LG ON2D User manual

Top panel
a 1(Standby)
Turns the power on or off.
bUSB Port
You can play MP3 les by connecting the USB device.
c Display window
dF (Function)
Selects the function and input source.
eB(Open/Close)
Opens and closes the disc tray.
C/V (Skip/Scan)
- Skips backward or forward.
- Scans for a section within a track/file/chapter.
- Selects the radio stations.
Z(Stop)
Stops playback.
VOL (Volume) -/+
Adjusts speaker volume.
N(Play/Pause)
Starts or pauses playback.
fMIC VOL (Microphone volume) -/+
Adjust microphone volume.
MIC (Microphone) ECHO -/+
Adjusts microphone echo level.
BASS -/+
Adjusts bass level.
EQ
Chooses sound impressions.
f
a
bcd
e
Front panel / Rear panel
aRemote sensor
bDisc tray
cPower cord
dSERVICE ONLY: S/W download connector.
eHDMI OUT TO TV: Connect to TV.
fANTENNA FM
gAUX IN (L/R): Connect an auxiliary device.
hMIC (Microphone) 1/2: Connect a microphone.
cdefgh
a
b
HDMI Connection :
Connect with the Unit and TV using HDMI .
a
Connect the Unit to the TV using HDMI cable.
b
Set the input selector to HDMI on the TV.
c
Follow the instructions on the TV screen using
remote control.
Home menu appears on the TV screen. Enjoy various
functions on the player.
Home menu only appears on DVD.CD function.
TV Connection1 Home Menu2
Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 300.0 mm x
390.0 mm x 324.0 mm
Bus Power Supply (USB) 5 V 0500 mA
Design and specications are subject to change without
notice.
Replacement of battery
ENGLISH
www.lg.com
Copyright © 2020 LG Electronics Inc. All Rights Reserved.2004_Rev01
SIMPLE MANUAL
DVD Mini
Hi-Fi Audio
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may
differ from your unit.
MODEL
ON2D
MFL71714706
ON2D-F.EPERLLK_SIM_ENG_SPA(MEX)_MFL71714706.indd 1-4 2020-05-12  8:20:13
