LG VX1000 - Migo Cell Phone 8 MB User manual

Your new Migo phone should only be
used by children of an appropriate age
who are capable of using the device
responsibly. Carefully and thoroughly
review the kids' user guide with your
child. It is your responsibility to teach
users how to use the Migo phone and
the emergency calling capability. Any
complaints, penalties or fines assessed
due to excessive or erroneous calls are
your sole responsibility. The Migo
phone is not a child management tool
and is not a substitute for adult
supervision.

IMPORTANT SAFETY PRECAUTIONS
3
IMPORTANT SAFETY PRECAUTIONS
Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is
given in this user guide.
WARNING! Violation of the instructions may cause serious injury or death.
1. Never use an unapproved battery since this could damage the phone and/or battery and could
cause the battery to explode.
2. Never place your phone in a microwave oven as it will cause the battery to explode.
3. Never store your phone in temperatures less than -4°F or greater than 122°F.
4. Do not dispose of your battery by fire or with hazardous or flammable materials.
5. When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If
wireless equipment is improperly installed and the air bag is deployed, you may be seriously
injured.
6. Do not use a hand-held phone while driving.
7. Do not use the phone in areas where its use is prohibited. (For example: aircraft)

IMPORTANT SAFETY PRECAUTIONS
4
IMPORTANT SAFETY PRECAUTIONS
1. Do not expose the battery charger or adapter to direct sunlight or use it in places with high
humidity, such as a bathroom.
2. Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your
phone. This could cause a fire.
3. Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the
phone.
4. Do not use your phone in high explosive areas as the phone may generate sparks.
5. Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it
is loose as it may cause a fire or electric shock.
6. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as
it may cause electric shock or fire.
7. Do not handle the phone with wet hands while it is being charged. It may cause an electric shock
or seriously damage your phone.
8. Do not disassemble the phone.

5
IMPORTANT SAFETY PRECAUTIONS
1. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or
cause electric shock or fire.
2. Do not hold or let the antenna come in contact with your body during a call.
3. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the
battery. This could cause a fire.
4. Store the battery out of reach of children.
5. Be careful that children do not swallow any parts. This could cause asphxiation or suffocation
resulting in serious injury or death.
6. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.
7. Only use the batteries and chargers provided by LG. The warranty will not be applied to products
provided by other suppliers.
8. Only authorized personnel should service the phone and its accessories. Faulty installation or
service may result in accidents and consequently invalidate the warranty.
9. An emergency call can be made only within a service area. For an emergency call, make sure that
you are within a service area and that the phone is turned on.

TABLE OF CONTENTS
TABLE OF CONTENTS
6
IMPORTANT SAFETY
PRECAUTIONS 3
Table of Contents 6
Welcome 7
Important Information 7
Industry Canada Compliance 7
Technical Details 8
FCC RF Exposure Information 9
Phone Overview 11
Getting Started with Your
Phone 12
The Battery 12
Charging the Battery 12
Turning the Phone On and Off 13
Signal Strength 13
Using Phone Menus 15
Entering Menu 15
1 Set Ringtone 15
2 Set Caller ID 15
3 Phonebook 16
Multi-tap Method 16
4 Language 18
+ Emergency # 18
Making Calls 18
Emergency Calls 19
Receiving Calls 19
Incoming Calls 19
Missed Calls 19
Using Speakerphone 19
Helping Your Child Use Migo 19
Safety 20
TIA(Telecommunications
Industry Association) Safety
Information 20
Charger and Adapter Safety 23
Battery Information and Care 23
Safety Information 24
Avoid damage to your
hearing 26
FDA Consumer Update 26
Consumer Information on
SAR 33
ACCESSORIES 35
LIMITED WARRANTY
STATEMENT 36
Some of contents in this user guide maybe different from your phone
depending on the software of the phone or your service provider. Features
and specifications might be subject to change without prior notice.

WELCOME
Thank you for choosing Migo specially designed for
kids.
Migo has the following features:

Kid-Friendly Design.

Simplified Keypad and Interface.

4 Programmable Speed Dial Keys.

Dedicated Emergency Button.

Cute, Compact Design to Fit Small Hands.

Unique, Bright Green Color.

Ultra Lightweight.

Simplified Keypad with Large Keys.

Easy-to-Use User Interface.

Blue Backlit LCD for Caller ID and Missed Calls.

2 Small Antennas.

Side Volume Control Keys.

Headset Jack.
Important Information
This user’s guide provides important information on
the use and operation of your phone. Please read all
the information carefully prior to using the phone for
the best performance and to prevent any damage to
or misuse of the phone. Any unapproved changes or
modifications will void your warranty.
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15
of FCC rules. Operation is subject to the following
two conditions: (1) This device and its accessories
may not cause harmful interference, and (2) this
device and its accessories must accept any
interference received, including interference that
causes undesired operation.
Industry Canada Compliance
This phone complies with Industry Canada RSS 133.
This phone complies with the Class B limits for radio
noise emissions as set out in the interference causing
standard entitled "Digital Apparatus" ICES-003 of
Industry Canada.
WELCOME
7

8
TECHNICAL DETAILS
TECHNICAL DETAILS
Technical Details
The Migo is an all digital phone that operates on
both Code Division Multiple Access (CDMA)
frequencies: cellular services at 800 Mhz and
Personal Communication Services (PCS) at 1.9 Ghz.
CDMA technology uses a feature called DSSS
(Direct Sequence Spread Spectrum) that enables the
phone to keep communication from being crossed
and to use one frequency channel by multiple users
in the same specific area. This results in a 10-fold
capacity increase when compared with analog mode.
In addition, features such as soft / softer handoff,
hard Handoff, and dynamic RF power control
technologies combine to reduce call interruptions.
The Cellular and PCS CDMA networks consist of
MSO (Mobile Switching Office), BSC (Base Station
Controller), BTS (Base station Transmission System),
and MS (Mobile Station).
* TSB -74: Protocol between an IS-95A system and
ANSI J-STD-008
1xRTT system receives twice as many subscribers in
the wireless section as IS-95. Its battery life is twice
as long as IS-95. High-speed data transmission is
also possible.
The following table lists some major CDMA
standards.
CDMA Standard
Basic Air
Interface
TIA/EIA-95A
TSB-74
ANSI J-STD-008
TIA/EIA-IS2000
CDMA Dual-Mode Air Interface
14.4kbps radio link protocol
and inter-band operations
IS-95 adapted for PCS
frequency band CDMA2000
1xRTT Air Interface
MAS-BS
PCSC-RS
Intersystem operations
Non-signaling data comm.
Cellular base station
Cellular mobile station
PCS personal station
PCS base station
Speech CODEC
TIA/EIA/IS-634
TIA/EIA/IS/651
TIA/EIA/IS-41-C
TIA/EIA/IS-124
TIA/EIA/IS-97
TIA/EIA/IS-98
ANSI J-STD-018
ANSI J-STD-019
TIA/EIA/IS-125
TIA/EIA/IS-96-B
TIA/EIA/IS-99
TIA/EIA/IS-637
TIA/EIA/IS-657
IS-801
TIA/EIA/IS-707-A
Speech CODEC
Async Data and Fax
Short message service
Packet Data
Position Determination Service
High Speed Packet Data
Network
Service
Performance
Designator Description

TECHNICAL DETAILS
FCC RF Exposure Information
WARNING! Read this information before operating
the phone.
In August 1996, the Federal Communications
Commission (FCC) of the United States, with its action in
Report and Order FCC 96-326, adopted an updated
safety standard for human exposure to Radio Frequency
(RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the
safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC
guidelines and these international standards.
Bodily Contact During Operation
This device was tested for typical use with the back of the
phone kept 0.6 inches (1.5 cm) from the body. To
comply with FCC RF exposure requirements, a minimum
separation distance of 0.6 inches (1.5 cm) must be
maintained between the user’s body and the back of the
phone, including the antenna, whether extended or
retracted. Third-party belt-clips, holsters and similar
accessories containing metallic components should not
be used. Avoid the use of accessories that cannot
maintain 0.6 inches (1.5 cm) distance between the user’s
body and the back of the phone and have not been
tested for compliance with FCC RF exposure limits.
Vehicle-Mounted External Antenna
(Optional, if available.)
A minimum separation distance of 8 inches (20 cm) must
be maintained between the user / bystander and the
vehicle-mounted external antenna to satisfy FCC RF
exposure requirements. For more information about RF
exposure, visit the FCC website at www.fcc.gov.
Caution
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or
result in violation of FCC and IC regulations.
Do not use the phone with a damaged antenna. If a
damaged antenna comes into contact with the skin a
minor burn may result. Contact your local dealer for a
replacement antenna.
9

What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radiofrequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing the
time or wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a
recommendation in December 2000. They note that
no evidence exists that using a wireless phone causes
brain tumors or other ill effects. Their
recommendation to limit wireless phone use by
children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
TECHNICAL DETAILS
10
WELCOMETECHNICAL DETAILS

PHONE OVERVIEW
11
PHONE OVERVIEW
Headset
Jack
LCD
Screen
Side
Keys
Yes Key
Headset Jack Lets you attach a hands-free headset
(optional accessory) to hear and talk to your callers.
LCD Screen Displays phone status, indicator icons,
time, and date.
Side Keys Use to adjust the ringer volume and the
earpiece volume during a call. Also, if you press long
the side keys, the vibrate only mode turns on/off.
Yes Key Use to answer a call or access the Menu to set
your ringtone, change your phonebook, or set
emergency number.
Number Key Use to add phonebook entries and to
make a call to a phonebook entry.
Metal eyelet Attach a lanyard or carabiner.
Earpiece
No Key
Use to turn the power on/off and to end a call.
Also, in standby mode, press to display the date (after a
few seconds the time reappears). This key is also used to
backspace or delete a incorrectly entered character when
programming a name or a number in the phonebook.
Emergency Key Use for emergency calls. This key is
also used to insert a space between 2 words.
Microphone Lets callers hear you.
Charger port For charger cable.
No Key
Earpiece
Metal
eyelet
Emergency
Key
Microphone
Charger
port
Number
Key

12
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
The Battery
The phone comes with a rechargeable battery. Keep
the battery charged while not in use in order to
maximize talk and standby time. The battery charge
level is shown at the top of the LCD screen.
Installing the Battery
To install the battery, insert the battery into the
opening on the back of the phone. Put the battery
cover on the battery and push it slightly upwards.
Removing the Battery
Turn the power off.
Lift the release latch to detach the battery.
Charging the Battery
To use the charger provided with your phone:
WARNING! Use only the charger provided with the
phone. Using any charger other than the one included
with the Migo may damage your phone or battery.
1. Plug the end of the adapter into the phone’s
charger port and the other end into an electrical
outlet.
2. The charge time varies depending upon the
battery level.
Do not allow minors to install, remove or charge the
battery without parental or custodial assistance.
Fully DischargedFully Charged
Note
It is important to fully charge the battery before
initial use of the phone.

13
GETTING STARTED WITH YOUR PHONE
Turning the Phone On and Off
Turning the Phone On
1. Install a charged battery or connect the phone to
an external power source approved or
manufactured by LG such as a vehicle power
charger or hands-free car kit.
2. Press for a few seconds until the LCD screen
lights up.
Turning the Phone Off
1. Press and hold until the display turns off.
Signal Strength
Call quality depends on the signal strength in your
area. The signal strength is indicated on the screen
as the number of bars next to the signal strength
icon: The more bars, the better the signal strength. If
the signal quality is poor, move to an open area. If
you are in a building, the reception may be better
near a window.
Note
Like any other radio device, avoid any
unnecessary contact with the antenna while
your phone is on.
Note
Battery life and signal strength are 2 significant
factors (among many others) that could affect
the ability of the Migo phone to send/receive
calls.

14
GETTING STARTED WITH YOUR PHONE
GETTING STARTED WITH YOUR PHONE
Screen Icons
When the phone is powered on, the top line of the LCD screen displays icons indicating the status of the phone.
Signal strength indicator. The strength of the signal received
by the phone is indicated by the number of bars displayed.
In use indicator. A call is in progress.
* No icon indicates the phone is in standby mode.
1X Service indicator.
Roaming indicator. The phone is outside of the home service area.
No service indicator. The phone is not receiving a system signal.
Battery indicator. Indicates battery charge level.
Vib Only/ Ring+Vib.
Digital indicator. Digital service is available.
Speakerphone.
LBS indicator. The indicator is displayed all the time except
in roaming status.

USING PHONE MENUS
15
USING PHONE MENUS
Entering Menu
1. Press in standby mode to enter Menu.
2.
Enter Menu? is displayed.
3. Press .
The following 5 menus are listed.
1 Set Ringtone
This menu offers 10 ringtones. Choose
one of them to set it as your ringtone.
1. In standby mode press twice.
2. Press
Set Ringtone .
3. Use the side keys to highlight the sound you want
to hear when your Migo phone rings.
4. Press .
2 Set Caller ID
Caller ID displays the number of the
person calling when your phone rings.
Check with your service provider to ensure they offer
this feature.
1. In standby mode press twice.
2. Press
Set Caller ID .
3. Press , , or depending on
which phonebook entry you want to set with
Caller ID.
4. Use the side keys to highlight the ringtone that
will identify the phonebook entry.
5. Press .
Anytime Caller ID is not identifiable as setup in the
Phonebook, the default ringtone will be played.

3 Phonebook
Lets you enter four phone numbers into
your phonebook to quickly and easily
call these numbers. Use the multitap method shown
on the following page.
1. In standby mode press twice.
2. Press
Phonebook .
3.
Lock Code ???? is displayed.
4. Enter the numbers , , , in that
order.
5. Set Location: , , or .
6. Press one of the numbers, then enter the phone
number for that phonebook entry.
7. Press .
8. Use the number keys to enter a name to go with
the phone number entered.
9. Press .
Multi-tap Method
How to Enter Numbers
Each number key on the handset represents multiple
numbers and characters when pressed.
USING PHONE MENUS
16
USING PHONE MENUS
Note
Be careful when choosing a phonebook location.
If you have already used that location and you
select it again, the new information you enter
overwrites the old with no warning message.
Press
Key Once Twice Three times
1 2 3
4 5 6
7 8 9
0*#

17
USING PHONE MENUS
How to Enter Names
Key to
press Number of times to press key
1 2 3 4 5 6
A B C D E F
1 2 3 4 5 6
G H I J K L
1 2 3 4 5 6 7
M N O P Q R S
1 2 3 4 5 6 7
T U V W X Y Z
Key to press Number of times to press key
3 k6
11k00
11k44
22k55
22k55
22k55
11k11
22k22
11k11
2 k2
* Please wait 2 seconds between each key entry.
Key to press Number of times to press key
1 kM
33kOO
11kTT
22kHH
55kEE
66kRR

4 Language
Allows you to set your favorite language
to either
English or French .
Set the language your child is going to use.
1. In standby mode press twice.
2. Press
Language .
3. Use the side keys to highlight
English or French .
4. Press .
+ Emergency #
You can program this key to any
emergency contact number by
following these instructions (i.e. Mom's answering
service, etc).
1. In standby mode press twice.
2. Press
Emergency # .
3. Press , , , when
Lock Code
????
is displayed.
4. Enter the number you want to set as emergency #.
Making Calls
1. Make sure the phone is turned on. If not, press
for about 3 seconds.
2. Press the number key that corresponds to the
phonebook entry you want to call. The LCD
displays the name of the phonebook entry in the
form of a question.
For example, if you have saved Daddy as
phonebook entry #1, when you press
Call
Daddy?
will be displayed.
3. Press .
4. You will hear the connecting tone through the
earpiece when the call is made.
1
USING PHONE MENUS
18
USING PHONE MENUS

19
USING PHONE MENUS
Emergency Calls
1. In the event of an emergency, press and hold the
emergency key from standby mode.
2. A confirmation message ('
Call Emergency? ') is
displayed to make an emergency call.
3. Press and hold .
Receiving Calls
Incoming Calls
1. When the phone rings or vibrates press to
answer.
2. Press to end the call.
Missed Calls
When a call is missed, the LCD screen displays
Missed Call .
Using Speakerphone
Lets you activate the speakerphone function.
1. Press and hold to activate speakerphone.
"
Speaker On " is displayed briefly. In standby
mode the speakerphone icon is displayed on
the right side of the LCD.
2. Press and hold again to cancel
speakerphone.
Helping Your Child Use Migo
Please read this user guide in order to have a
thorough understanding of the Migo mobile handset.
This will help you guide your child to effectively and
safely use the Migo handset.
Note
and Side Keys ( ) cannot be used to
answer a call.

SAFETY
20
SAFETY
TIA(Telecommunications Industry
Association) Safety Information
The following is the complete TIA Safety Information
for wireless handheld phones.
Exposure to Radio Frequency Signal
Your wireless handheld portable phone is a low power
radio transmitter and receiver. When it is ON, it
receives and also sends out Radio Frequency (RF)
signals. In August, 1996, the Federal Communications
Commissions (FCC) adopted RF exposure guidelines
with safety levels for handheld wireless phones.
Those guidelines are consistent with the safety
standards previously set by both U.S. and
international standards bodies:

ANSI C95.1 (1992) *

NCRP Report 86 (1986)

ICNIRP (1996)

Health Canada, Safety Code 6, 1999.
Those standards were based on comprehensive and
periodic evaluations of the relevant scientific
literature. For example, over 120 scientists, engineers,
and physicians from universities, government health
agencies, and industry reviewed the available body of
research to develop the ANSI Standard (C95.1).
The design of your phone complies with the FCC
guidelines, IC Regulations (and those standards).
Antenna Care
Use only the supplied or an approved replacement
antenna. Unauthoriaed antennas, modifications, or
attachments could damage the phone and may
violate FCC regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would
any other telephone with the antenna pointed up
and over your shoulder.

Tips on Efficient Operation
For your phone to operate most efficiently:
Do not touch the antenna unnecessarily when the
phone is in use. Contact with the antenna affects call
quality and may cause the phone to operate at a
higher power level than otherwise needed.
Driving
Check the laws and regulations on the use of wireless
phones in the areas where you drive and always obey
them. Also, if using your phone while driving, please
observe the following:

Give full attention to driving -- driving safely is
your first responsibility;

Use hands-free operation, if available;

Pull off the road and park before making or answering
a call if driving conditions or the law so require.
Electronic Devices
Most modern electronic equipment is shielded from
RF signals. However, certain electronic equipment
may not be shielded against the RF signals from your
wireless phone.
Pacemakers
The Health Industry Manufacturers Association
recommends that a minimum separation of six inches
be maintained between a handheld wireless phone
and a pacemaker to avoid potential interference with
the pacemaker. These recommendations are
consistent with the independent research by and
recommendations of Wireless Technology Research.
Persons with Pacemakers:

Should ALWAYS keep the phone more than six
inches from their pacemaker when the phone is
turned ON;

Should not carry the phone in a breast pocket;

Should use the ear opposite the pacemaker to
minimize the potential for interference;

Should turn the phone OFF immediately if there is any
reason to suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may want to consult your service provider (or call the
customer service line to discuss alternatives.)
Optional for each phone manufacturer.
21
SAFETY
