Service Manual
LG-D605
Date: September, 2013 / Issue 1.0

- 2 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
1.3 Specications.............................................................................................5
2. PERFORMANCE.................................................................... 10
2.1 Product Name......................................................................................... 10
2.2 Supporting Standard........................................................................... 10
2.3 Functions of Major Semi-Conductors........................................... 10
2.4 HW Features ............................................................................................ 11
2.5 SW Features ............................................................................................. 13
2.6 H/W SPEC.................................................................................................. 27
2.7 LG-D605 Figures..................................................................................... 37
2.8 Assembly components....................................................................... 38
2.9 SMT Components: Bottom side....................................................... 39
2.10 SMT Components: TOP side ........................................................... 41
3. TROUBLE SHOOTING .......................................................... 43
3.1 Checking XO Block................................................................................ 43
3.2 Checking Transceiver DC Power Supply Circuit Block............ 45
3.3 Checking DC-DC Block........................................................................ 47
3.4 Checking FEMiD(GSM Quad, W B1/2/5/8) Block ...................... 49
3.5 GSM RF Part ............................................................................................. 53
3.6 WCDMA RF Part...................................................................................... 68
3.7 BT&WI-FI / NFC PART............................................................................ 86
3.8 GPS Part..................................................................................................... 94
3.9 Power .......................................................................................................100
3.10 Charger .................................................................................................105
3.11 CAMERA................................................................................................107
3.12 LCD .........................................................................................................110
3.13 Touch .....................................................................................................112
3.14 Sensor....................................................................................................115
3.15 USB .........................................................................................................119
3.16 SIM ..........................................................................................................121
3.17 Audio .....................................................................................................123
4. DOWNLOAD.......................................................................132
5. BLOCK DIAGRAM..............................................................149
6. CIRCUIT DIAGRAM ............................................................156
7. BGA PIN MAP.....................................................................167
8. PCB LAYOUT.......................................................................173
9. CALIBRATION.....................................................................178
10. HIDDEN MENU.................................................................197
11. DISASSEMBLE GUIDE......................................................218
12. EXPLODED VIEW & REPLACEMENT PART LIST .............222
12.1 EXPLODED VIEW................................................................................222
12.2 Replacement Parts ...........................................................................223
12.3 Accessory .............................................................................................257

- 3 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. INTRODUCTION
1. Introduction
This manual provides the information necessary to repair, calibration, description and download the features
of this model.
1. 1 Purpose
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example,
persons other than your company’s employees, agents, subcontractors, or person working on your
company’s behalf) can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated
with your telecommunications system. System users are responsible for programming and configuring
the equipment to prevent unauthorized use. The manufacturer does not warrant that this product is
immune from the above case but will prevent unauthorized use of common carrier
telecommunication service of facilities accessed through or connected to it. The manufacturer will not
be responsible for any charges that result from such unauthorized use.
1. 2 Regulatory Information
A. Security
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly
causing harm or interruption in service to the telephone network, it should disconnect telephone
service until repair can be done. A telephone company may temporarily disconnect service as long as repair
is not done.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these
changes could reasonably be expected to affect the use of the phones or compatibility with the net work,
the telephone company is required to give advanced written notice to the user, allowing the user to take
appropriate steps to maintain telephone service.
D. Maintenance Limitation
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore,
note that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.

- 4 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
3
E. Notice of Radiated Emission
This model complies with rules regarding radiation and radio frequency emission as defined by local
regulatory agencies. In accordance with these agencies, you may be required to provide information such as
the following to the end user.
ATTENTION
H. Electrostatic Sensitive Devices
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the
sign. information is ESD handling: Following
• Service personnel should ground themselves by using a wrist strap when exchange system boards.
• When repairs are made to a system board, they should spread the floor with anti-static mat which is
also grounded.
• Use a suitable, grounded soldering iron.
• Keep sensitive parts in these protective packages until these are used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as
described.
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
G. Interference and Attenuation
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly
different.

- 5 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
4
1. 3. Specifications
KEY FEATURES
•Android 4.1.2 - Powered Smartphone
• Up to 7 Customizable Home Screens
• 4.7” Touch Screen
• 8MP AF with flash, 1.3M VT Image sensor
• 3G Mobile Hotspot
• DivX® H.264, H.263 Capable
ENHANCED USER EXPERIENCE
•Android 4.1.2
• Home Screens – customize 5 or 7 screens with shortcuts to apps, favorites, and widgets
• QWERTY Keyboard with Swype® – use one continuous finger motion to input text when composing a
message
•Exchange Support – improved security, remote wipe capability for Exchange administrators, support for
Exchange calendars in the Calendar application, auto-discovery for easy setup and syncing of an
Exchange account,* and Global Address Lists lookup in the Email application
• Proximity Sensor – locks the touch screen and buttons while talking on the phone
•Motion Sensor – Digital compass , Accelerometer
• USB Charging via Computer
• Airplane Mode (RF Off)
*Available for Exchange 2007 and higher.
DESIGN
•Sleek and Stylish Design
• 4.7” HD Display
• Capacitive Touch Screen – Glass with fast and accurate response
• Touch Vibration for Tactile Feedback*
• Micro USB Charging Port
*Only available on certain interactions with the touch screen.
MOBILE MEDIA
•Android Market™ – browse and download thousands of free and paid apps from around the world†
• Live Wallpaper – dynamic, animated backgrounds

- 6 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
5
CAMERA/VIDEO
• Full Web Browsing
• Connect to Social Networks – send quick updates to Twitter™, Facebook®, MySpace™,* or added
social networks†
•Mobile Instant Messaging – Google Talk™, AIM®,* Yahoo!® Messenger,* Windows Live™*†
• Gmail™ and Email – mobile personal and corporate email†
• Visual Voice Mail†
• Text, Picture, Video, and Voice Messaging†
•Flash 10.1 for Mobile Devices
•Java Support
*Applications downloaded from Android Market.
• 8MP AF with flash, 1.3MP VT CMOS Image sensor and Camcorder*
• Camera Resolutions: 8M(2560 x 1920), 3M(2048 x 1536), W3M(2240 x 1344), 1M(1280 x 960), W1M(1280 x
768)
• Camera and Video Zoom: up to 4x
• Image Editor: Zoom, Exposure, Artistic Effect, Color, Adjustment
• Brightness, ISO, White Balance,* Color Effects, Scene Mode, Self-Timer
• Continuous Shot – take 6 shots in quick succession
• Video Resolutions: FHD(1920 x 1080), HD(1280 x 720), TV(720 x 480), VGA(640 x 480), QVGA(320 x
240)(MMS), QCIF(176 x 144)(MMS)
• Video Recording Time: up to 60 seconds (sending) or 120 minutes (saving)**
*Available in both video and camera modes.
**Depends on available memory.
MULTIMEDIA
• Video Player for AVI, WMV, MP4, MKV, 3GP, and 3G2 Formats
• Music Player for MP3, WMA, and Unprotected AAC
• Stereo Sound via Headset or Bluetooth
• Multitask While Playing Music in the Background
•Music Library – Organized by Artists, Albums, Songs, Genres, Folders and Playlists
• Repeat and Shuffle Music Playback Modes

- 7 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
1. Introduction
6
TOOLS & DATA
• microSD Memory Slot with Support for up to 32GB Storage
• USB Mass Storage – transfer files between microSD™ card and PC*
*USB cable (sold separately) and microSD card (included) required.
BLUETOOTH®
• Version: 4.0
•Save up to 100 Bluetooth Pairings*
• Supported Profiles: headset, hands-free, object push, advanced audio distribution (stereo), audio/video
remote control, file transfer, phone book access, message access, serial port
• Listen to Music with Optional Stereo Bluetooth Headset**
• Send User-Generated Pictures (JPEG) and Videos via Bluetooth Wireless Technology
*Depends on available memory.
**Accessories sold separately.
VOICE/AUDIO
• One-Touch Speakerphone*
•Wide Voice Extension*
•Voice Clarity*
• Voice Commands
• Voice-Activated Dialing
•Text to Speech
• MP3 Music Ringer Support (clips from hit songs)†
• Voice Memo Recording
• 20 Unique Ringtones + Vibrate and Silent Modes
• TTY Support
• Hearing Aid Compatible M3/T3
*Only available during a call.
•Android Apps: Browser, Calculator, Calendar (Corporate or Google), Camera, Clock, Contacts, Email, Gallery,
Gmail, Market, Messaging, Music, Phone, Settings, Voice Dialer, Voice Recorder, Voice Search
•Metro Navigator® – spoken turn-by-turn directions showing real-time traffic
•Wi-Fi Connectivity – IEEE 802.11b/g/n

- 8 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
• Phone Book – unlimited fields* for numbers, emails, physical addresses, IM screen names, notes,
nickname, web addresses, special dates, and a picture ID**
• FOTA Capable – upgrade firmware over the air†
•S-GPS and A-GPS Support for Enhanced Location Accuracy
*Depends on available memory.
**Dependent on photos stored in your gallery.
SPECIFICATIONS
•Technology: GSM/ WCDMA/GPS/ WiFI
•Frequencies:
1. Introduction
Support Band TX Freq (MHz) RX Freq (MHz)
GSM850 824-849 869-894
GSM900 880-915 925-960
DCS1800 1710-1785 1805-1880
PCS1900 1850-1910 1930-1990
W2100(B1) 1920-1980 2110-2170
W1900(B2) 1850-1910 1930-1990
W850(B5) 824-849 869-894
W900(B8) 880-915 925-960
BT/WiFi 2400 MHz ~ 2483.5 MHz
GPS 1574.42 MHz ~ 1576.42 MHz
7

- 9 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
8
•Data Transmission: EDGE, GPRS (Class 12) , HSPA+(Cat. 24) HSUPA(Cat. 6)
• Dimensions: 128.4(H) x 66.5(W)x 9.4(D) (mm)
• Weight: 120g ( with Battery)
•Display: 4.7”, HD1280x 720 pixels, TFT
•Standard Battery: 2,150[mAh]
• Internal Memory Size: 8 GB
•MicroSD™ Memory Slot: up to 32GB memory card*
ACCESSORIES
•Standard Battery*
• Travel Adapter and USB Data Cable*
• Bluetooth Headset (Optional)
• Bluetooth Hands-free kit (Optional)
• Stereo Headset (Optional)
• Vehicle Power Charger (VPC) (Optional)

2. PERFORMANCE
- 10 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. PERFORMANCE
2.1 Product Name
LG-D605 : WCDMA850/900/1900/2100+EGSM/GSM850/DCS/PCS/
(HSDPA Cat. 24 / HSUPA Cat.6 / EDGE,GPRS Multislot class 12)
2.2 Supporting Standard
LG-D605 Product SPEC
3
2.1 Product Name
LG-D605 : WCDMA850/900/1900/2100+EGSM/GSM850/DCS/PCS/
(HSDPA Cat. 24 / HSUPA Cat.6 / EDGE,GPRS Multislot class 12)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard
WCDMA(FDD1,2,5,8)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
Frequency Range
WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD2) TX: 1850 – 1910 MHz
WCDMA(FDD2) RX: 1930 – 1990 MHz
WCDMA (FDD8) TX : 882 – 912 MHz
WCDMA (FDD8) RX : 927 – 957 MHz
WCDMA(FDD5) TX : 824 – 849 MHz
WCDMA(FDD5) RX : 869 – 894 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0
2.3 Main Parts : GSM Solution
Item
Part Name
Comment
Digital Baseband MSM8230 : Qualcomm
Analog Baseband MSM8230 : Qualcomm
RF Chip WTR2605 : Qualcomm
LG-D605 Product SPEC
3
2.1 Product Name
LG-D605 : WCDMA850/900/1900/2100+EGSM/GSM850/DCS/PCS/
(HSDPA Cat. 24 / HSUPA Cat.6 / EDGE,GPRS Multislot class 12)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard
WCDMA(FDD1,2,5,8)/EGSM/GSM850/DCS1800/PCS1900
with seamless handover
Phase 2+(include AMR)
Frequency Range
WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD2) TX: 1850 – 1910 MHz
WCDMA(FDD2) RX: 1930 – 1990 MHz
WCDMA (FDD8) TX : 882 – 912 MHz
WCDMA (FDD8) RX : 927 – 957 MHz
WCDMA(FDD5) TX : 824 – 849 MHz
WCDMA(FDD5) RX : 869 – 894 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0
2.3 Main Parts : GSM Solution
Item
Part Name
Comment
Digital Baseband MSM8230 : Qualcomm
Analog Baseband MSM8230 : Qualcomm
RF Chip WTR2605 : Qualcomm
2.3 Functions of Major Semi-Conductors

2. PERFORMANCE
- 11 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2.4 HW Features
LG-D605 Product SPEC
4
2.4 HW Features
Item Feature Comment
Form Factor DOP type
Battery
1) Capacity
Standard : Li-ion, 2150mAh
2) Packing Type : Hard Pack
Size Standard :
128.4 x 66.5 x 9.4mm
Weight 120g With Battery
RX sensitivity
WCDMA(FDD1) : -106 dBm
WCDMA(FDD2) : -106 dBm
WCDMA(FDD5) : -106 dBm
WCDMA(FDD8) : -106 dBm
EGSM : -105 dBm
GSM850 : -105 dBm
DCS 1800 : -105 dBm
PCS 1900 : -105 dBm
GPRS compatibility GPRS Class 12
EDGE compatibility EDGE Class 12
TX output
power
LTE/
WCDMA/
GSM/
GPRS
WCDMA : 24dBm/3.84MHz,+1/-3dBm
EGSM : 33 dBm
GSM850 : 33 dBm
DCS1800 : 30.5 dBm
PCS 1900: 30 dBm
Class3(WCDMA)
Class4 (EGSM)
Class4 (GSM850)
Class1 (PCS)
Class1 (DCS)
EDGE
GSM 850 : 27 dBm
GSM 900 : 27 dBm
DCS 1800 : 26 dBm
PCS 1900 : 26 dBm
E2 (GSM850)
E2 (GSM900)
E2 (PCS)
E2 (DCS)
SIM card type Normal SIM(2FF) 3V /1.8V
Display Main LCD : TFT LCD
(4.7”, WVGA 1280X720 pixels HD)
Built-in Camera 8M AF Camera with flash + 1.3M VT
Status Indicator Yes
Keypad Full Touch Screen
Side Key : 4
Side Key : Power On
Volume up/down
Quick Memo
ANT Main : Internal Fixed Type
System connector 5 Pin u-USB

2. PERFORMANCE
- 12 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
5
Ear Phone Jack 3.5 pi type
PC synchronization Yes
Memory 8GB eMMC
8Gb LPDDR2
Speech coding FR, EFR, HR, AMR
Vibrator Built in Vibrator
Blue Tooth Bluetooth 4.0 + BLE
MIDI(for Buzzer
Function) SW Decoded 72Poly
Music Player MP3/WMA/AAC/MIDI/EAAC+/HEAAC/OGG
Video Player MPEG4, H.264
Camcorder MPEG4 or H.263
Voice Recording Yes
Speaker Phone mode
Support Yes
Travel Adapter Yes
CDROM No
Stereo Headset Yes
Data Cable Yes
T-Flash
(External Memory) Yes ( Up to 32GB )

2. PERFORMANCE
- 13 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
6
1) RSSI Display
RSSI BAR GSM WCDMA Comment
BAR 5->4 - 91dBm± 2dB - 88dBm± 3dB
1. Call Connected
& CPIPH Level=-
3.3
BAR 4->3 - 96dBm± 2dB - 93dBm± 3dB
BAR 3->2 - 99dBm± 2dB - 98dBm± 3dB
BAR 2->1 - 103dBm± 2dB - 103dBm± 3dB
BAR 1->0 - 105dBm± 2dB - 108dBm± 3dB
Measure RSSI after 10 seconds when you change power
2) Charging Time
Under 3 hours for 2150mAh charging
3) Travel Charger
Input : 100 ~ 240 V, 50/60 Hz
Output : 5.0 V, 850 mA
4) Battery Type
Li-ion Battery Pack, 2150 mAh
Standard Voltage : 3.8 V, Battery Full Charge Voltage : 4.35V
5) Current Consumption
Specification
GSM WCDMA
Standby 8.5mA @ P.P 5 9mA @ DRX 7
Talk 400mA @ GSM LVL 5 800mA @ Max pwr
400mA @ TX 10dBm
Power Off Mode 300uA under
LG-D605 Product SPEC
6
1) RSSI Display
RSSI BAR GSM WCDMA Comment
BAR 5->4 - 91dBm± 2dB - 88dBm± 3dB
1. Call Connected
& CPIPH Level=-
3.3
BAR 4->3 - 96dBm± 2dB - 93dBm± 3dB
BAR 3->2 - 99dBm± 2dB - 98dBm± 3dB
BAR 2->1 - 103dBm± 2dB - 103dBm± 3dB
BAR 1->0 - 105dBm± 2dB - 108dBm± 3dB
Measure RSSI after 10 seconds when you change power
2) Charging Time
Under 3 hours for 2150mAh charging
3) Travel Charger
Input : 100 ~ 240 V, 50/60 Hz
Output : 5.0 V, 850 mA
4) Battery Type
Li-ion Battery Pack, 2150 mAh
Standard Voltage : 3.8 V, Battery Full Charge Voltage : 4.35V
5) Current Consumption
Specification
GSM WCDMA
Standby 8.5mA @ P.P 5 9mA @ DRX 7
Talk 400mA @ GSM LVL 5 800mA @ Max pwr
400mA @ TX 10dBm
Power Off Mode 300uA under
1) RSSI Display
5) Current Consumption
Measure RSSI after 10 seconds when you change power
2) Charging Time
Under 3 hours for 2150mAh charging
3) Travel Charger
Input : 100 ~ 240 V, 50/60 Hz
Output : 5.0 V, 850 mA
4) Battery Type
Li-ion Battery Pack, 2150 mAh
Standard Voltage : 3.8 V, Battery Full Charge Voltage : 4.35V

2. PERFORMANCE
- 14 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
7
6) Battery Bar
Battery Bar Specification Battery Bar Specification
Bar 20(Full) 98% Bar 9 -> Bar 8 43% -> 42%
Bar 20 -> Bar 19 98% -> 97% Bar 8 -> Bar 7 38% -> 37%
Bar 19 -> Bar 18 93% -> 92% Bar 7 -> Bar 6 33% -> 32%
Bar 18 -> Bar 17 88% -> 87% Bar 6 -> Bar 5 28% -> 27%
Bar 17 -> Bar 16 83% -> 82% Bar 5 -> Bar 4 23% -> 22%
Bar 16 -> Bar 15 78% -> 77% Bar 4 -> Bar 3 18% -> 17%
Bar 15 -> Bar 14 73% -> 72% Bar 3 -> Bar 2 13% -> 12%
Bar 14 -> Bar 13 68% -> 67% Bar 2 -> Bar 1 8% -> 7%
Bar 13 -> Bar 12 63% -> 62% Bar 1 -> Bar 0 3% -> 2%
Bar 12 -> Bar 11 58% -> 57% Power off 2% ->1%
Bar 11 -> Bar 10 53% -> 52% Low battery pop-up 15% , 5%, 1%
Bar 10 -> Bar 9 48% -> 47%
6) Battery Bar

2. PERFORMANCE
- 15 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
8
2.5 SW Features
Function Detail Item O / X Specification Etc.
OS OS O Android 4.1
JB
Data Circuit X Video Telephony using
64kbps CSD
Packet O
Connectivity
Infrared (IrDA) X
Bluetooth O Ver. 4.0
Wi-Fi O 802.11 a/b/g/n
USB O 2.0 HS
USB Mass storage X MTP support
RS232 X
DLNA O
Voice Function
Voice Recording O
Voice Command
X Digit Dial
X Name Dial
X Menu
X Phonebook Searching
Answering machine X Driving, Meeting, user
define(absent)
Memory User Memory
O Total 8GB eMMC/ 8Gb DDR +
external MicroSD
O Total User Memory 3.4GB (w/o MicroSD)
O MMS
O Pictures (Still Image &
Moving Image)
O MP3
(Music Contents)
X Java Contents
O Wallpaper
O Ringtone
O External memory (microSD) up to 32GB
2.5 SW Features

2. PERFORMANCE
- 16 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
9
Camera Module O 8MP BSI
Auto Focus O Auto, Manual, Face tracking
Digital Zoom O X4 with 16 step
Capture Resolution O
8M(3264x2448),
W6M(3264x1836),
5M(2560x1920),
3M(2048x1536),
W3M(2304X1296),
1M(1280x960),
W1M(1536x864)
Continuous Shot O
Quality X
Preview Image O 960x720(Normal),
1280x720(Wide)
TV-Out X
Flash O
Filter O None/Mono/Sepia/Negative
Timer O Off / 3 secs / 5 secs/10 secs
JPEG Encoding
O JPEG
O Thumbnail
O
3264x2448,3264x1836,2560
x1920,2048X1536,2304x129
6,1280x960,1536x864
JPEG Decoding
O JPEG
O Min, Max Supported by Gallery
Panorama Shot O
Album&Slide show O Slide show Supported by Gallery

2. PERFORMANCE
- 17 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
10
Camera
(Movie Capture)
Movie Resolution O
1920x1088, 1280x720,
720x480,640X480,
320x240, 176x144
Filter O Same as the Still Capture
Quality X
MPEG Visual Bit Rate X
Default code is H.264
And video Bit rate is
17Mbps
We can support MPEG-4,
but the bit rate is depend
on Application setting
Audio Encode O AAC, AMR-NB
Audio Decode O AMR
Movie Recode O Recode, Stop, Pause,
Resume
Movie Playback O Play, Stop, Pause
Stream Format (Mux) O 3gp
Stream Format (Demux) O 3gp
Recoding Time O Real Time Recoding
TV-Out X
Audio Multimedia Voice Codec O AMR
AAC /AAC+/ EAAC+ O
MP3, WAV O
WMA O
Midi O Midi Type0, Midi Type1,
SP-MIDI
Music ringtone O MP3, AAC, AAC+, AAC-LC,
XMF 1.01, AMR
AMR-NB O
Music player skin O Music Player
FM Radio O
Speakerphone O

2. PERFORMANCE
- 18 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
11
Multimedia
MPEG4/H.263 O
H.264 O
WMV O
Normal View X Moving Image Capture &
Movie Contents
contents size
Wide View O Full Screen mode
Custom DTV Zoom X
Other Features
File Viewer O doc, xls, ppt, gif, jpg
Macromedia Flash Lite X Not Available
e-Book/e-Comic Book X
Flight Mode O
Internet Browser
WAP
(Windows Mobile 6.0 IE
Mobile )
X version 2.0
X WML1.3
O XHTML1.1
O HTML4.01 Partially support - HTML 5
Java
MIDP X
J2ME support X
Game & Contents X
CLDC X
Call Management Call waiting O
Flash Flash Game X
Streaming Service
H.263+AAC/AMR-NB O
MPEG4+AAC
/AMR-NB O
WMV9 X
Support WMV main and
base profile except
advanced profile
DRM OMA DRM
O Forward Lock
O Separate Delivery
O Combined Delivery - Count-
only
OTA OTA O OTA 1.1
Display
RSSI O 0~5 Levels
Battery Level O 0~21 Levels
RTC O
Multi Language O

2. PERFORMANCE
- 19 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
12
Quick Access Mode O Phone / Contacts /
Messaging / Apps
PLMN/Service Indicator O
Screen Timeout
O 15s, 30s, 1min, 2min, 5min,
10min, 15min, Never
Dual Clock O widget
Normal Features
Last Dialed Number O
Last Received Number O
Last Missed Number O
Scratch Pad Memory X

2. PERFORMANCE
- 20 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LG-D605 Product SPEC
13
Call Management Call Waiting O
Call Swap O
Call Retrieve O
Auto Answer X
Automatic Redial X
Calling Line
Identification O
Full Call divert O
Speed Dialing O
Last Number Redial X
Multiparty Call
(Conference Call) O
Explicit Call Transfer O
Network
Automatic Network
Selection O
Manual Network
Selection O
Network Service
Status O
DTMF
DTMF Signaling O
DTMF Enable &
Disable X
Audio
Key Tone Volume O 0 ~ 7 Levels
Ring Tone Volume O 0 ~ 7 Levels
Ring Tone Pattern O
Ring Type Silent O Vibrator, Silent, Ring (Indicator)
Earpiece Volume O 1 ~ 7 Levels
Mute O
Cell Broadcast
Read Cell Broadcast O
Cell Broadcast
Categories X
Cell Broadcast
Message Language O
Supports filtering with language IDs
(German,Italian,French,Spanish,
Dutch,Swedish,Danish,Portuguese,Finnish,Norw
eggian
,Greek,Turkish,Hungarian,Polish,Czech)
