battery charger to direct
sunlight or use it in high humidity, such as
the bathroom.
• Do not leave the battery in hot or cold
places, this may deteriorate the battery
performance.
• There is risk of explosion if the battery is
replaced by an incorrect type.
• Dispose of used batteries according to
the manufacturer’s instructions. Please
recycle when possible. Do not dispose as
household waste.
• If you need to replace the battery, take it
to the nearest authorised LG Electronics
service point or dealer for assistance.
• Always unplug the charger from the wall
socket after the phone is fully charged to
save unnecessary power consumption of
the charger.
• Actual battery life will depend on network
configuration, product settings, usage
patterns, battery and environmental
conditions.
Guidelines for safe and efficient use

11
Camera
Charger, cable,
handsfree connector
Call key
Dials a phone
number and answers
incoming calls.
Clear key
Deletes a character
with each press.
Use this key to
go back to the
previous screen.
End/Power key
Ends or rejects a call.
Turns the phone on/off.
Returns to the standby screen when
you use the menu.
Main screen
Getting to know your phone
Volume key

LG BL20 | User Guide
12
Battery cover
Battery
Memory card slot
Flash
Open view
Camera lens

13
1 Remove the battery cover and the
battery
Slide down the battery cover and pull out
the battery.
WARNING: Do not remove the battery
when the phone is switched on, as this may
damage the phone.
2 Install the USIM card
Slide the USIM card into the USIM card
holder. Make sure the gold contact area on
the card is facing downwards. To remove
the USIM card, gently pull it outwards.
3 Install the battery
Insert the top of the battery into the top
edge of the battery compartment first.
Ensure that the battery contacts align with
the phone’s terminals. Press the bottom of
the battery down until it clips into place.
Installing the SIM and battery

LG BL20 | User Guide
14
Installing a memory card
You can expand the memory space available
on your phone using a memory card. The
BL20 will support a memory card of up to
16 GB.
TIP! A memory card is an optional accessory.
Open the slide covering the memory card
slot. Slide the memory card into the slot, until
it clicks into place. Make sure that the gold
contact area is facing downwards.
Removing the memory card
Open the slide and carefully remove the
memory card by gently pushing it as shown
in the following diagram:
Formatting the memory card
If your memory card is not already formatted,
you will need to do so before you can begin
using it.
1From the standby screen press Menu and
select Settings.
2Choose Memory status and select
External memory.
3Press Format and enter the password,
which is set to 0000 as default. Your card
will be formatted and ready to use.
4To view the new formatted folders on your
BL20 press Menu and select My stuff.
Choose External memory.
WARNING: When you format your memory
card, all the content will be wiped. If you do not
want to lose the data on your memory card,
back it up first.
Memory card

15
Advice to the customer
In order to allow better antenna sensitivity LG suggest that you hold the handset as shown
in the figure below.
0X
Please do not cover the antenna area with your hand during a call or when using a
Bluetooth connection. It may interfere and degrade signal quality.
The quick keys
The quick keys provide easy, one-press
access to your most used functions.
Select to open your message editor.
Select to choose a sound profile for
your phone.
Select to open the quick menu.
Select to open contacts.
The main menu
The main menu provides twelve menu
options. To open the main menu:
1Select Menu.
2The main menu will appear on the screen.
3Move the highlighted image onto your
desired position. And select center key to
open.
Your standby screen

LG BL20 | User Guide
16
The status bar
The status bar uses various icons to indicate
things like signal strength, new messages
and battery life, as well as telling you whether
your Bluetooth is active.
Below is a table explaining the meaning of
icons you’re likely to see in the status bar.
Icon Description
Network signal strength
(number of bars will vary)
No network signal
GPRS available
EDGE available
Flight mode is activated
Calls are diverted
Roaming service
Bluetooth®is activated
WAP service is connected
An alarm is set
Schedule
Icon Description
New message
New voice message
General profile in use
Silent profile in use
Vibrate profile in use
Outdoor profile in use
Headset profile in use
Remaining battery life
Battery empty
Your standby screen

17
Making a call
1Key in the number using the keypad. To
delete a digit press .
2Press to initiate the call.
3To end the call, press .
TIP! To enter + when making an international
call, press and hold 0.
Making a call from your contacts
1Select Contacts from the Standby screen.
2Using the keypad, enter the first letter of
the contact you want to call. For example,
for Office, press 6three times.
3Select Call or press to initiate the
call.
Answering and rejecting a call
When your phone rings, press Accept or
press to answer the call.
While your phone is ringing, press the lock
key, then select Silent to mute the ringing.
This is great if you have forgotten to change
your profile to Silent for a meeting.
Press or select Reject to reject the
incoming call.
Adjusting the call volume
To adjust the volume during a call, press the
lock key, then press the volume key on the
right hand side of your phone.
Calls

LG BL20 | User Guide
18
Speed dialling
You can assign a speed dial number to a
contact you call frequently.
1Press Contacts and press menu, then
select Speed dials.
2Your voicemail is set to speed dial 1 and
you cannot change this. Select any other
number either by using the navigation
key arrows and selecting Assign or by
pressing the hard key number.
3Your address book will open. Select the
contact you’d like to assign to that number
using the navigation arrows, then select
OK.
To call a speed dial number, press and
hold the assigned number until the contact
appears on screen. The call will initiate
automatically; there’s no need to press .
Using call divert
1Select Menu, select Settings and choose
Call.
2Select Call divert.
3Choose whether to divert all calls, when
there is not answered, when you are out of
reach.
4Choose Activate and select whether to
divert to another number or your favourite
number.
5Enter your divert number or select Search
to browse Contacts for your divert
number.
Note: Charges are incurred for diverting
calls. Please contact your network provider
for details.
TIP! To turn off all call diverts, choose
Deactivate all from the Call divert menu.
Calls

19
Using call barring
1Select Menu, select Settings and choose
Call.
2Select Call barring and choose Voice
calls.
3Choose options:
4 Select Activate and enter the call barring
password. Please check with your network
operator for this service.
TIP! Select Fixed dial number from the Call
menu to turn on and compile a list of numbers
which can be called from your phone. You’ll
need your PIN2 code from your operator. When
activated, only numbers included in the fixed dial
list can be called from your phone.

LG BL20 | User Guide
20
Searching for a contact
1Select Contacts from the standby screen,
and choose Search.
2Using the keypad enter the first letter of
the contact you want to call. For example,
for Office, press 6 three times.
3To scroll through the contacts and their
different numbers use the navigation
arrows.
Adding a new contact
1Select Contacts and choose Create new
contact.
2Choose whether to store your new contact
on your Phone or SIM card.
3Enter all the information you have in the
fields provided and select Save.
Or, using the slightly quicker method…
1Enter the number you wish to store on the
standby screen and select Options.
2Choose Save or Add to existing
contact.
3Enter the relevant information as above
and select Save.
Note: When you are storing a contact’s email
address, press to enter a symbol and
scroll with the navigation arrows until you
see @.
Contact options
There are many things you can do when
viewing a contact. Here’s how to access and
use the Options menu:
1Open the contact you’d like to use. See
Searching contacts above.
2Select Options to open the list of options.
From here you can:
Edit - Change any of the contact’s details.
New message - Send a message to
the contact. If the contact has an email
address, select whether you’d like to send
a Message or Email.
Send via - Send the contact’s details
to another person as a business card.
Choose to send as a Text message,
Multimedia message,via Bluetooth or
by Email.
Delete - Delete the contact. Select Yes if
you are sure.
New contact - Add a new contact.
Contacts
