LG LG800G User manual

Phone Components
Phone Components Installing the SIM card and the handset batteryInstalling the SIM card and the handset battery
LG800G Quick Start Guide
• Depending on the software installed or your service provider or
country, some of the descriptions in this guide may not match your
phone exactly.
• Depending on your country, your phone and accessories may
appear different from the picture in this guide.
Bluetooth QD ID B000000 P/N: MMBB0000000 (1.0)
*Many of the features and services described are network dependent and may require
additional subscription and/or usage charges. Not all features are available for purchase
or use in all areas. Other conditions and restrictions may apply. See carrier for more
information.
© 2010 LG Electronics, Inc.
Earpiece
Call key
Dials a phone number and
answers incoming calls.
End key
Clear key
Go back to a previous screen.
Using your touch screen
Touch screen tips
• To select an item, touch the centre of the icon.
• Do not press too hard. The touchscreen is sensitive enough to pick up a
light, firm touch.
• Use the tip of your finger to touch the option you require. Be careful not
to touch any other keys.
• Whenever your LG800G is not in use, it will return to the lock screen.
Control the touch screen
The controls on the LG800G touch screen change dynamically
depending on the task you are carrying out.
Calls
Making a Call
1Touch to open the keypad.
2Key in the number using the keypad.
3Touch to initiate the call.
TIP! To enter + for making an international call, press and hold
0+
.
Press the power key to lock the touchscreen to prevent calls being made
by mistake.
Making a call from your contacts
1From the home screen touch to open the Contacts.
2Tap the Name field box on the top of the screen and enter the first few
letters of the contact you would like to call using the keypad.
3From the filtered list, touch the Call icon next to the contact you want
to call. The call will use the default number if there is more than one
for that contact.
4Or, you can touch the contact name and select the number to use if
there is more than one for that contact to use. You can also touch
to initiate the call to the default number.
Answering and rejecting a call
When your phone rings, press key to answer the call.
To mute the ringing, touch on Silent tab in alerting screen. This is useful
if you forgot to change your profile to Silent for a meeting. Touch on
Reject tab to reject an incoming call in alerting screen.
Calls
Changing the common setting
1Touch Call in the Settings menu.
2Scroll and touch Common settings.
• Call reject - Slide the switch left for ON.You can touch the Reject list to
choose All calls, Contacts, Groups, All unknown callers and All unknown
numbers.
• Send my number - Choose whether to display your number on an
outgoing call.
• Auto-redial - Slide the switch left for ON or right for OFF.
• Answer mode
Press send key: Allows you to only answer an incoming call by
pressing the key.
Press any key: Allows you to answer an incoming call by pressing any
key, except the key.
• Minute minder - Slide the switch left to ON to hear a tone every
minute during a call.
• BT answer mode - Select Handsfree to be able to answer a call using a
Bluetooth headset, or select Handset to press a handset key to answer
a call.
• Save new number - Select ON or OFF to save a new number.
Contacts
Searching for a contact
1Touch Contacts.
2You see a list of contacts. Typing in the first letter of a contact’s name
in the Name field will jump the menu to that alphabetical area of the
list.
Adding a new contact
1Touch Contacts and touch Add.
2Choose whether to save the contact to your Internal memory or SIM.
3Enter your first and last name.
4You can enter up to five different numbers per contact.
5Add an email addresses. You can enter up to two different email
addresses per contact.
6Assign the contact to one or more groups.
7Touch Save to save the contact.
3Insert the SIM card.
4Insert the battery pack.
5Attach the back cover.
6 Charge the battery.
Installing the SIM Card
When you subscribe to a cellular
network, you are provided with
a plug-in SIM card loaded with
your subscription details, such as
your PIN, any optional services
available and many others.
Important!
The plug-in SIM card and its
contacts can be easily damaged
by scratches or bending, so be
careful when handling, inserting
or removing the card. Keep all SIM
cards out of the reach of small
children.
Illustrations
Always switch the device off and
disconnect the charger before
removing the battery.
1Remove the back cover.
2Lift battery away.
Volume keys
• When the screen is at the Home screen:
Ring tone and touch tone volume.
• During a call: Earpiece volume.
• Down volume key: Press and hold to
activate/ deactivate Silent mode.
Handsfree or Stereo earphone
connector
Power/Lock key
• Short press to turn on/off the screen.
• Long press for power on/off.

TIA Safety Information
The following is the complete TIA Safety
Information for wireless handheld phones.
Antenna Care
Use only the supplied or an approved
replacement antenna. Unauthorized antennas,
modifications, or attachments could damage
the phone and may violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you
would any other telephone with the antenna
pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
Don’t touch the antenna unnecessarily when
the phone is in use. Contact with the antenna
affects call quality and may cause the phone to
operate at a higher power level than otherwise
needed.
Driving
Check the laws and regulations on the use
of wireless phones in the areas where you
drive and always obey them. Also, if using
your phone while driving, please observe the
following:
• Give full attention to driving -- driving safely is
your first responsibility;
• Use hands-free operation, if available;
• Pull off the road and park before making or
answering a call if driving conditions or the
law require it.
Electronic Devices
Most modern electronic equipment is shielded
from RF signals. However, certain electronic
equipment may not be shielded against the RF
signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association
recommends that a minimum separation
of six (6) inches be maintained between a
handheld wireless phone and a pacemaker
to avoid potential interference with the
pacemaker. These recommendations are
consistent with the independent research by
and recommendations ofWirelessTechnology
Research.
Persons with pacemakers:
• Should ALWAYS keep the phone more than
six (6) inches from their pacemaker when the
phone is turned ON;
• Should not carry the phone in a breast pocket;
• Should use the ear opposite the pacemaker to
minimize the potential for interference;
• Should turn the phone OFF immediately if
there is any reason to suspect that interference
is taking place.
Hearing Aids
Some digital wireless phones may interfere
with some hearing aids. In the event of such
interference, you may want to consult your
service provider (or call the customer service
line to discuss alternatives).
Consumer Information on SAR For Your Safety
This phone model meets the government's
requirements for exposure to Radio Waves.
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not
to exceed the emission limits for exposure
to Radio Frequency (RF) energy set by the
Federal Communications Commission of
the U.S. Government. These limits are part
of comprehensive guidelines and establish
permitted levels of RF energy for the general
population.The guidelines are based on
standards that were developed by independent
scientific organizations through periodic and
thorough evaluation of scientific studies. The
standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile
phones employs a unit of measurement known
as the Specific Absorption Rate, or SAR.The
SAR limit set by the FCC is 1.6 W/kg.Tests for
SAR are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level
in all tested frequency bands. Although SAR
is determined at the highest certified power
level, the actual SAR level of the phone while
operating can be well below the maximum
value. Because the phone is designed to operate
at multiple power levels to use only the power
required to reach the network, in general, the
closer you are to a wireless base station antenna,
the lower the power output.
Before a phone model is available for sale to the
public, it must be tested and certified to the FCC
that it does not exceed the limit established by
the government-adopted requirement for safe
exposure. The tests are performed in positions
and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model.
The highest SAR value for this model phone
when tested for use at the ear is 1.08 W/kg
and when worn on the body, as described
in this user guide, is 0.51W/kg (body-worn
measurements differ among phone models,
depending upon available accessories and FCC
requirements). While there may be differences
between SAR levels of various phones and at
various positions, they all meet the government
requirement for safe exposure.
The FCC has granted an Equipment
Authorization for this model phone with all
reported SAR levels evaluated as in compliance
with the FCC RF emission guidelines. SAR
information on this model phone is on file
with the FCC and can be found under the
Display Grant section of http://www.fcc.gov/
oet/fccid after searching on FCC ID BEJLG800G.
Additional information on Specific Absorption
Rates (SAR) can be found on the Cellular
Telecommunications Industry Association (CTIA)
website at http://www.ctia.org.
* In the United States and Canada, the SAR limit
for mobile phones used by the public is 1.6
watts/kg (W/kg) averaged over one gram of
tissue.The standard incorporates a substantial
margin of safety to give additional protection
for the public and to account for any variations
in measurements.
Body-worn Operation
This device has been tested for typical
body-worn operations with the distance
of 0.79inches (2.0cm) from the user’s
body.
To comply with FCC RF exposure
requirements, a minimum separation
distance of 0.79inches(2.0cm) must be
maintained from the user’s body.
For example, this device must be
maintained from the user’s body with
an appropriatebelt-clip accessory.[More
than 0.79inches(2.0cm)]
Additionally, Belt clips, holsters & other
body-worn accessories may not contain
metallic components.
Part 15.21 statement
Change or Modifications that are not
expressly approved by the manufacturer
could void the user’s authority to operate
the equipment.
Part 15.19 statement
This device and its accessories comply
with part 15 of FCC rules. Operation is
subject to the following two conditions:
(1) This device and its accessories
may not cause harmful interference,
and (2) this device and its accessories
must accept any interference received,
including interference that may cause
undesired operation.
Part 15.105 statement
This equipment has been tested and
found to comply with the limits for a class
B digital device, pursuant to Part 15 of the
FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation.
If this equipment does cause harmful
interference or television reception,
which can be determined by turning
the equipment off and on, the user
is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Contacts
Changing your contact settings
You can adapt your contact settings so that your Contacts suits your
own preferences.
Touch Options key and touch Settings.
• Display name - Choose whether to display the first or last name of a
contact first.
• Copy - Copy your contacts from your SIM to Internal memory, or vice
versa.
• Move - This works in the same way as Copy, but the contact is stored at
the new location only. Therefore, once a contact is moved from the SIM
to the Internal memory it will be deleted from the SIM memory.
• Send all contacts via Bluetooth - Sends all contacts to other handset
via Bluetooth.
• Back up contacts/ Restore contacts - Save or restore the contacts data
to the other storage.
• Clear contacts - Delete all your contacts. Touch Yes if you are sure you
want to delete all your contacts.
Messaging
Your LG800G combines SMS and MMS into one intuitive and easy-to-use
menu.
Sending a message
1Touch Messages in menu and touch Create new message to begin
composing a new message.
2Touch Insert to add an image, video, sound, template and so on.
3Touch To at the top of the screen to enter the recipients. Then enter
the number or touch to select a contact. You can even add multiple
contacts.
4Touch Send when ready.
WARNING: If an image, video or sound is added to an SMS it
will be automatically converted to an MMS and you will be charged
accordingly.
Entering Text
You can choose your input method by tapping and Input method.
Touch to turn on T9 mode. This icon is only shown when you choose
Keypad as the input method.
Touch to change between numbers, symbols and text input.
U se Shift key to change between capital or lowercase input.
Handwriting recognition
In Handwriting mode you simply write on the screen and your LG800G
will convert your handwriting into your message.
Camera
Taking a quick photo
1Touch Camera menu.
2When the camera has focused on your subject, touch the on the
right-center of the screen to take a photo.
TIP: To switch to the camera mode or video mode, slide up/down the
camera or video icon on the centre-right of the viewfinder.
Making a quick video
To switch to the camera mode or video mode, slide up/down the camera
or video icon on the right centre of the viewfinder.
1Holding the phone horizontally, point the lens towards the subject of
the video.
2Press the red dot .
3Rec will appear at the bottom of the viewfinder with a timer at the
bottom showing the length of the video.
4To pause the video, touch and resume by selecting .
5Touch on screen to stop video recording.
Music
To access the music player, touch Music. From here, you can access a
number of folders:
Recently played - Plays the songs you have played recently.
All tracks - Contains the songs you have on your phone except the pre-
loaded default music.
Artists - Browse through your music collection by artist.
Albums - Browse through your music collection by album.
Genres - Browse through your music collection by genre.
Playlists - Contains all the playlists you have created.
Shuffle tracks - Play your tracks in a random order.
Transferring music onto your phone
The easiest way to transfer music onto your phone is via Bluetooth or the
data cable.
To transfer music using Bluetooth:
1Make sure both devices have Bluetooth switched on and are
connected to each other.
2Select the music file on the other device and select send via Bluetooth.
3When the file is sent, you will have to accept it on your phone by
touching Yes.
4The file should appear in Music > All tracks.
NOTE:
If the file size is smaller than 300Kb, it will be not displayed in Music
menu.
Settings
Personalising your proles
You can personalise each profile setting.
1Touch Profiles.
2Choose the profile you want to edit.
3You can then change all the sounds and alert options available in the
list, including your Ringtone and Volume, Message tone settings and
more.
Changing your phone settings
Use the freedom of adapting the LG800G to your own preferences.
From the home screen, select and touch Settings then scroll to
Phone.
Sending and receiving your les using Bluetooth
To send a file:
1Open the file you want to send, typically this will be a photo, video or
music file.
2Choose Send via. Choose Bluetooth.
3If you have already paired the Bluetooth device, your LG800G will not
automatically search for other Bluetooth devices. If not, your LG800G
will search for other Bluetooth enabled devices within range.
4Choose the device you want to send the file to.
5Your file will be sent.
Video camera
Settings
To receive a file:
1Your Bluetooth must be both ON and Visible. Visible mode can be
set on for only 3 minutes; for your security. If you want to check your
visibility, select Options and choose Settings.
2A message will prompt you to accept the file from the sender. Touch
Yes to receive the file.
3You will see where the file has been saved. For image files, you can
choose to View the file. Files will usually be saved to the appropriate
folder in My stuff.
TIA Safety Information
• Do not disassemble or open crush, bend or
deform, puncture or shred
• Do not modify or remanufacture, attempt
to insert foreign objects into the battery,
immerse or expose to water or other liquids,
expose to fire, explosion or other hazard.
• Only use the battery for the system for which
it is specified
• Only use the battery with a charging system
that has been qualified with the system per
this standard. Use of an unqualified battery or
charger may present a risk of fire, explosion,
leakage, or other hazard.
• Do not short circuit a battery or allow metallic
conductive objects to contact battery
terminals.
• Replace the battery only with another battery
that has been qualified with the system per
this standard, IEEE-Std-1725-200x. Use of an
unqualified battery may present a risk of fire,
explosion, leakage or other hazard.
• Promptly dispose of used batteries in
accordance with local regulations
• Battery usage by children should be
supervised.
• Avoid dropping the phone or battery. If the
phone or battery is dropped, especially on a
hard surface, and the user suspects damage,
take it to a service center for inspection.
• Improper battery use may result in a fire,
explosion or other hazard.
• For those host devices that utilize a USB port
as a charging source, the host device’s user
manual shall include a statement that the
phone shall only be connected to products
that bear the USB-IF logo or have completed
the USB-IF compliance program.
