LG LG-D385 User manual

Internal Use Only
Service Manual
LG-D385
Date: April, 2014 / Issue 1.0

- 2 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
1.3 Specications.............................................................................................5
2. PERFORMANCE...................................................................... 8
2.1 Product Name............................................................................................8
2.2 Supporting Standard..............................................................................8
2.3 Main Parts : GSM Solution.....................................................................8
2.4 HW Features ...............................................................................................9
2.5 HW SPEC ................................................................................................... 11
2.6 D385 Figures ........................................................................................... 22
3. TROUBLE SHOOTING .......................................................... 23
3.1 WCDMA Rx Part...................................................................................... 23
3.2 WCDMA Tx Part Trouble...................................................................... 48
3.3 GSM Rx Part Troubleshooting.......................................................... 80
3.4 GSM Tx Part Troubleshooting.........................................................116
3.5 Power .......................................................................................................125
3.6 Charging .................................................................................................129
3.7 USB TS ......................................................................................................131
3.8 Audio........................................................................................................132
3.9 6 AXIS Sensor........................................................................................146
3.10 Proximity Sensor...............................................................................149
3.11 Touch Sensor Trouble Shooting..................................................151
3.12 Vibrator Trouble Shooting.............................................................152
3.13 8M Main Camera TS .........................................................................154
3.14 Main LCD TS ........................................................................................157
3.15 BT/Wi TS .............................................................................................160
3.16 GPS TS....................................................................................................163
3.17 FM TS......................................................................................................166
3.18 DTV.........................................................................................................168
4. DOWNLOAD.......................................................................171
5. BLOCK DIAGRAM..............................................................188
6. CIRCUIT DIAGRAM ............................................................199
7. BGA PIN MAP .....................................................................222
8. PCB LAYOUT.......................................................................229
9. CALIBRATION.....................................................................231
10. HIDDEN MENU.................................................................250
11. DISASSEMBLE GUIDE......................................................257
12. EXPLODED VIEW & REPLACEMENT PART LIST .............262
12.1 EXPLODED VIEW................................................................................262
12.2 Replacement Parts...........................................................................263
12.3 Accessory .............................................................................................292

- 3 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. INTRODUCTION
This manual provides the information necessary to repair calibration description and download the
1.1 Purpose
1. Introduction
This
manual
provides
the
information
necessary
to
repair
,
calibration
,
description
and
download
the
features of this model.
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example,
persons other than your company
’
s employees agents subcontractors or person working on your
1.2 Regulatory Information
A. Security
persons
other
than
your
company s
employees
,
agents
,
subcontractors
,
or
person
working
on
your
company’s behalf) can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated
with your telecommunications system. System users are responsible for programming and configuring
the equipment to prevent unauthorized use. The manufacturer does not warrant that this product is
immune from the above case but will prevent unauthorized use of common carrier
telecommunication service of facilities accessed through or
connected to it The manufacturer will not be responsible for any charges that result from such
connected
to
it
.
The
manufacturer
will
not
be
responsible
for
any
charges
that
result
from
such
unauthorized use.
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly
causing harm or interruption in service to the telephone network, it should disconnect telephone
service until repair can be done. A telephone company may temporarily disconnect service as long as repair
is not done
is
not
done
.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these
changes could reasonably be expected to affect the use of the phones or compatibility with the net work,
the telephone company is required to give advanced written notice to the user, allowing the user to take
appropriate steps to maintain telephone service.
D. Maintenance Limitation
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore,
note that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.
E. Notice of Radiated Emission
This model complies with rules regarding radiation and radio frequency emission as defined by local
regulatory agencies. In accordance with these agencies, you may be required to provide information such as
the following to the end user.
- 4 -

- 4 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly
different.
H. Electrostatic Sensitive Devices
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
G. Interference and Attenuation
ATTENTION
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the sign. Following
information is ESD handling:
• Service
p
ersonnel should
g
round themselves b
y
usin
g
a wrist stra
p
when exchan
g
e s
y
stem boards.
p g y g p g y
• When repairs are made to a system board, they should spread the floor with anti-static mat which is
also grounded.
• Use a suitable, grounded soldering iron.
• Keep sensitive parts in these protective packages until these are used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as
described
described
.
- 5 -

- 5 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
1.3 Specification
KEY FEATURES
• Android 4.4-(KitKat)
• 5” Touch Screen WVGA (480 x 800)
• 8MP AF with flash
• 3G Mobile Hotspot
ENHANCED USER EXPERIENCE
• Android 4.4
• Proximity Sensor – locks the touch screen and buttons while talking on the phone
• Motion Sensor – Electronic compass , Accelerometer and Gyroscope
• USB Charging via Computer
•
Airplane Mode (RF Off)
Airplane
Mode
(RF
Off)
DESIGN
• Sleek and Stylish Design
• 5“ WVGA LCD Screen
• Capacitive Touch Screen – Glass with fast and accurate response
Mi USB/Ch i P t
•
Mi
cro
USB/Ch
arg
i
ng
P
or
t
- 6 -
1.3 Specication

- 6 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
• 8MP AF with flash and Camcorder
CAMERA/VIDEO
• Camera Resolutions: 3264 X 2448 3200 X 1920 2560 x 1920 1280 X 960 Pixels
• Image Editor: zoom, rotate, crop images
• Brightness, ISO, White Balance,* Color Effects, Timer
• Cheese shutter – take photo with voice command.
• Video Resolutions: 800 X 480 640 x 480 320 x 240 176 x 144 Pixels
MULTIMEDIA
• Music Player for MP3, WMA, and Unprotected AAC
• Stereo Sound via Headset or Bluetooth
• Music Library – Organized by Artists, Albums, Songs, and Playlists
• Repeat and Shuffle Music Playback Modes
BLUETOOTH®
• Version: 4.0
• Supported Profiles: headset, hands-free, object push, advanced audio distribution (stereo),
audio/video remote control, file transfer, phone book access, message access, serial port
• Listen to Music with Optional Stereo Bluetooth Headset**
• Send User-Generated Pictures (JPEG) and Videos via Bluetooth Wireless Technology
*Depends on available memory.
**
Accessories sold separately
Accessories
sold
separately
.
- 7 -

- 7 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
VOICE/AUDIO
1. Introduction
• One-
T
ouch Speakerphone*
• Speaker-Independent Voice Commands
• Voice-Activated Dialing
• Text to Speech
• MP3 Music Ringer Support
TOOLS & DATA
TOOLS
&
DATA
Android Apps: Alarm/Clock, Browser, Calculator, Calendar (Corporate or Google), Camera, Contacts,
Email, Gallery, Gmail, Google+, Maps, Messaging, Messenger, Music Player, Phone, Places, Play
Books, Play Movies, Play Music, Play Store, Talk, Video Player, Voice Recorder, Youtube
Navigation – spoken turn-by-turn directions showing real-time traffic
Wi-Fi Connectivit
y
– IEEE 802.11 b/
g
/n
y
g
• A-GPS Support for Enhanced Location Accuracy
SPECIFICATIONS
•
T
echnolo
gy
: GSM/WCMDA
gy
• Frequencies: GSM 850,900,1800,1900
• WCDMA 2100, 850
• Data Transmission: WCMDA, GPRS
• Dimensions: 138.24 x 74.28 x 9.7 (mm)
• Display: 5" , WVGA (480 x 800) pixels
Standard Battery 2 540 [
mAh
]
•
Standard
Battery
:
2
,
540
[
mAh
]
ACCESSORIES
• Standard Battery
- 8 -
•
T
ravel Adapter and USB Cable*
• Stereo Headset

2. PERFORMANCE
- 8 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. PERFORMANCE
2.1 Product Name
LG-D385 : WCDMA 850//2100+GSM850/EGSM/DCS/PCS (HSUPA 5.76Mbps(cat6)/HSDPA 21Mbps(cat14)/GPRS Class12/EDGE
Class12)
2.2 Supporting Standard
LG-D385 Product SPEC
4
2.1 Product Name
LG-D385 : WCDMA 850//2100+GSM850/EGSM/DCS/PCS
(HSUPA 5.76Mbps(cat6)/HSDPA 21Mbps(cat14)/GPRS Class12/EDGE Class12)
2.2 Supporting Standard
Supporting Standard
WCDMA(FDD1,5)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
SIM Toolkit : Class 1, 2, 3, C-E
Frequency Range
WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD5) TX : 824 – 849 MHz
WCDMA(FDD5) RX : 869 – 894 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
GSM900 TX : 880 – 915 MHz
GSM900 RX : 925 – 960 MHz
DCS1800 TX :1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM8210 : Qualcomm
Analog Baseband PM8110 : Qualcomm
RF Chip WTR2605 : Qualcomm
2.3 Main Parts : GSM Solution
LG-D385 Product SPEC
4
2.1 Product Name
LG-D385 : WCDMA 850//2100+GSM850/EGSM/DCS/PCS
(HSUPA 5.76Mbps(cat6)/HSDPA 21Mbps(cat14)/GPRS Class12/EDGE Class12)
2.2 Supporting Standard
Supporting Standard
WCDMA(FDD1,5)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
SIM Toolkit : Class 1, 2, 3, C-E
Frequency Range
WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD5) TX : 824 – 849 MHz
WCDMA(FDD5) RX : 869 – 894 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
GSM900 TX : 880 – 915 MHz
GSM900 RX : 925 – 960 MHz
DCS1800 TX :1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM8210 : Qualcomm
Analog Baseband PM8110 : Qualcomm
RF Chip WTR2605 : Qualcomm

2. PERFORMANCE
- 9 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2.4 HW Features
LG-D385 Product SPEC
5
2.4 HW Features
List Type / Spec.
1. Phone Type DOP Type
2. Size 138.24 x 74.28 x 9.7 (mm)
3. Weight 141g
4. Battery 2,540mAh ( typ.), 2,460mAh(min) (Li-Ion)
5.Chipset MSM8210
6. Memory 8GB(EMMC) +1Gb(LPDDR2)
7. LCD
Size 5 inch
Dot 480(H) X 800(V)
Color 16.7M colors
Display Type Active matrix TFT
NTSC Typ. 70%
Contrast Ratio Typ. 1000:1
Pixel Pitch(mm) 0.1362mm X 0.1362mm
(186PPI)
8. Main Camera (8M)
Type CMOS image sensor
Resolution 3280(H) X 2464(V) pixels.
Frame Rate 2.5fps @ Full Size (3280 x 2464)
View Angle 71.4°
Image Scaling Down 8M,5M,3M,W3M,1M,W1M
Pixel x size 1.1um x1.1um

2. PERFORMANCE
- 10 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D385 Product SPEC
6
10. Audio
1) MIDI MIDI
2) Mono 18 X 10 X 3T Speaker
3) Receiver 13 X 07 X 2.7T Wideband Receiver
11. Bluetooth
Effective Distance 10M
Distance 0 m ~ 10 m (depend on environment)
12. WLAN
standard IEEE 802.11 b/g/n
Throughput Max 40Mbps (SDIO Driver
performance)
depend on environment 0 ~ 50m (depend on environment)
13. GPS type A-GPS, GNSS

2. PERFORMANCE
- 11 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2.5 HW SPEC
1) WCDMA transmitter specication
LG-D385 Product SPEC
7
2.5 HW SPEC
1) WCDMA transmitter specification
Item Spec. Min Typ. Max Unit
Maximum Output
Power Power class Ⅲ21.0 23 25.0 dBm/3.84MHz
Frequency Accuracy - -200 - +200 Hz
Minimum Output
Power - - - -50 dBm/3.84MHz
Occupied
Bandwidth - - - 4.6 MHz
Adjacent Channel
Leakage Power
Ratio
Δf = 5MHz - - -33 dBm/3.84MHz
Δf = 10MHz - - -43 dBm/3.84MHz
Error Vector
Magnitude(EVM) - --17 %
Peak Code Domain
Error - - - 15 dBm/3.84MHz
Open Loop
Output Power
Ior =-
106.7dBm/3.84MHz -46.7 - -28.7 dBm/3.84MHz
Ior =-65.7dBm/3.84MHz -23.0 - -5.0 dBm/3.84MHz
Ior =-25.0dBm/3.84MHz -0.0 - 14.0 dBm/3.84MHz
Transmit Off Power - - - -56 dBm/3.84MHz
Spectrum Emission
Mask
Δf = 2.5~3.5MHz -35-15 * (Δf-2.5) dBc/30KHz
Δf = 3.5~7.5MHz -35-1 * (Δf-3.5) dBc/1MHz
Δf = 7.5~8.5MHz -39 10 * (Δf-7.5) dBc/1MHz
Δf = 8.5~12.5MHz -49 dBc/1MHz
Transmit Spurious
Emission
9kHz ~ 150kHz -36 dBm
150kHz ~ 30MHz -36 dBm
30MHz ~ 1GHz -36 dBm
1GHz ~ 12.5GHz -30 dBm

2. PERFORMANCE
- 12 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2) WCDMA receiver specication
LG-D385 Product SPEC
8
2) WCDMA receiver specification
Item Specification
Receive Frequency
BD1: 2110 ~ 2170 MHz
BD5: 869 MHz ~ 894 MHz
Reference Sensitivity Level
<REFÎor>
Band1 : BER < 0.001 when Îor = -106.7 dBm / 3.84 MHz
Band5 : BER < 0.001 when Îor = -104.7 dBm / 3.84 MHz
Maximum Input Level BER < 0.001 when Îor = -25 dBm / 3.84 MHz
Adjacent Channel Selectivity
(ACS)
ACS > 33 dB where BER < 0.001 when
Îor = <REFÎor> + 14 dB / 3.84 MHz
& Ioac = –52 dBm / 3.84 MHz @ ±5 MHz
Blocking Characteristic
BER < 0.001 when Îor = <REFÎor> + 3 dB / 3.84 MHz
& Iblocking = -56 dBm / 3.84 MHz @ Fuw(offset) = ±10 MHz
or Iblocking = -44 dBm / 3.84 MHz @ Fuw(offset) = ±15 MHz
Spurious Response
BER < 0.001 when Îor = <REFÎor> + 3 dB / 3.84 MHz
& Iblocking = -44 dBm
Intermodulation
BER < 0.001 when Îor= <REFÎor> + 3 dB / 3.84 MHz
& Iouw1 = -46 dBm @ Fuw1(offset) = ±10 MHz
& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(offset) = ±20 MHz
Spurious Emissions
< -57 dBm / 100 kHz BW @ 9 kHz ≤ f < 1 GHz
< -47 dBm / 1 MHz BW @ 1 GHz ≤ f ≤ 12.75 GHz
Inner Loop Power Control
In Uplink
Adjust output(TPC command)
cmd 1dB 2dB 3dB
+1 +0.5/1.5 +1/3 +1.5/4
0 -0.5/+0.5 -0.5/+0.5 -0.5/+0.5
-1 -0.5/-1.5 -1/-3 -1.5/-4
group(10equal command group)
+1 +8/+12 +16/+24

2. PERFORMANCE
- 13 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3) HSDPA transmitter specication
LG-D385 Product SPEC
9
3) HSDPA transmitter specification
Item Spec. Min Typ. Max Unit
Trands
mitter
5.2.A Maximum
Output Power
with HS-DPCCH
1/15 c/d 12/15
13/15 c/d 15/8
15/7 c/d 15/0
21.0
20
19
22.5
22.5
22
25.0
25
25
dBm/3.84MHz
5.7A HS-DPCCH MAX /
0dBm
Step 0 0 dBm +/- 1 dB dB
Step 1 – Step 0 6 dB +/- 2.3 dB dB
Step 2 – Step 3 1 dB +/- 0.6 dB dB
Step 5 – Step 4 0 dB +/- 0.6 dB dB
Step 6 – Step 7 5 dB +/- 2.3 dB dB
5.9A Spectrum
Emission Mask
with HS-DPCCH
Δf = 2.5~3.5MHz -35-15 * (Δf-2.5) dBc/30KHz
Δf = 3.5~7.5MHz -35-1 * (Δf-3.5) dBc/1MHz
Δf = 7.5~8.5MHz -39 10 * (Δf-7.5) dBc/1MHz
Δf = 8.5~12.5MHz -49 dBc/1MHz
5.10A Adjacent
Channel Leakage
Power Ratio with
HS-DPCCH
Δf = 5MHz - - -33 dBm/3.84MHz
Δf = 10MHz - - -43 dBm/3.84MHz
5.13.1A Error
Vector Magnitude
(EVM) with HS-
DPCCH
MAX Power
-20 dBm --17.5 %
Receiver
6.3A Maximum
Input Level for
HS-PDSCH
Reception
Pin = -25dBm - -10 BLER(%)

2. PERFORMANCE
- 14 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D385 Product SPEC
10
4) GSM specification
Item Spec.
Phase Error Rms : 5°/Peak : 20 °
Frequency Error GSM : 0.1 ppm
DCS/PCS : 0.1 ppm
EMC(Radiated Spurious Emission Disturbance) GSM/DCS : < -28dBm
Transmitter Output power and Burst Timing GSM : 5dBm – 33dBm ± 3dB
DCS/PCS : 0dBm – 30dBm ± 3dB
Burst Timing <3.69us
Spectrum due to modulation out to less than
1800kHz offset
200kHz : -36dBm
600kHz : -51dBm/-56dBm
Spectrum due to modulation out to larger than
1800kHz offset to the edge of the transmit band
GSM :
1800-3000kHz :< -63dBc(-46dBm)
3000kHz-6000kHz : <-65dBc(-46dBm)
6000kHz < : < -71dBc(-46dBm)
DCS :
1800-3000kHz :< -65dBc(-51dBm)
6000kHz < : < -73dBc(-51dBm)
Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0), -23dBm
600kHz : -21dBm/-24dBm(5/0), -26dBm
Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)
Usable receiver input level range 0.012(-15 - -40dBm)
Intermodulation rejection – Speech channels ± 800kHz, ± 1600kHz
: -98dBm/-96dBm (2.439%)
AM Suppression
-GSM : -31dBm - DCS : -29dBm -98dBm/-96dBm (2.439%)
Timing Advance ± 0.5T
4) GSM specication

2. PERFORMANCE
- 15 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D385 Product SPEC
11
5) Bluetooth transmitter specification
Item Spec. Min Typ. Max Unit
Output Power DH5
PRBS9
Power
(Class I) 0 - +20 dBm
Power Density DH5
PRBS9
@100kHz
RBW - +20 dBm
Power Control DH1
PRBS9
Step size 2 - 8 dB
Power(min) - 4 dBm
Frequency Range DH5
PRBS9
-30dBc
@100kHz
RBW
2400 - 2483.5 MHz
Tx Output Spectrum
(20dB BW)
DH5
PRBS9 Δf =fH-fL- 1 MHz
Tx Output Spectrum
(Adjacent Output
Power)
DH5
PRBS9
@M-N = 2 - -20 dBm
@M-N 3 - -40 dBm
Modulation Index
DH5
11110000 f1AVG 140 - 175 kHz
DH5
10101010
f2MAX 115 - kHz
f2AVG/f1AVG 0.8 -
Initial Carrier Freq.
Tolerance
DH5
PRBS9 -75 - +75 kHz
Carrier Frequency Drift
DH1
10101010
Freq. Drift -25 - +25 kHz
Drift Rate -20 - +20 kHz/50us
DH3
10101010
Freq. Drift -40 - +40 kHz
Drift Rate -20 - +20 kHz/50us
DH5
10101010
Freq. Drift -40 - +40 kHz
Drift Rate -20 - +20 kHz/50us
5) Bluetooth transmitter specication

2. PERFORMANCE
- 16 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D385 Product SPEC
12
6) Bluetooth receiver specification
Item Spec.
BER=0.1% Min Typ. Max Unit
Sensitivity
(Single Slot Packet)
DH1
PRBS9
Input power @BT_w
- - -70 dBm
Sensitivity
(Multi Slot Packet)
DH5
PRBS9
Input power @BT_w
- - -70 dBm
C/I Performance*
DH1
PRBS9
Input power @BT_i
C/I@Co-Channel
-60dBm @ BT - 11
dB
C/I @1MHz
-60dBm@ BT - 0
C/I @2MHz
-60dBm@ BT - -30
C/I @≥3MHz
-67dBm@ BT - -40
C/I @Image
-67dBm@ BT - -9
C/I @ Image1MHz
-67dBm@ BT - -20
Blocking Performance
DH1
PRBS9
Input power @CW
30M ~2 GHz
-67dBm@ BT -10 -
dBm
2 ~ 2.4 GHz
-67dBm@ BT -27 -
2.5 ~ 3 GHz
-67dBm@ BT -27 -
3 ~ 12.75 GHz
-67dBm@ BT -10 -
Intermodulation
Performance
DH1
PRBS9
Input power @CW_i
Δf = +5MHz (CW_i)
Δf = +10MHz (BT_i)
-64dBm@ BT_w
-39 - dBm
Δf = -5MHz (CW_i)
Δf = -10MHz (BT_i)
-64dBm@ BT_w
-39 - dBm
Maximum Input Level
DH1
PRBS9
Input power @BT_w
- -20 - dBm
6) Bluetooth receiver specication

2. PERFORMANCE
- 17 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D385 Product SPEC
13
7) WLAN 802.11b transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13)
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy
(Peak EVM) ≤ 35%
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -76dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
7) WLAN 802.11b transceiver specication

2. PERFORMANCE
- 18 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D385 Product SPEC
14
8) WLAN 802.11g transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13)
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM) ≤ -5dB
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※ACR shall be measured by setting the desired signal's strength 3
dB above the rate-dependent
sensitivity specified in min input sensitivity
8) WLAN 802.11g transceiver specication

2. PERFORMANCE
- 19 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D385 Product SPEC
15
9) WLAN 802.11n transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13)
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance
within ±25 PPM
Spectrum Mask ≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -45 @ ±30MHz offset (20MHz ~ 30Mhz)
T
ransmitter constellation error
(rms EVM)
≤ [email protected], ≤ -10dB@13Mbps, ≤ -13d[email protected],
≤ -16dB@26Mbps, ≤ -19dB@39Mbps, ≤ -22dB@52Mbps,
≤ [email protected], ≤ -28dB@65Mbps
Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity PER ≤ 10%
[email protected], -79dBm@13Mbps, -77d[email protected]
-74dBm@26Mbps, -70dBm@39Mbps, -66dBm@52Mbps
[email protected], -64dBm@65Mbps
Rx Max input Sensitivity ≥ -20dBm(6.5,13,19.5,26,39,52,58.5,65Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ [email protected], ACR ≥ 13dB@13Mbps,
ACR ≥ [email protected], ACR ≥ 8dB@26Mbps,
ACR ≥ 4dB@39Mbps, ACR ≥ 0dB@52Mbps
ACR ≥ [email protected], ACR ≥ -2dB@65Mbps
※ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity
9) WLAN 802.11n transceiver specication

2. PERFORMANCE
- 20 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
10) GPS receiver specication
11) Current consumption
** Test condition for Standby current consumption should be as below.
: Measurement time 1hr, with Agilent & CMT JIG
LG-D385 Product SPEC
16
10) GPS receiver specification
Item Spec.
Sensitivity Test Success rate ≥60% @ -154 dBm
11) Current consumption
** Test condition for Standby current consumption should be as below.
: Measurement time 1hr, with Agilent & CMT JIG
Item
Specification
WCDMA GSM
1. Sleep Mode Under 3.5mA Under 3.5mA
2. Sleep : connector Ear jack Under 4.5mA Under 4.5mA
3. Current(Sleep & Idle AVG) Under 4.5mA @ DRX 7 Under 4.5mA @ P.P 5
4. BT Connected idle Under 6mA Under 6mA
5. Talk Mode
-Max Pwr
Under 600mA @ Avg
- Tx 10dBm
Under 400 mA @ Avg
GSM LVL 5
Under 400mA @ Avg.
6. No SVC Mode Under 200mA Under 200 mA
7. Power Off Mode Under 300uA Under 300uA
LG-D385 Product SPEC
16
10) GPS receiver specification
Item Spec.
Sensitivity Test Success rate ≥60% @ -154 dBm
11) Current consumption
** Test condition for Standby current consumption should be as below.
: Measurement time 1hr, with Agilent & CMT JIG
Item
Specification
WCDMA GSM
1. Sleep Mode Under 3.5mA Under 3.5mA
2. Sleep : connector Ear jack Under 4.5mA Under 4.5mA
3. Current(Sleep & Idle AVG) Under 4.5mA @ DRX 7 Under 4.5mA @ P.P 5
4. BT Connected idle Under 6mA Under 6mA
5. Talk Mode
-Max Pwr
Under 600mA @ Avg
- Tx 10dBm
Under 400 mA @ Avg
GSM LVL 5
Under 400mA @ Avg.
6. No SVC Mode Under 200mA Under 200 mA
7. Power Off Mode Under 300uA Under 300uA
