LG LSAB009-M16 User manual

OWNER’S MANUAL
LG LED Signage
(LED SCREEN)
Please read the safety information carefully before using this product.
After reading this manual, keep it in an easily accessible location for future reference.
www.lg.com
Copyright © 2022 LG Electronics Inc. All Rights Reserved.
LSAB009-M16
LSAB009-Q16
LSAB009-S16
LSAB009-N16
LSAB009-U16
LSAB009-T16

2
ENGLISH
TABLE OF CONTENTS
SAFETY PRECAUTIONS .............3
-Precautions for the AC Cable and Power...... 4
-Precautions for Moving the Product................ 6
-Precautions for Installing the Product............. 7
-Precautions for Cleaning the Product............. 9
-Precautions for Using the Product................. 10
-Product Disposal ......................................................12
ASSEMBLING AND PREPARING .
.................................................. 13
-Essential Accessories............................................. 13
-Optional Accessories.............................................. 14
-Handling for Protecting LED Package Screen
...........................................................................................15
-Remove Protective Bracket................................17
-Installation Precautions Guide.......................... 19
-Installation Location............................................... 21
-Terminal......................................................................... 23
INSTALLATION GUIDE ............ 24
SETTINGS ................................ 31
-Home ..............................................................................31
-Ez Setting..................................................................... 32
-General ..........................................................................41
-Display............................................................................ 52
-Sound..............................................................................59
-Admin .............................................................................62
CONTENT MANAGER ............. 64
-Web Login.................................................................... 64
-Content Manager.....................................................64
-Group Manager 2.0.................................................71
-Gallery Mode .............................................................. 74
-ScreenShare................................................................ 75
-LG Presenter...............................................................75
MANAGEMENT TOOLS........... 78
-Control Manager ......................................................78
-Picture ID...................................................................... 79
IR CODE ................................... 80
CONTROLLING MULTIPLE
PRODUCTS............................... 82
-Connecting cables ...................................................82
-Communication Parameter................................. 83
-Command Reference List .................................... 84
-Transmission/Reception Protocol.................... 89
MAKING CONNECTIONS...... 117
-Connecting with LAN Cable............................117
-Connecting with AC Cable...............................118
TROUBLESHOOTING............. 120
PRODUCT SPECIFICATIONS. 122

3
ENGLISH
SAFETY PRECAUTIONS
The safety precautions are intended to prevent unexpected danger or harm by helping the user to use the product
safely and for its intended purpose.
WARNING
If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.
CAUTION
If you ignore the caution message, you may be slightly injured or the product may be damaged.
WARNING
Indoor Use Only.

4
ENGLISH
Precautions for the AC Cable and Power
WARNING
• Before using an AC cable, make sure it conforms to the national standards.
• Operate the display only from a power source(i.e. voltage) indicated in the product specification.
-Otherwise the product can be damaged, fire can occur or you may be electrocuted. If you are not sure what type of
power supply you have, consult a certified installation company.
• Be sure to connect the AC cable to a grounded power disconnecting device.
-If you do not you may be electrocuted or injured or the product can be damaged.
• Insert the AC cable securely so that it does not come loose.
-Poor connection may cause a fire or electric shock.
• In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very
dangerous.
-It can cause electric shock.
• Be careful not to place heavy objects (electronic appliances, clothes, etc.) on or step on the AC cable. In addition, do
not bend or pull the AC cable with excessive force.
-Damaged power cords may cause a fire or electric shock.
• Do not connect the AC cable to a power disconnecting device if it has been damaged by a sharp object.
-You may be electrocuted.
• Do not insert a conductor (such as a metal chopstick) into the power disconnecting device while the AC cable is
connected on the other side of the same power disconnecting device. In addition, do not touch the AC cable directly
after removing it from the power disconnecting device.
-You may be electrocuted.

5
ENGLISH
• If water or any foreign substance enters the product, disconnect the AC cable immediately and contact the service
centre.
-Otherwise, this may cause a fire or electric shock due to damage to the product.
• Keep the AC cable away from heating devices.
-The cord coating may melt and cause fire or electric shock.
• Never disassemble, repair, or modify the AC cable.
-This may cause a fire or electric shock.
• As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the
unit is turned off.
• For the power consumption to be zero, the AC cable must be disconnected.
CAUTION
• If there is dust on the AC cable or the power disconnecting device, wipe them clean.
-Overheating due to layers of dust may cause a fire or electric shock.
• If there is moisture on the AC cable or the power disconnecting device, wipe them clean. In addition, do not touch
them if your hands are wet.
-This may cause an electric shock.
• Do not turn the product on or off by connecting or disconnecting the AC cable. In other words, do not use the AC
cable as a switch.
-This may cause an electric shock or product malfunction.
• Do not disconnect the AC cable while using the product.
-Electrical shock can damage the product.

6
ENGLISH
Precautions for Moving the Product
WARNING
• Contact the service centre before moving the product.
-It may cause electric shock and damage the product.
• Make sure the product is turned off, unplugged, and all cables have been removed before the product is moved.
-You may be electrocuted or the product can be damaged.
• When moving the product, do not shock or cause an impact on the front panel.
-You may be electrocuted or the product can be damaged.
• Usethecorrectnumberofpeopleaccordingtotheweightoftheproduct.(Under25kgperpersonuselifting
equipmentwhenexceeding100kg)
-If use the damaged product again, contact the service centre because it can cause electric shock or fire.
• Do not hold it upside down while holding only the stand. (It is for stand supported models only.)
-This may cause stand warping, panel damage and other types of product damage.
CAUTION
• Do not dispose of the product-packing box. Use it when moving by putting the product in the box to carry it.

7
ENGLISH
Precautions for Installing the Product
WARNING
• Contact the service centre before installing the product.
-It can cause electric shock and damage the product.
• Do not drop an object on or impact on the product. Keep out of reach of children and do not place toys or objects
near the product to prevent throwing things on the product screen.
-It can cause injury to human, problem to product and damage the display.
• Do not put heavy objects on, or hang from, the product.
-If the product collapses or is dropped, you may be injured.
• Do not touch the surface of the product if it overheats.
-It can cause injury to human.
• Install the product firmly fixed on a floor, wall, etc. to prepare against external impact such as wind and earthquake.
-You must refer to the manual provided.
• Prevent Children from climbing or hanging on the product.
-If the product collapses or is dropped, you may be injured.
• Do not install it where there are heating devices such as electrical heaters or lighting equipment.
-Fire, electrical shock, malfunction may occur.
• Do not install this product by yourself as you may injure yourself or cause damage to the product. Please contact
service engineer authorised by service centre.
• Do not install this product on a wall if it could be exposed to oil or oil mist.
-This may damage the product and cause it to fall.
• Do not leave the AC cable, signal cables, etc. in one’s walking path.
-This could cause a trip or fall, which could cause an electrical shock, fire, product breakdown, or injury.
• Do not let the product drop when connecting it to an external device connected with a short cable.
-This may cause injury and damage to the product.
• If you dropped the product or the case is broken, turn off the product and unplug the power cord and contact the
service centre.
-If you continue to use without taking proper measures, electrical shock or fire can occur.
• Install the product in a dry place where it is not near dust and water. Avoid high temperatures and humidity.
-This may cause electrical shock, fire or product damage.
• Safely install the product in a place that can hold the weight of the product.
-A lack of strength may cause the product to fall.
• Take a comfortable and natural position to relax the muscles when working with a product.
• A readily accessible disconnect device shall be incorporated external to the equipment. The maximum rating of an
overcurrent protective device to be provided external to the equipment may be one of the protective device ratings
available in the country of installation.

8
ENGLISH
CAUTION
• Install the product where no Electromagnetic Interference occurs.
• If you install the product in a place that does not meet the recommended conditions, this may cause serious damage
to the product’s picture quality, life cycle, and appearance. Please check with service engineer before installing. Please
do not install the product in places such as where there is an abundance of fine dust or oil mist, chemical substances
are used, exposed to direct sunlight, the temperature is very high or low, the humidity is very high.
• MakesuretheproductiswellventilatedbyInstallingatadistance(100mmormore)fromthewall.
-If you install the product too close to the wall, it may be deformed or fire can break out due to internal heat buildup.
• When the AC cable is connected, make sure that the vents are not blocked by tablecloths, curtains, or other objects
(such as plastic).
-The product can be deformed or fire can break out due to overheating inside the product.
• Do not install the product in an area with poor ventilation (e.g. on a bookshelf, in a closet) or outside and avoid placing
on cushions or carpets.
-The product could catch fire due to overheating inside the product.
• Install the product on a flat and stable place that is large enough to support the product.
-If the product is dropped, you may be injured or the product may be broken.
• When installing the product on a shelf or cabinet, make sure that the bottom end of the product is not protruding
forward.
-The product may fall due to unbalanced centre of gravity, which may cause personal injury or damage to the
product. Be sure to use cabinets or shelves that fit your product.

9
ENGLISH
Precautions for Cleaning the Product
WARNING
• Keep the product clean at all times.
-If you don’t clean the unit for a long time and it becomes covered in dust, it can cause fire or product damage.
• When you need to clean the inside of the product, you must contact the service centre.
-Otherwise, cleaning without support may cause a fire, electric shock, or damage to the product.
• When cleaning the product, disconnect the AC cable and wipe it gently with a soft cloth to prevent scratches.
-An electric shock may occur or damage to the screen if its scratched.
• Do not physically come in contact with the screen of the LED Package.
-This may cause damage to the product.
• To clean the product, use an air gun to lightly remove dust from the front frame and the screen.
-If there are foreign substances in between the LEDs on the screen, it may cause a defect on the screen.
CAUTION
• When cleaning the product or the screen, unplug the power cord and wipe it gently with a soft cloth. Do not spray
water or other liquids directly on the product. Especially, do not clean your product with chemicals including glass
cleaner, any type of air freshener, insecticide, lubricants, wax (car, industrial), abrasive, thinner, benzene, alcohol, etc.,
which can damage the product or its panel.
-This may result in fire, electric shock or product damage (deformation, corrosion or breakage).

10
ENGLISH
Precautions for Using the Product
WARNING
• Do not use the product in any environment with excessively high temperatures or humidity.
• If you use the product for a long period of time, take a rest from time to time to protect your vision.
-Extended viewing could result in impaired vision.
• Listening at high volume or using for a long time can cause damage to your hearing.
• If water or any foreign substance enters a unit, turn off the unit, disconnect it from the AC cable, and contact the
service centre.
-Otherwise, the product may cause fire or electric shock.
• In the event that no image appears on the screen or no sound is heard, stop using the product. Disconnect the AC
cable from the power disconnecting device immediately and contact the service centre.
-Otherwise, the product may cause fire or electric shock.
• Do not drop an object or impact on the product or screen.
-It can cause injury to human, problem to product and damage the screen.
• If there is smoke or a strange sound or smell, disconnect the AC cable and contact the service centre.
-If you continue to use the product without taking proper measures, it may cause electrical shock or fire.
• Do not attempt to disassemble, repair or modify the product yourself. Please contact service centre if you need to
repair it.
-Fire or electric shock can occur.
• Do not place objects filled with liquids such as vases, cups etc. on or over the product to prevent liquid from entering
the product.
-Failure to do so may result in fire, electric shock, malfunction or deformation.
• The product must be installed in an environment out of human reach. If a person touches the product, its
performance may deteriorate. If the product needs to be installed in a place where human contact with the product is
likely, a separate measure to prevent people from touching it needs to be taken.
• Do not push hard on or scratch the product’s surface with your hands or sharp objects, such as nails, pencils or pens.
Do not shock or scratch the front and sides of the screen with metallic objects.
-This may damage the products and cause it to malfunction.
• Do not touch the product if it has been exposed to sunlight or an intense light because it could be hot.
