LG-TM540
User Guide
CDMA/AMPS/PCS TRI-MODE PHONE

For more information about RF exposure, please visit the FCC website at www.fcc.gov
FCC RF EXPOSURE INFORMATION
In August 1996 the Federal Communications Commission (FCC) of the United States
with its action in Report and Order FCC 96-326 adopted an updated safety standard
for human exposure to radio frequency electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The design of this
phone complies with the FCC guidelines and these international standards.
Use only the supplied or an approved antenna. Unauthorized antennas,
modifications, or attachments could impair call quality, damage the phone, or result in
violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged antenna comes into
contact with the skin, a minor burn may result. Please contact your local dealer for
replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with the back of the phone
kept 1.5 cm. from the body. To maintain compliance with FCC RF exposure
requirements, use only belt-clips, holsters or similar accessories that maintain a 1.5
cm. separation distance between the user’s body and the back of the phone, including
the antenna, whether extended or retracted. The use of third-party belt-clips, holsters
and similar accessories should not contain metallic components in its assembly. The
use of accessories that do not satisfy these requirements may not comply with FCC
RF exposure requirements, and should be avoided.
WARNING! Read this information before using your phone

Contents
Introduction
Highlights
Important Information
Check Accessories
Before You Start
FCC RF EXPOSURE INFORMATION
Chapter 1. Getting Started
Cautions
Phone Overview
On screen Icons
Chapter 2. Basic Functions
Turning the Phone On and Off
Making a Call
Correcting Dialing Mistakes
Receiving Calls
Using Quick Mode
Call Waiting
Mute
Redialing Calls
Adjusting the Volume
Power Save Mode
Signal Strength
Emergency Dialing
Mini Display
Speed Dialing
Caller ID
Phone Book Features
Chapter 3. Menu Features
General Guidelines to MENU Access and Settings
Sound
Display
System
Features
Utility
Security
Voice Services
Browser Start
Chapter 4. Book Features
Call History
Phone Book
Function of Scheduler
General Guidelines to Scheduler Access and Settings
Scheduler Item Descriptions
Schedule
Wake Up
Viewing Your Telephone Number
Chapter 5. Message Features
Voice

Send Msg
New Text
Old Text
Erase All
Setting
Chapter 6. Functions used during a call
Mute
Memo
Recording
Key Tone
Voice Privacy
Chapter 7. Accessories
Chapter 1. Getting Started
Cautions
lUsing the phone in proximity to receiving equipment (i.e., TV or radio) may cause
interference.
lKeep your phone in a safe place when not in use.
lOnly use the batteries, antennas, and chargers provided by LG. Using the wrong
accessories could void your warranty.
lOnly authorized personnel should service the phone and its accessories. Faulty installation
or service may result in accidents and consequently invalidate the warranty.
lDo not hold the antenna while the phone is in use.
lDo not use the phone in designated “no cellular phone use” areas.
lDo not expose the phone to high temperature or humidity.
lAvoid getting your phone wet. If the phone gets wet, turn the power off immediately and
remove the battery pack. If the phone is mal-functional, return it to the dealer for service.
lAvoid shock or impact on the phone.
Phone Overview
Function Key Descriptions
Lamp The red light goes on when you use the power key to turn on the phone and when there are
incoming calls and messages.
LCD screen Displays messages & indicator icons.
END/PWR Used to turn power on/off. This key disconnects a call. Using this key, you can also exit out of
a menu back to the phone’s standby display without changing the setting.
SEND Allows user to place or answer calls.
Mouse Key This mouse key allows quick access to text and voice mail notification messages. calendar,
outgoing call log, phonebook Find name.
Cellcase Close the active cellcase to the terminate a call in progress.
Open the active cellcase to answer an incoming call.
Soft Keys
The current operation of a soft key is defined by the word at the bottom of the display.
Soft Keys 2 :
If you press this key once in a menu, you can go back one level and if you press and hold the
key in a menu, you can go back to the standby display.
Side Keys These keys enable you to adjust keybeep volume (in standby mode) and earpiece volume (in a
call status).
Scroll Keys These keys are used to scroll through the memory locations and menu items. -In the standby status, set the manner mode by pressing the button. (for 2 seconds)
-In the standby status, set the lock function by pressing the button. (for 2 seconds)
Alphanumeric
Keypad These keys enable you to enter numbers and characters and choose menu items.
Clear Key

On screen Icons
The phone screen displays several onscreen icons and onscreen icons appears when the phone is
power on.
Icons Descriptions
Displays the strength of the signal received by the phone and current signal
strength is indicated as the number of bars displayed on the screen.
No service
The phone is not receiving a system signal.
In use
A call is in progress.
No icon indicates the phone is in standby mode.
Digital indicator
Digital service is available.
Analog indicator
Analog service is available
Indicates that a text message or voice mail has been received
Roaming
The phone is outside of its home service area.
Charge level
Indicates battery charge level.
D
Chapter 2. Basic Functions
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery pack or connect the phone to an external power source such as the
cigarette lighter adapter or car kit.
2. Press [END/PWR] for a few seconds until the red light on the top of the phone flashes.
lFully extend the antenna for the best performance.
<Note> Like any other radio device, avoid any unnecessary contact with the antenna while your
phone is on.

Turning the Phone Off
1. Press and hold until display screen will be turned off, and then release the key.
2. Protect the antenna by pushing it back into the phone, if extended.
Making a Call
When you make a call, follow these simple steps:
1. Make sure the phone is turned on.
lIf not, press [END/PWR].
2. Enter the phone number with area code, if needed.
3. Press [SEND].
lIf the phone is locked, enter the lock code.
l“Call Failed” indicates that the call di d not go through.
4. Press [END/PWR] to disconnect the call.
Correcting Dialing Mistakes
If you make mistakes in dialing a number, press [CLR] key once to erase the last entered digit or
hold down [CLR] for at least two second to delete all digits, or simply press soft key 2 [BACK] to
exit dialing state.
Receiving Calls
1. When the phone rings, open cellcase or If cellcase is open, press any key (except [END/PWR],
[5][6], [3v4]) to answer.
lIf you press the key [END/PWR], Side Keys ([5][6]) once when you receive a call, you
can hold the present call and ring sound or vibration stops. If you press the [END/PWR]
key, Side Keys ([5][6])twice, the present call is terminated.
2. Press [END/PWR] to disconnect the call.
In call waiting mode, the present call is on hold as you answer another incoming call.
This service is provided by your service provider.
When the call waiting function is activated, your phone will beep to let you know if you have an
incoming call. Your phone may also display the incoming caller’s identification.
Dialing a call from Phone Book
You can place a call from any memory location either by speed dialing or by pressing [SEND] while
looking up the memory location.
One-Touch Dialing : One-touch dialing is a convenient feature which enables you to dial
frequently used numbers in your personal phone book by pressing a key (for memory location 1
through 8).
lEntry 9 is designated to Emergency Call.
lFor locations 1 to 8, you can use one-touch dialing (if enabled, see “One-Touch” on page
37.) by pressing and holding down the key corresponding to the memory location.
OR

lPress digit, then press [SEND].
Two-Touch Dialing (Speed Dialing) : This dialing feature enables you to dial numbers in your
phone book through two keys (for locations 10 to 99).
1) Press the first digit.
2) Press and hold the key of the second digit.
OR
1) Press the first and second digits, then press [SEND].
Three-Touch Dialing (Speed Dialing) : This dialing feature enables you to dial numbers in your
phone book through three keys (for location 100 to 199).
1) Press the first and second digits.
2) Press and hold the key of the third digit.
Dialing from a Memory List
1) From a memory list, press the scroll keys to go to the memory location you want.
2) Press [SEND].
Dialing from a Memory Location.
On viewing and checking the memory location to call, press [SEND].
Chapter 3. Menu Features
General Guidelines to MENU Access and Settings
1. Press Soft Key [Menu]. The three menu items will appear on the display screen.
2. Press[v]to go through the list of menu features, or use the side keys.
3. Press the corresponding number to the menu item that you want to select. Then the sub-menu
list will appear on the screen.
4. Press the appropriate key to select the sub-menu you want to access.
5. Select preferred settings, using the [v]keys. Press Soft Key 2 [Back] to go one step backward
while accessing menu or selecting settings.
6. Press Soft Key 1 [Ok] to save the settings or Soft Key 2 [Back] to cancel without saving.
Sound ([Menu]+[1])
Ring Sound ([Menu]+[1]+ [1])
Select the ringer sound with [5] [6]or [v] key. The ring sound will notify that you have an
incoming call.
Ring Type ([Menu] +[1]+[2])
Select one out of four ring types (Ring, Vibrate, Vib+Ring and Lamp) with [5] [6]or [v] key.
Ring & Vibrate Volume ([Menu] +[1]+[3])
Adjust the volume of the ringer using the [5] [6]or [v] key.
Key Tone ([Menu] +[1]+[4] )
Set Key Tone length and touch tone playback speed.
lNormal : Sends out a tone for a fixed period of time only if you keep the key pressed.
lLong : Sends out a continuous tone for as long as you keep the key pressed.

Key Volume ([Menu] +[1]+[5] )
Adjust the key beep volume (the volume of sound on key pressing).
Ear Volume ([Menu] +[1]+[6] )
Adjust the earpiece volume during a call, by pressing the side keys.
Alerts ( [Menu]+[1]+[7] )
1. Fade ([Menu]+[7]+[1] )
Set an alert to inform you when you have lost a call or lose services.
2. Minute ([Menu]+[7]+[2] )
Alerts you 10 seconds before the end of every minute during a call.
3. Service ([Menu]+[7]+[3] )
If on, alerts you when service changes.
When you enter a service area, the phone displays “Entering Service Area” message.
When you leave a service area, the phone displays “Leaving Service Area” message.
4. Call Connect ([Menu]+[7]+[4] )
Alert tones notify the user of the time when the call is connected.
Display ([Menu]+[2] )
Backlight ([Menu]+ [2]+[1] )
Allows you to select how long or when the display screen and keypad are backlit. The backlight is
turned off 10 seconds after the last key is pushed. the backlight is turned off 30 seconds after the
last key is pushed. “On when Cellcase open” means that the backlight is always on while Cellcase
is open. “Always on” means that the backlight is on regardless of the Status of Cellcase. Choosing
“Always on”significantly decreases talk time. “Always off” means that the backlight is never on.
Contrast( [Menu] [2]+ [2] )
Banner ( [Menu]+ [2]+[3] )
Theme ( [Menu]+ [2]+[4] )
You can set up the screen displayed on the LCD screen in the standby mode.(Default, Star theme)
Language ([Menu]+ [2]+[5] )
Version ([Menu]+ [2]+[6] )
View the software and PRL version.
Features ([Menu]+[3])
Data ([Menu]+ [3] +[1])
In “Data/Fax” setting, data and fax can be transmitted. Wireless data communication services refer
to utilization of subscriber terminals for access to internet with personal computer or laptops at
8Kbps or at maximum of 13Kbps.
lData In : This setting enables the subscriber terminal to receive data calls.
lFax In : This setting enables the subscriber terminal to receive fax transmittals.
Auto Answer ([Menu]+ [3] +[2])
Select the ring type before the phone automatically answers a call. This feature is most commonly
used with the car kit.
off lafter 1 ring(or melody 5 seconds)

lafter 3 rings(or melody 10 seconds)
lMachine Enable
When you have incoming call, the phone automatically response with pre-recorded voice message
and record caller’s speech after 3 rings.
Auto Retry ([Menu]+ [3]+[3])
Set the length of time the phone waits before automatically redialing a number when the
attempted call fails.
loff / every 10 seconds / every 30 seconds / every 60 seconds
One-Touch ([Menu]+ [3]+[4])
Enable/Disable one-touch dialing.
Voice Privacy ([Menu]+ [3]+[5])
Set the voice privacy feature for CDMA calls as “Enhanced” or “Standard : CDMA offers inherent
voice privacy. Check with your service provider for availability of the enhanced voice privacy mode.
Audio AGC ([Menu]+ [3]+[6])
SIO Config ([Menu]+ [3]+[7])
If you want to use HSPD mode, you should set the baud rate as 230,400 bps in the menu 2 (Data
Baud menu).
1. Port Map (DATA DIAG OPTION)
U1 U2 -- : When using UART 1 and UART2 simultaneously
U1 -- HFK : When using UART 1 only for normal case
2. Data Baud (Data Baud Set)
AUTOBAUD : Default Data Baud Rate (ipr = 0)
9,600/19,200/38,400/57,600/115,200/230,400 : Optional Data Baud Rate
3. Diag Baud (Diag Baud Set)
38,400 : Default Diag Baud Rate
115,200 : Optional Diag Baud Rate
System ([Menu]+ [4])
System Select ([Menu]+ [4]+[1])
Choose setting to control which cellular company your phone uses. Leave this setting as default
unless you want to alter the system selection. (As instructed by your service provider.)
lHome is B (Automatic_B, Home only, Automatic_A) is displayed.
Set NAM ([Menu]+ [4]+[2])
Select the phone’ s NAM (Number Assignment Module) if the phone is registered with multiple
service provides.
Auto NAM ([Menu]+ [4]+[3])
Allows the phone to automatically switch to one of the programmed Telephone No. if it is operating
in the corresponding service provider area.
Force Call ([Menu]+ [4]+[4])
Make next call in analog mode. You have 30 seconds to place an analog call. This feature is
typically used for data applications.

TTY Mode ([Menu]+ [4]+[5])
To enable or disable TTY mode, select‘TTY Mode “Enable”/”Disable”‘using [5] [6]or [v] key.
If TTY mode is enabled, TTY Features is activated during call.
Security ([Menu]+[5])
Lock code is commonly last 4 digit of your phone. (You must enter the lock code after pressing
[Menu] ). If you need to modify the password, you may modify it using the “New Lock Code” of
Security.
Lock Mode ([Menu]+ [5]+[1])
Helps you to protect your phone from unauthorized use and once the phone is locked, the phone is
restricted from making calls until the lock code is entered.
However you can still receive phone calls and make emergency calls while your phone is locked.
“Never”means that the phone is never locked (Lock mode can be used). When locked, you can
only make emergency calls or receive incoming calls. “On power up” means that locked the phone
when the phone is turned on. “Always”means that the phone is always locked.
Restrict ([Menu]+ [5]+[2])
Set call restrictions to “Yes” or “No”. If set to “Yes”, you can only make calls to emergency numbers
and phone numbers in Phonebook Entry. You can still receive calls in restrict mode. Check with
your service provider.
Clear Call ([Menu]+ [5]+[3])
Allows you to delete all the telephone number saved in the “Call History”.
Clear Data ([Menu]+ [5]+[4])
Deletes all information saved in the memory location(001-199) (Entry 9 is designated to
Emergency Call). Be careful since any deleted information is not recoverable.
Emergency # ([Menu]+ [5]+[5])
To enter 3 emergency numbers ([Edit] →enter →number →[Save] →[v]→). You can call these
numbers and 911 even when the phone is locked or restricted.
New Lock Code ([Menu]+[5]+[6])
New Lock Code allows you to enter a new four-digit lock code number. For confirmation, it will ask
you to enter the new lock code twice. This is the same number as the pin code.
Voice Service ([Menu]+[6])
Allows you to make a call by simply saying the programmed word and when you are not available
to answer the phone, the caller can leave the message into voice mail and you can playback the
message later.
-Voice Dialing :
You can make a call by simply saying the programmed word.
-Voice Recording :
You can record conversation over the phone.
-Voice Memo :
When you are not available to answer the phone, the caller can leave the message into voice
mail.
-Auto Answering Machine :
When you are not available to answer the incoming call, you may set your phone as auto
